Taurus SelectaBell TF-ADB-55 User manual

TF-ADB50.02.04
TF-ADB-55.01.04
ADJSTAND.02.04
~ 60 Min.
Taurus SelectaBell Dumbbell
TF-ADB-50-2, TF-ADB-55, TF-ADJ-STAND-2
TF-ADB-50-2
TF-ADJ-STAND-2
TF-ADB-55
Assembly and Operating Instructions

SelectaBell Dumbbell
2

SelectaBell Dumbbell
3
Content
1 GENERAL INFORMATION 6
1.1 Technical Data 6
1.2 Personal Safety 7
1.3 Set-Up Place 8
2 ASSEMBLY 9
2.1 General Instructions 9
2.2 Scope of Delivery 9
2.3 Assembly 9
3 OPERATING INSTRUCTIONS 11
4 STORAGE AND TRANSPORT 12
4.1 General Instructions 12
5 TROUBLESHOOTING, CARE AND MAINTENANCE 12
5.1 General Instructions 12
5.2 Faults and Fault Diagnosis 12
5.3 Maintenance and Inspection Calendar 15
6 DISPOSAL 15
7 RECOMMENDED ACCESSORIES 16
8 ORDERING SPARE PARTS 17
8.1 Serial Number and Model Name 17
8.2 Parts List 18
8.3 Exploded Drawing 18
9 WARRANTY 19
10 CONTACT 21

SelectaBell Dumbbell
4
Dear customer,
Thank you for choosing a high-quality equipment of the brand Taurus®. Taurus® oers sports and
tness equipment for the sophisticated home sport and the equipment of tness studios and
business customers.WithTaurus® tness equipment, the focus is on what sport is all about: maximum
performance! Therefore, the equipment is developed in close consultation with athletes and sports
scientists. Because athletes know best what makes perfect tness equipment.
Further information can be found at www.sport-tiedje.com.
Legal Notice
Sport-Tiedje GmbH
Europe’s No. 1 for home tness
International Headquarters
Flensburger Straße 55
24837 Schleswig
Germany
Management:
Christian Grau
Sebastian Campmann
Dr. Bernhard Schenkel
No. HRB 1000 SL
Local Court Flensburg
European VAT Number: DE813211547
Disclaimer
©2010 Taurus® is a registered brand of the company SportTiedje GmbH. All rights
reserved. Any use of this trademark without the explicit written permission of Sport-
Tiedje is prohibited.
Product and manual are subject to change. Technical data can be changed without
advance notice.
Intended Use
The equipment may only be used for its intended purpose.
The equipment is suitable for home use and semi-professional use (e.g. hospitals, clubs, hotels,
schools, etc.). The equipment is not suitable for commercial or professional use (e.g. tness
studio).
Please note that this manual refers to both versions of the Taurus SelectaBell (50LB and 55LB) and
the corresponding optional stand.

SelectaBell Dumbbell
5
ABOUT THIS MANUAL
Please carefully read the entire manual before installation and rst use. The manual will help you to
quickly set up the system and explains how to safely use it. Make sure that all persons exercising with
the equipment (especially children and persons with physical, sensory, mental or motor disabilities)
are informed about this manual and its contents in advance. In case of doubt, responsible persons
must supervise the use of the equipment.
This equipment has been manufactured according to the latest safety knowledge.
As far as possible, potential safety hazards which could cause injury have been
eliminated. Make sure to carefully follow the instructions and that all parts are
securely in place. If required, read through the instructions again to correct any
mistakes.
Please pay close attention to the safety and maintenance instructions given here. The contract
partner cannot be held liable for damage to health, accidents or damage to the equipment when it
is not used in accordance with these instructions.
The following safety instructions may appear in this manual:
࣑ATTENTION
This notice indicates potentially hazardous situations which, if not avoided, may result in
property damage.
⚠CAUTION
This notice indicates potentially hazardous situations which, if not avoided, may result in slight
or minor injuries!
⚠WARNING
This notice indicates potentially hazardous situations which, if not avoided, may result in death
or serious injuries!
⚠DANGER
This notice indicates potentially hazardous situations which, if not avoided, will result in death
or serious injuries!
LNOTICE
This notice indicates further useful information.
Retain these instructions in a safe place for future reference, maintenance or when ordering
replacement parts.

SelectaBell Dumbbell
6
1 GENERAL INFORMATION
1.1 Technical Data
TF-ADB-50-2
Packaging dimensions (L x W x H): approximately 43 cm x 26.5 cm x 28.5 cm
Set-up dimensions (L x W x H): approximately 38.4 cm x 21.7 cm x 18.2 cm
Article weight (gross, including packaging): 25 kg
Article weight (net, without packaging): 23.35 kg
TF-ADB-55
Packaging dimensions (L x W x H): approximately 55 cm x 26.5 cm x 28.5 cm
Set-up dimensions (L x W x H): approximately 45.6 cm x 21.7 cm x 18.2 cm
Article weight (gross, including packaging): 28 kg
Article weight (net, without packaging): 26.14 kg
TF-ADJ-STAND-2
Packaging dimensions (L x W x H): approximately 69.8 cm x 46.5 cm x 11.5 cm
Set-up dimensions (L x W x H): approximately 42.3 cm x 41 cm x 57.2 cm
Article weight (gross, including packaging): 9.8 kg
Article weight (net, without packaging): 7.8 kg

SelectaBell Dumbbell
7
1.2 Personal Safety
⚠DANGER
+ Before you start using the equipment, you should consult your physician that this type of
exercise is suitable for you from a health perspective. Particularly aected are persons who:
have a hereditary disposition to high blood pressure or heart disease, are over the age of 45,
smoke, have high cholesterol values, are overweight and/or have not exercised regularly in
the past year. If you are under medical treatment that aects your heart rate, medical advice
is absolutely essential.
+ Note that excessive training can seriously endanger your health. Please also note that
heart rate monitoring systems can be inaccurate. If you notice any signs of weakness,
nausea, dizziness, pain, shortness of breath, or other abnormal symptoms, stop exercising
immediately and seek advice from your doctor if necessary.
⚠WARNING
+ This equipment may not be used by children under the age of 14.
+ Children should not be allowed unsupervised access to the equipment.
+ Persons with disabilities must have a medical license and must be under strict observation
when using the equipment.
+ The equipment is strictly for use by one person at a time.
+ If your equipment provides a safety key, the clip of the safety key must be attached to your
clothing before starting your training. In the event of a fall, the EMERGENCY STOP of the
equipment can be initiated.
+ Keep your hands, feet and other body parts, hair, clothing, jewellery and other objects well
clear of moving parts.
+ During use, wear suitable sports clothing rather than loose or baggy clothing.When wearing
sports shoes, make sure they have suitable soles, preferably made of rubber or other non-
slip materials. Shoes with heels, leather soles, studs or spikes are unsuitable. Never exercise
barefoot.
⚠CAUTION
+ If your equipment needs to be connected to the power supply with a mains cable, make
sure that the cable is not a potential tripping hazard.
+ Make sure that nobody is within the range of motion of the equipment during training so as
not to endanger you or other persons.
࣑ATTENTION
+ Do not insert any objects of any kind into the openings of the device.

SelectaBell Dumbbell
8
1.3 Set-Up Place
⚠WARNING
+ Do not place the equipment in main corridors or escape routes.
⚠CAUTION
+ The training room should be well ventilated during training and not be exposed to any
draughts.
+ Choose the place in which to set up the equipment such that there is enough free space/
clearance to the front, the rear and to the sides of the equipment.
+ The set-up and mounting surface of the equipment should be at, loadable and solid.
࣑ATTENTION
+ The device may only be used in one building, in suciently tempered and dry rooms
(ambient temperatures between 10°C and 35°C). The equipment should not be used
outdoors or in rooms with high humidity (over 70%) like swimming pools.
+ A oor protective mat/equipment underlay can help to protect high-quality oor coverings
(parquet, laminate, cork, carpets) from dents and sweat and can help to level out slight
unevenness.

SelectaBell Dumbbell
9
2 ASSEMBLY
LNOTICE
The dumbbell stand is an optionally availble accessory and needs to purchased separately. The
stand is compatible with 50LB as well as the 55LB SelectaBells.
2.1 General Instructions
⚠DANGER
+ Do not leave any tools, packaging materials such as foils or small parts lying around,
as otherwise there is a danger of suocation for children. Keep children away from the
equipment during assembly.
⚠WARNING
+ Pay attention to the instructions attached to the equipment in order to reduce the risk of
injuries.
⚠CAUTION
+ Do not open the packaging when it is lying on its side.
+ Ensure to have sucient room for movement in each direction during assembly.
+ The assembly of the equipment must be carried out by at least two adults. If in doubt, seek
the help of a third technically skilled person.
࣑ATTENTION
+ To prevent damage to the equipment and the oor, assemble the equipment on a mat or
packaging board.
LNOTICE
+ In order to make the assembly as simple as possible, some screws and nuts to be used can
already be pre-assembled.
+ Ideally, assemble the equipment at its later set-up place.
2.2 Scope of Delivery
At the beginning, check whether all parts belonging to the device are included in the scope of
delivery and whether damage has occurred. In the event of complaints, the contractual partner must
be contacted directly.
⚠CAUTION
If parts of the scope of delivery are missing or damaged, the assembly must not be carried out.
2.3 Assembly
Before assembly, take a close look at the individual assembly steps shown and carry out the assembly
in the order given.

1
2
3
4
4
2
8
8
7
7
3
7
7
7
1
5
5
1
5
5
SelectaBell Dumbbell
10
LNOTICE
First loosely screw all parts together and check that they t properly. Tighten the screws using
the tool only when you are instructed to do so.
Step1
To assemble the base, connect the legs (2,4) to the bottom stabilizer (3) with four long screws (8) and
nuts (7). Tighten with a screwdriver and wrench.
Step 2
To attach the dumbbell tray plate (compatible for both 50lb and 55lb dumbbells), fasten four short
screws (5) and four nuts (7) from the bottom of the stand. Tighten with a screwdriver.
Step 3
Please remove the dumbbell and make sure the tray is empty before assembling. To attach the
dumbbell tray plate (1) to the base, insert four long screws (5). Tighten with a screwdriver.
Step 4
Place the dumbbells onto the stand.
