SVAT CLEARVU11 User manual

INSTRUCTION MANUAL
Model #:
CLEARVU11
www.svat.com
SVAT ELECTRONICS
now you can see
Version 1.0
COMPLETE SYSTEM
4CH 15" LCD-DVR All-In-One System
H.264 DVR with 4 Indoor/Outdoor Hi-Res Night Vision Security Cameras
www.svat.com

CLEARVU11 2
NEED
HELP?
DO NOT RETURN THIS
PRODUCT TO THE STORE
Please contact a SVAT customer support representative rst regarding any additional information on
product features, specications or assistance with set-up.
Please contact us via one of the methods below:
Toll free telephone:
1.866.946.7828
For more product information visit www.svat.com
Email:
[e-mail]
Online live web chat:
Visit www.svat.com
Toll free fax:
1.888.771.1701
Note: This is manual version 1.1 for this product, you may nd updated versions by visiting our website.
IMPORTANT! PLEASE READ!

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER (BACK).
NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK, DO NOT OPEN MONITOR
CLEARVU11 www.svat.com
PRODUCT WARRANTY INFORMATION
Please visit our website at www.svat.com
for information about your product’s warranty.
We take quality very seriously. This is why all of our products come with a one year warranty from the original purchase date
against defects in workmanship and materials. If you have warranty or support issues please contact us using any of the following
methods:
Phone: [phone] SVAT USA SVAT CANADA
Fax: [phone] Industrial Parkway #Z64 4080 Montrose Road
Email: [email protected] Cheektowaga, NY Niagara Falls, ON
Website: www.svat.com USA 14227 Canada L2H 1J9
Warranty Terms
1. SVAT products are guaranteed for a period of one year from the date of purchase against defects in workmanship
and materials. This warranty is limited to the repair, replacement or refund of the purchase price at SVAT’s option.
2. This warranty becomes void if the product shows evidence of having been misused, mishandled or tampered with contrary
to the applicable instruction manual.
3. Routine cleaning, normal cosmetic and mechanical wear and tear are not covered under the terms of this warranty.
4. The warranty expressly provided for herein is the sole warranty provided in connection with the product itself and no other
warranty, expressed or implied is provided. SVAT assumes no responsibilities for any other claims not specically
mentioned in this warranty.
5. This warranty does not cover shipping costs, insurance, or any other incidental charges.
6. You MUST call SVAT before sending any product back for repair. You will be sent a Return Authorization form with return
instructions. When returning the product for warranty service, please pack it carefully in the original box with all supplied
accessories, and enclose your original receipt or copy, and a brief explanation of the problem (include RA #).
7. This warranty is valid only in Canada and the continental U.S.
8. This warranty cannot be re-issued.
IMPORTANT! PLEASE READ!

SVAT ELECTRONICS
now you can see
CLEARVU11 1
INTRODUCTION ...............................................................................................................................................................3
WHAT IS INCLUDED .........................................................................................................................................................3
BUTTON FUNCTIONS AND CONNECTIONS ........................................................................................................................4
15” LCD/DVR ............................................................................................................................................ 5
REMOTE CONTROL ...................................................................................................................................6
BASIC SETUP ...............................................................................................................................................................6
TIPS BEFORE ASSEMBLING.......................................................................................................................6
MOUNTING THE CAMERA .........................................................................................................................7
WIRING THE CAMERAS ............................................................................................................................ 7
POWERING THE SYSTEM ..........................................................................................................................8
GENERAL INFORMATION ................................................................................................................................................. 9
MAIN SCREEN .......................................................................................................................................... 9
TEXT INPUT ........................................................................................................................................... 10
USING THE MOUSE .................................................................................................................................11
MOTION DETECTION SETUP USING THE MOUSE ......................................................12
PTZ SETUP USING THE MOUSE ...............................................................................12
VIDEO ADJUSTMENT ICONS ...................................................................................12
COMMON ICONS .................................................................................................... 12
ALPHA-NUMERIC KEY............................................................................................13
MAIN MENU .................................................................................................................................................................13
LOGIN/LOGOUT ...................................................................................................................................... 13
STATUS DISPLAY .................................................................................................................................... 14
VIDEO ADJUSTMENT .............................................................................................................................. 15
BACKUP DEVICE .....................................................................................................................................15
SETUP ................................................................................................................................................... 16
PRE-CAMERA SET UP ............................................................................................ 17
CAMERA SETUP .....................................................................................................18
TITLE.........................................................................................18
VIDEO LOSS SETTINGS ...............................................................18
MOTION DETECTION ..................................................................20
MOTION SETTINGS .................................................................... 20
MOTION SETUP ..................................20
COVERT .....................................................................................22
CALL BY EVENT ......................................................................... 22
DWELL TIME ............................................................................. 23
AUDIO .......................................................................................23
RECORD QUALITY AND RECORD IPS ...........................................23
EVENT RECORD IPS ....................................................................23
PRE-RECORD IPS .......................................................................23
NORMAL RECORD IPS ................................................................23
ALARM SETUP .......................................................................................................24
SEQ DISPLAY SETUP ............................................................................................... 25
SCHEDULED RECORD SETUP ...................................................... 27
HDD SETUP ............................................................................. 28
Table of Contents
TABLE OF CONTENTS

SVAT ELECTRONICS
now you can see
CLEARVU11 2
TABLE OF CONTENTS
HDD FORMAT/CLEAR ....................................................................30
PASSWORD ..............................................................................................................31
SYSTEM SETUP .........................................................................................................32
RS-232/422/485 SETUP ...........................................................................................33
NETWORK SETUP .....................................................................................................34
EMAIL SETUP ...............................................................................35
ADVANCED NETWORK SETUP .......................................................36
FACTORY DEFAULTS ..................................................................................................37
SOFTWARE UPGRADE ............................................................................................................................37
SYSTEM SHUTDOWN .............................................................................................................................37
NETWORKING GUIDE .......................................................................................................................................................38
CONNECTING YOUR DVR TO THE ROUTER................................................................................................38
FINDING THE DVR’S IP ADDRESS .............................................................................................................39
PREPARING YOUR COMPUTER FOR VIEWING THE DVR .............................................................................40
VIEWING YOUR DVR ON YOUR COMPUTER ..............................................................................................41
INSTALL THE ACTIVEX CONTROLS .............................................................................42
CONFIGURING YOUR ROUTER (PORT FORWARDING) ..................................................43
FINDING YOUR DEFAULT GATEWAY ............................................................................43
CONNECTING THE DVR USING A ROUTER ...................................................................44
FINDING YOUR IP ADDRESS.......................................................................................45
DYNAMIC DNS ..............................................................................46
IF YOU CANNOT CONNECT .............................................................48
VIEWING YOUR DVR OUSTIDE YOUR NETWORK .......................................................................................49
REMOTE VIEWING .......................................................................49
SEARCH MENU .................................................................................................................................................................52
SEARCH BY TIME ....................................................................................................................................52
PLAYBACK/ARCHIVE FOR SERACH BY TIME ...............................................................53
SERACH BY EVENT ..................................................................................................................................55
PLAYBACK/ARCHIVE FOR SEARCH BY EVENT .............................................................56
SEARCH BY ARCHIVED FILES ...................................................................................................................56
PLAYBACK FOR ARCHIVED FILES ...............................................................................57
PDA/MOBILE PHONE REMOTE ACCESS ..............................................................................................................................57
CD SOFTWARE AND ARCHIEVED VIEWING .......................................................................................................................57
KEYBOARD CONTROL SIMULATOR...........................................................................................................58
TROUBLE SHOOTING .. .....................................................................................................................................................59
SPECIFICATIONS .............................................................................................................................................................66
CAMERA SPECIFICATIONS ......................................................................................................................68
NOTES AREA ...................................................................................................................................................................70

SVAT ELECTRONICS
now you can see
CLEARVU11 3
INTRODUCTION
WHAT IS INCLUDED
• Mounting Hardware
• Quick Start Guide
• Instruction Manual
• 1 Year Warranty
• 24/7 Online/ Toll Free Support
15" LCD DVR with 320GB Hard
Drive
4 Outdoor Night Vision
Cameras
4 Window Warning Stickers 8.5 ft. DC12V Power Adapter
for DVR
4 x 60ft. 4 PIN DIN to RCA (male)
Power Cables
10ft RJ-45 Cable Software CD 1 - 4 port power supply for
Cameras
5 RCA to BNC Connectors PS-2 Mouse
You have just purchased a state of the art, ultra sleek, all-in-one LCD/DVR. This digital video system is especially
designed for DIY surveillance. Your new system contains a H.264 compression system, which means that you will get
more high quality video in less storage space. H.264 compression is a revolutionary way to store data and is highly
compatible with surveillance applications. This LCD/DVR system also features six-fold operation without sacricing the
functionality, performance and reliability of the recording.
Your new Clearvu11 is designed to be easy to setup and easy to congure to all your surveillance needs. If at any
time you have questions, we are always here to help. Call our 24/7 live customer support line to get intelligent and
understandable answers to any questions you may have about your new product.

SVAT ELECTRONICS
now you can see
CLEARVU11 4
BUTTON FUNCTIONS AND CONNECTIONS
23
45
13
14
15
1
67 8
9
10 11
12
16
17181920
24
23
22
21
29
28
27
26
25
30
15" LCD/DVR

SVAT ELECTRONICS
now you can see
CLEARVU11 5
1. Monitor Speaker
2. MENU/ESC – Displays the main menus & returns you to the previous set of menus
3. Camera Selection Buttons (Ch1-Ch4) – Switches from full screen for selected camera
4. MODE/*/MARK – Toggles between live mode and playback mode
5. Quad View Mode (+/-) – Cycle between quad and single mode viewing or to change contents
6. CALL/BACKUP button – Copies playback images to USB storage device
7. Play/Pause (►/ ) – Plays recorded images, or pauses playback
8. Stop/PTZ button (■/PTZ) – Stops playback, or enters/exits PTZ control
9. LEDs –Indicators for POWER, & HDD access
10. Remote Control Infrared (IR) Sensor
11. Down/Delete button (►/DEL) – Moves curser vertically, controls PTZ cameras, works as “del” key
12. Right button (►►) – Fast forward, pans camera in PTZ controls
13. Enter ( ) – Conrms selection in navigating onscreen menus for DVR
14. Up/Backspace button (▲/BS) – Move vertically between camera views, works as “Backspace” key
15. Left button – Moves cursor horizontally, rewinds, pans camera in PTZ controls
16. Hard Drive Cover
17. Power Switch (POWER) – Turns the DVR o and on
18. Power Cord Inlet (POWER IN) – For DC-IN
19. Mouse plug port (PS/2) – For PS/2 mouse connection
20. LAN (Ethernet) – Connects DVR to the internet
21. Video Input Connectors – Connects cameras with BNC connectors (Ch1-Ch4)
22. Video Output Connectors – Connects additional TV monitors
23. Audio Input/Output Connectors –For connecting audio supported accessories
24. RS-485 Connector/Alarm Output Connectors/Alarm Input Connectors
25. Power – Turns the LCD monitor o/on
26. MENU/ENTER –Conrms selection in navigating monitor options
27. LEFT/- - Move left through monitor options
28. RIGHT/+ - Move right through monitor options
29. AUTO/ESC – Exits the monitor display options
30. USB Port – Connects ash drive for backup
BUTTON FUNCTIONS AND CONNECTIONS

SVAT ELECTRONICS
now you can see
CLEARVU11 6
TIPS BEFORE ASSEMBLING
BASIC SETUP
• The camera should be installed between 8 and 13ft above the area to be monitored.
• Ensure there are no obstructions in the camera’s view, to maximize viewing area.
• Ensure that the sunshade is positioned to avoid glare and position camera away from direct sunlight.
• Decide whether the camera will be wall-mounted or sit on a desk/table top. If wall mounting, use the
mounting hardware in the package. We recommend that the mounting bracket is secured using the included
screws for all installations.
• This camera comes with 60ft of video/power wire. Please make sure that you mount the cameras no more
than 60ft from the TV/monitor/VCR/DVR.
• We recommend using a surge protected power bar to protect the cameras internal circuitry.
REMOTE CONTROL
1. Alarm Reset – Cancels alarm activation/silences buzzer
2. REC – Force manual recording
3. Rewind (◄◄ ) – Rewinds in playback mode
4. Fast Forward (►►) – Fast forwards in playback mode
5. Step Forward - (► )- Moves playback ahead one frame
6. ( ) Back-up– Creates a backup
7. Play/Pause (►/ ) – Plays or pauses recorded images
8. Stop (■ ) – Stops playback
9. MENU – Calls up menu options
10. ESC/PTZ – Exits screen, or calls up PTZ options
11. ENTER - Conrms selection in navigating onscreen menus for DVR
12. Directional Buttons – Toggles the curser around the screen.
13. x2/GOTO – Enters digital zoom.
14. MUTE/NEXT – Toggles muting on or o
15. Volume Control - Only works with audio supported cameras
(not included)
16. Quad View Mode (+/-) – Cycle between quad and single mode viewing
or to change highlighted values
17. MODE - Cycles between Quad and Single mode viewing
18. SEQ - Sequences through camera views
19. CALL - Copies playback images onto USB Storage Device
20. Search - Calls up search menu
21. Alpa/Numeric keys
22. */mark - Toggles between live mode and playback mode.
23. #/code - Used in text input to call up dierent languages
2
3
45
13
14
15
1
6
78
910
11 12
16
17
18
19
20
2322
21
BUTTON FUNCTIONS AND CONNECTIONS

SVAT ELECTRONICS
now you can see
CLEARVU11 7
BASIC SETUP
MOUNTING THE CAMERA
1. Screw the mounting bracket into the camera’s mounting hole,
turning it clockwise.
2. Mount the camera in the desired location no more than 60 feet from
the DVR unless you have purchased additional wiring. You may wall
mount or desk mount these cameras.
3. Adjust cameras to the desired viewing angles.
1. Plug the 4PIN DIN female connection
on the camera into the 4PIN DIN male
connection on the 60ft video/power wire.
2. Plug the camera’s power supply into one of
the 4 ports of the power supply.
3. Plug the four port power supply into the
12 V adapter.
4. Plug the power supply into the 12 V
adapter.
5. Attach all of the BNC to RCA adapters
to the camera inputs and the monitor
outputs on the back of the LCD/DVR.
6. Connect the male RCA plug from the 60
ft power wire to the BNC connectors on
the channel inputs (1-4) on the back of
the DVR.
7. Plug the other end into the female end
of the 3.5 mm wire from the camera.
Follow these instructions for the installation of each camera. The 60ft video/power wire has two connections: one for
video out, and one for power.
WIRING THE CAMERAS
1 2
67
34

SVAT ELECTRONICS
now you can see
CLEARVU11 8
POWERING THE SYSTEM
1. Insert the power supply wire
into the rear DC 12V Port on the
LCD/DVR.
2. Plug the mouse into the PS2
port at the back of the LCD/DVR
(recommended).
3. Insert the power cord into the
power supply.
4. Plug the power cord into a
power outlet.
5. Turn on the master switch on
the back right of the system.
6. Press POWER on the top panel
of the system if it doesn’t start
after turning on the master
switch.
NOTE: We recommend using a surge protected power bar and/or
Uninterrupted Power Supply (UPS) backup to prevent damage
to your DVR system.
BASIC SETUP

SVAT ELECTRONICS
now you can see
CLEARVU11 9
GENERAL INFORMATION
MAIN SCREEEN
NOTE: The following
instructions are
described for use with
the remote control.
Front panel buttons
may not match with the
following directions. It
is recommended that
you use the included
mouse or remote for full
function.
You must be logged in to access all the DVR menus. Please refer to page 13 for login instructions.
The split-window screen, as shown above, is the main screen after system start-up. There are two types of on
screen viewing modes, 1-Window and 4-Window. The system will remember the last viewing mode before normal
shutdown.
In addition to the split windows, the system time is displayed on the lower-left corner, the hard drive information on
the lower-right corner, and the scrolling event messages (if shown while certain events occur), across the bottom.
The system information, from left to right at the bottom of the screen, is described as the following:
(1) SEQ display ON/OFF or playback state – SEQ icon shown for SEQ display ON, other icons for dierent playback states.
(2) Backup state – Backup icon shown for backup.
(3) Manual record ON/OFF – REC icon shown for ON.
(4) Current Zoom – x1, x2, or x4.
(5) Mute state –Speaker icon shown for not mute, not shown for mute.
(6) Alarm recording percentage.
(7) Normal recording percentage.

SVAT ELECTRONICS
now you can see
CLEARVU11 10
TEXT INPUT (To be used with remote control)
There are certain circumstances where the system requires the user to enter text, such as system login, camera title
setup, and so on. Below are the instructions on how to enter text using the remote control:
1. Press ENTER to edit the highlighted option. The ashing cursor will be shown to indicate the editing point.
To aid in nding which key represents which letter, a keypad legend will be shown as below.
2. Press ◄► to move the cursor to the left/right.
3. Press #/code in text editing mode to change text case. (If you are in the number only mode, pressing #/
code will have no eects.) Indicators on the screen show the current setting:
123 = Number only
abc = No capital letters
ABC = All capital letters
CODE = Internal code for the selected language, such as Chinese, Japanese, etc.
4. Press 2 for “2”, “a/A”, “b/B”, “c/C”. 5 for “j/J”, “k/K”, “l/L”. MUTE for “6”, “m/M”, “n/N”, “o/O”. Please refer to the
Keyboard legend for any other alpha-numeric entries.
5. Press */mark to bring up a list of punctuation marks and special characters. The highlighted character in
the list shows the selected one. Press ▲▼◄► to change the selection.
6. If you make a mistake, press BS (▲) to remove the character to the left of the cursor, or press DEL (▼) to
delete the character at the current cursor position.
7. In text editing mode, internal code box, and mark list, press ENTER to exit and save changes, press ESC/
PTZ to exit without making changes.
GENERAL INFORMATION

SVAT ELECTRONICS
now you can see
CLEARVU11 11
GENERAL INFORMATION
USING THE MOUSE
To make use of the mouse when operating the DVR please move the cursor to the bottom of the screen. You will see
the icons of the mouse functions displayed. When you move the cursor over the icons, you will see the name of that
icon. Below is a list of the icons and what their use is. Using the mouse is the simplest way of operating the DVR.
1. Menu – Used to call up the full menu
2. Search – Used to call up the search options
3. ESC – Used to escape out of some menu options
4. Backwards – Used to play the recorded footage in reverse. Can toggle between fast or
slow reverse play
5. Forwards – Used to control the playback speed. It can be set for fast forward or slow forward
6. Single Step – Will pause the playback. If paused and this button is pressed it will
advance the playback slightly each time it is pressed.
7. Play/Pause – Alternates between playback and pausing the playback.
8. Stop - Stops using playback mode
9. Copy –Pulls up the backup menu. A backup device must be connected. (See backup for
more details)
10. Sequence – Used to cycle live viewing mode between single camera, quad screen and sequence
11. & Used to hide/reveal the viewing modes (removes icons adjacent to these)
12. Camera selections – choose between cameras 1,2,3,and 4.
13. PTZ – Activates PTZ controls (see PTZ)
14. Mode – Cycles between live viewing and playback on the selected camera
15. Alarm Reset – Used to reset the buzzer and the alarm relay output
16. Record – Manually start recording as per “Normal Record IPS” settings
17. x 2 Activates zoom mode - After pressing this button, a yellow box will appear. Move
the yellow box by clicking the outside of it in the direction you want it to move. Clicking
thw yellow box with zoom in 2x on what was selected by the yellow box. This can be
done up to 4x digital zoom
18. Volume – Turns muting on or o

SVAT ELECTRONICS
now you can see
CLEARVU11 12
GENERAL INFORMATION
MOTION DETECTION SETUP USING THE MOUSE
PTZ SETUP USING THE MOUSE
The PTZ camera functions and their corresponding icons are shown below.
VIDEO ADJUSTMENT ICONS USING THE MOUSE
COMMON ICONS
Move the cursor to Menu -›Setup -› Camera -› Motion setting -› Detection setting
Move the cursor to the bottom of the screen, the icons of motion detection will be displayed.

SVAT ELECTRONICS
now you can see
CLEARVU11 13
MAIN MENU
While in the split-window display, press MENU (MENU/ESC) to call up Menu display as shown. We recommend using
the mouse. With the mouse the menu is found by dragging the cursor to the bottom of the screen. If you are using the
remote, simply press the menu button.
There are a variety of displays under the Menu display. In Menu display and all the subsequent displays, the items
enabled are shown in black-colored text, and those disabled in white-colored text. You will need to login before being
able to access all functions of the DVR. Once logged in, the text will be black.
The user’s operations are described as the followings:
• (▲▲ )Press these buttons to change the
highlighted item.
• ENTER
Press this button to enter the detailed display
of the highlighted option. For the details of
each option, please refer to the corresponding
sections.
• ESC (MENU/ESC) Press this button to escape
from Menu display, and return to split-
window display.
LOGIN AND LOGOUT
There are three password levels in the system, including Administrator (Admin) (highest), Supervisor, and
Operator (lowest). If the user does not login to the system, he/she will be treated as “Guest” and can only view live
video display.
The system allows up to 18 user accounts. The administrator can set up the login name and password for each user.
The Administrator can operate every aspect of the DVR while the Supervisor can only operate live video display, image
playback and the archive. The Operator can only operate live video display.
To login/logout of the system, press MENU when in the split-window display to call up the Menu display, and then
press ENTER when the Login/Logout option is highlighted to enter the Login/Logout display as shown.
ALPHA-NUMERIC KEYBOARD
GENERAL INFORMATION

SVAT ELECTRONICS
now you can see
CLEARVU11 14
In Login/Logout menu, follow the Text Input method to enter the Login name and Password
• Press ▲▼ to highlight login name, Use the text input method to enter the login name. Press Enter
• Press ▲▼ to highlight password name, Use the text input method to enter the login name. Press Enter.
• Press ENTER to login the system.
• To logout of the system, just press ▲▼ to highlight and select the Logout option, and then press
ENTER.
• Press ESC (MENU/ESC) to exit without making changes.
The preset administrator login name is “aa” and the password if “11”. The use can user this username to login to the
system for the rst time.
STATUS DISPLAY
In Menu display, press ▲▼ to
change the highlighted option to
Status, and then press ENTER to
call up Status display as shown.
The Status display is read only.
The status display includes:
• Alarm Recording Hard Drive Status
• Normal Recording Hard Drive Status
• Camera Event Status
• Alarm Input Status
• Product Serial Number
• Product Version Number
Press ESC (MENU/ESC) to exit from the Status display, and return to Menu display.
MAIN MENU

SVAT ELECTRONICS
now you can see
CLEARVU11 15
VIDEO ADJUSTMENT
In Menu display, press ▲▲ to
change the highlighted option to
Video Adjustment, and then
press ENTER to call up Video
Adjustment display as shown.
There are 4 items which can be adjusted, including Brightness, Contrast, Hue, and Saturation. The operations are as below:
• ▲▲ - Press these buttons to select the items.
• Numeric (CH1 – CH4) - Press these buttons to select the camera you wish to adjust .
• (+/-) Press these buttons to adjust the selected item.
• SEQ - Press this button to reset the settings for this camera to factory default values.
• CALL - Press this button to reset the settings for all cameras to factory default values.
• MODE - Press this button to restore the values to original setting.
• ESC (MENU/ESC) - Press this button to escape from this screen, and return to Menu display. The settings
will be saved for future reference.
BACKUP DEVICE
In Menu display, press ▲▲ to
change the highlighted option to
Backup Device, and then press
ENTER to call up Backup Device
display as shown below.
The system supports a variety of USB 2.0 storage devices. (It will also support USB 1.0)
The operations are as below:
• ▲▲▲▲Press these buttons to select the items.
• ESC (MENU/ESC) -Press this button to escape from this screen, and return to previous display.
• Connect/Disconnect – If the backup device is disconnected (as shown in Current Status), please plug
the device in one of the backup ports (USB) and/or insert a DVD for DVD device, and then press ENTER
to command the system to connect with it. If the device is already connected (E.g. R/W - Read/write, as
shown in Current Status), please press ENTER to command the system software to disconnect with the
device, and then unplug the device from the backup port.
MAIN MENU

SVAT ELECTRONICS
now you can see
CLEARVU11 16
NOTES:
1. DO NOT format the DVD disc for better performance and compatibility.
2. Before using USB pen drive, please format it to FAT32 le system by Windows XP or higher.
3. The backup device has to be connected by the system software before it can be used to read/write.
4. Some backup devices may have compatibility problems. Please contact Customer Support at 1-866-946-
7828 for any issues you may have.
5. Please DO NOT unplug the backup device when it’s connected, or the system may act abnormally or even
shut down. Always disconnect the device from the backup device menu before removing it.
• Backup - Press ENTER when this item is selected to backup the congurations of this unit to the
corresponding device. This will be used to restore your conguration settings at a later time.
• Restore - Press ENTER when this item is selected to restore the conguration settings from the corresponding
backup device to this DVR.
Tested USB 2.0 Drives (the DVR is not limited to only these devices)
• Macpower’s Alumni Prefect USB 2.0 - PF-U2MS
• Transcend’s JetFlash 150/V60 Series
• Apacer’s Handy Steno AH220
• Pretec’s i-Disk Wave 512M-Black
• Kingston’s DataTraveler USB Flash Drive
• SanDisk’s Cruzer micro USB Flash Drive
• Sony’s MICRO VAULT Classic Series
SETUP (Administrator mode only)
In Menu display, press ▲▼ to change the highlighted
option to Setup, and then press ENTER to call up Setup
Menu display as shown.
To enter the Setup Menu display of the system, you must be
logged in as an administrator.
MAIN MENU
NOTE: The DVR is not limited to only these backup devices. Other backup devices may work normally.

SVAT ELECTRONICS
now you can see
CLEARVU11 17
From the setup menu, you can access various aspects of the system, including camera setup, schedule setup, network
setup and password setup.
• ▲▼- Press these buttons to change the highlighted item.
• ENTER - Press this button to enter the setup of the highlighted option. For the details of each option, please
refer to the corresponding sections.
• ESC (MENU/ESC) -- Press this button to escape from Setup Menu display, and return to Menu display.
PRE-CAMERA SETUP
In Setup Menu display, press
▲▼ to change the highlighted
option to Pre-Camera, and then
press ENTER to call up the Pre-
Camera Setup display as shown.
Up to 4 cameras can be connected to the system. The Pre-Camera Setup allows the administrator to dene some
fundamental attributes for the installed cameras.
The general operations are as below:
• ▲▼◄► - Press these buttons to select the items.
• Numeric (CH1-CH4) - Press these buttons to select the camera.
• ESC (MENU/ESC) - Press this button to escape from this screen, and return to Setup Menu display. If the
contents have been modied, a Save dialog will be shown to ask the user to save the changes, press ENTER
to exit and save, ESC (MENU/ESC) to exit without saving.
Following is a brief description for each item and its specic operations:
• REC Resolution – the record resolution for all the cameras in the system. For NTSC, it can be 720x480,
720x240, or 360x240; for PAL, 720x576, 720x288, or 360x288. Press +/- buttons to select the resolution.
• Watermark - press ENTER buttons to change the value. The watermark will permanently record time and
date over the video clips. This is very important when logging video data, and using video as evidence.
• Installed – whether this camera is installed or not. Press ENTER or +/- to check/uncheck this item. The
default setting is “” - checked. When the camera is checked saying it is installed you can adjust the
settings of that camera in the Camera Settings menu. If it is not checked, no adjustments can be made.
• PTZ ID – the PTZ ID of this camera if it’s a PTZ camera. The PTZ ID has to be consistent with the setting of this
camera. Please refer to the manual of the camera for the ID settings. Press +/- buttons to change the value
(N/A or 0-255). The default setting is “N/A” – Not Available, which means that it’s not a PTZ camera.
MAIN MENU
