Sunrise Medical JAY Basic User manual

O w n e r ’ s a n u a l
Jay®Basic Back
a n u a l d e
i n s t r u c c i o n e s
Respaldo Jay®Basic
a n u e l
d ’ i n s t r u c t i o n s
Dossier Jay®Basic
B a s i c B a c k
Improving People’s Lives
I PORTANT CONSU ER INFO
Notice: This packet contains instructions that must be passed on to
the user of this product. Please do not detach this packet before
delivery to the end user.
INFOR ACIÓN I PORTANTE PARA EL CONSU IDOR
Aviso: Este paquete contiene instrucciones importantes que deben
ser entregadas al usuario de este producto. Por favor no retire este
paquete antes de la entrega al usuario final.
INFOR ATIONS I PORTANTES POUR LE
CONSO ATEUR
Avis : Cette pochette contient des instructions importantes qui
doivent être communiquées à l’utilisateur de ce produit. Prière de ne
pas retirer cette pochette avant de remettre le produit à l’utilisateur.
Warranty Registration:
To validate the warranty on this product, please complete and
return the postcard attached to the enclosed instruction and war-
ranty booklet.
Registro de la garantía:
Para validar la garantía de este producto, favor de llenar y devolver
la tarjeta que se adjunta en el folleto de instrucciones y garantía
que se incluye.
Enregistrement de la garantie :
Pour valider la garantie de ce produit, veuillez compléter et
retourner la carte postale accompagnant les instructions et le livret
de garantie ci-joints.
932165RevB New Basic Back.qxd:Layo t 1 8/20/08 11:57 AM Page 1

932165 Rev. B 2
TABLE OF CONTENTS
Introduction ...................................................... 3
Determining Attachment Mechanism............... 3
Maintenance and Cleaning ................................ 4
Jay Basic with Strap Attachment....................... 5
Installation ................................................ 5
Adjustment............................................... 5
Jay Basic with Clamp Hardware ....................... 6
Installation ................................................ 6
Adjustment............................................... 7
Warranty ........................................................... 8
CONTENIDO
Introducción...................................................... 8
Determinación del mecanismo de fijación........ 8
Mantenimiento y limpieza................................. 9
Respaldo Jay Basic Back con fijación de correa 10
Instalación................................................. 10
Ajuste ....................................................... 10
Respaldo Jay Basic Back con abrazadera........... 11
Instalación................................................. 11
Ajuste ....................................................... 12
Garantia .......................................................... 20
TABLE DES ATIÈRES
Introduction ...................................................... 13
Détermination du mécanisme d’attache........... 13
Entretien et nettoyage ...................................... 14
Dossier Jay Basic à sangle de retenue............... 15
Installation ................................................ 15
Réglage..................................................... 15
Dossier Jay Basic Back à collier de serrage....... 16
Installation ................................................ 16
Réglage..................................................... 17
Garantie .......................................................... 20
932165RevB New Basic Back.qxd:Layo t 1 8/20/08 11:57 AM Page 2

932165 Rev. B
3
ENGLISH
INTRODUCTION
WARNING
Installing a back support on a wheelchair may affect the
center of gravity of the wheelchair and may cause the
wheelchair to tip backwards potentially resulting in injury.
Always assess for the potential need for anti-tippers or
amputee axle adapter brackets to be added to the
wheelchair to help increase stability.
WARNING
Do not use the back to push or lift wheelchair.
Improper use may cause the back to unexpectedly
detach from the wheelchair.
Sunrise edical recommends that a clinician such as a doctor
or therapist experienced in seating and positioning be con-
sulted to determine if a Basic Back is appropriate. Backs
should only be installed by an authorized Sunrise edical
supplier.
THE JAY BASIC BACK
The Jay Basic Back is designed to provide the important benefits of
a proper back support for a wide variety of users. It is designed to
provide simple, comfortable and effective support to help maximize
function and increase sitting tolerance. In addition, it is lightweight,
durable and easy to use.
aximum user weight: 250 lbs. (113 kg).
DETERMINING AT TACHMENT MECHANISM
Please read the following instructions before beginning installation.
The Basic Back Comes in Two Variations
1. Basic Back with Shell and Strap Attachment
2. Basic Back with Clamp Hardware
Installation, adjustment and cleaning procedures differ depending
on the version of the Basic Back you use. Use the figure to the
right to determine which version of the Basic Back you are using.
Clamp Hardware Strap Attachment
932165RevB New Basic Back.qxd:Layo t 1 8/20/08 11:57 AM Page 3

932165 Rev. B 4
ENGLISH
MAINTENANCE AND CLEANING
AINTENANCE
Sunrise recommends that all fasteners be checked for wear, such as
loose bolts or broken components every 6 months. oose fasteners
should be retightened according to the installation instructions. All
fasteners should be tightened to torque specifications as stated in
the hardware installation section. Contact your authorized Sunrise
Medical supplier immediately to replace any broken components.
Do not continue to use the system after identifying loose or broken
components.
EASY CLEANING
1. CLA P HARDWARE VERSIONS
Remove back from the wheelchair. Detach foam and cover from alu-
minum shell. ocate the zipper on bottom of cover and unzip.
Remove foam and turn cover inside out. Zip cover closed to avoid
snagging. Machine wash cover in warm water (60°C). Drip or Tumble
dry on low heat. Reinsert the foam inside the cover and zip the cover
closed.
NOTE: Do not ry clean covers or use in ustrial washers an ryers to clean
cover. Do not steam autoclave. Do not bleach.
To clean back shell:
Shell may be wiped clean with soap and water. No other mainte-
nance should be required.
2. STRAP & SUPPORT VERSION
oosen straps and remove back from the wheelchair. ocate the
zipper on bottom of cover and unzip. Remove foam and plastic
support shell and turn cover inside out. Zip cover closed to avoid
snagging. Machine wash cover in warm water (60°C). Drip or tum-
ble dry on low heat. Reinsert the foam and support shell inside the
cover and zip the cover closed.
NOTE: Do not ry clean covers or use in ustrial washers an ryers to clean
cover. Do not steam autoclave. Do not bleach.
NOTE– The ABS plastic support shell is esigne to be place insi e the
cover to provi e a itional support to the back.
To clean back shell:
Shell may be wiped clean with soap and water. No other mainte-
nance should be required.
If you have any additional questions regarding cleaning procedures,
please contact your authorized Sunrise Medical dealer.
Laundry Care Symbols
Machine wash in warm water
(60° C)
Only non-chlorine bleach,
when needed
Drip dry
Do not iron
Do not dry clean
932165RevB New Basic Back.qxd:Layo t 1 8/20/08 11:57 AM Page 4

932165 Rev. B
5
ENGLISH
JAY B AS IC BACK WITH STRAP AT TACHMENT
INSTALLING THE BASIC BACK WITH
STRAP ATTACH ENT
To install the Jay Basic Back, it is best to begin without a user in the
wheelchair.
The Strap Attachment version of the Basic Back is mounted over or
on top of the standard sling upholstery that typically is shipped on
most wheelchairs. For this version, do not remove sling upholstery.
1. oosen both left and right straps (Fig. 1-A).
2. Slide straps over both back canes.
3. Secure the back by tightening the straps.
Removal
1. Remove back by unsnapping the plastic buckles on each side
(B).
2. ift the back off the chair.
ADJUSTING THE BASIC BACK WITH
STRAP ATTACH ENT
Width Adjustment (Fig. 2)
1. oosen straps to match the width of the back canes.
2. Slide straps over both back canes.
3. Secure the back by tightening the straps.
Height and Depth Adjustment
The strap version of the Basic Back does not offer height or depth
adjustment capabilities.
Figure 1
Figure 2
AB
932165RevB New Basic Back.qxd:Layo t 1 8/20/08 11:57 AM Page 5

932165 Rev. B 6
ENGLISH
JAY BASIC BACK WITH CL AMP HARDWARE
INSTALLING THE BASIC BACK WITH
CLA P HARDWARE
To install the Jay Basic Back, it is best to begin without a user in the
wheelchair.
1. Remove sling upholstery from wheelchair according to the
wheelchair manufacturers instructions.
2. If an aftermarket cushion is going to be used on the chair,
ensure that it is placed on the wheelchair to ensure proper
back height placement.
3. Visually determine the desired location of the receivers on
the wheelchair’s back canes. The mounting hardware should
be at approximately equal heights on each back post (Fig. 3)
and parallel to the seat frame (Fig. 4).
4. Attach the hardware receivers by removing the screws (Fig.
5-A) and wrapping the hinge around the wheelchair back-
canes.
NOTE– Two sets of screws are inclu e with the Jay Basic Back. For smaller
7/8" tubing, use the shorter screws. For wi er 1" tubing, use the
longer screws.
NOTE– The hinge an the tapere attachment must be aligne when
assembling screws.
Reattach and tighten the screws enough to the secure the
bracket in place. Note that the tapered attachment point
should be facing upwards (B) and the hinge should be facing
forward (C).
NOTE– For 7/8” tubing, place pin in slot D (Fig. 5).
For 1” tubing, place pin in slot E (Fig. 5).
5. Tighten bracket screws (A) using a 4mm hex key (included
with Basic Back). Note: Back height may require additional
adjustment to ensure proper fit to the user.
6. Align the back shell to the mounting hardware, if the width of
the shell-side hardware needs adjustment, please reference
the adjustment section.
7. Attach the back shell to the mounting hardware by raising
the shell horizontally and lower onto mounting hardware
(Fig. 6). Once the shell is seated properly on the hardware
rotate the shell bottom so that the back shell is in a vertical
position (Fig. 7).
8. Test that the attachment is aligned properly by removing and
re-attaching the back shell. Proper alignment of the mounting
hardware and back is achieved when the back can be
smoothly attached and released.
9. If proper alignment has not been achieved, adjust the compo-
nents (according to step #3) until properly aligned.
10. Once properly aligned, tighten the hardware receiver clamp
screws (Fig. 5-A). The recommended torque specification is
15-20 in-lbs. (1.7- 2.3 Nm).
Figure 3
Figure 4
parallel
equal
Figure 5
A
B
rear
of chair
front
of chair
Figure 6
Figure 7
C
D
E
932165RevB New Basic Back.qxd:Layo t 1 8/20/08 11:57 AM Page 6

932165 Rev. B
7
ENGLISH
JAY BASIC BACK WITH CL AMP HARDWARE
ADJUSTING THE BASIC BACK WITH
CLA P HARDWARE
1. Height Adjustment (Fig. 8)
1. oosen the clamp screws on the chair side mounting hard-
ware (A) and slide along the back canes until the desired
height is reached. The mounting hardware should be at
approximately equal heights on each back post (Fig 3) and
parallel to the seat frame (Fig. 4).
2. Securely tighten the clamp screws (A). The recommended
torque specification is 15 - 20 in-lbs (1.7 - 2.3 Nm).
Additional Height
If additional height is needed, change the position of the
shell-side hardware by loosening nuts (Fig. 12-E) and placing
upper or lower hardware in optional holes (Fig. 9-B).
Securely tighten the chair-side mounting hardware. The recom-
mended torque specification is 75 - 85 in-lbs (8.5 - 9.6 Nm).
Reattach back shell to chair side mounting hardware.
2. Angle Adjustment
The Basic Back offers up to 10 degrees of angle with limited seat
depth loss.
1. Detach the back shell from the mounting hardware.
2. Remove the left and right socket head screws (Fig. 10-C) on
the chair side mounting hardware.
3. Adjust the angle by moving the tapered pin (Fig. 10-D) forward
or backward in the bracket as shown in Fig. 11. Securely tight-
en the socket head screws. The recommended torque specifi-
cation is 15 - 20 in-lbs (1.7 - 2.3 Nm).
4. As the back angle is adjusted, also adjust the angle of the
tapered pin to match (Fig. 11, inset G). The recommended
torque specification is 15 - 20 in-lbs (1.7 - 2.3 Nm).
To minimize seat depth loss, place the lower mounting hardware
(F) in a lower mounting hole as seen in Fig. 13. The recommended
torque specification is 25-30 in-lbs (2.8 - 3.4 Nm).
3. Width Adjustment (Fig. 12)
1. oosen nuts (Fig. 12-E) using a 7/16” wrench.
2. Slide hardware horizontally until the appropriate width is
achieved. The appropriate width allows for attaching to the
chair-side mounting hardware.
NOTE– Wi th can be a juste +1” to allow a smaller back to be mounte
on wi er back canes.
3. Secure the width nuts. The recommended torque specifica-
tion is 75-85 in-lbs.
Figure 8
A
Figure 9
B
Figure 12
E
Figure 13
F
Figure 11
Figure 10
C
D
G
932165RevB New Basic Back.qxd:Layo t 1 8/20/08 11:57 AM Page 7

932165 Rev. B 8
ESPAÑOL
INTRODUCCIÓN
ADVERTENCIA
Instalar un respaldo en la silla de ruedas puede afectar el
centro de gravedad de la misma y puede provocar que la
silla de ruedas se vuelque hacia atrás, provocando lesiones
potenciales.
Evalúe siempre la necesidad de instalar en la silla de ruedas
tubos antivolcaduras o abrazaderas adaptadoras del eje
para amputados para ayudar a aumentar la estabilidad.
ADVERTENCIA
No use el respaldo para empujar o levantar la silla de
ruedas. El uso inapropiado puede provocar que el
respaldo se desprenda inesperadamente de la silla de
ruedas.
Sunrise edical recomienda que consulte a un profesional
clínico, por ejemplo, un médico o terapeuta, que cuente con
experiencia en el sentado y posicionamiento del paciente
para que determine si el respaldo Basic Back es adecuado.
Los respaldos sólo deben ser instalados por un proveedor
autorizado Sunrise edical.
RESPALDO JAY BASIC BACK
El respaldo Jay Basic Back ha sido diseñado para ofrecer a una
amplia gama de usuarios los beneficios importantes de un soporte
adecuado de la espalda. Ha sido diseñado para proveer un apoyo
sencillo, cómodo y eficaz para maximizar las funciones e incremen-
tar el tiempo de tolerancia al estar sentado. Además, es liviano,
duradero y fácil de usar.
Peso máximo del usuario: 113 kg (250 lbs).
DETERMINACIÓN DEL MECANISMO DE FIJACIÓN
Antes de comenzar la instalación, favor de leer las instrucciones
siguientes.
El respaldo Basic Back viene en dos versiones
1. Respaldo Basic Back con fijación de alojamiento y correa
2. Respaldo Basic Back con abrazadera
a instalación, el ajuste y los procedimientos de limpieza son difer-
entes de acuerdo a la versión del respaldo Basic Back que utiliza.
Consulte la figura de la derecha para determinar qué versión de
respaldo Basic Back está utilizando.
Abrazadera Fijación de correa
932165RevB New Basic Back.qxd:Layo t 1 8/20/08 11:57 AM Page 8

932165 Rev. B
9
ESPAÑOL
MANTENIMIENTO Y LIMPIEZA
ANTENI IENTO
Sunrise recomienda revisar todos los sujetadores cada 6 meses en
busca de desgaste, por ejemplo, pernos sueltos o componentes
rotos. os sujetadores sueltos deben volverse a ajustar de acuerdo
a las instrucciones de instalación. Todos los sujetadores deben apre-
tarse de acuerdo a las especificaciones de tensión estipuladas en la
sección de instalación de accesorios. Comuníquese con el provee-
dor autorizado Sunrise Medical de inmediato para reemplazar los
componentes rotos. No debe continuar utilizando la silla de ruedas
después de identificar componentes sueltos o rotos.
LI PIEZA FÁCIL
1. VERSIONES CON ABRAZADERA
Retire el respaldo de la silla de ruedas. Quite la cubierta y la base
de espuma del alojamiento de aluminio. Ubique el cierre de cre-
mallera en la parte inferior de la cubierta y ábralo. Quite la base de
espuma y voltee la cubierta para que el interior quede por fuera.
Cierre la cremallera de la cubierta para evitar que la tela se
enganche. ave la cubierta a máquina con agua caliente (60°C).
Seque colgando o en máquina con calor bajo. Vuelva a instalar la
base de espuma dentro de la cubierta y cierre la cremallera.
NOTA: No limpie las cubiertas en tintorería ni use lava oras y seca oras
in ustriales. No las meta en autoclave e vapor. No use cloro.
Para limpiar el alojamiento del respaldo:
Puede limpiarse con un paño con agua y jabón. No necesita ningún
otro tipo de mantenimiento.
2. VERSIONES DE CORREA Y SOPORTE
Afloje las correas y retire el respaldo de la silla de ruedas. Ubique
el cierre de cremallera en la parte inferior de la cubierta y ábralo.
Quite la base de espuma y el alojamiento plástico de soporte, y
voltee la cubierta para que el interior quede por fuera. Cierre la
cremallera de la cubierta para evitar que la tela se enganche. ave
la cubierta a máquina con agua caliente (60°C). Seque colgando o
en máquina con calor bajo. Vuelva a instalar la base de espuma y el
alojamiento de soporte dentro de la cubierta y cierre la cremallera.
NOTA: No limpie las cubiertas en tintorería ni use lava oras y seca oras
in ustriales. No las meta en autoclave e vapor. No use cloro.
NOTA: El alojamiento e soporte plástico ABS ha si o iseña o para ser
coloca o entro e la cubierta y ofrecer apoyo a icional a la espal a.
Para limpiar el alojamiento del respaldo:
Puede limpiarse con un paño con agua y jabón. No necesita ningún
otro tipo de mantenimiento.
Si tiene más preguntas sobre los procedimientos de limpieza, favor
de comunicarse con el distribuidor autorizado Sunrise Medical.
Símbolos de cuidados de lavado
avar a máquina con agua
caliente (60°C).
Usar sólo blanqueador sin
cloro cuando sea necesario
Secar colgado
No planchar
No limpiar en tintorería
932165RevB New Basic Back.qxd:Layo t 1 8/20/08 11:57 AM Page 9

932165 Rev. B 10
ESPAÑOL
RESPALDO JAY BASIC CON FIJACIÓN DE CORREA
INSTALACIÓN DEL RESPALDO BASIC CON
FIJACIÓN DE CORREA
Para instalar el respaldo Jay Basic Back debe comenzar la instalación
sin el usuario sentado en la silla de ruedas.
a versión con fijación de correa del respaldo Basic Back se monta
por encima o sobre la parte superior de la tapicería estándar de
eslinga con la cual se envían la mayoría de sillas de ruedas. Para esta
versión, no retire la tapicería de eslinga.
1. Afloje las correas de la izquierda y la derecha (Fig. 1-A).
2. Deslice las correas sobre ambos bastones.
3. Fije el respaldo apretando ambas correas.
Remoción
1. Retire el respaldo soltando las hebillas plásticas de cada lado
(B).
2. evante y saque el respaldo de la silla.
AJUSTE DEL RESPALDO BASIC CON
FIJACIÓN DE CORREA
Ajuste del ancho (Fig. 2)
1. Afloje las correas para que correspondan al ancho de los
bastones.
2. Deslice las correas sobre ambos bastones.
3. Fije el respaldo apretando ambas correas.
Ajuste de la altura y profundidad
a versión del respaldo Basic Back de correa no incluye el ajuste de
la altura y profundidad.
Figura 1
Figura 2
AB
932165RevB New Basic Back.qxd:Layo t 1 8/20/08 11:57 AM Page 10
