USER MANUAL
2.1 Multimedia
Speaker System
PS-720
PS-750

ENG
2
2.1 Multimedia
Speaker System
Congratulations on your purchase of the SVEN speaker system!
COPYRIGHT
© SVEN PTE. LTD. Version 2.0 (17.09.2021).
This Manual and information contained in it are copyrighted. All rights reserved.
BUYER RECOMMENDATIONS
• Unpack the device carefully. Make sure there are no accessories left in the box. Check up thede-
vice for damage; if the product was damaged during transportation, address the rm which
carried out the delivery; if the product functions incorrectly, address the dealer at once.
• Shipping and transportation equipment is permitted only in the original container.
• Does not require special conditions for realization.
• Dispose of in accordance with regulations for the disposal of household and computer equipment.
• The date of manufacture of the product is indicated on the box.
APPLICATION
SVEN PS-720/PS-750 party speaker system with Bluetooth and FM-radio is designed for operation
with PC, notebooks and other mobile devices by means of data transfer via Bluetooth protocol.
Itcan be also used in internet telephony, during video conferences, in multimedia applications,
ininteractive games, for speech recognition and foreign language teaching. Microphone input
withecho function, FM-tuner and the player with USB-ash and micro SD-cards are included.
PACKAGE CONTENTS
• Speaker system — 1 pc
• Antenna/3.5 mm mini-jack to 3.5 mm mini-jack signal cable — 1 pc
• USB to USB type-C power cable — 1 pc
• Remote control (RC) — 1 pc
• RC batteries (ААА type) — 2 pcs
• Microphone holder — 2 pcs
• User Manual — 1 pc
• Warranty card — 1 pc
SPECIAL FEATURES
• Bluetooth wireless signal transmission.
• Eective multi-colored lighting.
• Wireless connection of two speakers to one source*.
• Wired/wireless audio signal transmission.
• Built-in player for audio les from USB-ash and micro SD card.
• Built-in equalizer.
• Two microphone inputs with echo function.
• Built-in FM tuner.
• LED display.
* Only for models with production date from 04.2021.
Technical support is on www.sven..

ENG
3
PS-720
PS-750
User Manual
Speaker system description
aMIC1: 6.3 mm jack microphone jack.
bMIC2: 6.3 mm jack microphone jack.
cAUX: 3.5 mm mini-jack for audio signal connecting (phone, MP3 player, etc.).
dTF CARD: micro SD card slot.
e USB: USB-ash card slot.
fON/OFF: power button.
gIndicator.
hDC 5V: USB type-C jack for charger connecting, the USB port of laptop/PC.
iMIC VOL +/-: microphone volume control knob.
jVOLUME +/-: volume control knob.
kMODE: switching modes button: Bluetooth/Radio/Player/LINE IN (short pressing); ON/OFF
the service signals (long pressing).
lAUTO SCAN/ : Play/Pause button (in Player and Bluetooth mode); Start/Stop auto scan (long
pressing in Radio mode); Mute (short pressing in Radio and LINE IN mode).
mCH/ : button for switching between stations or frequency (in Radio mode); Repeat mode
selection button (in the Player mode): ONE — repeats the current track; RAND — play tracks
inthe random order; ALL — plays all tracks in the sequential order; Disconnect from device
(long pressing in Bluetooth mode); Save the selected frequency of the radio station in memory
(long pressing in Radio mode).
Fig.1.

ENG
4
2.1 Multimedia
Speaker System
n LIGHT: switching backlight modes (short pressing); Turning on/o the backlight (long pressing).
oDisplay.
pMIC PRI: mute with a connected microphone.
qEQ: EQ mode switch button (short pressing); Return to default settings (long pressing).
rFM-/ : previous track (short pressing in Player and Bluetooth mode); Navigation onthetrack
(long pressing in Player mode); Previous track/station (in Radio mode); Search forastation
withalower frequency (in Radio mode).
sIR receiver.
tFM+/ : next track (short pressing in Player and Bluetooth mode); Navigation on thetrack
(long pressing in Player mode); Next track/station (in Radio mode); Search for a station withahigh-
er frequency (in Radio mode).
uDEL(TWS): FM station deletion (long pressing in Radio mode); Connecting an additional
speaker (long pressing in Bluetooth mode).
vECHO +/-: microphone echo adjustment knob.
Remote control
aMODE: switching modes button: Bluetooth/Radio/Player/
LINE IN (short pressing); ON/OFF the service signals (long press-
ing).
bLIGHT (MUTE): switching backlight modes (short pressing);
Mute (long pressing).
cREP: disconnect from the device (long pressing Bluetooth
mode); Repeat mode selection button (in Player mode).
dEQ: EQ mode switch button.
eVOL-/+: volume up/down.
f, CH-: previous track (in Player and Bluetooth mode);Previ-
ous station (in Radio mode).
g, CH+: next track (in Player and Bluetooth mode);Next sta-
tion (in Radio mode).
h, AUTO SCAN: Play/Pause button (in Player and Bluetooth
mode); Start/Stop auto scan (long pressing in Radio mode); Mute
(short pressing in Radio and LINE IN mode).
iFM-/+: frequency changeа (in Radio mode).
j0-9: numeric pad for entering track number (in Player mode)
or number track/station (in Radio mode).
CONNECTION AND OPERATION
Attention! The built-in battery must be charged completely prior to the application.
Speaker system battery charging
• Connect speaker system to a USB port of PC or USB charger using type-C to USB cable (included).
During battery charging the indicator gis red. Indicator g goes out when the battery ischarged.
• The battery is used in the speaker system as an integral part of the device, therefore do nottry
toextract or replace it, because this can result in the warranty cancellation or the device damage.
OPERATION MODES
Bluetooth mode
• Wireless data transfer via the Bluetooth protocol enables to connect speaker system to com-
patible devises. Maximum radius of action of data transfer is 10 m. Such obstacles as walls
orother electronic devices can interfere with the signal transfer.
Fig. 2.

ENG
5
PS-720
PS-750
User Manual
• Turn on the speaker system Bluetooth mode — press button МODE kseveral times until
display shows «bt» inscription.
• It is necessary to select the search mode of devices with Bluetooth on a signal source (tele-
phone, notebook, smartphone, etc.). «SVEN PS-720/750», massage will be displayed onthescreen
whichis to be connected to*.
• When connection is successful, there will be a short beep and the indication of the search
mode on speaker system is over**.
* You might have to enter «0000» code to connect some models of devices via Bluetooth.
** If the item has been already registered in the device list of a source, then the second search
mode activation is not obligatory. Choose the item name «SVEN PS-720/750» and the “connect”
command on the source.
Radio mode
Attention! To improve the reception quality of the radio signal, connect the 3.5 mm mini-jack
cable (included) to the AUX input c.
• Turn on the speaker system — press button МODE kseveral times until the display shows
the station frequency. Long-term pressing button lactivates auto search mode. After scan-
ning completion, the rst scanned radio station will start to operate automatically. With buttons
rand tselect a desired radio station.
Player mode
Attention! The le system of a micro SD carrier is FAT32. Maximum volume is 32 GB. Itisnotrec-
ommended to use the micro SD Ultra Speed.
• The system will enter the Player mode automatically when a carrier (USB ash or SD card)
isconnected to corresponding ports. Use button l to switch between Play/Pause modes. Youcan
control tracks by using buttons r(previous track) and t(next track).

ENG
6
2.1 Multimedia
Speaker System
THE USE IN THE WIRED MODE (LINE IN)
• Speaker system can be used as an external device for amplifying any audio source
witha3.5mm output mini-jack. Connect a cable mini USB, plug 3.5 mini-jack to the audio input
AUX c. Turn the speakers to the LINE IN mode — press the MODE button kseveral times until
«LINE» appears on the display.
Connecting an additional speaker (only for models with production date from 04.2021)
For models PS-720/PS-750 you can connect an additional speaker (Bluetooth mode only):
• Turn both speakers into Bluetooth mode.
• Connect the signal source to one of the speakers via Bluetooth (the second column should be
insearch mode).
• On another speaker press and hold button DEL(TWS) u.
• If two speakers are successfully connected between themselves, the inscription TWS will glow
constantly.
Reset
To reset the settings, long press the EQ button until «RES»appears. Then press button h
onthe RC or button lon the front panel. Settings will reset.
TECHNICAL SPECIFICATIONS
Parameter, measurement unit Value
Frequency response, Hz 45–22 000
Output power (RMS), W 80 (2 × 40)
Speaker diameter, mm Ø 32 + Ø 145
Battery capacity, mA*h 4 400 (2 pcs)
Power supply, V USB ⎓5
Weight, g 5 200
Dimensions, mm 230 × 640 × 260
Notes. Technical specications given in this table are supplemental information andcan-
not give occasion to claims. Technical specications and package contents aresubject
to change without notice due to the improvement of SVEN production.

ENG
7
PS-720
PS-750
User Manual

2.1 Multimedia
Speaker System
PS-720
PS-750
Model: PS-720, PS-750
Importer: Tiralana OY, Office 102, Kotolahden-
tie 15, 48310 Kotka, Finland.
Manufacturer: SVEN PTE. LTD, 176 Joo Chiat
Road, № 02-02, Singapore, 427447.
Produced under the control of Oy Sven Scan-
dinavia Ltd. 15, Kotolahdentie, Kotka, Finland,
48310. Made in China.
® Registered Trademark
of Oy SVEN
Scandinavia Ltd. Finland.
1В0917
