Technaxx® * User Manual
TX-SW6HR Smartwatch
with temperature measurement
The manufacturer Technaxx Deutschland GmbH & Co.KG hereby declares that
this device, to which this user manual belongs, complies with the essential
requirements of the standards referred to the Directive RED 2014/53/EU. The
Declaration of Conformity you find here: www.technaxx.de/ (in bar at the
bottom “Konformitätserklärung”). Before using the device the first time, read
the user manual carefully.
Service phone No. for technical support: 01805 012643 (14 cent/minute from
German fixed-line and 42 cent/minute from mobile networks).
Free Email: suppo[email protected]
This device has a rechargeable battery. It must be fully charged before
first use. NOTE: Charge the battery of the device every 2–3 month if it is
not used!
Keep this user manual for future reference or product sharing carefully. Do
the same with the original accessories for this product. In case of warranty,
please contact the dealer or the store where you bought this product.
Warranty 2 years
Enjoy your product * Share your experience and opinion on one of the
well-known internet portals.
Features
⚫Smartwatch to monitor your body temperature, sport activities,
heart rate, your fitness and your sleep activities
⚫Displays heart rate, steps, distances, burned calories, sleep time,
time & date
⚫Notification reminder: calls, SMS, Email, WhatsApp, social media,
achieved goals, activity reminder, drink reminder
⚫Free Youth Health APP in Google Play Store and Apple AppStore
⚫Anti-lost function: find your mobile phone or the Smartwatch
⚫IP67 Waterproof
⚫15 days standby time
⚫Wake up screen by turning your wrist

Technical specifications
Display
1.4“ Color Screen (240*240 Pixel)
Processor
NRF52832
Heart rate sensor
HRS3300
Temerature sensor
tolerance
±0.3°C
Protection class
IP67
Bluetooth / Distance
Version 4.0 BLE / ~10m
BT transmitting frequency
2.4GHz
BT max. radiated output power
2.5mW
Power supply
Built-in rechargeable 190mAh
Lithium-polymer battery 3,7V
Operating time
~5 days usage / ~15 days standby
Charging time
~2 hours (use the magnetic charging cable
with a USB charging adapter)
APP
Youth Health
Supported APP
Languages
GB, DE, FR, ES, PT, IT, PL, NL, RU, CZ, TR
(November 2018)
Weight / Dimensions
40g / (L) 44 x (W) 39 x (H)11.2mm
Storage temperature /
Operation temperature
–10°C up to 45°C
Package Contents
Technaxx® TX-SW6HR Smartwatch,
charging cable, user manual
Compatibility
Android 5.1 or above & iOS 10.0 or above
Hints for Environment Protection: Packages
materials are raw materials and can be recycled. Do
not disposal old devices or batteries into the domestic
waste. Cleaning: Protect the device from
contamination and pollution. Avoid using rough,
coarse-grained materials or solvents/aggressive
cleaner. Wipe the cleaned device accurately.
Distributor: Technaxx Deutschland GmbH & Co.KG,
Kruppstr. 105, 60388 Frankfurt a.M., Germany

Charging
Plug the magnetic USB
charger in a USB-port with
power source
Now connect the magnetic
charger to the watch to
charge it
Product overview
1
Display
4
Heart rate sensor
2
Button
5
Thermometer sensor
3
Charging pins
NOTE: The device should be charged at least 1 hour before
use.
Start up
Connect the Smartwatch with the magnet charger or press down the
button for 5 seconds.

Install Youth Health APP on your smart phone
Search for “Youth Health”APP in the Google Play Store/Apple APP-
Store or scan the following QR code for the installation.
Connect the Smart watch with the Youth Health APP
Wait until the device is fully charged. Activate the Bluetooth of your
Smartphone. Open the Youth Health APP. Confirm all requests to get
the most out of the APP. Press „Add device“ under „Device“ and
search for “TX-SW6HR”. Choose “TX-SW6HR” from the list and you
are ready. Now the Smartwatch is connected with your Smartphone
and the APP.
INFO: If the last mobile device connected to your Smartwatch is
turned on and the Bluetooth function is activated on both devices,
then the Smartwatch will automatically connect with the mobile
device.
Start using
When the Smart watch is connected to the APP successfully, it will
synchronize the time, the date and the language. It counts steps,
distance and calories automatically. Press the button to activate the
LCD screen. Swipe up to see all functions. Swipe right to go back.
Swipe down on the start to see the main functions. Swipe right on the
start screen to see notifications.

Main screens
Press and hold to change the watch face.
Pedometer
Swipe up until you see this icon. Tap this icon to enter this
option. The Pedometer counts footsteps, calculates the
distance and calorie consumption. Swipe down for historical
data from the hole week.
Select a sport
Swipe up until you see this icon. Tap this icon to enter this
option. Now you can choose between different sports. Swipe
right until you have reached the desired sport. Now push the
desired sport to start the workout. Hostorical reports at last
option
Sleep monitor
Swipe up until you see this icon. Tap this icon to enter this
option. If you would like to monitor your sleep quality based
on your sleeping time, you should wear the Smartwatch on
your wrist while you go to sleep. Swipe down for historical
data. Sleep is tracked from 9pm to 9am.
Alarm
Swipe up until you see this icon. Tap this icon to enter this
option. Here you see the alarm you can set in the App.
