Technaxx TX-SW3HR User manual

Technaxx® * User Manual
GPS Smartwatch TX-SW3HR
The manufacturer Technaxx Deutschland GmbH & Co.KG hereby declares that
this device, to which this user manual belongs, complies with the essential
requirements of the standards referred to the Directive RED 2014/53/EU. The
Declaration of Conformity you find here: www.technaxx.de/ (in bar at the
bottom “Konformitätserklärung”). Before using the device the first time, read
the user manual carefully.
Service phone No. for technical support: 01805 012643 (14 cent/minute from
German fixed-line and 42 cent/minute from mobile networks).
Free Email: support@technaxx.de
This device has a rechargeable battery. It must be fully charged before
first use. NOTE: Charge the battery of the device every 2–3 month if it is
not used!
Keep this user manual for future reference or product sharing carefully. Do
the same with the original accessories for this product. In case of warranty,
please contact the dealer or the store where you bought this product.
Warranty 2 years
Enjoy your product * Share your experience and opinion on one of the
well-known internet portals.
Features
⚫GPS Smartwatch to monitor your sport activities, heart rate, your
fitness and your sleep activities
⚫Displays heart rate, steps, distances, burned calories, sleep time,
clock & date
⚫Notification reminder: calls, SMS, Email, WhatsApp, social media,
achieved goals, activity reminder, drink reminder
⚫Free FunDo Pro APP in Google Play Store and Apple AppStore
⚫Anti-lost function: find your mobile phone or the Smartwatch
⚫Waterproof according to protection class IP67
⚫20 days usage time and 50 days standby time
⚫Wake up screen by turning your wrist

Technical specifications
Display
1.3“ Round Color Screen (240*240 Pixel)
Processor
Nordic 52832
Heart rate sensor
HRS3300
Protection class
IP67
Bluetooth / Distance
Version 4.0 BLE / ~10m
BT transmitting frequency
2.4GHz
BT max. radiated output power
2.5mW
Power supply
Built-in rechargeable 460mAh
Lithium-polymer battery 3,8V
Operating time
~20 days usage / ~50 days standby
Charging time
~3 hours (use the magnetic charging cable
with an USB charging adapter)
APP
FunDo Pro
Supported APP
Languages
GB, DE, FR, ES, PT, IT, PL, NL, RU, CZ, TR
(November 2018)
Weight / Dimensions
45g / (L) 40.8 x (W) 40.8 x (H)15.5mm
Storage temperature /
Operation temperature
–20°C up to 45°C
Package Contents
Technaxx® GPS Smartwatch TX-SW3HR,
charging cable, user manual
Compatibility
Android 4.3 or above & iOS 8.0 or above
Hints for Environment Protection: Packages
materials are raw materials and can be recycled. Do
not disposal old devices or batteries into the domestic
waste. Cleaning: Protect the device from
contamination and pollution. Avoid using rough,
coarse-grained materials or solvents/aggressive
cleaner. Wipe the cleaned device accurately.
Distributor: Technaxx Deutschland GmbH & Co.KG,
Kruppstr. 105, 60388 Frankfurt a.M., Germany

Charging
Plug the magnetic USB
charger in a USB-port with
power source
Now connect the magnetic
charger to the watch to
charge it
Product overview
1
Display
3
Heart rate sensor
2
Crown-button
4
Charging pins
NOTE: The device should be charged at least 1 hour before
use.
Start up
Connect the Smartwatch with the magnet charger or press down the
crown button for 2 seconds.
1.
3.
2.
4.

Install FunDo Pro APP on your Smartphone
Search for “FunDo Pro”APP in the Google Play Store/Apple APP-
Store or scan the following QR code for the installation.
Connect the Smartwatch with the FunDo Pro APP
Wait until the device is fully charged. Activate the Bluetooth of your
Smartphone. Then open the APP. Confirm all requests to get the
most out of the APP. Press “Add device” under “More” and search for
“TX-SW3HR”. Choose “TX- SW3HR” from the list and you are ready.
Now the Smartwatch is connected with your Smartphone and the
APP.
INFO: If the last mobile device connected to your Smartwatch is
turned on and the Bluetooth function is activated on both devices,
then the Smartwatch will automatically connect with the mobile
device.
Start using
When the Smartwatch is connected to the APP successfully, it will
sychronize the time and the date. It counts steps, distance and
calories automatically. Press the Crown-Button to activate the lcd
screen. Swipe left to see all functions. Swipe right to go back. Swipe
up or down on the start to see the main functions. Swipe right on start
screen to see notifications.

Main screen
Battery/Date/Time
Steps
Heart rate
Bluetooth
Pedometer
Swipe left until you see this icon. Tap this icon to enter
this option. The Pedometer counts footsteps, calculates
the distance and calorie consumption. Swipe down for
historical data from the hole week.
Select a sport
Swipe left until you see this icon. Tap this icon to enter
this option. Now you can choose between different
sports. Swipe down until you have reached the desired
sport. Now push the desired sport to start the workout.
After the gps is found the tracking begin.
QR-Code for APP
Swipe left until you see this icon. Tap this icon to enter
this option. Now you see a QR-Code. Scan it to go to the
Appstore page for the App FunDo Pro
Heart rate
Swipe left until you see this icon. Tap this icon to enter
this option. Your heart rate will now be measured.

Sports historical data
Swipe left until you see this icon. Tap this icon to enter
this option. Now you see your historical sport activities
chronological.
Sleep monitor
Swipe left until you see this icon. Tap this icon to enter
this option. If you would like to monitor your sleep quality
based on your sleeping time, you should wear the
Smartwatch on your wrist while you go to sleep. Swipe
down for historical data.
Music player
Swipe left until you see this icon. Tap this icon to enter
this option. Now you can start and stop the music by
pressing the play/pause button, previous or next title.
Alarm
Swipe left until you see this icon. Tap this icon to enter
this option. Here you see the Alarm you can set in the
App.
Messages / Push-Notifications
Swipe right and you see your Push-Notifications like
missed calls, SMS, WhatsApp, Twitter, Instagram,
Facebook, Messenger, etc.

Countdown
Swipe left until you see this icon. Tap this icon to enter
this option. Select a Time and press start to begin a
countdown.
Stopwatch
Swipe left until you see this icon. Tap this icon to enter
this option. Press start to begin. Press reset for a lap time
and stop and reset to zero the stopwatch
Phone finder
Swipe left until you see this icon. Tap this icon to enter
this option. Now the Smartwatch send a notificiation to
your phone and it begin to ring. Note: If there is no
Bluetooth connection, the option is not available
Settings
Swipe left until you see this icon. Tap this icon to enter
this option. Here you can change the brightness / lcd time
and see the system informations. Reset is also available
over this option.
Power-Off
Hold down the crown button for 2 seconds. The smartwatch vibrates
before turning off.
Hints
⚫Bluetooth connection becomes disconnected when the device
exceeds a certain distance. ⚫Reconnect with Bluetooth if Bluetooth
does not work for more than 5 min. ⚫Before binding the bracelet to
another account, you need to unbind it with the current account. ⚫If
the bracelet cannot be illuminated, connect the bracelet to the
charger.

Safety instructions
⚫Rebuilding or modifying the product impairs product safety. ⚫All
modifications and repairs of the device or accessories must be
performed by the manufacturer or by persons expressly authorized
by the manufacturer. ⚫Never open the product by yourself or
perform repairs by yourself! ⚫Handle the product carefully. It can be
damaged by knocks, blows or even by falling from low height. ⚫Keep
the product away from damp, moisture and extreme heat. ⚫Never
immerse the product in water or other fluids. ⚫Technical
specifications are subject to change without notice. ⚫Never heat the
battery above 60°C and do not drop or throw it into the fire, danger
of explosion/fire hazard! ⚫Do not short-circuit the battery. ⚫Do not
subject the battery to mechanical stress. Avoid dropping, striking,
bending, twisting or cutting the battery. ⚫Discontinue the charging
process immediately should the battery become overheated. A
battery that becomes overheated or deformed during the charging
process is defective and should no longer be used. ⚫Never drain the
battery completely, as this shortens its lifetime. ⚫If the battery must
be stored, it is recommended that it be stored at 30% of its loading
volume. Store out of direct sunlight. Ideal storage temperature: 10–
20°C. ⚫Keep the product away from little children.
Disposal
Old electrical appliances from private households
⚫ If you no longer want to use the appliance, hand it in free of charge
at a public collection point for old electrical appliances. ⚫ Old
electrical appliances must never be placed in the residual waste bins.
Further disposal instructions
⚫ Return the old electrical appliance in such a way that its
subsequent reuse or recycling is not impaired. Batteries must be
removed beforehand and the destruction of containers containing
liquids must be avoided. ⚫ Old electrical appliances can contain
harmful substances. If the device is handled incorrectly or damaged,
this can lead to damage to health or water and soil contamination
when the device is later recycled.
