Sym Fiddle II 50 SYM Series User manual

SERVICE MANUAL
FORWARD
HOW TO USE THIS MANUAL
CONTENTS
MECHANISM ILLUSTRATIONS

FORWARD
This service manual contains the technical data of each component inspection
and repair for the SANYANG Fiddle 50 series scooter. The manual is shown
with illustrations and focused on “Service Procedures”, “Operation Key Points”,
and “Inspection Adjustment” so that provides technician with service guidelines.
If the style and construction of the scooter, Fiddle 50 series, are different from
that of the photos, pictures shown in this manual, the actual vehicle shall prevail.
Specifications are subject to change without notice.
Service Department
Sanyang Industry Co., LTD.
Home page Contents

How to Use This Manual
This service manual describes basic information of different system parts and
system inspection & service for SANYANG Fiddle 50 scooters. In addition,
please refer to the manual contents in detailed for the model you serviced in
inspection and adjustment.
The first chapter covers general information and trouble diagnosis.
The second chapter covers service maintenance information.
Th third to the tenth nine chapters covers engine and driving systems.
The tenth to the fourteenth is contained the parts set of assembly body.
The fifteenth chapter is electrical equipment.
The sixteenth chapter is wiring diagram
Please see index of content for quick
having the special parts and system
information.
All information, illustration, directions and specifications included in this manual
are current as at the time of publication. Sanyang reserves the rights to make
changes at any time without prior notice and without incurring any obligation
whatever. Without written consent by SANYANG can not copy any part of this
manual.
There are 4 buttons, “Forward,” “How to use this manual,” “Mechanism
Illustrations,” and “Contents” on the CD-R version, and can be access to these
items by click the mouse.
If user wants to look for the content of each chapter, selecting the words of
each chapter on the main contents can reach to each chapter. There are two
buttons, Back to homepage and Main contents, onto the top line of first page of
the each chapter. Thus, if the user needs to check other chapters, he can click
the top buttons to back the homepage or main contents. The content of each
chapter can be selected too. Therefore, when needs to checking the content
inside of the chapter, click the content words of the chapter so that can back to
the initial section of the content. In addition, there is a “This chapter contents”
button at the top line of each page so that clicking the button can back to the
contents of this chapter.
Home page Contents

CONTENTS
Page Content Index
1-1 ~ 1-16 GENERAL INFORMATION
1
2-1 ~ 2-12 SERVICE MAINTENANCE INFORMATION 2
3-1 ~ 3-6 LUBRICATION SYSTEM 3
4-1 ~ 4-6 ENGINE REMOVAL 4
5-1 ~ 5-8 CYLINDER HEAD/CYLINDER/PISTON 5
6-1 ~ 6-4 ALTERNATOR 6
7-1 ~ 7-14 “V” TYPE BELT DRIVING SYSTEM/KICK-STARTER 7
8-1 ~ 8-6 FINAL DRIVING MECHANISM 8
9-1 ~ 9-6 CRANKCASE/CRANKSHAFT 9
10-1 ~ 10-10
FUEL SYSTEM
10
11-1 ~ 11-6 BRAKE SYSTEM 11
12-1 ~ 12-12
BODY COVER
12
13-1 ~ 13-12
STEERING/FRONT WHEEL/SUSPENSION
13
14-1 ~ 14-4 REAR WHEEL/SUSPENSION 14
15-1 ~ 15-20
ELECTRICAL EQUIPMENT
15
16-1 ~ 16-2 ELECTRICAL DIAGRAM 16
Home page

MODEL ILLUSTRATION
FA05U
Head light
Front brake lever Rear brake lever
Tail light
Helmet hook
Fuel tank cap
Engine number
Storage box
Muffler
Battery / Fuses /
C.D.I. /
Eng. Oil tank cap
Light / Starter switch
High & Low beam /
Turn signal / Horn switch
Air cleaner
Frame number
Front turn signal
Ignition switch
Rear turn signal
Seat lock
Rear turn signal
Home page Contents

1. GENERAL INFORMATION
1-1
Symbols and Marks··························1-1
General Safety ··································1-2
Service Precautions ·························1-3
Specifications ···································1-5
Torque values···································1-6
Cables and Harness Routing ··········1-8
Troubleshooting·······························1-11
Lubrication Points····························1-15
Symbols and Marks
Symbols and marks are used in this manual to indicate what and where the special service are needed,
in case supplemental information is procedures needed for these symbols and marks, explanations will
be added to the text instead of using the symbols or marks.
Warning Means that serious injury or even death may result if procedures are not
followed.
Caution Means that equipment damages may result if procedures are not
followed.
Engine oil Limits to use SAE 20 JASO FC class oil. Warranty will not cover the
damage that caused by not apply with the limited engine oil.
(Recommended oil: MAX-2 serial oils)
Grease King Mate G-3 is recommended.
Gear oil King Mate gear oil serials are recommended. (Bramax HYPOID GEAR
OIL # 140)
Locking
sealant Apply sealant, medium strength sealant should be used unless otherwise
specified.
Oil seal Apply with lubricant.
Renew Replace with a new part before installation.
Brake fluid Use recommended brake fluid DOT3 or WELLRUN brake fluid.
Special tools Special tools.
OCorrect Meaning correct installation.
XWrong Meaning wrong installation.
Indication Indication of components.
Directions Indicates position and operation directions.
Components assembly directions each other.
Indicates where the bolt installation direction, --- means that bolt cross
through the component (invisibility).
Home page Contents
1

1. GENERAL INFORMATION
1-2
General Safety
Carbon monoxide
If you must run your engine, ensure the place is
well ventilated. Never run your engine in a closed
area. Run your engine in an open area, if you
have to run your engine in a closed area, be sure
to use an extractor.
Caution
Exhaust contains toxic gas which may cause
one to lose consciousness and even result in
death.
Gasoline
Gasoline is a low ignition point and explosive
material. Work in a well-ventilated place, no
flame or spark should be allowed in the work
place or where gasoline is being stored.
Caution
Gasoline is highly flammable, and may explode
under some conditions, keep it away from
children.
Used engine oil
Caution
Prolonged contact with used engine oil (or
transmission oil) may cause skin cancer
although it might not be verified.
We recommend that you wash your hands with
soap and water right after contacting. Keep the
used oil beyond reach of children.
Hot components
Caution
Components of the engine and exhaust system
can become extremely hot after engine
running. They remain very hot even after the
engine has been stopped for some time. When
performing service work on these parts, wear
insulated gloves and wait until cooling off.
Battery
Caution
yBattery emits explosive gases; flame is
strictly prohibited. Keep the place well
ventilated when charging the battery.
yBattery contains sulfuric acid (electrolyte)
which can cause serious burns so be careful
do not be spray on your eyes or skin. If you
get battery acid on your skin, flush it off
immediately with water. If you get battery
acid in your eyes, flush it off immediately
with water and then go to hospital to see an
ophthalmologist.
yIf you swallow it by mistake, drink a lot of
water or milk, and take some laxative such
as castor oil or vegetable oil and then go to
see a doctor.
yKeep electrolyte beyond reach of children.
Brake shoe
Do not use an air hose or a dry brush to clean
components of the brake system, use a vacuum
cleaner or the equivalent to avoid dust flying.
Caution
Inhaling dust may cause disorders and cancer
of the breathing system.
Brake fluid
Caution
Spilling brake fluid on painted, plastic, or
rubber parts may cause damage to the parts.
Place a clean towel on the above-mentioned
parts for protection when servicing the brake
system. Keep the brake fluid beyond reach of
children.
