Task Force Tips EDUCTOR 125 Series Programming manual

©Copyright Task Force Tips LLC 2010-2021 1 LIU-330 February 15, 2021 Rev09
TASK FORCE TIPS LLC
MADE IN USA · tft.com
3701 Innovation Way, Valparaiso, IN 46383-9327 USA
800-348-2686 · 219-462-6161 · Fax [phone]
G-Force
INSTRUCTION FOR INSTALLATION, OPERATION, AND MAINTENANCE
EDUCTOR
125 SERIES IN-LINE
DANGER
Understand manual before use. Operation of this device without understanding the manual and
receiving proper training is a misuse of this equipment. Obtain safety information at tft.com/
serial-number.
This equipment is intended for use by trained and qualified emergency services personnel for
firefighting. All personnel using this equipment shall have completed a course of education
approved by the Authority Having Jurisdiction (AHJ).
This instruction manual is intended to familiarize firefighters and maintenance personnel with the
operation, servicing, and safety procedures associated with this product. This manual should be
kept available to all operating and maintenance personnel.
Inlet Pressure:
200 psi (13.8 bar)
160 psi (11 bar)
145 psi (10 bar)
Maximum
Back Pressure:
130 psi (9 bar)
100 psi (6.9 bar)
95 psi (6.5 bar)
Concentration Settings:
OFF, 1/4%, 1/2%, 1%, 3%, 6%
Models:
60 gpm (225 L/min)
95 gpm (263 L/min)
120 gpm (450 L/min)
125 gpm (475 L/min)

©Copyright Task Force Tips LLC 2010-2021 2 LIU-330 February 15, 2021 Rev09
TABLE OF CONTENTS
1.0 MEANING OF SAFETY SIGNAL WORDS
2.0 SAFETY
3.0 GENERAL INFORMATION
3.1 USE WITH SALT WATER
3.2 VARIOUS MODELS AND TERMS
4.0 OPERATING INSTRUCTIONS
4.1 CLEANING INSTRUCTIONS
5.0 USE WITH FOAM
5.1 FOAM SELECTION
5.2 FOAM ATTACHMENT OPTIONS
5.3 FOAM CONSUMPTION
5.4 FOAM SUPPLY LOGISTICS
6.0 MAXIMUM HOSE LAY
7.0 NOZZLE SELECTION
7.1 NOZZLE COMPATIBILITY
8.0 WARRANTY
9.0 MAINTENANCE
9.1 SERVICE TESTING
9.2 REPAIR
10.0 TROUBLE SHOOTING
11.0 EXPLODED VIEWS AND PARTS LISTS
12.0 OPERATION AND INSPECTION CHECKLIST
LIA-025 Foam Aspirator Manual
SUPPORTING MATERIALS
The following documents contain supporting safety
and operating information pertaining to the equipment
described in this manual.

©Copyright Task Force Tips LLC 2010-2021 3 LIU-330 February 15, 2021 Rev09
The member companies of FEMSA that provide emergency
response equipment and services want responders to know and
understand the following:
1. Firefighting and Emergency Response are inherently
dangerous activities requiring proper training in their hazards
and the use of extreme caution at all times.
2. IT IS YOUR RESPONSIBILITY to read and understand
any user’s instructions, including purpose and limitations,
provided with any piece of equipment you may be called on
to use.
3. IT IS YOUR RESPONSIBILITY to know that you have been
properly trained in Firefighting and/or Emergency Response
and in the use, precautions, and care of any equipment you
may be called upon to use.
4. IT IS YOUR RESPONSIBILITY to be in proper physical
condition and to maintain the personal skill level required to
operate any equipment you may be called upon to use.
5. IT IS YOUR RESPONSIBILITY to know that your equipment is
in operable condition and has been maintained in accordance
with the manufacturer’s instructions.
6. Failure to follow these guidelines may result in death, burns or
other severe injury.
Fire and Emergency Manufacturers and Service Association, Inc.
PO Box 147, Lynnfield, MA 01940 • www.FEMSA.org
© 2020 FEMSA. All Rights Reserved.
PERSONAL RESPONSIBILITY CODE
DANGER

©Copyright Task Force Tips LLC 2010-2021 4 LIU-330 February 15, 2021 Rev09
1.0 MEANING OF SAFETY SIGNAL WORDS
A safety related message is identified by a safety alert symbol and a signal word to indicate the level of risk involved with a particular
hazard. Per ANSI Z535.6, the definitions of the four signal words are as follows:
2.0 SAFETY
DANGER
DANGER indicates a hazardous situation which, if not avoided, will result in death or serious injury.
WARNING
WARNING indicates a hazardous situation which, if not avoided, could result in death or serious
injury.
CAUTION CAUTION indicates a potentially hazardous situation which, if not avoided, could result in minor
or moderate injury.
NOTICE
NOTICE is used to address practices not related to physical injury.
DANGER
Lack of foam can place operator at risk of injury or death. Establish foam flow and adequate supply
of concentrate for the task before advancing into hazardous situations.
WARNING
This equipment is intended for use by trained personnel for firefighting. Use of this equipment for
other purposes may involve hazards not addressed by this manual. Seek appropriate guidance and
training to reduce risk of injury.
WARNING
Improper use of foam or using the wrong type of foam can result in illness, injury, or damage to the
environment. Follow foam manufacturer’s instructions and fire service training as directed by the
AHJ.
WARNING
For Class B fires, lack of foam or interruption in the foam stream can cause a break in the foam
blanket and greatly increase the risk of injury or death. Follow procedures established by the AHJ
for the specific fuel and conditions.
WARNING
Equipment may be damaged if frozen while containing significant amounts of water. Such damage
may be difficult to detect visually. Subsequent pressurization can lead to injury or death. Any time
the equipment is subject to possible damage due to freezing, it must be tested and approved for
use by qualified personnel before being considered safe for use.
NOTICE
To prevent mechanical damage, do not drop or throw equipment.

©Copyright Task Force Tips LLC 2010-2021 5 LIU-330 February 15, 2021 Rev09
3.0 GENERAL INFORMATION
TFT’s 125 Series Eductors can be used with 1/4% or 1/2% Class A foam concentrate for wildland, rural, and urban fire suppression on
Class A fuels (wood, paper, combustible materials). Class A concentrates that have received USDA and USFS approval are
recommended.
On class B materials, the eductors can be used with high viscosity 1%, 3%, 6%, 3x3%, and 3x6% Alcohol Resistant Class B
concentrates.
The eductor can also be used with plain AFFF concentrates rated at 1%, 3% or 6% with various freeze protected foams, and with FFFP
foam types. These foams generally have a lower viscosity than the calibration viscosity of the TFT eductor and will be inducted faster
than expected resulting in stronger concentrations. While this does not degrade foam quality, it does reduce the operation time for a
given foam supply. Testing should be done with the foam being used to assure accurate induction rate.
Standard inlet operating pressure is 200 psi (13.8 bar) on all standard TFT 125 Series Eductors. Contact the factory for custom inlet
pressures of 160 psi (11 bar) and 145 psi (10 bar).
3.1 USE WITH SALT WATER
Consult foam manufacturer’s documentation and training by the Authority Having Jurisdiction (AHJ) before mixing foam concentrate with
salt water.
If the equipment is used with salt water, it must be thoroughly cleaned with fresh water after each use. The service life of the equipment
may be shortened due to the effects of corrosion, and is not covered under warranty.
3.2 VARIOUS MODELS AND TERMS
TFT 125 Series Eductors are available in several flows and with a variety of inlet couplings. These must be specified at the time of order.
Consult the factory for special thread requests.
The eductor can be split into two parts by grasping the locking ring and retracting it fully to separate the metering head from the eductor
body. All the foam passageways can easily be inspected. The foam passageway into the eductor contains a free-floating check disk with
three fins. The check disk is pressure activated to keep water from coming out of the pick-up hose and back into the foam pail.
The metering head contains a red back flush button that can be depressed to open the check disk.
The metering head also has a large proportioning knob that can be rotated to align the ball valve to six different detent positions, OFF,
1/4% 1/2%, 1%, 3%, and 6%. Each foam setting has a precision sized metering orifice in the valve ball. The eductor cannot be operated
between settings, as the metering orifices will not line up properly. The setting of the proportioning knob lines up with the white indicator
ball.
Figure 3.2
CAUTION Intermixing metering heads and eductor bodies of different flow rates can cause incorrect foam
strength, resulting in risk of injury as the ability to control the fire is compromised. Do not intermix
metering heads with eductor bodies of different flow rates.
PROPORTIONING INDICATOR
36" LONG 1" ID CLEAR HOSE
(Not to Scale)
20" LONG 1" OD WAND
(Not to Scale)
EDUCTOR BODY
EXIT
METERING HEAD
RETRACT THE LOCKER RING
TO UNLOCK.
RELEASE THE LOCKER RING
TO ENGAGE.
TURN KNOB TO SET
PROPORTIONING RATE.
PUSH BUTTON TO
BACK FLUSH.
CHECK DISK

©Copyright Task Force Tips LLC 2010-2021 6 LIU-330 February 15, 2021 Rev09
4.0 OPERATING INSTRUCTIONS
Refer to training approved by the AHJ for appropriate foam type, concentration, and hose length.
1. Choose the appropriate foam concentration.
2. Lay the appropriate hose line.
3. Connect the appropriate nozzle.
4. Charge the hose and open the nozzle fully to establish the water flow.
5. Adjust the pump pressure so the eductor inlet is set at pressure specified on body label.
6. Rotate the percentage knob to the desired concentration.
7. Place the concentrate intake wand in the foam supply.
4.1 CLEANING INSTRUCTIONS
The eductor must be cleaned after each use to prevent residual foam concentrate from clogging the passageways.
1. After use, take the concentrate intake hose out of the foam supply.
2. Turn down the pump pressure to below 75 psi (5.2 bar).
3. Shut off the nozzle.
4. Restrain the wand and expect a rapid discharge of water, especially at the 6% setting.
5. Push the red flush button to run fresh water through the hose and metering head on each setting until there is no visible foam in
the flush water.
6. Retract the lock ring to remove the metering head.
7. Turn off water supply and remove the eductor from the hose so that any remaining foam residue can be washed from the wand,
metering head and eductor.
5.0 USE WITH FOAM
5.1 FOAM SELECTION
Actual foam concentrations vary with changes in water flow, foam concentrate temperature and viscosity. The user must verify that the
concentrate’s performance is suitable for use in their application. Refer to training approved by the AHJ regarding foam concentrate use.
In all cases, the manufacturer’s recommendations must be followed.
5.2 FOAM ATTACHMENT OPTIONS
Expansion ratios vary depending on the type of nozzle used. Refer to training approved by the AHJ when choosing a foam nozzle or
attachment.
Medium Expansion Nozzle — produces the greatest expansion ratios. It is generally used on Class B fuels for vapor suppression and
Class A fuels when a longer lasting insulating layer of drier foam is desired.
Low Expansion Nozzle — can be used with either Class A or B foam solutions. Reach is slightly less than the smooth bore. It is
generally used on Class B fires for extinguishment and Class A fuels to soak the fuel with a wet foam solution.
Straight Stream Nozzle — is for Class A foam solutions. Foam expansion will be negligible. For use where maximum reach or
penetration is desired.
CAUTION Rapid backflush discharge from the wand could cause injury.
The backflush push button is pressure activated and must not be forced at pressures over 75 psi (5
bar). Do not backflush above 75 psi.
CAUTION Mixing of foam concentrates can cause the contents of the foam tank to gel and produce
unpredictable results. To reduce the risk of injury due to unpredictable foam production:
• Do not mix different types of foam concentrates or foams of the same type from different
manufacturers.
• Clean tank and foam passages thoroughly when changing foam types.

©Copyright Task Force Tips LLC 2010-2021 7 LIU-330 February 15, 2021 Rev09
5.3 FOAM CONSUMPTION
The following tables indicate the theoretical foam concentrate flow rate and the time it will take to empty a 5 gallon (18.9 liters) container
of various concentrates with eductors of different ratings.
TESTING NOTES:
1. The Class A foam used for calibration is the “Knock Down” from National Foam. The calibration viscosity is 20 Centipoise.
2. The class B foam used for calibration is the “Universal Plus 3%/6% Alcohol Resistant Aqueous Film Forming Foam” (AR-AFFF)
from National Foam. The calibration viscosity is 2892 Centipoise tested with Brookfield #3 Spindle @ 30 rpm.
3. TFT’s eductors were calibrated with 1 ¾” Conquest Hose.
- UE-060-NF calibration hose length is 300 ft.
- UE-095-NF calibration hose length is 250 ft.
- UE-125-NF calibration hose length is 150 ft.
60 GPM (225 L/min) Eductor 95 GPM (360 L/min) Eductor
Setting Foam
Class
Time to Empty
5 Gallons
Foam Flow
Rate
Setting Foam
Class
Time to Empty
5 Gallons
Foam Flow
Rate
1/4% A 33 min 20 sec 0.15 gpm
(.057 L/min)
1/4% A 20 min 50 sec 0.24 gpm
(0.9 L/min)
1/2% A 16 min 40 sec 0.3 gpm
(1.14 L/min)
1/2% A 10 min 25 sec 0.5 gpm
(1.89 L/min)
1% B 8 min 20 sec 0.6 gpm
(2.27 L/min)
1% B 5 min 16 sec 1.0 gpm
(3.78 L/min)
3% B 2 min 47 sec 1.8 gpm
(6.81 L/min)
3% B 1 min 45 sec 2.9 gpm
(10.97 L/min)
6% B 1 min 23 sec 3.6 gpm
(13.62 L/min)
6% B 53 sec 5.7 gpm
(28.38 L/min)
120 GPM (450 L/min) Eductor 125 GPM (475 L/min) Eductor
Setting Foam
Class
Time to Empty
5 Gallons
Foam Flow
Rate
Setting Foam
Class
Time to Empty
5 Gallons
Foam Flow
Rate
1/4% A 16 min 40 sec 0.29 gpm
(1.09 L/min)
1/4% A 16 min 0.3 gpm
(1.14 L/min)
1/2% A 8 min 20 sec 0.58 gpm
(2.18 L/min)
1/2% A 8 min 0.6 gpm
(2.27 L/min)
1% B 4 min 10 sec 1.25 gpm
(4.72 L/min)
1% B 4 min 1.3 gpm
(4.92 L/min)
3% B 1 min 23 sec 3.65 min
(13.8 L/min)
3% B 1 min 20 sec 3.8 gpm
(14.38 L/min)
6% B 42 sec 7.2 gpm
(27.25 L/min)
6% B 40 sec 7.5 gpm
(28.38 L/min)
Actual calibrated rate for each setting and
the foam concentration used for calibration
Setting Actual
Rate
Foam
Class
UL-162
Tolerance
1/4% 0.287% A .25 - .325%
1/2% 0.575% A .5 - .65%
1% 1.15% B 1 - 1.3%
3% 3.45% B 3 - 3.9%
6% 6.5% B 6 - 7%

©Copyright Task Force Tips LLC 2010-2021 8 LIU-330 February 15, 2021 Rev09
5.4 FOAM SUPPLY LOGISTICS
The foam suction hose is matched to the eductor and must not be lengthened. Lengthening the foam suction hose reduces foam flow,
resulting in weak foam. Position foam buckets within reach of the standard length foam suction hose.
6.0 MAXIMUM HOSE LAY
The maximum hose lay is based on the back pressure. Pushing the foam solution through the hose and eductor causes back pressure
on the eductor exit.
• On a 200 psi (13.8 bar) model, if the back pressure is over 130 psi (9 bar) the eductor will not work.
• On a 160 psi (11 bar) model, if the back pressure is over 100 psi (6.9 bar) the eductor will not work.
• On a 145 psi (10 bar) model, if the back pressure is over 95 psi (6.5 bar) the eductor will not work.
Elevation loss adds to the back pressure when the nozzle is higher than the eductor. For each foot in vertical height, there is 0.4 psi
elevation loss.
Friction loss varies with different brand hoses. Determine the friction loss of your own hose. The nominal flow of the eductor is the sum
of water plus foam concentrate when set at 6%. The eductor should always have its rated pressure at the inlet. The water flow does not
change with different percentage settings; however, the inducted foam concentrate will change when the percentage setting is changed.
Therefore, the total flow exiting the eductor is lower at 1/4% than at 6%. Longer hose lengths can be used when proportioning rate is
less because less work is needed to move lower total flows.
7.0 NOZZLE SELECTION
Eductors work with any nozzle whose gallonage is equal or greater than that of the eductor. If a nozzle with a larger gallonage is used,
the reach of nozzle and the proportioning rate of the eductor will be compromised.
Non-aspirated automatic nozzles can produce expansion ratios of 6-8:1 when measured at the end of the stream. By maintaining a
constant nozzle pressure, automatic nozzles keep the velocity of the stream high. Large amounts of air are pulled into the stream and
mix with the foam concentrate/water solution as the stream leaves the nozzle.
Air-aspirating devices, such as the TFT FOAMJET, allow a wider selection of foam concentrates to be used, and can produce a better
quality of finished foam. The final expansion ratio and, amount of finished foam, depends on the type of foam concentrate being used.
DANGER
Lack of foam can place operator at risk of injury or death. To reduce the risk of injury due to lack
foam:
• Establish foam flow before advancing into hazardous situations.
• Keep an adequate supply of foam concentrate on hand.
• Check concentrate level periodically.
WARNING
Excess back pressure causes loss of foam flow resulting in risk of injury or death from an
ineffective stream.
• Verify that adequate foam flow is established and maintained.
• Do not exceed the maximum back pressure.
WARNING
Excess back pressure causes loss of foam flow resulting in risk of injury or death from an
ineffective stream. Operate the nozzle fully open to prevent excessive back pressure.

©Copyright Task Force Tips LLC 2010-2021 9 LIU-330 February 15, 2021 Rev09
7.1 NOZZLE COMPATIBILITY
The following tables list the compatibility between eductors and nozzles. A 75 psi (5 bar) nozzle will result in lower nozzle pressure and
shorter stream reach.
Table 7.1A
UE-060 EDUCTOR
60 GPM (225 L/min)
200 PSI (13.8 bar) Inlet Pressure
TFT
Nozzle Name
Nozzle Model # Water Flow
Setting
Nozzle
Pressure
Low Expansion
Foam Attachment
Multi-Expansion
Foam Attachment
Twister F2060, FS2060,
FS2060P
60 gpm
(230 L/min)
100 psi
(7 bar
NONE FJ-MX-F
Bubble Cup F2060BC,
FS2060BC,
FS2060BCP
60 gpm
(230 L/min)
100 psi
(7 bar)
BUILT-IN BUILT-IN
Metro 0 ME0** 60 gpm
230 L/min)
100 or 75 psi
(7 or 5 bar)
FJ-U
FJ-LX-U
FJ-UMX
1.0”
Quadrafog
DQ60, DQS60,
DQS60P
5-10-24-40-60 gpm
(20-40-90-150-230 L/min)
100 psi
(7 bar)
FJ-DQ FJ-MX-DQ
1.0”
G-Force
Selectable Flow
Fixed Pressure
15-30-45-60-75 gpm
(55-110-170-230-285 L/min)
100 or 75 psi
(7 or 5 bar)
FJ-GD
FJ-LX-U
FJ-UMX
1.0”
G-Force
Automatic Pressure
with Variable Flow
30-80 gpm
(110-300 L/min)
100 or 75 psi
(7 or 5 bar)
FJ-GD
FJ-LX-U
FJ-UMX
Ultimatic
B-*, BTO-*, BH-*,
BGH-*
10-125 gpm
(40-475 L/min)
100 psi
(7 bar) FJ-U
FJ-LX-U
FJ-UMX
BL-*, BTOL-*, BHL-*,
BGHL-*
10-100 gpm
(40-400 L/min)
75 psi
5 bar)
Metro 1 ME1** 60 gpm
(230 L/min)
100 or 75 psi
(7 or 5 bar)
FJ-HM
FJ-LX-HM
FJ-MX-HM
1.5”
Quadrafog
FQ125**, FQS125** 30-60-95-125 gpm
(110-230-360-470 L/min)
100 or 75 psi
(7 or 5 bar)
FJ-LX-FQ FJ-MX-FQ
QuadraCup
FQ125BC,
FQS125BC**,
FQCS**
30-60-95-125 gpm
(110-230-360-470 L/min)
100 or 75 psi
(7 or 5 bar)
BUILT-IN BUILT-IN
1.5” G-Force Selectable Flow
Fixed Pressure
30-60-95-125-150 gpm
(110-230-360-470-570 L/min)
100 or 75 psi
(7 or 5 bar)
FJ-LX-G FJ-MX-G
1.5” G-Force Automatic Pressure
with Variable Flow
60-150 gpm
(230-570 L/min)
100 or 75 psi
(7 or 5 bar)
FJ-LX-G FJ-MX-G
Thunderfog FT200*, FTS200* 30-60-95-125-150-200 gpm
(110-230-360-470-570-750 L/min)
100 or 75 psi
(7 or 5 bar)
NONE FJ-MX-FT

©Copyright Task Force Tips LLC 2010-2021 10 LIU-330 February 15, 2021 Rev09
Table 7.1B
UE-095 EDUCTOR
95 GPM (360 L/min)
200 PSI (13.8 bar) Inlet Pressure
TFT
Nozzle Name
Nozzle Model # Water Flow
Setting
Nozzle
Pressure
Low Expansion
Foam Attachment
Multi-Expansion
Foam Attachment
Twister F2095, FS2095,
FS2095P 95 gpm
(360 L/min)
100 psi
(7 bar)
NONE FJ-MX-F
Bubble Cup F2095BC, F95BC,
FS2095BC, FS95BC,
FS2095BCP, FS95BCP
95 gpm
(360 L/min)
100 psi
(7 bar)
BUILT-IN BUILT-IN
Ultimatic
B-*, BTO-*, BH-*,
BGH-*
10-125 gpm
(40-475 L/min)
100 psi
(7 bar) FJ-U
FJ-LX-U
FJ-UMX
BL-*, BTOL-*, BHL-*,
BGHL-*
10-100 gpm
(40-400 L/min)
75 psi
(5 bar)
Metro 1 ME1* 95 gpm
(360 L/min)
100 or 50 psi
(7 or 3 bar)
FJ-HM
FJ-LX-HM
FJ-MX-HM
Quadrafog FQ**, FQS** 30-60-95-125 gpm
(110-230-360-470 L/min)
100 or 75 psi
(7 or 5 bar)
FJ-LX-FQ FJ-MX-FQ
QuadraCup FQ125BC, FQ125BC**,
FQCS**
30-60-95-125 gpm
(110-230-360-470 L/min
100 or 75 psi
(7 or 5 bar)
BUILT-IN BUILT-IN
1.5”
G-Force
Selectable Flow
Fixed Pressure
30-60-95-125-150 gpm
(110-230-360-470-570 L/min)
100 or 75 psi
(7 or 5 bar)
FJ-LX-G FJ-MX-G
1.5”
G-Force
Automatic Pressure
with Variable Flow
60-150 gpm
230-570 L/min
100 or 75 psi
(7 or 5 bar)
FJ-LX-G FJ-MX-G
Thunderfog FT200*, FTS200*,
FT250*,
FTS250*, JT250*,
JTS250*
30-60-95-125-150-200 gpm
(110-230-360-470-570-750 L/min)
100 or 75 psi
(7 or 5 bar)
NONE FJ-MX-FT
Thunderfog FT250**, FTS250*,
FTS**, JT**, JTS**
95-125-150-200-250 gpm
(360-470-570-680-950 L/min)
100 psi
(7 bar)
NONE FJ-MX-FT
Metro 2 ME2** 95 gpm
(360 L/min)
100 psi
(7 bar)
FJ-H FJ-HMX
Mid-Matic HM-**, HML-** 70-200 gpm
(260-760 L/min)
100 or 75 psi
(7 or 5 bar) FJ-HM
FJ-LX-HM
FJ-MX-HM
HMK-* 70-180 gpm
(260-680 L/min)
55 psi
(4 bar)
Mid-Force HMD-**, HMDL-** 70-200 gpm
(270-760 L/min)
100 or 75 psi
(7 or 5 bar)
FJ-HM
FJ-LX-HM
FJ-MX-HM
Handline H-** 95-300 gpm
(360-1140 L/min)
100 psi
(7 bar)
FJ-H FJ-HMX
HL-** 95-250 gpm
(360-950 L/min)
75 psi
(5 bar)
HK-** 95-225 gpm
(360-850 L/min)
55 psi
(4 bar)
Dual-Force HD-** 95-300 gpm
(360-1150 L/min)
100 psi
(7 bar) FJ-H FJ-HMX
HDL-** 95-250 gpm
(360-950 L/min)
75 psi
(5 bar)

©Copyright Task Force Tips LLC 2010-2021 11 LIU-330 February 15, 2021 Rev09
Table 7.1C
UE-125 EDUCTOR
125 GPM (475 L/min)
200 PSI (13.8 bar) Inlet Pressure
TFT
Nozzle Name
Nozzle Model # Water Flow
Setting
Nozzle
Pressure
Low Expansion
Foam Attachment
Multi-Expansion
Foam Attachment
Ultimatic
B-** 10-125 gpm
(40-475 L/min)
100 psi
(7 bar)
FJ-U
FJ-LX-U FJ-UMX
Metro 1 ME1* 125 gpm
(475 L/min)
100, 75, or
50 psi
(7, 5, or 3
bar)
FJ-HM
FJ-LX-HM
FJ-MX-HM
Quadrafog FQ125**, FQS125** 30-60-95-125 gpm
(110-230-360-470 L/min)
100 or 75 psi
(7 or 5 bar)
FJ-LX-FQ FJ-MX-FQ
QuadraCup FQ125BC, FQ125BC**,
FQCS**
30-60-95-125 gpm
(110-230-360-470 L/min)
100 or 75 psi
(7 or 5 bar)
BUILT-IN BUILT-IN
1.5”
G-Force
Selectable Flow
Fixed Pressure
30-60-95-125-150 gpm
(110-230-360-470-570 L/min)
100 or 75 psi
(7 or 5 bar)
FJ-LX-G FJ-MX-G
1.5”
G-Force
Automatic Pressure
with Variable Flow
60-150 gpm
230-570 L/min
100 or 75 psi
(7 or 5 bar)
FJ-LX-G FJ-MX-G
Thunderfog FT200*, FTS200*, FTS* 30-60-95-125-150-200 gpm
(110-230-360-470-570-750
L/min)
100 or 75 psi
(7 or 5 bar)
NONE FJ-MX-FT
Thunderfog FT250*, FTS250*,
FTS**,
JT**, JTS**
95-125-150-200-250 gpm
(360-470-570-680-950 L/min)
100 or 75 psi
(7 or 5 bar)
NONE FJ-MX-FT
Metro 2 ME2* 125 gpm
(475 L/min)
75 psi
(5 bar)
FJ-H FJ-HMX
Mid-Matic HM-**, HML-* 70-200 gpm
(260-760 L/min)
100 or 75 psi
(7 or 5 bar) FJ-LX-HM FJ-MX-HM
HMK-* 70-180 gpm
(260-680 L/min)
55 psi
(4 bar)
Mid-Force HMD-** 70-200 gpm
(270-760 L/min)
100 or 75 psi
(7 or 5 bar)
FJ-HM
FJ-LX-HM
FJ-MX-HM
Handline H-** 95-300 gpm
(360-1160 L/min)
100 psi
(7 bar)
FJ-H FJ-HMX
HL-** 95-250 gpm
(360-950 L/min)
75 psi
(5 bar)
HK-** 95-225 gpm
(360-850 L/min)
55 psi
(4 bar)
Dual-Force HD-** 95-300 gpm
(360-1150 l/min)
100 psi
(7 bar) FJ-H FJ-HMX
HDL-** 95-250 gpm
(360-950 L/min)
75 psi
(5 bar)

©Copyright Task Force Tips LLC 2010-2021 12 LIU-330 February 15, 2021 Rev09
Table 7.1D
UEM-225 EDUCTOR
60 GPM (225 L/min)
160 PSI (11 bar) Inlet Pressure
TFT
Nozzle Name
Nozzle Model # Water Flow
Setting
Nozzle
Pressure
Low Expansion
Foam Attachment
Multi-Expansion
Foam Attachment
Metro 0 ME0** 60 gpm
(220 L/min)
75 psi
(5 bar)
FJ-U
FJ-LX-U
FJ-UMX
1.0”
G-Force
Selectable Flow
Fixed Pressure
15-30-45-60-75 gpm
(55-110-170-230-285 L/min)
75 psi
(5 bar)
FJ-GD
FJ-LX-U
FJ-UMX
1.0”
G-Force
Automatic Pressure
with Variable Flow
30-80 gpm
(110-300 L/min)
75 psi
(5 bar)
FJ-GD
FJ-LX-U
FJ-UMX
Ultimatic BL, BTOL, BHL, BGHL 10-100 gpm
(40-400 L/min)
100 psi
(7 bar)
FJ-U
FJ-LX-U FJ-UMX
Metro 1 ME1* 60 gpm
(230 L/min)
75 psi
(5 bar)
FJ-HM
FJ-LX-HM
FJ-MX-HM
1.5”
Quadrafog
FQ**, FQS** 30-60-95-125 gpm
(110-230-360-470 L/min)
75 psi
(5 bar)
FJ-LX-FQ FJ-MX-FQ
QuadraCup
FQ125BC,
FQS125BC**,
FQCS**
30-60-95-125 gpm
(110-230-360-470 L/min)
75 psi
(5 bar)
BUILT-IN BUILT-IN
1.5” G-Force Selectable Flow
Fixed Pressure
30-60-95-125-150 gpm
(110-230-360-470-570 L/min)
75 psi
(5 bar)
FJ-LX-G FJ-MX-G
1.5” G-Force Automatic Pressure
with Variable Flow
60-150 gpm
(230-570 L/min)
75 psi
(5 bar)
FJ-LX-G FJ-MX-G
Thunderfog FT200*, FTS200*, FTS* 30-60-95-125-150-200 gpm
(110-230-360-470-570-750
L/min)
75 psi
(5 bar)
NONE FJ-MX-FT

©Copyright Task Force Tips LLC 2010-2021 13 LIU-330 February 15, 2021 Rev09
Table 7.1E
UE-450 EDUCTOR
120 GPM (450 L/min)
160 PSI (11 bar) Inlet Pressure
TFT
Nozzle Name
Nozzle Model # Water Flow
Setting
Nozzle
Pressure
Low Expansion
Foam Attachment
Multi-Expansion
Foam Attachment
Metro 1 ME1* 95 gpm
(360 L/min)
100 or 50 psi
(7 or 3 bar
FJ-HM
FJ-LX-HM
FJ-MX-HM
Quadrafog FQ**, FQS** 30-60-95-125 gpm
(110-230-360-470 L/min)
75 psi
(5 bar)
FJ-LX-FQ FJ-MX-FQ
QuadraCup FQ125BC, FQ125BC**,
FQCS**
30-60-95-125 gpm
(110-230-360-470 L/min)
75 psi
(5 bar)
BUILT-IN BUILT-IN
1.5”
G-Force
Selectable Flow
Fixed Pressure
30-60-95-125-150 gpm
(110-230-360-470-570 L/min)
75 psi
(5 bar)
FJ-LX-G FJ-MX-G
1.5”
G-Force
Automatic Pressure
with Variable Flow
60-150 gpm
230-570 L/min
75 psi
(5 bar)
FJ-LX-G FJ-MX-G
Thunderfog FT200*, FTS200*,
FTS*
30-60-95-125-150-200 gpm
(110-230-360-470-570-750
L/min)
75 psi
(5 bar)
NONE FJ-MX-FT
Metro 2 ME2* 125 gpm
(475L/min)
75 psi
(5 bar)
FJ-H FJ-HMX
Mid-Matic HML-* 70-200 gpm
(260-760 L/min)
75 psi
(5 bar) FJ-LX-HM FJ-MX-HM
HMK-* 70-180 gpm
(260-680 L/min)
55 psi
(4 bar)
Mid-Force HMDL-** 70-200 gpm
(270-760 L/min)
75 psi
(5 bar)
FJ-HM
FJ-LX-HM
FJ-MX-HM
Handline
HL-** 95-250 gpm
(360-950 L/min)
75 psi
(5 bar) FJ-H FJ-HMX
HK-** 95-225 gpm
(360-850 L/min)
55 psi
(4 bar)
Dual-Force HDL-** 95-250 gpm
(360-950 L/min)
75 psi
(5 bar)
FJ-H FJ-HMX

©Copyright Task Force Tips LLC 2010-2021 14 LIU-330 February 15, 2021 Rev09
8.0 WARRANTY
Task Force Tips LLC, 3701 Innovation Way, Valparaiso, Indiana 46383-9327 USA (“TFT”) warrants to the original purchaser of its
products (“equipment”), and to anyone to whom it is transferred, that the equipment shall be free from defects in material and
workmanship during the five (5) year period from the date of purchase. TFT’s obligation under this warranty is specifically limited to
replacing or repairing the equipment (or its parts) which are shown by TFT’s examination to be in a defective condition attributable to
TFT. To qualify for this limited warranty, the claimant must return the equipment to TFT, at 3701 Innovation Way, Valparaiso, Indiana
46383-9327 USA, within a reasonable time after discovery of the defect. TFT will examine the equipment. If TFT determines that there is
a defect attributable to it, TFT will correct the problem within a reasonable time. If the equipment is covered by this limited warranty, TFT
will assume the expenses of repair.
If any defect attributable to TFT under this limited warranty cannot be reasonably cured by repair or replacement, TFT may elect to
refund the purchase price of the equipment, less reasonable depreciation, in complete discharge of its obligations under this limited
warranty. If TFT makes this election, claimant shall return the equipment to TFT free and clear of any liens and encumbrances.
This is a limited warranty. The original purchaser of the equipment, any person to whom it is transferred, and any person who is an
intended or unintended beneficiary of the equipment, shall not be entitled to recover from TFT any consequential or incidental damages
for injury to person and/or property resulting from any defective equipment manufactured or assembled by TFT.
It is agreed and understood that the price stated for the equipment is in part consideration for limiting TFT’s liability. Some states do not
allow the exclusion or limitation of incidental or consequential damages, so the above may not apply to you.
TFT shall have no obligation under this limited warranty if the equipment is, or has been, misused or neglected (including failure to
provide reasonable maintenance) or if there have been accidents to the equipment or if it has been repaired or altered by someone else.
THIS IS A LIMITED EXPRESS WARRANTY ONLY. TFT EXPRESSLY DISCLAIMS WITH RESPECT TO THE EQUIPMENT ALL
IMPLIED WARRANTIES OF MERCHANTABILITY AND ALL IMPLIED WARRANTIES OF FITNESS FOR A PARTICULAR PURPOSE.
THERE IS NO WARRANTY OF ANY NATURE MADE BY TFT BEYOND THAT STATED IN THIS DOCUMENT.
This limited warranty gives you specific legal rights, and you may also have other rights which vary from state to state.

©Copyright Task Force Tips LLC 2010-2021 15 LIU-330 February 15, 2021 Rev09
9.0 MAINTENANCE
The Eductor must be completely cleaned after each use. Lack of regular cleaning allows the foam concentrate to dry inside and around
the percentage ball resulting in plugged metering orifices. Look down inside the metering head after flushing and check valve to ensure
clean passageways.
9.1 SERVICE TESTING
In accordance with NFPA 1962, equipment must be tested a minimum of annually. Units failing any part of this test must be removed
from service, repaired and retested upon completion of the repair.
9.2 REPAIR
Factory service is available with repair time seldom exceeding one day in our facility. Factory serviced equipment is repaired by
experienced technicians, wet tested to original specifications, and promptly returned. Any returns should include a note as to the nature
of the problem and whom to reach in case of questions.
Repair parts and service procedures are available for those wishing to perform their own repairs. Task Force Tips assumes no liability for
damage to equipment or injury to personnel that is a result of user service. Contact the factory or visit the web site at tft.com for parts
lists, exploded views, test procedures and troubleshooting guides.
Performance tests shall be conducted on the equipment after a repair, or anytime a problem is reported to verify operation in accordance
with TFT test procedures. Consult factory for the procedure that corresponds to the model and serial number of the equipment. Any
equipment which fails the related test criteria should be removed from service immediately. Troubleshooting guides are available with
each test procedure or equipment can be returned to the factory for service and testing.
10.0 TROUBLE SHOOTING
Table 10.0
11.0 EXPLODED VIEWS AND PARTS LISTS
Exploded views and parts lists are available at tft.com/serial-number.
CAUTION Any alterations to the product or its markings could diminish safety and constitutes a misuse of
this product.
NOTICE
All replacement parts must be obtained from the manufacturer to assure proper operation of the
device.
SYMPTOM POSSIBLE CAUSE REMEDY
Eductor picks
up too much
foam
concentrate
Percentage Knob is set at higher percentage than desired Turn knob to desired percentage
Eductor inlet pressure is incorrect Set eductor inlet pressure to pressure specified on
labels
Metering head paired with incorrect body Use correct metering head for body
Weak Foam or
No Foam
Out of foam or bucket is nearly empty Refill tank
Percentage knob is set to lower percentage or is set to OFF Turn knob to desired percentage
Percentage ball is partially or completely plugged Take off the meter head and clean debris out of the
percentage ball
Hose lay is incorrect Correct hose lay per training approved by the AHJ
Eductor inlet pressure is incorrect Set eductor inlet pressure to pressure specified on
labels
Hose is kinked Straighten kinks out of hose
Concentrate intake hose is completely or partially clogged Clean debris out of concentrate intake hose
Valve in nozzle is not fully open Fully open valve in nozzle
Nozzle size is incorrect Select correct nozzle
Nozzle is clogged Flush nozzle to clear out debris or remove nozzle to
clean debris out
Foam has thickened due to cold temperatures Use a foam suitable for temperatures

©Copyright Task Force Tips LLC 2010-2021 16 LIU-330 February 15, 2021 Rev09
TASK FORCE TIPS LLC
MADE IN USA · tft.com
3701 Innovation Way, Valparaiso, IN 46383-9327 USA
800-348-2686 · 219-462-6161 · Fax [phone]
12.0 OPERATION AND INSPECTION CHECKLIST
BEFORE EACH USE, the Eductor must be inspected to this checklist:
1. There is no obvious damage such as missing, broken or loose parts, damaged labels, etc.
2. All controls move freely and operate properly.
3. Waterways, foam passages, and foam suction hose are not obstructed.
4. There are no leaks when the Eductor is flowing.
BEFORE BEING PLACED BACK IN SERVICE, the Eductor must be inspected to this list:
1. All controls and adjustments are operational.
2. There are no broken or missing parts.
3. There is no damage that could impair safe operation (e.g. detents, cracks, corrosion, or other defects).
4. The waterway is clear of obstructions.
5. The Eductor is cleaned and markings are legible.
WARNING
Equipment failing any part of the checklist is unsafe for use and must have the problem corrected
before use or being placed back into service. Operating equipment that has failed the checklist is a
misuse of this equipment.
