Manufacturer and equipment identication
A- Manufacturer’s name and address
B- Description of product
C- Electrical specifications and type of fuses
(700 and 500 versions)
D- Equipment classification
E- CE Mark
F- Tells you to consult the User manual
G- Serial number and date of manufacture
H- Certification mark for the USA and Canada
I- Product code
The values stated in the illustration are purely indicative; refer to the label attached to the equipment or the data in Technical
data section for the correct information.

4
Bike Excite
Manufacturer and equipment identication
Equipment with codes DAC7M..., DAC5M..., DAC2M..., DAC3M... are intended for medical use and have been designed and
built for use in outpatient clinics, hospitals, clinics and sport centres, for muscular therapy and rehabilitation.
Equipment with codes DAC7M..., DAC5M..., DAC2M..., DAC3M... can be used by or close to children, invalids, disabled
persons or people with evident physical problems only under close superUnityn of a doctor or a qualified professional.

5
Bike Excite
Description of the equipment
Control panel
Handlebar
Sensors
Fast Track Control
Saddle
Pedals
Bases
Reading stand
Tray
TGS key reader
Control panel: controls all available functions, from setting up workout programs to viewing messages and related workout
information.

6
Bike Excite
Description of the equipment
Control panel
Handlebar
Sensors
Fast Track Control
Saddle
Pedals
Bases
Reading stand
Tray
TGS key reader
Handlebar: this can be held by the user during the workout. The 700 and 700 SP versions have sensors for monitoring the heart
rate (hand sensor) and the Fast Track Control to change the effort level.

7
Bike Excite
Description of the equipment
Control panel
Handlebar
Sensors
Fast Track Control
Saddle
Pedals
Bases
Reading stand
Tray
TGS key reader
Handlebar: this can be held by the user during the workout. The 700 and 700 SP versions have sensors for monitoring the heart
rate (hand sensor) and the Fast Track Control to change the effort level.

8
Bike Excite
Description of the equipment
Control panel
Handlebar
Sensors
Fast Track Control
Saddle
Pedals
Bases
Reading stand
Tray
TGS key reader
Handlebar: this can be held by the user during the workout. The 700 and 700 SP versions have sensors for monitoring the heart
rate (hand sensor) and the Fast Track Control to change the effort level.

9
Bike Excite
Description of the equipment
Control panel
Handlebar
Sensors
Fast Track Control
Saddle
Pedals
Bases
Reading stand
Tray
TGS key reader
Saddle, adjustable height.

10
Bike Excite
Description of the equipment
Control panel
Handlebar
Sensors
Fast Track Control
Saddle
Pedals
Bases
Reading stand
Tray
TGS key reader
Pedals: with adjustable straps for a more stable foot position.

11
Bike Excite
Description of the equipment
Control panel
Handlebar
Sensors
Fast Track Control
Saddle
Pedals
Bases
Reading stand
Tray
TGS key reader
Bases: support the equipment frame and components.

12
Bike Excite
Description of the equipment
Control panel
Handlebar
Sensors
Fast Track Control
Saddle
Pedals
Bases
Reading stand
Tray
TGS key reader
Reading stand: for standing magazines or books on.

13
Bike Excite
Description of the equipment
Control panel
Handlebar
Sensors
Fast Track Control
Saddle
Pedals
Bases
Reading stand
Tray
TGS key reader
Tray: for standing the water bottle or other useful items on during the workout.

14
Bike Excite
Description of the equipment
Control panel
Handlebar
Sensors
Fast Track Control
Saddle
Pedals
Bases
Reading stand
Tray
TGS key reader
TGS key reader: for the TGS key (optional).

15
Bike Excite
Technical data
Bike 500 and 700
Power supply 100÷240 Vac 50/60 Hz
Mains power input 100 VA max (160 VA max with Unity)
Fuses 2 x 3.15A (F)
Weight of equipment 61 kg (135 lb)
Maximum user weight 180 kg (397 lb)
Time 0÷999 min ± 1% (0÷99.99 mls ± 5%)
Distance 0÷99.99 km ± 5%
Braking power 40÷500 W ± 10%
Protection grade IP 20
Electric isolation class Class I
Marks and Certificates CE - UL(*)
Bike 500 SP and 700 SP
Weight of equipment 61 kg (135 lb)
Maximum user weight 180 kg (397 lb)
Time 0÷999 min ± 1%
Distance 0÷99.99 km ± 5% (0÷99.99 mls ± 5%)
Braking power 40÷500 W ± 10%
Protection grade IP 20
Electric isolation class Class I
Marks and Certificates CE - UL(*)
(*) Only if the symbol is present on the equipment identification label.

16
Bike Excite
600 mm
(24")
1338 mm
(53")
1216 mm
(48")
1185 mm
(47")
Technical data

17
Bike Excite
A
B
D
E
F
C
Accessories
The equipment’s standard outfit comprises:
ASet of wrenches
BUser manual
CWarranty certificate
DCEE Power Supply cable with SH socket (700 and 500 versions)
ETwo replacement fuses (2 x 3.15A (F) (700 and 500 versions)
FChest band with transmitter for heart rate monitor (optional)

18
Bike Excite
B C
A
Safety devices and notices
AFixed guard: guards against access to the inside of the equipment.
BMain switch: turns the equipment’s power on and off (700 and 500 versions).
CFuses: they protect the equipment’s electrical parts (700 and 500 versions). When the current reaches an excessive value,
the fuses melt thus protecting the internal electronics.

19
Bike Excite
E
F
G
Safety devices and notices
Warning
Please read the adhesive labels on the equipment, which provide information about possible risks and hazards.
In the 700 and 500 versions:
EThe label affixed to the frame under the control panel states the electrical
specifications.
FThe label, which can be affixed close to the main switch, states safety
indications.
GThe label which can be affixed to the power supply cable states the
electrical specifications for the cable.
CAUTION: do not connect a device with load
exceeding 7 A
CAUTION: do not connect to a circuit operating
at more than 150V to ground
CAUTION: risk of electric shock. Do not
disconnect under load

20
Bike Excite
Place of installation
To ensure that exercising with Bike is easy, safe and effective, the place where it is used should comply with certain specific
requirements; in particular, before choosing the place where the equipment will be installed, please ensure that the following
conditions are satisfied:
- the temperature is between +10°C and +25°C;
- enough air is circulating to keep humidity during exercise to between 20% and 90%;
- the lighting is good enough to make the area safe and relaxing place to exercise in;
- plenty of free space around each item of equipment;
- that the floor is flat, stable and vibration-free, and strong enough to bear the weight of the equipment plus user.
The place of installation must comply with all the suitability requirements laid down in current legislation on this matter.
Equipment not suitable for use in the presence of anaesthetic mixtures inflammable in air, oxygen or nitrous oxide.
In order to guarantee the performance indicated by the manufacturer, you are advised against using the equipment in zones
with high short-wave presence or similar.
