OPERATING INSTRUCTIONS
HT11K Hand Tool NANOMQS 0.13-0.35 SQ.MM
Document number: 411-18608-1_Rev.A
TE Connectivity (TE) PN: 4-744017-9
Language: en (Translation of the original German version)

TE Connectivity Germany GmbH
a TE Connectivity Ltd. Company
Ampèrestr. 12–14
64625 Bensheim
Germany
Tel.: [phone]
Fax: [phone]
www.te.com
Certified in accordance with ISO 14001 and ISO/TS 16949:2002
© 2016 TE Connectivity Germany GmbH. All Rights Reserved.
NanoMQS, TE Connectivity and TE connectivity (logo) are brands.
Other product or company names may be trademarks of their respective owners.
General information
The information provided is for the purpose of product descriptions only. Users must
carry out their own assessments and tests. It should be noted that our products are
subject to natural wear and ageing processes.
The front page shows a sample configuration. The supplied product may vary from
that shown.
The original operating instructions were written in German.

HT11K Hand Tool NANOMQS 0.13
-
0.35
SQ.MM
OPERATING INSTRUCTIONS
411-18608-1_Rev.A Page 1 - 9
Table of Contents
1 Revisions......................................................................................................... 2
1.1 Revision history ....................................................................................................................... 2
2 Introduction..................................................................................................... 2
2.1 About these operating instructions.......................................................................................... 2
2.2 Signs and symbols used in this document..............................................................................2
2.2.1 Instructions .............................................................................................................................. 3
2.2.2 Notes ....................................................................................................................................... 3
2.3 Abbreviations........................................................................................................................... 3
3 General Safety Instructions........................................................................... 3
3.1 Intended Use ........................................................................................................................... 3
3.2 Safety measures...................................................................................................................... 4
3.2.1 General.................................................................................................................................... 4
3.2.2 Safety measures for operation ................................................................................................ 4
3.3 Warnings.................................................................................................................................. 4
4 Description...................................................................................................... 5
4.1 Functional description.............................................................................................................. 5
4.2 Layout...................................................................................................................................... 5
5 Set-up............................................................................................................... 6
5.1 Cross-section setting............................................................................................................... 6
6 Operation......................................................................................................... 7
6.1 Crimping terminals................................................................................................................... 7
7 Repair and maintenance ................................................................................ 8
7.1 Daily Maintenance................................................................................................................... 8
7.2 Periodic inspection .................................................................................................................. 8
8 Disposal........................................................................................................... 9
9 Customer Service Europe, Middle East and Africa (EMEA)........................ 9

HT11K Hand Tool NANOMQS 0.13
-
0.35
SQ.MM
OPERATING INSTRUCTIONS
411-18608-1_Rev.A Page 2 - 9
1 Revisions
1.1 Revision history
Rev. Date Description Name
A 19.09.2016 First version L. Sandhu
Table 1: Revision history
2 Introduction
2.1 About these operating instructions
These operating instructions describe the use and operation of the HT11K hand tool and
the necessary maintenance measures.
All persons using the hand tool must therefore be familiar with these operating instruc-
tions and follow them.
These operating instructions must be available with the hand tool at all times.
The owner and/or user is obliged to supplement these operating instructions with instruc-
tions in line with existing national regulations for accident prevention and environmental
protection.
These operating instructions apply to the following hand tool from TE Connectivity:
HT11K Hand Tool NANOMQS TAB 0.13-0.35 TE P/N 4-1579014-2
Warranty claims, liability
TE Connectivity disclaims all liability for any loss or damage arising from failure to ob-
serve instructions on the hand tool or in the operating instructions.
The manufacturer is not liable for any loss or damage arising from unauthorised changes
or modifications to the hand tool.
Service
For further information and technical support, please contact the TE Connectivity Cus-
tomer Support Centre. For addresses, see Section 9.
2.2 Signs and symbols used in this document
The signs and symbols mentioned in this section are used in these operating instructions.

HT11K Hand Tool NANOMQS 0.13
-
0.35
SQ.MM
OPERATING INSTRUCTIONS
411-18608-1_Rev.A Page 3 - 9
2.2.1 Instructions
Instructions are marked as follows:
For action steps
For action results
2.2.2 Notes
General note on operation/use.
2.3 Abbreviations
Abbrevia-
tion Meaning
TE P/N TE Connectivity part number
Table 2: Abbreviations used
3 General Safety Instructions
The hand tool has been manufactured in line with current industry standards and recog-
nised safety rules.
Nonetheless, a risk of physical and material damage exists if the following general safety
instructions and warnings preceding the instructions in these operating instructions are
not followed.
Finding information about RoHS
Information on the presence and location of substances subject to Restriction of Hazard-
ous Substances (RoHS) guidelines can be found on the following website:
http://www.te.com/en/resources/product-compliance.html
Click on the entry field underneath Test Product Compliance and Request State-
ments of Compliance (SoCs) and enter the relevant item numbers.
Click on the entry field underneath Product Compliance and enter the relevant part
number(s).
Click on the Search button.
The search results will be displayed.
3.1 Intended Use
The hand tool is used to crimp NanoMQS terminals according to the TE processing speci-
fication and drawing listed in Table 3.
The hand tool may only be used for repair purposes or for making samples, not for series
production.

HT11K Hand Tool NANOMQS 0.13
-
0.35
SQ.MM
OPERATING INSTRUCTIONS
411-18608-1_Rev.A Page 4 - 9
The following NanoMQS terminals can be processed with the hand tool:
Diameter Terminal Terminal PN TE processing specification
0.13 – 0.17 mm
2
NanoMQS 2236905-x Appl. Spec.114-94288
Appl. Spec.114-18022
0.22 – 0.35 mm
2
NanoMQS 1-2236905-x Appl. Spec.114-94288
Appl. Spec.114-18022
Table 3: Processable terminals
Operational environment
The hand tool may only be used in a dry and dust-free environment. Do not use the hand
tool in environments with a gas atmosphere.
3.2 Safety measures
3.2.1 General
The hand tool may only be used for the intended purpose.
The hand tool may only be used by suitably trained and authorised staff.
3.2.2 Safety measures for operation
The hand tool must only be used in technically perfect condition and with full awareness
of safety aspects and potential dangers. If the hand tool is considered to be no longer
safe to use, it must be taken out of service.
Never crimp live wires
Wear eye protection when using the hand tool. Failure to follow this instruction can lead
to eye injuries from flying particles.
Observe the relevant processing specification when using the tool.
3.3 Warnings
The signs and symbols set out in this section are used in these operating instructions.
Attention
ATTENTION!
Type of hazard
Cause
Measures for averting hazards
"Attention" indicates information or recommendations which can refer directly or indirectly
to the safety of persons or material damage.

HT11K Hand Tool NANOMQS 0.13
-
0.35
SQ.MM
OPERATING INSTRUCTIONS
411-18608-1_Rev.A Page 5 - 9
4 Description
4.1 Functional description
Crimping is performed by squeezing the handles together. Suitable crimp terminals are
crimped using dies.
The ratchet mechanism of the hand tool has resting points which click when closing the
handles.
4.2 Layout
Figure 1: Hand tool
Item Designation Item Designation
1 Terminating head 2 Handles
3 Locking mechanism 4 Crimping die
5 Crimping nest 6 Die latch
7 Wire stop 8 Terminal holder
Table 4: Components of the hand tool
1
8
7
6
5
4
3
2

HT11K Hand Tool NANOMQS 0.13
-
0.35
SQ.MM
OPERATING INSTRUCTIONS
411-18608-1_Rev.A Page 6 - 9
5 Set-up
5.1 Cross-section setting
Based on the wire cross-section and the relevant processing specification, determine the
right crimping die for the terminal to be processed. Proceed as follows to crimp the termi-
nal:
Close the hand tool until the locking mechanism allows you to open the handles.
Cross-section data may differ from the actual hand tool.
The locking mechanism of the hand tool has a ratchet that makes audible clicks
when you close the handles. When you hear the last click, the locking mechanism
releases and the hand tool can be opened again. For an emergency release, the
lever of the unlocking mechanism must be operated.
Figure 2: Position the die
Lift the die latch and position the die, so that the cross-section to be processed can
be seen in the viewing window.
The die latch must then be returned to the starting point, so that the die is fixed in po-
sition.
Viewing

HT11K Hand Tool NANOMQS 0.13
-
0.35
SQ.MM
OPERATING INSTRUCTIONS
411-18608-1_Rev.A Page 7 - 9
6 Operation
ATTENTION!
Fatigue symptoms
Prolonged use of mechanical hand tools can lead to fatigue symptoms, also
called "cumulative trauma disorders", such as tendon sheath inflammation. Hand
tools are only intended for occasional use with low stress levels.
In situations where prolonged use is necessary, pneumatic or electric hand
tools should be used.
6.1 Crimping terminals
Open the hinged terminal holder.
Open the wire stop and insert the terminal to be processed into the terminal holder.
Make sure the terminal is pushed into the stop in the terminal holder.
Figure 3: Position the terminal over the terminal holder (left), insert wire (right).
Carefully close the hinged terminal holder.
Feed the wire, insulated according to the processing specification, into the terminal
until it reaches the wire stop.
Hold the wire against the wire stop and press the handles together until the locking
mechanism opens again. The hand tool then opens fully.
Wire stop

HT11K Hand Tool NANOMQS 0.13
-
0.35
SQ.MM
OPERATING INSTRUCTIONS
411-18608-1_Rev.A Page 8 - 9
Figure 4: Crimp terminal (left), check the crimped terminal (right)
Then you can remove the crimped terminal from the crimping die. Ensure that the
wire stop is opened. If the terminal is stuck, jiggle it slightly to remove it from the ter-
minal holder.
Check the crimp height of the crimped terminal, Refer to the information in the TE
Connectivity processing specification and drawing.
The hand tool is ready for use again.
7 Repair and maintenance
7.1 Daily Maintenance
The following daily maintenance tasks should be performed by the responsible operator:
Using a soft, clean brush or a lint-free cloth, remove dirt, dust, moisture and other
residue from the hand tool. Do not use any hard or abrasive tools or materials that
could damage the hand tool.
Apply sewing-machine oil to all pivot points and bearing surfaces. Do not lubricate
excessively.
When the hand tool is not needed, store it in a clean and dry location.
7.2 Periodic inspection
The hand tool should be inspected periodically by suitably qualified staff according to
the level of use, and the inspections should be documented.
Check the hand tool for wear and damage, particularly in the crimping nest areas.

HT11K Hand Tool NANOMQS 0.13
-
0.35
SQ.MM
OPERATING INSTRUCTIONS
411-18608-1_Rev.A Page 9 - 9
8 Disposal
The hand tool can be disposed of as normal waste or as recyclable waste where possi-
ble. Disposal must take place in compliance with the local regulations. In case of doubt,
the hand tool can be sent to TE for disposal. See Section 9 for contact details.
9 Customer Service Europe, Middle East and Africa
(EMEA)
Contact for service enquiries or technical support:
Office hours:
Monday – Thursday 8 am – 4 pm
Friday 8 am – 2 pm
Phone: [phone]
E-mail contact:
EMEA Field Service Hotline: [email protected]
EMEA Hand Tool Repair: [email protected]
EMEA Wear & Spare Parts: [email protected]
EMEA Field Service Administration: [email protected]
Address:
TE Connectivity Germany GmbH
c/o Schenck Technologie- und Industriepark GmbH
Landwehrstr. 55 / Gebäude 83
64293 Darmstadt
Germany
Please note that the EMEA service hotline staff speak English and German. Addi-
tional information and contact details can also be found online. Visit us at:
http://tooling.te.com/
