Symmons Origins Trim Series Installation instructions

Origins®
Model Numbers
Origins Trim Series
Origins Trim Series with TA-10 Flow Control Spindle & T-12A Cap Assembly
Installation & Operation Instructions
TRIM ONLY
9600-P-TRM
Shower Valve Trim
9600-PLR-TRM
Shower Valve Trim
9601-P-TRM
Shower Trim
9601-PLR-TRM
Shower Trim
9602-P-TRM
Tub/Shower Trim
9602-PLR-TRM
Tub/Shower Trim
9603-P-TRM
Hand Shower Trim
9603-PLR-TRM
Hand Shower Trim
9604-P-TRM
Tub/Hand Shower Trim
9604-PLR-TRM
Tub/Hand Shower Trim
9605-P-TRM
Shower/Hand Shower Trim
9605-PLR-TRM
Shower/Hand Shower Trim
9606-P-TRM
Tub/Shower/Hand Shower Trim
9606-PLR-TRM
Tub/Shower/Hand Shower Trim
Compliance
• ASME A112.18.1/CSA B125.1
Limited Lifetime - to the original end purchaser in
consumer/residential installations.
5 Years - for industrial/commercial installations.
Refer to www.symmons.com/warranty for complete
warranty information.
Go to www.symmons.com/register to register your
Symmons product.
TRIM, TA-10, T-12A
9600PTRMTC
Shower Valve Trim
9600PLRTRMTC
Shower Valve Trim
9601PTRMTC
Shower Trim
9601PLRTRMTC
Shower Trim
9602PTRMTC
Tub/Shower Trim
9602PLRTRMTC
Tub/Shower Trim
9603PTRMTC
Hand Shower Trim
9603PLRTRMTC
Hand Shower Trim
9604PTRMTC
Tub/Hand Shower Trim
9604PLRTRMTC
Tub/Hand Shower Trim
9605PTRMTC
Shower/Hand Shower Trim
9605PLRTRMTC
Shower/Hand Shower Trim
9606PTRMTC
Tub/Shower/Hand Shower Trim
9606PLRTRMTC
Tub/Shower/Hand Shower Trim
Warranty
9600-P-TRM
9600PTRMTC
9602-P-TRM
9602PTRMTC
TA-10T-12A
9600-PLR-TRM
9601PLRTRMTC
9601-P-TRM
9601PTRMTC
9601-PLR-TRM
9601PLRTRMTC
9602-PLR-TRM
9602PLRTRMTC
9603-P-TRM
9603PTRMTC
9603-PLR-TRM
9603PLRTRMTC
9604-P-TRM
9604PTRMTC
9604-PLR-TRM
9604PLRTRMTC
9605-P-TRM
9605PTRMTC
9605-PLR-TRM
9605PLRTRMTC
9606-P-TRM
9606PTRMTC
9606-PLR-TRM
9606PLRTRMTC

2
1. Recommended Tools
FLOORFLOOR
KK
BB
EE
GG
FF
ZZ
XX
UU VV
II
QQ
TT
RR
AA NN
OO
PP
CC
LL
MM
SS
WOOD
BLOCKING
WOOD
BLOCKING
HH
JJ
DD
FIGURE 2
WW YY
Measurements
A 6-3/8", 162 mm
B 3", 76 mm
C
Diverter Valve Hole Size
Min. Ø 3", 76 mm
Max. Ø 3-1/4", 83 mm
D 3 1/2", 89 mm
E
Male 1/2" NPT fitting must
protrude 3/8" from
finished wall
FRef. 10", 254 mm
G Ref. 77", 1956 mm
H
Shower Valve Hole Size
Min. Ø 3", 76 mm
Max. Ø 4", 102 mm
I 2-7/8", 73 mm
JRough-in
2-3/8" ± 1/2", 60 mm ± 13 mm
K
9600, 9601, 9603, 9605:
Ref. 42", 1067 mm
9602, 9604, 9606:
Ref. 32", 813 mm
L
Male 1/2" NPT fitting must
protrude 4" from
finished wall
M5-1/2", 140 mm
N Ø 2-1/2", 64 mm
O Ø 2-3/4", 70 mm
P Ø 4-1/4", 108 mm
Q Ø 2-1/2", 64 mm
R Ø 5-3/4", 146 mm
S Ø 2-1/2", 64 mm
TØ 3-1/8", 79 mm
U 36", 914 mm
V39", 991 mm
W2-7/8", 73 mm
X2-1/8", 54 mm
Y3-5/8", 92 mm
Z3-3/8", 86 mm
Notes:
1) Valve body and piping not included and shown as reference only.
2) Plaster shield (p/n T-176) for dry wall, plaster or other type walls 1/2" or greater.
3) All dimensions measured from nominal rough-in (see J as reference).
4) Dimensions subject to change without notice.
Phillips Screwdriver
Adjustable Wrench Safety Glasses Thread Seal TapeDrill Allen Wrench (3mm)
FIGURE 1
2. Dimensions

3
5. Installation - Adjust Packing Nut (Model Numbers Ending in TRMTC)
1) Turn hot and cold supplies on. Valve will not operate unless both hot and cold water supply pressures are on.
2) Place handle over flow control spindle.
3) Tighten packing nut for positive frictional resistance as handle is rotated from shut-o position across adjustment range.
6. Installation - Setting Limit Stop Screw (Model Numbers Ending in TRMTC)
1) Turn hot and cold supplies on. Valve will not operate unless both hot and cold water supply pressures are on.
2) Place handle on flow control spindle and open valve to maximum desired temperature.
3) Turn limit stop screw clockwise until it seats.
WARNING: Failure to adjust limit stop screw properly may result in serious scalding.
The temperature limit stop screw limits valve handle from being turned to maximum position resulting in excessive hot
water discharge temperatures.
3. Parts Breakdown (Model Numbers Ending in TRMTC)
4. Installation - Remove Test Cap (Model Numbers Ending in TRMTC)
1) Check for leaks around the valve assembly and all pipe
fittings.
Flow control spindle (TA-10) and cap assembly (T-12A) will
come factory assembled for all model numbers ending in
TRMTC. When ready to remove Test Cap and install trim,
follow the instructions below:
2) Remove test cap from valve (FIGURE 4.1).
3) If system is dirty, flush valve.
4) Thread flow control spindle and cap assembly into valve
body. Turn clockwise to secure to valve (FIGURE 4.2).
FIGURE 4.1 FIGURE 4.2
LIMIT STOP
SCREW
2
1
PACKING
NUT
FIGURE 3
Replacement Parts
Item Description Part Number
1 Cap Assy. T-12A
2 Flow Control Spindle TA-10
IMPORTANT: Model numbers ending in TRMTC
coordinate with Temptrol pressure balancing valves
ordered with Test Cap. The Test Cap is used to
allow pressurization of system. Do not remove
test cap from valve during wall construction,
installation of valve or pressurization of system.
WARNINGS:
1. Test cap rated for pressure testing up to 200
psi maximum. DO NOT exceed 200 psi while
pressure testing valve body.
2. Do not expose valve with test cap to heat
for longer than 2 minutes when soldering
copper tubing. Doing so may damage the
internal components of the valve and will
void the product warranty.
3. Ensure test cap is re-torqued to 30 lb-ft after
soldering valve body.

4
Replacement Parts
Item Description Part Number
A Showerhead 4-141
B
C
Shower Arm
Flange 300S
D 'PLR' Handle RTS-063
E Dome Cover T-19
F
G
Diverter Escutcheon
Screws 96-66-DIV-ESC
H 'P' Handle RTS-061
I
J
Shower Escutcheon
Screws
Standard (P):
9600-P-ESC
Brass (P):
9600-P-B-ESC
Standard (PLR):
9600-PLR-ESC
Brass (PLR):
9600-PLR-B-ESC
K
K1
Tub Spout
Diverter Tub Spout
060
054
L Hand Shower ADACHS
M Wall Elbow 40A
N Slide Mechanism FP-SM6
O 60" Hose RTS-045
Notes:
1) Append appropriate sux for premium finish.
2) Append appropriate flow rate to showerhead
or hand shower for low flow.
3) Apply a bead of silicone around the perimeter
of all shower trim installed flush to the
finished wall. Leave opening on bottom of
escutcheons for weep hole.
4) Apply plumber tape to all threaded
connections.
A
B
C
FIGURE 7
N
D
E
F
FJ
H
E
I
I
KK1
D
O
L
M
G
EF-109*
*Order in-line vacuum breaker (EF-109) for
hand shower systems without dual checks.
7. Parts Breakdown

5
8. Installation - Shower Valve Trim
1) Secure large shower escutcheon to Temptrol
pressure balancing valve using mounting screws
(FIGURE 8.1).
2) Install dome cover by turning clockwise (FIGURE 8.2).
3) Install 'P' handle to shower valve. Secure with set
screw. Install plug button (FIGURE 8.3).
4) Install 'PLR' handle to shower valve. Secure with set
screw (FIGURE 8.4).
FIGURE 8.1 FIGURE 8.2
FIGURE 8.3 FIGURE 8.4
9. Installation - Diverter Valve Trim
2) Install dome cover by turning clockwise (FIGURE 9.2).
1) Secure small diverter escutcheon to Symmons diverter
valve using mounting screws (FIGURE 9.1).
FIGURE 9.1 FIGURE 9.2
3) Install handle to diverter valve. Secure with set screw
(FIGURE 9.3).
FIGURE 9.3
1) Attach arm and flange to shower pipe. Turn clockwise
to tighten (FIGURE 10.1).
2) Install showerhead to shower arm. Turn clockwise to
tighten (FIGURE 10.2).
3) Install tub spout to stub out pipe. Turn clockwise to
tighten (FIGURE 10.3).
FIGURE 10.1 FIGURE 10.2
FIGURE 10.3
10. Installation - Showerhead & Tub Spout

6
1) Remove slide bar ends from slide bar flanges. Using
flanges as a guide, drill 1/8" pilot holes into studs or
wood blocking. With slide bar in position, secure to
wall using screws. Attach slide bar ends to bar flanges
(FIGURE 11.1).
2) Remove screw cap from slide mechanism (FIGURE 11.2).
6) Press tabs on wall elbow flange. Install wall elbow to
pipe fitting. Turn clockwise to secure (FIGURE 11.6).
7) Attach small end of hand shower hose to wall elbow.
Turn clockwise to tighten (FIGURE 11.7).
3
FIGURE 11.1
1
2
4
11. Installation - Slide Bar Assembly
8) Attach large end of hand shower hose to hand shower
wand. Turn clockwise to tighten (FIGURE 11.8).
FIGURE 11.2
FIGURE 11.3
FIGURE 11.4
5) Install slide mechanism components to slide bar
following STEPS 11.2 - 11.4 in reverse. Flat edge on (N1)
and (N2) must be aligned. Arrows on (N1) and (N3)
identify bottom side (FIGURE 11.5).
Note:
Adjust screw cap for ease of movement of slide
assembly.
1
FIGURE 11.6
2
FIGURE 11.7
FIGURE 11.8
FIGURE 11.5
SLIDE
SLIDE
LOCK
N1
N2
N3
3) Remove wand holder from slide mechanism
(FIGURE 11.3).
4) Remove lever handle from slide mechanism
(FIGURE 11.4).

7
12. Operation (Temperature Control)
1) Turn shower handle counter-clockwise
approximately 1/4 turn to put valve in
cold position (FIGURE 12.1).
2) Turn shower handle counter- clockwise
approximately 1/2 turn to put valve in
warm position (FIGURE 12.2).
3) Turn shower handle counter- clockwise
approximately 3/4 turn to put valve in
hot position (FIGURE 12.3).
FIGURE 12.1 FIGURE 12.2 FIGURE 12.3
13. Operation (Dual Outlet Diverter Control)
1) Cartridge is factory set to divert to
function 1 (FIGURE 13.1).
2) Turn handle to position 2 to divert to
function 2 (FIGURE 13.2).
3) Turn handle to position 3 to share
functions 1 and 2 (FIGURE 13.3).
FIGURE 13.1 FIGURE 13.2 FIGURE 13.3
14. Operation (Triple Outlet Diverter Control)
1) Cartridge is factory set to divert to
function 1 (FIGURE 14.1).
2) Turn handle to position 2 to divert to
function 2 (FIGURE 14.2).
3) Turn handle to position 3 to divert to
function 3 (FIGURE 14.3).
FIGURE 14.1 FIGURE 14.2 FIGURE 14.3
4) Turn handle to position 4 to share
functions 2 and 3 (FIGURE 14.4).
5) Turn handle to position 5 to share
functions 1 and 3 (FIGURE 14.5).
6) Turn handle to position 6 to share
functions 1 and 2 (FIGURE 14.6).
FIGURE 14.4 FIGURE 14.5 FIGURE 14.6
Note: Additional handle positions for
same output are illustrated.

Symmons Industries, Inc. ■31 Brooks Drive ■Braintree, MA 02184 ■Phone: [phone] ■ Fax: [phone]
Copyright © 2020 Symmons Industries, Inc. ■symmons.com ■[email protected] ■ZV-3295 REV A ■ 031920
WARNING: This product can expose you to chemicals including lead, which is known to the state of California to cause cancer, birth
defects, or other reproductive harm. For more information, go to www.P65Warnings.ca.gov.
15. Troubleshooting Chart
Problem Cause Solution
Finish is spotting. Elements in water supply may cause
water staining on nish.
Clean nished trim area with a soft
cloth using mild soap and water or a
non-abrasive cleaner and then quickly
rinse with water.
