Sven MS-905 User manual

www.sven.fi
OPERATION
MANUAL
2.1 Multimedia Speaker System
MS-905

Congratulations on your purchase of the Sven speaker system!
COPYRIGHT
© 2014. SVEN PTE. LTD. Version 1.0 (V 1.0).
This Manual and information contained in it are copyrighted. All rights reserved.
TRADEMARKS
All trademarks are the property of their legal holders.
NOTICE OF RESPONSIBILITY RESTRICTION
Despite the exerted efforts to make this Manual more exact, some discrepancies may occur. The
information in this Manual is given on «as is» terms. The author and the publisher do not bear any
liability to a person or an organization for loss or damage which has arisen from the information
contained in this Manual.
CONTENTS
1. BUYER RECOMMENDATIONS ..................................................
.............
2. PACKAGE CONTENTS............................................................. ............
3. SAFETY PRECAUTIONS .................................................. ...................
4. TECHNICAL DESCRIPTION .................................................... ................
5. PREPARATION AND OPERATION ..........................................
......................
6. TROUBLESHOOTING.................................
...............................................
7. TECHNICAL SPECIFICATIONS .................................................... ...........
1
2
2
2
3
5
5
1. BUYER RECOMMENDATIONS
•Unpack the device carefully. Make sure there are no accessories left in the box. Check up the
device for damage; if the product was damaged during transportation, address the firm which
carried out the delivery; if the product functions incorrectly, address the dealer at once.
•Check up the package contents and availability of the warranty card. Make sure the warranty
card has a shop stamp, a legible signature or the seller’s stamp and purchase date, and the goods
number corresponds to that in the warranty card.
• Do not switch on the speaker system immediately after you bring it into a room from environment
with negative temperature! After unpacking, the speaker system should be kept in conditions of
room temperature for at least 4 hours.
•Before installing and using the speaker system, read this Manual carefully and keep it for future
reference.
Technical support is on www.sven.fi.
ENG
1
Operation Manual MS-905

ENG
2
2.1 Multimedia Speaker System
2. PACKAGE CONTENTS
•Subwoofer – 1 pc
•Satellites – 2 pcs
•Signal cable – 1 pc
•Operation manual – 1 pc
•Warranty card – 1 pc
3. SAFETY PRECAUTIONS
•To avoid electric shock, do not open the MSS and do not perform repairs by yourself. Service and
repairs should be performed only by qualified specialists in an authorized service center. The list of
authorized service centers is available on www.sven.fi
•Do not allow the circuit of wires (including the grounded ones) between the speakers, on the
power amplifier or the ground, for it causes damage to the power amplifier output stage.
•Do not touch the MSS power cord plug pins for 2 seconds after unplugging it from the mains.
•Do not put foreign objects inside the holes of the MSS.
•Protect the MSS from high humidity, water and dust.
•Protect the MSS from heating: do not place it closer than 1 m from a heat source. Do not expose
it to direct sunlight.
•Do not place any open flame sources on or close to MSS.
•Do not place the MSS in poorly ventilated areas. Leave an air gap of 10 cm or more. When
operating the MSS, do not put any devices on it, do not cover it with cloth or other objects pre-
venting it from cooling.
•Do not use any chemical agents for cleaning. Clean it with dry soft cloth only.
4. TECHNICAL DESCRIPTION
MS-905 Multimedia Speaker System 2.1 (MSS) is designed to play music and sound games,
movies etc. The MSS has a built-in amplifier, due to which it can be connected to virtually any audio
source (CD/DVD-player, TV, PC, etc.) without using an additional power amplifier.
Special features
•Built-in transformer power supply
•Separate master volume control and bass control knobs
•Speaker system is compatible with PCs, DVD/Media-players, mobile devices and other sound
sources
•Magnetic shielding
•MDF subwoofer cabinet
Caution! High voltage inside! To avoid the risk of electric
shock do not open or touch elements inside.

a
b
c
d
e
f
g
Subwoofer rear panel
aVOLUME: master volume control knob
bBASS: subwoofer volume control knob
cPOWER: power LED
dAUDIO OUTPUT L/R: audio satellite outputs
eAUDIO INPUT: audio input
fPOWER SOURCE ON/OFF: POWER switch
gPower cord
5. PREPARATION AND OPERATION
Speaker placement
•Place the speakers symmetrically to the listener at the
distance not less than one meter.
•The MSS has a phase inverter on the side panel,
therefore the MSS should be installed at the distance of
20-30 cm from a wall or other obstacle. The subwoofer emits
non-directional sound, therefore it can be located in any
place of the room, where it will sound to the best
advantage.
•Place MSS far away from monitors and TV sets, as insig-
nificant image distortion in these supersensitive devices is
possible
Installation and operation
MS-905 Multimedia Speaker System can be connected to
virtually any audio source (see connection diagram, Fig. 2).
•Before connecting make sure that the MSS is switched off. Connect the built-in audio cables to
the audio outputs on the rear panel of subwoofer AUDIO OUTPUT L/R d(see. Fig. 2).
Note that the red RCA-jack of the right speaker should be connected to the red terminal of
the subwoofer and the white RCA-jack of the left speaker – to the white terminal of the
subwoofer (AUDIO OUTPUT R/L). The correctness and reliability of the cable connections
directly affect the quality of sound.
•The mini-jack of the stereo signal cable should be inser- ted into AUDIO INPUT econnector of
the subwoofer, and the other mini-jack of the cable should be plugged into a Ø 3.5 mm LINE OUT
port of the computer sound card or audio output of a player, as shown in the diagram (see Fig. 2).
Note. To connect the MSS to a DVD/CD-player or a TV it is necessary to use a mini-jack to
2RCA stereo signal cable (not included) or a mini-jack to 2RCA adapter (not included).
•Plug the power cord gon the rear panel of the subwoofer into an outlet.
•Adjust volume level to minimum by turning VOLUME control knob acounterclockwise until it
stops.
•Switch on the device (f, position ON), power LED clights up.
• Turn on the audio source.
•Adjust Master volume level by turning VOLUME control knob a. By turning the knob clockwise,
volume level is increased, and by turning the knob counterclockwise, it is reduced.
Fig. 1. Subwoofer rear panel
ENG
3
Operation Manual MS-905

CD
DVD
Power
cord
Audio
cable Audio
cable
Mini-jack to mini-jack
Ø 3.5 mm signal cable
Mini-jack to 2RCA
signal cable
PC
PLAYER
Fig. 2. Connection diagram
Right
speaker
Left
speaker
•Adjust bass level by turning BASS control knob b. By turning the knob clockwise, bass level is
increased, and by turning the knob counterclockwise, it is reduced.
Notes:
• If the MSS has not been used for a long time, please mind to switch it off using power
switch (f, position OFF) on the subwoofer rear panel and unplug it g.
• To enhance sound quality, use Line-Out output of the sound card.
ENG
4
2.1 Multimedia Speaker System

Parameter, measurement unit
Output power (RMS), W
subwoofer
satellites
Frequency range, Hz
subwoofer
satellites
Speaker diameter, mm
subwoofer
satellites
Power supply, V / Hz
Dimensions (W × H × D), mm
subwoofer
satellites (one speaker)
Weight, kg
Value
22 (10 + 2 × 6)
10
2 × 6
50 – 140
140 – 20,000
Ø 137
Ø 63
~220/50
212 × 221 × 239
80 × 190 × 80
4.2
7. TECHNICAL SPECIFICATIONS
If none of the above methods can solve the problem, please seek professional advice at your
nearest service center. Never attempt to repair the product yourself.
6. TROUBLE SHOOTING
Notes:
• Technical specifications given in this table are supplemental information and cannot give
occasion to claims.
• Technical specifications and package contents are subject to change without notice due to
the improvement of SVEN production.
Problem
The MSS does not
turn on.
No sound or sound
of speakers is too
quiet.
Distortion of
sound.
Cause
The MSS is not connected to the mains
outlet.
Power switch is off.
Volume level is set at minimum value.
The audio source is improperly connected.
Large amplitude of the input signal.
Solution
Check the connection.
Turn on the switch.
Adjust the volume control knob.
Connect audio sources correctly.
Turn down the source volume
and MSS volume.
ENG
5
Operation Manual MS-905

Модель: MS-905
Импортер вРоссии: ООО «СКАНДИТРЕЛ», 111024,
РФ, г. Москва, ул. Авиамоторная, д. 65, стр. 1.
Уполномоченная организация вРоссии: ООО «РТ-Ф»,
105082, г. Москва, ул. Фридриха Энгельса, д. 75, стр. 5.
Условия гарантийного обслуживания смотрите
вгарантийном талоне или на сайте www.sven.fi.
Гарантийный срок: 12 мес. Срок службы: 5 лет.
Производитель: «СВЕН ПТЕ. Лимитед», 176
Джу Чиат Роуд, №02-02, Сингапур, 427447.
Произведено под контролем «Свен Скандинавия
Лимитед», 48310, Финляндия, Котка, Котолахдентие, 15.
Сделано вКитае.
Manufacturer: SVEN PTE. LTD., 176 Joo Chiat Road,
№02-02, Singapore, 427447. Produced under the
control of Oy Sven Scandinavia Ltd. 15, Kotolahdentie,
Kotka, Finland, 48310. Made in China.
® Registered Trademark of Oy SVEN
Scandinavia Ltd. Finland.
