Team Losi MINI-T User manual

PRICE LIST
EXPLODED VIEW
Effective:
10/1/2003
800-0218
Team Losi
A Division of Horizon Hobby, Inc.,
4710 E. Guasti Rd, Ontario, CA 91761
www.TeamLosi.com / [e-mail]

B-1016
B-1037
B-1027
B-1043
B-1051
B-1100
B-1045
B-1047
B-1047
B-1016
B-1031
B-1020
B-1100
B-1073
B-1043
B-1049
B-1031
B-1049
B-1024
B-1041
B-1043
B-1014
B-1047
B-1047
B-1051
B-10
4
B-1
0
B-1033
B-1037
B-1027
B-1100
B-1078
B-1045
B-1047
B-1051 B-1014
B-1036
B-1047
B-1035
B-1045
B-1047
B-1073
B-1022
B-1051
B-1031
B-1049
B-1051
B-1024
B-1041
B-1039
B-1071
LOSB1001 Mini-T Painted & Trimmed Body - Silver .............$18.99
LOSB1002 Mini-T Painted & Trimmed Body - Blue ..............$18.99
LOSB1003 Mini-T Painted & Trimmed Body - ed ............... $18.99
LOSB1004 Mini-T Painted & Trimmed Body - Black ..............$18.99
LOSB1005 Mini-T Painted & Trimmed Body - Yellow ........... $18.99
LOSB1006 Mini-T Painted & Trimmed Body - Purple ........... $18.99
LOSB1008 Mini-T Clear Body w/Masks & Stickers ............... $11.99
LOSB1010 Mini-T Sticker Sheet ............................................... $4.50
LOSB1011 Mini-T number Sheet ............................................. $1.50
LOSB1012 Mini-T Jump amps (4) ...................................... $7.00
LOSB1014 Main Chassis Set ................................................. $6.00
LOSB1016 Battery Box Set ..................................................... $4.50
LOSB1018 Front Bulkhead, Kickplate & Brace ....................... $4.00
LOSB1020 F/ Pivot Block Set ................................................. $3.00
LOSB1022 F/ Shock Tower Set............................................. $4.00
LOSB1024 F/ Suspension Arm Set ...................................... $5.00
LOSB1027 Spindle, Carrier & Hub Set .................................... $4.00
LOSB1029 Steering Set ............................................................... $4.00
LOSB1031 Camber and Steering Link Set ................................. $2.00
LOSB1033 Servo Mount & Steering Pin Set ................................. $2.50
LOSB1035 Front Bumper & Motor Guard Set .............................. $7.00
LOSB1037 Front Axle & Pin Brace Set ....................................... $5.00
LOSB1039 Damper Set (4) Assembled .................................... $14.99
LOSB1041 Suspension Pin Bag ................................................. $4.00
LOSB1043 E-Clip Bag .................................................................. $1.50
LOSB1045 Wheel Nuts & Drive Pins ........................................... $2.00
LOSB1047 Complete Screw Set ................................................. $2.00
LOSB1048 Body Clips (10) ......................................................... $1.50
LOSB1049 od End Set (14) ....................................................... $3.00
LOSB1051 Ball Stud Set (10) ....................................................... $5.00
LOSB1058 Transmission Case & Motor Plate Set ..................... $9.00
LOSB1060 Transmission Ball Bearing Set (7) ......................... $19.99
LOSB1062 Transmission Shaft Set ............................................ $6.00
LOSB1064 Slipper Hardware Set ................................................ $4.00
800-0218
NOT RESPONSIBLE FOR TYPOGRAPHICAL ERRORS ALL PRICES SUBJECT TO CHANGE WITHOUT NOTICE

B-1041
B-1027
B-1076
B-1100 B-1047
B-1047
B-1035
B-1041
B-1047
B-1071
B-1047
B-1051
B-1018
B-1029
B-1051
B-1029
B-1018
B-1047
B-1020
B-1024
B-1041
B-1037
B-1043
B-1043
B-1047
4
7
B-1022
0
18
B-1029
B-1051
B-1039
B-1047
B-1060
B-1068
B-1066
B-1060
B-1058
B-1073
B-1047
B-1062
B-1066
B-1060
B-1073
B-1047
B-1058
B-1047
B-1062
B-1060
B-1064
B-1029
B-1033
B-1049
B-1033
B-1060
B-1060
B-1058
B-1064
B-1062
LOSB1066 Gear Bag .................................................................. $3.00
LOSB1068 Spur Gear Bag ......................................................... $3.50
LOSB1069 Pinion Gear Bag ...................................................... $3.00
LOSB1071 Gear Cover & Body Post Set .................................... $2.50
LOSB1073 Outdrive, Dogbone & Axle Set ............................... $11.99
LOSB1076 Front Wheels & Tires (Pre-glued) .......................... $13.99
LOSB1078 ear Wheels & Tires (Pre-glued) ........................... $13.99
LOSB1084 Transmitter ............................................................. $34.99
LOSB1085 Transmitter Antenna ................................................. $6.00
LOSB1087 eceiver/Esc Unit ..................................................... $49.99
LOSB1089 Motor w/wires and plugs ...................................... $11.99
LOSB1091 Servo (complete) ...................................................$13.99
LOSB1092 Servo Gear Set ....................................................... $3.00
LOSB1094 Xtal Set 26.995 - Brown/Ch.1 ................................. $6.00
LOSB1095 Xtal Set 27.045 - ed/Ch.2 .................................... $6.00
LOSB1096 Xtal Set 27.095 - Orange/Ch.3 ............................... $6.00
LOSB1097 Xtal Set 27.145 - Yellow/Ch.4 ................................. $6.00
LOSB1098 Xtal Set 27.195 - Green/Ch.5 ................................. $6.00
LOSB1099 Xtal Set 27.255 - Blue/Ch.6 .................................... $6.00
LOSB1100 Ball Bearing Upgrade Set (Wheels & Hubs) ..... $14.99
LOSB1150
Front Wheels (pr): yellow ........................................ $3.00
LOSB1151 Front Wheels (pr): Chrome ................................... $4.00
LOSB1153 Front Tires w/foam (pr): Directional ib ............... $9.99
LOSB1160 ear Wheels (pr): yellow....................................... $3.00
LOSB1161 ear Wheels (pr): Chrome ................................... $4.00
LOSB1163 ear Tires w/foam (pr): Taper Pin ........................ $9.99
LOSB1175 F. Directionals and Chrome Wheels, glued ....... $14.99
LOSB1178 . Taper Pins and Chrome Wheels, glued ........ $14.99
OPTIONAL PARTS FOR THE Mini-T

Before you start running your new Mini-T, it is absolutely necessary that you read through all of the
operating instructions to get the maximum enjoyment and prevent unnecessary damage.
Remove the transmitter battery tray
by sliding the bottom cover. Install
eight (8) AA alkaline batteries into
the battery holder. Pay close attention
to the correct direction of the positive
(+) and negative (-) ends as marked in
the tray. Reinstall the battery tray using
the molded pegs in the bottom as a
guide for the correct location and
replace the bottom cover.
Fig. 1
Step 1
After removing the body, remove
the small hatch pin just in front of
the the receiver above the steering
servo. Carefully swing the plate
with the receiver/speed control
upward and remove the battery box.
Fig. 2
Step 2
Insert the antenna wire through the
antenna mount and into the antenna
tube pushing it through until it comes
out the other end. Push the antenna
tube into the antenna mount.
Fig. 3
Step 3
Intstall the battery box with the
plug at the right front corner. Let
the receiver/speed control plate
drop over the batteries onto the
mounting post and replace the
hatch pin that secures it in place.
Plug in the battery using the slots
and bars molded into the plugs as
a guide and your are ready to go!
Fig. 5
Step 5
After you are done running, turn the Mini-T off FIRST by sliding the switch toward the back of the truck (Fig. 5). After the model has been
turned off, turn off the transmitter (Fig. 6). If you wish to clean your Mini-T, use compressed air and / or a soft paintbrush to remove dust and
dirt. NEVER use chemicals or anything wet as it can cause damage to both the electronics and plastic parts.
ALWAYS
Turn on the transmitter before the truck
Use caution when running around people
Turn both the Mini-T and transmitter "off" when done
Check the battery condition of the transmitter before running.
NEVER
Operate the Mini-T with low battery power.
Run the Mini-T through water or wet grass
Use chemicals to clean the chassis
Run the Mini-T without a gear cover
Turn on the Mini-T by sliding the switch on the right side of the
receiver forward (Fig 5.) as noted on the side of the switch. If
the rear wheels turn, adjust the "TH. TRIM" knob (Fig. 8) located
to the lower right of the steering wheel until they stop. To go
forward pull the trigger back. If you should need reverse, wait
for the model to stop then push the trigger forward. When going
forward the model should move in a straight line. If not, adjust
the "ST. TRIM" (Fig. 8) so that it tracks in a straight line without
having to turn the steering wheel.
Fig. 7 Fig. 8
Step 7
Always
turn on the transmitter first by
sliding the switch on the left side upward.
The small red and green lights to the left
of the steering wheel should both light up.
If not you need to checkfor low or in-
correctly installed batteries.
Fig. 6
Step 6
Remove the battery box top by lightly
prying the bottom rail of either end of
the retaining clip. Install four (4) AA
alkaline batteries into the battery box,
again paying close attention to the
correct direction of the cells. Replace
the cover and make sure the retaining
clips snap over the railsat either end.
Fig. 4
Step 4
800-0218
