Sym 2009 FIDDLE II 125 User manual

The Fiddle II, a modern and timeless design all in one. Technologically advanced, Fiddle II
is built for durability, safety and fun. The chrome rear view mirrors and chrome accents, its
front optics and its vintage tail light supplement the ongoing seduction.
2009 FIDDLE II 125:
Retro Spirit

1
1. CONTENTS
1. Contents.......................................................................................................................... 1
2. Control location................................................................................................................ 3
3. Before riding.................................................................................................................... 4
4. Safe riding ..................................................................................................................... 4
5. Driving ........................................................................................................................... 5
6. Use genuine spare parts ................................................................................................ 5
7. Use of each component ................................................................................................. 6
Gauges .......................................................................................................................... 6
Operation of ignition switch ............................................................................................ 7
Operation of steering handle lock switch ....................................................................... 7
Operation of seat open switch ....................................................................................... 7
Use of buttons ............................................................................................................... 7
Storage box...................................................................................................................... 9
Safety helmet hook......................................................................................................... 10
Fuel tank cap................................................................................................................. 10
Brake............................................................................................................................. 10
8. Important points and cautions for starting engine ........................................................ 11
9. The best way to drive off .............................................................................................. 12
The control of throttle valve handle .............................................................................. 12
Parking method ............................................................................................................ 12
10.Inspection and maintenance before riding .................................................................... 13
Routine inspection ....................................................................................................... 13
Engine oil inspection and change ................................................................................ 13
Fuel inspection .............................................................................................................. 14
Transmission oil inspection and change........................................................................ 14
Inspection and adjustment of brake free play .............................................................. 15
Disc brake inspection (depending on models) ............................................................. 16
Throttle valve handle clearance adjustment ................................................................. 17
Inspection and maintenance of battery ........................................................................ 17
Tire inspection ............................................................................................................. 18
Steering handle front shock absorbers inspection ....................................................... 18
Checking and changing fuses ...................................................................................... 19
Checking the turn signal lights and horn ...................................................................... 19
Checking the front and rear lights ................................................................................ 19
Checking the brake light .............................................................................................. 19

2
1. CONTENTS
Checking for fuel leakage ............................................................................................ 20
Checking the lubrication of body’s various mechanisms .............................................. 20
Checking the spark plug .............................................................................................. 20
Checking the air cleaner .............................................................................................. 20
11.When there is an abnormal condition or a trouble ....................................................... 21
Diagnosis when engine does not start ......................................................................... 21
12.C.D.I. electrical ignition system .................................................................................... 21
13.Suggestions on engine fuel .......................................................................................... 21
14.Transmission oil ........................................................................................................... 21
15.Cautions for riding motorcycle ..................................................................................... 22
16.Periodical maintenance schedule................................................................................... 23
17.Specification ................................................................................................................ 24

3
2. CONTROL LOCATION
MODEL: AW12W-6/AW12W-F
無車身號碼及引擎號碼標示處
Fuel tank cap
Light/Starter switch
Muffler
High& Low beam/Turn
signal/Seat open/Horn Switch
Front light
/
Position light
Main stand
Front brake level
Tail/Stop light Fuses &C.D.I
Battery
Air Cleaner
Oil level
Front turn
signal light
Helmet hook
Storage box
Kick starter
pedal
Side stand
Ignition switch
Rear turn
signal light
Engine start
control switch
Rear brake
level

4
3. BEFORE RIDING
This manual describes the correct usage of this motorcycle including safety riding, simple inspection
methods and so on.
For a more comfortable and safety riding, please read this manual carefully.
yIn case the motorcycle’s specifications and construction are modified and different from the
photos and diagrams on the owner’s manual / catalogues, the specifications and construction of
the actual motorcycle shall prevail.
4. SAFE RIDING
It is very important to be relax and clothe properly when driving, observe traffic regulations, do not rush,
always drive carefully and relaxed.
Usually, most people would ride their newly bought motorcycle very carefully, but after they became
familiar with their motorcycles, they tended to become reckless which may result in an accident.
WARNING!!
yTo avoid getting burned by exhaust pipe when taking a passenger. Make sure your passenger
has put his/her feet on the pedals.
yAfter running, the exhaust pipe is very hot, be careful not to get burned when conducting an
inspection or maintenance.
yAfter running, the exhaust pipe is very hot, select a suitable location to park your motorcycle to
avoid others getting burned by the exhaust pipe.
Thank you very much for your patronage
In order to maximize your motorcycle’s performance, a periodical inspection and maintenance
should be completely carried out.
We recommend that after riding your new motorcycle for the first 300 kilometers, you should
take your motorcycle to the original dealer for an initial inspection, and to have your motorcycle
inspected periodically every 1000 kilometers thereafter.
To remind you:
yPlease wear a safety helmet, and properly tighten the chin belt when riding a motorcycle.
yClothes with open or loose cuffs may be blown by wind and cause the cuffs to get caught on the
steering handle and thus affects riding safety.
ySo, put on clothes with tight sleeves.
yHold the steering handle by both hands when riding. Never ride with only one hand.
yObserve the speed limit.
yWear suitable low-heel shoes.
yPerform periodical maintenance and inspection in accordance with the schedule.
For your benefit, please ask your SANYANG dealer the operating manual and carefully read the
following:
yCorrect use of the motorcycle.
yPre-delivery inspection and maintenance.
CAUTION:
Modified motorcycle will affect its structure or performance, and cause poor engine operation or
exhaust noise, which will result in shortening the motorcycle’s service life.
Besides, modification is illegal and does not conform to the original design and specifications.
A modified motorcycle will not be covered by warranty, therefore, do not modify your motorcycle at
will.

5
5. DRIVING
yKeep the related parts of your body such as arms, palms, lumbar, and toes relax and ride
with the most comfortable posture in order to be able to react quickly whenever it is
necessary.
yRider’s posture will greatly affect riding safety. Always keep your body’s gravity in the center of
the saddle, if your body’s gravity is on the rear part of saddle, the front wheel load will be reduced,
and this will cause the steering handle shaking. It is dangerous to ride a motorcycle with an
unstable handle.
yIt will be much easier to make a turn if rider inclines his body inward when turning. On the other
hand, the rider will feel unstable if his body and the motorcycle do not incline.
yThe motorcycle is hard to control on a bumpy, unleveled, unpaved road, try to know the road
conditions in advance, slow down and use your shoulder’s force to control the handle.
ySuggestion: Do not load objects on the front pedals unnecessarily, to avoid affecting the riding
safety and the operation of steering handle.
6. USE GENUINE SPARE PARTS
In order to maintain the motorcycle’s best performance, each part’s quality, material, and machined
precision must conform with the design requirements. “SYM Genuine Spare Parts” were made
from the same high quality materials used for the original motorcycle. No parts would be sold to the
market until they could meet the designed specifications through sophisticated engineering and
stringent quality control. Therefore, it is necessary to purchase “SYM Genuine Spare Parts” from
“SYM Authorized Dealers or Franchised Dealers” when replacing spare parts. If you buy cheap,
or fake substitute parts from the market, no guarantee can be provided either for the quality or
durability. Also, it may result in unexpected troubles and lower the motorcycle’s performance.
yAlways use SYM Genuine Spare Parts to keep your motorcycles pure blood and to ensure its
long service life.
CAUTION:
The rider’s feeling on the handle is slightly different with a load or without a load.
Overload may cause the handle to swing and affects the riding safety.
Therefore, do not overload your motorcycle.
CAUTION:
yDo not place flammable materials such as rags between the body side cover and engine to
avoid components damaging by fire.
yDo not load objects on areas not specified for loading to avoid damage.
SUGGESTION
To maximize the motorcycle’s performance and prolong its service life:
The first month or first 1000km is the wear- in period for the engine and components.
Avoid rapid acceleration, and keep the speed below 60km/hr.

6
CAUTION:
Do not wipe plastic components, e.g. instrument panel, headlight, with organic solvents such as
gasoline…etc to avoid damaging these components.
The panel figure for speedometer may vary from model to model, but the location usually are the
same.
7. USE OF EACH COMPONENT
(The following is SYM 4 stroke air-cooling 125 c.c. scooter’s basic operation, and they
could vary from different individual models. Please consult the end of this manual.)
§GAUGES§
ySpeedometer：
Indicates driving speed.
yOdometer：
Indicates total accumulated distance traveled.
yHigh Beam Indicator：
This indicator comes on with high beam headlight is turned on.
yTurn (left/right) Signal Indicator：
The left or right Indicator will be flashing according to the operated directions of turn signal light switch
when it is turned on.
yFuel Meter:
The pointer in this meter shows how much fuel remains in the tank.
The pointer stays in “E” position when key switch is turned to “OFF”.
High Beam
Indicator
Fuel meter
Odometer
Speedometer
Turn Right
Signal Indicator
Turn Left Signal
Indicator

7
§OPERATION OF IGNITION SWITCH §
“ON” position:
yEngine can be started in this position.
yIgnition switch key can not be removed.
“OFF” position:
yEngine is shut off and can not be started in this
position .
yIgnition switch key can be removed.
§OPERATION OF STEERING HANDLE LOCK SWITCH §
“Steering handle lock” position
yTurn the steering handle to left and insert the key
into, press ignition switch key clockwise and then
lightly turn it to left to the “lock” position.
yThe steering handle is locked in this position.
yIgnition switch key can be removed.
yWhen unlocking, simply turn the key from the
“LOCK” position to the “OFF” position.
§OPERATION OF SEAT OPEN SWITCH§
yInserted the ignition switch key in the main switch lock.
yTurn the ignition switch key to the“seat open”position counter-clockwise.
yThen, the seat will be open.
§USE OF BUTTONS§
CAUTION:
yNever operate the ignition switch key when the motorcycle is running. To turn the ignition
switch to “OFF” and “LOCK” position will shut off the electrical system and that may result in a
dangerous accident. Therefore, the ignition switch can only be turned off after the motorcycle
has been completely stopped.
yAlways remove the key and be sure to take the key away with you after locking the steering
handle before leaving your motorcycle.
yIf ignition switch remains in the “ON” position for a prolonged period after the engine has been
stopped, the battery’s capacity will be reduced and this may affect the engine’s start ability.
yMake sure to take the key away with you before you lock your seat.
Turn Signal
Switch
Horn Switch
Light switches
High/low
beam switch Seat open
switch
Electrical starter
button
IGNITION SWITCH
CAUTION:
yMake sure to take the
key away with you
before you lock your
seat.

8
yLight Switches
When the switch is turned to this position as the engine is being started, headlight, rear light,
instrument panel light, and position light will come on. This is the high beam of headlight
switching switch.
When the switch is turned to this position as the engine is being started, rear light, instrument
panel light, and position light will come on.
yWhen the switch is turned to this position, all lights will go off.
yElectrical starter button
This is a starting motor button(switch) for engine starting.
With the main switch “on”, press this button while holding the front or rear brake lever will
start the engine.
yHigh/low beam switch
This is the high and low beam of headlight switching switch. Press this switch to switch between
high and beams.
This is for high beam.
This is for low beam.(please turn to low beam riding in city.)
ySeat open switch
Turn ignition switch to the“ON”position and press this button down. Then, the seat will
be open.
This button will return to original position after
releasing.
Press the seat down and it will be locked
automatically.
After the seat catch has been locked , check to
make sure it has locked properly by lightly
lifting the seat.
CAUTION:
yRelease this button immediately after engine has been starter, and never press the button
again to avoid damaging the engine.
yThis mechanism is a safety design. The engine can only be started after the front or rear brake
lever (pedal) has been applied.
yDo not use light system. Turn headlight and turn signal light to the “off” position when the
engine is being started.
S
eat open
switch
CAUTION:
yBe sure to remove the key after the seat
has been locked.
yDo not put the key inside the storage box
after unlocking to avoid the key being
locked inside the storage box when the
seat is pressed down automatically.

9
yEngine start control switch
The switch button position is under seat.
“ON”position: Engine is locked and can not be started
engine in this position.
“OFF”position: When the ignition switch is “on”position,
the start control switch is “off”position, press
electrical starter button while holding the front
or rear brake lever will start the engine.
yHorn Switch
Press this button down when ignition switch is in the “ON”position, the horn will sound.
yTurn Signal Switch
Turn signal lights are used when turning left/right or changing lane.
Turn ignition switch to the “ON”position, and slide the turn signal switch to left or right . Then, the turn
signal lights will flash.
To release, simply return the turn signal light button to the original position.
Right-side turn signal light flashing means you intend to make a right turn.
Left-side turn signal light flashing means you intend to make a left turn.
§STORAGE BOX§
yThis box is located under the saddle.
yMaximum load capacity:10kg.
yDo not store valuables in the box.
yMake sure that the saddle has been locked completely
after it was pressed down.
yTake out valuables before washing to avoid wetting
these objects.
yDo not place thermal sensitive objects in the box
because of engine’s heat and high temperature.
Storage box
Engine start
control switch

10
§SAFETY HELMET HOOK§
yStop the motorcycle, and hook the safety helmet
chin belt the hook.
§FUEL TANK CAP§
1.Insert the key into the seat lock and open the seat, and turn the fuel cap anticlockwise, then the
cap can be removed.
2. Do not fill above the fuel upper limit when refueling.
3. Align the “△”mark on the cap with the “△”mark on the fuel tank, then turn the fuel cap
clockwise and lock the seat.
§BRAKE§
yAvoid unnecessary sudden braking.
yUse front and rear wheel brakes simultaneously when braking.
yAvoid brake continuously for a long period of time because that may overheat the brakes and
reduce its braking efficiency.
ySlow down and brake early when riding in rainy days on slippery roads. Never apply the brakes
suddenly to prevent skidding and falling.
yUsing only the front brake or the rear brake increases the risk of falling because the motorcycle is
tend to pulled to one side.
《Engine Brake》
Return the throttle valve handle back to its original position, and apply engine brake.
It is necessary to apply brake both for front wheel and for rear wheel intermittently when riding on a
long or stiff slope.
CAUTION:
yDo not hang the safety helmet onto this hook
when riding to avoid damaging motorcycle and
loosing safety helmet’s function.
CAUTION:
yMain stand should be put down on the ground, engine should be shut off and flames should be
strictly prohibited to ensure safety when refueling.
yDo not fill above fuel upper limit when refueling. Otherwise, fuel will flow out through a hole on
the cap that may damage the body’s painting, in serious cases; it serious cases; it may cause
a fire to burn down the motorcycle.
yMake sure the fuel cap has been tighten properly.
For Rear Wheel For Front Wheel
Hook

11
8. IMPORTANT POINTS AND CAUTIONS FOR STARTING ENGINE
1.Turn ignition switch key to the ”ON” position.
2.Apply hand (foot) rear wheel brake.
3.Do not accelerate, press starter button when the brake is applied.
［We care for you! Before drive off, keep the hand brake applied on the rear wheel.］
【When starting engine with starting lever.】
yAfter step 1~5 is completed, press the kick starter forcefully by foot with the throttle valve handle
at the close position.
yIf engine is difficult to start with the starting lever when the engine is cold, rotating the throttle
valve 1/8~1/4 turns will make the start easier.
yPut the kick starter back to its original position after the engine has been started.
CAUTION:
yIf engine can not be started after press the kick starter arm for 3~5 times, turn the throttle
valve handle 1/8~1/4 turns, and then press the kick starter arm again for an ease start.
yIn order to avoid damaging the starter motor, please do not press the starter button
continuously over 15 seconds.
yIf engine still can not be started after pressing starter button over 15 times, stop and wait for
10 seconds before start it again.
yIt is harder to get the engine started after the motorcycle has been left idle for a long time or
after refueling only after the fuel has been depleted. Then, it is necessary to press starting
lever or starter button several times, and keep the throttle valve handle at the close position to
start the engine.
yIt may need several minutes to warm up engine if it is a cold start.
yExhaust contains harmful gases (CO), therefore please start the engine at a well ventilated
place.
CAUTION:
yPlease check the oil and fuel volume are adequate or not before starting the engine.
yTo start the engine the main parking stand must be firmly on the ground and the brake is
applied on the rear wheel to prevent the motorcycle from moving forward suddenly.
CAUTION:
yFirmly support the motorcycle with the main parking stand before starting the engine with the
kick starter arm.
yStarter engine with the kick starter arm occasionally to prevent it from loosing its function
because of unused for a long time.
1/4 1/8

12
9. THE BEST WAY TO DRIVE OFF
yTurn on the turn signal light before moving, and make sure no vehicle is coming from behind. Then,
drive off.
§THE CONTROL OF THROTTLE VALVE HANDLE §
Acceleration : To increase speed. When riding on an inclined road, turn the throttle valve handle
slowly to allow the engine to output its power.
Deceleration : To decrease speed.
§PARKING METHOD §
yWhen approaching the parking lot:
1. Turn on the turn signal light early, and pay attention to the vehicles in front, from rear, left and right,
then take the inner lane and approach slowly.
2. Return the throttle valve handle back to its original position, and apply brakes in advance. (Brake
light comes on when braking to warn drivers of vehicles behind.)
yWhen stop completely:
3. Press the turn signal switch back to its original position, and turn the ignition switch key to the “OFF”
position to shut off the engine.
4. Get off the motorcycle from left side after the engine has been stopped, and select a parking place
where the motorcycle will not interfere with traffic and the ground is level, then put down
motorcycle’s main parking stand.
5. Hold the steering handle with your left hand, and hold down the front end of saddle or hold the
parking handle on the lower-left side of saddle with your right hand.
6. Press the main parking stand with your right foot, put down the main parking stand firmly on the
ground.
To remind you: Lock the steering handle and remove the key after parking to prevent the
motorcycle from being stolen.
CAUTION:
yPark your motorcycle at a safe place where it will not interfere with traffic.
Deceleration
Acceleration

13
10. INSPECTION AND MAINTENANCE BEFORE RIDING
(Please refer to the components location diagram for the following components.)
§ROUTINE INSPECTION §
Check Items Check Key Points
Engine Oil Is there enough engine oil?
Fuel Is it enough? Is it Octane 90 or above
Brake Front Braking condition?
(Brake lever free play: 10~20mm)
Rear Braking condition?
(Brake lever free play: 10~20mm)
Tires Front Is tire pressure normal?
(Standard: 1.75kg/cm2)
Rear Is tire pressure normal?
(Standard: 2.0 kg/cm2for 1 person, 2. 25 kg/cm2for 2 persons)
Steering Handle Does the handle vibrate abnormally or is difficult to turn?
Speedometer, lights, and
rearview mirror Is it operated properly? Do lights come on? Can it be seen clearly from behind?
Tightness of Main Components Are screws, nuts loosen?
Abnormal Points Do the previous troubles still exist?
§ENGINE OIL INSPECTION AND CHANGE §
yINSPECTION:
1. Use the main parking stand to support the
motorcycle on a level ground, remove the dipstick
after engine stopped for 3~5 minutes. Wipe oil off
the dipstick and then insert it into the guide tube
again (Do not rotate it.)
2. Remove the dipstick and check whether oil level is
in between the upper and lower marks.
yAdd oil to upper limit if oil is under the lower limit.
(Check cylinder, crankcase…etc for leakage.)
CAUTION:
yIf any problem founded during routine inspection, correct the problem before using the
motorcycle again, have your motorcycle checked and repaired by the “SYM dealer or
authorized service personnel” if necessary.

14
OIL CHANGE:
yChange engine oil after the first 300km, and change the
engine oil every 1000km thereafter.
yIn order to maintain the engine’s maximum
performance, check whether the engine oil is enough
every 500km. Add oil to upper limit if the engine oil
has been found to be inadequate.
yEngine Oil : Use (API) SH/CD SAE 10W-30 grade or
better engine oil. Otherwise, damage will not be covered
by warranty.
※Recommended Oil: SYM Genuine 4X OIL.
yOil Capacity : 0.85 Liter (0.8 liter for routine change).
【Oil Filter Cleaning】
The oil filter nut assembly of the element, and remove the
element. Remove the foreign materials from the element by
using a gasoline or air spraying gun.
§FUEL INSPECTION§
yTurn main switch key to “ON” position, and check fuel gauge’s needle range to make sure there
is enough amount of fuel in the fuel tank.
yThis motorcycle’s engine is designed for using the unleaded fuel of Octane 90 or above.
yFirmly secure the main stand on the ground, shut off the engine and keep flames away from the
motorcycle when refueling.
yDo not fill above fuel upper limit lever when refueling.
yMake sure the fuel tank cap had been tighten properly.
§TRANSMISSION OIL INSPECTION AND CHANGE§
INSPECTION:
yUse the main stand to support the motorcycle on a level ground, after the engine stops, wait for
3~5 minutes. Remove the transmission oil infusion bolt, put a measuring glass under the drain
bolt, and remove the drain bolt. Let the oil flows into measuring glass and check for decreased or
not. (at disassembly: 100~110c.c./at change:90~100c.c.).
OIL REPLACEMENT:
yStop the engine and use the main stand to support your motorcycle on a lever ground. Remove
the infusion bolt and drain bolt, drain out the oil.
yInstall the drain bolt and tighten it. Fill new transmission oil (90~100c.c.), and install the infusion
bolt and tighten it. (make sure that bolts are tightened and check that there’s no leakage.)
yRecommend Oil: Genuine SYM HYPOLD GEAR OIL (SAE 85W-140).
yUse SAE85-90 when outside temperature is below 0℃.
WARNING:
yOil level will not be correct when checking the oil level
with the motorcycle parked on an unleveled ground or
immediately after the engine stopped.
yEngine and exhaust pipe are hot right after engine
stopped. Pay special attention not to get burned
when checking or replacing engine oil.
yIf the oil lever approach lower limit again after refilled,
check the engine for leaks and refill it again.
yKeep away from spark and flames when refilling the oil.
Upper limit
Lower limit
Oil filter
Filter nut

15
§INSPECTION AND ADJUSTMENT OF BRAKE FREE PLAY§
INSPECTION: (Brake lever free play must checked with the engine shut off.)
yBrake lever and pedal free play for front and rear wheels.
◆If checking the hand-braking lever for front wheels, its free play (the stroke of hand-braking lever
from no braking to initial braking) should be 10~20mm. It is abnormal if the feel is spongy when
holding the hand-braking lever forcefully.
◆If checking the foot-braking pedal for rear wheels, its free play (the stroke of foot-braking pedal
from no braking to initial braking) should be 20~30mm. It is abnormal if the feel is spongy when
press the foot-braking pedal forcefully.
Adjustment:﹙Drum type﹚
yThe indentation of brake adjustment nut must be aligned with the pin. (see below figure)
yTurn the adjustment nut on brake arm of front and rear wheels to adjust the free play of
hand-brake lever.
yHold the hand-brake levers after adjusting with both hands until there is effective brake feeling.
yMeasure the free play with a ruler.
Pin
A
djustment nut
10~20 mm
Rear Wheel hand-brake type
CAUTION:
When free play is between 10~20 mm, check brake
indicators of front and rear wheels. If the arrow on
the brake arm aligned with the “△” marked on the
brake disk, that means the brake lining has been
excessively worn, and must be replaced
immediatel
y
.
To decrease
free play
To increase
free play
A
djustment nut
Rear Wheel drum type

16
§DISK BRAKE INSPECTION§(Applicable for model equipped with disc brake.)
yVisual check brake lines for leakage, or damage, check
brake lines connections for looseness using a wrench or
similar tool, and check whether steering handle vibration
in driving, or any parts’ interference may have damage
the brake lines. If so, bring your motorcycle to your
SANYANG dealer for repairing or service.
（leak, damaged, looseness of brake line）
（Checking front brake lining）
ycheck the brake from behind the brake
caliper. The brake pad must be replaced
with new lining when the brake pad wear
limit reaches the brake disk.
（Checking oil quantity in brake oil
reservoir）
yPark the motorcycle on a lever ground, and
check if fluid lever is under the “LOWER”
mark. Recommended Brake Fluid: WELL
RUN BRAKE OIL (DOT 3).
（Replenishment of front wheel brake fluid）
1.Loosen the screws and remove the master cylinder
cover.
2.Wipe clean foreign materials, dirt around the reservoir,
being careful not to let foreign materials fall into the
reservoir.
3. Remove the diaphragm plate and the diaphragm.
4. Add brake fluid to upper lever.
5.Install the diaphragm plate and the diaphragm, and
install the master cylinder cover.
6.please note the diaphragm direction, and do not let
foreign materials fall into the reservoir. And tighten the
master cylinder cover securely.
CAUTION:
yPlease drive your motorcycle on a dry road
surface slowly and operate front and rear brakes
in order to find out if there is any malfunction so
as to ensure the motorcycle is at optimum
condition and safe ride. .
Brake disk
Brake calipe
r
Brake pad wear
limit grooves
CAUTION:
yTO prevent chemical reaction, please do not use brake fluids other than those recommended.
yDo not fill above the upper limit when adding brake fluid and avoid dropping on painting or
plastic components to prevent damage.
Screw
Master
c
y
linder cove
r
Diaphragm
Uppe
r
Brake fluid

17
§THROTTLE VALVE HANDLE CLEARANCE ADJUSTMENT §
yCorrect clearance allows throttle vale handle to
rotate 2~6mm.
yLoosen the lock nut first, then turn the adjust nut
to adjust. Tighten the lock nut securely when
finished.
§INSPECTION AND MAINTENANCE OF BATTERY §
yThe motorcycle is equipped with a maintenance-free type battery, so it is unnecessary to check
and add electrolyte. Have your motorcycle checked by SYM Authorized Dealer or Franchised
Dealer should any abnormality is found.
﹙Cleaning of battery terminals﹚
yRemove the battery terminals and clean if there
are dirt and corrosion on them.
yBattery removal procedures are as follows:
Turn ignition switch to the “OFF” position, then
remove negative cable screw firstly and
disconnect the negative cable. Then, remove
positive cable screw and positive cable.
yThe motorcycle is equipped with a maintenance-free type battery, so it is unnecessary to check
and add electrolyte. Have your motorcycle checked by SYM Authorized Dealer or Franchised
Dealer should any abnormality is found.
Check Items:
1. Check throttle valve cable to see if it can be
moved smoothly from a closed position to a wide
open position.
2. Rotate steering handle from side to side to check
if the throttle valve cable is interfered.
3. Check to see if the throttle valve cable is
obstructed by other cables preventing it from
being operated smoothly.
2~6 mm
Lock nut
A
djust nut
CAUTION:
yClean the battery posts with warm water if the posts are eroded and have some white
powders on them.
yIf there is an obvious erosion on the terminals, disconnect the cables, and then clean the
erosion off with a steel brush or a piece of sandpaper.
yInstall battery cable after cleaning and apply a thin coat of grease on the terminals.
yInstall battery in reverse order of removal.
Negative
Positive
CAUTION:
yThis is a closed type battery. Never remove the caps.
yIn order to prevent electric leakage and self-discharge when the battery sits idle for long periods.
Remove battery from motorcycle, store it in well-ventilated and dimly lighted place after the
battery has been fully charged. Disconnect battery’s negative cable if the battery is still kept on
the motorcycle.
yIf the battery needs to be replaced, replace with a same closed-type battery (Maintenance-Free).

18
§TIRE INSPECTION §
yTires should be checked and inflated with the engine shut off.
yIf a tire’s ground contacting curve is abnormal, check it with an air pressure gauge and inflate it
to the specified pressure.
yTires pressure must be checked with an air pressure gauge when cold.
yVisual check tires for frontal and lateral side walls
for crack or damage.
yVisual check tires for any nails or small stones
wedged in the tread.
yCheck the “tread wear indicator” condition to see
if tread groove depth is insufficient.
yA tire with a wear bar showing is worn out and
should be replaced immediately.
§STEERING HANDLE FRONT SHOCK ABSORBERS INSPECTION §
yPerform this check with engine shut off and ignition
switch key removed.
yVisual check front shock absorbers for damage.
yOperate steering handle up and down, and check front
shock absorbers for noises due to bends.
yCheck the bolts and nuts of front shock absorbers with
wrenches for tightness.
yShake steering handle up & down, left & right, and front &
rear to check if it is loosen, has too much resistance and
pulls to one side.
yCheck steering handle if it is being pulled too tight by the
brake cables.
yTake your motorcycle to SYM Authorized Dealer or
Franchised Dealer for a check or adjustment if any
abnormal conditions are found.
PLEASE REFER TO SPECIFICATIONS FOR STANDARD TIRE PRESSURE
CAUTION:
yAbnormal tire pressure, wear, or crack is the most important cause that results in the loss
control of the steering handle and a punctured tire(s).
Tread wear
indicato
r
Crack and
dama
g
e
Foreign materials
(nails or small
stones)

19
§CHECKING AND CHANGING FUSES §
Turn off ignition switch, and check fuses if they are intact. Replace the blown fuse with a new one
having the same specified amperage rating (7A). Using a fuse of more than 7 amperes, a brass or iron
wire to replace a blown fuse is strictly prohibited to avoid damaging the electrical system and the
circuit.
yRemove the storage box, and you’ll find the fuse holder near battery.
yOpen the fuse box cover, and pull out the fuse. Check it for damage or broken.
yFuses must be firmly secured with wire connectors when replacing. Loose connections will result
in overhead and damage.
yUse only parts having the specified specification to replace electrical components such as light
bulbs. Using parts not having the specified specifications for replacement may cause the fuse
to blow and over-discharge the battery.
yAvoid spraying water directly on or around fuse box when washing the motorcycle.
yIf the new fuse burn out quickly again, please check the faulty reason before replace it again.
Take your motorcycle to your dealer for an inspection if a fuse is blown by unknown causes.
§CHECKING THE TURN SIGNAL LIGHTS AND HORN §
yTurn the ignition switch key to the “ON” position.
yTurn on the turn signal light switch, and make sure that the front & rear and left & right signal
lights flashes and also check if the warning buzzer sounds.
yCheck turn signal light covers if they are dirty, crack, or loosen.
yPress horn button to check if it works.
§CHECKING THE FRONT AND REAR LIGHTS §
yStart engine and turn on the head lamp switch. Check if head lamp and rear lamp come on.
yCheck the brightness and direction of front light by wall to see if it is correct.
yCheck the head lamp cover if it is dirty, crack, or loosen.
§CHECKING THE BRAKE LIGHT §
yTurn the ignition switch key to the “ON” position, hold the hand-braking levers for front and rear
wheels. Check if the brake lights come on.
yCheck the brake light cover if it is dirty, crack, or loosen.
CAUTION:
ySpecified specification bulbs should be used for turn signal lights. Otherwise, the normal
operation of turn signal lights will be affected.
yTurn on the turn signal light before turning or switching lane to warn driver of vehicles behind.
yTurn off the turn signal light immediately by pressing its button down after using. Otherwise,
the flashing of twin signal lights may confuse the drivers of vehicles behind.
CAUTION:
yUse only specified specification bulbs, do not use bulbs with different specifications to avoid
damaging electrical system, burning out bulbs, and discharging the battery.
yDo not modify or add other electrical components to prevent over load or short circuit which
may result in a fire and burn down the motorcycle in serious cases.
【INSTALLATION】
Press in from above
【REMOVE】
Wire Fuse connectors
