TallyGenicom 6600 Series User manual

6600 Series Printers
Maintenance Manual
Approved Final
May 19, 2011

6600 Series Printers
Maintenance Manual

Trademark Acknowledgements
ANSI is a registered trademark of American National Standards Institute, Inc.
Belkin is a registered trademark of Belkin Corporation.
Centronics is a registered trademark of Genicom Corporation.
Chatillon is a trademark of John Chatillon & Sons, Inc.
Code V is a trademark of Quality Micro Systems.
Dataproducts is a registered trademark of Dataproducts Corporation.
EIA is a registered service mark of Electronic Industries Association.
E NERGY S TAR® is a registered trademark of the United States
Environmental Protection Agency. As an
E NERGY S TAR® Partner,
Printronix has determined that this product meets the
E NERGY S TAR®
guidelines for energy efficiency.
IBM is a registered trademark of International Business Machines
Corporation.
IEEE is a registered trademark of the Institute of Electrical and Electronics
Engineers.
IGP is a registered trademark of Printronix, Inc.
Intelligent Printer Data Stream and IPDS are trademarks of International
Business Machines Corporation.
Java is a trademark of Sun Microsystems.
LinePrinter Plus is a registered trademark of Printronix, Inc.
Linux is a registered trademark assigned to Linus Torvalds.
MS-DOS and Microsoft Windows (3.1x, 95, 98, Me, NT, 2000, and XP) are
trademarks of Microsoft Corporation.
PC-DOS is a trademark of International Business Machines Corporation.
PGL is a registered trademark of Printronix, Inc.
Primelogic is a trademark of PTC Group, Inc.
PrintNet is a registered trademark of Printronix, Inc.
Printronix is a registered trademark of Printronix, Inc.
PSA and PSA3 are trademarks of Printronix, Inc.
QMS is a registered trademark of Quality Micro Systems.
SureStak is a trademark of Printronix, Inc.
TallyGenicom brand is owned by Printronix, Inc.
Torx is a registered trademark of Camcar/Textron Inc.
UNIX is a registered trademark of The Open Group.
Utica is a registered trademark of Cooper Power Tools.

Warranty And Copyright Information
Printronix, Inc. makes no representations or warranties of any kind regarding
this material, including, but not limited to, implied warranties of
merchantability and fitness for a particular purpose. Printronix, Inc. shall not
be held responsible for errors contained herein or any omissions from this
material or for any damages, whether direct, indirect, incidental or
consequential, in connection with the furnishing, distribution, performance or
use of this material. The information in this manual is subject to change
without notice.
This document contains proprietary information protected by copyright. No
part of this document may be reproduced, copied, translated or incorporated
in any other material in any form or by any means, whether manual, graphic,
electronic, mechanical or otherwise, without the prior written consent of
Printronix, Inc.
All rights reserved.
© 2011, Printronix, Inc.
E NERGY S TAR
The Environmental Protection Agency E NERGY S TAR ®Computers program is
a partnership effort with manufacturers of data processing equipment to
promote the introduction of energy-efficient personal computers, monitors,
printers, fax machines, and copiers to help reduce air pollution and global
warming caused by electricity generation.
Printronix, Inc. participates in this program by introducing printers that reduce
power consumption when they are not being used. As an E
NERGY S TAR ®
Partner, Printronix has determined that this product meets the E
NERGY S TAR ®
guidelines for energy efficiency.
NOTE: The E NERGY S TAR ®emblem does not represent EPA endorsement of
any product or service.

Communication Notices
Federal Communications Commission (FCC) Statement
This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to Part 15 of the FCC Fules. These limits are
designed to provide reasonable protection against harmful interference when
the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference
to radio communications. Operation of this equipment in a residential area is
likely to cause harmful interference in which case the user will be required to
correct the interference at his own expense.
Properly shielded and grounded cables and connectors must be used in order
to meet FCC emission limits. Printronix is not responsible for any radio or
television interference caused by using other than recommended cables and
connectors or by unauthorized changes or modifications to this equipment.
Unauthorized changes or modifications could void the user’s authority to
operate the equipment.
This device complies with Part 15 of the FCC Fules. Operation is subject to
the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
European Union (EU) Conformity Statement
Printronix cannot accept responsibility for any failure to satisfy the protection
requirements resulting from a non-recommended modification of the product,
including the fitting of option cards not authorized by Printronix.
This product has been tested and found to comply with the limits for Class A
Information Technology Equipment according to European standard EN
55022. The limits for Class A equipment were derived for commercial and
industrial environments to provide reasonable protection against interference
with licensed communication devices.
This is a Class A product. In a domestic environment this product may
cause radio interference in which case the user may be required to
take adequate measures.
WARNING

Properly shielded and grounded cables and connectors must be used in order
to reduce the potential for causing interference to radio and TV
communications and to other electrical or electronic equipment. Such cables
and connectors are available from Printronix authorized dealers. Printronix
cannot accept responsibility for any interference caused by using other than
recommended cables and connectors.
Industry Canada Compliance Statement
This Class A digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe A conform á la norme NMB-003 du
Canada.
Statement of CISPR 22 Compliance
Attention: This is a Class A Product. In a domestic environment this product
may cause radio interference in which case the user may be required to take
adequate measures.
Japanese VCCI Class A
Taiwan
Warning: This is a Class A product. In a domestic environment this product
may cause radio interference in which case the user will be required to take
adequate measures.

Australia/New Zealand
Attention: This is a Class A Product. In a domestic enviroment this product
may cause radio interference in which case the user may be required to take
adequate measures.
China
Declaration: This is a Case A Product. In a domestic environment this
product may cause radio interference, in which case the user may be required
to take practical actions.
German Conformity Statement
Zulassungsbescheinigung Gesetz über die elektromagnetische
Verträglichkeit von Geraten (EMVG) vom 30. August 1995
Dieses Gerät ist berechtigt in Übereinstimmung mit dem deutschen das EG-
Konformitätszelchen - CE - zu führen.
Der Außteller der Konformitätserklärung ist die Printronix......(1)
Informationen in Hinsicht EMVG Paragraph 3 Abs. (2) 2:
EN 55022 Klasse A Geräte bedürfen folgender Hinweise:
Nach dem EMVG: “Geräte dürfen an Orten, für die sie nicht asreichend
entstört sind, nur mit besonderer Genehmigung des Bundesminesters für
Post und Telekommunikation oder des Bundesamtes für Post und
Telekommunikation betrieben werden. Die Genehmigung wird erteilt, wenn
keine elektromagnetischen Störungen zu erwarten sind.” (Auszug aus dem
EMVG, Paragraph 3, Abs. 4) Dieses Genehmigungsverfahren ist nach
Paragraph 9 EMVG in Verbindung mit der entsprechenden Kostenverordnung
(Amtsblatt 14/93) kostenpflichtig.
EN 55022: Dieses ist eine Kategorie A Vorrichtung. Betrieb in den
Wohnbereichen kann elektrische Störung verursachen. Es ist die
Verantwortlichkeit des Benutzers, passende Gegenmaßnahmen zu ergreifen.
Das Gerät erfüllt die Schutzanforderungen nach EN 55022 und
EN 55024 Klasse A.

EN 55024: Begrenzung Werte für Gebrauch in bevölkerten Bereiche,
kommerziellen und Industriegebieten sind innen Übereinstimmung mit den
spezifizierten Anforderungen Hinsichtlich Störfreiheit.
Anmerkung: Um die Einhaltung des EMVG sicherzustellen sind die Geräte,
wie in den Handbüchern angegeben, zu installieren und zu betreiben.
European Union (EC) Electromagnetic Compatibility
Directives
This product conforms to the protection requirements of EC Council Directive
89/336/EEC on the approximation of the laws of the Member States relating
to electromagnetic compatibility. Printronix cannot accept responsibility for
any failure to satisfy the protection requirements resulting from a non-
recommended modification of the product, including the fitting of option cards
not authorized by Printronix.
Dieses Gerät ist berechtigt in Übereinstimmung mit dem deutschen EMVG
vom 9.Nov.92 das EG-Konformitätszeichen zu furhren.
Properly shielded and grounded cables and connectors must be used to
reduce the potential for causing interference to radio and TV communication
and to other electrical or electronic equipment. Printronix cannot be
responsible for any interference caused by using other than recommended
cables and connectors.
This product has been tested and found to comply with limits for Class A
Information Technology Equipment according to CISPR 22/European
Standard EN 55022. The limits for Class A equipment were derived for
commercial and industrial environments to provide reasonable protection
against interference with licensed communication equipment.
Warning: This is a Class A product. In a domestic environment this product
may cause radio interference in which case the user may be required to take
adequate measures.
Dieses Gerät erfüllt die Bedingungen der EN 55022 Klasse A. Für diese
Klasse von Geräten gilt folgende Bestimmung nach dem EMVG:
Geräte dürfen an Orten, für die sie nicht ausreichend entstört sind, nur mit
besonderer Genehmigung des Bundesminesters für Post und
Telekommunikation oder des Bundesamtes für Post und Telekommunikation
betrieben werden. Die Genehmigung wird erteilt, wenn keine
elektromagnetischen Störungen zu erwarten sind.
(Auszug aus dem EMVG vom 9.Nov.92, Para.3, Abs.4)
Hinweis: Dieses Genehmigungsverfahren ist von der Deutschen Bundespost
noch nicht veröffentlict worden.

Table of Contents
1 Maintenance Overview ......................................... 17
TallyGenicom® 6600 Cartridge Ribbon Printer (CRP) Series ................17
Order the Correct Spares.................................................................18
How to Identify a 6600 Cartridge Ribbon Printer..............................19
Zero Tear Pedestal (ZTP) Printers...................................................19
Printer Configuration Code...............................................................20
Forms Handling................................................................................20
Important Maintenance Notes.................................................................21
Notices .............................................................................................21
About this Manual ...................................................................................22
How to Use this Manual ...................................................................22
Printing Conventions in this Manual.................................................23
Safety Notices.........................................................................................23
Hinweise zur Sicherheit ..........................................................................24
Controls and Indicators...........................................................................25
Electrical Controls ............................................................................25
Mechanical Controls.........................................................................28
Tools and Test Equipment......................................................................30
Plugging in the Printer ............................................................................31
TallyGenicom Customer Support Center................................................32
TallyGenicom Supplies Department .......................................................32
Corporate Offices....................................................................................33
Maintenance Training for TallyGenicom Products..................................33
2 Preventive Maintenance ....................................... 35
Cleaning the Printer ................................................................................35
Cleaning the Exterior........................................................................35
Cleaning the Interior.........................................................................36
Cleaning the Shuttle Frame Assembly ...................................................38
Cleaning the Card Cage Fan Assembly .................................................41

Table of Contents
3 Troubleshooting .................................................... 43
Introduction.............................................................................................43
Troubleshooting Aids..............................................................................43
Start Here... ............................................................................................44
Troubleshooting Display Messages........................................................45
List of Messages ..............................................................................46
Troubleshooting Other Symptoms........................................................111
General Symptom List....................................................................112
Communications Failures .....................................................................134
Diagnostic Printer Tests........................................................................136
Selecting And Running Diagnostic Printer Tests ...........................137
Boot Diagnostics Menu.........................................................................141
Factory Menu........................................................................................144
Exception Menu....................................................................................146
Firmware Diagnostic Port .....................................................................147
Diagnostic Cable ............................................................................147
Capturing Information.....................................................................148
Hex Code Printout ................................................................................149
How To Print A Hex Dump .............................................................149
ASCII Character Set .............................................................................151
Hard Reset (Cycle Power) ....................................................................152
4 Adjustments and Tests ....................................... 153
Introduction...........................................................................................153
Adjustments and Tests...................................................................153
Preparing the Printer for Maintenance..................................................154
Returning the Printer to Normal Operation ...........................................155
Belt, Paper Feed Timing, Adjustment...................................................156
Belt, Platen Open, Adjustment..............................................................158
Paper Scale Alignment .........................................................................160
Platen Gap Adjustment.........................................................................162
Paper Out Adjustment ..........................................................................164
Hammer Phasing Adjustment...............................................................167
Loading Flash Memory .........................................................................169
Loading Software with the Firmware Download Utility ...................170
Loading through Parallel Port using DOS ......................................171
Loading Software if Flash Contains Only Boot Code .....................173
Loading Software through the NIC.................................................174
Reprogramming the Security Key.........................................................176
How to Reprogram the Security Key..............................................176
Coil Temperature Adjustment...............................................................178
Dynamic Paper Tension Adjustment ....................................................179

Table of Contents
Tractor Belt Tension Adjustment ..........................................................181
Shuttle Electrical Short Check ..............................................................182
Hammer Bank Power Cable Shorts Test..............................................183
Cable Shorts Test .................................................................................184
Main Wire Harness Test Diagnostic .....................................................186
Power Supply Operational Check.........................................................187
5 Replacement Procedures ................................... 191
Organization of this Chapter .................................................................191
Replacement Procedures .....................................................................191
List of Removal / Installation Procedures.......................................191
Belt, Paper Feed Timing ................................................................193
Belt, Platen Open ...........................................................................194
Cartridge Interface Board (CIB)......................................................195
Circuit Breaker ...............................................................................196
Connector Coupling Shrouds .........................................................197
Control Panel Assembly.................................................................199
Controller Board .............................................................................200
Cover Assembly, Hammer Bank / Ribbon Mask ............................202
Cover Assembly, Shuttle ................................................................203
Cover Assembly, Top, Pedestal Models ........................................204
Dashpot..........................................................................................205
Fan Assembly, Cabinet Exhaust ....................................................206
Fan Assembly, Card Cage .............................................................207
Fan Assembly, Hammer Bank........................................................208
Hammer Spring Assembly, Version 1 ............................................209
Hammer Spring Assembly, Version 2 ............................................211
Magnetic Pickup (MPU) Assembly.................................................217
Memory (Flash, Expansion) ...........................................................218
Motor Bracket Assembly ................................................................219
Paper Feed Motor ..........................................................................220
Paper Ironer ...................................................................................221
Paper Guide Assembly ..................................................................222
Platen .............................................................................................223
Platen Open Motor .........................................................................227
Platen Stop Assembly ....................................................................229
Power Supply Board ......................................................................230
Resistors, Terminating, V6 Controller Board..................................231
Ribbon Drive Motor ........................................................................233
Security Key ...................................................................................234
Shaft, Splined.................................................................................236
Shaft, Support ................................................................................238

Table of Contents
Shuttle Frame Assembly ................................................................239
Spring, Extension, Hammer Bank ..................................................241
Switch Assembly, Paper Detector..................................................242
Switch Assembly, Platen Interlock .................................................243
Tractor (L/R)...................................................................................244
Weld Sensor...................................................................................244
6 Illustrated Parts Breakdown................................ 245
Organization of this Chapter.................................................................245
Illustrations of Printer Components ................................................245
7 Principles Of Operation....................................... 279
Line Matrix Printing ...............................................................................279
Printing Rates .......................................................................................282
Printing Mechanism ..............................................................................282
Shuttle Frame Assembly.......................................................................283
Hammer Bank Assembly................................................................283
Shuttle Drive Motor ........................................................................284
Paper Transport System.......................................................................285
Ribbon Transport System.....................................................................286
Integrated Print Management System ..................................................287
Operation .......................................................................................287
Logical Control of the Printer ................................................................290
Control Panel........................................................................................291
Controller Board....................................................................................292
Data Controller ...............................................................................294
Engine Controller ...........................................................................296
Power Supply Board.............................................................................298
AC Power .......................................................................................298
DC Power.......................................................................................298
Printer Interface ....................................................................................299
A Wire Data ........................................................... 301
B Abbreviations...................................................... 343
C Metric Conversion Tables .................................. 351

Table of Contents
D SureStak™ Power Stacker ................................ 353
Contents ...............................................................................................353
Introduction...........................................................................................354
Stacker Operation.................................................................................354
Stacker Problems .................................................................................359
Stacker First Inspection..................................................................359
Stacker Confidence Check.............................................................360
Stacker Motor Check......................................................................361
Removing the Power Stacker ...............................................................364
Installing the Power Stacker .................................................................370
Replacing the Constant Force Spring...................................................382
Replacing the Timing Belts ...................................................................384
Replacing the Roller Drive Shaft...........................................................387
Illustrated Parts Breakdown..................................................................390
List of Illustrations ..........................................................................390
E Zero Tear Pedestal (ZTP) Printer....................... 403
Contents ...............................................................................................403
Overview...............................................................................................404
Operation ..............................................................................................405
Load Paper and Set Up the Tractors .............................................405
Remove Paper ...............................................................................406
Adjust The Paper Guides ...............................................................407
Position the Paper Out Sensor.......................................................409
Set the Tear Bar Distance..............................................................410
Set the Top Of Form ......................................................................411
Control Panel Menus ............................................................................412
Performance Limitations.......................................................................413
Adjustments and Tests .........................................................................415
List of Adjustments and Tests Procedures.....................................415
Preparing the ZTP Printer for Maintenance....................................416
Returning the Printer to Normal Operation.....................................416
Barrier Panel ..................................................................................417
Belt, Paper Feed Timing, Adjustment.............................................418
Paper Guide Leaf, Front, Center, Outer.........................................420
Paper Out Sensor, Adjustment ......................................................420
Paper Tension, Horizontal..............................................................420

Table of Contents
Replacement Procedures .....................................................................421
List of Removal / Installation Procedures.......................................421
Belt, Paper Feed Timing ................................................................422
Control Panel Assembly.................................................................423
Cover Assembly, Top, Pedestal Models ........................................423
Paper Feed Motor ..........................................................................424
Paper Guide Leaf, Center ..............................................................425
Paper Guide Leaf, Front.................................................................425
Paper Guide Leaf, Outer ................................................................425
Paper Out Sensor ..........................................................................426
Shaft, Splined.................................................................................428
Shaft, Support ................................................................................431
Tractor (L/R)...................................................................................432
Tractor Assembly Support Gate.....................................................433
Illustrated Parts Lists ............................................................................435
Illustrations of ZTP Components....................................................435
F Paper Specifications And Forms Design ............ 449
Introduction...........................................................................................449
General Paper Specifications ...............................................................450
Paper Guidelines ..................................................................................451
Terms and Definitions ....................................................................451
Environmental Considerations .......................................................453
Form Types ....................................................................................453
Form Weight...................................................................................453
Form Thickness..............................................................................453
Form Evenness ..............................................................................453
Tractor Pin Engagement ................................................................453
Methods of Forms Attachment .......................................................454
Chaff Content ................................................................................. 455
Form Design Checklist..........................................................................456
Summary ..............................................................................................459
Storage and Handling ....................................................................459
G Customer Support.............................................. 461
TallyGenicom Customer Support Center..............................................461
TallyGenicom Supplies Department .....................................................462
Corporate Offices..................................................................................462

17
1 Maintenance Overview
TallyGenicom®6600 Cartridge Ribbon Printer (CRP) Series
TallyGenicom
®
has been the global leader in industrial printing solutions for
over 30 years, earning a reputation for designing and manufacturing leading
edge products and delivering them to market with unsurpassed service and
support.
The TallyGenicom 6600™ Line Matrix Printing Platform extends the series of
technology innovations that cement TallyGenicom’s leadership position. Line
matrix printing is TallyGenicom’s flagship technology, and it remains the
workhorse solution for supply-chain and back-office printing applications
because of its reliability, lower cost of ownership and flexibility of printing
applications.
• Most reliable printer ever – provides more up time and lower operating
costs
• Ultra capacity ribbons – deliver darker image, last longer, and costs less
to operate than other print technologies
• Integrated print management system – provides precise control over print
quality, print costs, and job planning
• Cabinet or Pedestal styles – best user access and forms handling
flexibility
• Unsurpassed ease of use – simplifies operation and enhances
productivity
There are four printer configurations:
Enclosed Cabinet
• The enclosed cabinet models provide for near silent operation, making
these printers perfectly suitable for use in the quietest of office
environments.
• Provides the best paper handling for large print runs. All paper input and
output is contained inside the cabinet and protected from bumping and
contamination.
• Highly effective combination of moveable fences and chains allows for
precise stacking all the way up to a full box of paper.
• For tougher forms that tend not to refold well, a SureStak power stacker
option is available for the enclosed cabinet models.
• Available in four print speeds – 500 line per minute (lpm), 1000 lpm,
1500 lpm, and 2000 lpm models.

18
Chapter 1 TallyGenicom® 6600 Cartridge Ribbon Printer (CRP) Series
Pedestal
• The pedestal model has a clamshell design that allows easy access to all
controls, providing faster ribbon replacements and easier paper loading.
• Oversized casters are standard making movement easy.
• Versatility to configure the paper path for either top or rear exit.
• Using the top paper exit, this printer is ideal for short print runs and easy
access to output.
• Available in three print speeds – 500 line per minute (lpm), 1000 lpm, and
1500 lpm models.
Quiet Pedestal
• This printer configuration is the same as the above Pedestal configuration
but with an enclosed input paper area with a front door, side panels, and
bottom panel to seal the input paper path.
• Provides a reduction in acoustic noise.
Zero Tear Pedestal
• Special push tractor configuration enables printing from the very first to
the very last line of a form and then tear-off with no forms lost.
• The elimination of wasted forms between jobs can yield significant
savings.
• An ideal solution for supply-chain and back-office applications.
• Available in three print speeds – 500 line per minute (lpm), 1000 lpm, and
1500 lpm models.
Order the Correct Spares
When you replace worn or damaged printer components, make sure you
order the correct spares for the model you are servicing. The next section
shows you how to identify a 6600 Cartridge Ribbon Printer.

How to Identify a 6600 Cartridge Ribbon Printer
19
How to Identify a 6600 Cartridge Ribbon Printer
A 6600 printer has a model number logo and ribbon cartridge logo on the
printer front cover. The model number is an alphanumeric code that identifies
the printer type, its housing, and its maximum rated print speed. The serial
number “C” indicates that this is a cartridge equipped printer. The model
number and serial number of the printer are on the identification label next to
the input/output ports at the rear of the printer. Figure 1 shows how to
interpret a model number.
Figure 1. How to Interpret a Model Number
The speed of printing for “real world” print jobs is affected by the interaction of
many variables and varies from print job to print job. For more information,
see “Printing Rates” on page 282.
Zero Tear Pedestal (ZTP) Printers
Zero Tear Pedestal (ZTP) printers are models equipped with special
hardware and software that permits them to print small jobs or single sheets
without losing a sheet between print jobs. A ZTP printer automatically
presents the current print line to a tear bar when it finishes printing and
presents the perforation of the last form printed to the tear bar. When it
receives more data from the host computer, the printer pulls the form down to
the print station and resumes printing.
ZTP printers are covered in Appendix E (page 403).
6600 CRP Printer
6605QZ
Housing Code:
Without Q = Pedestal
Q= Floor Cabinet
Speed Rating:
05 = 500 lines per minute (lpm)
10 = 1000 lpm
15 = 1500 lpm
20 = 2000 lpm
Z= Zero Tear printer

20
Chapter 1 TallyGenicom® 6600 Cartridge Ribbon Printer (CRP) Series
Printer Configuration Code
Every printer has a configuration code which specifies the printer’s cabinet
type, controller board revision level, V8 ASIC revision level, and MECA ASIC
revision level. The configuration code is included in the configuration printout.
Figure 2 shows how to interpret the printer’s configuration code.
Figure 2. How to Interpret the Printer’s Configuration Code
Forms Handling
Pedestal Models
Pedestal models provide access to printed forms from the top cover with a
tear-at-perforation edge for ejected forms or a paper exit at the rear of the top
cover. Pedestal printers also have a wireform paper tray attached to the front
of the pedestal and a wireform catch basket attached either to the back of the
pedestal or to the back of the printer top cover.
Cabinet Models
Cabinet models can be equipped with four kinds of paper stacking devices:
• The fixed paper fence is a wireform divider that separates the source
paper stack from the printed output stack, and is used in combination with
hanging chains that guide printed forms downward.
• For improved performance at higher print speeds, the chains are used
with a moveable fence called the “passive paper stacker,” which can be
positioned to match the form’s length.
• The front access paper stacker consists of a shelf that holds the input
paper and a sliding tray that receives the printed forms. The sliding tray
pulls forward, permitting the user to both load and unload paper from the
front of the printer. This option is helpful in locations where access to the
rear of the printer is limited or impossible.
• For more demanding applications, an optional power stacker is available.
(The power stacker is covered in Appendix D on page 353.)
These devices are summarized in Table 1.
FH06AA
Cabinet Type:
F= Floor Cabinet
P= Pedestal Model
Controller Board Revision Level.
H= PSA3 board
V8 ASIC Revision Level
MECA ASIC
Revision Level
