Symmons Carrington Trim Series Installation instructions

Carrington®
Model Numbers
Carrington Trim Series
Carrington Trim Series with TA-10 Flow Control Spindle &
T-12A Cap Assembly
Installation & Operation Instructions
TRIM ONLY
4400-TRM
Shower Valve Trim
4401-TRM
Shower Trim
4403-TRM
Hand Shower Trim
4405-TRM
Shower/Hand Shower Trim
4406-TRM
Tub/Shower/Hand Shower Trim
Compliance
• ASME A112.18.1/CSA B125.1
Limited Lifetime - to the original end purchaser in consumer/residential installations.
5 Years - for industrial/commercial installations.
Refer to www.symmons.com/warranty for complete warranty information.
Go to www.symmons.com/register to register your Symmons product.
TRIM, TA-10, T-12A
4400TRMTC
Shower Valve Trim
4401TRMTC
Shower Trim
4403TRMTC
Hand Shower Trim
4405TRMTC
Shower/Hand Shower Trim
4406TRMTC
Tub/Shower/Hand Shower Trim
Warranty
4400-TRM
4400TRMTC
4401-TRM
4401TRMTC
4405-TRM
4405TRMTC
4406-TRM
4406TRMTC
TA-10T-12A
4403-TRM
4403TRMTC

2
1. Recommended Tools
AA
D
D
J
J
I
I
N
NO
O
P
P
H
H
B
BC
C
F
F
M
M
K
K
Q
Q
R
R
L
L
U
U
V
V
E
E
T
T
S
S
G
G
Floor
Floor
FIGURE 2
Notes:
1) Valve body and piping not included and shown as reference only.
2) Plaster shield (p/n T-176) for dry wall, plaster or other type walls 1/2" or greater.
3) All dimensions measured from nominal rough-in (see U as reference).
4) Dimensions subject to change without notice.
Phillips Screwdriver
Adjustable Wrench Safety Glasses Thread Seal TapeDrill Allen Wrench (3mm)
FIGURE 1
2. Dimensions
Measurements
A Ø 2-5/8", 67 mm
B 9-1/4", 235 mm
C 1/2" NPT
D 2-1/8", 54 mm
E 1/2", 13 mm
FMale 1/2" IPS thread must be
recessed 1/4" from finished wall
G 6", 152 mm right or left
H 77", 1956 mm
I Ø 7-1/2", 191 mm
J Ø 4-5/8", 117 mm
K 8", 203 mm
L 2-7/8", 73 mm
M 4-3/8", 111 mm
N Ø 2-5/8", 67 mm
O
4400, 4401, 4403, 4405:
Ref. 42", 1067 mm
4406:
Ref. 32", 813 mm
P 12", 305 mm
Q 3-1/8", 79 mm
R 2-3/4", 70 mm
S 1/2" NPT
T 1/2", 13 mm
U(Rough in)
2" ± 1/2", 51 mm ± 13 mm
V 6-1/2", 165 mm

3
3. Parts Breakdown (Model Numbers Ending in TRMTC)
5. Installation - Adjust Packing Nut (Model Numbers Ending in TRMTC)
1) Turn hot and cold supplies on. Valve will not operate unless both hot and cold water supply pressures are on.
2) Place handle over flow control spindle.
3) Tighten packing nut for positive frictional resistance as handle is rotated from shut-o position across adjustment range.
6. Installation - Setting Limit Stop Screw (Model Numbers Ending in TRMTC)
1) Turn hot and cold supplies on. Valve will not operate unless both hot and cold water supply pressures are on.
2) Place handle on flow control spindle and open valve to maximum desired temperature.
3) Turn limit stop screw clockwise until it seats.
WARNING: Failure to adjust limit stop screw properly may result in serious scalding.
The temperature limit stop screw limits valve handle from being turned to maximum position resulting in excessive hot
water discharge temperatures.
4. Installation - Remove Test Cap (Model Numbers Ending in TRMTC)
1) Check for leaks around the valve assembly and all pipe
fittings.
Flow control spindle (TA-10) and cap assembly (T-12A) will
come factory assembled for all model numbers ending in
TRMTC. When ready to remove Test Cap and install trim,
follow the instructions below:
2) Remove test cap from valve (FIGURE 4.1).
3) If system is dirty, flush valve.
4) Thread flow control spindle and cap assembly into valve
body. Turn clockwise to secure to valve (FIGURE 4.2).
FIGURE 4.1 FIGURE 4.2
LIMIT STOP
SCREW
2
1
PACKING
NUT
FIGURE 3
Replacement Parts
Item Description Part Number
1 Cap Assy. T-12A
2 Flow Control Spindle TA-10
IMPORTANT: Model numbers ending in TRMTC
coordinate with Temptrol pressure balancing valves
ordered with Test Cap. The Test Cap is used to
allow pressurization of system. Do not remove
test cap from valve during wall construction,
installation of valve or pressurization of system.
WARNINGS:
1. Do not expose valve with test cap to heat
for longer than 2 minutes when soldering
copper tubing. Doing so may damage the
internal components of the valve and will
void the product warranty.
2. Ensure test cap is tightened securely after
soldering valve body.

4
Notes:
1) Append appropriate sux for premium finish.
2) Append appropriate flow rate to showerhead
or hand shower for low flow.
3) Apply a bead of silicone around the perimeter
of all shower trim installed flush to the
finished wall. Leave opening on bottom of
escutcheons for weep hole.
4) Apply plumber tape to all threaded
connections.
FIGURE 7
O
PQ
R
T
S
U
A
B
J
J
K
F
I
C
D
E
G
H
L
L
M
F
I
C
D
E
G
H
N
EF-109*
*Order in-line vacuum breaker (EF-109) for
hand shower systems without dual checks.
7. Parts Breakdown
Replacement Parts
Item Description Part Number
A Showerhead 442SH
B Shower Arm 304
C
D
E
F
Set Screw
Handle
Flange
O-ring
DF-28-LPO
G Lock Nut T-20-PL
H Washer 40B-PL
I Dome Cover DF-11
J
K
Mounting Screws
Diverter Escutcheon DF-14
N Shower Plate 7.5-ETCH
O Hand Shower 442W
P
Q
R
Wall Cradle
Screws
Mounting Plate
EF-106
S Wall Elbow EF-105
T 60" Hose RTS-045
U Tub Spout 063

5
8. Installation - Shower Valve Trim
FIGURE 8.1 FIGURE 8.2
FIGURE 8.3
2
1
9. Installation - Diverter Valve Trim
1) Attach shower arm to stub out pipe. Turn clockwise to
tighten (FIGURE 10.1).
2) Install showerhead to shower arm. Turn clockwise to
tighten (FIGURE 10.2).
3) Install tub spout to stub out pipe. Turn clockwise to
tighten (FIGURE 10.3).
FIGURE 10.1 FIGURE 10.2
FIGURE 10.3
10. Installation - Showerhead & Tub Spout
1) Secure escutcheon and shower plate to Temptrol
pressure balancing valve using mounting screws
(FIGURE 8.1).
2) Install dome cover and washer to valve. Secure with
lock nut by by turning clockwise (FIGURE 8.2).
3) Place o-ring in groove under spindle broach. Install
flange and handle to shower valve. Secure with screw
(FIGURE 8.3).
FIGURE 9.1 FIGURE 9.2
FIGURE 9.4
2
1
2) Install dome cover and washer to valve. Secure with
lock nut by by turning clockwise (FIGURE 9.2).
1) Secure escutcheon to Symmons diverter valve using
mounting screws (FIGURE 9.1).
3) Place o-ring in groove under spindle broach. Install
flange and handle to diverter valve. Secure with screw
(FIGURE 8.3).

6
3) Install wall elbow to stub out pipe. Tighten set screw to
secure (FIGURE 11.3).
4) Attach small end of hand shower hose to wall elbow.
Turn clockwise to tighten (FIGURE 11.4).
1
3
FIGURE 11.1
2
4
TILE ANCHOR
DRY WALL ANCHOR
ANCHOR TOOL
11. Installation - Slide Bar Assembly
5) Attach large end of hand shower hose to hand shower
wand. Turn clockwise to tighten (FIGURE 11.5).
FIGURE 11.3 FIGURE 11.4
FIGURE 11.5
1) Place mounting plate in position. Mark and drill 3/16"
holes for tile anchors, 5/16" holes for drywall anchors.
Install anchors (FIGURE 11.1).
Note: For dry wall 1/2" thick or less, insert anchor tool
into drywall anchor to secure behind wall prior to
installing wall cradle.
2) Remove cover of hand shower cradle. Install cradle
and mounting plate. Secure with three screws. Replace
cover on hand shower cradle (FIGURE 11.2).
3
1
2
4
FIGURE 11.2

7
12. Operation (Temperature Control)
1) Turn shower handle counter-clockwise
approximately 1/4 turn to put valve in
cold position (FIGURE 12.1).
2) Turn shower handle counter- clockwise
approximately 1/2 turn to put valve in
warm position (FIGURE 12.2).
3) Turn shower handle counter- clockwise
approximately 3/4 turn to put valve in
hot position (FIGURE 12.3).
FIGURE 12.1 FIGURE 12.2 FIGURE 12.3
13. Operation (Dual Outlet Diverter Control)
1) Cartridge is factory set to divert to
function 1 (FIGURE 13.1).
2) Turn handle to position 2 to divert to
function 2 (FIGURE 13.2).
3) Turn handle to position 3 to share
functions 1 and 2 (FIGURE 13.3).
FIGURE 13.1 FIGURE 13.2 FIGURE 13.3
14. Operation (Triple Outlet Diverter Control)
1) Cartridge is factory set to divert to
function 1 (FIGURE 14.1).
2) Turn handle to position 2 to divert to
function 2 (FIGURE 14.2).
3) Turn handle to position 3 to divert to
function 3 (FIGURE 14.3).
FIGURE 14.1 FIGURE 14.2 FIGURE 14.3
4) Turn handle to position 4 to share
functions 2 and 3 (FIGURE 14.4).
5) Turn handle to position 5 to share
functions 1 and 3 (FIGURE 14.5).
6) Turn handle to position 6 to share
functions 1 and 2 (FIGURE 14.6).
FIGURE 14.4 FIGURE 14.5 FIGURE 14.6
Note: Additional handle positions for
same output are illustrated.

Symmons Industries, Inc. ■31 Brooks Drive ■Braintree, MA 02184 ■Phone: [phone] ■ Fax: [phone]
Copyright © 2019 Symmons Industries, Inc. ■symmons.com ■[email protected] ■ZV-3278 REV A ■ 062419
WARNING: This product can expose you to chemicals including lead, which is known to the state of California to cause cancer, birth
defects, or other reproductive harm. For more information, go to www.P65Warnings.ca.gov.
15. Troubleshooting Chart
Problem Cause Solution
Finish is spotting. Elements in water supply may cause
water staining on nish.
Clean nished trim area with a soft
cloth using mild soap and water or a
non-abrasive cleaner and then quickly
rinse with water.
