Taurus BACK EXTENSION IT95 User manual

Owner‘s Manual
TF-IT9532
BACK EXTENSION IT95
TAURUS® is a registered brand of the company Sport-Tiedje GmbH.
All rights reserved. Any use of this trademark without the explicit written permission of Sport-Tiedje is prohibited.

Table Of Contents
CAUTION!
Read all precautions and instructions in this manual before using this equipment.
Please assemble according to the actual Weights you buy !
Important Safety Instructions----------------------------------------------------------- 3
Instructions-------------------------------------------------------------------------------- 5
Exploded View and Parts List------------------------------------------------------------ 6
Measurement Guide--------------------------------------------------------------------- 14
Assembly Instructions------------------------------------------------------------------ 15
Assembly--------------------------------------------------------------------------------- 16
Adjust Instructions---------------------------------------------------------------------- 29
Exercise Instructions-------------------------------------------------------------------- 30
Maintenance Schedule------------------------------------------------------------------ 31
General Maintenance Information----------------------------------------------------- 32
Weight Training Tips-------------------------------------------------------------------- 33

3
Important Safety Instructions
Before beginning any fitness program, you should obtain a complete physical
examination from your physician. When using exercise equipment, basic
precautions should always be taken, including the following:
1. Read all instructions before using the equipment.
These instructions are written to ensure your safety and to protect the unit.
2. Use the equipment only for its intended purpose as described in this guide.
Do not use accessory attachments that are not recommended by the
manufacturer: such attachments might cause injuries.
3. The product should only be used on a level surface and is with 0.5 meters
space around the product.
Do not use the equipment outdoors.
4. Do not allow children on or near the equipment. And children are not allowed
to use this equipment.
Teenagers should use this equipment with adult supervision.
5. Do not overexert yourself or work to exhaustion.
Do not attempt to lift more weight than you can control safely.
If you feel any pain or abnormal symptoms, stop your workout immediately
and consult your physician.
6. This equipment is not used as medical apparatus and instruments.
7. Never operate the unit when it has been dropped or damaged.
Never drop or insert anything into any opening in the equipment.
Always check the unit and its cables before each use. Make sure that all
fasteners and cables are secure and in good working condition.
Frayed or worn cables can be dangerous and may cause injury. Periodically
check these cables for any indication of wear.
Keep hands, limbs, loose clothing and long hair well out of the way of moving
parts.
8. Be careful when getting on or off the equipment.
9. Wear proper exercise clothing and shoes for your workout, no loose clothing.

Specifications
Class: S
Maximum Wt. Capacity: 134kg/ 295lbs
Maximum User Weight: 150kg/ 330lbs
Product Total Surface: 1185*1233mm
Product Total Mass: 123.7kg/ 273lbs
Training Area and Free Area
4
Important Safety Instructions
Personal Safety During Assembly
Read each step in the assembly instructions and follow the steps in sequence.
Do not skip ahead. If you skip ahead, you may learn later that you have to
disassemble components and that you may have damaged the equipment.
Assemble and operate the equipment on a solid, level surface. Locate the unit
a few feet from walls or furniture to provide easy access. The equipment is
designed for your enjoyment. By following these precautions and using
common sense, you will have many safe and pleasurable hours of healthful
exercise with the equipment.

5
Instructions
Tools Required
The equipment is designed to provide the smoothest, most effective exercise
motion possible. After assembly, you should check all functions to ensure correct
operation. If you experience problems, first recheck the assembly instructions to
locate any possible errors made during assembly. If you are unable to correct the
problem, call your authorized dealer. Be sure to have your serial number and this
manual when calling. When all parts have been accounted for, continue on.
Ratchet Wrench and Socket
Adjustable Wrench
Rubber Mallet
Hex Key Wrench Set
Phillips Screwdriver
Before beginning assembly please take the time to read instructions thoroughly.
Please use the various lists in this manual to make sure that all parts have been
included in your shipment. When ordering, use part number and description from
the lists. Use only our replacement part when servicing. Failure to do so will void
your warranty and could result in personal injury.

6
Exploded View and Parts List
Overall
Item No. Grade No. Part No. Description QTY
1 1 IT953201ASSY Weight Stack Frame ASSY 1
2 2 IT95320200 Main Frame 1
3 3 IT953203ASSY Bottom Cross Brace ASSY 1
4 4 IT95320400 Rear Connection Frame 1
5 5 IT953205ASSY Swing Frame ASSY 1
6 6 IT953206ASSY Wheel Frame ASSY 1
7 7 IT951709ASSY Circular Foot Frame ASSY 2
8 8 IT950509ASSY Handle Frame ASSY 1
9 9 IT93149300 Weight Stack Space 300 2
10 10 IT950121ASSY Top Bracket ASSY 1
11 11 IT950122ASSY Bottom Bracket ASSY 2
12 12 IT95016000 Plastic Cover 3
13 13 IT95012300 Rear Bracket 1
14 14 IT95014200 Top Plate 1
15 15 IT95014400 Guide Rod φ19*1242 1
16 16 IT95015100 Top Cover 1
17 17 IT95015200 Training Placard Cover 1
18 18 IT95015500 Top Rear Shroud 1
19 19 IT801210300P11C Cup Holder 1
20 20 SD1000B3000ASSY Adjustable Foot Plate 2
21 21 SG500110400V5 4.5" Pulley 3
22 22 IE950528ASSY FOAM ASSY 1
23 23 IT95081800 Seat Pad 1
24 24 IT95322000 Lumbar Pad 1
25 25 IT95015300 Front Shroud 1
26 26 IT95015400 Right Front Shroud 1
27 27 IT95015600 Rear Shroud 1
28 28 IT80023000 Weight Rubber Bumper 2
29 29 IT90012000V1 Selector Pin W/Coil 1
30 30 FE97212000 Circle Ring φ62.5*5 2

7
Exploded View and Parts List
Overall
Item No. Grade No. Part No. Description QTY
31 31 HFOPT900-04A1400 Aluminium Sheath 1
32 32 IT95016500 Spout Plug φ16.5*6.88 2
33 33 V22500 Plug 1
34 34 FE97211900 Cap φ60 3
35 35 GB818M6*16DHS2 Cross Recessed Pan Head Screw M6*16 4
36 36 GB818M6*10DHS2 Cross Recessed Pan Head Screw M6*10 4
37 37 GB818M6*20DHS2 Cross Recessed Pan Head Screw M6*20 18
38 38 GB70M8*20N19 Socket Head Cap Screw M8*20 2
39 39 GB70BTM10*25DN18 Socket Head Cap Screw M10*25 5
40 40 GB70BTM10*50DN18 Socket Head Cap Screw M10*50 3
41 41 GB70BTM10*65DN18 Socket Head Cap Screw M10*65 4
42 42 GB70BTM10*75DN18 Socket Head Cap Screw M10*75 2
43 43 GB70BTM10*80DN18 Socket Head Cap Screw M10*80 4
44 44 GB70BTM10*130DN18 Socket Head Cap Screw M10*130 2
45 45 GB70BTM12*30DN18 Socket Head Cap Screw M12*30 2
46 46 GB70BTM12*135DN18 Socket Head Cap Screw M12*135 6
47 47 IT95016100 Guide Rod Fixing Sleeveφ25*φ19*45 2
48 48 GB958DN2 Flat Washer φ9*φ16*1.6 2
49 49 GB9510DN2 Flat Washer φ11*φ20*2 28
50 50 GB9512DN2 Flat Washer φ13*φ24*2.5 8
51 51 NM10DN2 Nylon Lock Nut M10 9
52 52 HFOPT900-04A0602 Spring 2
53 54 IT95325400 Cable ASSY 1
54 55 GB70BTM10*30DN18 Socket Head Cap Screw M10*30 2
55 56 IE950912800 Plastic Ring 1
56 70 NBS6DHS Hex Key S=6 1
57 71 NBS8DHS Hex Key S=8 1
58 72 LW200BS Wrench φ6*117 1
59 73 YHY Lube 1

8
Exploded View and Parts List
Overall

9
Exploded View and Parts List
Weight Stack Frame ASSY
Item No. Grade No. Part No. Description QTY
1 1.1 IT95320100 Weight Stack Frame 1
2 1.2 GB17880.5M6*16.5DS17 Rivet Nut M6 14
3 1.3 AC32705800 U-nut M6 4
4 1.4 IT95015700 Foot Plate 2
5 1.5 IT95015900 Plastic Block 2
6 1.6 IT95015800 Plug φ95*81.1 2
7 1.7 GB818M6*20DHS2 Cross Recessed Pan Head Screw M6*20 2

10
Exploded View and Parts List
Bottom Cross Brace ASSY
Item No. Grade No. Part No. Description QTY
1 3.1 IT95320300 Bottom Cross Brace 1
2 3.2 IT95016400 Pulley Cover 2
3 3.3 IT95057800 Thin 4.5" Pulley 2
4 3.4 IT90013800P11C Plug RT50*100 1
5 3.5 FE97122100 Pulley Spacer 1 2
6 3.6 FE97122300 Threaded Cloumn 1
7 3.7 GB70BTM10*25DN18 Socket Head Cap Screw M10*25 2
8 3.8 DQ10N19B Flat Washer φ11*φ25*2 2

11
Exploded View and Parts List
Swing Frame ASSY
Item No. Grade No. Part No. Description QTY
1 5.1 IT95320500 Swing Frame 1
2 5.2 GB2766006-2ZNBK Bearing 2
3 5.3 IT950521ASSY Long Pin 1
4 5.4 GB958DN2 Flat Washer φ9*φ16*1.6 2
5 5.5 GB938N19 Spring Washer φ8 2
6 5.6 PNLM8*25DN20 Button Head Cap Screw M8*25 2
7 5.7 IT95121200 Counter Poise Block 1

12
Exploded View and Parts List
Wheel Frame ASSY
Item No. Grade No. Part No. Description QTY
1 6.1 IT95320600 Wheel Frame 1
2 6.2 IT95321800 Lining Board 1
3 6.3 IN-S10111200 Rubber Sleeve φ17*10.5 2
4 6.4 FE97213100 Square Rubber Sleeve 1
5 6.5 GB2766006-2ZNBK Bearing 2
6 6.6 GB70M8*20DS20 Socket Head Cap Screw M8*20 2
7 6.7 GB958DN2 Flat Washer φ9*φ16*1.6 2
8 6.8 NM8DN2 Nylon Lock Nut M8 2

13
Exploded View and Parts List
Circular Foot Frame ASSY
Handle Frame ASSY
Item No. Grade No. Part No. Description QTY
1 7.1 IT95170900 Foot Set Tube 1
2 7.2 FE970112000 Foot Set 2
Item No. Grade No. Part No. Description QTY
1 8.1 IT95050900 Handle Frame 1
2 8.2 026-01PL0206-12 Grip 2
3 8.3 V39600 Aluminum Grip Cap 2
4 8.4 V39500 Aluminum Grip Ring 2
5 8.5 YZGB7710-32*3.2N19 Socket Set Screw 10-32UNF*3.2 8

Inches
Millimeters
BHCS = Button Head Cap Screw
SHCS = Socket Head Cap Screw
FHCS = Flat Head Cap Screw
HHB = Hex Head Bolt
Measurement Guide
Diameter of bolt
(mm/inch) M6(1/4") M8(5/16") M10(3/8") M12(1/2") M16(5/8")
Tightening
torque (N.m) 9~12 22~30 45~59 78~104 193~257
Operational
methods for
adult men
The strength of
the wrist
The strength of
the wrist and
forearm
The strength of
the entire arm
The strength of
the arm and
upper body
with all strength
14
CRPHS = Cross Recessed Pan
Head Screw

15
Assembly Instructions
Assembly of the equipment takes professional installers about 2 hours. If this
is the first time you have assembled this type of equipment, plan to spend
more time. It is strongly recommended to assemble the equipment by
professional installers. You may find it quicker, safer, easier to assemble this
equipment with the help of a friend, as some of components may be large,
heavy or awkward to handle alone. It is important that you assemble your
product in a clean, clear, uncluttered area. This will enable you to move around
the product while you are fitting components and reduce the possibility of
injury during assembly.
As with any assembled part, proper alignment and adjustment is critical. While
tightening the fasteners, be sure to leave room for adjustments. Do not fully
tighten the fasteners until instructed to do so. Be careful to assemble the
components in the sequence presented in this guide.
NOTE

STEP 1
1. Attach two Adjustable Foot Plates (#20) to the Main Frame (#2).
2. Attach the Rear Bracket (#13) to the Top Rear Shroud (#18) using:
two M6*10 CRPHS (#36)
Note: Wrench Tighten Bolts.
Assembly
16

Assembly
17
STEP 2
1. Attach the Bottom Cross Brace ASSY (#3) to the Weight Stack Frame ASSY (#1) using:
two M10*80 SHCS (#43) two M10 Nylon Lock Nut (#51)
four Φ11*Φ20*2 Flat Washer (#49)
2. Attach the Rear Connection Frame (#4) to the Weight Stack Frame ASSY (#1) and the
Bottom Cross Brace ASSY (#3) using:
two M12*30 SHCS (#45) two M12*135 SHCS (#46)
four Φ13*Φ24*2.5 Flat Washer (#50) one Plastic Cover(#12)
3. Attach the Main Frame (#2) to the Rear Connection Frame (#4) and the Bottom Cross
Brace ASSY (#3) using:
four M12*135 SHCS (#46) four Φ13*Φ24*2.5 Flat Washer (#50)
two Plastic Cover (#12)
Note: 1. Wrench Tighten Bolts and Nylon Lock Nuts.
2. Adjust the Adjustable Foot Plates to make the machines stable.

STEP 3
1. Attach the 4.5" Pulley (#21) to the Weight Stack Frame ASSY (#1) using:
one M10*50 SHCS (#47)
two Φ11*Φ20*2 Flat Washer (#49)
one M10 Nylon Lock Nut (#51)
2. Attach two Bottom Bracket ASSY (#11) to the Weight Stack Frame ASSY (#1) using:
two M10*75 SHCS (#42)
four Φ11*Φ20*2 Flat Washer (#49)
two M10 Nylon Lock Nut (#51)
3. Attach the Top Bracket ASSY (#10) to the Weight Stack Frame ASSY (#1) using:
two Φ9*Φ16*1.6 Flat Washer (#48)
two M8*20 SHCS (#38)
4. Attach the Wheel Frame ASSY (#6) to the Bottom Cross Brace ASSY (#3) using:
one M10*25 SHCS (#39)
one Cap Φ60 (#34)
one Circle Ring Φ62.5*5 (#30)
5. Attach the Swing Frame ASSY (#5) to the Bottom Cross Brace ASSY (#3) using:
one M10*25 SHCS (#39)
one Cap Φ60 (#34)
one Circle Ring Φ62.5*5 (#30)
6. Attach the Handle Frame ASSY (#8) to the Main Frame (#2) using:
two M10*25 SHCS (#39)
two M10*130 SHCS (#44)
four Φ11*Φ20*2 Flat Washer (#49)
two M10 Nylon Lock Nut (#51)
7. Attach two Circular Foot Frame ASSY (#7) to the Main Frame (#2) using:
four M10*65 SHCS (#41)
four Φ11*Φ20*2 Flat Washer (#49)
Note: Wrench Tighten Bolts and Nylon Lock Nuts.
Assembly
18

19
Assembly
STEP 3

STEP 4
1. Attach:
two Guide Rod Φ19*1242 (#15)
two Weight Rubber Bumper (#28)
fifteen Weight Plate 10LBS (#75)
two weight stack space(#76)
two Weight Stack Space 300(#9)
one Top Plate (#14)
to the Weight Stack Frame ASSY (#1) using:
two Guide Rod Fixing Sleeve Φ25*Φ19*45 (#47)
two Spring (#52)
2. Attach the Selector Pin W/Coil (#29) to the Top Plate (#14).
Assembly
20
Here is the assembly instruction for 160LBS Weights !
Grade No. Part No. Description QTY
75 FE97193100 10LBS Weight Plate 15
76 FEWS01ASSY Weight Stack Space 2
