DVG-V-EC / DVG-H-EC
F200, F300, F400 EN 12101-3 (400˚C, 120 Min.)
DVG-V-EC/F400 DVG-H-EC/F400
Instructions for transport, installation, commissioning and
maintenance of roof fans DVG-EC
Appendixes:
1 - Mounting of service switch/Mounting of vertical outlets for DVG-V
3, 4 – Accessories – mounting
5 – Bridges in controller and wiring schemes
Controller “Compacto” – instructions
Controller “Invento” - instructions
Page 3
Systemair
d.o.o.
– Špelina ulica 2, SI-2000 Maribor
Tel.: [phone] – Fax: [phone]
[email protected] – www.systemair.com

- 2 -
Index
Page

1.0
APPLICATION
3

2.0
TECHNICAL DESCRIPTION
3

3.0
TRANSPORT
AND STORAGE
3
3.1 Transport
3
3.2 Storage
4

4.0
INSTRUCTIONS FOR INSTALLATION
4
4.1 Inspection before installation
4
4.2 Safety instructions for installation, commissioning,
maintenance and controlling
4
4.3 Installation of the fan
4
4.4 Instructions for installation
5

5.0
COMMISSIONING
6

6.0
APPR
OVAL
6

7.0
MAINTENANCE AND PERIODIC CONTROL
7

8.0
SYSTEM MALFUNCTIONS DURING OPERATION
7

9.0
G
UA
RANT
E
E
8
Attachment
:
•
Test protocoll
•Instruction of electric motor
•EC declaration of conformity

- 3 -
1.0 APPLICATION
Smoke extract roof fans are designed for use in powered smoke and heat exhaust
ventilating systems in the event of fire, and ventilating in normal conditions. Ventilated areas
and emergency exits contribute to easier evacuation of people and equipment in the event
of fire, and to faster and more efficient fire extinguishing; they protect the building structure
and equipment against excessive temperatures and decrease fire escalation to the
surrounding areas.
•Fire resistance of fans: 400C, 120 min;
•installation on roofs over heated buildings;
•horizontal outlet (DVG-H) or vertical outlet (DVG-V);
•EC-motor outside air stream;
•daily ventilation of medium with temperature from -20 up to 120°C, supposing
continuously operation, up to 80°C in standstill;
•the fans DVG must not be mounted in explosion hazardous zones;
•0-10V speed control input;
•Modbus controllable;
•Fire mode to disable motor and controller protection in case of fire.
Not intended or unprofessional use can be dangerous for l
ife of user or
third person. It can lead to damage of the fan. The risk for this carries the
operator alone.
2.0 TECHNICAL DESCRIPTION
Casing
Electric motor with impeller is fastened to a sturdy supporting construction. The casing
cover is made of see water resistant aluminium.
Impeller
Impeller of DVG fan is manufactured from galvanized steel. It is fastened with taper bush
and secured screw directly on to the motor shaft. Dynamically balanced in accordance with
ISO 1940 T1, class G6,3.
Electric motor
Fans are serial equipped with EC (electronically commutated) high efficiency electric motors
for single-phase current 200 to 265V, 50/60Hz Hz (sizes 355 and 450), rsp. 342 to 506V,
50/60Hz Hz (sizes 560, 630, 800). Protection class IP 54. Insulation class F.
Max. RPM: 1500 RPM, rsp. 900 RPM at DVG 800.
Detailed description of controller connection and control possibilities please see in attached
instructions of controllers.
3.0 TRANSPORT AND STORAGE
3.1 Transport
Fans are delivered in wooden crates or cardboard boxes. It is recommended to leave the
fans in original packing during transport to the place of installation as well as to load and
unload them carefully to avoid any possible damage. The fans must be transported in a
horizontal position only. During transport and loading/unloading the weight of the fan must
be considered.

- 4 -
On receipt the fan must be visually inspected, and the shipment must be checked for proper
quantity.
3.2 Storage
Store the fans in a dry, weather and dust protected place. If this is impossible, it is important
to raise the fan above the ground surface and cover it with a PE foil.
4.0 INSTRUCTIONS FOR INSTALLATION
4.1 Inspection before installation
Each fan is controlled by the manufacturer before delivery.
After unpacking and before installing, check the following:
•if any eventual damage occurred during transport;
•mounting of service switch and vertical outlets (DVG-V only) up to Appendix 1;
•check by hand if impeller is rotating smoothly.
4.2 Safety instructions for installation, commissioning, maintenance and controlling
Installation and electrical connection must be accomplished only by
authorized technical personnel and in agreement with the valid regulations.
Any hazard of unintended touching the impeller (risk of injury!) has to be
prevented (with a duct long enough or a protective guard)!
Commissioning is allowed only after installation into the ventilation system
or after installation of protective guard (EN 13857). After installation impeller
must not be accessible anymore.
During installation, commissioning, maintenance and controlling,
unauthorized personal should not have access to the fan and installation
place.
Any risk of unintended start-up of the fan and any risk of touching the
impeller during above mentioned works has to be excluded (switch off the
fan and exclude possibility of unintended start-up).
Before removing the casing cover, protective guard on the pressure side or
an eventual protective guard on the suction side make sure the fan is
separated from the mains supply.
Common rules for safety work have to be strictly observed.
4.3 Installation of the fan
•Fans type DVG should be installed outside fire zones (on roofs over heated buildings);
•Fans DVG must not be mounted in explosion hazardous zones;
•Before installation check the carrying capacity and stability of the roof;
•Fans must be installed upright in a vertical position (shaft vertical) and raised above the roof
surface on a base with minimum height of 250 mm (respectively according to expected snow
height);
•The fan shall be fixed to the base with 4 screws on the corners;
•The fan housing should not be deformed during mounting;
•Check, if impeller rotating smoothly;
•Access to the fan for maintenance must be assured.

- 5 -
At installation the dimensions of the fan and possible extension of parts by
the temperature rise has to be considered (provide flexible connection of
appropriate temperature/time class)!
4.4 Instructions for installation
Air ducting system
The suction side of the fan is provided with a connection for flange-type mounting of the air
duct (6 resp. 8 bolts M8 on the base plate). It is recommended to mount fire proof flexible
connections between fan and duct to avoid tension or deformation of the fan base. Flexible
connection should meet temperature/duration class as well as the under pressure at
operation of the fan. In each case smooth rotation of impeller must be insured.
Any risk of unintended start
-
up of the fan and any risk of touching the
impeller during above mentioned works has to be excluded (switch off the
fan and exclude possibility of unintended start-up).
Connection of the fan to the mains
Electrical connection has to comply with valid local regulations and must be
accomplished only by a qualified electrician. In case of unprofessional
connection guarantee will not be valid. The risk for this carries the operator
alone. Observe attached detailed instructions of motor and controller
supplier – since EC motor built-in, there are warnings for remaining voltage
after supply switched off. Type of permitted RCD protective devices observe
local regulations.
Power supply to motor has to be executed in the service switch placed on the fan. Electric
motor is pre-wired with controller. Control cables should be led through the black tube to
controller. To get to controller dismount the upper cover of the fan.
For control possibilities please see attached instructions of motor and controller supplier.
1~ unit: instructions of controller “Compacto”
3~ unit: instructions of controller “Invento”
The quality and installation of cables for electrical connection must ensure
uninterrupted energy supply, also in case of fire. The electric cable must not
touch or be fastened to the casing of the fan (high temperature!). If danger of
unintended switch off of service switch, it should be locked to guarantee
operation in fire case. Drill hole in position “on” into handle and provide with
a padlock (not supplied with the fan).

- 6 -
Electrical data on the fan nameplate have to comply with the provided mains connection.
Motor protection has to be provided by the installer.
I
f
fan
used f
o
r smoke and heat extract
in case of fire
switch to fire mode
(max. speed, disabled protection of controller and motor) and bridging of
motor protective devices is necessary to assure operation.
Switching on max. speed even after eventual short supply cut off must be assured.
Operating over 1400 to 1500 RPM (size 800: 850 RPM) is not allowed.
5.0 COMMISSIONING
Before initial operation, read through appropriate instructions and check the following:
•Assembling of the fan (fixing, eventual deformations);
•Check all joints for leakage;
•Check if foreign objects were left in the fan or in the connected ducts;
•Check if protective elements are fitted;
•Check the accuracy of the electric wiring and connections to the mains.
Then start the fan for a short period and switch it off again to check the direction of rotation.
It has to comply with the direction of the arrow on the casing of the fan. Check it for proper
operation (smoothly rotating impeller, current, eventual vibrations, noise).
Protective glasses are needed to avoid any injury of the eyes.
Fill in attached control report and file it.
6.0 APPROVAL
It is particularly im
portant to prove the proper function of system and
control devices as well as compliance with requirements of the project and
regulations.
When the system is approved, file the reports. Make sure that only
authorised personnel can handle with on/off switch.

- 7 -
7.0 MAINTENANCE AND PERIODIC CONTROL
Unintended start
-
up during installing, controlling, maintenance or repair of
the fan has to be prevented!
The following must be controlled periodically (once a year):
1. Check if screws between impeller and hub got loose and tighten them if needed;
2. Tighten the screw between wheel hub and shaft if needed;
3. Remove dirt from the fan impeller if there is any;
4. Check the functionality of protective devices;
5. Check the functionality of control devices;
6. Current during operation;
7. Eventual vibrations;
8. Noise which might appear in el. motor bearings.
The function of the system and control devices has to be checked according to system
maintenance book, minimum every 3 months. Operation at least 15 minutes each time,
once a year 3 hours recommended, if possible.
Checking points 1 to 4 can be done only if the
supply voltage is switched off
and possibility of unintended start-up is excluded.
Parameters of points 5 to 8 must not deviate from the starting values (at installation). In
case that parameters deviate, the electric motor or the impeller have to be replaced or
repaired. This must only be done by an authorised customer service, otherwise the
manufacturer's guarantee is invalid.
The electric motor has to be maintained according to the attached instructions of the
manufacturer of the electric motor.
8.0 SYSTEM MALFUNCTIONS DURING OPERATION
For all inspections, point 4.2. must be considered.
Possible malfunctions and solutions:
The fan doe
s
not operate Check connection to the mains in service switch. If ok. check connection to controller.
Air volume is
too low Check operating point and system design.
Under
-
,
overvoltage,
overheating,
overcurrent,
locked rotor
etc.
Please see chapter “Troubleshooting” in the instructions of controller.
Noise
Damage to the bearings, impeller blocked or touching the casing.
Get the electric motor or if necessary the complete fan repaired.
Vibrations
Check operating point and system construction. If the actual pressure
drop of the system is higher than supposed, the fan could operate in an
instable area of the fan curve. Inform customer service of the

- 8 -
manufacturer.
Damage or dust layer on impeller.
Clean the impeller, if necessary balance it or replace it.
If the reason for the malfunction can not be clearly determined, inform the customer service
of the manufacturer.
After a case of fire the fan must be checked by the manufacturer.
9.0 GUARANTEE
Guarantee will be valid only if transport, storage, installation, connection and periodical
maintenance have been executed in compliance with the above instructions and local
regulations regarding electric installation and fire protection. For validity of the guarantee
duly filled and signed control report has to be submitted.
It is very important that the installation of the fan is done with all necessary
care, to ensure uninterrupted and safe operation.

Anlage 1. Montage des Revisionsschalters / Montage der Umlenkungsbleche bei DVG-V
Appendix 1. Mounting of service switch / Mounting of vertical outlets for DVG-V
Bilaga 1. Beslag av tjänste- kopplar/beslag av lodlinjeuttag för DVG-V
Приложение 1. П
у
сковое
у
тройство -монтаж / Вертикальный выброс -монтаж

Anlage 3. Zubehör - Montage
Appendix 3. Accessories – mounting
Bilaga 3. Tillbehör - installation
П
р
иложение 3. П
р
инадлежности -монтаж
DVG-H
SSG/F
ASG/F
VKG/F
ASSG/F
DVG-H
VKG/F
ASSG/F
FDG/F
DVG-H
VKG/F
SSG/F
ASG/F
ASSG/F
DVG-H
VKG/F
SSGE/F
(FDGE/F)
ASG/F
ASSG/F

Anlage 4. Zubehör - Montage
Appendix 4. Accessories – mounting
Bilaga 4. Tillbehör - installation
Приложение 4. Принадлежности - монтаж
DVG-V
SSG/F
ASG/F
VKG/F
ASSG/F
DVG-V
VKG/F
ASSG/F
FDG/F
DVG-V
VKG/F
SSG/F
ASG/F
ASSG/F
DVG-V
VKG/F
SSGE/F
(FDGE/F)
ASG/F
ASSG/F

Appendix 5. – Bridges in controller as delivered from factory
Bridges are factory inserted to allow test of fan without connecting control cables.
In case of using the fan for smoke and heat extraction, remove the red bridge 16-17 (fire mode) and connect
controller to fire central up to wiring scheme (10-11 at 3~ controller). arning: removing this bridge without
connecting to fire central and running the fan in fire mode causes no protection is active. Running in fire
mode is allowed only in case of fire or during periodical tests.
or fan speed setting with potentiometer replace bridge 9-10 (6-7 at 3~ controller) and connect potentiometer
(R >= 1kΩ) according to wiring scheme.
or fan speed setting using AN1 input (0-10V): remove bridge 9-10 (6-7 at 3~ controller) and connect 0-10V
input according to wiring scheme.
Replace bridge 18-19 (11-12 at 3~ controller) with start – stop switch.
Controller default setup controls the fan speed with potentiometer or AN1 input.
Using internal regulator for fan speed control requires change of controller setting via MODBUS (see controller
instructions). Using MODBUS for fan speed control requires change of controller setting via MODBUS (see
controller instructions).
Minimum fan speed can be increased in setup via MODBUS.
Maximum fan speed can be decreased in setup via MODBUS.
More about settings please see controller instructions.
1~ controller
3~ controller

DVG
355
355
-EC, DVG 450-EC – Wiring 1~, 230V, 50/60Hz……..27.11.2013

DVG 560-
EC, DVG 630
EC, DVG 630
-EC, DVG 800-EC – Wiring 3~, 400V, 50/60Hz……..
27.11.2013
27.11.2013

E Declaration o onformity
EG-Konformitatserklaru ng
EG-intyg om overensstammelse
•••• •
::: \ : :systemalr
..• :: .•..
...
The Manufacturer
Der Hersteller:
Tillverkaren:
Systemair d.o.o.
Spelina 2
81-2000 Maribor
Tel.: [phone]
certified herewith that the following products:
erklart hiermit,dass folgende Produkte:
fbrklarar harmed att fbljande produkter:
Smoke and heat extract fans,type DVG*,year of man.13/14
Brandgasventilatoren,Typ DVG*,Baujahr 13/14
BrandgasWiktar Typ DVG*, tillverkningsar 13/14
complieswith theprovisions of theTest reports,issued bytheLGAI Technological Center,SA,Bellaterra (Barcelona),No.09/100216-502 from
12.06.2009 and No.11/2673-1035 from 14. 06.2011 (DVG),No. 11/3662-2628 2629 from09. 01. 2012 and No. 12/3662-441 from 19. 03.2012
(DVG-EC)
'ubereinstimmt mit den Bestimmungen derPrufberichten von LGAI TechnologicalCenter,SA,Bellaterra(Barcelona),Nr.09/100216-502vom 12.
06.2009 und Nr.11/2673-1035vom14.06.2011 (DVG), Nr.11/3662-2628,2629 vom 09.01.2012 und Nr.12/3662-441vom 19 03.2012 (DVG-
EC)
'overensstammer med bestammelserna i testrapporterfran LGAITechnologicalCenter,S.A.,Bellaterra (Barcelona)nr09/100216-502avden 12
juni 2009 och nr.11/2673-1035 av den 14 juni 2011 (DVG),nr11/3662-2628,2629 av den09 januari 2012 ochnr12/3662-441 avden 19mars
2012
Note:The compliancewith ECMachineryDirective and EN ISO 13857 refers tothe mounted protectiveguards on the inletofthe fan,as far they
are in the extent of delivery.For the fully accordance withmentioned requirements (protectiveguards orsafety assurance in other way)the
performer is res onsible.
Hinweis:DieEinhaltung der EG-Maschinenrichtlinieund EN ISO 13857 beziehtsichauf die montierte Schutzgittersaugseitig,sofern diese zum
Lieferumfanehoren.Fur die vollstandi e Erfullunder enanntenAnforderun en ist der Installateur verantwortlich.
Observera: Overensstammelsen med EG-maskindirektivetochENISO 13857 gallerfOr demonterade skyddsgallren pasugsidansavida deingarI
leveransen.Installatorenansvararfor att alia namnda krav upp lis.
Maribor,
27.11.2013
Date/Datum rancKirbis,Dire orroduction
Franc Kirbis,Direktor der Produktion
FrancKirbis,produktionschef
