Sven PS-100BL User manual

www.sven.fi
OPERATION
MANUAL
Portable Speaker System
with Bluetooth
PS-100BL

ENG
1
Operation Manual
Technical support is on www.sven.fi.
Congratulations on your purchase of the Sven speaker system!
COPYRIGHT
© 2014.SVEN PTE. LTD. Version 1.0 (V 1.0).
This Manual and information contained in it are copyrighted. All rights reserved.
TRADEMARKS
All trademarks are the property of their legal holders.
NOTICE OF RESPONSIBILITY RESTRICTION
Despite the exerted efforts to make this Manual more exact, some discrepancies may occur. The
information in this Manual is given on «as is» terms. The author and the publisher do not bear any
liability to a person or an organization for loss or damage which has arisen from the information
contained in this Manual.
CONTENTS
1. BUYER RECOMMENDATIONS ..................................................
..............
2. PACKAGE CONTENTS............................................................. .............
3. SAFETY PRECAUTIONS .................................................. ......................
4. TECHNICAL DESCRIPTION .................................................... .................
5. PREPARATION AND OPERATION .......................................... .......................
6. TROUBLESHOOTING.................................. ...............................................
7. TECHNICAL SPECIFICATIONS ..................................................... ...........
1
2
2
2
3
5
6
1. BUYER RECOMMENDATIONS
•Unpack the device carefully. Make sure there are no accessories left in the box. Check up the
device for damage; if the product was damaged during transportation, address the firm which
carried out the delivery; if the product functions incorrectly, address the dealer at once.
•Check up the package contents and availability of the warranty card. Make sure the warranty card
has a shop stamp, a legible signature or the seller’s stamp and purchase date, and the goods
number corresponds to that in the warranty card. Remember: in case of warranty card loss or
discrepancy of numbers you forfeit the right for warranty repairs.
• Do not switch on the speaker system immediately after you bring it into a room from environment
with negative temperature! After unpacking, the speaker system should be kept in conditions of
room temperature for at least 4 hours.
•Before installing and using the speaker system, read this Manual carefully and keep it for future
reference.
PS-100BL

de
ba
fg hijkl
c
2. PACKAGE CONTENTS
•Speaker system – 1 pc
•Mini-jack to mini-jack signal cable – 1 pc
•USB to micro USB power cable – 1 pc
•Operation Manual – 1 pc
•Warranty card – 1 pc
3. SAFETY PRECAUTIONS
•Do not open the multimedia speaker system (MSS) and do not perform repairs by yourself. Service
and repairs should be performed only by qualified specialists in an authorized service center. The
list of authorized service centers is available on www.sven.fi.
•Do not put foreign objects inside the holes of the MSS.
•Protect the MSS from high humidity, ingress of splashes and drops of water as well as dust on the
device; do not place any vessels with liquids on it.
•Protect the MSS from heating: do not place it closer than 1 m from a heat source. Do not expose
it to direct sunlight.
•Do not place open flame sources closely to MSS.
•Do not use any chemical agents for cleaning. Clean it with dry soft cloth only.
4. TECHNICAL DESCRIPTION
PS-100BL Multimedia Speaker System (MSS) is designed to play music and sound games, movies,
etc. MSS can be connected to the audio source via a signal cable (included). Also the MSS has the
built-in V2.1 Bluetooth module, thanks to which it can be connected to audio sources without using
the cable, if they have built-in Bluetooth module.
Special features
•The MSS is compatible with PC, Media/МР3 players, mobile devices
•Built-in V2.1 + EDR Bluetooth module
•Ability to control the tracks (in Bluetooth mode)
•Headset mode
•AUX stereo input
•Passive emitters
•Built-in lithium battery with capacity 1150 mA•h
•Support for iPod
MSS design
aOperation mode indicator
bMIC: microphone
cSupport for iPod
dBattery charging mode indicator
eDC 5V: micro USB port to connect
the device to a charger or USB port
of a notebook/PC
fAUX IN: jack to connect an external
sound source Fig. 1. MSS design
ENG
2
Portable Speaker System
with Bluetooth

gON/OFF: MSS power switch
h+: volume level up button
i–: volume level down button
j: previous track switch button (short pressing)
k: Play/Pause (pressed short in Bluetooth mode);
when there is a call answer/rejection (in Bluetooth mode);
entry into search Bluetooth mode (long pressing, more than 2 sec)
l: next track switch button (short pressing)
5. PREPARATION AND OPERATION
Speaker placement
• Place the device in an easy-to-use place for a user.
• Place the MSS far away from monitors and TV sets, as insignificant image distortion in these
supersensitive devices is possible.
MSS connecting
PS-100BL speaker system can be connected to virtually any audio source: PC, notebook, МР3/МР4
players, mobile devices etc. (see connection diagram in Fig. 2 and 3)
• Before use, the built-in battery in the speaker system must be charged. Connect DC 5V jack e
with USB port of a computer or 5V DC power unit using USB cable (included). During connection to
an external power source, the charging mode indicator dwill light red. Upon the battery charging
completion the indicator dwill change the light color to green.
• To connect the MSS to PC, МР3/CD players via AUX IN jack fuse the mini-jack to mini-jack
signal cable (included). For this purpose insert mini jack of the signal cable into the jack f, then
the second mini jack into the sound card linear output of a PC or MP3/CD player (see Fig. 2).
• Put the switch gon the MSS side panel in ON position to switch on the MSS.
• When connecting to a sound source via Bluetooth, it is necessary to fulfill the intercommunication
procedure with an audio signal source (see Fig. 3).
• Select the desired volume level with buttons hand ion the side panel.
• After the MSS use, switch offthe power supply with the switch gon the side panel.
Bluetooth mode
This mode is active in the absence of connected jack in AUX IN jack f.
• For the signal transmission in this mode it is necessary first to interconnect the MSS with a signal
source long pressing, more than 2 sec the button k. The MSS will go to the search mode, the
indicator awill start blinking blue color frequently (2-4 Hz) (Bluetooth searching) and the MSS will
beep the confirmation signal. Then on the signal source (telephone, smartphone, etc.) choose the
search mode of devices with Bluetooth. The name of the MSS “SVEN PS-100BL” will be displayed
on the signal source screen, with which you need to intercommunicate*. Select this device and the
“connect” command.
• When the connection is successful, the MSS will beep the confirmation signal and the indicator a
on the front panel will reduce the blinking frequency (~1 Hz).
• To switch the MSS to the search mode you can also press long the button k(or to switch offthe
MSS and then to switch on it once again).
* If the MSS has been already listed in the device list of the signal source, then the second activation of the
search mode is not required. Select only this device and the “connect” command.
ENG
3
Operation Manual PS-100BL

• After interconnection with the signal source you can control the player of the signal source using
buttons j, kand l.
• You can receive/finish incoming calls (after their receipt) with the button k.
Fig. 3. Audio sources connection diagram via Bluetooth module
Phone
PC
Fig. 2. Audio signal source connection diagram
USB port
Socket
Mini-jack to mini-jack
signal cable
CD player
iPhone
iPod
MP4 player MP3 player
USB to micro USB
power cable
PC
3
ENG
4
Portable Speaker System
with Bluetooth

ENG
5
Operation Manual
AUX Mode
• The MSS enters into AUX mode automatically after the plug insertion into AUX IN jack fon the
side panel.
• At the instant of connection, the MSS will beep the confirmation signal and the indicator aon the
front panel will change its light to green.
6. TROUBLESHOOTING
Problem
The MSS does not
turn on.
No sound or there is
too quiet sound of
speakers.
Distortion of sound.
Cause
Built-in battery is discharged.
The volume level is set at minimum
value.
No connection via Bluetooth / wrong
connection or selection of an audio
signal source.
High amplitude of the input signal.
Solution
Connect the MSS to a charger,
USB port of a notebook or PC to
charge the battery.
Press the button “vol+” on the
front panel.
Fulfill the interconnection
procedure via Bluetooth /
connect or select an audio signal
source correctly.
Turn down the source volume
and the MSS volume.
If none of the above methods can solve the problem, please seek professional advice at your
nearest service center. Never attempt to repair the product yourself.
PS-100BL

ENG
6
Parameter, measurement unit
Output power (RMS), W
Frequency range, Hz
Speaker diameter, mm
Power supply:
lithium-ion accumulator, mA · h
USB, V
Bluetooth version
Bluetooth operating range, m
Dimensions (W × H × D), mm
Weight, kg
Value
6 (2 × 3)
80 – 20,000
2 × Ø 40
1150
DC 5
2.1 + EDR
8
195 × 115 × 35
0.437
7. TECHNICAL SPECIFICATIONS
Notes:
• Technical specifications given in this table are supplemental information and cannot give
occasion to claims.
• Technical specifications are subject to change without notice due to the improvement of
SVEN production.
Portable Speaker System
with Bluetooth

Модель: PS-100BL
Импортер вРоссии: ООО «СКАНДИТРЕЛ», 111024,
РФ, г. Москва, ул. Авиамоторная, д. 65, стр. 1.
Уполномоченная организациявРоссии: ООО «РТ-Ф»,
105082, г. Москва, ул. ФридрихаЭнгельса, д. 75, стр. 5.
Условия гарантийного обслуживания смотрите
вгарантийном талоне или на сайте www.sven.fi
Гарантийный срок: 12 мес. Срок службы: 5 лет.
Производитель: «СВЕН ПТЕ. Лимитед», 176
Джу Чиат Роуд, №02-02, Сингапур, 427447.
Произведено под контролем «Свен Скандинавия
Лимитед», 48310, Финляндия, Котка, Котолахдентие, 15.
Сделано вКитае.
Manufacturer: SVEN PTE. LTD., 176 Joo Chiat Road,
№02-02, Singapore, 427447. Produced under the
control of Oy Sven Scandinavia Ltd. 15, Kotolahdentie,
Kotka, Finland, 48310. Made in China.
® Registered Trademark of Oy SVEN
Scandinavia Ltd. Finland.
