Symmons Dia 352TS Manual

1Symmons Industries, Inc. ■31 Brooks Drive ■Braintree, MA 02184 ■[phone] ■ Fax: [phone]
©2014 Symmons Industries, Inc. ■ www.symmons.com ■ [email protected] ■ ZV-3014 REV 0 01/15/2014
352TS
Dia™Diverter Tub Spout
Operation & Maintenance Manual
Model Number Specifications
352TS Dia Diverter Tub Spout 7" diverter tub spout made from metal and plastic
materials plated in standard polished chrome nish.
Modifications Compliance
-STN Satin nickel finish
Note: Append appropriate -sufx to model number.
-ASME A112.18.1/CSA B125.1
Warranty
Limited Lifetime - to the original end purchaser in
consumer installations.
5 Years - for commercial installations.
Refer to www.symmons.com/warranty for complete
warranty information.
Dimensions
Measurements
A Ø 2 1/2”, 64 mm
B 4 3/4”, 121 mm
C 7”, 178 mm
D 1/2”-14 NPT
Required for Installation
Teon Tape
Note: Dimensions are subject to change without notice.
CC
D
D
B
B
AA

2Symmons Industries, Inc. ■31 Brooks Drive ■Braintree, MA 02184 ■[phone] ■ Fax: [phone]
©2014 Symmons Industries, Inc. ■ www.symmons.com ■ [email protected] ■ ZV-3014 REV 0 01/15/2014
1) Install diverter tub spout onto 1/2" NPT stub out
pipe. Turn clockwise to secure.
1) Diverter lever in down position for tub spout
operation.
2) Diverter lever in up position for shower operation.
352TS
Dia™Diverter Tub Spout
Operation & Maintenance Manual
Installation Operation
1
2
Care and Cleaning
1) Clean nished trim area with a soft cloth using mild soap and water or a non-abrasive cleaner and then quickly rinse
with water.
