Sylvac UL 4 User manual

1
E
INSTRUCTIONS
MODE D’EMPLOI
BEDIENUNGSANLEITUNG
MANUALE D’USO
MODO DE EMPLEO
E
F
D
UL 4
Ultra-light caliper
Pied à coulisse ultra-léger
Extra-leichter Messschieber
Calibro a corsoio ultraleggero
Calibre ultraligero
I
S

2
Installing and replacing the battery
Mise en place et remplacement de la
batterie
Einbau und Austausch von Batterie
Installazione e sostituzione della batteria
Colocación y sustitución de la batería
No. 1
Battery / batterie / batterie / batteria / bateria: lithium 3V, type CR2477 or CR2032 (with adaptater)
CR2477
CR2032
Option to use a CR2032 battery with the adapter accommodated at the end of the main beam.
Possibilité d’utiliser une pile CR2032 avec l’adaptateur logé à l’extrémité de la perche.
Batterie CR2032 mit Adapter am Stangenende verwendbar.
Possibilità di utilizzare una pila CR2032 con l’adattatore alloggiato all’estremità dell’asta
Posibilidad de utilizar una batería CR2032 con el adaptador alojado en el extremo de la columna.
+
No. 7
or / ou / oder / o / o

3
E
Outline dimension drawing
Schéma d’encombrement
Masszeichnung
Disegno quotato
Planos dimensionales
202
103
10
38
8
30
262
124
8x30 h6
90 133 47.6
64.5
60
747 7 47
7
23.5 23.5
25
2x Ø4 F8 1x M4 1x M4 2x Ø4 F8
202
103
10
38
8
30
262
124
8x30 h6
90 133 47.6
64.5
60
747 7 47
7
23.5 23.5
25
2x Ø4 F8 1x M4 1x M4 2x Ø4 F8

4
MINMAX
PRESET
TOL INPUT
2
x
1
IN
mm
H
B
B
1. Left measurement jaw
2. Right measurement jaw
3. Measurement button
4. Left moving cursor locking lever
5. Right cursor clamp knob
6. Internal measurement plunger clamp knob
7. Pressure cursor
8. Pressure cursor locking lever
9. Pressure indicator
10. SET button
11. Favourites button
12. Mode button
13. Battery cover
14. Display
15. Internal interchangeables measurement plungers
16. Main beam
17. Proximity cable housing
16
15
17
4 14 5 10 8 7
13 12 11 9
2
15
1
6
3
Pressure indicator
Middle position
Measuring position
(external measurement)
Measuring position
(internal measurement)

5
E
MAX
PRE PUT
TOL
H
mm
IN
MIN
SET IN
1. Measurement unit (mm/INCH)
2. + / - indicator
3. Low battery
4. Active tolerance mode
5. Button locking
6. Preset mode
7. Multiplication factor
8. 6-digit display
9. Freeze measurement value
10. Bluetooth® connection
11. Send data
12. MIN / MAX / DELTA mode
13. Internal/external measurement indicator
14. Active reference indicator
15. Tolerance indicator
14 13 12 11
10
9
8
7654
3
2
1
15

6
1. Operating features of the instrument
- The instrument has two operating modes: basic functions (direct ac-
cess) and advanced functions. In addition to the conguration functions,
available access to the MIN, MAX and DELTA (TIR) mode, or display of
tolerances (see chaps. 3 and 4)
- The «favourite» key gives direct access to the function used most often
(see chap. 7)
- Sets a Preset value, reset the MIN/MAX mode, veries a selection, and
controls switching off the instrument. By default, SIS mode enables au-
tomatic switch-off with no loss of origin (see chap. 8).
1.1 Personalising the functions
It is possible to activate or de-activate certain functions of the instrument via
RS232 (see chap. 11)
1.2 Data transmission parameters
4800Bds, 7 bits, even parity, 2 stop bits
2. Start
Press a button.
SET
MODE
3. Basic functions
MODE
MODE
SET
Each short press on gives direct access to the basic functions:
→ Units selection (mm or Inch)
→ Choice of reference (REF1, REF2 or
automatic REF)
→ Inputting a Preset value
next digit 0...9 save the
Preset
MODE
MODE
SET
MODE
SET
MODE
MODE
MODE
ArEf
sEt 0.00 → Normal mode : zero reset
Min (max) Mode : diameter calibration on the
measured min (max) value.

7
E
4. Advanced functions
MODE
MODE
Prolonged pressure (>2s) on gives access to the advanced functions.
Then, each short press on accesses the required function:
MODE
SET
MODE
SET
MODE
SET
MODE
MINIMUM, MAXIMUM mea-
surement and DELTA (TIR)
.................Tolerance display
(inputting tolerance limits, see chap. 6)
.................Choice of measurement direction
(positive or negative sense)
save the
Preset
3.1 Automatic references
The instrument has the ability to switch automatically between its two references.
This allows using the caliper for both internal and external measuring without
going through the menu to change the reference.
Steps :
On Ref 1
• Introduce a measurement standard as preset, measure this standard and
do a preset recall
• Or set the zero at closed jaws position
On Ref 2
• Measure the internal measurement probes gap (with a caliper, probes
included) and introduce it as preset value
• Do a preset recall at closed jaws position
Set AREF
It is now possible to measure in REF1 when closing the jaws or in REF2 when
opening the jaws.

8
4. Advanced functions (continuation)
SET
MODE
SET
MODE
SET
MODE
SET
MODE
SET
MODE
Introduction of a multiplier, other than 1.000
next digit 0...9 save the multiplier
Keypad lock : only the favourite key remains active
(to unlock the keypad, press for 5 s.)
SET
MODE
MACrEsEt
Bluetooth ® function
The connection procedure has been designed to be simple and is signalled by
the following three states:
1° Symbol off disconnected mode
2° Symbol blinking advertising mode
3° Symbol on connected mode
Connection:
1°Activate Bluetooth ® Smart compatible software and hardware (Master : PC,
Display Unit)
2°Start the instrument. By default the Bluetooth® module is active and the
instrument is available for connection during 120s (advertising mode)
3°As soon as the device is detected, a connection is established automatical-
ly. If no connnection is established during 120s, reactivate the Bluetooth ®
module using the bt / On menu.
4°Instrument is ready to communicate (connected mode)
5. Bluetooth®
5.1 Pairing
Pairing with master is automatically done at rst connection.
To connect the instrument to a new master (new pairing), it is necessary to
clear all pairing information on the instrument using the bt / rESEt menu.
Automatic switch-off mode
MAn = de-activated, Auto = active (after 20 min.)

9
E
Introduction of a multiplier, other than 1.000
next digit 0...9 save the multiplier
Keypad lock : only the favourite key remains active
(to unlock the keypad, press for 5 s.)
Bluetooth ® function
6. Insert tolerance limits
MODE
MODE
SET
In order to introduce or modify the tolerance limits, it is necessary to select tol →
On , followed by a short press on
Note :
- In case of measuring internal ratings, you can cross the indicators by reversing
the order of entering the tolerance intervals (upper interval < lower interval)
- It is possible to introduce different tolerance limits on REF1 and REF2.
- It is also possible to display the tolerance limits when the instrument is working
in MIN, MAX or DELTA (TIR) mode
....... Input the lower tolerance limit (e.g. +0019.90 for 20-0.1mm)
.......Input the upper tolerance limit (e.g. +0020.10 for 20+0.1mm)
next digit 0...9 save the tolerance
5.2 Bluetooth ® specication
Radio frequency 2.4Ghz
Robustness FHSS
Latency (from not connected state to
send data) <6ms
Range Open space : up to 15m
Industrial environment : 1-5m
Autonomy with CR2477
Continuous : up to 8 months (Always connected with 4 values /sec)
Saver : up to 21 months (The instrument sends value only when the position has changed)
Blind/Push : up to 24 months (Value is sent from the instrument (button) or requested from
the computer)
Other specications on the manufacturer’s website

10
The «favourite» key gives direct access to a predened function, and can be
congured according to the needs of the user.
In order to assign a function to the «favourite» key, give a prolonged press on
and then select the required function:
Validation of selection: By a prolonged press on , or a press on or
Note: a function can also be assigned via RS232 using the command <FCT
+ Function No.> / example : Change of Unit = <FCT4>
7. Favourite key
10 dir
9 rES
8 toL
7 ModE
6 PrE
4 Unit
3 SEt
2 CLr
1 HoLd
0 dAtA Data transmission
(default)
Hold display
Re-initialise Min-
Max-Delta
Zero reset
Diameter calibration
(min.-max. mode)
mm – IN
Recall Preset
Nor–Min–Max-Delta
Tol ON–Tol OFF
Measurement
sense, positive -
negative
Multiplier
Bluetooth®
10 dir
9 rES
8 toL
7 ModE
6 PrE
4 Unit
3 SEt
2 CLr
1 HoLd
0 dAtA
11 Mul
12 bt
8. Adjustment of the measuring system
MODE
SET
Certain applications need to adjust the instrument to the MIN (or MAX) measured
value. In this case, proceed as follows :
8.1 Adjustment of the instrument
• Enter a Preset value corresponding to the actual size of the standard (see
chap. 3)
• Select the MIN mode (or MAX, depending on the application) (see chap. 4)
• Make a standard measurement (going through the turnaround point)
• Adjust the instrument by selecting the SEt mode and pressing on the button
(see chap. 3)
• The instrument is adjusted and ready to measure.
8.2 Measure
• Make the measurements. The digital display stores and displays the MIN
(or MAX) measured value.
• Before each new measurement, reset the measured value by a short press
on
SET

11
E
SET
>2s
SET
9. Extinction
The instrument goes automatically into stand-by if not used for 20 minutes,
unless Auto OFF mode has been turned off (see Chap. 4, advanced functions)
Stand-by mode can be forced by a prolonged press (> 2 sec) on
SET
MODE
The initial instrument settings can be restored at any time by a prolonged press
(>4 sec) simultaneously on and until the message rESEt is displayed.
Nevertheless the instrument retains its conguration settings (units and resolution).
In stand-by mode, the value of the origin is retained by the sensor (SIS mode),
and the instrument automatically restarts with any movement of the measure-
ment probe, RS command, Bluetooth®request or press of a button.
The instrument can be switched off completely for a long period of non-use,
but this will necessitate a zero reset on restart (the origin will be lost):
- Prolonged press (>4s) on :
SET
>4s
SET
10. Re-initialising the instrument
11. Personalising the instrument
Access to the functions of your instrument can be personalised, for more infor-
mation see manufacturer’s website (requires you to connect your instrument
via a Proximity RS/USB cable).
Possibilities:
- De-activate or active the required functions
- Modify access to the advanced functions (direct access)

12
13. List of the main commands
Selection and conguration
CHA+ / CHA-
FCT0 ...9...A...F
MM / IN
KEY0 / KEY1
MUL [+/-] xxx.xxxx
PRE [+/-] xxx.xxx
REF1 / REF2 / AREF
STO1 / STO0
TOL1 / TOL0
LCAL dd.mm.yy
NCAL dd.mm.yy
TOL +/-xxx.xxx +/-zzz.zzz
MIN / MAX / DEL / NOR
CLE
UNI1 / UNI0
OUT1 / OUT0
PRE ON / PRE OFF
PRE
SET
NUM xxxxxxxxxx
Change measurement direction
Assign «favourite» function
Change measurement unit
Lock / unlock keypad
Modication of the multiplier
Modify preset value
Change the active reference
Activate/de-activate HOLD
Activate/de-activate tolerances
Modify last calibration date
Modify next calibration date
Inputting tolerance limits
Selecting MIN, MAX, Delta, Normal mode
Re-initialisation of MIN, MAX or Delta mode
Activate/de-activate change of units
Activate/de-activate contin. data transmission
Activate/de-activate preset function
Recall preset
Zero reset
Modify the serial number
12. Connecting the instrument
The instrument can be connected to a
peripheral via a Proximity (RS or USB) or
Bluetooth®Smart. (See chap. 1)
Measured values can be transmitted and
the instrument driven using predened re-
tro-commands (see chap. 13 for a list of the
main commands)

13
E
Change measurement direction
Assign «favourite» function
Change measurement unit
Lock / unlock keypad
Modication of the multiplier
Modify preset value
Change the active reference
Activate/de-activate HOLD
Activate/de-activate tolerances
Modify last calibration date
Modify next calibration date
Inputting tolerance limits
Selecting MIN, MAX, Delta, Normal mode
Re-initialisation of MIN, MAX or Delta mode
Activate/de-activate change of units
Activate/de-activate contin. data transmission
Activate/de-activate preset function
Recall preset
Zero reset
Modify the serial number
14. Construction
Hardened steel guide rods
External measurement
Jaw length 200 mm
Jaw width 8 mm
Material TiN coated stainless steel
Internal measurement
Cylindrical measurement probes Ø 8 mm h6
Probe length 30 mm
Material Hard metal
Bluetooth®
BT0/BT1 Activate/de-activate Bluetooth® modules
BTRST Reset pairing information
MAC? Bluetooth® MAC adress ?
Maintenance functions
BAT? Battery status (BAT1=Ok, BAT0=low battery)
OFF Switch off (wake up using a button or RS)
RST Re-initialisation of the instrument
SBY Put instrument in stand-by(SIS)
VER? Version No. and date of rmware
Current value? (mode Tol, value followed by < >)
Measurement sense?
«Favorite» function active?
Measurement unit active?
Keypad locked?
Multiplier value?
Preset value?
Reference active?
Status of HOLD function?
Current tolerance limit values?
Date of last calibration?
Date of next calibration?
Active mode (MIN, MAX, Delta or Normal)?
Main instruments parameters?
Instrument identication code?
Serial number?
Interrogation
?
CHA?
FCT?
UNI?
KEY?
MUL?
PRE?
REF?
STO?
TOL?
LCAL?
NCAL?
MOD?
SET?
ID?
NUM?

14
15. Specications
Instrument UL4 400 UL4 600 UL4 1000 UL4 1500
External measurement capacity 0-415 mm 0-620 mm 0-1030 mm 0-1545 mm
Internal measurement capacity 26-441 mm 26-646 mm 26-1056 mm 26-1571 mm
Max error. 30 µm 40 µm 50 µm 90 µm
Repeatability 20 µm (with constant measuring force)
Weight 1.5 kg 1.6 kg 1.9 kg 2.3 kg
Measurement force 5 - 10 N
Max. speed of travel 2.0 m/s
No. of measurements/sec mesurement : 10 meas/s MIN/MAX mode : 20 meas/s
Measurement unit metric/english (inch)
Maximum Preset. +9999.99 mm / +399.9995 IN
Measurement system Sylvac Inductive System (patented)
Power 1 battery lithium 3V, type CR2477 or CR2032 (+ adapter)
Battery life CR2477 : 30’000 hours, CR2032 : 7’500 hours
Bluetooth® (see chap. 5.2)
Data output Bluetooth® smart / Proxi. -RS232 or - USB
Range up to 15m (depending on the environment)
Working temperature (storage) +5 à +40° C (-10 à +60° C)
Electromagnetic compatibiliy as per. EN 61326-1
IP rating (according with
IEC60549)
electronic module : IP67

15
E

16
MINMAX
PRESET
TOL INPUT
2
x
1
IN
mm
H
B
B
1. Bec de mesure gauche
2. Bec de mesure droit
3. Touche de mesure
4. Levier de verrouillage du curseur mobile gauche
5. Poulet de serrage du curseur droit
6. Poulet de serrage des tiges de mesure intérieure
7. Curseur de pression
8. Levier de blocage du curseur de pression
9. Indicateur de pression
10. Bouton SET
11. Bouton Favoris
12. Bouton Mode
13. Bouchon batterie
14. Display
15. Tiges de mesure intérieure interchangeables
16. Perche
17. Logement pour câble Proximity
16
15
17
4 14 5 10 8 7
13 12 11 9
2
15
1
6
3
Indicateur de pression
Position centrale
Position de mesure
(Mesure extérieure)
Position de mesure
(Mesure intérieure)

17
F
MAX
PRE PUT
TOL
H
mm
IN
MIN
SET IN
1. Unité de mesure (mm/INCH)
2. Indicateur + / -
3. Batterie faible
4. Mode tolérance actif
5. Verrouillage des boutons
6. Mode preset
7. Facteur de multiplication
8. Afchage 6 digits
9. Gel de la valeur de mesure
10. Connexion Bluetooth®
11. Envoi de données
12. Mode MIN / MAX / DELTA
13. Indicateur de mesure intérieur / extérieur
14. Indicateur de la référence active
15. Indicateur des tolérances
14 13 12 11
10
9
8
7654
3
2
1
15

18
1. Les fonctionnalités de l’instrument
- L’instrument possède 2 modes de travail: fonctions de base (avec accès
direct) et fonctions avancées.
En plus des fonctions de conguration, vous pouvez accéder à 2 références
de travail, au mode MIN, MAX et DELTA (TIR), à l’afchage des tolérances,
ou à l’introduction d’un facteur de multiplication (voir chap. 3 et 4)
- Le bouton «favori» permet d’attribuer un accès direct à la fonction prin-
cipalement utilisée (voir chap. 7)
- Le bouton «SET» permet d’attribuer une valeur de Preset, de réinitialiser
le mode MIN/MAX, de quittancer une sélection, et de gérer l’extinction
de l’instrument. Par défaut, le mode SIS permet l’extinction automatique
sans perte de l’origine (voir chap. 8).
1.1 Personnalisation des fonctions
Vous avez la possibilité d’activer ou désactiver certaines fonctions de l’instru-
ment par RS232 (voir chap. 11)
1.2 Paramètres de transmission de données
4800Bds, 7 bits, parité paire, 2 stop bits
2. Démarrer
Presser un bouton.
SET
MODE
3. Fonctions de base
MODE
MODE
SET
Chaque pression courte sur le bouton permet un accès direct aux fonctions de base :
→ Sélection de l’unité (mm ou Inch)
→ Choix de la référence (REF1, REF2 ou REF
automatique)
→ Introduction d’une valeur de Preset
prochain digit 0...9 sauve le
Preset
MODE
MODE
SET
MODE
SET
MODE
MODE
MODE
ArEf
sEt 0.00 → Mode normal : Mise à zéro
Mode min (max) : calibration du diamètre
valeur min(max) mesurée

19
F
4. Fonctions avancées
MODE
MODE
Une pression longue (>2s) sur permet d’accéder aux fonctions avancées.
Puis, chaque pression courte sur accède à la fonction souhaitée:
MODE
SET
MODE
SET
MODE
SET
MODE
Mesure du MINIMUM,
MAXIMUM et DELTA (TIR)
.................Afchage des tolérances
(introduction des limites de tolérance, voir chap. 6)
.................Choix de la direction de mesure
(sens positif ou négatif)
sauve le
Preset
3.1 Référence automatiques
L’instrument est capable de commuter automatiquement entre ses deux références.
Ceci permet d’utiliser le calibre pour les mesures intérieures et extérieures sans
passer par le menu pour changer de référence.
Marche à suivre :
En Ref 1
• Introduire une valeur étalon comme preset, mesurer l’étalon et faire un
rappel de preset
• Ou effectuer un zéro becs fermés
En Ref 2
• Mesurer l’écart entre les touches de mesure intérieure (avec un calibre,
touches comprises) et l’introduire comme valeur de preset
• Effectuer un rappel de preset becs fermés
Passer en AREF
Il est maintenant possible de mesurer en REF1 lorsque les becs se ferment ou
en REF2 lorsque les becs s’ouvrent.

20
4. Fonctions avancées (suite)
SET
MODE
SET
MODE
SET
MODE
SET
MODE
SET
MODE
Introduction d’un facteur de multiplication autre que 1.000
Prochain digit 0...9 sauve le facteur
Blocage du clavier : Seule la touche favori reste active
(pour désactiver le blocage du clavier, presser pendant 5 s.)
SET
MODE
MACrEsEt Activation du module
Bluetooth ®
Conguration Bluetooth ®
La procédure de connexion a été pensée au plus simple et se distingue par
les 3 états ci-dessous:
1° Symbole mode déconnecté
2° Symbole mode découverte (clignote)
3° Symbole mode connecté
Connexion:
1° S’assurer que l’application et le matériel Bluetooth ® Smart compatibles
sont actifs (PC, unité de mesure).
2° Démarrer l’instrument. Par défaut le module Bluetooth ® est actif et l’instru-
ment est connectable durant 120s (mode découverte).
3° Dès que l’instrument est détecté la connexion est automatique. Si la
connexion n’a pas été établie durant les 120s, réactiver le module Bluetooth ®
via le menu bt / On
4° L’instrument est prêt à transmettre (mode connecté)
5. Bluetooth®
5.1 Appairage
L’appairage de l’instrument avec le maître se fait automatiquement à la pre-
mière connexion.
Pour connecter un instrument à un nouveau maître (nouvel apparaige) il est
nécessaire d’effacer ses informations d’appairage via le menu bt/rESEt.
Mode d’extinction automatique
MAn = désactivé, Auto = actif (après 20 min.)
