Sunrise Medical Quickie Nitrum User manual

Supplier: This manual must be given to the rider of this
wheelchair.
Rider: Before using this wheelchair read this entire
manual and save for future reference.
Nitrum Instructions for Use
P/N 249817 Rev. A
Distribuidor: Este manual debe ser entregado al pasajero de
esta silla de ruedas.
Pasajero: Antes de usar esta silla de ruedas, lea este manual
en su totalidad y guárdelo para futura referencia.
Cada una de las sillas se envía con un manual de instrucciones en inglés. El manual en español
• francés está disponible en formato PDF en nuestra página en Internet:
www.SunriseMedical.com. Ingrese a la página del producto específico para descargar el
manual,
• comuníquese con el proveedor autorizado de Sunrise Medical.
Au Fournisseur: Ce manuel doit être remis à l’usager de ce fauteuil
roulant.
À l’Usager: Veuillez lire tout le manuel et le conserver pour
référence ultérieure.
Chaque fauteuil est livré avec un manuel d’instructions en anglais. Les versions en espagnol et en
français sont à votre disposition en format PDF sur le site : www.SunriseMedical.com. Veuillez vous rendre
à la page de votre produit pour télécharger le manuel dans la langue souhaitée, ou contactez un
fournisseur agréé Sunrise Medical.
Owner’s Manual
Manual de
Instrucciones
Manuel
d ’instructions
Quickie ®NITRUM
Quickie ®NITRUM
Quickie ®NITRUM

Quickie ®NITRUM
249817 Rev. A 2
I. INTRODUCTION
SUNRISE MEDICAL LISTENS
Thank you for choosing a Quickie wheelchair. We want to hear your questions
or comments about this manual, the safety and reliability of your chair, and the
service you receive from your Sunrise dealer. Please feel free to write or call us at
the address and telephone number below:
SUNRISE MEDICAL (US) LLC
Customer Service Department
2842 N. Business Park Avenue
Fresno, CA 93727 USA
[phone]
Be sure to return your warranty card, and let us know if you change your
address. This will allow us to keep you up to date with information about safety,
new products and options to increase your use and enjoyment of the wheelchair. If
you lose your warranty card, call or write and we will gladly send you a new one.
You can also register your product at:
www.sunrisemedical.com/register
FOR ANSWERS TO YOUR QUESTIONS
Your authorized dealer knows your wheelchair best, and can answer most of your
questions about chair safety, use and maintenance.
For future reference, please fill in the following:
Dealer: ______________________________________________________
Address: _____________________________________________________
Telephone: __________________________________________________
Serial #: ____________________ Date/Purchased: _______________
ADDITIONAL INFORMATION YOU SHOULD KNOW
No component of this chair was made with Natural Rubber Latex.
www.sunrisemedical.com/register
DISPOSAL AND RECYCLING INFORMATION
When this product reaches the end of its life, please take it to an
approved collection or recyling point designated by your local or state
government. This product is manufactured using a variety of materials.
Your product should not be disposed of as ordinary household waste. You should dispose
of your product properly, according to local laws and regulations. Most materials that are
used in the construction of this product are fully recyclable. The separate collection and
recyling of your product at the time of disposal will help conserve natural resources and
ensure that it is disposed in a manner that protects the environment.
Ensure you are the legal owner of the product prior to arranging for the product disposal
in accordance with the above recommendations.

Quickie ®NITRUM
249817 Rev. A3
II. TABLE OF CONTENTS
I. INTRODUCTION.......................................................................................2
II. TABLE OF CONTENTS............................................................................3
III. YOUR UNIT AND ITS PARTS...............................................................4
IV. NOTICE — READ BEFORE USE.........................................................4
A. Choose the Right Chair & Safety Options .................................4
B. Review This Manual Often.................................................................4
C. Warnings....................................................................................................4
V. GENERAL WARNINGS............................................................................5
A. Weight Limit ............................................................................................5
B. Intended Use............................................................................................5
C. Attendants and Caregivers ................................................................5
D. Accessories...............................................................................................5
E. Know Your Chair...................................................................................5
F. Reduce the Risk of an Accident ......................................................5
G. Safety Checklist ......................................................................................6
H. Changes & Adjustments .....................................................................6
I. Environmental Conditions .................................................................6
J. Terrain.........................................................................................................6
K. Street Use.................................................................................................6
L. Motor Vehicle Safety............................................................................6
M. When You Need Help.........................................................................7
N. Choking Hazard......................................................................................7
O. Pinch Point................................................................................................7
P. Sharp Edges ..............................................................................................7
Q. Electrical Shock.......................................................................................7
R. LED & Battery Pack..............................................................................7
VI. SAFETY WARNINGS: FALLS & TIP-OVERS ...................................8
A. Center of Balance..................................................................................8
B. Dressing or Changing Clothes .........................................................8
C. Obstacles...................................................................................................8
D. Front Caster Lift.....................................................................................8
E. Reaching or Leaning..............................................................................8
F. Moving Backward...................................................................................8
G. Escalators...................................................................................................9
H. Ramps, Slopes & Sidehills ...................................................................9
I. Transfers ....................................................................................................10
J. Curbs & Single Steps............................................................................10
K. Climbing a Curb or Single Step .......................................................11
L. Descending a Curb or Single Step..................................................11
M. Stairs............................................................................................................11
N. Climbing Stairs ........................................................................................11
O. Descending Stairs...................................................................................11
VII. WARNINGS: COMPONENTS & OPTIONS..................................12
A. Anti-tip Tubes..........................................................................................12
B. Armrests....................................................................................................12
C. Cushion & Sling Seats...........................................................................12
D. Fasteners....................................................................................................12
E. Footrests....................................................................................................12
F. Pneumatic Tires ......................................................................................12
G. Offset Seating (Option).......................................................................13
H. Positioning Belts (Option)..................................................................13
I. Push Handles (Option) ........................................................................13
J. Quick-Release Axles.............................................................................13
K. Rear Wheels ............................................................................................13
L. Rear Wheel Locks.................................................................................13
M. Modified Seat Systems.........................................................................13
N. Seat and Back Upholstery..................................................................14
O. Backrest Tension Adjustable .............................................................14
P. Freestyle Back (Option) ......................................................................14
Q. Folding Lock Down Adjustable Backrest.....................................14
R. Seat Back ...................................................................................................14
S. Backrest - Towel Bar ............................................................................14
VIII. USE AND MAINTENANCE ...................................................................15
A. Introduction .............................................................................................15
B. Critical Safety Checks..........................................................................15
C. Cleaning .....................................................................................................15
D. Safety Checklist ......................................................................................15
E. Troubleshooting Chart........................................................................15
F. To Mount and Remove Rear Wheels............................................16
G. Wheel Locks............................................................................................16
H. Anti-tips .....................................................................................................16
I. Single Post Height Adjustable Armrests (Option)...................17
J. Padded Swing-away Armrests (Option).......................................17
K. Flip-up Footplate....................................................................................17
L. Freestyle Back (Option) ......................................................................17
M. Back Angle Performance ....................................................................18
N. Tension Adjustable Upholstery........................................................18
O. Seat Sling Adjustment ..........................................................................19
P. Tension Adjustable Seat Sling ...........................................................19
Q. Cushion Installation ..............................................................................19
R. Storage Tips..............................................................................................19
S. LED & Battery Pack..............................................................................20
T. Check Out................................................................................................20
IX. DEALER SERVICE AND ADJUSTMENT...........................................21
A. Dealer Service Introduction..............................................................21
B. Critical Maintenance Tips...................................................................21
C. Cleaning .....................................................................................................21
D. Rear Wheel Axle Nut Adjustment................................................21
E. Anti-tip Receiver ....................................................................................21
F. Wheel Locks............................................................................................22
G. Armrest Receiver Attachment.........................................................22
H. Padded Swing Away Armrests (Option)......................................23
I. Casters .......................................................................................................23
J. Caster Fork Adjustment.....................................................................24
K. Footrest Height Adjustment.............................................................26
L. Adjusting Rear Seat Height................................................................26
M Backrest......................................................................................................27
N. Freestyle Back Maintenance and Adjustment............................27
O. 4-LINK Rear Suspension.....................................................................28
P. Rear Axle...................................................................................................29
Q. Rear Wheel Spacing..............................................................................31
R. Check Out................................................................................................31
XI. SUNRISE LIMITED WARRANTY.........................................................32

Quickie ®NITRUM
249817 Rev. A 4
12
8
6
11
10
2
1
3
4
5
7
9
1. Back Upholstery
2. Tire
3. Handrim
4. Quick Release Axle
5. Spokes
6. Caster Wheel
7. Caster Housing
8. Camber Tube
9. Caster Fork
10. Footrest
11. Wheel Lock
12. Seat Sling
NOTE: All features may not be available
with some chair setups or in conjunction
with another chair feature. Please consult
your authorized dealer for information.
III. YOUR UNIT AND ITS PARTS
NITRUM
A. CHOOSE THE RIGHT CHAIR & SAFETY
OPTIONS
Sunrise provides a choice of many wheelchair styles to meet your needs. This
product is intended for single person use only. Final selection of the type of
wheelchair, options and adjustments rests solely with you and your health
care professional. Choosing the best chair for your unique mobility needs, will
depend on such things as:
1. Your disability, grasping strength, balance and coordination.
2. The types of hazards you must overcome in daily use (where you live and
work, and other places you are likely to use your chair).
3. The need for options that will improve your positioning, safety and
comfort (such as anti-tip tubes, positioning belts, or special seating
systems).
B. REVIEW THIS MANUAL OFTEN
Before using this chair you, and each person who may assist you, should read
this entire manual and make sure to follow all instructions. Review the
warnings often, until they are second nature to you.
C. WARNINGS
The word “WARNING” refers to a hazard or unsafe practice that may cause
severe injury or death to you or to other persons. The “Warnings” are in three
main sections, as follows:
1. V - GENERAL WARNINGS
Here you will find a safety checklist and a summary of risks you need to
be aware of before you ride this chair.
2. VI - SAFETY WARNINGS: FALLS & TIP-OVERS
Here you will learn about practices for the safe use of your chair, and
how to avoid a fall or tip-over while you perform daily activities in your
chair.
3. VII - WARNINGS — COMPONENTS & OPTIONS
Here you will learn about the components of your chair and options you
can select for safety. Consult your authorized supplier and your health
care advisor to help you choose the best set-up and options for safe use.
NOTE - Where they apply, you will also find “Warnings” in other sections
of this manual. Heed all warnings in these sections. If you fail to do so a fall,
tip-over or loss of control may occur and cause severe injury to the rider or
others.
IV. NOTICE — READ BEFORE USE

Quickie ®NITRUM
249817 Rev. A5
V. GENERAL WARNINGS
A. WEIGHT LIMIT
WARNING
NEVER exceed the weight limit specified by Sunrise Medical. The weight
capacity provided by your manufacturer is for the combined weight of a rider
and items carried using on-board storage. If you do exceed the weight limit,
damage to your chair, a fall, tip-over or loss of control may occur and cause
severe injury to the rider or others.
Weight Capacity
Quickie NITRUM (Open Fixed Front) - 275 lbs/(125kg)
B. INTENDED USE
The NITRUM wheelchair’s intended use is to provide mobility to persons
limited to a sitting position.
WARNING
DO NOT use this device for purposes other than what is intended by the
manufacturer.
1. The wheelchiar is not designed for weight training and is unsafe for use
as a seat while weight training. Weight training from the wheelchair
substantially changes the stability of the chair and may cause tipping.
2. DO NOT stand on the frame of the wheelchair.
3. NEVER allow someone to stand on your chair or use it as a step ladder.
4. This chair is designed for a single rider only.
5. Unauthorized modifications and use of parts or accessories not supplied
or approved by Sunrise Medical may change the chair structure. This
will void the warranty and may cause a safety hazard. If the warning is
ignored, damage to your chair, and the potential for severe injury of the
person using the chair for unintended purposes can occur.
C. ATTENDANTS AND CAREGIVERS
WARNING
Before you assist a rider, be sure to read all warnings contained in this
manual, and follow all instructions that apply. Be aware that after consulting a
healthcare professional, you will need to learn safe and proven body
mechanics to use and create assistive methods best suited to your abilities.
D. ACCESSORIES
WARNING
Unauthorized modifications or use of parts, or accessories not supplied or
approved by Sunrise Medical may change the chair structure. This will void
the warranty and may cause a safety hazard.
Some problems that may occur, but are not limited to:
1. Incorrect wheels and/or tires that put the rider at risk of a fall or tip-over.
2. Adding a component to the frame, changing the structural integrity of the
chair.
3. Any modification or disassembly can potentially create an unsafe situation
where rider and/or attendant are put at risk.
E. KNOW YOUR CHAIR
WARNING
Every wheelchair is different. Take the time to learn the feel of this chair before
you begin riding. Start slowly, with easy, smooth strokes. If you are used to a
different chair, you may use too much force and tip over. If you use too much
force, damage to your chair, a fall, tip-over or loss of control may occur and
cause severe injury to the rider or others.
F. REDUCE THE RISK OF AN ACCIDENT
WARNING
1. BEFORE you begin riding, you should be trained in the safe use of this
chair by your health care advisor.
2. Practice bending, reaching and transfers utnil you know the limit of your
ability. Have someone help you until you know what can cause a fall or
tip-over and how to avoid doing so.
3. Be aware that you must develop your own methods for safe use best
suited to your level of function and ability.
4. NEVER try a new maneuver on your own. Ask the advice of your health
care professional to lower the risk of a fall or tip over.
5. Get to know the areas where you plan to use your chair. Look for
hazards and learn how to avoid them.

Quickie ®NITRUM
249817 Rev. A 6
V. GENERAL WARNINGS
G. SAFETY CHECKLIST
WARNING
Before Each Use Of Your Chair:
1. Make sure the chair rolls easily and that all parts work smoothly. Check
for noise, vibration, or a change in ease of use. (This may indicate low tire
pressure, loose fasteners, or damage to your chair).
2. Immediately repair any problem. Your authorized dealer can help you find
and correct the problem(s).
3. Check to see that both quick-release rear axles are locked. When locked,
the axle button will “pop out” fully. If not locked, the wheel may come off
and cause you to fall.
4. If your chair has anti-tip tubes, lock them in place.
H. CHANGES & ADJUSTMENTS
WARNING
1. See your healthcare advisor and have them adjust seating components
any time a change or adjustment needs to be made.
2. Unauthorized modifications or use of parts not supplied or approved by
Sunrise may change the chair structure. This will void the warranty and
may cause a safety hazard.
If you fail to heed these warnings, damage to your chair, a fall, tip-over or loss
of control may occur and cause severe injury to the rider or others.
I. ENVIRONMENTAL CONDITIONS
WARNING
1. Use extra care if you must ride your chair on a wet or slick surface. If you
are in doubt, ask for help.
2. Contact with water or excess moisture may cause your chair to rust or
corrode. Avoid all extreme weather situations if possible.
a. Do not use your chair in a shower, pool or other body of water.
The chair tubing and parts are not water-tight and may rust or
corrode from the inside.
b. Avoid excess moisture (for example, do not leave your chair in a
damp bathroom while taking a shower).
c. Dry your chair as soon as you can if it gets wet, or if you use water
to clean it.
If you fail to heed these warnings, damage to your chair, a fall, tip-over or loss
of control may occur and cause severe injury to the rider or others.
J. TERRAIN
WARNING
1. Based on ANSI/RESNA testing, Sunrise Medical recommends the use of
a caster wheel with a minimum diameter of 5”, if the wheelchair will be
overcoming obstacles up to 1/2” on a regular basis.
2. Your chair is designed for use on firm, even surfaces such as concrete,
asphalt, indoor flooring, and carpets.
3. Do not operate your chair in sand, loose soil, or over rocky terrain.
4. If you use your chair on terrain that is rougher than described above
there is a danger that screws and bolts will loosen prematurely, and that
damage to wheels or axles could put the rider at risk of a fall, tip-over, or
loss of control.
If you fail to heed these warnings, damage to your chair, a fall, tip-over or loss
of control may occur and cause severe injury to the rider or others.
K. STREET USE
WARNING
1. This product is not intended for street use.
2. Avoid streets whenever possible.
3. Obey and follow all legal pedestrian pathways, and laws that apply to
pedestrians.
4. Be alert to the danger of motor vehicles in parking lots, or if you must
cross a road.
If you fail to heed these warnings, damage to your chair, a fall, tip-over or loss
of control may occur and cause severe injury to the rider or others.
L. MOTOR VEHICLE SAFETY
If possible and feasible, the rider should transfer to the Original Equipment
Manufacturer vehicle seat and use the OEM vehicle restraint.
Sunrise Medical does provide a WC-19 Wheelchair Tie-Down and Occupant
Restraint System, otherwise called a Transit Option. To Identify whether your
wheelchair has been manufactured with the Transit Option installed, look
for four points of securement. Two Front points, (A) and two rear points
(B). These points are recognized by the securement point decal which can be
found on or near the securement points. If your wheelchair is equipped with
the Transit Option please review the Transit Securement supplement that was
provided with the wheelchair for additional information and instructions. You
can request a copy from your authorized supplier, or Sunrise Medical if you
don’t have it.
WARNING
If your chair is NOT equipped with the Transit Option:
1. NEVER let anyone sit in this chair while in a moving vehicle.
a. ALWAYS move the rider to an approved vehicle seat.
b. ALWAYS secure the rider with proper motor vehicle restraints.
2. In an accident or sudden stop the rider may be thrown from the chair.
Wheelchair seat belts will not prevent this, and further injury may result
from the belts or straps.
3. NEVER transport this chair in the front seat of a vehicle. It may shift and
interfere with the driver.
4. ALWAYS secure this chair so that it cannot roll or shift.
5. Do not use any chair that has been involved in a motor vehicle accident.
The frame and/or components may have been changed due to the
accident. Such items could be, but are not limited to: bent, loosened,
and/or broken components that were subjected to an impact.
If you fail to heed these warnings, damage to your chair, a fall, tip-over or loss
of control may occur and cause severe injury to the rider or others.
1 2
Look for this symbol on your wheelchair. It indicates wheelchair
securement points which conform to ANSI/RESNA (1998) V.1 –
Section 19 & ANSI/RESNA (2012) V.4 WC-19.
A
1 2
B

Quickie ®NITRUM
249817 Rev. A7
V. GENERAL WARNINGS
M. WHEN YOU NEED HELP
WARNING
For The Rider: Make sure that each person who helps you reads and follows all
warnings and instructions that apply.
For Attendants:
1. Work with the rider’s doctor, nurse or therapist to learn safe methods
best suited to your abilities and those of the rider.
2. Tell the rider what you plan to do, and explain what you expect the rider
to do. This will put the rider at ease and reduce the risk of an accident.
3. Make sure the chair has push handles. They provide secure points for you
to hold the rear of the chair to prevent a fall or tip-over. Check to make
sure push handle grips will not rotate or slip off.
4. To prevent injury to your back, use good posture and proper body
mechanics. When you lift or support the rider or tilt the chair, bend your
knees slightly and keep your back as upright and straight as you can.
5. Remind the rider to lean back when you tilt the chair backward.
6. When you descend a curb or single step, slowly lower the chair in one
easy movement. Do not let the chair drop the last few inches to the
ground. This may damage the chair or injure the rider.
7. To avoid tripping, unlock and rotate anti-tip tubes up, out of the way.
8. Whenever you aren’t attending the wheelchair, ALWAYS use the wheel-
lock to secure the rear wheels, and lock the anti-tip tubes in place.
If you fail to ask for help when in doubt, you run a high risk of a fall, tip-over or
loss of control that may occur and cause severe injury to the rider or others.
N. CHOKING HAZARD
WARNING
NOTE- Your chair consists of many small parts that could present a choking
or swallowing hazard to young children. Take care to keep loose parts out of
reach when doing any work on the chair. Seek immediate help if a loose part is
swallowed by a child.
O. PINCH POINT
WARNING
NOTE- Your wheelchair has many moving parts that can create pinch points
and possible finger traps. Be aware when making any adjustments, when
folding and unfolding, when moving, and any other situation that could cause a
pinch point situation.
P. SHARP EDGES
WARNING
NOTE- This wheelchair contains parts and hardware of many shapes and
sizes. When using or working around the wheelchair, take caution to avoid any
corners or edges that may cause a scrape or a cut.
Q. ELECTRICAL SHOCK
WARNING
NOTE- When using this wheelchair, please take all precautions to avoid
situations that can possibly cause an electric shock to the patient, care-giver or
wheelchair itself. Situations would include: while maintaining the optional LED
& battery pack assembly and wiring; using electrical appliances near water while
using the wheelchair; working on electrical equipment, while in the chair, during
severe weather conditions.
R. LED & BATTERY PACK
WARNING
NOTE- Use caution if the LED lights or battery pack need to be serviced or
repaired. If in doubt, disconnect the LED lights from the battery pack. Please
contact your local authorized dealer or manufacturer with any questions you
may have.
• Before you use the LED light for the first time, please make sure to fully
charge the battery.
• Battery for LED Lights: Lithium Ion battery (hazardous product).
• Electrical and electronic equipment need to be disposed of separately to
general household waste at specific state provided locations. The correct
disposal and separate collection of used appliances serves to prevent
potential damage to health and the environment. It is a requirement for the
re-utilization and recycling of used electrical and electronic equipment.
• Detailed information on the disposal of your used equipment can be
obtained from your local authority, your waste disposal or service, the
specialist dealer from which you purchased the product, your sales contact.

Quickie ®NITRUM
249817 Rev. A 8
VI. SAFETY WARNINGS: FALLS & TIP-OVERS
A. CENTER OF BALANCE
WARNING
The point where this chair will tip forward, back or to the side depends on its
center of balance and stability. How your chair is set up, the options you select
and the changes you make may affect the risk of a fall or tip-over.
1. The Most Important Adjustment Is:
The position of the rear wheels. The more you move the rear wheels
forward, the more likely your chair will tip over backward.
1. The Center Of Balance Is Also Affected By:
a. A change in the set-up of your chair, including:
• The distance between the rear wheels.
• The amount of rear wheel camber.
• The seat height and seat angle.
• Backrest angle.
b. A change in your body position, posture or weight distribution.
c. Riding your chair on a ramp or slope.
d. A back pack or other options and the amount of added weight.
2. To Reduce The Risk Of An Accident:
a. Consult your doctor, nurse or therapist to find out what axle and
caster position is best for you.
b. Consult your authorized dealer BEFORE you modify or adjust
this device. Be aware that you may need to make other changes
to correct the center of balance.
c. Have someone help you until you know the balance points of
your chair and how to avoid a tip-over.
d. Use anti-tip tubes.
If you fail to heed these warnings, you are at a high risk of a fall, tipover
or loss of control that could cause severe injury to the rider or
others.
B. DRESSING OR CHANGING CLOTHES
WARNING
Your weight may shift if you dress or change clothes while seated in this chair.
To reduce the risk of a fall or tip-over:
1. Rotate the front casters until they are as far forward as possible. This
makes the chair more stable.
2. Lock anti-tip tubes in place. (If your chair does not have anti-tip tubes,
back it up against a wall and lock both rear wheels).
If you fail to heed these warnings, you are at a high risk of a fall, tipover
or loss of control that could cause severe injury to the rider or
others.
C. OBSTACLES
WARNING
Riding over curbs or obstacles can cause tipping and serious bodily harm. If
you have any doubt that you can safely cross any curb or obstacle, ALWAYS
ASK FOR HELP. Be aware of your riding skills and personal limitations.
Develop new skills only with the help of a companion.
To avoid the risk of traversing obstacles:
1. Keep a lookout for danger – scan the area well ahead of your chair as you
ride.
2. Make sure the floor areas where you live and work are level and free of
obstructions.
3. Remove or cover threshold strips between rooms.
4. Install a ramp at entry or exit doors. Make sure there is not a drop off at
the bottom of the ramp.
5. To Help Correct Your Center Of Balance:
a. Lean your upper body FORWARD slightly as you go UP over an
obstacle.
b. Press your upper body BACKWARD as you go DOWN from a
higher to a lower level.
6. If your chair has anti-tip tubes, do not go over an obstacle without help.
7. Keep both of your hands on the handrims as you go over an obstacle.
8. Never push or pull on an object (such as furniture or a doorjamb) to
propel your chair.
If you fail to heed these warnings, you are at a high risk of damage to your
chair, a fall, tip-over or loss of control that may occur and cause severe injury
to the rider or others.
D. FRONT CASTER LIFT
WARNING
Front caster lift can occur when the front wheels, ordinarily in contact with
the ground, are either intentionally, or unintentionally caused to lift from the
ground while the rear wheels remain in contact. Pitch control (partial or full)
should NEVER be attempted without consulting your healthcare advisor and
making sure that anti-tips are installed.
E. REACHING OR LEANING
WARNING
If you reach or lean it will affect the center of balance of your chair. This may
cause you to fall or tip over. When in doubt, ask for help or use a device to
extend your reach.
1. NEVER reach or lean if you must shift your weight sideways or rise up off
the seat.
2. NEVER reach or lean if you must move forward in your seat to do so.
Always keep your buttocks in contact with the backrest.
3. NEVER reach with both hands (you may not be able to catch yourself to
prevent a fall if the chair tips).
4. NEVER reach or lean to the rear unless your chair has anti-tip tubes
locked in place.
5. DO NOT reach or lean over the top of the seat back. This may damage
one or both backrest tubes and cause you to fall.
6. If You Must Reach Or Lean:
a. Do not lock the rear wheels. This creates a tip point and makes a
fall or tip-over more likely.
b. Do not put pressure on the footrests.
c. Move your chair as close as you can to the object you wish to
reach.
d. Do not try to pick up an object from the floor by reaching down
between your knees. You are less likely to tip if you reach to the
side of your chair.
e. Rotate the front casters until they are as far forward as possible.
This makes the chair more stable.
f. Firmly grasp a rear wheel or an armrest with one hand. This will
help to prevent a fall if the chair tips.
If you fail to heed these warnings damage to your chair, a fall, tip-over or loss of
control may occur and cause severe injury to the rider or others.
F. MOVING BACKWARD
WARNING
Use extra care when you move your chair backward. Your chair is most stable
when you propel yourself forward. You may lose control or tip over if one of
the rear wheels hits an object and stops rolling.
1. Propel your chair slowly and smoothly.
2. If your chair has anti-tip tubes, make sure to lock them in place.
3. Stop often and check to be sure your path is clear.
If you fail to heed these warnings damage to your chair, a fall, tip-over or loss of
control may occur and cause severe injury to the rider or others.

Quickie ®NITRUM
249817 Rev. A9
VI. SAFETY WARNINGS: FALLS & TIP-OVERS
G. ESCALATORS
WARNING
NEVER use this chair on an escalator, even with an attendant. If you do, a fall
or tip-over is likely.
If you fail to heed these warnings damage to your chair, a fall, tip-over or
loss of control may occur and cause severe injury to the rider or others.
H. RAMPS, SLOPES & SIDEHILLS
WARNING
Whenever possible, avoid riding on a slope, which includes a ramp or sidehill.
This will change the center of balance of your chair. Your chair is less stable
and more difficult to manuever. when it is at an angle. When moving up a hill,
anti-tip tubes may not prevent a fall or tip-over.
1. DO NOT use your chair on a slope steeper than 6%. (A 6% slope
means: one foot in elevation for every ten feet of slope length.)
2. ALWAYS go as straight up and as straight down as you can. (Do not
“cut the corner” on a slope or ramp.)
3. DO NOT turn or change direction on a slope.
4. When you have to use a ramp, always stay in the CENTER of the ramp.
Make sure ramp is wide enough that you have no risk of going off the
edge.
5. DO NOT stop on a steep slope. If you stop, you may lose control of
your chair.
6. NEVER use rear wheel locks to try to slow or stop your chair. This is
likely to cause your chair to veer out of control.
7. ALWAYS be aware of:
a. Wet or slippery surfaces.
b. A change in grade on a slope (or a lip, bump or depression). These
may cause a fall or tip-over.
8. To Reduce The Risk Of A Fall Or Tip-Over:
a. Lean or press your body UPHILL. This will help adjust for the
change in the center of balance caused by the slope or sidehill.
b. Keep pressure on the handrims to control your speed on a down
slope. If you go too fast you may lose control.
c. ASK FOR HELP any time you are in doubt.
9. Ramps At Home & Work– For your safety, ramps at home and work
must meet all legal requirements for your area:
a. AVOID A DROP-OFF
Make sure there is a section at the top or bottom to smooth out
the transition.
b. ALWAYS stay in the center of the ramp and control your speed.
If you fail to heed these warnings damage to your chair, a fall, tip-over or loss of
control may occur and can possibly cause severe injury to the rider or others.
345 6 IF you need to go down a hill:
a. The Downslope should be
less than 6°
b. GO SLOW
c. ALWAYS Go Straight down
d. ALWAYS Control your speed
e. NEVER turn on a hill
IF you need to go up a hill:
a. The Upslope should be
less than 6°
b. ALWAYS Go Straight up
c. NEVER Stop on the upslope
d. NEVER turn on a hill
e. ALWAYS lean forward
IF you need to traverse a Sidehill:
a. Sidehill must be less than 6°
or you are risking a tip over
b. DON’T STOP
c. DO NOT make any Turns on
the sidehill
IF you need to traverse a
Ramp:
a. Go Slowly
b. Watch out for Drop-offs
c. ALWAYS Go Straight down
d. Stay centered on the Ramp
3
4
5
6

Quickie ®NITRUM
249817 Rev. A 10
VI. SAFETY WARNINGS: FALLS & TIP-OVERS
I. TRANSFERS
WARNING
It is dangerous to transfer on your own. It requires good balance and agility. Be aware that there is a point
during every transfer when the wheelchair seat is not below you.
To avoid a fall:
1. Work with your health care advisor to learn safe methods for transfers.
a. Learn how to position your body and how to support yourself during a transfer.
b. Have someone help you until you learn safe transfer methods.
2. Lock the rear wheels before you transfer.
3. Be aware that the chair can still slide and/or tip. The wheel lock keeps the rear wheels from rolling
while you are perforrming the transfer.
4. Make sure that the pneumatic tires are properly inflated. Low tire pressure may allow the rear wheel
locks to slip. (see table in Section VII: F “Pneumatic Tires”)
5. Move your chair as close as you can to the seat you are transferring to.
If possible, use a transfer board.
6. Rotate the front casters until they are as far forward as possible.
7. If you can, remove the footrests, or swing them out of the way.
a. Make sure your feet do not catch in the space between the footrests.
b. Avoid putting weight on the footrests as this may cause the chair to tip.
8. Make sure armrests are removed, or out of the way and do not interfere with the transfer.
9. Transfer as far back onto the seat surface as you can. This will reduce the risk that the chair will tip or
move away from you.
If you fail to heed these warnings damage to your chair, a fall, tip-over or loss of control may occur and can
possibly cause severe injury to the rider or others.
J. CURBS & SINGLE STEPS
WARNING
Before riding over curbs, and negotiating even a single step, ALWAYS ask for assistance first. Curbs and
steps can cause tipping and serious bodily harm. When in doubt as to your ability to avoid, or traverse any
obstacle, always ask for help. Be aware of your riding skills and personal limitations. Develop new skills only
with the help of a companion.
For Attendant: Each person who assists the rider with curbs and steps should read and follow all
instructions and warnings pertaining to attendants, and caregivers.
1. Do not try to climb a high curb or step (more than 4 inches high) UNLESS you have help. Doing so
may cause your chair to exceed its balance point and tip over.
2. Go straight up and straight down a curb or step. If you climb or descend at an angle, a fall or tip-over
is likely.
3. Be aware that the impact of dropping down from a curb or step can damage your chair or loosen
fasteners.
If you fail to heed these warnings damage to your chair, a fall, tip-over or loss of control may occur and can
possibly cause severe injury to the rider or others.
7 8
Before transferring:
Flip-Back, or Remove the armrests out of
the way.
Swing, or remove the footrests out of the way.
Make sure the wheel lock is set.
9
Optimum Transfer position
7
8
1. 2. 3.
GET READY TRANSFER ADJUST
9

Quickie ®NITRUM
249817 Rev. A11
VI. SAFETY WARNINGS: FALLS & TIP-OVERS
K. CLIMBING A CURB OR SINGLE STEP
WARNING
For Attendant: follow these steps to help the rider climb a curb or single step going BACKWARD:
1. Stay behind the chair.
2. Continue backward until the rear wheels contact the face of the curb or step. Lift and roll the rear
wheels to the top of the curb.
3. Pull the chair backwards until the caster wheels have cleared the edge of the curb and return the chair
to it’s rolling position.
If you fail to heed these warnings damage to your chair, a fall, tip-over or loss of control may occur and cause
severe injury to the rider or others.
L. DESCENDING A CURB OR SINGLE STEP
WARNING
For Attendant: Follow these steps to help a rider descend a curb or single step going FORWARD:
1. Stay at the rear of the chair.
2. Several feet before you reach the edge of the curb or step, tip the chair slightly and pull it
backward.
3. When the chair is at it’s balance point, carefully step forward until the rear wheels reach the edge of
the curb or step. Then allow the rear wheels to slowly roll down onto the lower level.
4. Push the chair forward until you are standing on the lower level.
5. When the rear wheels are safely on the lower level, tilt the chair back to its balance point.
If you fail to heed these warnings damage to your chair, a fall, tip-over or loss of control may occur and cause
severe injury to the rider or others.
M. STAIRS
WARNING
1. NEVER use this chair on stairs UNLESS you have someone to help you. Doing so is likely to cause a fall
or tip-over.
2. Negotiating stairs with a wheelchair always requires at least 2 attendants for safety.
If you fail to heed these warnings damage to your chair, a fall, tip-over or loss of control may occur and cause
severe injury to the rider or others.
N. CLIMBING STAIRS
WARNING
1. Use at least two attendants to move a chair and rider up stairs.
2. Move the chair and rider BACKWARD up the stairs.
3. The person at the rear is in control. He or she tilts the chair back to its balance point.
4. A second attendant at the front firmly grasps a non-detachable part of the front frame and lifts the
chair up and over one stair at a time.
5. The attendants move to the next stair up. Repeat for each stair, until you reach the landing.
O. DESCENDING STAIRS
WARNING
1. Use at least two attendants to move a chair and rider down stairs.
2. Move the chair and rider FORWARD down the stairs.
3. The person at the rear is in control. He or she tilts the chair to the balance point of the rear wheels
and rolls it to the edge of the top step.
4. A second attendant stands on the third step from the top and grasps the chair frame. He or she lowers
the chair one step at a time by letting the rear wheels roll over the stair edge.
5. The attendants move to the next stair down. Repeat for each stair, until you reach the landing.
9
9
10
10
10
10

Quickie ®NITRUM
249817 Rev. A 12
VII. WARNINGS: COMPONENTS & OPTIONS
A. ANTI-TIP TUBES
WARNING
Anti-tip tubes can help keep your chair from tipping over backward in normal
conditions.
1. Sunrise recommends the use of anti-tip tubes:
2. When locked in place (in the “down” position) anti-tip tubes should be
BETWEEN 1 1/2to 2 inches off the ground.
a. If set higher than 2 inches, they may not prevent a tip-over.
b. If set lower than 1 1/2inches, they may “hang up” on obstacles and
cause a fall or tip over.
3. If you have to climb or descend a curb, or overcome an obstacle it may
be necessary to have an attendant make sure the anti-tip tubes are
rotated up, and out of the way, so that the chair and rider do not get
stuck and/or become unstable.
If you fail to heed these warnings damage to your chair, a fall, tip-over or loss of
control may occur and cause severe injury to the rider or others.
B. ARMRESTS
WARNING
Armrests detach and will not bear the weight of this chair.
1. NEVER lift this chair by its armrests. They may come loose or break.
2. Lift this chair only by non-detachable parts of the main frame.
If you fail to heed these warnings damage to your chair, a fall, tip-over or loss of
control may occur and cause severe injury to the rider or others.
C. CUSHIONS & SLING SEATS
WARNING
1. Quickie sling seats and standard foam cushions are not designed for the
relief of pressure.
2. If you suffer from pressure sores or if you are at risk that they will occur,
you may need a special seat system or a device to control your posture.
Consult your doctor, nurse or therapist to find out if you need such a
device for your well-being.
3. Seat slings are not intended to be used as a direct seating surface. A
cushion or other seating surface should be placed on the sling before use.
If you fail to heed these warnings damage to your chair, a fall, tip-over or loss of
control may occur and cause severe injury to the rider or others.
D. FASTENERS
WARNING
Many of the screws, bolts and nuts on this chair are special high-strength
fasteners. Use of improper fasteners may cause your chair to fail.
1. ONLY use fasteners provided by an authorized supplier (or ones of the
same type and strength, as indicated by the markings on the heads).
2. Over- or under-tightened fasteners may fail or cause damage to chair
parts.
3. If bolts or screws become loose, tighten them as soon as you can.
If you fail to heed these warnings damage to your chair, a fall, tip-over or loss of
control may occur and cause severe injury to the rider or others.
E. FOOTRESTS
WARNING
1. At the lowest point, footrests should be AT LEAST 2 inches off the
ground. If set too LOW, they may “hang up” on obstacles you can expect
to find in normal use. This may cause the chair to stop suddenly and tip
forward.
2. To Avoid A Trip Or Fall When You Transfer:
a. Make sure your feet do not “hang up” or get caught in the space
between the footrests.
b. Avoid putting weight on the footrests, as the chair may tip
forward.
c. Footrests should be swung out of the way or removed whenever
entering or exiting the wheelchair.
3. NEVER lift this chair by the footrests. Footrests detach and will not bear
the weight of this chair. Lift this chair only by non-detachable parts of the
main frame.
4. Never use the footrests of your chair to open doors, this may cause
them to fail prematurely and create an unsafe situation.
If you fail to heed these warnings damage to your chair, a fall, tip-over or loss of
control may occur and cause severe injury to the rider or others.
F. PNEUMATIC TIRES
WARNING
Proper inflation extends the life of your tires and makes your chair easier to
use.
1. Do not use this chair if any of the tires are under- or over-inflated. Check
weekly for proper inflation level, as listed on the tire sidewall.
2. Low pressure in a rear tire may cause the wheel lock on that side to slip
and allow the wheel to turn when you do not expect it.
3. Low pressure in any of the tires may cause the chair to veer to one side
and result in a loss of control.
4. Over-inflated tires may burst.
If you fail to heed these warnings damage to your chair, a fall, tip-over or loss of
control may occur and cause severe injury to the rider or others.
Recommended Tire Pressures
Recommended
Pressure or Pressure
Range
Tires
Nitrum
kPa PSI
Pneumatic - 20” x 448 65
Pneumatic - 22” x 448 65
Pneumatic - 25” x 448 65
Pneumatic - 26” x 448 65
High Pressure Clincher (24”) x 758 110
High Pressure Clincher (26”) x 758 110
Knobby V-Track (24”) x 448 65
Schwalbe Marathon (22”) x 586-1000 85-145
Schwalbe Marathon (24”) x 586-1000 85-145
Schwalbe Marathon (25”) x 586-1000 85-145
Schwalbe Marathon (26”) x 586-1000 85-145
Schwalbe Speed Run (24”) x 586-1000 85-145
Schwalbe Speed Run (26”) x 586-1000 85-145

Quickie ®NITRUM
249817 Rev. A13
VII. WARNINGS: COMPONENTS & OPTIONS
G. OFFSET SEATING (Option)
WARNING
1. A fore/aft change in the backrest position will affect the center of
balance of your chair.
2. Only use this option when installing a forward offset mounted seating
solution, not using the standard back sling.
3. Each time you adjust or modify the backrest plane location, the change
may make it easier to tip backwards. Use anti-tips until you adapt to the
change, and are sure you are not at risk to tip over.
If you fail to heed these warnings damage to your chair, a fall, tip-over or loss of
control may occur and cause severe injury to the rider or others.
H. POSITIONING BELTS (Option)
WARNING
The positioning belt is predominately used to support your posture. It can also
be used to limit slipping and/or sliding that you might experience when the chair
is in motion. The positioning belt is not a transit rated safety belt and should
not be used in the place of a seat belt while being transported in a motor
vehicle. Improper use of positioning belts may cause severe injury or death.
If you use a positioning belt, be sure to follow the recommendations in this
section:
1. Make sure the rider does not slide down in the wheelchair seat. If this
occurs, the rider may suffer chest compression or suffocate due to
pressure from the belts.
2. The belts must be snug, but must not be so tight that they interfere with
breathing. You should be able to slide your open hand, flat, between the
belt and the rider.
3. A pelvic wedge or a similar device can help keep the rider from sliding
down in the seat. Consult with the rider’s doctor, nurse or therapist to
find out if the rider needs such a device.
4. Use positioning belts only with a rider who can cooperate. Make sure the
rider can easily remove the belts in an emergency.
5. NEVER use positioning belts
a. As a patient restraint. A restraint requires a doctor’s order.
b. On a rider who is comatose or agitated.
c. As a motor vehicle restraint. In an accident or sudden stop the
rider may be thrown from the chair. Wheelchair positioning belts
will not prevent this, and further injury may result from the belts or
straps.
If you fail to heed these warnings, damage to your chair, a fall, tip-over or loss of
control may occur and cause severe injury to the rider or others.
I. PUSH HANDLES (Option)
WARNING
When you have an attendant, make sure that this chair has push handles.
1. Push handles provide secure points for an attendant to hold the rear of
this chair, to prevent a fall or tip-over.
2. Check to make sure push handle grips will not rotate or slip off.
If you fail to heed these warnings damage to your chair, a fall, tip-over or loss of
control may occur and cause severe injury to the rider or others.
J. QUICK-RELEASE AXLES
WARNING
1. Do not use this chair UNLESS you are sure that both quick-release rear
axles are locked.
2. An axle is not locked until the quick-release button pops out fully.
3. An unlocked axle may come off during use, resulting in a fall, tip-over or
loss of control and cause severe injury to the rider or others.
• Quick-Release Axles should be periodically cleaned and inspected for
function and signs of wear or bending. Replace as necessary.
If you fail to heed these warnings damage to your chair, a fall, tip-over or loss of
control may occur and cause severe injury to the rider or others.
K. REAR WHEELS
WARNING
A change in set-up of the rear wheels will affect the center of balance of your
chair.
1. The farther you move the rear axles FORWARD, the more likely it is that
your chair will tip over backward.
2. Consult your healthcare advisor to find the best rear axle set-up for your
chair. Do not change the set-up UNLESS you consult your health-care
advisor first.
3. Adjust the rear wheel locks after you make any change to the rear axles.
a. If you fail to do so, the wheel locks may not work.
b. Make sure lock arms embed in the tires at least 1/8 inch when
locked.
If you fail to heed these warnings damage to your chair, a fall, tip-over or loss of
control may occur and cause severe injury to the rider or others.
L. REAR WHEEL LOCKS
WARNING
Rear wheel locks are NOT designed to slow or stop a moving wheelchair.
Use them only to keep the rear wheels from rolling when your chair is at a
complete stop.
1. NEVER use rear wheel locks to try to slow or stop your chair when it is
moving. Doing so may cause a fall or tip-over.
2. To keep the rear wheels from rolling, always set both rear wheel locks
when you transfer to or from your chair.
3. Low pressure in a rear tire may cause the wheel lock on that side to slip
and may allow the wheel to turn when you do not expect it.
4. Make sure lock arms embed in tires at least 1/8inch when locked. If you fail
to do so, the locks may not work.
If you fail to heed these warnings damage to your chair, a fall, tip-over or loss of
control may occur and cause severe injury to the rider or others.
M. MODIFIED SEAT SYSTEMS
WARNING
Use of a seat system not approved by Sunrise may alter the center of balance of
this chair. This may cause the chair to tip over.
1. Do not change the seat system of your chair UNLESS you consult your
authorized supplier first.
2. Use of a seating system not approved by Sunrise may affect the backrest
folding mechanism of this chair.
3. Use of a seating system not provided by Sunrise is prohibited for transit
use.
If you fail to heed these warnings damage to your chair, a fall, tip-over or loss of
control may occur and cause severe injury to the rider or others.

Quickie ®NITRUM
249817 Rev. A 14
VII. WARNINGS: COMPONENTS & OPTIONS
N. SEAT AND BACK UPHOLSTERY
WARNING
1. Replace worn or torn fabric of seat and seat back as soon as you can. If
you fail to do so, the seat or seat back may fail.
2. Sling fabric will weaken with age and use. Look for fraying, thin spots, or
stretching of fabrics especially at edges and seams.
3. “Dropping down” into your chair will weaken fabric and result in the need
to inspect and replace the seat more often.
4. Be aware that laundering or excess moisture will reduce the flame
retardation qualities of the fabric.
If you fail to heed these warnings damage to your chair, a fall, tip-over or loss of
control may occur and cause severe injury to the rider or others.
O. BACKREST TENSION ADJUSTABLE
WARNING
The Tension Adjustable Backrest is a versatile back intended to replace standard
wheelchair back upholstery. It is designed to provide simple, comfortable and
effective support to help maximize function and increase seating tolerance. In
addition, it is lightweight, durable, and easy to use.
Sunrise Medical recommends that a clinician such as a doctor or therapist
experienced in seating and positioning be consulted to determine if the
Backrest Tension Adjustable is appropriate. Back systems should only be installed
by an authorized Sunrise Medical supplier.
Maximum user weight 275lbs. (125 kg.)
WARNING
Installing a back support on a wheelchair may affect the center of gravity of the
wheelchair and may cause the wheelchair to tip backwards potentially resulting
in injury.
Always assess for the potential need for anti-tippers to be added to the
wheelchair to help increase the stability.
WARNING
Do not use the Backrest Tension Adjustable to push or lift the wheelchair.
Improper use may cause the back to unexpectedly detach from the wheelchair.
If you fail to heed these warnings damage to your chair, a fall, tip-over or loss of
control may occur and cause severe injury to the rider or others.
P. FREESTYLE BACK (Option)
WARNING
The Freestyle Adjustable Backrest is a versatile back intended to replace
wheelchair back upholstery. It is designed to provide simple, comfortable and
effective support to help maximize function and increase seating tolerance. In
addition, it is lightweight, durable, and easy to use.
Sunrise Medical recommends that a clinician such as a doctor or therapist
experienced in seating and positioning be consulted to determine if the Integral
Adjustable Backrest is appropriate. Backs should only be installed by an
authorized Sunrise Medical supplier.
Maximum user weight 275lbs. (125 kg.)
WARNING
Installing a back support on a wheelchair may affect the center of gravity of the
wheelchair and may cause the wheelchair to tip backwards potentially resulting
in injury.
Always assess for the potential need for anti-tippers to be added to the
wheelchair to help increase the stability.
WARNING
Do not use the Freestyle Adjustable backrest to push or lift the wheelchair.
Improper use may cause the back to unexpectedly detach from the wheelchair.
If you fail to heed these warnings damage to your chair, a fall, tip-over or loss of
control may occur and cause severe injury to the rider or others.
Q. FOLDING LOCK DOWN ANGLE
ADJUSTABLE BACKREST
WARNING
Only adjust backrest angle when in a safe and stable position. You may increase
the likelihood of tipping or instability.
If you fail to heed these warnings damage to your chair, a fall, tip-over or loss of
control may occur and cause severe injury to the rider or others.
R. SEAT BACK
WARNING
Adjusting the seat back depth could cause the strut tube to be located in a
position where it could contact the user and cause skin breakdown or other
serious injuries.
If you fail to heed these warnings damage to your chair, a fall, tip-over or loss of
control may occur and cause severe injury to the rider or others.
S. BACKREST - TOWEL BAR
WARNING
NOTE: extreme impact or force to the backrest towel bar may cause
degradation or failure of the towel bar, release bar or the function of the
backrest.

Quickie ®NITRUM
249817 Rev. A15
VIII. USE AND MAINTENANCE
WARNING
The owner of this chair is responsible for making sure that it has
been set up and adjusted by a trained service professional under
the advice of a healthcare professional. The chair may require
periodic safety and function checks or certain in-use adjustments
that can be performed by the owner, caregiver or authorized
dealer if desired. Always use parts and/or accessories that have
been recommended or approved by Sunrise Medical when
servicing this chair.
A. INTRODUCTION
1. Proper maintenance will improve performance and extend the useful life
of your chair.
2. Clean your chair regularly. This will help you find loose or worn parts and
make your chair easier to use. You will need a mild detergent
solution and plenty of cleaning rags.
3. If discovered, have loose, worn, bent or damaged parts replaced before
using the chair.
4. To protect your investment, have all major maintenance and repair
work done by your authorized dealer.
5. Inspect and maintain this chair strictly per the safety
checklist.
6. If you detect a problem, make sure to order parts, or have
service, and repair work done at your authorized dealer
before use.
7. At least once per year, have a complete inspection,
safety check, and service of your chair made by an
authorized dealer.
B. CRITICAL SAFETY CHECKS
1. Tire Air Pressure:
Check air pressure in pneumatic tires at least ONCE PER WEEK. The
wheel locks will not grip properly if you fail to maintain the air pressure
shown on tire sidewall.
2. Axles & Axle Sleeves:
When checking axles and axle sleeves every six months, make sure they
are clean and tight. Loose sleeves will damage the axle plate and will
affect performance.
3. Camber Tubes and Camber Plugs
Inspect the camber tubes and plugs every 6 months ensuring that all
fasteners are tight and that no parts have moved from their preset
positions.
C. CLEANING
1. Paint Finish
a. Clean the painted surfaces with mild soap or detergent at least
once a month.
b. Protect the paint with a coat of non-abrasive auto wax every
three months.
2. Axles and Moving Parts
a. Clean around axles and moving parts WEEKLY with a slightly
damp (not wet) cloth.
b. Wipe off or blow away any fluff, dust or dirt on axles or moving
parts.
3. Upholstery
a. Hand-wash (machine washing may damage fabric).
b. Drip-dry only. DO NOT machine dry as heat will damage fabric.
4. Basic Maintenance Materials available at local store
a. Tire pump
b. Tire pressure gauge
c. Clean rags or cotton cloth.
d. Teflon-based lubricant
e. Mild detergent.
NOTE - You do not need to grease or oil the chair.
D. SAFETY CHECKLIST
Weekly 3 Months 6 Months Annually
Safety & Function Check
RTire Inflation level
RWheel locks
RVisually check for loose hardware
RArmrests
RAxle and axle sleeves
RQuick-release axles
RWheels, tires, and spokes
RCasters
RAnti-tip tubes
RFrame, Camber tubes, and Crossbrace
RUpholstery
RService by authorized dealer
NOTE - The user or caregiver should perform these weekly and monthly
checks to maintain the safety of their chair. If an item is not working properly,
please contact your authorized dealer.
E. TROUBLESHOOTING CHART
Left turn in chair Right turn in chair Looseness in chair Sluggish turning Squeaks and rattles Caster flutter Solution
R R R R
Make sure tire pressure is
correct and equal in both rear
tires and front caster tires, if
pneumatic.
R R R R Make sure all nuts and bolts
are tight.
R R
Make sure all spokes and
nipples are tight on radial
spoke wheels.
R
Use Tri-Flow Lubricant
(Teflon®-based) between
frame connections and parts
R R R R
Check for proper caster fork
adjustment. See instructions
for caster fork adjustment.
Symptoms

Quickie ®NITRUM
249817 Rev. A 16
VIII. USE AND MAINTENANCE
F. TO MOUNT & REMOVE REAR WHEELS
WARNING
Do not use this chair UNLESS you are sure both quick-release axles are locked. An unlocked axle may come
off during use and cause a fall.
NOTE– Setting the wheelchair on a flat surface, such as a workbench or table, helps make these procedures
easier.
1. To Install Wheel
a. Depress quick-release button (A) fully.
b. Insert axle (B) through hub of rear wheel.
c. Keep button (A) depressed as you slide axle (B) into camber plug (C).
d. Release button to lock axle in camber plug. Adjust axle if it does not lock. See Section VIII-B.
e. Repeat steps on other side.
2. To Remove Wheel
a. Depress quick-release button (A) fully.
b. Remove wheel by sliding axle (B) completely out of camber plug (C).
c. Repeat steps on other side.
NOTE– The axle is not locked until the quick-release button pops out fully (A). Check that the axle is locked
by pulling on the wheel in the direction of the axle.
G. WHEEL LOCKS
WARNING
Wheel locks are installed at Sunrise and should be adjusted by your qualified service person.
Inspect wheel locks weekly per the maintenance chart. Do not use your chair UNLESS you are sure both
wheel-locks can fully engage. A wheel-lock that is not correctly adjusted may allow your chair to roll, or turn
unexpectedly.
Wheel-locks must be adjusted after making sure the tires have the correct air pressure. When fully
engaged, the arm (D) should be imbedded into the tire at least 1/8inch to be effective.
If you find the wheel locks have slipped or are not working correctly contact your service provider for
proper adjustment.
H. ANTI-TIPS
Sunrise Medical recommends anti-tip tubes for all wheelchairs.
1. Inserting Anti-tip Tubes Into Receiver
a. Press the rear anti-tip release button ( I ) on the anti-tip tube so that both release pins are
drawn inside.
b. Insert the anti-tip tube (E) into the anti-tip receiver (F).
c. Turn the anti-tip tube down until release pin is through the receiver mounting hole.
d. Insert second anti-tip tube the same way.
2. Adjusting Anti-Tip Tube Wheel
The anti-tip wheels may have to be raised or lowered to achieve proper clearance of 1 1/2to 2 inches.
Press the anti-tip wheel release button (G) so that both release pins are drawn inside. Raise or lower
to one of the five predrilled holes (H). Release button. Adjust the second anti-tip tube wheel the same
way. Both wheels should be the same height.
3. Turning Anti-Tip Tubes Up
Turn anti-tip tubes up when being pushed by attendant, overcoming obstacles or climbing curbs. Press
the rear anti-tip tube release button ( I ). Hold lever in and turn anti-tip tube up. Release the lever and
repeat with second anti-tip tube. Remember to return anti-tip tubes to down position after completing
maneuver.
11 12
13
14
11
B
C
12
13
I
F
G
H
E
14

Quickie ®NITRUM
249817 Rev. A17
VIII. USE AND MAINTENANCE
I. SINGLE POST HEIGHT-ADJUSTABLE ARMRESTS (Option)
Sunrise Medical offers several different types of armrests. Fixed, Swing-away, and Flip-back armrests.
Swing-away armrests can be detached or can swing away to allow lateral transfers. They are height
adjustable (1-inch increments)
1. Basic Installation
a. Slide the outer armpost (1) into the receiver (7) mounted to the wheelchair frame.
b. The armrest should lock into place.
2. Height Adjustment
a. Release the upper securing lever. (2)
b. Slide armpad (4) up or down to desired height.
c. Return lever (2) to locked position.
3. Removing the Armrest
a. Squeeze the Release Lever (3) and remove the armrest from the receiver (7).
J. PADDED SWING-AWAY ARMRESTS (Option)
1. Installation
a. The armrest height is determined by the adjustment bolt (A) position.
b. Slide the armrest into the receiver tube (B) on rear of frame until the adjustment bolt is
securely seated (locked) in the receiver tube slot.
2. Swinging Away
a. Lift armrest out of the locked position and rotate to the side
3. Removing Armrest
a. Pull armrest straight out of the receiver.
K. FLIP-UP FOOTPLATE
The footplate (C) can be rotated up towards the user for transfers and adjustment.
L. FREESTYLE BACK (Option)
Back pad Installation
a. Wrap the Backpad (D) around the back shell (E) as shown.
b. Attach the Velcro straps so that the pad is secure.
WARNING
Make sure that your Authorized dealer, when doing regular maintenance, tightens the back hardware to the
torque specified in section IX-N. Do not use this chair UNLESS you are sure the adjustments are locked in
to this torque.
15
1. Outer armpost
2. Height release lever
3. Release lever
4. Armrest pad
5. Transfer bar
6. Side panel
7. Receiver
8. Receiver adjustment hardware
15
16 16
17
C
17
18 18

Quickie ®NITRUM
249817 Rev. A 18
M. BACK ANGLE PERFORMANCE
Adjusting the Angle of the Backrest
1. While the patient is out of the chair, use a 4mm Allen wrench and remove bolt (A) from both the right
and left backrest bracket. (Fig. 19)
2. Each of the backrest brackets has a number of holes to allow you to choose different backrest angles.
Once you have determined your new angle, reattach bolts (A) into the new holes in the backrest
brackets. With a 4mm Allen wrench and 8mm wrench, secure both bolts to 5 Nm.
Folding and Unfolding the Backrest
1. Release the backrest to fold the back down by pulling up on the release bar. (B) (Fig. 20)
2. To re-secure the backrest, pull up on the backrest towel bar until it locks back into the upright
position. There is also a second, (optional) way to fold the backrest down or back up. If the chair is
equipped with this option, there is a grip (C) that is located in the middle of the towel bar, that you
can rotate forward and the backrest can be folded down or back up. (Fig. 20)
WARNING
Towel Bar Use
NOTE: extreme impact or force to the backrest towel bar may cause degradation or failure of the towel
bar, release bar or the function of the backrest. Use caution when backing the chair up where the towel
bar handle (C), or release bar (B) may come into contact or rub up along something to allow the back to
unintentionally fold down. (Fig. 20)
N. TENSION ADJUSTABLE UPHOLSTERY
Installing Standard Tension Adjustable Backrest Upholstery
1. Slide Velcro® straps (F) over the backrest frame (G) section. Make sure to include at least one strap
below the towel bar (if using a rigid chair).
2. Tighten the straps appropriately to desired tension level. DO NOT over tighten straps as this will
cause undue strain upon the chair backrest frame (G).
3. If using fold down push handles, insert the single Velcro® strap (F) through the slots in the front of the
push handles ( I ).
If using integral push handles ( J ), slide straps from bottom of backrest upward.
4. Install backrest cover at desired level and fold over rear of Velcro® strapping system (K). The
Quickie patch should be upright on the rear of the chair.
5. Finish installation by placing vanity flap (center panel) down onto Velcro® on the seat sling to secure
attachment (L).
WARNING
Any changes made to the straps will affect the center of gravity. It is best to have the attendant stationed
behind the wheelchair to prevent the wheelchair from tipping backwards while the user becomes
accustomed to the adjustment.
19 20
VIII. USE AND MAINTENANCE
21 22 23 24
19
20
21
22
23
24
J
A

Quickie ®NITRUM
249817 Rev. A19
VIII. USE AND MAINTENANCE
O. SEAT SLING ADJUSTMENT
Remove the screws (A) retaining the left side seat sling. Readjust VELCRO®-style material to increase the
tension in the seat sling. Replace screws. If there is any difficulty in reattaching the screws, try using a probe
to help align the holes. Ensure that the plastic saddles (B) are under the seat rail in all fastener positions.
P. TENSION ADJUSTABLE SEAT SLING
The Tension Adjustble Seat Sling may be removed by first loosening the Velcro straps (C) that encircle the
chair frame. All straps must be reinstalled in the same position and quantity as the original set-up.
Q. CUSHION INSTALLATION
Place cushion on seat sling with VELCRO® side down. The beveled edge of the cushion should be in front.
Press firmly into place.
R. STORAGE TIPS
1. Store your chair in a clean, dry area. If you fail to do so, parts may rust or corrode.
2. Before using your chair, make sure it is in proper working order.
3. Inspect and service all items on the “Maintenance Chart”.
4. If stored for more than three months, have your chair inspected by an authorized dealer before use.
25
26
25
C
26

Quickie ®NITRUM
249817 Rev. A 20
S. LED AND BATTERY PACK
Switching the lights on: by pushing the button A on top of the control-Box (Fig.27), you can cycle through
operating-modes of the LEDs:
1. Full power mode 3. Flash-mode
2. Low-power mode 4. Off
The charging-status of the battery is indicated by the backlit button A :
• red: charging-status <50%
• red (when battery is connected to the charger): battery is charging
• green (when battery is connected to the charger): battery fully charged
Remove the control-box from the calf-strap for charging: detach cables on the sides by gently pulling the
pins out of the connectors (C ). Now pull the control-box upwards to remove it from the calf-strap.
Charge the battery: connect the USB-cable to the connector (B) on the front-side of the control-Box. Use
a standard USB-charger or your Computer´s USB-port to charge the battery. Green light will indicate a
fully charged battery.
Battery Specification
Battery-type Lithium-Ion
Nominal capacity 2600mAh
Nominal voltage 3.6V
Charging-time 3hrs
Checking batteries
• Before using LED for the very first time, please charge your batteries for a period of 24 hours.
• Are the batteries sufficiently charged? The green lights on the battery indicator must be on.
Attach to Chair:
1. Attach calf strap to chair.
2. Clean adhesive surfaces for LED light with LOCTITE ®SF7063.
3. LED Light screw positioning, pressing, and screwing, pointing cable towards frame (Fig. 28).
4. Lay the cable in calf strap as shown (Fig. 29).
5. Attach the calf strap cover to the rear and shorten it to length, cutting edge immediately to the right
of the sewn field (Fig. 30).
6. Clip the battery pack into calf strap, mount the plug, place remaining cable in the calf strap and
attach the cable ties.
T. CHECK OUT
After the wheelchair is assembled and adjusted, it should roll smoothly and easily. All accessories should
also perform smoothly. If you have any problems, follow these procedures:
1. Review the set-up and check-out sections and operating guide to make sure chair was properly
prepared.
2. Review the troubleshooting chart at the beginning of this section.
3. If your problem persists, contact your authorized dealer. If you still have a problem after contacting
your authorized dealer, contact Sunrise Medical customer service. See the Introduction Page for
details on how to contact your authorized dealer or Sunrise Medical customer service.
VIII. USE AND MAINTENANCE
27
27
28
29
30
31
28 29 30 31
Cutting edge immediately to
the right of the sewn field
C
B
A
