syslogic TFT/HMIxxxIS6-1A Series User manual

© 2010 Syslogic Datentechnik AG www.syslogic.com Page 1 of 4
Version 1.0 |September 2010 All rights reserved
Product specifications subject to change without notice. |All data is for information purposes only and not guaranteed for legal purposes. Information in this data sheet has been carefully checked and is believed to be accurate. However, no responsibility is assumed for inaccuracies.
Document order code: DOC/HMIxxxISx-INST
Deutsch
Montage Anweisung
Infrarot Touch Panel Display
TFT/HMIxxxIS6-1A
Sicherheitshinweise
Allgemeine Hinweise
Zur Gewährleistung eines sicheren Betriebes darf das Gerät
nur nach den Angaben in der Betriebsanleitung betrieben
werden. Bei der Verwendung sind zusätzlich die für den
jeweiligen Anwendungsfall erforderlichen Rechts- und Sicher-
heitsvorschriften zu beachten. Sinngemäss gilt dies auch bei
Verwendung von Zubehör.
Bestimmungsgemässe Verwendung
Das Gerät ist für den industriellen, stationären Einsatz konzi-
piert. Jeder darüber hinaus gehende Gebrauch gilt als nicht
bestimmungsgemäss.
Qualifiziertes Personal
Die Displays dürfen nur von qualifiziertem Personal instal-
liert, eingesetzt und bedient werden unter Einhaltung der
technischen Bestimmungen. Qualifiziertes Personal ist defi-
niert als Personen, die im Umgang mit diesem Gerät vertraut
sind und über die benötigten Ausbildungen und Erfahrungen
für den Umgang mit dem Gerät verfügen.
Restgefahren
Die Displays entsprechen dem Stand der Technik und sind
betriebssicher. Von den Geräten können Restgefahren aus-
gehen, wenn sie von ungeschultem Personal unsachgemäss
eingesetzt und bedient werden.
Benutzerdokumentation
Die Benutzerdokumentation des HMI–Panel erhalten Sie auf
Anfrage oder als Download unter www.syslogic.com
(Document order code: DOC/HMIxxxISx-xxE und
DOC/COMPACT6-SLE)
English
Installation guide
Infrared touch panel display
TFT/HMIxxxIS6-1A
Safety information
General information
In order to ensure safe operation, the device may only be
operated in accordance to the specifications stated in this
operation manual. Furthermore, all legal and safety regula-
tions concerning this specific application should be observed.
This also applies to the use of accessories.
Correct use to the independent purpose
The device is designed for industrial, stationary use. All other
forms of usage do not comply with the intended purpose.
Qualified staff
The Displays may only be installed, connected, set-up and
operated by qualified staff and in compliance with technical
specifications. Qualified staff is defined as persons, who are
familiar with set-up, mounting, start-up and operation of this
device and who posses a recognized degree or certificate of
appropriate professional training.
Remaining hazards
These Displays employ state-of-the-art technology and safe
operate. However, if they are installed and operated by
unqualified staff, an element of risk remains.
User documentation
You will get a detailed user documentation on request or as
download. Please visit www.syslogic.com
(Document order code: DOC/HMIxxxISx-xxE and
DOC/COMPACT6-SLE)
© 2010 Syslogic Datentechnik AG www.syslogic.com Page 2 of 4
Version 1.0 |September 2010 All rights reserved
Product specifications subject to change without notice. |All data is for information purposes only and not guaranteed for legal purposes. Information in this data sheet has been carefully checked and is believed to be accurate. However, no responsibility is assumed for inaccuracies.
Document order code: DOC/HMIxxxISx-INST
Lieferumfang
Verpackung
Standard Zubehör
HMI Panel
Konterrahmen
10.4", 12.1", 15" Versionen 19" Version
1x HMI-Panel 1x HMI-Panel
1x Dichtung 1x Dichtung
1x Power Supply Stecker 1x Power Supply Stecker
4x Befestigungsmuttern 8x Befestigungsmuttern
1x Konterrahmen 1x Konterrahmen
Installationshinweise und Inbetriebnahme
Montage
Das HMI-Panel von vorne in den Ausschnitt der Fronttafel1.
schieben.
Die Frontdichtung muss zwischen Frontplatte und Front-2.
tafel flach und rundum gleichmässig aufliegen.
Das Gerät im Ausschnitt zentrieren.3.
Das Gerät mit dem mitgelieferten Befestigungsrahmen4.
von der Rückseite her gleichmässig mit den 4 oder 8
Sicherungsmuttern festschrauben (maximal bis der Front-
rahmen umlaufend an der Fronttafel anliegt.)
Achten Sie auf einwandfreien Sitz der Dichtungen an der•
Fronttafel. Bei Geräten mit Runddichtung müssen die bei-
den Enden der Dichtung an der Geräteunterseite bündig
montiert werden.
Vermeiden Sie Drehmomente grösser 0.5Nm, das Gerät•
könnte sonst beschädigt werden.
Die Fronttafel darf eine maximale Dicke von 5mm nicht•
überschreiten.
Zur Vermeidung einer Überhitzung des Gerätes während
dem Betrieb ist folgendes zu beachten:
Allfällige Kühlschlitze müssen frei sein, um die System-•
kühlung zu gewährleisten
Vermeiden Sie die direkte Sonneneinstrahlung auf die•
Front
Der Neigungswinkel zum senkrechten Einbau darf max.•
± 35° betragen.
Included in delivery
Packing
Standard accessory
HMI Panel
Fixing frame
10.4", 12.1", 15" Versions 19" Version
1x HMI-Panel 1x HMI-Panel
1x Seal 1x Seal
1x Power supply connector 1x Power supply connector
4x Securing nuts 8x Securing nuts
1x Fixing frame 1x Fixing frame
Installation instructions and operation
Mounting
Push the HMI-Panel from the front into the cutout of the1.
front panel.
The front seal must be level and evenly positioned be-2.
tween the front plate and the front panel.
Centring the device in the cutout3.
Secure the device from the rear with the supplied fixing4.
frame. For this use 4 or 8 securing nuts which should be
tightened evenly from the rear until the front frame is
flush with the front panel all round.
Ensure that the seal is fitted correctly on the front panel.•
For devices with a round seal the two ends must be at the
lower side of the device and should fit together without a
gap.
Avoid tightening torques of greater than 0.5Nm as this•
could otherwise damage the device.
The thickness of the front panel must not exceed 5mm.•
The following must be ensured in order to prevent the
device from overheating during operation:
The cooling slots must always be free in order to ensure•
the proper cooling of the system.
Avoid the exposure of the flat screen to direct sunlight.•
The mounting angle must not exceed ± 35° from the•
vertical, if these conditions cannot be met, the mounting
of an external fan is recommended.
© 2010 Syslogic Datentechnik AG www.syslogic.com Page 3 of 4
Version 1.0 |September 2010 All rights reserved
Product specifications subject to change without notice. |All data is for information purposes only and not guaranteed for legal purposes. Information in this data sheet has been carefully checked and is believed to be accurate. However, no responsibility is assumed for inaccuracies.
Document order code: DOC/HMIxxxISx-INST
Schnittstellen
An nachfolgende Schnittstellen angeschlossene Kabellei-•
tungen sind von niederspannungsführenden Leitungen
getrennt zu verlegen.
Nr. Anschluss Beschreibung
1 Power Supply User Documentation
DOC/COMPACT6-SLE
2 Diagnose LED
3 COM1 / COM2
4 Reset
5 ETH 1 / ETH 2
6 USB 0 - 3
Power Supply Anschluss 24VDC
Das HMI-Panel ist ein Gerät der Schutzklasse 3. Die System-
versorgung hat mit Sicherheitskleinspannung SELV 24VDC
(safety extra-low voltage) zu erfolgen. Die Versorgung ist
nicht galvanisch getrennt.
Pin Signal Beschreibung
1 24VDC 24VDC Power Supply
2 24VDC 24VDC AUX
3 GND
3 PF Power Fail
Frontplatten Ausschnitt / Abmessungen
Interfaces
Cables connected to the following interfaces must be laid•
separately from the low-voltage cables.
No.. Connection Description
1 Power Supply User Documentation
DOC/COMPACT6-SLE
2 Diagnose LED
3 COM1 / COM2
4 Reset
5 ETH 1 / ETH 2
6 USB 0 - 3
Power supply connection 24VDC
The HMI-Panel device belongs to protection class 3. The
system power supply must be provided with a 24VDC SELV
voltage. The power supply is not isolated.
Pin Signal Description
1 24VDC 24VDC Power Supply
2 24VDC 24VDC AUX
3 GND
3 PF Power Fail
Front cutout / dimensions
1 2 3 3 4 5 5 6 6
Ausschnitt [mm]1Abmessungen [mm]
Produkt A B BxHxT
TFT/HMI104IS 329 +0/-1 238 +0/-1 345 x 260 x 64 (10.4 Zoll)
TFT/HMI121IS 344 +0/-1 262 +0/-1 361 x 279 x 63 (12.1 Zoll)
TFT/HMI150IS 410 +0/-1 315 +0/-1 427 x 332 x 63 (15 Zoll)
TFT/HMI190IS 495 +0/-1 403 +0/-1 512 x 420 x 64 (19 Zoll)
1Details gemäss Benutzerdokumentation



Cut out [mm]1Dimesions [mm]
Product A B WxHxD
TFT/HMI104IS 329 +0/-1 238 +0/-1 345 x 260 x 64 (10.4 inch)
TFT/HMI121IS 344 +0/-1 262 +0/-1 361 x 279 x 63 (12.1 inch)
TFT/HMI150IS 410 +0/-1 315 +0/-1 427 x 332 x 63 (15 inch)
TFT/HMI190IS 495 +0/-1 403 +0/-1 512 x 420 x 64 (19 inch)
1for details see user documentation



© 2010 Syslogic Datentechnik AG www.syslogic.com Page 4 of 4
Version 1.0 |September 2010 All rights reserved
Product specifications subject to change without notice. |All data is for information purposes only and not guaranteed for legal purposes. Information in this data sheet has been carefully checked and is believed to be accurate. However, no responsibility is assumed for inaccuracies.
Document order code: DOC/HMIxxxISx-INST
Entsorgung
Nicht mehr benutzte HMI-Panel müssen ordnungsge-•
mäss entsorgt oder zur Entsorgung zum Hersteller zurück
gesandt werden. (weitere Informationen finden Sie in der
Benutzerdokumentation)
Nicht mehr benötigte Verpackungen müssen ordnungs-•
gemäss entsorgt oder zur Entsorgung an den Hersteller
oder Vertrieb retourniert werden. Die Verpackung besteht
aus folgenden Materialien:
Schachtel aus Karton, Transportschutz und Kunststoffbeu-
tel aus TFL Schaumstoff (Polyethylen).
Kontakt und technischer Support
Syslogic Datentechnik AG, Baden-Dättwil, Schweiz
Tel +41 56 200 90 40 |Fax +41 56 200 90 50
[email protected] |[email protected]
Disposal
HMI-Panel devices that are no longer used must be fairly•
disposed or returned to the manufacturer for disposal.
(Further information you will find in the device user
documentation)
Packaging not needed anymore must be fairly disposed•
or returned to the manufacturer or distributor for
disposal.
The wrapping contains the following materials:
Cardboard box, transportation protection and bag made
of TFL-foam (Polyethylene).
Contact and technical support
Syslogic Datentechnik AG, Baden-Dättwil, Switzerland
Phone +41 56 200 90 40 |Fax +41 56 200 90 50
[email protected] |[email protected]

Other syslogic Touch Panel manuals

syslogic IPC/RSL8-X E Series Operator's manual

syslogic

syslogic IPC/RSL8-X E Series Operator's manual

syslogic C Series Operator's manual

syslogic

syslogic C Series Operator's manual

syslogic TFT/HB101PR8 Series Operator's manual

syslogic

syslogic TFT/HB101PR8 Series Operator's manual

syslogic TFT/PB101PU Series Operator's manual

syslogic

syslogic TFT/PB101PU Series Operator's manual

syslogic TFT/HB PU8 Series Operator's manual

syslogic

syslogic TFT/HB PU8 Series Operator's manual

syslogic TFT/HB PU71 16 Series Operator's manual

syslogic

syslogic TFT/HB PU71 16 Series Operator's manual

syslogic TFT/HB101PU Series Operator's manual

syslogic

syslogic TFT/HB101PU Series Operator's manual

syslogic TFT/PB101PU-C Operator's manual

syslogic

syslogic TFT/PB101PU-C Operator's manual

syslogic TFT/PANxxxIS-F1 Series User manual

syslogic

syslogic TFT/PANxxxIS-F1 Series User manual

Popular Touch Panel manuals by other brands

Protech Systems SP-S214 Quick reference guide

Protech Systems

Protech Systems SP-S214 Quick reference guide

ABB PP882 Hardware and installation guide

ABB

ABB PP882 Hardware and installation guide

Interlogix 60-597 installation instructions

Interlogix

Interlogix 60-597 installation instructions

Siemens SIMATIC WinCC V11 System manual

Siemens

Siemens SIMATIC WinCC V11 System manual

Chipsee CS19108F215P-C111 user manual

Chipsee

Chipsee CS19108F215P-C111 user manual

PAT IK350/1272 user manual

PAT

PAT IK350/1272 user manual

Winmate W10IB3S-MRH2 user manual

Winmate

Winmate W10IB3S-MRH2 user manual

Smarttech SMART Board 7000 series manual

Smarttech

Smarttech SMART Board 7000 series manual

YING ELECTRONICS TOUCHWIN TP Series user manual

YING ELECTRONICS

YING ELECTRONICS TOUCHWIN TP Series user manual

Tormach 35575 Technical document

Tormach

Tormach 35575 Technical document

Gecko in.k300 Quick reference card

Gecko

Gecko in.k300 Quick reference card

Cincoze CO-100/P2002 Series user manual

Cincoze

Cincoze CO-100/P2002 Series user manual

Advantech PPC-112W manual

Advantech

Advantech PPC-112W manual

PT PT200M Operator's manual

PT

PT PT200M Operator's manual

Extron electronics TouchLink TLP Pro 520M user guide

Extron electronics

Extron electronics TouchLink TLP Pro 520M user guide

Avery Weigh-Tronix E1010 manual

Avery Weigh-Tronix

Avery Weigh-Tronix E1010 manual

GE druck dpi 104 user manual

GE

GE druck dpi 104 user manual

IOT NEXCOM APPC 1240T user manual

IOT

IOT NEXCOM APPC 1240T user manual

manuals.online logo
manuals.online logoBrands
  • About & Mission
  • Contact us
  • Privacy Policy
  • Terms and Conditions

Copyright 2025 Manuals.Online. All Rights Reserved.
