Sylvac S Mike EVO User manual

1
E
F
D
Digital Micrometer
Micromètre Digital
Digital Mikrometer
Instructions - Mode d’emploi - Bedienungsanleitung

2
Installing and replacing the battery /Mise en place et remplacement de la batterie /
Einbau und Austausch von Batterie
The display of the symbol «B» indicates the end of the battery life. However some working hours will remain. /
L’affichage du symbole «B» indique la fin de vie de la batterie. Cependant il reste des heures de travail disponibles. /
Die Anzeige des Buchstabens «B» zeigt das Ende der Batteriebetriebsdauer an. Es verbleiben einige Arbeitsstunden.
Battery / batterie / Batterie: Lithium 3V, type CR2032
1. Open the battery cover / Dévisser le bouchon de pile / Batterie deckel mittels
2. Change the Battery (Lithium CR2032 type) / Changer la pile
(Pile lithium type CR2032) / Batterie wechseln. (Lithium Batterie,
Typ CR2032).
3. Check the rubber protection position / Contrôler la mise en place du joint
/ Dichtungslagerung kontrollieren.
4. Close the battery cover / Revisser le bouchon / Deckel wieder einschrauben.

E
F
D
Reference setting / Prise de référence / Referenzpunkt setzen
33
--SEt--
mm
When used for the first time, after a battery change or a complete switch OFF, it is necessary to set the reference
(--sEt--). Close the micrometer completely by rotating the friction thimble. (see chap. 5).
Lors de la première utilisation, après un remplacement de batterie, ou après une extinction complète (OFF),
l’instrument demande une nouvelle prise de référence (--sEt--). Fermez complètement le micromètre en tournant
le tambour. (voir chap. 5).
Beim Erstgebrauch, nach einem Batteriewechsel oder nach einem kompletten Ausschalten (OFF) verlangt
das Instrument einen neuen Referenzpunkt (--sEt--). Schließen Sie die Messschraube vollständig, indem Sie die
Trommel drehen. (sehe Kap. 5).

4
Unlocking the spindle / Déblocage du tambour / Entriegeln der Spindel
If you fully retracted the spindle,the controller will not move it forward, it will be locked.
Si vous avez complètement rétracté la broche, le tambour ne la fera pas avancer, elle sera verrouillée.
Wenn Sie die Spindel ganz eingefahren haben, bewegt der Trommel sie nicht vorwärts, sie ist gesperrt.

E
F
D
5
To unlock the spindle, rotate the speeder to disengage the lock, then keep rotating the controller to move the
spindle forward.
Pour déverrouiller la broche, tournez la manette rapide pour débloquer le verrou, puis continuez à tourner l’avance
rapide pour faire avancer la broche.
Um die Spindel zu entriegeln, drehen Sie den Speeder, um die Verriegelung zu lösen, und drehen Sie dann den
Trommel weiter, um die Spindel vorwärts zu bewegen.

6
12
7
3 4
5
9
6
10
12
11
13 14 15 16 17
18
19
20
8

E
7
Description
1. Measuring spindle
2. Anvil
3. Thermal isolation
4. Mode button
5. Set button
6. Favourite button
7. Rotating thimble
8. Speeder
9. Battery cover
10. mm/inch
11.+/- indicator
12. Low battery
13. Preset mode
14. Active reference
15. Keypad lock
16. Multiplication factor
17. Hold measured value
18. Send data
19. Bluetooth®active
20. 7-digit display

8
1. General description
The external micrometer is equipped with a Bluetooth®connection and the SIS. (Smart Inductive Sensor)
with the reference position being maintained, even when the instrument is in standby mode.
It includes the following functional features:
•Input of Preset values.
•Selection of the measuring unit (mm / INCH).
•Transfer of measurement value (Bluetooth®connection).
•Protection against penetration of dust and liquids (oil, water), protection degree IP67
according to (IEC 60529 standard).
The micrometer is extremely easy to operate thanks to its menu selection system.

E
9
2. First level functions
Fav
rESEt
mm
MAC
mm
off
mm
Set Set Set
1.922
mm
1.922
mm H
25.00
mm
25.000
mm PRESET
26.000
mm PRESET
PrE
25.000
mm
mm
SEt
mm
On
mm
bt
mm
rEF2
mm
rEF1
mm
rEF
mm
Mode
Mode
Mode
Mode Set
Set
Mode
Set
Set
Mode
Set
Mode
Fav
Fav
Fav Fav Fav
0.000
mm
Fav
After the last digit
Après le dernier digit
Nach der letzen Steile
Zero setting can be activated by master
La mise à zéro peut être activée via le master
Der Null-Einstellung kann über den Master aktiviert werden
* Hold function can be activated by master
* La fonction Hold peut être activée par le master
* Haltefunktion kann vom Master aktiviert werden
*
Fav
Fav
1)

10
Without push (after 5s) : Return to measuring mode
(15s for preset input)
1)Instrument with Bluetooth®
3. Second level functions
2)The sign + indicates the currently active profile.
1)
Set
Set
MM
mm
Inch
INCH
Unit
Off
mm
On
mm
Loc
0.001
mm
0.01
mm
mm
mm
rEs
mm
Mode
Set
Set
Mode
SetMode Set
Auto
mm
MAn
mm
OFF
mm
SetMode Set
Mode
Set
SIMPLE
mm
PAIr
mm
bt. CFG
mm
Mode Set
HId
mm
Set
+
Fav Fav
Fav Fav
Fav Fav
Fav Fav
Fav Fav
Fav
2)
Depends on model

E
11
4. Maintenance
Store the micrometer in a dry environment when not in use for long periods of time to avoid corrosion of the
metallic parts.
Do not close the measuring spindle with the anvil when not in use. Keep a distance of 1-2 mm.
Do not use aggressive products (alcohol, trichloroethylene or others) to clean the plastic parts. Do not store the
micrometer in areas which are exposed to sun, heat or humidity.
Important : clean and dry the spindle and metallic parts regularly, and protect the spindle with light oil to
guarantee a perfect mechanical functioning and to avoid corrosion.
5. Switching ON, initialisation
After pressing any button, the instrument displays «--SET--» for the initialisation of the reference point.
Bring the measuring spindle on to the anvil (0-25mm) or on to the corresponding setting Gauge block for
larger ranges. Then press [SET]. The instrument is now ready (Check the Preset Value).

12
6. Standby
The Reduced Consumption Mode works without the loss the reference position. The standby mode is ac-
tivated automatically after 10 minutes of no use. It can also be activated by pressing the [SET] key until
extinction of display.
The instrument awakes automatically when movement is detected on the thimble, by pressure on a button,
or when requesting Data.
7. Full Switch OFF
In order to fully switch off the instrument (minimum power consumption), press the [SET] button until the
message «OFF» appears. In this state no data is maintained and therefore the Reference position is lost. The
--SET-- message will be displayed again during the next use (see “Switching ON”).

E
13
8. Description of the menu system
The [MODE] key enables the selection of the different menus (each key stroke activates the following
menu). The [FAV] key enables the activation of a function assigned to the corresponding selected menu.
To avoid a wrong action, each menu is active only for 5s. After 5s, the instrument automatically switches
back to «Measuring Mode» as long as no action has been performed to the [MODE], [SET] or [FAV] key.
9. Preset mode
Preset makes it possible to introduce an alternative reference value different from zero.
Repeatedly press the [MODE] button until menu «PRE» appears. Then press the [FAV] button to activate
the function Introduction of Preset. The display shows 00.000 or the last stored value of Preset. The first
digit blinks.
Each push of the [SET] button modifies the value of the blinking digit (±, 0..9).

14
Each push on the [FAV] button moves the cursor to the right. A short press on the [MODE] button validates
the Preset value and leaves the Preset menu. The instrument automatically returns to «Measuring Mode»
when there are no further actions from the buttons [MODE] or [SET] or [FAV] for a period of 15s.
A push of 2s on the [SET] button assigns the Preset-value (or zero) to the current position of the measuring
spindle.
10. Reset, recall of the preset
11. Changing unit (mm/inch)
Press [MODE] button until the display enters Advanced Menus, then the [FAV] button to change the unit
«MM» or «INCH».

E
15
12. Locking of the instrument
Press [MODE] until the display enters advanced menus, then repeatedly press [MODE] until the display
shows «LOC».
When the instrument is locked, only the function of [Fav] button is active (default: Data sending). Pressure
of 5s on a button, unlocks the instrument.
13. Bluetooth®Function (depends on model)
The connection procedure has been designed to be simple and is signalled by the following three states:
1° Symbol off Disconnected Mode
2° Symbol blinking Advertising Mode
3° Symbol on Connected Mode

16
The following options can be selected to control the Bluetooth® module.
On Enable Bluetooth® module (start advertising mode).
OFF Disable Bluetooth® module (terminate active connection).
rESEt Clear pairing information.
MAC Display the MAC (Media Access Control) address.
Three Bluetooth®profiles are available.
SIMPLE Profile without pairing (default).
PAIr Paired and secured profile.
HId Virtual keyboard mode (compatible with recent equipement without driver installation).
Note:
- Bluetooth®pairing information is cleared when the profile is changed.

E
17
13.1. Connection :
1° Activate Bluetooth®compatible software and hardware (Master : PC, Display Unit).
2° Start the instrument. By default the Bluetooth®module is active and the instrument is available for connection
(Advertising Mode).
3° If no connnection is established during the advertisement period reactivate the Bluetooth®module using
the bt /On menu.
4° Instrument is ready to communicate (connected mode.)
13.2. Only with Paired Profile :
Pairing with master is automatically done at first connection.
To connect the instrument to a new master (new pairing), pairing information on the instrument must be cleared
using the bt/ rESEt menu.

18
13.3. Bluetooth® Specifications
Frequency Band 2.4GHz (2.402 - 2.480GHz)
Modulation GFSK (Gaussian Frequency Shift Keying)
Max Output Power Class 3: 1mW (0dBm)
Range Open space: up to 15m
Industrial environment: 1-5m
Battery life
Continuous : up to 2 months - Always connected with 4 values /sec.
Saver : up to 5 months - The instrument sends value only when the position has changed.
Blind/Push : up to 7 months - Value is sent from the instrument (button) or requested from
the computer.

E
19
14. Favourite keys
The [FAV] key gives direct access to a predefined function, and can be configured according to the needs of the
user. In order to assign a function to the [FAV] key, give a prolonged press on the Favourite key, and then select the
required function :
Validation of selection: By a prolonged press on [FAV] Key or a short press on [SET]or [MODE].
Note :
- A function can also be assigned via RS232 using the command <FCT + Function No.> (FCT 0..9 A..F)
example : Toggle unit = <FCT6>, reference change = <FCT3>.
0 dAtA
1 HoLd
2 SEt
3 rEF
4 PrE
5 bt
6 Unit
7 rES
Data Transmission (default)
Hold Display
Zero Reset
REF 1 - REF 2
Recall Preset
Bluetooth®ON-OFF
mm - INCH
0.01 0.001 / 0.001 0.0001
(depends on model)
8 no.F No function

20
The other commands are shown in the following table:
? Sends the displayed value
AOFF 0 / AOFF 1 / AOFF? Deactivates/activates/status the automatic switch-off
BAT? Sends the status of the battery (BAT1=ok or BAT0=low)
ID ? Sends the instrument identification (SY306)
IN Activates the Inch unit
KEY 0 / KEY 1 / KEY? Locks/unlocks/status of keyboard (except data output)
ECO 1 / ECO 0 / ECO? Activate/deactivate/status of Bluetooth®economic mode
LCAL? Sends the date of the last calibration (DD.MM.YYYY)
LCAL DD.MM.[YY]YY Sets the date of the last calibration
MM Activates the millimeter unit
NCAL? Sends the date of the next calibration (DD.MM.YYYY)
15. Remote commands
The data request is done by the sending of the character ASCII <?>, followed by <CR> (carriage return). The instru-
ment also answers in the same way during the detection of an impulse pedals/automaton.
