Sym ORBIT III XE05W2-EU Series User manual

SANYANG MOTOR CO .,LTD.
3 CHUNG HUA ROAD HUKOU HSINCHU TAIWAN,R.O.C.
TEL:[phone] FAX:[phone]
E-mail:[email protected]
http://www.sym.com.tw
XE05W2-EU SERIES
XE05W2-IT SERIES
XE05W2-NL SERIES
XE12W2-EU SERIES
XE12W2-IT SERIES
Owner’s Manual

1
1.CONTENTS
1. Contents ........................................................................................................................ 1
2. Control location ............................................................................................................. 3
3. Before riding .................................................................................................................. 4
4. Safe riding ..................................................................................................................... 4
5. Driving ........................................................................................................................... 5
6. Use genuine spare parts ............................................................................................... 5
7. Use of each component ................................................................................................ 6
Gauges .......................................................................................................................... 6
Operation of ignition switch ........................................................................................... 7
Operation of steering handle lock switch ....................................................................... 7
Operation of fuel tank cap switch .................................................................................. 7
Use of buttons ............................................................................................................... 8
Storage box.......................................................................................................................9
Safety helmet hook.........................................................................................................10
Fuel tank cap ................................................................................................................ 10
Brake ............................................................................................................................ 10
8. Important points and cautions for starting engine ........................................................ 11
9. The best way to drive off ............................................................................................. 12
The control of throttle valve handle ............................................................................. 12
Parking method ........................................................................................................... 12
10.Inspection and maintenance before riding ................................................................... 13
Routine inspection ....................................................................................................... 13
Engine oil inspection and change ................................................................................ 13
Fuel inspection.............................................................................................................. 14
Transmission oil inspection and change....................................................................... 14
Inspection and adjustment of brake free play .............................................................. 15
Disc brake inspection (depending on models) ............................................................. 16
Throttle valve handle clearance adjustment ................................................................ 17
Inspection and maintenance of battery ....................................................................... 17
Tire inspection ............................................................................................................. 18
Steering handle front shock absorbers inspection ....................................................... 18
Checking and changing fuses ..................................................................................... 19
Checking the turn signal lights and horn ..................................................................... 19
Checking the front and rear lights ............................................................................... 19
Checking the brake light .............................................................................................. 19

2
1.CONTENTS
Checking for fuel leakage ........................................................................................... 20
Checking the lubrication of body’s various mechanisms ............................................. 20
Checking the spark plug ............................................................................................. 20
Checking the air cleaner ............................................................................................. 20
11.When there is an abnormal condition or a trouble ....................................................... 21
Diagnosis when engine does not start ........................................................................ 21
12.Suggestions on engine fuel ......................................................................................... 21
13.Transmission oil .......................................................................................................... 21
14.Cautions for riding motorcycle ..................................................................................... 22
15.Periodical maintenance schedule...................................................................................23
16.Specification ................................................................................................................ 24

3
2.CONTROL LOCATION
Fuel tank cap
Starter switch
Exhaust Muffler
High &Low beam/Passing/
Turn signal/Horn switch
Front brake level
Tail light
Battery
Air Cleaner
Oil level
Front turn
signal light
Helmet hook
Storage box
Main stand
Ignition switch
Front /Rear brake level
Engine start
control switch
Side stand
Front light /
Position light
Rear turn
signal light
Engine number
Frame number

4
3.BEFORE RIDING
This manual describes thecorrect usage of this motorcycle including safety riding, simple inspection methods
and so on.
For a more comfortable and safety riding, please read this manual carefully.
For your benefit, please ask your SYM dealer the operating manual and carefully read the following:
Correct use of the motorcycle.
Pre-delivery inspection and maintenance.
Thank you very much for your patronage
In order to maximize your motorcycle’s performance, a periodical inspection and maintenance should
be completely carried out.
We recommend that after riding your new motorcycle for the first 300 kilometers, you should take
your motorcycle to the original dealer for an initial inspection, and to have your motorcycle inspected
periodically every 1000 kilometers thereafter.
In case the motorcycle’s specifications and construction are modified and different from the photos
and diagrams on the owner’s manual / catalogues, the specifications and construction of the actual
motorcycle shall prevail.
4. SAFE RIDING
It is very important to be relaxed and clothe properly when driving, observe traffic regulations, do not rush,
always drive carefully and relaxed.
Usually, most people would ride their newly bought motorcycle very carefully, but after they became familiar
with their motorcycles, they tended to become reckless which may result in an accident.
To remind you:
Please wear a safety helmet, and properly tighten the chin belt when riding a motorcycle.
Clothes with open or loose cuffs may be blown by wind and cause the cuffs to get caught on the
steering handle and thus affects riding safety.
So, put on clothes with tight sleeves.
Hold the steering handle by both hands when riding. Never ride with only one hand.
Observe the speed limit.
Wear suitable low-heel shoes.
Perform periodical maintenance and inspection in accordance with the schedule.
WARNING!!
To avoid getting burned by exhaust pipe when taking a passenger. Make sure your passenger has put
his/her feet on the pedals.
After running, the exhaust pipe is very hot, be careful not to get burned when conducting an
inspection or maintenance.
After running, the exhaust pipe is very hot, select a suitable location to park your motorcycle to avoid
others getting burned by the exhaust pipe.
CAUTION:
Modified motorcycle will affect its structure or performance, and cause poor engine operation or
exhaust noise, which will result in shortening the motorcycle’s service life.
Besides, modification is illegal and does not conform to the original design and specifications.
A modified motorcycle will not be covered by warranty; therefore, do not modify your motorcycle at
will.

5
5.DRIVING
Keep the related parts of your body such as arms, palms, lumbar, and toes relax and ride with
the most comfortable posture in order to be able to react quickly whenever it is necessary.
Rider’s posture will greatly affect riding safety. Always keep your body’s gravity in the center of the
saddle, if your body’s gravity is on the rear part of saddle, the front wheel load will be reduced, and
this will cause the steering handle shaking. It is dangerous to ride a motorcycle with an unstable
handle.
It will be much easier to make a turn if rider inclines his body inward when turning. On the other hand,
the rider will feel unstable if his body and the motorcycle do not incline.
The motorcycle is hard to control on a bumpy, unleveled, unpaved road, try to know the road
conditions in advance, slow down and use your shoulder’s force to control the handle.
Suggestion: Do not load objects on the front pedals unnecessarily, to avoid affecting the riding safety
and the operation of steering handle.
CAUTION:
The rider’s feeling on the handle is slightly different with a load or without a load.
Overload may cause the handle to swing and affects the riding safety.
Therefore, do not overload your motorcycle.
CAUTION:
Do not place flammable materials such as rags between the body side cover and engine to avoid
components damaging by fire.
Do not load objects on areas not specified for loading to avoid damage.
SUGGESTION
To maximize the motorcycle’s performance and prolong its service life:
The first month or first 1000km is the wear- in period for the engine and components.
6. USE GENUINE SPARE PARTS
In order to maintain the motorcycle’s best performance, each part’s quality, material, and machined
precision must conform with the design requirements. “SYM Genuine Spare Parts” were made from the
same high quality materials used for the original motorcycle. No parts would be sold to the market until
they could meet the designed specifications through sophisticated engineering and stringent quality
control. Therefore, it is necessary to purchase “SYM Genuine Spare Parts” from “SYM Authorized
Dealers” when replacing spare parts. If you buy cheap or fake substitute parts from the market, no
guarantee can be provided either for the quality or durability. Also, it may result in unexpected troubles
and lower the motorcycle’s performance.
Always use SYM Genuine Spare Parts to keep your motorcycles pure blood and to ensure its long
service life.

6
7.USE OF EACH COMPONENT
(The following is SYM 4 stroke air-cooling scooter’s basic operation, and they could vary from
different individual models. Please consult the end of this manual.)
§GAUGES §
The panel figure for speedometer may vary from model to model, but the location usually are the
same.
CAUTION:
Do not wipe plastic components, e.g. instrument panel, headlight, with organic solvents such as
gasoline…etc to avoid damaging these components.
Speedometer：
Indicates driving speed.
Odometer：
Indicates total accumulated distance traveled.
High Beam Indicator：
This indicator comes on with high beam
headlight is turned on.
Turn (left/right) Signal Indicator：
The left or right Indicator will be flashing
according to the operated directions of turn
signal light switch when it is turned on.
Fuel Meter:
The pointer in this meter shows how much fuel
remains in the tank.
The pointer stays in “E”position when key
switch is turned to “OFF”.
Fault indicator light
If there is something wrong with the ECU, the
warning light will light all the time.
Fuel meter
Odometer
Speedometer
Turn Right
Signal Indicator
Turn Left
Signal Indicator
High Beam
Indicator
Fault indicator light

7
§OPERATION OF IGNITION SWITCH §
“ON” position:
Engine can be started in this position.
Ignition switch key can not be removed.
“OFF” position:
Engine is shut off and can not be started in this position .
Ignition switch key can be removed.
§OPERATION OF STEERING HANDLE LOCK SWITCH §
“Steering handle lock” position
Turn the steering handle to left and insert the key into,
press ignition switch key clockwise and then lightly turn
it to left to the “lock” position.
The steering handle is locked in this position.
Ignition switch key can be removed.
When unlocking, simply turn the key from the “LOCK”
position to the “OFF”position.
§OPERATION OF FUEL TANK CAP SWITCH§
“Fuel tank cap open”position：
How to open：Insert your key into the ignition switch, and turn it to the right.
How to lock：Push the fuel tank cap and it locks automatically
§OPERATION OF IGNITION§
“OPEN”position:
The keyhole baffle can be moved to open by turning the “open “after contact and pointing at the
magnet switch keyhole
“SHUT”position:
Directly press the black button next to the “shut “button and the keyhole shutter can be closed by
automatically popping the keyhole baffle.
MAGNETITE KEY：
Insert your magnetite key into the magnetite keyhole, and turn it to right ignition keyhole block
board can be to open.
When close ignition keyhole. You just push the Ignition keyhole block board push rod, and ignition
keyhole can be to close.
Magnetite key keyhole
IGNITION SWITCH
CAUTION:
Make sure to take the
key away with you
before you lock your
seat.
Magnetite key

8
CAUTION:
Never operate the ignition switch key when the motorcycle is running. To turn the ignition switch
to “OFF”and “LOCK”position will shut off the electrical system and that may result in a
dangerous accident. Therefore, the ignition switch can only be turned off after the motorcycle has
been completely stopped.
Always remove the key and be sure to take the key away with you after locking the steering
handle before leaving your motorcycle.
If ignition switch remains in the “ON” position for a prolonged period after the engine has been
stopped, the battery’s capacity will be reduced and this may affect the engine’s start ability.
Make sure to take the key away with you before you lock your seat.
§USE OF BUTTONS §
Electrical starter button
This is a starting motor button (switch) for engine starting.
With the main switch “on”, press this button while holding the front or rear brake lever will start
the engine.
CAUTION:
Release this button immediately after engine has been starter, and never press the button again
to avoid damaging the engine.
This mechanism is a safety design. The engine can only be started after the front or rear brake
lever (pedal) has been applied.
High/low beam switch
This is the high and low beam of headlight switching switch. Press this switch to switch between high
and beams.
This is for high beam.
This is for low beam.(please turn to low beam riding in city.)
Horn Switch
Turn Signal Switch
passing
High/low beam
switch
Electrical starter
button

9
passing switch
Turn ignition switch to the“ON”position and press this button down. Then, the high beam of
headlight will come on immediately to warn the driver of the vehicle ahead that you intend to overtake
him/her.(For overtake, high beam indicator will come on at this time ) This button will return to original
position after releasing
Engine start control switch
The switch button position is under seat.
“LOCK”position: Engine is locked and can not be started engine in
this position.
“UNLOCK”position: When the ignition switch is “on”position, the
start control switch is “off”position, press electrical
starter button while holding the front or rear brake lever
will start the engine.
Horn Switch
Press this button down when ignition switch is in the “ON”position,
the horn will sound.
Turn Signal Switch
Turn signal lights are used when turning left/right or changing lane.
Turn ignition switch to the “ON”position, and slide the turn signal switch to left or right . Then, the turn
signal lights will flash.
To release, simply return the turn signal light button to the original position.
Right-side turn signal light flashing means you intend to make a right turn.
Left-side turn signal light flashing means you intend to make a left turn.
§STORAGE BOX§
This box is located under the seat.
Maximum load capacity:5kg.
Do not store valuables in the box.
Make sure that the seat has been locked completely after it was
pressed down.
Take out valuables before washing to avoid wetting these objects.
Do not place thermal sensitive objects in the box because of engine’s
heat and high temperature.
Engine start
control switch
Storage box
Passing

10
§SAFETY HELMET HOOK§
Stop the motorcycle, and hook the safety helmet chin belt
the hook.
§FUEL TANK CAP§
1. Insert the key into the ignition switch and rotate to the right ,the fuel tank cap will popup
automatically.
2. Do not fill above the fuel upper limit when refueling.
3. Align the “△”mark on the cap with the “△”mark on the fuel tank, then depress the fuel cap
clockwise .
CAUTION:
Main stand should be put down on the ground, engine should be shut off and flames should be
strictly prohibited to ensure safety when refueling.
Do not fill above fuel upper limit when refueling. Otherwise, fuel will flow out through a hole on the
cap that may damage the body’s painting, in serious cases; it serious cases; it may cause a fire to
burn down the motorcycle.
Make sure the cap has been tightened properly.
§BRAKE§
Pull the right brake lever to operate the front brake.
Pull the left brake lever to operate the front and rear brake simultaneously (CBS model).
Avoid unnecessary sudden braking.
Use front and rear wheel brakes simultaneously when braking.
Avoid brake continuously for a long period of time because that may overheat the brakes and reduce
its braking efficiency.
Slow down and brake early when riding in rainy days on slippery roads. Never apply the brakes
suddenly to prevent skidding and falling.
Using only the front brake or the rear brake increases the risk of falling because the motorcycle is
tend to pulled to one side.
《Engine Brake》
Return the throttle valve handle back to its original position, and apply engine brake.
It is necessary to apply brake both for front wheel and for rear wheel intermittently when riding on a long or
stiff slope.
CAUTION:
Do not hang the safety helmet onto this hook when
riding to avoid damaging motorcycle and loosing safety
helmet’s function.
For Front Wheel
For Front Wheel And
Rear Wheel
CBS model
CBS group
CAUTION:
Do not adjust these
bolts if there is no
special status.
If you need some
adjustment, you
must go to SYM
authorized shop to
adjust.
Hook

11
8.IMPORTANT POINTS AND CAUTIONS FOR STARTING ENGINE
CAUTION:
Please check the oil and fuel volume are adequate or not before starting the engine.
To start the engine the main parking stand must be firmly on the ground and the brake is applied
on the rear wheel to prevent the motorcycle from moving forward suddenly.
1.Turn ignition switch key to the ”ON” position.
2.Apply hand rear wheel brake.
3.Do not accelerate, press starter button when the brake is applied.
［We care for you! Before drive off, keep the hand brake applied on the rear wheel.］
CAUTION:
If engine can not be started after press the kick starter arm for 3~5 times, turn the throttle valve
handle 1/8~1/4 turns, and then press the kick starter arm again for an ease start.
In order to avoid damaging the starter motor, please do not press the starter button continuously
over 15 seconds.
If engine still can not be started after pressing starter button over 15 times, stop and wait for 10
seconds before start it again.
It is harder to get the engine started after the motorcycle has been left idle for a long time or after
refueling only after the fuel has been depleted. Then, it is necessary to press starting lever or
starter button several times, and keep the throttle valve handle at the close position to start the
engine.
It may need several minutes to warm up engine if it is a cold start.
Exhaust contains harmful gases (CO), therefore please start the engine at a well ventilated place.
【When starting engine with starting lever.】
After step 1~3 is completed, press the kick starter forcefully by foot with the throttle valve handle at
the close position.
If engine is cold and it is difficult to start, rotating the throttle valve 1/8~1/4 turns will make the start
easier.
Put the kick starter back to its original position after the engine has been started.
CAUTION:
Firmly support the motorcycle with the main parking stand before starting the engine with the kick
starter arm.
Starter engine with the kick starter arm occasionally to prevent it from loosing its function because
of unused for a long time.
1/4
1/8

12
9.THE BEST WAY TO DRIVE OFF
turn on the turn signal light before moving, and make sure no vehicle is coming from behind. Then, drive
off.
§THE CONTROL OF THROTTLE VALVE HANDLE §
Acceleration : To increase speed. When riding on an inclined road, turn the throttle valve handle slowly
to allow the engine to output its power.
Deceleration : To decrease speed.
§PARKING METHOD §
when approaching the parking lot:
1. Turn on the turn signal light early, and pay attention to the vehicles in front, from rear, left and right, then
take the inner lane and approach slowly.
2. Return the throttle valve handle back to its original position, and apply brakes in advance. (Brake light
comes on when braking to warn drivers of vehicles behind.)
When stop completely:
3. Press the turn signal switch back to its original position, and turn the ignition switch key to the “OFF”
position to shut off the engine.
4. Get off the motorcycle from left side after the engine has been stopped, and select a parking place
where the motorcycle will not interfere with traffic and the ground is level, then put down motorcycle’s
main parking stand.
5. Hold the steering handle with your left hand, and hold down the front end of saddle or hold the parking
handle on the lower-left side of saddle with your right hand.
6. Press the main parking stand with your right foot, put down the main parking stand firmly on the ground.
To remind you: Lock the steering handle and remove the key after parking to prevent the motorcycle
from being stolen.
CAUTION:
Park your motorcycle at a safe place where it will not interfere with traffic.
Deceleration
Acceleration

13
10.INSPECTION AND MAINTENANCE BEFORE RIDING
(Please refer to the components location diagram for the following components.)
§ROUTINE INSPECTION §
Check Items
Check Key Points
Engine Oil
Is there enough engine oil?
Fuel
Is it enough? Is it Octane 90 or above
Brake
Front
Braking condition?
(Brake lever free play: 10~20mm)
Rear
Braking condition?
(Brake lever free play: 10~20mm)
Tires
Front
Is tire pressure normal?
(Standard: 1.75kg/cm2)
Rear
Is tire pressure normal?
(Standard: 2.0 kg/cm2for 1 person, 2. 25 kg/cm2for 2 persons)
Steering Handle
Does the handle vibrate abnormally or is difficult to turn?
Speedometer, lights, and rearview
mirror
Is it operated properly?
Do lights come on? Can it be seen clearly from behind?
Tightness of Main Components
Are screws, nuts loosen?
Abnormal Points
Do the previous troubles still exist?
CAUTION:
If any problem founded during routine inspection, correct the problem before using the
motorcycle again, have your motorcycle checked and repaired by the “SYM dealer or
authorized service personnel” if necessary.
§ENGINE OIL INSPECTION AND CHANGE §
INSPECTION:
1. Use the main parking stand to support the motorcycle on a
level ground, remove the dipstick after engine stopped for
3~5 minutes. Wipe oil off the dipstick and then insert it into
the guide tube again (Do not rotate it.)
2. Remove the dipstick and check whether oil level is in
between the upper and lower marks.
Add oil to upper limit if oil is under the lower limit. (Check
cylinder, crankcase…etc for leakage.)

14
OIL CHANGE:
Change engine oil after the first 300km, and change
the engine oil every 1000km thereafter.
In order to maintain the engine’s maximum
performance, check whether the engine oil is enough
every 500km. Add oil to upper limit if the engine oil
has been found to be inadequate.
Engine Oil : Use (API)SJ MA 10W-30 grade or better
engine oil. (especially suggest USE SM 10W-50)
Otherwise, damage will not be covered by warranty.
Oil Capacity : 0.8 Liter (0.70 liters for routine change).
Use SAE 5W-40 when outside temperature is below 0℃.
【Oil Filter Cleaning】
The oil filter nut assembly of the element, and remove the
element. Remove the foreign materials from the element by
using a gasoline or air spraying gun.
WARNING:
Oil level will not be correct when checking the oil level
with the motorcycle parked on an unleveled ground or
immediately after the engine stopped.
Engine and exhaust pipe are hot right after engine
stopped. Pay special attention not to get burned when
checking or replacing engine oil.
If the oil lever approaches lower limit again after refilled,
check the engine for leaks and refill it again.
Keep away from spark and flames when refilling the oil.
§FUEL INSPECTION§
Turn main switch key to “ON”position, and check fuel gauge’s needle range to make sure there is
enough amount of fuel in the fuel tank.
This motorcycle’s engine is designed for using the unleaded fuel of Octane 90 or above.
Firmly secure the main stand on the ground, shut off the engine and keep flames away from the
motorcycle when refueling.
Do not fill above fuel upper limit lever when refueling.
Make sure the fuel tank cap had been tighten properly.
§TRANSMISSION OIL INSPECTION AND CHANGE§
INSPECTION:
Use the main stand to support the motorcycle on a level ground, after the engine stops, wait for 3~5
minutes. Remove the transmission oil infusion bolt, put a measuring glass under the drain bolt, and
remove the drain bolt. Let the oil flows into measuring glass and check for decreased or not. (at
disassembly:180c.c./at change:170c.c. For:XE12W2-EU/IT)/ at disassembly:100.c.c.at change:90c.c
For:XE05W2-EU/NL/IT)
OIL REPLACEMENT:
stop the engine and use the main stand to support your motorcycle on a lever ground. Remove the
infusion bolt and drain bolt, drain out the oil.
Install the drain bolt and tighten it. Fill new transmission oil (170c.c.), and install the infusion bolt and
tighten it. (Make sure that bolts are tightened and check that there’s no leakage.)
Recommend Oil: Genuine SYM HYPOLD GEAR OIL (SAE 85W-140).
Upper limit
Oil filter
Filter nut
Lower limit
Avoid oil emulsification
1. Warming up at regular intervals
2. Warm car runs in a minute every time
3. At least run 10 km once a month
4. Replace oil when 3 months or 1000km

15
§INSPECTION AND ADJUSTMENT OF BRAKE FREE PLAY§
INSPECTION: (Brake lever free play must checked with the engine shut off.)
Brake lever and pedal free play for front and rear wheels.
◆If checking the hand-braking lever for front wheels, its free play (the stroke of hand-braking lever from no
braking to initial braking) should be 10~20mm. It is abnormal if the feel is spongy when holding the
hand-braking lever forcefully.
Adjustment:﹙Drum type﹚
The indentation of brake adjustment nut must be aligned with the pin. (see below figure)
Turn the adjustment nut on brake arm of front and rear wheels to adjust the free play of hand-brake
lever.
Hold the hand-brake levers after adjusting with both hands until there is effective brake feeling.
Measure the free play with a ruler.
Pin
Adjustment nut
CAUTION:
When free play is between 10~20 mm, check brake
indicators of front and rear wheels. If the arrow on the
brake arm aligned with the “△” marked on the brake
disk, that means the brake lining has been excessively
worn, and must be replaced immediately.
To decrease
free play
To increase
free play
Adjustment nut
Rear Wheel drum type
Front wheel drum type
10~20 mm

16
§DISK BRAKE INSPECTION§
Visual check brake lines for leakage, or damage, check brake
lines connections for looseness using a wrench or similar tool,
and check whether steering handle vibration in driving, or any
parts’interference may have damage the brake lines. If so,
bring your motorcycle to your SYM dealer for repairing or
service.
（leak, damaged, looseness of brake line）
（Checking front brake lining）
check the brake from behind the brake caliper.
The brake pad must be replaced with new
lining when the brake pad wear limit reaches
the brake disk.
（Checking oil quantity in brake oil reservoir）
Park the motorcycle on a lever ground, and
check if fluid lever is under the “LOWER”mark.
Recommended Brake Fluid: WELL RUN
BRAKE OIL (DOT 3).
（Replenishment of front wheel brake fluid）
1.Loosen the screws and remove the master cylinder
cover.
2.Wipe clean foreign materials, dirt around the reservoir,
being careful not to let foreign materials fall into the
reservoir.
3. Remove the diaphragm plate and the diaphragm.
4. Add brake fluid to upper lever.
5.Install the diaphragm plate and the diaphragm, and install
the master cylinder cover.
5. please note the diaphragm direction, and do not let
foreign materials fall into the reservoir. And tighten the
master cylinder cover securely.
CAUTION:
TO prevent chemical reaction, please do not use brake fluids other than those recommended.
Do not fill above the upper limit when adding brake fluid and avoid dropping on painting or plastic
components to prevent damage.
CAUTION:
Please drive your motorcycle on a dry road surface
slowly and operate front and rear brakes in order to
find out if there is any malfunction so as to ensure
the motorcycle is at optimum condition and safe
ride.
Brake disk
Brake caliper
Brake pad wear
limit grooves
Screw
Master
cylinder cover
Diaphragm
Upper
Brake fluid

17
§THROTTLE VALVE HANDLE CLEARANCE ADJUSTMENT §
Correct clearance allows throttle vale handle to rotate
2~6mm.
Loosen the lock nut first, then turn the adjust nut to adjust.
Tighten the lock nut securely when finished.
§INSPECTION AND MAINTENANCE OF BATTERY §
The motorcycle is equipped with a maintenance-free type battery, so it is unnecessary to check and add
electrolyte. Have your motorcycle checked by SYM Authorized Dealer should any abnormality is found.
﹙Cleaning of battery terminals﹚
Remove the battery terminals and clean if there are
dirt and corrosion on them.
Battery removal procedures are as follows:
Turn ignition switch key to the “OFF” position, then
remove negative cable screw firstly and disconnect
the negative cable. Then, remove positive cable
screw and positive cable.
CAUTION:
Clean the battery posts with warm water if the posts are eroded and have some white powders on
them.
If there is an obvious erosion on the terminals, disconnect the cables, and then clean the erosion off
with a steel brush or a piece of sandpaper.
Install battery cable after cleaning and apply a thin coat of grease on the terminals.
Install battery in reverse order of removal.
The motorcycle is equipped with a maintenance-free type battery, so it is unnecessary to check and add
electrolyte. Have your motorcycle checked by SYM Authorized Dealer should any abnormality is found.
CAUTION:
This is a closed type battery. Never remove the caps.
In order to prevent electric leakage and self-discharge when the battery sits idle for long periods.
Remove battery from motorcycle; store it in well-ventilated and dimly lighted place after the battery
has been fully charged. Disconnect battery’s negative cable if the battery is still kept on the
motorcycle.
If the battery needs to be replaced, replace with a same closed-type battery (Maintenance-Free).
Check Items:
1. Check throttle valve cable to see if it can be moved
smoothly from a closed position to a wide open position.
2. Rotate steering handle from side to side to check if the
throttle valve cable is interfered.
3. Check to see if the throttle valve cable is obstructed by
other cables preventing it from being operated smoothly.
2~6 mm
Lock nut
Adjust nut
Negative
Positive

18
§TIRE INSPECTION §
Tires should be checked and inflated with the engine shut off.
If a tire’s ground contacting curve is abnormal, check it with an air pressure gauge and inflate it to the
specified pressure.
Tires pressure must be checked with an air pressure gauge when cold.
Visual check tires for frontal and lateral side walls for
crack or damage.
Visual check tires for any nails or small stones wedged
in the tread.
Check the “tread wear indicator” condition to see if
tread groove depth is insufficient.
A tire with a wear bar showing is worn out and should
be replaced immediately.
CAUTION:
Abnormal tire pressure, wear, or crack is the most important cause that results in the loss control
of the steering handle and a punctured tire(s).
§STEERING HANDLE FRONT SHOCK ABSORBERS INSPECTION §
Perform this check with engine shut off and ignition switch key
removed.
Visual check front shock absorbers for damage.
Operate steering handle up and down, and check front shock
absorbers for noises due to bends.
Check the bolts and nuts of front shock absorbers with wrenches for
tightness.
Shake steering handle up & down, left & right, and front & rear to
check if it is loosen, has too much resistance and pulls to one side.
Check steering handle if it is being pulled too tight by the brake
cables.
Take your motorcycle to SYM Authorized Dealer for a check or
adjustment if any abnormal conditions are found.
PLEASE REFER TO SPECIFICATIONS FOR STANDARD TIRE PRESSURE
Tread wear
indicator
Crack and
damage
Foreign materials
(nails or small
stones)

19
§CHECKING AND CHANGING FUSES §
Turn off ignition switch, and check fuses if they are intact. Replace the blown fuse with a new one having the
same specified amperage rating (20A/15A*2/10A). Using a fuse of more than (20A/15A*2/10A) amperes, a
brass or iron wire to replace a blown fuse is strictly prohibited to avoid damaging the electrical system and the
circuit.
Remove the storage box, and you’ll find the fuse holder near battery.
Open the fuse box cover, and pull out the fuse. Check it for damage or broken.
Fuses must be firmly secured with wire connectors when replacing. Loose connections will result in
overhead and damage.
Use only parts having the specified specification to replace electrical components such as light bulbs.
Using parts not having the specified specifications for replacement may cause the fuse to blow and
over-discharge the battery.
Avoid spraying water directly on or around fuse box when washing the motorcycle.
If the new fuse burn out quickly again, please check the faulty reason before replace it again. Take
your motorcycle to your dealer for an inspection if a fuse is blown by unknown causes.
§CHECKING THE TURN SIGNAL LIGHTS AND HORN §
Turn the ignition switch key to the “ON” position.
Make sure that the front & rear and left & right signal lights flashes and also check if the warning buzzer
sounds.
Check turn signal light covers if they are dirty, crack, or loosen.
Press horn button to check if it works.
CAUTION:
Specified specification bulbs should be used for turn signal lights. Otherwise, the normal
operation of turn signal lights will be affected.
Turn on the turn signal light before turning or switching lane to warn driver of vehicles behind.
Turn off the turn signal light immediately by pressing its button down after using. Otherwise, the
flashing of twin signal lights may confuse the drivers of vehicles behind.
§CHECKING THE FRONT AND REAR LIGHTS §
Start engine the head lamp is turned on automatically. Check if head lamp and rear lamp come on.
Check the brightness and direction of front light by wall to see if it is correct.
Check the head lamp cover if it is dirty, crack, or loosen.
§CHECKING THE BRAKE LIGHT §
Turn the ignition switch key to the “ON” position, hold the hand-braking levers for front and rear wheels.
Check if the brake lights come on.
Check the brake light cover if it is dirty, crack, or loosen.
CAUTION:
Use only specified specification bulbs, do not use bulbs with different specifications to avoid
damaging electrical system, burning out bulbs, and discharging the battery.
Do not modify or add other electrical components to prevent over load or short circuit which may
result in a fire and burn down the motorcycle in serious cases.
【INSTALLATION】
【REMOVE】
