Sunrise Medical Quickie Rhapsody SB User manual

Owner’s Manual
Quickie®Rhapsody
CB, BB, SB
SUPPLIER: This manual must be given to the owner of this wheelchair.
RIDER: Before using this wheelchair read this entire manual and save
for future reference.
Mode d’emploi
Quickie®Rhapsody
CB, BB, SB
FOURNISSEUR: Ce manuel doit être remis à l’utilisateur / utilisatrice de ce
fauteuil roulant.
UTILISATEUR / UTILISATRICE : Avant d’utiliser ce fauteuil roulant, lisez
entièrement ce manuel et conservez le pour le consulter ultérieurement.
Manual de
Instrucciones
Quickie®Rhapsody
CB, BB, SB
DISTRIBUIDOR: Este manual debe ser entregado al pasajero de esta
silla de ruedas.
PASAJERO: Antes de usar esta silla de ruedas, lea este manual en su
totalidad y guárdelo para futura referencia.
Rhapsody
Improving People’s Lives

101244 Rev. G 2
ENGLISH
I. INTRODUCTION
I. INTRODUCTION
SUNRISE LISTENS
Thank you for choosing a Quickie wheelchair. We want to hear your questions or comments
about this manual, the safety and reliability of your chair, and the service you receive from your
Sunrise supplier. Please feel free to write or call us at the address and telephone number below:
SUNRISE MEDICAL
Customer Service Department
7477 East Dry Creek Parkway
Longmont, Colorado 80503
[phone] or [phone]
FOR ANSWERS TO YOUR QUESTIONS
Your authorized supplier knows your wheelchair best and can answer most of your questions
about chair safety, use and maintenance. For future reference, fill in the following:
Supplier: ______________________________________________________________________________
Address: _______________________________________________________________________________
______________________________________________________________________________________
Telephone: _____________________________________________________________________________
Serial #: _______________________________________ Date/Purchased: ________________________

101244 Rev. G
3
ENGLISH
II. TABLE OF CONTENTS
II. TABLE OF CONTENTS
I. INTRODUCTION................................................... 2
II. TABLE OF CONTENTS.......................................... 3
III. YOUR CHAIR AND ITS PARTS ............................ 4
IV. NOTICE - READ BEFORE USE.............................. 5
V. EMI (ELECTROMAGNETIC INTERFERENCE)...... 5
A.What is EMI................................................................ 5
B. What Effect Can EMI Have........................................ 5
C.Sources of EMI........................................................... 5
D.Distance From the Source......................................... 6
E. Immunity Level........................................................... 6
F. Report All Suspected EMI Incidents........................... 6
VI. GENERAL WARNINGS .......................................... 6
A.Notice to Rider .......................................................... 6
B. Notice to Attendants ................................................. 6
C.Weight Limit............................................................... 6
D.Controller Settings..................................................... 7
E. EMI............................................................................. 7
F. Safety Check-List ....................................................... 7
G.Changes & Adjustments............................................. 7
H.When Seated in a Parked Wheelchair........................ 7
I. Environmental Conditions ......................................... 7
J. Terrain ........................................................................ 7
K.Street Use .................................................................. 8
L. Motor Vehicle Safety.................................................. 8
M.Center of Balance...................................................... 8
N.Transfers..................................................................... 8
O.Reaching or Leaning................................................... 8
P. Dressing or Changing Clothes ................................... 9
Q.Obstacles ................................................................... 9
R. Driving in Reverse...................................................... 9
S. Ramps, Slopes & Sidehills........................................... 9
T To Reduce the Risk of Falls, Tip-over or
Loss of Control .......................................................... 9
U.Ramps at Home & Work............................................ 9
V. Wheelchair Lifts ......................................................... 9
W.Curbs & Single Steps.................................................. 10
X.Stairs........................................................................... 10
Y. Escalators ................................................................... 10
VII. WARNINGS: COMPONENTS & OPTIONS.......... 10
A.Armrests .................................................................... 10
B. Batteries..................................................................... 10
C.Cushions..................................................................... 10
D.Fasteners.................................................................... 10
E. Footplate & Footrests................................................ 10
F
.Motor Locks............................................................... 11
G.On/Off Switch............................................................ 11
H.Pneumatic Tires ......................................................... 11
I. Positioning Belts......................................................... 11
J. Seating Systems.......................................................... 11
K.Upholstery Fabric ...................................................... 11
L. Suspension.................................................................. 11
M.Wiring ........................................................................ 11
N.Power Seating ............................................................ 12
O. C.G. Power Tilt Accessory....................................... 12
VIII. SET UP, ADJUSTMENT & USE.............................. 13
Notes ............................................................................. 13
Tools You Will Need ...................................................... 13
Check Out ..................................................................... 13
A.Battery Removal......................................................... 14
B. Footplate Adjustment ................................................ 14
C.Center Mount Hanger Adjustment............................ 15
D.Swing-Away Footrests ............................................... 15
E. Elevating Legrests....................................................... 15
F. Joystick or Enhanced Display Swing-Away
Retractable Mount ..................................................... 16
G.A.S.A.P. Seating Adjustment ....................................... 16
H.Flip-Back Armrests Adjustment ................................. 16
I. Backrest ..................................................................... 16
J. Seat Height Adjustment ............................................. 16
K.Seat Removal.............................................................. 17
L. Shroud Removal......................................................... 17
M.Check-Out................................................................. 17
IX. OPERATING GUIDE .............................................. 18
A.Performance Control Settings ................................... 18
B. Thermal Roll-Back...................................................... 18
C.Circuit Breakers......................................................... 18
D.Joystick Assembly....................................................... 18
E. Motor Locks............................................................... 19
X. BATTERIES ............................................................. 20
A.Introduction ............................................................... 20
B. Battery Charger ......................................................... 20
C.Acid Burns.................................................................. 20
D.Connecting Batteries in Battery Well......................... 20
E. Charging Batteries...................................................... 21
F. Disposing of Batteries ................................................ 21
XI. MAINTENANCE..................................................... 22
A.Notes ......................................................................... 22
B. Cleaning ..................................................................... 22
C.Storage Tips ............................................................... 22
D.Battery Maintenance .................................................. 22
E. Pneumatic Tires ......................................................... 22
F
. To Repair or Replace a Tire ....................................... 22
G.Motor Brushes ........................................................... 23
H.Ordering Parts ........................................................... 23
I. Maintenance Chart..................................................... 23
J. Wiring Diagram.......................................................... 23
XII. SUNRISE LIMITED WARRANTY .......................... 24
ESPAÑOL................................................................ 25
FRANÇAIS.............................................................. 48

101244 Rev. G 4
ENGLISH
III. YOUR CHAIR AND ITS PARTS
III. YOUR CHAIR AND ITS PARTS
1. Flip-back, height-adjustable armrest
(CB only)
2. VR2 controller joystick
3. Contour seat or Contour Flat Pan
seat (CB only)
4. Front caster 7"
5. Rear stabilizing caster 6"
6. Single plate foot platform
(CB and BB only)
7. 10" drive wheels
8. Freewheel release
9. Caster Fork (front)
10. Caster Fork (rear)
11. Shroud
1
3
6
7
8
9
11
4
5
10
2
Weight
199 lbs (complete chair)
151 lbs (w/o batteries)
107 lbs (base)
44 lbs (seat w/armrests & joystick)
(CB only)
Drive Wheels
10" Mag: Std. airless insert,
Joystick
Standard – VR2 (right-hand or
left-hand mount)
Option - VR2 w/actuator control
(SB only)
Batteries
(2 deep cycle batteries required to
operate chair)
Standard - U1 Gel
Option - 50Ahr
Battery Charger
Off board 5 AMP
Colors
Red, Blue
Seats, Upholstery and Style
High back chair offers semi recline
(CB only)
Material: vinyl
Color: grey
Width: 16, 18, 20
Depth: 16, 18, 20
Sizes:
16" W x 16" D (depth adj. 16"-18")
18" W x 18" D (depth adj. 17"-19")
20" W x 19" D (depth adj. 18" - 20")
Option- Grey cloth seat cover
Standard-
A.S.A.P. (Adjustable Seating and Positioning)
Rehab Seat Frame (BB, SB only):
Sizes: 16" - 20" wide, 16" - 20" deep
Footrest:
Standard (CB & BB)- Foot Platform
Option- Swing away footrests with heel
loops
Option- Manual elevating legrests
Casters (front)
Standard- 7” solid
Casters (rear)
Standard- 6” solid
Armrest
14" Flip back, height adjustable
14" arm pad (CB, BB, SB)
Option- Flip back, Fixed height,
14" armpad (CB only)
Suspension
Standard- all wheel independent
All features may not be available with some
chair setups or in conjunction with another
chair feature. Please consult your supplier
for more information. Your authorized sup-
plier can also provide you with more infor-
mation on accessories.
QUICKIE RHAPSODY

101244 Rev. G
5
ENGLISH
IV. NOTICE– READ BEFORE USE
IV. NOTICE– READ BEFORE USE
A. CHOOSE THE RIGHT CHAIR & SAFETY
OPTIONS
Sunrise provides a choice of many power wheelchair styles, sizes
and adjustments to meet the needs of the rider. However, final
selection of a wheelchair rests solely with you and your health care
professional. Choosing the best chair for you depends on such
things as:
1. Your size, disability, strength, balance and coordination.
2. Your intended use, and your level of activity.
3. The types of hazards you must overcome in daily use (in
areas where you are likely to use your chair).
4. The need for options for your safety and comfort (such as
positioning belts or special seat systems).
B. ADJUST CHAIR TO YOUR ABILITY
You need to work with your doctor, nurse or therapist, and your
supplier, to fit this chair and adjust the controller settings for your
level of function and ability.
C. REVIEW THIS MANUAL OFTEN
Before using this chair you, and each person who may assist you,
should read this entire Manual and make sure to follow all instruc-
tions. Review the warnings often, until they are second nature to you.
D. WARNINGS
The word “WARNING” refers to a hazard or unsafe practice that
may cause severe injury or death to you or to other persons. The
“Warnings” are in four main sections, as follows:
1. V — EMI
Here you will learn about electromagnetic interference and
how it can affect your chair.
2. VI — GENERAL WARNINGS
Here you will find a safety checklist and a summary of risks
you need to be aware of before you ride this chair.
3. VII — WARNINGS — COMPONENTS & OPTIONS
Here you will learn about your chair. Consult your supplier
and your health care professional to help you choose the
best set-up and options for your safety.
4. XI — BATTERIES
Here you will learn about battery and charger safety, and
how to avoid injury.
NOTE– Where they apply, you will also find “Warnings” in other sections of
this Manual.
V. EMI (ELECTROMAGNETIC INTERFERENCE
V. EMI (ELECTROMAGNETIC INTERFERENCE)
WARNING
Heed all warnings to reduce the risk of unintended
brake release or chair movement:
1. Beware of the danger from hand-held transceivers. (A
“transceiver” is a device that both sends and receives
radio wave signals). Never turn on or use a hand-held
transceiver while power to your chair is on. Use extra
care if you believe that such a device may be in use
near your chair.
2. Be aware of nearby radio or TV stations, and avoid
coming close to them.
3. If unintended movement occurs, turn your chair off as
soon as it is safe to do so.
A. WHAT IS EMI?
WARNING
1. EMI means: electromagnetic (EM) interference (I). EMI
comes from radio wave sources such as radio transmitters
and transceivers.
2. There are a number of sources of intense EMI in your daily
environment. Some of these are obvious and easy to avoid.
Others are not, and you may not be able to avoid them.
3. Powered wheelchairs may be susceptible to electromagnetic
interference (EMI) emitted from sources such as radio sta-
tions, TV stations, amateur radio (HAM) transmitters, two
way radios, and cellular phones.
4. EMI can also be produced by conducted sources or electro-
static discharge (ESD).
B. WHAT EFFECT CAN EMI HAVE?
WARNING
1. EMI can cause your chair, without warning, to:
• Release its brakes
•Move by itself
•Move in unintended directions
If any of these occurs, it could result in severe injury to you or
others.
2. EMI can damage the control system of your chair. This could
create a safety hazard, and lead to costly repairs.
C. SOURCES OF EMI
WARNING
The sources of EMI fall into three broad types:
1. Hand-Held T
ransceivers:
The antenna is usually mounted directly on the unit. These
include:
• Citizens band (CB) radios
•“Walkie-talkies”
• Security, fire and police radios
• Cellular phones
•Lap-top computers with phone or fax
• Other personal communication devices
NOTE– These devices can transmit signals while they are on, even if not in
use.
2. Medium-Range Mobile T
ransceivers:
These include two-way radios used in police cars, fire trucks,
ambulances and taxi cabs. The antenna is usually mounted on the
outside of the vehicle.

101244 Rev. G 6
ENGLISH V.
3. The Quickie Rhapsody with the following configuration was
tested and found to be immune to at least 20 V/m:
Quickie Rhapsody power wheelchair with a right-hand
mounted Penny & Giles VR2, highback seat, flip-back arm-
rests, solid flip-up footplate and U1 gel cell batteries.
WARNING
Individuals with physical limitations requiring the use of
a specialty control input device known not to be
immune to 20V/m, or not known, should exercise extra
care around known sources of EMI.
WARNING
There is no way to know the effect on EMI if you add
accessories or modify this chair. Any change to your
chair may increase the risk of EMI. Parts from other
suppliers have unknown EMI properties.
F. REPORT ALL SUSPECTED EMI
INCIDENTS
WARNING
You should promptly report any unintended movement
or brake release. Be sure to indicate whether there was
a radio wave source near your chair at the time.
Contact: Sunrise Medical Customer Service
Department at [phone].
3. Long-Range Transceivers:
These include commercial radio and TV broadcast antenna towers
and amateur (HAM) radios. Note: The following are not likely to
cause EMI problems: Lap-top computers (without phone or fax),
Cordless phones, TV sets or AM/FM radios, CD or tape players.
D. DISTANCE FROM THE SOURCE
WARNING
EM energy rapidly becomes more intense as you get
closer to the source. For this reason, EMI from hand-
held devices is of special concern. (See C.1 above) A
person using one of these devices can bring high levels
of EM energy very close to your chair without you
knowing it.
E. IMMUNITY LEVEL
WARNING
1. The level of EM energy is measured in volts per meter (V/m).
Every power wheelchair can resist EMI up to a certain level.
This is called its “immunity level”.
2. The higher the immunity level, the less the risk of EMI. It is
believed that a 20 V/m immunity level will protect the power
wheelchair user from the more common sources of radio
waves.
VI. GENERAL WARNINGS
B. NOTICE TO ATTENDANTS
WARNING
Make sure you heed all warnings and follow all instruc-
tions in each section of this manual. (Be aware that
warnings that apply to the rider also apply to you).
Notes:
1. You need to work with the rider and the rider’s doctor,
nurse or therapist, to
develop safe methods best suited to your abilities and those
of the rider.
2. To manually push the chair you must release the motor locks.
Make sure you have full control over the chair when you
release the motor locks. When you do so the chair will not
have brakes.
3. Propel this chair by the armrest supports only. If using a seat
frame, propel the chair by the push handles on the top of the
backrest. They provide secure points for you to hold the rear
of the chair to prevent a fall or tip-over.
C. WEIGHT LIMIT
WARNING
1. Never exceed a total weight of 300 pounds (136.3 kilograms)
for rider plus items carried.
2. Never use this chair for weight training if the total weight
(rider plus additional weights) exceeds 300 pounds (136.3
kilograms).
VI. GENERAL WARNINGS
WARNING
Heed all warnings in this section. If you fail to do so a
fall, tip-over or loss of control may occur and cause
severe injury to you or others.
A. NOTICE TO RIDER
WARNING
1. Before using this chair, you should be trained in its safe use
by your health care professional.
2. Every wheelchair is different. Take the time to learn the feel
of this chair before you begin riding.
3. Be aware that you must develop your own methods for the
safe use of this chair that are best suited to your level of
function and ability.
4. Have someone help you practice bending, reaching and
transferring until you learn how to do them safely.
5. Never try a new maneuver on your own unless you are sure
it is safe.
6. Get to know the areas where you plan to use your chair.
Look for hazards and learn how to avoid them.
7. Do not allow additional riders on the chair, armrests or chas-
sis. Doing so may result in injury or damage.

101244 Rev. G
7
ENGLISH VI.
3. Exceeding the weight limit is likely to damage the seat,
frame, or fasteners and may cause severe injury to you or
others from chair failure.
4. Exceeding the weight limit will void the warranty.
D. CONTROLLER SETTINGS
WARNING
Be aware that you may need to adjust the controller
settings of your chair to reduce the risk of a collision,
fall or tip-over.
1. Check and adjust the settings every six to twelve months (or
more often, if needed).
2. Consult your supplier to adjust the control settings immedi-
ately if you notice any change in your ability to:
• Control the joystick.
• Hold your torso erect.
• Avoid running into objects.
E. EMI
WARNING
Read Section V to learn about EMI. To reduce the risk
of unintended brake release or chair movement:
1. Never turn on or use a hand-held transceiver while power to
your chair is on. Use extra care if you believe that such a
device may be in use near your chair.
2. Be aware of nearby radio or TV stations, and avoid coming
close to them.
3. If unintended movement or brake release occurs, turn your
chair off as soon as it is safe.
F. SAFETY CHECK-LIST
WARNING
Before each use of this chair:
1. Make sure the chair operates smoothly. Check for noise, vibra-
tion, or a change in ease of use. (They may indicate low tire
pressure, loose fasteners, or damage to your chair). If you
detect a problem, make sure to repair or adjust the chair.
Deferring repair or adjustment could increase the risk for
injury. Your supplier can help you find and correct the problem.
2. Make sure batteries are charged. Green lights on the con-
troller charge indicator will light up when charge is full.
Yellow lights indicate battery charge level is getting low. Red
lights indicate batteries are in immediate need of charging.
G. CHANGES & ADJUSTMENTS
WARNING
Never use non-Quickie parts or make changes to your
chair unless authorized by Sunrise. (Doing so will void
the Warranty and may create a safety hazard).
1. If you modify or adjust this chair it may increase the risk of a
fall or tip-over.
2. Modifications unauthorized by Sunrise constitutes remanufac-
turing of the wheelchair. This voids the warranty. The rider
then assumes all future liability for the wheelchair.
H. WHEN SEATED IN A PARKED
WHEELCHAIR
WARNING
1. Always turn off all power to your chair when you are parked,
even for a moment. This will prevent:
• Accidental movement from contact with the joystick by
you or others.
• Unintended brake release or movement from EMI
sources. (See Section V)
2. Make sure that persons who help you (for example, store
clerks) are aware of the joystick and do not touch it. If they
do, your chair may move suddenly when you do not expect it.
I. ENVIRONMENTAL CONDITIONS
WARNING
Your chair is not designed for use in a heavy rain storm,
or in snowy or icy conditions.
1. Contact with water or excessive moisture can cause an elec-
trical malfunction. The frame, motors and other chair parts
are not watertight and may rust or corrode from the inside.
To avoid a chair failure:
• Minimize exposure of your chair to a rain storm or very
wet conditions.
• Never take your chair into a shower, tub, pool or sauna.
• Do not use your chair in fresh or salt water (such as at
the edge of a stream, lake, or ocean).
• Make sure shroud cover and deck lid are secure.
• Replace joystick boot if it becomes torn or cracked.
• Make sure all electrical connections are secure.
• Dry the chair as soon as you can if it gets wet, or if you
use water to clean it.
2. Proceed slowly and use extra care if you must operate your
chair on a wet or slick surface.
• Do so only if you are sure it is safe.
• Stop if one or both main wheels lose traction. If this
occurs, you may lose control of your chair or fall.
• Never operate your chair on a slope or ramp if there is
snow, ice, water or oil film present.
• When in doubt, have someone help you.
3. When not in use, keep your chair in a clean, dry place.
J. TERRAIN
WARNING
1. This chair is designed for use on firm, even surfaces such as
concrete, asphalt and indoor flooring.
2. Do not operate your chair in sand, loose soil or over rough
terrain. Doing so may damage wheels, bearings, axles or
motors, or loosen fasteners.

101244 Rev. G 8
ENGLISH VI.
3. Work with your health care professional to learn safe methods.
• Learn how to position your body and how to support
yourself during a transfer.
• Have someone help you until you are sure you can do a
safe transfer on your own.
4. Move your chair as close as you can to the seat you are
transferring to. If possible, use a transfer board.
5. Rotate the front casters until they are as far forward as
possible.
6. Be careful of the foot platform. If you can, remove or swing
it out of the way.
• Never stand on footrests when you transfer. Doing so
may damage them or cause your chair to tip.
• Make sure your feet do not “hang up” or get caught in
the space between the footrests.
7. Make sure armrests do not interfere.
8. Transfer as far back onto the seat surface as you can. This
will reduce the risk that you will miss the seat or fall.
O. REACHING OR LEANING
WARNING
Reaching or leaning affects the center of balance of your
chair. If done improperly, a fall or tip-over is likely. When in
doubt, ask for help or use a device to extend your reach.
To Reduce the Risk of injury and/or Damage to the Chair:
1. Never reach or lean if you must shift your weight sideways
or rise up off the seat.
2. Never reach or lean if you must move forward in your seat
to do so. Always keep your buttocks in contact with the
backrest.
3. Never reach with both hands (you may not be able to catch
yourself to prevent a fall if you lose your balance).
4. Never try to pick up an object from the floor by reaching
down between your knees.
5. Never put pressure on the foot platform while reaching. This
may cause the chair to tip if you lean too far.
6. Never reach or lean over the top of the seat back. This may
damage the backrest and cause you to fall.
IF YOU MUST REACH OR LEAN, DO SO AT
YOUR OWN RISK.
Remember to:
1. Move your chair as close as you can to the object you wish
to reach.
2. Rotate the front casters until they are as far forward as possi-
ble. This makes the chair more stable.
NOTE– To do this: Move your chair past the object you want to reach, then
back up alongside it. Backing up will rotate the casters forward.
3. Turn off all power to your chair. If you fail to do so, you may
touch the joystick and cause your chair to move when you
do not expect it.
4. Firmly grasp an armrest with one hand. This will help to pre-
vent a fall if the chair tips.
K. STREET USE
WARNING
In most states, power chairs are not legal for use on
public roads. Be alert to the danger of motor vehicles
on roads or in parking lots.
1. At night, or when it is hard to see, use reflective tape on
your chair and clothing.
2. It may be hard for drivers to see you. Make eye contact with
drivers before you proceed. When in doubt, yield until you
are sure it is safe.
L. MOTOR VEHICLE SAFETY
WARNING
To date, the U.S. Department of Transportation has not
approved any tie down system for transporting this
wheelchair in a motor vehicle.
1. Never sit in this chair while in a moving vehicle. In an acci-
dent or sudden stop you may be thrown from the chair.
• Wheelchair belts are designed to position the rider
only and will not protect you in an accident; further
injury may result from the belts.
2. Always move to an approved vehicle seat. You must be
secured with proper motor vehicle restraints.
3. Never transport this chair in the front seat of a vehicle. It
may shift and interfere with the driver.
4. Always secure this chair so that it cannot roll or shift.
M. CENTER OF BALANCE
WARNING
The point where this chair will tip forward, back or to
the side depends on its center of balance and stability.
The Center Of Balance Is Affected By:
1. The seat height and seat angle.
2. A change in your body position, posture or weight distribution.
3. Using this chair on a ramp or slope.
4. The use of a back pack or other options, and the amount of
added weight.
To Reduce The Risk Of A Fall Or Tip-Over:
1. Consult your supplier for information on modifications
authorized by Sunrise before you modify or adjust this chair.
NOTE– You may need to make additional changes to correct the center of
balance.
2. Use extreme care until you know the balance points of this
chair and how to avoid a fall or tip-over.
N. TRANSFERS
WARNING
It is dangerous to transfer on your own. It requires
good balance and agility. Be aware that there is a point
during every transfer when the wheelchair seat is not
below you. To avoid a fall:
1. Always turn off power before you transfer to or from your
chair. If you fail to do so you may touch the joystick and
cause your chair to move when you do not expect it.
2. Make sure motor locks are engaged. This keeps the chair
from moving when you transfer.

101244 Rev. G
9
ENGLISH VI.
P. DRESSING OR CHANGING CLOTHES
WARNING
Be aware that your weight will shift if you dress or
change clothes while seated in this chair. To make the
chair more stable, rotate the front casters until they are
forward.
Q. OBSTACLES
WARNING
Obstacles you may have to overcome in daily use
include door thresholds, lifts, ramps and hazards such as
potholes and broken pavement. These can damage your
chair and may cause a fall, tip-over or loss of control.
1. Be aware that thresholds are very dangerous. (Even a small
change in height may stop a caster wheel and cause your
chair to tip). You may need to:
• Remove or cover threshold strips between rooms.
• Install a ramp at entry or exit doors.
2. Keep your eyes moving when you ride; scan the area well
ahead of your chair.
3. Make sure the floor areas where you use this chair are level
and free of obstacles.
4. To help correct your center of balance:
• Lean your upper body forward slightly as you go up over
an obstacle.
• Press your upper body backward as you go down from a
higher to a lower level.
R. DRIVING IN REVERSE
WARNING
Use extra care when you drive your chair in reverse.
You may lose control or fall if one of the rear wheels
hits an object.
1. Operate your chair slowly and at an even speed.
2. Stop often and check to make sure your path is clear of
obstacles.
S. RAMPS, SLOPES & SIDEHILLS
WARNING
The center of balance of your chair changes when you
are on a slope.
NOTE– “Slope” includes a ramp or sidehill. Your chair is less stable when it
is at an angle. Never use this chair on a slope unless you are sure it
is safe. When in doubt, have someone help you.
Beware Of:
1. Steep slopes. Do Not use this chair on a slope steeper than
10%. (A 10% slope means: One foot in elevation for every
ten feet of slope length).
2. Wet or slippery surfaces (such as when ice, snow, water or oil
film is present). A loss of traction may cause a fall or tip-over.
3. A change in grade on a slope (or a lip, bump or depression).
These may cause a fall or tip-over.
4. A drop-off at the bottom of a slope. (A drop-off of as small
as 3/4 inch can stop a front caster and cause the chair to tip
forward).
T. TO REDUCE THE RISK OF A FALL,
TIP-OVER OR LOSS OF CONTROL
WARNING
1. Never use your chair on a slope unless you are sure you can
do so without losing traction.
2. Always go as straight up and as straight down as you can.
• Do not “cut the corner” on a slope or ramp.
• Do not turn or change direction on a slope.
3. Always stay in the center of the ramp. Make sure ramp is
wide enough that you are not at risk that a wheel may roll
off the side.
4. Lean or press your body uphill. This will help adjust for a
change in the center of balance caused by the slope.
5. Keep your chair moving at a slow, steady speed. Keep control
over the chair at all times.
• On a descent, do not let your chair accelerate beyond its
normal speed.
• If the chair picks up speed, center the joystick to slow
down or stop.
NOTE– The solid state controller of your chair has a logic system that will
help control your speed when driving on a slope or uphill.
• If you stop, re-start slowly.
U. RAMPS AT HOME & WORK
WARNING
Make sure ramps meet all Building Codes for your area.
1. For your safety, have a licensed contractor build or remodel
ramp to meet all standards.
2. NOTE– The proper design will vary, depending on such
things as: the length and height of the ramp; the need for an
intermediate platform; landing size; doors and the direction
of swing; and whether the ramp includes a turn or angle.
At A Minimum:
1. Open sides of ramp must have side rails to prevent your
chair from going over the edge.
2. Slope must not be steeper than one inch in height for every
one foot of slope length.
3. Ramp surface must be even, and have a non-skid surface.
4. You may need to add a section at the top or bottom to avoid
a lip or drop-off.
5. Ramp must be sturdy. Add bracing if needed, so ramp does
not “bow” when you ride on it.
V. WHEELCHAIR LIFTS
WARNING
Wheelchair lifts are used in vans, buses, and buildings to
help you move from one level to another.
1. Always turn off all power to your chair when you are on a lift.
If you fail to do so, you may touch the joystick by accident
and cause your chair to drive off the platform. (Be aware that
a “roll-stop” at the end of the platform may not prevent this).
2. Make sure there is not a lip or drop-off at the top or bottom
of the platform. These may cause a fall or tip-over. When in
doubt, have someone help you.
3. Always secure the rider with a positioning belt to help pre-
vent falls during transfers.
4. Avoid moving forward if a wheel is “hung up” on the lip of
the ramp. Backup, reposition the caster for a more direct
approach and slowly try again.

101244 Rev. G 10
ENGLISH VI.
X. STAIRS
WARNING
Never use this chair to go up or down stairs, even with
an attendant. Doing so is likely to cause a fall or tip-
over.
Y. ESCALATORS
WARNING
Never take this chair on an escalator, even with an
attendant. Doing so is likely to cause a fall or tip-over.
W. CURBS & SINGLE STEPS
WARNING
1. Your chair is not designed to drive up or down a curb or step
more than two (2.0) inches high. Doing so may:
• Result in a fall or tip-over.
• Damage the frame, wheels, axles or other chair parts, or
loosen fasteners.
2. To prevent a fall or tip-over, use wheelchair access ramps or
have someone help you.
3. If you must climb or descend a curb or step alone do so at
your own risk and use extreme care.
• Go as straight up or straight down as you can. Never turn
or climb or descend at an angle as a fall or tip-over is
likely.
• Proceed slowly, at a steady speed.
4. Avoid driving along curb edges and drop-offs. A minimum
distance from the edge of 18” is recommended.
VII. WARNINGS: COMPONENTS & OPTIONS
• Consult your doctor, nurse or therapist to find out if you
need such a device for your well-being.
D. FASTENERS
WARNING
Many of the screws, bolts and nuts on this chair are spe-
cial high-strength fasteners. Use of improper fasteners
may cause your chair to fail.
1. Only use fasteners recommended by Sunrise.
2. If fasteners become loose, tighten them as soon as you can.
3. Over- or under-tightened fasteners may fail or cause damage
to chair parts.
• See Section VIII, “Set-Up, Adjustment & Use”, for proper
torque settings.
E. FOOTPLATE & FOOTRESTS
WARNING
1. At the lowest point, the foot platform and footrests should
be at least 2 1/2" off the ground. If set too LOW, it may “hang
up” on obstacles you can expect to find in normal use. This
may cause the chair to stop suddenly and tip forward.
2. To avoid a trip or fall when you transfer:
• Make sure your feet do not “hang up” or get caught in
the space surrounding or in between the footrests.
• Avoid putting weight on the footplate or footrests, as the
chair may tip forward.
• Flip the footplate back or swing the footrests out of the
way, if possible.
3. Never lift this chair by the footplate or footrests. Footrests
fold or detach and will not bear the weight of this chair. Lift
this chair only by non-detachable parts of the main frame.
VII. WARNINGS: COMPONENTS & OPTIONS
WARNING
Note: If you use parts or make changes not authorized
by Sunrise it may create a safety hazard and will void
the Warranty.
A. ARMRESTS
WARNING
Armrests cannot be used to lift chair or the seat.
1. Never lift this chair by its armrests.
2. Lift this chair only by non-detachable parts of the main frame.
B. BATTERIES
WARNING
1. Only deep cycle sealed case construction batteries should be
used in this device.
2. To prevent an acid spill, always keep batteries upright.
(wet cell batteries only)
3. Never smoke or hold an open flame near batteries. They are
a known explosion hazard.
4. Always wear rubber gloves and safety glasses when you han-
dle batteries.
5. Read all of section X Batteries before attempting to change
or charge batteries.
C. CUSHIONS
WARNING
1. Quickie Highback seats are designed for comfort, not specifi-
cally for the relief of pressure.
2. If you suffer from pressure sores, or if you are at risk that
they will occur, you may need a special seat system such as
can be provided by the Seat Frame, or a device to control
your posture.

101244 Rev. G
11
ENGLISH VII.
F. MOTOR LOCKS
WARNING
1. Do not engage or disengage motor locks unless power to the
chair is off. In addition, make sure both free wheel levers are
completely pushed in before turning the power on to ensure
the wheelchair can be driven in a straight forward motion.
2. Be aware that the chair will not have brakes when motor
locks are in the free-wheel position. (See Section F of
Operating Guide.)
3. Make sure that the person pushing the chair has full control
when motor locks are disengaged.
4. Make sure the chair is on level ground when motor locks are
disengaged.
NOTE– The wheelchair may need to be rocked back and forth slightly
several times before the lock will release.
G. ON/OFF SWITCH
WARNING
1. Never use the ON/OFF switch to stop the chair except in an
emergency. This will result in an abrupt stop and may cause
you to fall.
2. To slow your chair to a stop, return the joystick to neutral,
before turning off the chair.
H. PNEUMATIC TIRES (OPTIONAL)
WARNING
Proper inflation extends the life of your tires and makes
your chair easier to use.
1. Do not use this chair if any of the tires are under- or over-
inflated. Check weekly for proper inflation level, as listed on
the tire sidewall.
2. Low pressure in a tire may cause the chair to veer to one
side and result in a loss of control.
3. An over-inflated tire may burst.
4. Never use a gas station air pump to inflate a tire. Such pumps
provide air at high volume, and could cause the tire to burst.
To prevent tire damage:
• Use a hand pump (or a low volume air pump) to inflate
tires.
• Use a tire gauge to check pressure.
5. Driving over sharp objects may cause damage to pneumatic
tires and tubes.
I. POSITIONING BELTS
WARNING
Use a positioning belt only to help support your pos-
ture. Improper use of such belts may cause severe
injury or death.
1. Make sure you are not at risk to slide down in the wheelchair
seat. If this occurs, you may suffer chest compression or suf-
focate due to pressure from the belt.
2. A pelvic wedge or a similar device can help you from sliding
down in the seat. Consult your health care professional to
find out if you need such a device.
3. The belt must be snug, but must not be so tight that it inter-
feres with breathing. You should be able to slide your open
hand, flat, between the belt and your stomach.
4. Make sure you can easily remove the belt in an emergency.
5. Never use a positioning belt:
• In place of a motor vehicle seat belt. In an accident or
sudden stop you may be thrown from the chair. A posi-
tioning belt will not prevent this, and further injury may
result from the belt.
• As a restraint. A restraint requires a doctor’s order.
• On a rider who is comatose or agitated.
J. SEATING SYSTEMS
WARNING
1. Use of a seating system not approved by Sunrise may alter
the center of balance of this chair. This may cause a fall or
tip-over.
2. Never change the seating system of your chair unless you
consult your supplier first.
K. UPHOLSTERY FABRIC
WARNING
1. Replace worn or torn fabric of the seat as soon as you can. If
you fail to do so, the seat may fail and cause you to fall. Worn
fabrics may increase the potential for a fire hazard.
2. Fabric will deteriorate with age and use. Look for fraying,
thin spots, or stretching of fabric at rivet holes. Replace fabric
as required.
3. Be aware that washing may reduce flame retardation of the
fabric.
L. SUSPENSION
WARNING
The suspension system does contain Dry Natural
Rubber. The suspension, or any other component on the
chair, does not contain any latex based product. The
suspension components are enclosed and inaccessible to
the user.
M. WIRING
WARNING
Never pull on cables directly. This can result in wires
breaking inside the connector or harness. T
o remove a
plug or connector, always grasp the plug or connector
itself. (See section XI for wiring diagram.)

101244 Rev. G 12
ENGLISH VII.
N. POWER SEATING (SB only)
WARNING
1. Operation
• While driving this wheelchair in the tilted position use cau-
tion.
• Do Not attempt to operate any power seating option
while positioned on an incline.
• Do Not attempt to operate any power seating option
while this wheelchair is in motion.
• Do not attempt to operate the power seating options
around children.
2. Drive Inhibit
This power chair is designed to automatically inhibit driving
when the power seating is tilted more than 17°.
3. Pinch points
Pinch points may occur when operating the powered seating
options on this chair. Ensure all hands and body parts are
clear of all power seating components that may result in
pinch points before operating them.
4. Tilting Power Base with Push Handles
Do not attempt to tilt power wheelchairs by pulling down on
the push handles. Power wheelchairs have heavy bases. As
such, attempting to tilt a power wheelchair to traverse
obstacles can damage components in the seating system
and/or modular actuators.
5. Remain Clear During Power Accessory Operation
Please stay clear of any powered actuator while the compo-
nent is in motion. Sunrise power mechanisms move over
large ranges of travel. Users should be aware of their sur-
roundings while components are in motion.
6. Maximum User Weight
Do not exceed the weight capacity for your specific
chair/seating system configuration. Doing so could result in
premature failure or injury.
O. CG TILT POWER ACCESSORY (SB only)
WARNING
The powered CG Tilt accessory for this chair has a maximum
user weight capacity of up to 300 lbs. Never exceed this
capacity while operating the powered actuator.
WARNING
The powered CG Tilt should not be operated for more than
three minutes of continuous use. Doing so may shorten the
life of the powered CG Tilt.

VIII. SET-UP, ADJUSTMENT & USE
NOTES:
1. Work Surface For Set-Up:
Use a flat surface, such as a table, to assemble, adjust and check your chair. This makes the
steps easier and helps ensure a correct set-up.
2. Fasteners:
•Many of the screws and bolts on this chair are special high-strength fasteners and may
have special coatings.
• Many nuts are of the Nylock type. They have a plastic insert to help prevent loosening.
WARNING
1. Use of improper fasteners may cause the chair to fail.
2. Over- or under-tightened fasteners may fail or cause damage to chair parts.
3. If bolts or screws become loose, tighten them as soon as you can. Loose bolts
or screws can cause damage to other chair parts causing them to fail.
3. Washers & Spacers:
• Note the position of washers and spacers before disassembly.
• To avoid damage to the frame, replace all washers and spacers when you reassemble
parts.
4. Torque Settings:
•A torque setting is the optimal tightening for a particular fastener. Use a torque wrench
that measures 120 inch-pounds to secure screws, nuts and bolts on this chair.
NOTE– Unless otherwise noted, use a torque setting of 120 inch-pounds for all fasteners.
TOOLS YOU WILL NEED
1. Basic Tool Kit:
To set-up, adjust and maintain your chair you will need the following tools:
2. Torque Wrench:
If you plan to adjust and maintain this chair yourself, Sunrise recommends that you use a
torque wrench.
NOTE– The wrench must measure inch-pounds. You can buy a torque wrench and proper sockets from a
hardware store.
CHECK-OUT
Be sure this chair performs to your chosen operational settings. If it does not, turn the chair
off immediately and have your supplier reprogram your wheelchair as needed.
NOTE– Repeat this procedure until the chair performs to your specifications.
WARNING
When properly set up, this chair will operate smoothly. Check to see that all
components work properly. If you detect a problem, be sure to correct it
before use.
• 5mm Allen Wrench
•8mm open-end wrench
• 3/8" combination wrench
•10mm combination wrench
•13mm combination wrench
• 18mm combination wrench
• 17mm deep socket wrench
• 5mm socket wrench
•19mm socket wrench
• Phillips screwdriver #2
•Flat-head screwdriver
•Wire cutters
• Needle nose pliers
101244 Rev. G
13
ENGLISH

101244 Rev. G 14
ENGLISH VIII.
A. BATTERY REMOVAL (Figures 1, 2, 3)
T
o remove the batteries for transporting or servicing:
1. Remove Batteries
a. Disconnect the joystick power cable in the rear of the chair (Fig. 1).
b. Carefully remove seat (see Section K. Seat Removal).
c. Remove the shroud by first removing the four wing nuts then lifting up on the shroud.
(Fig. 2).
d. Unwrap the battery strap; unplug and remove batteries from the chair.
e. Lift batteries using battery handles (Fig. 3).
2. Battery Installation
See Section X. Batteries, D for installatio.
WARNING
Batteries may weigh up to 45 lbs. Care must be taken to avoid injury when lift-
ing up on battery straps.
B. FOOTPLATE ADJUSTMENT (CB & BB only)
The single footplate can be adjusted in three different ways: height, length, and angle.
1. Height Adjustment (Figure 4)
(4 possible adjustments):
a. Remove the two securing bolts (A).
b. Move footplate to desired height and slide it into slot.
c. Re-install bolts (A) through desired holes.
2. Length Adjustment (Figure 5)
(4 possible adjustments):
a. Remove pin (B).
b. Move footplate to desired length.
c. Re-install pin (B) through desired hole.
3. Angle Adjustment (Figure 6)
Adjust bolt (C) until desired angle is reached.
1
2
5
6
3
4
A
B
C

C. CENTER MOUNT HANGER ADJUSTMENT
(SB only)
1. Removal (Fig. 7)
a. Remove the seat pan by removing the four attachment bolts (A).
b. Remove the four bolts (B) and slide the footrest out.
2. Height Adjustment (Fig. 8)
a. Remove the six securing bolts (C).
b. Move footplate to desired height.
c. Re-install bolts (C) through desired holes.
3. Calf Pad Adjustment (Fig. 9)
a. Remove the two securing bolts (D).
b. Move calf pads to desired height.
c. Re-install bolts (D) through desired holes.
D. SWING-AWAY FOOTRESTS
1. Installation (Fig. 10)
a. Place swing-away pivot pin (E) into the locating hole (F) on top of the hanger mount
with the footrest facing outward from frame.
b. Rotate the footrest inward until latch plate locks (G) into place on locking bolt.
2. Removal (Fig. 11)
a. To remove footrest, press quick-release lever (H).
b. Rotate footrest outward and lift.
3. Height Adjustment (Fig. 11)
a. Remove both bolts (I) in the hanger frame tube.
b. Reposition footrest height.
c. Re-tighten all bolts (I).
E. ELEVATING LEGREST (Optional)
1. Installation
To install or remove Elevating Legrest (ELR) see instructions for Swing-away Footrest installa-
tion.
2. Adjustment (Fig. 12)
a. To raise legrest, lift to desired position. Legrest will automatically lock in place.
b. To lower legrest, while seated in chair, first lift slightly then press release lever ( J)
down and lower legrest to desired position.
101244 Rev. G
15
ENGLISH VIII.
7
A
B
8
C
9
D
I
E
F
G
H
J
10
11
12

101244 Rev. G 16
ENGLISH VIII.
F. JOYSTICK OR ENHANCED DISPLAY SWING-AWAY
RETRACTABLE MOUNT (Optional) (Fig. 13)
The joystick or Enhanced Display is mounted with a mechanism which allows the control to
be locked in a forward or retracted position using magnets.
Adjustment
a. To retract the joystick or Enhanced Display, push outward on the inside of joystick.
b. Push the joystick or Enhanced Display away from front of armrest until it locks into
retracted position.
c. To return to forward position, push the joystick or Enhanced Display forward until it
locks into place.
G. ASAP SEATING ADJUSTMENT (BB & SB only)
Please refer to the ASAP Seating Adjustment Guide for details on how to adjust the seat
depth, seat width, armrest height, and backrest angle.
H. FLIP-BACK ARMRESTS ADJUSTMENT (CB only)
1. Width Adjustment (Figure 14)
a. Insert armrest support inside of 1" square tube located on back of the seat.
b. Repeat for other side of seat.
c. Position armrest at appropriate width.
d. Tighten knob screws (A) on square tube.
2. Angle Adjustment (Figure 15)
a. Flip back armrest.
b. Adjust the angle of the armrest by turning the bolt (B) clockwise to reduce the angle
and counter clockwise to increase the angle.
c. Fully tighten the jam nut.
3. Height Adjustment (Figure 16)
a. Remove the knob screw (C).
b. Select the desired armrest height.
c. Reinsert the knob screw and tighten.
WARNING
Avoid pinching fingers in the flip-back armrest.
I. BACKREST
Adjustment for the High Back Contour Seat (CB only)
(Figure 17)
a. Pull lever (D) upwards.
b. Lean back to desired position.
c. Release lever (D).
CAUTION– Backrest latches must be locked into place before operating wheelchair.
J. SEAT HEIGHT ADJUSTMENT
(Figure 18)
1. Remove seat (See Section K. Seat Removal).
2. Remove pins from all four seat mount posts.
3. Select the desired seat height (rear seat mount should never be more than
one position lower than the front).
4. Reinsert the pins.
WARNING
Ensure both front seat posts are positioned to the same height. Rear seat posts
should also be set to the same height.
14
15
16
17
18
A
B
C
D
13

101244 Rev. G
17
ENGLISH VIII.
K. SEAT REMOVAL
1. Remove Seat - CB
a. Disconnect the joystick power cable in the rear of the chair. (Fig. 19)
b. To remove the seat: release the safety lock-out pin, pull out on both release
mechanisms, and tilt the seat forward. (Fig. 20)
c. Loosen the screws on each side of the front seat mount.
d. Slide the seat backwards and lift off.
2. Remove Seat - BB & SB
a. Disconnect the joystick power cable in the rear of the chair. (Fig. 19)
b. Remove the two bolts that attach the seat to the front seat posts. (Fig. 21)
c. Release the safety locking pin on the rear of the seat post. Pull on both release mecha-
nisms, and lift off the seat. (Fig. 20)
WARNING
When replacing the seat into the mounts, ensure you do not pinch your fingers.
WARNING
Always replace the safety lock-out pin to prevent inadvertent release of the seat.
L. SHROUD REMOVAL (Figure 22 & 23)
The plastic protective shroud can be removed for adjustment or servicing.
1. Remove Shroud
a. Remove the seat (see Section K. Seat Removal).
b. Remove the four fasteners.
c. Remove shroud by lifting up.
2. Replace Shroud
Replace shroud by reversing above instructions.
M. CHECK-OUT
Once the wheelchair is assembled and adjusted, it should roll smoothly and easily. All acces-
sories should also perform smoothly.
After the wheelchair has been set up be sure the chair performs to your specified operational
settings (see Operating Guide). If the chair does not perform to specifications, turn the
wheelchair OFF immediately and contact your authorized supplier to reprogram operational
specifications using the QTRONIX Programming Pad (see section B of Operating Guide).
Repeat this procedure until the wheelchair performs to specifications before
attempting active use of the wheelchair.
If you have any problems, follow these procedures:
1. Review the Set-up, Adjustment & Use section and Operating Guide to make sure chair
was properly prepared.
2. If your problem persists, contact your authorized supplier. If you still have a problem
after contacting your authorized supplier, contact Sunrise customer service. See the
introduction page for details on how to contact your authorized supplier or Sunrise
customer service.
20
21
22
23
19

101244 Rev. G 18
ENGLISH
IX. OPERATING GUIDE
IX. OPERATING GUIDE
A. PERFORMANCE CONTROL SETTINGS
1. It is vital to match control settings to your level of function and ability.
2. Consult your health care professional and your supplier to select the best control set-
tings for you.
3. Check and adjust the settings every six to twelve months (or more often, if needed).
4. Adjust the control settings immediately if you notice any change in your ability to:
• Control the joystick.
• Hold your torso erect.
•Avoid running into objects.
5. Control Settings are adjusted by authorized Sunrise suppliers through the use of the
Quickie QTRONIX Programming Pad.
B. THERMAL ROLL-BACK
Your chair has a thermal roll back circuit. This protects the controller from damage due to
overheating. In extreme conditions (such as repetitive hill climbing) the circuit will decrease the
power to your motors. This allows the chair to operate at a reduced speed. When the con-
troller cools, the chair will return to normal speed.
C. CIRCUIT BREAKERS
1. Notes:
Your Quickie Rhapsody has a circuit breaker at the rear of the chair.
• In the unlikely event of a short circuit or heavy overload, all power to your chair will be
shut off.
• To reset your chair, depress the circuit breaker button located at the rear corner of the
chair. A few minutes wait is required before the circuit breaker will reset.
2. Repeated Shutdown:
If the chair continues to shut down after resetting, have it serviced by a supplier.
D. JOYSTICK ASSEMBLY
The standard VR2 joystick controls the chair’s performance. It consists of the following parts:
1. Speed Control or Drive Mode Selection Buttons
(A and B)
To decrease the speed level depress button A. Or, when 1- 5 Drive modes are programmed,
depress button A to activate lower drive mode(s).
To increase speed level, depress button B. Or, when 1- 5 Drive modes are programmed,
depress button B to activate higher drive mode(s).
Speed level active, or Drive Mode selected, is indicated on display (C) by a series of five
lights. One light indicates slowest level/mode currently active, while five lights indicates high-
est level/mode currently active.
2. Battery Charge Indicator (D)
• Green lights indicate that batteries are fully charged.
• Yellow lights indicate that batteries need recharging.
• When the lights stay in the red band, the batteries must be recharged.
3. On/Off Button (E)
Turning the chair on or off is accomplished by depressing button E.
4. Horn (F)
5. Joystick (G)
The joystick controls the direction and speed of your chair. Turn the chair on and move the
joystick in the direction you want to go.
•Moving the joystick from the neutral (center) position disengages the motor locks,
Circuit
Breaker
AD
F
G
H
BE
C
VR2 Joystick

101244 Rev. G
19
ENGLISH IX.
allowing the chair to move.
• The chair will move faster the more you move the joystick away from neutral.
NOTE– If your speed becomes hard to manage, release the Joystick and the chair will come to a complete
stop.
• When you release the joystick it will return to neutral; the chair will slow to a stop and
the motor locks will reengage.
• We recommend that you switch the chair off if you stop for any length of time. This
will conserve battery power.
NOTE– Once the chair stops, switching the chair off will not affect the motor locks.
6. Joystick Boot (H)
Make sure the boot is not torn or cracked (this could allow debris, water or moisture to
enter). If the boot is torn or cracked, replace it as soon as you can.
7. Tilt Control (SB only) (I)
This button once depressed allows you to control the up and down movement of the tilt. Press
button “I”. Then pull the joystick back to tilt the seat upward or push the joystick forward to
tilt the seat downward. Pressing button “I” again will allow drive operations to resume.
E. MOTOR LOCKS
Disconnect the motor locks when you need to manually push the chair.
(For example, in an emergency, or if batteries fail).
WARNING
1. Do not disengage motor locks unless power to the chair is off.
2. With either one or both brakes released, the chair will not operate and the
battery charge indicator will flash 9 bars rapidly (if power to the chair is on.)
3. Be aware that the chair will not have brakes in the free-wheel position.
4. Make sure that the person pushing the chair has full control when motor locks
are disengaged.
1. Release Motor Locks
a. The motor release levers (A) are attached to the upper rear section of the motors
located towards the back of the chair.
b. Pull the release levers rearward toward the rear of the chair.
2. Engage Motor Locks
a. The motor release levers (A) are attached to the upper rear section of the motors
located at the back of the chair.
b. Push the motor release levers inward, toward the front of the chair.
A
I
VR2 Joystick with Actuator
Control

101244 Rev. G 20
ENGLISH
X. BATTERIES
•Never charge a frozen battery. A fully charged battery will
rarely freeze, but the fluid in a discharged battery can freeze
at 16 degrees Fahrenheit (minus 9 degrees Centigrade). If
you suspect a battery is frozen, thaw it before charging.
WARNING
Lead acid batteries generate explosive gas while charg-
ing. Completely read and follow all warnings about the
batteries in this user instruction manual and any labels
applied to the product. Failure to do so could result in
fire, explosion, injury and/or death.
C. ACID BURNS (UNSEALED WET CELL
BATTERIES)
Acid in batteries is corrosive. If you choose to use wet cell batteries,
they can cause serious burns to the eyes and skin and can damage
floors, furniture, clothing and your wheelchair.
WARNING
1. Use extreme care not to spill acid when you handle
wet cell batteries. Keep batteries upright.
2. Avoid contact of acid with bare skin or clothing.
3. Always wear rubber gloves and safety glasses when you
handle batteries.
4. If acid contacts your skin or clothing, wash immediate-
ly with soap and water.
5. If acid contacts your eyes, immediately flood eyes with
cold running water for at least 15 minutes. Seek med-
ical attention immediately.
Sunrise Medical does not recommend the use of wet
cell batteries on this chair.
D. CONNECTING BATTERIES IN
BATTERY WELL
WARNING
1. Each battery weighs
up to 45 lbs. Take
care to avoid injury
when lifting.
2. Keep batteries
upright. T
ake care
not to spill acid
(wet cell batteries).
3. Always wear rubber
gloves and safety
glasses when
you handle batter-
ies.
4. Before working around batteries, remove all metal
personal effects, such as necklaces, rings, watches,
pins, and other metal jewelry that might contact bat-
tery terminal and cause a short.
1. Attach battery harness to battery post. Connect red to posi-
tive terminal and black to negative terminal.
2. Tighten all terminal fasteners using two wrenches.
3. Cover battery posts with insulating caps on harness.
4. Lift batteries into battery well.
X. BATTERIES
A. INTRODUCTION
1. Notes:
• Batteries supply the power for your chair. They contain a
finite amount of energy and have limits on how long they can
store and supply energy.
•You can charge batteries only a certain number of times
before they will fail and no longer hold a charge.
• For answers to questions about batteries, consult your
supplier.
2. Use Proper Batteries:
Your chair operates on two 12 volt batteries.
• They should be U1, 40 Ahr or 50 Ahr batteries.
• When you buy a replacement, insist on a deep cycle sealed
case. Do not use a car starter battery.
3. Breaking In:
• A battery requires “breaking-in” for the first 6 to 12 charges.
It will not accept a full charge for this period.
•It is best to limit the length of your trips until you break the
batteries in and you know the range of your chair.
4. Discharged Batteries:
•Never allow a battery to completely discharge. If you oper-
ate your wheelchair until it has almost stopped, you will
greatly reduce the life of your batteries.
•Never let a battery sit in a discharged condition. Give
unused or stored batteries a full charge once per month.
•Always fully charge the batteries. Avoid “topping off” with
frequent charges.
WARNING
Never connect a life support or auxiliary device to a
wheelchair battery. The electrical system may fail and
result in severe injury to or death of rider.
B. BATTERY CHARGER
A battery charger produces a direct current (DC). When applied to
a discharged battery, this reverses the chemical reaction that led to
its discharge.
1. Charge Rate. How fast a battery will charge depends on:
• Its electrical capacity, state of charge, electrolyte temperature,
and internal condition.
• The DC output of the charger. (The charge rate will vary if
the alternating current (AC) supply is higher or lower than
110 volts).
2. CAUTION– To Avoid Damage to the Charger
•Never expose charger to rain or snow.
•Never unplug charger by pulling on the electrical cord. This
will damage the cord.
•Never open a charger or attempt to repair it yourself.
Return charger to Sunrise or have repairs made only by a
qualified person.
• Keep cord out of the way, where it will not be stepped on,
tripped over, or damaged.
3. CAUTION– To Avoid Damage to the Battery
•Make sure you use the correct setting for sealed (gel) batter-
ies (located on off-board chargers).
Refer to wiring diagram for
battery connections
