Sunricher SR-2802 User manual

RF Single Color Remote Controller 09.02802.04111
Note:Before the first use, please remove the protective film on the battery.
Function introduction
Important: Read All Instructions Prior to Installation
Output RF signal
Operation Frequency 868/915/434MHz
Operating temperature 0-40°C
Relative humidity 8% to 80%
Dimensions 136.3x38.9x10.7mm
Front side
Back side
• Control 10 zones of receivers separately
• Single color controller
• Compatible with all universal series RF receivers
• 1 receiver can be paired by max 8 different remote controls.
• Waterproof grade: IP20
Product Data
• This device contains a button lithium battery that shall be stored and disposed properly.
• DO NOT expose the device to moisture.
Safety & Warnings
Power Supply 3V(1xCR2025 battery)
Click to turn on/off,
Press and hold down to increase/
decrease light intensity
1 2
3 4
5 6
7 8
9 10
Each button controls one zone of
receiver separately
Pair with RF receiver
Step 3:Choose one zone and click of the zone(e.g. zone 10),
LED lights connected with the RF receiver flicker once means the receiver is
paired with zone 10 successfully.
Step 2:Click the “Learning Key” button on RF receiver to set it into pairing status
Note: one receiver can be paired with max 8 remote controls.
Learning Key
RF LED Receiver
Step 1:Do wiring the RF receiver according to wiring diagram(please refer to the
instruction of RF receiver that you would like to pair with.
After pairing, click or hold of 1/2/3/4/5/6/7/8/9/10 to control each zone separately
1 2
3 4
5 6
7 8
9 10

If you use multiple receivers, you have two choices:
Option 1: have all the receivers in the same zone, like zone 1
Lear ning K ey
RF LED Re ceive r
Zone 1
Option 2: have each receiver in a different zone, like zone 1, 2, 3 or 4
Zone 1 Zone 2 Zone 3
RF remote
RF remote
Lear ning K ey
RF LED Re ceive r
Lear ning K ey
RF LED Re ceive r
Lear ning K ey
RF LED Re ceive r
Lear ning K ey
RF LED Re ceive r
1 2
3 4
5 6
7 8
9 10
1 2
3 4
5 6
7 8
9 10
