Task Force Tips TORNADO User manual

©Copyright Task Force Tips LLC 2008-2019 LIY-300 August 12, 2019 Rev17
MANUAL: TORNADO, TORNADO OSC
& TORNADO RC MONITOR
INSTRUCTIONS FOR INSTALLATION, SAFE OPERATION AND MAINTENANCE
DANGER Understand manual before use. Operation of this device without understanding the manual
and receiving proper training is a misuse of this equipment.
Obtain safety information at www.tft com/serial-number
This instruction manual is intended to familiarize fi refi ghters and maintenance personnel with the operation, servicing and safety
procedures associated with the Tornado Monitor series.
This manual should be kept available to all operating and maintenance personnel.
TASK FORCE TIPS LLC
MADE IN USA • tft.com
3701 Innovation Way, Valparaiso, IN 46383-9327 USA
800-348-2686 • 219-462-6161 • Fax [phone]
tornado
TM
tornado rc
TM
See Section 3.2.3 for
Flow/Pressure
Operating Envelope
 
TM

©Copyright Task Force Tips LLC 2008-2019 LIY-300 August 12, 2019 Rev17
2
DANGER
PERSONAL RESPONSIBILITY CODE
The member companies of FEMSA that provide emergency response
equipment and services want responders to know and understand the
following:
1. Firefi ghting and Emergency Response are inherently dangerous activities
requiring proper training in their hazards and the use of extreme caution
at all times.
2. It is your responsibility to read and understand any user’s instructions,
including purpose and limitations, provided with any piece of equipment
you may be called upon to use.
3. It is your responsibility to know that you have been properly trained in
Firefi ghting and /or Emergency Response and in the use, precautions, and
care of any equipment you may be called upon to use.
4. It is your responsibility to be in proper physical condition and to maintain
the personal skill level required to operate any equipment you may be
called upon to use.
5. It is your responsibility to know that your equipment is in operable
condition and has been maintained in accordance with the manufacturer’s
instructions.
6. Failure to follow these guidelines may result in death, burns or other
severe injury.
FEMSA
Fire and Emergency Manufactures and Service Association
P.O. Box 147, Lynnfi eld, MA 01940 • www.FEMSA.org

©Copyright Task Force Tips LLC 2008-2019 LIY-300 August 12, 2019 Rev17
3
1.0 Meaning of Safety Signal Words
2.0 Safety
3.0 General Information
3.1 Various Models and Terms
3.2 Specifications
3.2.1 Mechanical
3.2.2 Electrical
3.2.3 Safe Operating Envelope
3.3 Use With Salt Water
3.4 Inlets and Outlets
3.5 Overall Dimensions
4.0 Installation
4.1 Structural Requirements
4.2 Quick Connect Inlet Mounting and Travel Ranges
4.2.1 Travel Stops
4.3 Nozzle Installation
4.4 Pressure Gage
4.5 Handle Installation
4.6 Draining Residual Water
5.0 Operation of Tiller Monitor
5.1 Spray Trajectory Adjustment
6.0 Operation of Oscillating Monitor
6.1 Horizontal Rotation Control
6.2 Elevation Control
6.3 To Engage the Oscillating Mechanism
6.4 To Disengage the Oscillating Mechanism
6.5 Coverage Area of Oscillating Monitor
7.0 Operation of RC Monitors
8.0 Recommended Park Position
8.1 Override Knobs
9.0 Flow Characteristics
9.1 Stacked Tips Flow
9.2 Tornado Monitor and Stream Straightener Friction Loss
9.3 Stream Straighteners
9.3.1 Stream Straighteners with Stacked Tips
9.3.2 Stream Straighteners with Fog Nozzles
10.0 Drawings and Parts List
10.1 Manual Monitor
10.2 Tornado OSC
10.3 Oscillator
10.4 RC Monitor
10.5 Monitor Control Box
10.6 Motor Subassembly
10.7 RC LT Monitor
10.8 Junction Box
11.0 Warranty
12.0 Maintenance
12.1 Lubrication
12.2 Troubleshooting
12.3 Repair
13.0 Answers to Your Questions
14.0 Inspection Checklist..................................................Back Cover
Table Of Contents

©Copyright Task Force Tips LLC 2008-2019 LIY-300 August 12, 2019 Rev17
4
1.0 MEANING OF SAFETY SIGNAL WORDS
A safety related message is identifi ed by a safety alert symbol and a signal word to indicate the level of risk involved with a particular
hazard. Per ANSI standard Z535-2011, the defi nitions of the four signal words are as follows:
DANGER DANGER indicates a hazardous situation which, if not avoided, will result in death or serious
injury.
WARNING WARNING indicates a hazardous situation which, if not avoided, could result in death or serious
injury.
CAUTION CAUTION indicates a potentially hazardous situation which, if not avoided, could result in minor
or moderate injury.
NOTICE NOTICE is used to address practices not related to physical injury.
2.0 SAFETY
The operation of this monitor can be dangerous. The following must be observed at all times.
WARNING An inadequate supply of nozzle pressure and/or fl ow will cause an ineff ective stream and can
result in injury, death, or loss of property. See fl ow graphs or call 800-348-2686 for assistance.
WARNING Injury or death may occur by attempting to use a damaged monitor. Before using the monitor
inspect it for damage resulting from, but not limited to:
• Failure to drain monitor followed by exposure to freezing conditions.
See section DRAINING RESIDUAL WATER for instructions.
• Exposure of monitor to temperatures in excess of 160 degrees F.
• Missing parts, physical abuse, exposure to severe chemicals.
• Deformed or cracked fl anges damaged as a result of improper installation.
- Excessive bolt torque
- Wrong tightening sequence
WARNING Injury can result from an inadequately supported monitor. The monitor mount must be capable of
supporting 400 lbs (180 kg) of nozzle reaction force.
WARNING The stream exiting a monitor is very powerful and capable of causing injury and property damage.
Make sure the monitor is securely attached to the base and pointing in a safe direction before
water to the monitor is turned on. Use care in directing the stream.
WARNING The monitor may be damaged if frozen while containing suffi cient amounts of water. Such damage
may be diffi cult to detect visually and can lead to possible injury or death. Any time the monitor is
subject to possible damage from freezing, it must be hydrostatically tested by qualifi ed personnel
before being considered safe for use.
WARNING Do not attempt to modify the oscillating mechanism to fi t any other monitor. To do so will cause
the reaction force of the nozzle to be misaligned with the center of rotation. The monitor may spin
very fast and could cause injury or death.
WARNING Keep hands and fi ngers away from moving parts of the oscillating unit when water is fl owing.
There are moving parts that can pinch fi ngers and hands.
WARNING This equipment is intended for use by trained personnel for fi refi ghting. Their use for other
purposes may involve hazards not addressed by this manual. Seek appropriate guidance and
training to reduce risk of injury.
CAUTION The electric monitor may be remotely operated. The electric drives are current limited but may
still produce enough force to cause injury. Keep hands and fi ngers away from pinch points on
the monitor.
CAUTION Do not use the manual override knobs while the electric controls are in operation. The electric
drives produce enough torque to cause injury.
CAUTION Maximum fl ow and pressure is 500 gpm (1900 l/min) and 200 psi (14 bar). Damage or injury may
result if the monitor is operated beyond these limits.
CAUTION On many vehicle installations, the monitor is the highest point on the apparatus. Be sure there
is suffi cient clearance to safely pass under any doors or overhead obstructions. Always check
parked position of the monitor before moving.
NOTICE To prevent mechanical damage, do not drop or throw equipment.

©Copyright Task Force Tips LLC 2008-2019 LIY-300 August 12, 2019 Rev17
5
3.0 GENERAL INFORMATION
The Tornado monitor is a 2 ¼ inch waterway, 500 gpm maximum monitor. It is available in a manually operated model as well as an
electric remote or joystick controlled model, and hydraulically oscillating version. The electric remote model is known as the Tornado
RC, the joystick model is known as the Tornado LT, and the hydraulically oscillating version is known as the Tornado OSC.
3.1 VARIOUS MODELS AND TERMS
The Tornado monitor is available in several diff erent models and inlet connections. Basic body styles are shown below, along with
some various parts and controls.
OUTLET
TILLER BAR
TURNING
HORIZONTAL ROTATION
LOCKING KNOB
VANE
2-1/2” NH
COUPLING
ELEVATION
LOCKING
KNOB
INLET FLANGE
MODEL & SERIAL
NUMBER ON LABEL
OSCILLATION
UNIT
GREASE FITTING
FOR HORIZONTAL ROTATION
OSCILLATION
ENGAGE KNOB
OSCILLATION
SWEEP SETTING
Fig. 3.1A
Manual Tornado Monitor Part Identifi cation
Fig. 3.1B
Tornado OSC Monitor Part Identifi cation
2 1/2" NH
COUPLING
WITH LOCK
MANUAL OVERRIDE KNOB
FOR ELEVATION
ELEVATION TRAVEL STOP
SEE SECTION 4.2
HORIZONTAL ROTATION
TRAVEL STOP
SEE SECTION 4.2
ELECTRIC NOZZLE
CONNECTION
ELECTRICAL
CONNECTOR
POWER AND
COMMUNICATION
CORD
QUICK CONNECT INLET
(2 1/2" ANSI 150 FLANGE SHOWN)
COUPLING LOCK
RELEASE PULLPIN
ELEVATION
GREASE FITTING
ELECTRIC
NOZZLE
CONNECTION
INLET FLANGE
Fig. 3.1C
Tornado RC Monitor Part Identifi cation
Fig 3.1D
Tornado LT Monitor Part Identifi cation

©Copyright Task Force Tips LLC 2008-2019 LIY-300 August 12, 2019 Rev17
6
3.2 SPECIFICATIONS
3.2.1 MECHANICAL
Manual Electric OSC
US METRIC US METRIC US METRIC
Weight 12 lbs 5.5 kg 25 lbs 11.4 kg 27 lbs 12.2 kg
Min. Flow Area 8.3 in2 24.5 cm28.3 in2 24.5 cm28.3 in224.5 cm2
Max Flow 500 gpm 1900 l/min 500 gpm 1900 l/min 500 gpm 1900 l/min
Max Operating Pressure 200 psi 14 bar 200 psi 14 bar 200 psi 14 bar
Horizontal Travel Range 360° Continuous 370° (185° left and right) 360° Continuous
Standard Inlets 2.5”-7.5 NH Female
2.0”-11 BSP Female
2.0”-11.5 NPT Female
3.0”-8 NPT Female
2.5”-11 BSP Female
2.5” ANSI 150 Flange
3.0 ANSI 150 Flange
2.5”-8 NPT Female
TFT Code-RLF (fi ts Extend-A-Gun RC3)
2.5 ANSI 150 Flange
3.0 ANSI 150 Flange
4.0 ANSI 150/DN100PN 16
Standard Outlets 2.5”-7.5 NH Male
2.5”-11 BSP Male
1.5”-9 NH Male
2.5” Special Male
2.5”-7.5 NH Male
2.5”-11 BSP Male
2.5”-8 NPSH Male
2.5” Special Male
Materials Used ANSI A356.0-T6 Aluminum, Stainless, Nylon
Maximum Torque Elevation 35 ft•lbs 50 n•m
Maximum Torque Horizontal 35 ft•lbs 50 n•m
Speed Elevation 25 deg/sec
Speed Horizontal 25 deg/sec
3.2.2 ELECTRICAL
Further specifi cations for Tornado RC models are shown the Remote Control (RC) Monitor Electrical Controls Supplemental
Instructions (LIY-500).

©Copyright Task Force Tips LLC 2008-2019 LIY-300 August 12, 2019 Rev17
7
3.2.3 SAFE OPERATING ENVELOPE
Tornado Operating Envelope
Flow (gpm)
Monitor Inlet Pressure (psi)
Flow (lpm)
Monitor Inlet Pressure (bar)
0
25
50
75
100
125
150
175
200
225
250
0 100 200 300 400 500 600 700 800 900
0
4
8
12
16
0 500 1000 1500 2000 2500 3000
Nozzle B Inlet
Pressure
Nozzle A Inlet
Pressure
Maximum Nozzle
Inlet Pressure Maximum Monitor
Inlet Pressure
Monitor
Loss
Nozzle C Inlet
Pressure
Nozzle A fl ows 250 gpm (950 l/min) at 100 psi (7 bar), K factor = 25
Nozzle B fl ows 500 gpm (1900 l/min) at 100 psi (7 bar), K factor = 50
Nozzle C fl ows 750 gpm (2900 l/min) at 100 psi (7 bar), K factor = 75
Tornado OSC Operating Envelope
Flow (gpm)
Monitor Inlet Pressure (psi)
Flow (lpm)
Monitor Inlet Pressure (bar)
0
25
50
75
100
125
150
175
200
225
250
0 100 200 300 400 500 600 700 800 900
0
4
8
12
16
0 500 1000 1500 2000 2500 3000
Nozzle B Inlet
Pressure
Nozzle A Inlet
Pressure
Maximum Nozzle
Inlet Pressure Maximum Monitor
Inlet Pressure
Monitor
Loss
Nozzle C Inlet
Pressure
Nozzle A fl ows 250 gpm (950 l/min) at 100 psi (7 bar), K factor = 25
Nozzle B fl ows 500 gpm (1900 l/min) at 100 psi (7 bar), K factor = 50
Nozzle C fl ows 750 gpm (2900 l/min) at 100 psi (7 bar), K factor = 75

©Copyright Task Force Tips LLC 2008-2019 LIY-300 August 12, 2019 Rev17
8
3.3 USE WITH SALT WATER
Use with salt water is permissible provided the monitor is thoroughly cleaned with fresh water after each use. The service life of the
monitor may be shortened due to the eff ects of corrosion and is not covered under warranty.
3.4 INLET AND OUTLET OPTIONS
Available inlets and outlets are shown below and should be specifi ed at time of order.
2.5" NH
MALE
(Y2320ANJ)
1.5" NH
MALE
(Y2325ANF)
2.5" BSP
MALE
(Y2320ABJ)
TORNADO RC
MODEL
TORNADO
TILLER BAR
MODEL INLET COUPLING
2.5-7.5 NH
2.5" BSP
FEMALE
(Y2405A)
2.0" BSP
FEMALE
(Y2425A)
2.5" ANSI 150
(Y2430A)
3.0" ANSI 150
(Y2431)
2.5" NPT
FEMALE
(Y2400A)
2.0" NPT
FEMALE
(Y2420A)
3.0" NPT
FEMALE
(Y2403A)
CODE-RLF
(Y2413A)
2.5" BSP
MALE
(Y2325ABF)
2.5" NH
MALE
(Y2320ANJ)
1.5" NH
MALE
(Y2325ANF)
2.5" BSP
MALE
(Y2320ABJ)
2.5" ANSI 150
(Y2418)
1.5" BSP
MALE
(Y2325ABF)
4.0" ANSI 150/DN100 PN16
(Y2417)
3.0" ANSI 150
(Y2412)
TORNADO OSC
MODEL
2.5" BSP
MALE
(XX020B)
2.5" NH
MALE
(XX020N)
2.5" ANSI 150
(Y2418)
Fig 3.4
Inlets and Outlets

©Copyright Task Force Tips LLC 2008-2019 LIY-300 August 12, 2019 Rev17
9
3.5 OVERALL DIMENSIONS
5.50
(140 mm)
8.25
(210 mm)
360°
CONTINUOUS
18.00
(460 mm)
14.00
(360 mm)
12.40
(315 mm)
90°
45°
See table below for additional height
from Inlet Fitting
17.80
(452 mm)
See table below for additional height
from Inlet Fitting
13.70
(348 mm)
90°
45°
8.25
(210 mm)
185° LEFT
185° RIGHT
Fig 3.5a
Manual Tornado Monitor Dimensions
Fig 3.5b
Electric Tornado RC Monitor Dimensions
MODEL INLET FITTING
TYPE
ADDITIONAL
HEIGHT
Y2-*1*A 2-1/2” - 7.5 NH FEMALE
(no inlet fi tting)
0.00"
0 mm
Y2-*2*A 2-1/2” - 11 BSP FEMALE 2.00"
51 mm
Y2-*3*A 2.0” - 11.5 BSP FEMALE 1.50"
38 mm
Y2-*6*A 2.5” ANSI 150 FLANGE 2.00"
51 mm
Y2-*0*A 3.0” ANSI 150 FLANGE 2.10”
53 mm
Y2-*7*A 2-1/2” - 8 NPT FEMALE 2.00"
51 mm
Y2-*8*A 2.0” - 11.5 NPT FEMALE 1.50”
38 mm
Y2-*9*A 3.0” - 8 NPT FEMALE 2.44”
62 mm
Y2-*L*A TFT CODE-RLF
(fi ts Extend-A-Gun RC3)
2.00”
51 mm

©Copyright Task Force Tips LLC 2008-2019 LIY-300 August 12, 2019 Rev17
10
7.00” [178mm]
OSC MAX.
8.20”
[208mm]
360°
CONTINUOUS
45°
90°
16.2”
[411mm] 12.10”
[306mm]
13.80”
[351mm]
90°
45°
185° LEFT
185° RIGHT
[158mm]
6.20
[153mm]
6.00
[425mm]
16.70
[315mm]
12.40
Fig 3.5c
Tornado OSC Monitor Dimensions
Fig 3.5d
Electric Tornado RC LT Monitor Dimensions
MODEL INLET FITTING
TYPE
ADDITIONAL
HEIGHT
Y2-SD*a 2.5” ANSI 150 FLANGE 0.60”
15 mm
Y2-SF*A 3.0” ANSI 150 FLANGE 0.00”
0 mm
Y2-SG*A 4.0” ANSI 150 FLANGE
DN100 PN16
0.16"
4 mm

©Copyright Task Force Tips LLC 2008-2019 LIY-300 August 12, 2019 Rev17
11
4.0 INSTALLATION
See Remote Control (RC) Monitor Electrical Controls Supplemental Instructions (LIY-500) For Tornado RC models.
4.1 STRUCTURAL REQUIREMENTS
The structure that the Tornado Monitor is mounted to must withstand the internal pressure of the monitor as well as shear and
bending forces due to nozzle reaction. Nozzle reaction can be as high as 400 lbs (180 kg) (500 gpm at 200 psi).
For fl anged connections the use of fl at fl anges without raised faces is recommended. Use a ring gasket as defi ned in ASME 16.21
or ISO 7483. Tighten fl ange bolts in an alternating sequence as shown in fi gure 4.1A. Tighten sequentially each bolt or stud three
times with 30%, then 60%, and fi nally 100% of the specifi ed torque in fi gure 4.1B. Tighten to 76-80 ft-lb (100-110 Newton-Meters).
1
3
2
4
1
5
3
7
2
6
4
8
Tighten Sequentially Each Bolt Three Times
Fig 4.1A Flange Bolt Tightening Sequence
FLANGE TYPE OUTSIDE
DIAMETER
THICKNESS BOLT
HOLE
CIRCLE
# OF
BOLTS
SIZE OF
BOLTS
TORQUE ON
BOLTS
in mm in mm in mm in mm ft-lb N-m
2.5 ANSI 150 6.9 175 0.98 25 5.5 140 4 5/8 16 76-80 100-110
3” ANSI 125/150-DN80 PN20 7.5 190 0.75 20 6.0 152.5 4 5/8 16 76-80 100-110
4” ANSI 150-DN100 PN20 9.0 230 0.94 23 7.5 190 8 5/8 16 76-80 100-110
DN80, PN16 FLANGE 7.9 200 0.87 22 6.3 160 8 5/8 16 76-80 100-110
DN100, PN16 FLANGE 8.7 220 0.87 22 7.1 180 8 5/8 16 76-80 100-110
WARNING Injury can result from an inadequately supported monitor. The monitor mount must be capable
of supporting the nozzle reaction force which can be as high as 400 lbs (180 kg). Flanges and
pipe made from plastic are inadequate for monitor mounting and must not be used. This monitor
is not recommended for portable use.
4.2 QUICK CONNECT INLET MOUNTING AND TRAVEL RANGES
The Tornado Monitor is available with various inlet fi ttings. These Inlet Adapters must be oriented upon installation so the Tornado will
point in the desired direction. Figure 4.2A shows examples of Inlet Adaptors and the location of a “Straight Ahead Reference Mark”.
This fi gure also gives some information about securing the Tornado to the Inlet Adapter. Travel ranges relative to the Straight Ahead
Reference Mark are shown in Figure 4.2B. Figure 4.2C gives the location of the “Stop Bolts”, which are used to limit the travel.
A rotational lock is included on quick connect couplings on RC models. The locking pin also holds the coupling up and out of the
way while orienting the monitor to engage the internal ear into the slot on the adaptor. Hold the pin out, push the coupling up and the
release pin before installing monitor on the adaptor. Once the monitor is properly aligned on the adaptor, hold the pin out while sliding
the coupling down to the adaptor. Rotate the coupling until it is tight. The coupling may become suffi ciently tight before reaching the
next detent position. It is not necessary to over tighten the coupling if the pull pin is between detent positions. Do not use the pull pin
as a lever to tighten or loosen the coupling.

©Copyright Task Force Tips LLC 2008-2019 LIY-300 August 12, 2019 Rev17
12
2 1/2" NH Coupling
ON TORNADO INLET WITH LOCK
(TILLER VERSION DOES NOT HAVE LOCK)
INTERNAL EAR ON TORNADO RC
ENGAGES THIS SLOT ON THE ADAPTER
TO GIVE ROTATIONAL ALIGNMENT.
STRAIGHT AHEAD REFERENCE MARK
IMPORTANT: INSTALL SO STRAIGHT
AHEAD REFERENCE MARK IS FACING
DESIRED DIRECTION.
SEE FIGURE 4.2B.
FLANGED
INLET ADAPTER
FEMALE THREADED
INLET ADAPTER
Fig 4.2A
Inlet Adapter and Straight Ahead Reference Mark
90° WITH
STOP BOLT
39° WITH
STOP BOLT
45° BELOW
90° ABOVE
Fig 4.2B Travel Ranges Relative to
Straight Ahead Reference Mark

©Copyright Task Force Tips LLC 2008-2019 LIY-300 August 12, 2019 Rev17
13
4.3 NOZZLE INSTALLATION
The nozzle is simply screwed onto the monitor’s exit threads. If the nozzle is installed on a Tornado RC (with electric motors) assure
that the nozzle’s coupling does not make contact with the horizontal drive motor housing and actuator when the monitor is in its
lowest elevation position.
CAUTION The nozzle threads must match the threads of the Tornado monitor in both size and type.
Mismatched or damaged threads may cause the nozzle to leak or uncouple under pressure and
could cause injury.
CAUTION Do not connect aluminum to brass or brass to aluminum. Dissimilar metals coupled together
can cause galvanic corrosion that will freeze the threaded joint or cause complete loss of thread
engagement. If dissimilar metals must be coupled together, the eff ects of corrosion can be greatly
delayed by various coatings on the metal such as powder paint, hard anodizing, or silicone grease.
4.4 PRESSURE GAGE PORT
There is a ¼” NPT female threaded hole on the back of the monitor and the exit elbow.The holes are plugged from the factory. If
a pressure gage is desired, unscrew the plug and install the gage using pipe sealant. Make sure the gage does not interfere with
operation.
4.5 HANDLE INSTALLATION
Mounting Screw
The tiller handle is shipped loose from the monitor and must be
installed to complete the installation process. When installing the
tiller handle, be sure to coat the threads of the mounting screw
with the Loctite supplied in the hardware packet.
Fig 4.5 Tiller Handle Installation
4.2.1 TRAVEL STOPS
Stop bolts and adjustment disks can be installed to limit the travel of the monitor in either travel direction. Instructions on how to install
the stop bolts and adjustment disks are shown below.
ADJUSTMENT DISK, #Y3146
INSTALL ON THIS SIDE OF
STOP BOLT TO REDUCE DOWNWARD
TRAVEL BY APPROX 13° FOR EACH
DISK INSTALLED. INSTALL DISKS
ON OTHER SIDE TO REDUCE
UPWARD TRAVEL
ADJUSTMENT DISK, #Y3146
INSTALL ON THIS SIDE OF STOP BOLT TO
REDUCE TRAVEL TO RIGHT BY APPROX 13°
FOR EACH DISK INSTALLED. INSTALL DISKS
ON OTHER SIDE TO REDUCE TRAVEL TO LEFT.
INSTALL STOP BOLT #Y4145
HERE TO LIMIT ELEVATION
TRAVEL TO 90° ABOVE AND
39° BELOW ON RC MODEL.
INSTALL STOP BOLT #Y4145 HERE
TO LIMIT HORIZONTAL TRAVEL TO
90° LEFT AND 90° RIGHT ON RC MODEL.
REMOVE #VT37-24SH500 SOCKET HEAD
CAP SCREW OR #VT37-24SS375
SET SCREW IF NECESSARY.
Fig 4.2.1 Stop Bolt Use
Remove Set Screw And Install Stop
Bolt To Obtain Desired Travel Limits.
RC Model With No Stop Bolts Installed
Has 185° Left And Right Travel Limits.
Tiller Model Has Continuous 360°
Horizontal Rotation. Stop Bolts Are Not
Used On Tiller Model.

©Copyright Task Force Tips LLC 2008-2019 LIY-300 August 12, 2019 Rev17
14
4.6 DRAINING RESIDUAL WATER
There is no drain on the Tornado Monitor itself. A drain valve should be installed on the piping to which the monitor is attached.
WARNING All monitors, valves and standpipes exposed to freezing conditions must be drained immediately
following use to prevent damage. To drain a standpipe, a drainage port must be opened
underground below the frost depth to keep water out of the standpipe until the next use.
5.0 OPERATION OF TILLER MONITORS
5.1 SPRAY TRAJECTORY ADJUSTMENT
On the Tiller Bar model the horizontal rotation is changed by pushing or pulling horizontally on the Tiller Handle. Twisting the Rotation
Locking Knob clockwise will increase the drag on the swivel joint to “lock” the monitor in a particular direction.
CAUTION Injury can result from the monitor changing direction due to an off center nozzle reaction. An off
center nozzle reaction may be caused by debris in the nozzle causing an asymmetrical stream.
Always keep the rotation lock tight when not rotating the monitor. Always keep one hand on
the tiller handle when loosening the locking knob. Where continuous 360 degree rotation of the
monitor is not needed it is recommended that the Horizontal Rotation Stop Bolts be installed to
reduce any chance of the monitor spinning due to an off center nozzle reaction caused by debris
trapped in the nozzle.
6.0 OPERATION OF OSCILLATING MONITORS
6.1 HORIZONTAL ROTATION CONTROL
A handwheel controls the monitor’s horizontal rotation direction. Clockwise rotation of the handwheel moves the nozzle to the left and
counter-clockwise rotation to the right. Approximately 8.5 turns of the handwheel will give a 90 degree change in horizontal rotation
direction.
6.2 ELEVATION CONTROL
A handwheel controls the monitor’s elevation direction. Clockwise rotation of the handwheel raises the elevation and counterclockwise
lowers it. About 13 turns of the handwheel will give the complete 135 degree elevation travel range of the monitor.
WARNING Do not attempt to modify the oscillating mechanism to fi t any other monitor. To do so will cause
the reaction force of the nozzle to be misaligned with the center of rotation. The monitor may spin
very fast and could cause injury or death.
6.3 TO ENGAGE THE OSCILLATING MECHANISM
If the nozzle moves freely left to right by hand, the oscillating
mechanism is not engaged. To engage, ensure the black knob on
the side of the oscillator is released, and move the nozzle from one
side to the other until the black knob clicks into the groove on the
spring canister. The minimum fl ow required to oscillate is 175 gpm
(650 l/min).
The oscillating mechanism is equipped with a safety device that
prevents damage to the gear train in case the oscillator comes in
contact with an object. The safety device will allow the mechanism
to continue to oscillate the portion of its sweep path not blocked by
the obstruction. The safety mechanism also allows the oscillating
mechanism to sweep vertically without disengaging the oscillator.
Once obstruction is removed, sweep pattern will return to normal.
PULL & TURN KNOB
TO STOP OSCILLATION
TURN & RELEASE KNOB
TO START OSCILLATION
OSCILLATION CONTROL
NOTICE The ends of the covered area will receive more water than the center because the oscillator must
slow down, stop, and reverse direction at the end of each sweep. If the center area of coverage
needs more cooling, it may be necessary to occasionally narrow the area of coverage or direct
the stream manually.
6.4 TO DISENGAGE THE OSCILLATING MECHANISM
To operate the oscillating monitor manually, pull then twist the black knob located on the side of the monitor. Twisting will lock the knob
in the disengaged position. The crank, rod, and spring canister will continue to move. Move the nozzle to the desired position by hand.

©Copyright Task Force Tips LLC 2008-2019 LIY-300 August 12, 2019 Rev17
15
6.5 COVERAGE AREA OF OSCILLATING MONITOR
To adjust the area of coverage, refer to fi gure 6.3.
Engage the oscillating mechanism once the desired
angle has been set.
Oscillation speed: The chart shows how many times
per minute the oscillator makes one complete cycle
as a function of fl ow. The higher the fl ow, the faster
it oscillates.
For nozzle reach, refer to the operating manual
for the specifi c nozzle. For reach with oscillation,
subtract 20% from the distance
200' / 61m
175' / 53m
150' / 45m
125' / 38m
100' / 30m
75' / 22m
50' / 15m
0'
20 DEGREES
30 DEGREES
40 DEGREES
WIDTH OF COVERAGE
150' / 45m
125' / 38m
100' / 30m
75' / 23m
50' / 15m
COVERAGE AREA OF OSCILLATING MONITOR
DISTANCE
TOP VIEW
30°
40°
20°
SLIDE TO
CHANGE
ANGLE
LIFT TO CHANGE
SWEEP SETTING
2
1
SWEEP
Fig. 6.3 Adjusting Sweep Angle
APPROXIMATE
CYCLES/MIN
GPM L/MIN
8 175 650
13 250 1000
21 375 1500
28 500 2000
OSCILLATION SPEED
NOTICE The type of nozzle and fl ow pressure are critical to the coverage area. The graph shows coverage
area based on the movement capability of the oscillating mechanism. Actual coverage will
depend on fl ow, pressure, type of nozzle, angle of fog pattern and wind conditions.
7.0 OPERATION OF RC MONITORS
See Remote Control (RC) Monitor Electrical Controls Supplemental Instructions LIY-500 for operation of the Tornado RC Monitors.

©Copyright Task Force Tips LLC 2008-2019 LIY-300 August 12, 2019 Rev17
16
8.0 RECOMMENDED PARK POSITION
For truck mounted applications it is recommended that the monitor be parked in a position such that the monitor’s nozzle rests
against a bracket or support surface. If a support surface is not available, run the elevation against one of its travel stops to take some
of the backlash out of the gear drive. This will minimize bouncing of the nozzle when the apparatus is traveling. Always be sure the
monitor is properly parked before moving the truck and know the overall height to avoid damage from overhead obstructions such
as doors or bridges.
See Remote Control (RC) Monitor Electrical Controls Supplemental Instructions (LIY-500) for information on programming DEPLOY,
OSCILLATE and PARK position Tornado RC models.
8.1 OVERRIDE KNOBS
11/16” (18mm) HEX
In the event of electrical system failure on the monitor or fi re truck
the Tornado RC Monitor is factory supplied with knobs so the
monitor may be manually operated. To make the Tornado RC more
compact the manual override knobs may be removed. The drive
shafts have a hex so an 11/16” wrench or socket may be used for
manual override. The wrenching hexes are shown in fi gure 8.1.
Fig 8.1
Wrenching Hexes on Drive Shafts
9.0 FLOW CHARACTERISTICS
9.1 STACKED TIPS FLOW
NOZZLE INLET PRESSURE
NOZZLE
DIAMETER
50 PSI 80 PSI 100 PSI 150 PSI 175 PSI
FLOW
(GPM)
REACTION
(LBS)
FLOW
(GPM)
REACTION
(LBS)
FLOW
(GPM)
REACTION
(LBS)
FLOW
(GPM)
REACTION
(LBS)
FLOW
(GPM)
REACTION
(LBS)
1.0 INCH 210 80 270 120 300 150 360 230 390 260
1-1/4 INCH 330 120 410 190 460 230 ————
1-1/2 INCH 470 170 — — — —————
FLOW EXCEEDS RATING OF TORNADO MONITOR
NOZZLE INLET PRESSURE
NOZZLE
DIAMETER
4 BAR 6 BAR 8 BAR 10 BAR 12 BAR
FLOW
(l/min)
REACTION
(KG)
FLOW
(l/min)
REACTION
(KG)
FLOW
(l/min)
REACTION
(KG)
FLOW
(l/min)
REACTION
(KG)
FLOW
(l/min)
REACTION
(KG)
25 MM 830 40 1000 60 1200 80 1300 100 1400 120
32 MM 1300 70 1700 100 1900 130 ————
38 MM 1900 90 — — — —————
FLOW EXCEEDS RATING OF TORNADO MONITOR
Fig. 9.1
Stacked Tips Flow Table

©Copyright Task Force Tips LLC 2008-2019 LIY-300 August 12, 2019 Rev17
17
9.2 TORNADO MONITOR AND STREAM STRAIGHTENER FRICTION LOSS
See fi gure 8.2 for Tornado Monitor, Tornado OSC Monitor, and Task Force Tips 5 and 10 inch Stream Straightener friction loss.
0
0.3
0.6
0.9
1.2
1.5
1.8
2.1
2.4
0 200 400 600 800 1000 1200 1400 1600 1800
0
3
6
9
12
15
18
21
24
27
30
33
0 100 200 300 400 500
LOSS (BAR)
FLOW (LPM)
LOSS (PSI)
FLOW (GPM)
TORNADO MONITOR
19 PSI LOSS AT 500 GPM
TORNADO MONITOR
7 PSI LOSS AT 300 GPM
5" OR 10" STREAM STRAIGHTENER
3 PSI LOSS AT 500 GPM
TORNADO OSC MONITOR
31 PSI LOSS AT 500 GPM
TORNADO OSC MONITOR
11 PSI LOSS AT 300 GPM
Fig 9.2
Friction Loss
9.3 STREAM STRAIGHTENERS
9.3.1 STREAM STRAIGHTENERS WITH STACKED TIPS
Turbulence though the Tornado Monitor is very low but stream quality and reach can be improved with the use of the integral stream
straightener on the TFT stacked tip nozzle. See fi gure 8.2 for the TFT stream straightener friction loss.
9.3.2 STREAM STRAIGHTENERS WITH FOG NOZZLES
When using a fog nozzle for fl ows below 300 gpm (1,100 l/min), it is recommended that no stream straightener be used since the
fog nozzle’s fl ow path serves as a stream straightener. Above 300 gpm (1,100 l/min), TFT’s 5 inch Stream Straightener will generally
improve a fog nozzle’s stream.

©Copyright Task Force Tips LLC 2008-2019 LIY-300 August 12, 2019 Rev17
18
10.0 DRAWING & PARTS LIST
10.1 MANUAL MONITOR
2
4
5
10
11
12
13
14 15
16 17
20
13
30
31
32
33
17
16
15
14
32
30
31
22
23
34
35
21
26 25 24
24
7
3
6
7
1

©Copyright Task Force Tips LLC 2008-2019 LIY-300 August 12, 2019 Rev17
19
ITEM # DESCRIPTION QTY PART #
1 QUICK CONNECT 2.5"NPTF ALUMINUM 1 Y2400A
QUICK CONNECT 2.5"BSPF ALUMINUM Y2405A
QUICK CONNECT 2.0"NPTF ALUMINUM Y2420A
QUICK CONNECT 2.0"BSPF ALUMINUM Y2425A
QUICK CONNECT 2.5" ANSI 150 FLANGE ALUMINUM Y2430A
2 GASKET - 2.5" HOSE COUPLING 1 V3190
3 COUPLING 2.5"NH 1 M307N
4 3/16" SS BALL 48 V2120
5 1/4-28 X 1/2 SOCKET SET SCREW 1 VT25-28SS500
6 BASE TILLER ALUMINUM 1 Y2410A
7 O-RING-233 2 VO-233
10 1/4-28 X 1/2 BUTTON HEAD SCREW 2 VT25-28BH500
11 NAME LABEL: TORNADO MONITOR 1 Y2124
12 LABEL BRACKET 1 Y2120
13 3/8-24 X 3/8 DOG POINT 2 H515
14 WEAR DISC 2 Y4191
15 LOCKING BOLT 2 Y2318
16 1/4-20 X 1/2 BUTTON HEAD SCREW 4 VT25-20BH500
17 LOCKING KNOB 2 Z245
20 3/8-16 X 1 SOCKET HEAD SCREW 1 VT37-16SH1.0
21 THREAD ADAPTER 2.5"NHM 1 Y2320ANJ
THREAD ADAPTER 1.5"NHM Y2320ANF
THREAD ADAPTER 2.5"BSPM Y2320ABJ
22 TILLER EXIT ELBOW ALUMINUM 1 Y2315A
23 TILLER HANDLE 1 Y2316
24 PEG 2 X362
25 3/8-16 X 1 3/4 STUD 1 VT37-16SD1.7
26 HANDLE BUSHING 1 Y2317
30 3/8-24 X 3/8 SOCKET SET SCREW 4 VT37-24SS375
31 5/16" BALL TORLON 120 VB.312TO
32 1/4-28 X 3/16 SOCKET SET SCREW 2 VT25-28SS187
33 LOWER SECTION TILLER ALUMINUM 1 Y2115A
34 O-RING-145 1 VO-145
35 1/4-20 X 5/16 BUTTON HEAD SCREW 2 VT25-20BH312

©Copyright Task Force Tips LLC 2008-2019 LIY-300 August 12, 2019 Rev17
20
10.2 TORNADO OSC
A
27
29
25
2
9
13 14
8
9
4
5
7
6
1
2
3
12 11
21
22
19 18
20
16
17
13
14
15
24
26
10
10
23
28
