Techni Mobili MODERN RTA-940TV User manual

REV-1-CMN-7733-1123
MODERN 2 DOOR TV STAND
MODEL RTA-940TV
ASSEMBLY INSTRUCTIONS
Thank you for purchasing our product

16
x1
15
x1
14
x1
12
x2 13 x1
1
x1 2
x2 3
x1
4
x1
5
x1
8
x1 9
x1
10
x1
11
x1
P.1 P.1
RTA-940TV
Front skirting board Right side/central
skirting board
Left side skirting
board
Rear skirting board
MAIN PARTS LIST
Replacement Parts for International
Customers & AK-HI-PR orders:
RTA Products will replace the part free of
charge, while the customer is responsible
for shipping costs plus any International
local taxes or duties.
Do a quick inventory
of all the parts and
hardware listed below.
For Support, assembly questions
& Replacement Parts within the
48 Contiguous United States:
Please email us at:
[email protected]
Lower panel
Shelf Right partition panel
Right side panel
Main top panel
Door Left decorative
panel
Right decorative
panel
Left back board Upper back board 18
x1
17
x1
Lower back board Right back board
6
x1 7
x1
Left side panel Left partition panel

RTA-940TV
P.2 P.2
MAIN PARTS LAYOUT (For reference)
HARDWARE LIST AND INCLUDED TOOLS
TOOLS REQUIRED BUT NOT INCLUDED
Hammer
Phillips Screwdriver
PART QTY SIZE / DESCRIPTION ITEM
M4x50
(Left)
(Back)
(Left)
(Front)
4
If you decide to use a power driver:
• Make sure to have the appropriate Phillips bits.
• Start using at a low torque or speed to
avoid stripping the screws.
A
M6x32
Bolt
19
B
Cam lock
19
C
Ø6x30
Wooden Dowel
26
D
M3.5x12
16
Plastic glide foot
8
E
Articulated hinge
4
F
J
K
L
M
Fixed hinge
4
G
Square junction
10
H
I
10mm nail
60
PART QTY SIZE / DESCRIPTION ITEM
100x10mm
Double side tape
40
Self-adhesive round
sticker
COLOR #1
Color
#1
2
4
Self-adhesive round
sticker
COLOR #2
Color
#2

P.3 P.3
RTA-940TV
•After the item is assembled, you can use rubbing alcohol to
erase or remove the visible part numbers printed or labeled
on the pieces.
BEFORE YOU START THE ASSEMBLY, PLEASE READ THE FOLLOWING TIPS AND WARNINGS.
M6
30mm
M6x30
• Make sure you understand which
hardware will be used on each step. Using
the wrong size of screw, bolt or pin might
strip the threads or cause damage to the
part in which it is being used.
• To avoid misalignments, always leave the screws
loosely and do not tighten them until all the pieces
are positioned correctly.
• Do not overtighten or force the screws as they might
break, strip, damage the threads of the holes, or get
stuck inside the parts.
• If the hole seems to small for the screw, make sure
you are using the correct size of screw and/or that
you are installing it in the correct hole.
• Sometimes on the wood panels the laminate or
material might be covering the hole partially or
entirely, if there is no visible hole or if it looks too
small, pass and press the tip of your finger over the
area to feel its indentation, and carefully pierce the
laminate to uncover the hole underneath.
• Do not discard this manual or any of the packaging
material until the unit is completely assembled.
• Please read the assembly instructions throughly and
follow step by step.
Thank you!
12
Leave loose,
tighten all together
√
√
• The assembly might require of 2 persons for certain
steps. Before you start the instalation, make sure there
is someone else nearby to help you.
Do not
overtighten
• Please be kind to our planet, when done with the
assembly, recycle any of the packaging materials
that is accepted by your city or recycling service.

RTA-940TV
P.4 P.4
1. Screw the bolt into the indicated hole on the
panel indicated in the assembly step.
CAM BOLT AND CAM LOCK TUTORIAL
THE INSTRUCTIONS BELOW
ARE NOT ACTUAL ASSEMBLY STEPS
This unit uses cam bolts and locks (also known as mini fixes).
If you are not familiar with this kind of hardware, the below is a tutorial
that explains how to use them on the steps where they are required.
2. Join the other panel (with the big hole) to the
panel with the bolt. If it comes with the cam
locks already pre-installed, make sure to align
them to receive the bolt's head (refer to point
3). There might be a very small gap between
the panels which is normal.
3. Insert the cam lock on the panel with the big
hole making sure it goes aligned to receive the
bolt's head.
4. Use a Phillips screwdriver to turn the cam
lock clockwise. This will lock the panels
togheter and also will close any gaps.
Cam lock
alignment
If the cam locks come
pre-in stalled, make sure they
are aligned (see point 3).
THE ASSEMBLY STEPS START ON NEXT PAGE
THIS IS ONLY
A TUTORIAL
THIS IS ONLY
A TUTORIAL
THIS IS ONLY
A TUTORIAL
THIS IS ONLY
A TUTORIAL

WE RECOMMEND TO PLACE THE PIECES OVER BLANKETS TO PROTECT THEIR
FINISH DURING ASSEMBLY.
RTA-940TV
P.5 P.5
B
D
ASSEMBLY STEPS
Install the wooden dowels Dinto the indicated holes on panels 2, 3, 6, 7, 8, 9
and 10.
Tools (Not included)
Install the bolts Binto the indicated holes on panels 1, 4, 5, 6, 7and 11.
OR
STEP 1
Hardware
DPcs
26
Ø6x30
Wooden
dowel
STEP 2
Hardware
BPcs
19
M6x32
OR
Tools (Not included)

RTA-940TV
P.6 P.6
• FIRST place the main top panel 11 upside-down and over a large
tablecloth or blanket to protect its finish, and identify its front
edge.
• THEN assemble panels 7and 9from step 3to panel 11 on the
middle with cam locks C, with all the front edges oriented as shown.
With the pieces placed oriented as shown, ensamble the partition
panels 7and 9to the shelf 8with cam locks Cas explained in the
TUTORIAL PAGE.
(Front)
(Back)
(Top)
(Back)
(Back)
(Front)
(Front)
(Bottom surface)
(Bottom)
(Top)
(Bottom)
C
C
OR
Tools (Not included)
STEP 3
Hardware
Pcs
2
Cam lock
STEP 4
Hardware
C
OR
Tools (Not included)
Pcs
2
Cam lock
C
Alignment
Alignment
The 4 panels
will be flushed
at the back.
Panels 7 & 9 will
be receded at
the front.
(Front)
(Back)

RTA-940TV
P.7 P.7
This step
requires of
2 persons
Assemble the side panels 6and 10 to the top main panel 11 with cam locks C.
With the help of another person, assemble the lower panel 5to the panels 6, 7,
9and 10 with screws A. Pay attention to the orientation of the panel, and when
finished, all the panels will be flushed at the back, but panels 7and 9will be
receded at the front.
Pay attention to the orientation of the fixed hinges G, and attach them to the
side panels 6and 10 with screws I.
(Front)
(Front)
(Back)
(Top)
(Top)
(Bottom)
(Bottom)
A
STEP 7
Hardware
APcs
4
M4x50
OR
Tools (Not included)
STEP 5
STEP 6
Hardware
IPcs
8
M3.5x12
GPcs
4
Fixed hinge
OR
Tools (Not included)
G
I
(Front)
OR
Tools (Not included)
Hardware
Pcs
2
Cam lock
C
(Front)
(Front)
(Back)
(Back)
(Bottom)
(Bottom)
(Front)
(Back)
C
Alignment
(Front)
(Back)
(Front)
(Back)

RTA-940TV
P.8 P.8
This step
requires of
2 persons
Assemble the skirting boards 2and 3in between the skirting boards 1and 4
with cam locks Cas shown.
C
Tools (Not included)
OR
STEP 8
Hardware
EPcs
8
Glide
JPcs
8
Nail
On the indicated profile of the skirting boards 1 and 4install 2 pieces of the glide
feet Eusing nails Jat approximately 2" from each end, then another 2 pieces E
in the middle at equidistant length.
14
2" from each end
+
STEP 9
OR
Tools (Not included)
Hardware
Pcs
6
Cam lock
C
C
Alignment
Alignment
STEP 10
OR
Tools (Not included)
Hardware
Pcs
7
Cam lock
C
With the help of another person, assemble the base structure built on step 9to
the lower panel 5with cam locks C.
Alignment and turn

RTA-940TV
P.9 P.9
This step
requires of
2 persons
• FIRST, and with the help of another person, carefully flip the unit over its front.
• THEN place all the back boards 15, 16, 17 and 18 over the unit on their
respective places making sure they are flush with each other and their edges
fit and are centered within the edges of the unit.
• THEN secure ONLY the outer edges of the boards with nails J.
• THEN place the metal junction plates H distributed along where the boards
join each other, and secure them with nails J.
• THEN, and with the help of another person, carefully flip the unit upright.
• LASTLY, cover the cam locks with the respectives stickers Land M.
DON'T FORGET TO USE A
BLANKET FOR PROTECTION
OF SURFACES
STEP 11
Hardware
HPcs
10
Juntion
JPcs
52
Nail
FIFTH: Flip
(Front)
(Back)
(Top)
(Bottom)
5
6
10
11
SECOND
18
16
17
15
THIRD: Outer
edges ONLY
FOURTH:
Along
junctions
J
J
H
Pcs
2
Color #1
L
Pcs
4
Color #2
M
LAST: Apply stickers
8
6
10
79
(Front)
(Top)
(Bottom)
FIRST: Flip
6
10 11
Tools (Not included)
OR

THEN: Have ready the
doors 12 oriented as
shown.
RTA-940TV
P.10 P.10
• FIRST place the decorative panels 13 and 14 upside-down and carefully peel-
off and attach to each of them 20 pieces of the double-sided tape K, but DO
NOT PEEL OFF on the top side until ready to join with doors 12.
• THEN place the doors 12 with the big holes facing down, and side by side.
• THEN carefully peel-off the tapes from 13 and 14.
• LASTLY, and very carefully, slowly and steadily, place the ornament panels
over the exterior surface of the doors 12.
K
I
F
STEP 12
Hardware
KPcs
40
Double
tape
Unfinished side
FIRST: Peel-off K on
one side ONLY, and
attach to the ornaments
13 and 14
FIRST: Flip doors,
keeping them side-
by-side
THEN: Atatch the hinges
(Big holes located underneath and on this side)
LAST: Peel-off K from
the ornaments, and
carefully attach them
to the doors.
K
K
STEP 13
Hardware
IPcs
8
4
Pcs
M3.5x12
FArticulated
hinge
OR
Tools (Not included)
(Big holes located underneath and on this side)
Flip the doors 12 and attach to them the articulated hinges Fwith screws I.
Unfinished side

RTA-940TV
P.11 P.11
• FIRST, inside the unit loosen up the middle screws on the fixed hinges G, and
on the doors 12 tighten the screw on the hinges F just a little bit to allow both
pieces of hinges to connect well one to another.
• THEN, install the doors 12 to the side panels 6and 10 on the unit by
connecting the articulated hinges Fto the fixed hinges G, and tightening the
screws on G.
• LASTLY, and to ensure that the doors will close smootly, adjust their alignment
by loosening the indicated screws, aligning the door, then re-tighten the
screws. You might have to play a little bit with the different adjustments.
To adjust the height, loosen
up these screws, align, then
re-tighten
To adjust the depth, loosen up
this screw, align, then re-
tighten
To adjust side-to-side,
loosen up or tighten this
screw.
THEN: Install the doors
LAST: Adjust the doors
(But just a little bit)
Tighten on F
STEP 14
G
OR
Tools (Not included)
FIRST: Adjust these screws
F
Loosen on G
(But just a little bit)

RTA-940TV
P.12 P.12
• Clean the surfaces preferable with a clean cloth damped in a solution of mild soap and
water, then dry with a clean towel.
• If you decide to use a cleaning agent, test first on an area hidden from view such as
underneath the tabletop.
• Every 4 months, inspect the unit completely and make sure that all screws are tighten.
• When transporting the unit to places far away, protect and secure the unit to avoid damage
in transit.
WEIGHT LIMITS
CARE AND MAINTENANCE
WARNINGS
• Do not exceed the indicated weight limits.
• Do not expose the surfaces to direct sunlight or to extreme environmental conditions.
• Do not use solvents or abrasive materials to clean the unit.
• Do not sit on the unit or lean against it.
• Do not allow small children to play over or inside the unit.
• Do not pull, push or drag the unit to move it for more than 1 feet. The unit must be lifted by at
least 2 persons when moving in the same or adjacent rooms.
• Before moving the unit, secure or remove your TV and objects that are heavy or might fall off.
• When lifting the unit, use both hands and bend your knees, not your backs.
• Do not use the product if screws are loose or missing, or if you notice damaged parts.
• The warranty does not extend to regular wear and tear, nor the manufacturer assumes liability
for damages or consequences due to accidents, incorrect assembly, negligence, improper use,
modifications, or not heeding the above warnings.
• Always pay close attention to small children playing near the unit or when they
are watching TV very close to it to prevent tip-over accidents.
42 Lbs
(19 Kg)
6.6 Lbs
(3 Kg)
2.2 Lbs
(1 Kg)

P.13 P.13
RTA-940TV
TECHNI MOBILI WARRANTY
RTA Products, LLC warrants to the Original Purchaser who acquired a new product from RTA
Products or its authorized resellers that this product will be free from defects in its workmanship
and materials, under normal use and service conditions, as described herein. "Defects" as used
in this warranty, is defined as any imperfections that impair the use of the furniture or product.
RTA products will repair or replace, at is option, without charge to the original purchaser ‘other
than freight from purchaser to RTA Products, only the defective products or parts for a period of
TWO (2) Years.
Replacement parts can only be supplied if parts are available. Items out of production may be
unavailable. This warranty will be effective for the applicable time period beginning the date of
purchase on your original sales receipt. RTA product’s obligation under this warranty is limited to
repairing or replacing products or parts as provided herein. This product has been designed for
and is intended for office and home-office use only. This warranty is Original Purchaser’s sole
remedy for product defects, and this warranty does not extend to any product, or damage to any
product, caused by or attributed to abuse or misuse, products used for commercial or rental
purposes, use modifications of, or attachments to the product, and products or parts not used,
maintained, or extended hereunder is in lieu of any and all other warranties, express or implied,
including without limitations any implied warranty or merchantability or of fitness for a particular
purpose. Please note, all desks made with PVC Laminate surface should not be exposed to
direct sunlight, as it may damage the material. Damage of this nature is not covered under this
warranty.
RTA Products will not be responsible for indirect, special, incidental or consequential damages.
This warranty is limited to merchandise purchased in the Continental United States, excludes
AK, HI and PR. Some States do not allow the exclusion or limitation of incidental or
consequential damages, so the above limitations or exclusions may not apply to you. This
warranty gives you specific legal rights. You may also have other rights that may vary from state
to state.
To file a Claim within the 48 contiguous United States: Email us to [email protected] to
explain the defect and provide your name, address, phone number, model number of our
product, date and place, and proof of purchase. Please provide pictures of the damage or
defect.
If we determine that a replacement will remedy the situation, and in order to determine the
extent or the cause of the defect, purchaser may be requested to send the part in question at
purchaser’s expense. Once we receive the part, we will examine it and determine whether the
claim is valid (or not), and then proceed to send the replacement. We will ship the replacement
at our expense.
Replacement Parts for International Customers & AK-HI-PR orders:
RTA Products will replace the part free of charge, while the customer is responsible for shipping
costs plus any International local taxes or duties.
TV Stand/Entertainment Center: 2 YEAR WARRANTY
