Task Force Tips BlitzForce XXLC-33-NH1 Programming manual

©Copyright Task Force Tips LLC 2006-2023 1 LIX-730 July 13,2023 Rev10
TASK FORCE TIPS LLC
MADE IN USA · tft.com
3701 Innovation Way, Valparaiso, IN 46383-9327 USA
800-348-2686 · 219-462-6161 · Fax [phone]
INSTRUCTIONS FOR INSTALLATION, OPERATION, AND MAINTENANCE
BlitzForce™
Portable Monitor
DANGER
Understand manual before use. Operation of this device without understanding the manual and
receiving proper training is a misuse of this equipment. Obtain safety information at tft.com/
serial-number.
This equipment is intended for use by trained and qualified emergency services personnel for
firefighting. All personnel using this equipment shall have completed a course of education
approved by the Authority Having Jurisdiction (AHJ).
This instruction manual is intended to familiarize firefighters and maintenance personnel with the
operation, servicing, and safety procedures associated with this product. This manual should be
kept available to all operating and maintenance personnel.
BlitzForce Portable Monitor
BlitzForce OSC Portable Monitor
MAXIMUM FLOW
500 GPM @ 175 PSI
(2000 L/min @ 12 BAR)
HYDROSTATIC PROOF TEST
900 PSI (62 BAR) per NFPA 1964

©Copyright Task Force Tips LLC 2006-2023 2 LIX-730 July 13,2023 Rev10
The member companies of FEMSA that provide emergency
response equipment and services want responders to know and
understand the following:
1. Firefighting and Emergency Response are inherently
dangerous activities requiring proper training in their hazards
and the use of extreme caution at all times.
2. IT IS YOUR RESPONSIBILITY to read and understand
any user’s instructions, including purpose and limitations,
provided with any piece of equipment you may be called on
to use.
3. IT IS YOUR RESPONSIBILITY to know that you have been
properly trained in Firefighting and/or Emergency Response
and in the use, precautions, and care of any equipment you
may be called upon to use.
4. IT IS YOUR RESPONSIBILITY to be in proper physical
condition and to maintain the personal skill level required to
operate any equipment you may be called upon to use.
5. IT IS YOUR RESPONSIBILITY to know that your equipment is
in operable condition and has been maintained in accordance
with the manufacturer’s instructions.
6. Failure to follow these guidelines may result in death, burns or
other severe injury.
Fire and Emergency Manufacturers and Service Association, Inc.
PO Box 147, Lynnfield, MA 01940 • www.FEMSA.org
© 2020 FEMSA. All Rights Reserved.
PERSONAL RESPONSIBILITY CODE
DANGER
SUPPORTING MATERIALS
The following document contains supporting safety and operating
information pertaining to the equipment described in this manual.
LIX-735 - BLITZFORCE XXL-B
Storage Bracket
©Copyright Task Force Tips LLC 2006-2020 1 LIX-735 November 30, 2020 Rev04
TASK FORCE TIPS LLC
MADE IN USA · tft.com
3701 InnovationWay, Valparaiso, IN 46383-9327 USA
800-34 8-2686 · 219-46 2-6161 · Fax [phone]
G-Force
INSTRUCTION FOR INSTALLATION
BlitzForce ™
XXL-B Storage Bracket
WARNING
The Portable Monitor Storage Bracket is designed only to store the Portable Monitor. Attempting to
ow from the storage bracket can cause the monitor to becom e dislodged fro m the bracket and out
of control, causing severe injury or death. Always properly deploy the m onitor before owing.
NOTICE
To reduce the risk of equipment damage, the storage bracket must be securely mounted to a
surface capable of supporting the weight of the monitor and nozzle, including an y shock loads that
may result from rough roads. It is the responsibility of the installer to determ ine that the installation
is capable of these loads.

©Copyright Task Force Tips LLC 2006-2023 3 LIX-730 July 13,2023 Rev10
TABLE OF CONTENTS
1.0 MEANING OF SAFETY SIGNAL WORDS
2.0 SAFETY
3.0 GENERAL INFORMATION
3.1 VARIOUS MODELS AND TERMS
3.2 MECHANICAL SPECIFICATIONS
3.3 OPERATING ENVELOPE
3.4 USE WITH SALT WATER
3.5 OPERATING INSTRUCTIONS
3.6 VALVE OPERATION
3.7 FOLDING LEGS
3.7.1 CARBIDE SPIKES
3.8 FULL TIME SWIVEL INLET HOSE COUPLING
3.9 OUTLET PIVOTS AND SAFETY ELEVATION PLUNGER
3.10 ELEVATION HOLDING MECHANISM
4.0 FLOW CHARACTERISTICS
4.1 AUTOMATIC, FIXED, AND SELECTABLE FLOW NOZZLES
4.2 STACKED TIPS OR SMOOTHBORE NOZZLES
4.3 STREAM STRAIGHTENERS
4.4 USE WITH FOAM
4.5 PRESSURE LOSS
5.0 DEPLOYMENT OF BLITZFORCE PORTABLE MONITOR
5.1 CARRYING WITH AN UNCHARGED HOSE
5.2 CARRYING WITH A CHARGED HOSE
5.3 PRESSURE GAUGE PORT
6.0 ANCHORING
6.1 ANCHORING BY USING THE TIE DOWN STRAP
6.2 ANCHORING BY WEIGHT
6.3 ANCHORING BY SPIKE HOLDS
6.4 ANCHORING BY HOOKING LEGS
7.0 OSCILLATING UNIT (OSC)
7.1 SAFETY - OSCILLATOR
7.2 GENERAL - OSCILLATOR
7.3 OSCILLATOR
7.4 OSCILLATION SPEED AND COVERAGE
8.0 STORAGE
9.0 WARRANTY
10.0 MAINTENANCE
10.1 SERVICE TESTING
10.2 REPAIR
11.0 EXPLODED VIEW AND PARTS LISTS
12.0 OPERATION AND INSPECTION CHECKLIST

©Copyright Task Force Tips LLC 2006-2023 4 LIX-730 July 13,2023 Rev10
1.0 MEANING OF SAFETY SIGNAL WORDS
A safety related message is identified by a safety alert symbol and a signal word to indicate the level of risk involved with a particular
hazard. Per ANSI Z535.6, the definitions of the four signal words are as follows:
2.0 SAFETY
DANGER
DANGER indicates a hazardous situation which, if not avoided, will result in death or serious injury.
WARNING
WARNING indicates a hazardous situation which, if not avoided, could result in death or serious
injury.
CAUTION CAUTION indicates a potentially hazardous situation which, if not avoided, could result in minor
or moderate injury.
NOTICE
NOTICE is used to address practices not related to physical injury.
DANGER
An inadequate supply of pressure and/or flow will cause an ineffective stream and can result
in injury or death. Choose operating conditions to deliver adequate fire suppression. See flow
graphs.
DANGER
Sudden change in position of an improperly secured monitor can result in an out of control monitor.
An out of control monitor can spray water in unintended directions or become a projectile, causing
serious injury or death. To reduce the risk of an out of control monitor:
• Do not attempt to move the monitor while flowing
• Keep elevation as high as practical
• Test Shut-off valve before each use
• Securely tie off monitor
• Ensure all legs are in the unfolded position
• Hook legs on stationary objects such as door frames, sign posts, etc.
• Choose surfaces that allow all spikes to contact the ground
• Do not place the monitor on top of debris, objects, or uneven terrain
• Assure that the hose is not lifting spikes off the ground
• If stability is questionable, reduce flow to limit reaction
In the event of an out of control monitor:
• Immediately retreat to a safe distance
• Shut down the water hose at its source before attempting to re-secure the monitor
WARNING
Interrupting flow to the monitor could cause injury or death. Avoid situations that may interrupt
flow to the monitor such as hose line kinks, traffic running over hose, and automatic doors or
devices that can pinch the hose.
WARNING
The stream exiting a nozzle is very powerful and capable of causing injury and property damage.
Make sure the nozzle is securely attached and pointing in a safe direction before water is turned on.
Do not direct water stream to cause injury or damage to persons or property.
WARNING
Equipment may be damaged if frozen while containing significant amounts of water. Such damage
may be difficult to detect visually. Subsequent pressurization can lead to injury or death. Any time
the equipment is subject to possible damage due to freezing, it must be tested and approved for
use by qualified personnel before being considered safe for use.
CAUTION Mismatched or damaged waterway connections may cause equipment to leak or uncouple under
pressure. Failure could result in injury. Equipment must be mated to matched connections.
CAUTION Dissimilar metals coupled together can cause galvanic corrosion that can result in the inability to
uncouple the connection, or complete loss of engagement over time. Failure could cause injury. Per
NFPA 1962, if dissimilar metals are left coupled together, an anti-corrosive lubricant should be
applied to the connection and the coupling should be disconnected and inspected at least
quarterly.
NOTICE
To prevent mechanical damage, do not drop or throw equipment.

©Copyright Task Force Tips LLC 2006-2023 5 LIX-730 July 13,2023 Rev10
3.0 GENERAL INFORMATION
The BlitzForce Portable Monitor is an efficient, compact and easy to maneuver portable monitor. The monitor is a lightweight aluminum
unit, capable of delivering up to 500 gpm of water. This monitor can be mounted in a pre-connected state on the truck-mounted storage
bracket to achieve a quick and effective initial attack.
3.1 VARIOUS MODELS AND TERMS
Figure 3.1
3.2 MECHANICAL SPECIFICATIONS
Table 3.2
Size (legs folded) 14.8”L x 9.0”W x 9.4”H (375mm x 230mm x 240mm)
Size (legs unfolded) 15”L x 25.8”W x 10”H (380mm x 655mm x 254mm)
Weight (without nozzle) 15 lbs (6.9 kg)
Maximum inlet pressure with valve shut off 300 psi (20 bar)
Maximum inlet pressure at maximum flow 175 psi (12 bar)
Flow Range up to 500 gpm (up to 2000 l/min)
Operating temperature of fluid 33 to 120°F (1 to 50°C)
Storage temperature range -40 to 150°F (-40 to 65°C)
Standard Inlet Coupling 2 ½” NH Female
Standard Outlet 2 ½” NH Male
Vertical Stream Range (manned) 20 to 60° above horizion
Vertical Stream Range (unmanned) 30 to 60° above horizon
Horizontal Stream Range +/- 20° either side of centerline
Materials used Aluminum 6000 series hard anodized MIL8625 class 3 type
2, stainless steel 300 series, nylon 6-6
.QHH
3DG
)ROGLQJ/HJ
+DQGOH
/RFNLQJ
.QRE
&DUU\LQJ
+DQGOH
6DIHW\
(OHYDWLRQ
3OXQJHU
3LYRWLQJ2XWOHW
ZLWK5HPRYDEOH
6WUHDP
6WUDLJKWHQHU
6WUDS+RRN
ZLWK%DJ
6HULDO1XPEHU
&DUELGH7LSSHG6SLNH
,QOHW
(OHYDWLRQ
+ROGLQJ
0HFKDQLVP
9DOYH+DQGOH

©Copyright Task Force Tips LLC 2006-2023 6 LIX-730 July 13,2023 Rev10
3.3 OPERATING ENVELOPE
3.4 USE WITH SALT WATER
Use with salt water is permissible provided the equipment is thoroughly cleaned with fresh water after each use. The service life of the
equipment may be shortened due to the effects of corrosion, and is not covered under warranty.
3.5 OPERATING INSTRUCTIONS
3.6 VALVE OPERATION
The valve handle is locked in the closed position so that the Portable
Monitor may be carried/moved without the valve inadvertently opening
when water flow is not desired. To unlock the valve handle from the
closed position:
1. Pull the knob on the right side of the valve handle.
2. While pulling the knob, use the other hand to move the valve
handle slowly to an open position.
As soon as valve is opened the knob may be released. Valve handle
may be moved to any position by pushing or pulling on the valve handle.
When the valve is closed the valve handle automatically locks and must
be unlocked again to reopen. The monitor has a label that indicates the
direction to open and close the valve.
3.7 FOLDING LEGS
The Portable Monitor has two legs that fold for storage and unfold for operation. The legs are held in the folded and unfolded position by
spring detents. To fold or unfold the legs:
1. Grasp the spike end of one leg and pivot it to the folded or unfolded position.
2. Repeat for the other leg.
WARNING
Damage or injury could result from operating the monitor beyond the safe operating envelope. Do
not operate the monitor outside the envelope in the following graph(s).
WARNING
Sudden changes in valve position can cause pressure spikes (water hammer) and could lead to
hose or pipe failure or an out of control monitor. Open and close the valve slowly to avoid water
hammer.
WARNING
In the unfolded position, the legs provide a stable base for operation of the monitor. Lack of stability
can cause an out of control monitor resulting in injury or death. Do not operate as a portable
monitor with one or both legs in the folded position.
0
5
10
15
20
25
600
Pressure (BAR)
0
0 100 200 300 400 500
Flow (GPM)
50
100
150
200
250
300
350
400
Pressure (PSI)
0 500 1000 1500 2000
Maximum Monitor
Inlet Pressure
Flow (L/MIN)
OPEN
POSITION
LOCKED
CLOSED
POSITION
Figure 3.6

©Copyright Task Force Tips LLC 2006-2023 7 LIX-730 July 13,2023 Rev10
3.7.1 CARBIDE SPIKES
The BlitzForce Portable Monitor has 3 tungsten carbide tipped spikes on the legs and the base to resist sliding by digging into the
surface the monitor is sitting on. The amount of sliding force these spikes can withstand depends upon the amount of downward and
sideways force that is on the base and the hardness and texture of the surface the spikes are in contact with. At low elevation angles, it
is difficult for these spikes to resist sliding. These spikes are essential to safe operation of the monitor and must be in contact with the
ground at all times. Set the monitor on an even surface so that all three spikes contact the ground. Replace any spike if the tip diameter
exceeds 1/16 inch (1.6mm).
3.8 FULL TIME SWIVEL INLET HOSE COUPLING
The BlitzForce Portable Monitor has a full-time swiveling inlet coupling so that when the hose is charged, any twist in the hose will
minimize the lifting of the spikes off the ground. The monitor is equipped with three spikes to provide traction when flowing from the
ground. For the spikes to provide traction they must remain in contact with the ground. Assure that the hose is not on top of anything that
would cause the spikes to be lifted off the ground.
3.9 OUTLET PIVOTS AND SAFETY ELEVATION PLUNGER
The monitor’s outlet pivots to allow for 20 degrees of horizontal rotation either side of center. The elevation range is from 20 to 60
degrees manned and 30 to 60 degrees unmanned (30 to 50 degrees with the oscillator version). While manned, to lower the outlet below
the 30 degrees elevation, push down the outlet to the desired elevation. Below the outlet pivot is a spring-loaded plunger that returns the
outlet to 30 degrees if the operator releases on the outlet or the monitor is unmanned. The pivots are easy to reposition under pressure
and are good for rapid redirecting of the stream.
Figure 3.9
3.10 ELEVATION HOLDING MECHANISM
The elevation pivot has a mechanism to support the weight of a nozzle. It is factory set to support the weight of nozzles likely to be used.
It may be adjusted. The mechanism releases when raising the nozzle so upwards drag from the mechanism is not felt. Avoid the use of
long stream straighteners or heavy nozzles which may overcome the holding torque of the elevation mechanism.
WARNING
For stable operation all spikes must maintain contact with the ground. Lack of stability can cause
an out of control monitor resulting in injury or death. Do not place the monitor on top of debris,
objects, or uneven terrain that could keep any of the spikes from contacting the ground.
WARNING
On hard slippery surfaces the spikes may provide little resistance to sliding. A sliding monitor may
become out of control and may cause injury or death.
To help increase resistance to sliding:
• Tie off the monitor
• Hook the legs on a stationary object
• Apply a person’s weight to the monitor
• Replace any spike if the tip diameter exceeds 1/16 inch (1.6 mm)
CAUTION Spikes are sharp and exposed. Use care around spikes to avoid injury and damage to clothing or
other property.
0,1
0$;
810$11('
 0$11('


(OHYDWLRQ'UDJ
$GMXVWLQJ1XW
7LJKWHQWRLQFUHDVH
GUDJ
/RRVHQWRGHFUHDVH
GUDJ
'RQRWH[FHHGLQ
OE10RIKROGLQJ
WRUTXH
;
]RRP
6DIHW\
(OHYDWLRQ
3OXQJHU

©Copyright Task Force Tips LLC 2006-2023 8 LIX-730 July 13,2023 Rev10
4.0 FLOW CHARACTERISTICS
The BlitzForce Portable Monitor is designed for maximum flows of 500 GPM (2000 LPM) and a maximum pressure of 175 PSI (12 BAR).
Do not exceed these limits.
4.1 AUTOMATIC, FIXED, AND SELECTABLE FLOW NOZZLES
A variety of water or foam nozzles may be used with the BlitzForce Portable Monitor.
Automatic nozzles maintain a constant pressure by adjusting their opening to match the available flow. Consult the nozzle manufacturer
for maximum flow and pressure ratings. In all cases do not exceed 500 GPM (2000 LPM) and/or 175 PSI (12 BAR).
4.2 STACKED TIPS OR SMOOTHBORE NOZZLES
Table 4.2
4.3 STREAM STRAIGHTENERS
Stream quality, especially with smooth bore nozzles, is generally improved with the use of a stream straightener. A stream straightener is
integrated into the exit of the monitor.
4.4 USE WITH FOAM
The monitor may be used with various foam nozzles and foam solutions. Refer to fire service training for the proper use of foam.
4.5 PRESSURE LOSS
Figure 4.5
NOZZLE
DIAMETER
NOZZLE INLET PRESSURE
50 PSI 80 PSI 100 PSI 150 PSI 175 PSI
FLOW
(GPM)
REACTION
(LBS)
FLOW
(GPM)
REACTION
(LBS)
FLOW
(GPM)
REACTION
(LBS)
FLOW
(GPM)
REACTION
(LBS)
FLOW
(GPM)
REACTION
(LBS)
1.0” 210 80 266 126 297 157 364 236 390 275
1-1/4” 328 120 415 196 464 245 --- --- --- ---
1-1/2” 473 177 --- --- --- --- --- --- --- ---
NOZZLE
DIAMETER
NOZZLE INLET PRESSURE
4 BAR 6 BAR 8 BAR 10 BAR 12 BAR
FLOW
(L/min)
REACTION
(KG)
FLOW
(L/min)
REACTION
(KG)
FLOW
(L/min)
REACTION
(KG)
FLOW
(L/min)
REACTION
(KG)
FLOW
(L/min)
REACTION
(KG)
25mm 830 40 1000 60 1200 80 1300 100 1400 120
32mm 1300 70 1700 100 1900 130 --- --- --- ---
38mm 1900 90 --- --- --- --- --- --- --- ---
--- FLOW EXCEEDS RATING OF BLITZFORCE PORTABLE MONITOR
WARNING
For Class B fires, lack of foam or interruption in the foam stream can cause a break in the foam
blanket and greatly increase the risk of injury or death. Follow procedures established by the AHJ
for the specific fuel and conditions.
WARNING
Improper use of foam or using the wrong type of foam can result in illness, injury, or damage to the
environment. Follow foam manufacturer’s instructions and fire service training as directed by the
AHJ.
0.0
5.0
10.0
15.0
20.0
25.0
30.0
35.0
40.0
0 100 200 300 400 500
FLOW (GPM)
LO SS ( PS I)
0.0
0.5
1.0
1.5
2.0
2.5
0 400 800 1200 1600 2000
FLOW (LPM)
LOSS (BAR)
BlitzForce PORTABLE MONITOR
8 PSI LOSS AT 500 GPM
OSCILLATING BlitzForce
18 PSI LOSS AT 500 GPM

©Copyright Task Force Tips LLC 2006-2023 9 LIX-730 July 13,2023 Rev10
5.0 DEPLOYMENT OF BLITZFORCE PORTABLE MONITOR
It is the responsibility of the individual fire department or agency to determine physical capabilities and suitability for an individual’s use
of this equipment. Operators of this equipment shall have completed a course of training approved by the Authority Having Jurisdiction
(AHJ).
5.1 CARRYING WITH AN UNCHARGED HOSE
On a preconnected hose line the monitor may be carried by the T-shaped handle or over the shoulder with the legs folded as illustrated.
Figure 5.1
5.2 CARRYING WITH A CHARGED HOSE
On a charged hose the BlitzForce Portable Monitor may be carried by holding the T-shaped handle located on top of valve body as
shown. Shut-off valve handle should be locked in the closed position to keep the valve from inadvertently opening.
Figure 5.2

©Copyright Task Force Tips LLC 2006-2023 10 LIX-730 July 13,2023 Rev10
5.3 PRESSURE GAUGE PORT
There is a 1/8” NPT female threaded hole on the back of the inlet
casting. The holes are plugged from the factory. If a pressure gauge
is desired, unscrew the plug and install the gage using pipe sealant.
Make sure the gauge does not interfere with operation.
6.0 ANCHORING
The nozzle reaction force on the BlitzForce Portable Monitor may be as high as 330 lbs - 500 GPM at 175 PSI (150 kg- 2000 LPM at 12
BAR). This nozzle reaction must be restrained to keep the monitor from moving.
The monitor should be anchored from moving by one or more of these methods:
6.1 ANCHORING BY USING THE TIE DOWN STRAP
The safest method of restraining the monitor is to use a tie down strap. It is inherently more reliable than other methods since it does not
rely on traction or digging in of the spikes. It is also the safest method because even if the monitor slides, its travel is limited by the strap
length. Permanently anchored from the factory is a safety strap system that comes with a storage bag and a safety hook attached to the
end of the strap. The strap may be wrapped around an object, snapped back onto the strap itself, and pulled tight. Keep the entire length
of the strap as close to the ground as possible.
If the strap is too short to reach a suitable anchor, it may be extended with strong rope or chain. Keep the distance between the monitor
and anchor as short as possible. Remove all slack between the monitor and anchor before flowing water.
Figure 6.1
6.2 ANCHORING BY WEIGHT
On surfaces with good traction a person’s weight on the monitor and/or hose may be sufficient to keep the monitor from sliding. This is
highly dependent on the friction of the surface. The ability to keep one or more people’s weight on the monitor is subject to operator
fatigue and may not be as reliable as other methods. Operating at limited flows will also reduce the risk of sliding.
METHOD RISK of MOVEMENT
Anchoring by Weight HIGH
Anchoring by Spike Holds MEDIUM
Hooking Legs on Vertical Surfaces MEDIUM
Using the Tie Down Strap LOW
WARNING
Personnel in the path of an out of control monitor have an increased risk of injury or death. Tying
the monitor off to a secure object can limit the monitor’s travel in the event of an out of control
monitor. Always tie off the monitor when it is in use.
Figure 5.3
Safety
Hook

©Copyright Task Force Tips LLC 2006-2023 11 LIX-730 July 13,2023 Rev10
6.3 ANCHORING BY SPIKE HOLDS
The holding ability of the spikes is generally excellent on surfaces like asphalt, wooden and carpeted floors because they allow the spike
to penetrate well. On hard smooth surfaces such as ceramic tile, smooth concrete, marble, terrazzo, or steel decking the BlitzForce
Portable Monitor’s spikes may not hold well. Placing the spikes into cracks, expansion joints, gratings or the like will help hold the
monitor from sliding. Even with the spikes anchored, sliding may be caused by the surface cracking under the load, or from the hose or
nozzle moving the monitor thereby dislodging the spikes from their hold.
The holding ability of the spikes on soft surfaces such as sand, gravel and mud is generally poor. Other anchoring methods should be
considered.
Figure 6.3
6.4 ANCHORING BY HOOKING LEGS
The legs on the BlitzForce Portable Monitor point back slightly so they can act as a hook for anchoring on posts, walls, door frames or
other fixed objects. Sliding can occur if the legs are unhooked due to the influence of the hose, nozzle, or operator.
Figure 6.4A
Figure 6.4B
Spike caught
in a crack
Anchoring by Hooking to a Post
GOOD POOR
Nozzle reaction keeps leg hooked.
Object is close to hose.
Nozzle reaction tends to
unhook the leg.
Anchoring by Hooking to a Wall or Door Frame
GOOD POOR
Nozzle reaction keeps leg hooked.
Hose hits wall and helps hold position.
Nozzle reaction tends to
unhook the leg.

©Copyright Task Force Tips LLC 2006-2023 12 LIX-730 July 13,2023 Rev10
7.0 OSCILLATING UNIT (OSC)
An automatic oscillating mechanism is available for the BlitzForce Portable Monitor. The BlitzForce Portable Monitor can be purchased
with the oscillating mechanism factory installed or installed at the factory by a qualified technician if purchased at a later date.
7.1 SAFETY - OSCILLATOR
7.2 GENERAL - OSCILLATOR
The BlitzForce oscillating mechanism can be used for exposure protection, cooling, or any other situation where it is desirable to have a
monitor sweep back and forth.
The horizontal sweep can be set for 20, 30, and 40 degree coverage. The oscillating mechanism can be uncoupled and the water
stream can be aimed manually.
The speed of oscillation is a function of flow rate, see the BlitzForce Oscillation Speed graph. A minimum flow rate of 175 gpm is
required for proper oscillator operation.
7.3 OSCILLATOR
The BlitzForce oscillator is protected by a shock absorber system. If the nozzle encounters an obstruction the shock absorber will
compress or extend as needed to protect the gears from overload.
Figure 7.3
DANGER
Modifying this oscillating mechanism to fit any other monitor will cause the reaction force of the
nozzle to be unaligned with the center of rotation. An unaligned monitor may spin very fast with a
very high force, which can result in serious injury or death. Do not modify the oscillator to fit any
other monitor.
WARNING
When the oscillator is in operation, the reaction force is acting in different directions on the leg
spikes. These sudden changes in direction may cause the monitor to become off-balance resulting
in sliding or loss of control. Make sure the monitor is on a firm surface with adequate holding power
and properly anchored by the tie down strap before operating the oscillator.
CAUTION The oscillator unit contains moving parts that can pinch fingers and hands when the unit is in
operation. Keep hands and fingers away from the moving parts of the oscillating unit when water is
flowing.
CAUTION Because the nozzle attached to the oscillator must slow down, stop and reverse direction at the end
of each sweep, the ends of the covered area will receive more water than the center. If the center
area of coverage needs the most cooling, occasionally narrow the area of coverage or use the
oscillator manually.
LIFT TO CHANGE SWEEP SETTING
1
PULL KNOB & TURN
TO STOP OSCILLATION
SLIDE TO
CHANGE
ANGLE
2
SWEEP
30°
20°
40°

©Copyright Task Force Tips LLC 2006-2023 13 LIX-730 July 13,2023 Rev10
7.4 OSCILLATION SPEED AND COVERAGE
Oscillation Speed: The chart shows how many times per minute the oscillator
makes one complete cycle as a function of flow. The higher the flow, the faster
it oscillates.
Nozzle Reach: Refer to the operation manual for the specific nozzle. For
reach with oscillation, subtract 20% from the distance.
Figure 7.4
8.0 STORAGE
The monitor may be stored pre-connected to its hose on the optional storage bracket, TFT part number XXL-B. The storage bracket may
be mounted on a horizontal surface, or a vertical surface with the nozzle end pointing down or sideways.
To mount the bracket, follow the instructions (LIX-735) provided with the bracket kit.
NOTICE
The type of nozzle and flow pressure are critical to the coverage area. The graph shows coverage
area based on the movement capability of the oscillating mechanism. Actual coverage will depend
on flow, pressure, type of nozzle, angle of fog pattern, and wind conditions.
WARNING
The Portable Monitor Storage Bracket is designed only to store the Portable Monitor. Attempting to
flow from the storage bracket can cause the monitor to become dislodged from the bracket and out
of control, causing severe injury or death. Always properly deploy the monitor before flowing.
APPROXIMATE
CYCLES/MIN
GPM L/MIN
8 175 650
13 250 1000
21 375 1500
28 500 2000
BlitzForce OSCILLATION SPEED
Table 7.4
200
175
150
125
100
75
50
0
DISTANCE IN FEET
20 DEGREES
30 DEGREES
40 DEGREES
WIDTH OF COVERAGE
150 / 45m
125 / 38m
100 / 30m
75 / 23m
50 / 15m
COVERAGE AREA
OF BlitzForce OSCILLATING UNIT
61m
53m
45m
38m
30m
22m
15m
DISTANCE IN METERS

©Copyright Task Force Tips LLC 2006-2023 14 LIX-730 July 13,2023 Rev10
9.0 WARRANTY
Task Force Tips LLC, 3701 Innovation Way, Valparaiso, Indiana 46383-9327 USA (“TFT”) warrants to the original purchaser of its
products (“equipment”), and to anyone to whom it is transferred, that the equipment shall be free from defects in material and
workmanship during the five (5) year period from the date of purchase for mechanical components, and the two (2) year period from the
date of purchase for electrical components. TFT’s obligation under this warranty is specifically limited to replacing or repairing the
equipment (or its parts) which are shown by TFT’s examination to be in a defective condition attributable to TFT. To qualify for this limited
warranty, the claimant must return the equipment to TFT, at 3701 Innovation Way, Valparaiso, Indiana 46383-9327 USA, within a
reasonable time after discovery of the defect. TFT will examine the equipment. If TFT determines that there is a defect attributable to it,
TFT will correct the problem within a reasonable time. If the equipment is covered by this limited warranty, TFT will assume the
expenses of repair.
If any defect attributable to TFT under this limited warranty cannot be reasonably cured by repair or replacement, TFT may elect to
refund the purchase price of the equipment, less reasonable depreciation, in complete discharge of its obligations under this limited
warranty. If TFT makes this election, claimant shall return the equipment to TFT free and clear of any liens and encumbrances.
This is a limited warranty. The original purchaser of the equipment, any person to whom it is transferred, and any person who is an
intended or unintended beneficiary of the equipment, shall not be entitled to recover from TFT any consequential or incidental damages
for injury to person and/or property resulting from any defective equipment manufactured or assembled by TFT.
It is agreed and understood that the price stated for the equipment is in part consideration for limiting TFT’s liability. Some states do not
allow the exclusion or limitation of incidental or consequential damages, so the above may not apply to you.
TFT shall have no obligation under this limited warranty if the equipment is, or has been, misused or neglected (including failure to
provide reasonable maintenance) or if there have been accidents to the equipment or if it has been repaired or altered by someone else.
THIS IS A LIMITED EXPRESS WARRANTY ONLY. TFT EXPRESSLY DISCLAIMS WITH RESPECT TO THE EQUIPMENT ALL
IMPLIED WARRANTIES OF MERCHANTABILITY AND ALL IMPLIED WARRANTIES OF FITNESS FOR A PARTICULAR PURPOSE.
THERE IS NO WARRANTY OF ANY NATURE MADE BY TFT BEYOND THAT STATED IN THIS DOCUMENT.
This limited warranty gives you specific legal rights, and you may also have other rights which vary from state to state.

©Copyright Task Force Tips LLC 2006-2023 15 LIX-730 July 13,2023 Rev10
10.0 MAINTENANCE
TFT products are designed and manufactured to be damage resistant and require minimal maintenance. However, as the primary
firefighting tool upon which your life depends, it should be treated accordingly. The unit should be kept clean and free of dirt by rinsing
with water after each use. Any inoperable or damaged parts should be repaired or replaced before placing the unit in service. To help
prevent mechanical damage, do not drop or throw equipment.
In applications where appliances are left continuously connected to the apparatus or other devices or are used where water is trapped
inside the appliance, the appliance must be flushed with fresh water following each use and inspected for damage.
This appliance should be disconnected, cleaned and visually inspected inside and out at least quarterly, or as water quality and use may
require. Moving parts such as handles, valve ball and couplings should be checked for smooth and free operation. Seals shall be
greased as needed with Silicone based grease such as Molykote 112. Any scrapes that expose bare aluminum should be cleaned and
touched up with enamel paint such as Rust-Oleum. Replace any missing or damaged parts before returning to service.
Any equipment taken out of service due to failure should be returned to the factory for repair or replacement. If you have any questions
regarding the testing or maintenance of your valve, please call Task Force Tips at 800-348-2686.
10.1 SERVICE TESTING
In accordance with NFPA 1962, equipment must be tested a minimum of annually. Units failing any part of this test must be removed
from service, repaired and retested upon completion of the repair.
10.2 REPAIR
Factory service is available. Factory serviced equipment is repaired by experienced technicians, wet tested to original specifications,
and promptly returned. Call TFT service department at 1-800-348-2686 to troubleshoot and, if needed, directions for return. A return for
service form can also be obtained at tft.com/Support/Returning-an-Item-for-Service.
Repair parts and service procedures are available for those wishing to perform their own repairs. Task Force Tips assumes no liability for
damage to equipment or injury to personnel that is a result of user service. Contact the factory or visit the web site at tft.com for parts
lists, exploded views, test procedures and troubleshooting guides.
Performance tests shall be conducted on the equipment after a repair, or anytime a problem is reported to verify operation in accordance
with TFT test procedures. Consult factory for the procedure that corresponds to the model and serial number of the equipment. Any
equipment which fails the related test criteria should be removed from service immediately. Troubleshooting guides are available with
each test procedure or equipment can be returned to the factory for service and testing.
11.0 EXPLODED VIEW AND PARTS LISTS
Exploded views and parts lists are available at tft.com/serial-number.
WARNING
It is the responsibility of service technicians to ensure the use of appropriate protective clothing
and equipment. The chosen protective clothing and equipment must provide protection from
potential hazards users may encounter while servicing equipment. Requirements for protective
clothing and equipment are determined by the Authority Having Jurisdiction (AHJ).
CAUTION Any alterations to the product or its markings could diminish safety and constitutes a misuse of
this product.
NOTICE
All replacement parts must be obtained from the manufacturer to assure proper performance and
operation of the device.

©Copyright Task Force Tips LLC 2006-2023 16 LIX-730 July 13,2023 Rev10
TASK FORCE TIPS LLC
MADE IN USA · tft.com
3701 Innovation Way, Valparaiso, IN 46383-9327 USA
800-348-2686 · 219-462-6161 · Fax [phone]
12.0 OPERATION AND INSPECTION CHECKLIST
Monitor must be inspected for proper operation and function according to this checklist before each use. Before flowing water check:
WARNING
Equipment failing any part of the checklist is unsafe for use and must have the problem corrected
before use or being placed back into service. Operating equipment that has failed the checklist is a
misuse of this equipment.
1) There is no damage to the appliance that could impair safe
operation (e.g. dents, cracks, corrosion, missing, broken or
loose parts, damaged markings, or other defects)
• Waterway is clear of obstructions
• Gaskets are in good condition
• Hose and nozzle are securely attached.
• The pressure setting on the relief valve (if so equipped)
is set correctly
2) Hose and nozzle are securely attached.
3) Both legs are fully open.
4) All three spikes are in contact
with the ground.
5) Valve handle locks when closed
and releases.
6) Inlet coupling swivels freely
when hose is charged.
Charged Hose
7) Monitor is anchored:
See Section 6
• Tied Off (required) • Hooked Leg • Spike Hold • Weight
8) Outlet pivots smoothly in both directions
and elevation safety plunger is operational.
9) Shut-Off valve is operational.
(see section 2.2)
10) Monitor is pointed in a safe direction.
Safety
Hook
Locks
and Unlocks
