Technogym GROUP CYCLE User manual

CONSOLE
User manual

2
Group Cycle - Console
CONTENTS
Description of the buttons.......................................................................................3
Description of the display........................................................................................4
Starting an exercise..................................................................................................7
Technogym threshold power test ...........................................................................8
Using the chest strap .............................................................................................10
Heart rate and power values .................................................................................12
Entering personal data...........................................................................................13
Choosing units of measurement...........................................................................14

3
Group Cycle - Console
DESCRIPTION OF THE BUTTONS
During the warm-up, press this button to start the exercise.
During the exercise, press this button to pause the exercise.
During the exercise or when paused, press and hold this button to end the exercise and view the results.
During the warm-up and during the exercise, press these buttons to scroll through the pages with the workout data.
Press and hold these two buttons simultaneously within a minute of the display turning on to start the Technogym threshold
power test.
No workout must be in progress.
Press this button to connect the chest strap.
Press and hold these two buttons simultaneously within a minute of the display turning on to enter personal data: age, weight
and functional threshold power.
Press and hold these three buttons simultaneously within a minute of the display turning on to choose the units
of measurement: km, kg / miles, lbs.

4
Group Cycle - Console
DESCRIPTION OF THE DISPLAY
The product is self powered.
Pedal for a few seconds to turn on the display.
To switch o the display, stop pedalling for at least 30 seconds; the product will also switch o if the pedal cadence is below 40 rpm.
The workout values are divided into 4 pages.
At the start of the exercise, the 4 pages are displayed in alternating fashion for around 10 seconds. Then the rst page remains displayed.
Press the arrow buttons to scroll through the pages.
This symbol indicates that the Wi-Fi connection is active.
If the connection is active, it is possible to log in.
This symbol indicates that the user has logged in.
You can log in with the TGS key, or with the mywellness app using NFC,
QR-Code or Bluetooth Smart.
Page 1 Page 2 Page 3 Page 4

5
Group Cycle - Console
DESCRIPTION OF THE DISPLAY
Page 1 contains the following:
Pedal cadence, expressed in revolutions per minute (rpm).
Instantaneous power, expressed in watts.
Instantaneous heart rate, expressed in beats per minute.
Eort level
Page 2 contains the following:
Pedal cadence, expressed in revolutions per minute (rpm).
Page 3 contains the following:
Average pedal cadence since the start of the exercise, expressed
in revolutions per minute (rpm).
Instantaneous speed, expressed in km/h.
Calorie consumption, expressed in kilocalories.
Distance covered, expressed in kilometres.
Page 4 contains the following:
Maximum pedal cadence reached, expressed in revolutions per
minute (rpm).
Maximum power reached, expressed in watts.
Maximum heart rate reached, expressed in beats per minute.
Calorie consumption, expressed in MOVE.
Ratio between instantaneous power and threshold power,
expressed as percentage of watts.
Ratio between instantaneous heart rate and maximum heart rate,
expressed as a percentage of beats per minute.
Exercise duration in minutes and seconds.

6
Group Cycle - Console
DESCRIPTION OF THE DISPLAY
The heart rate is displayed only if the chest strap is connected.
The time is displayed only during the exercise, not during the warm-up phase.
The ratio between instantaneous power and threshold power is displayed only if the threshold power is known. The threshold power is calculated with the
Technogym threshold power test.
The ratio between instantaneous heart rate and maximum heart rate is displayed only if the age is known.
Depending on the product setting, the distance and speed values can be displayed in km and km/h, or in mi and mph, on page 3.
If the user has not logged in or entered their weight, the calorie consumption is calculated on the basis of a default 70 kg bodyweight.

7
Group Cycle - Console
STARTING AN EXERCISE
To switch on the display, pedal for a few seconds at a cadence of at least 40 rpm.
The warm-up phase begins.
The duration is not counted during the warm-up.
Press this button during the warm-up to start an exercise.
When the exercise begins, all values are reset and the calculations start again.
It is possible to connect the chest strap both during the warm-up and the exercise.
If the Wi-Fi connection is active, it is possible to log in: this means that the results will be saved to the personal prole.
Press this button to pause the exercise.
Press and hold this button to stop the exercise.
At the end of the exercise the results are displayed; these are divided across 2
pages.
Press the arrow buttons to scroll through the pages.

8
Group Cycle - Console
TECHNOGYM THRESHOLD POWER TEST
This test allows you to calculate your threshold power.
If you have also connected a chest strap, the threshold heart rate will also be calculated. To obtain this result, the chest strap must be connected before
starting the test.
Before the test it is advisable to perform a warm-up of at least 20 minutes at increasing levels of intensity.
Press and hold these two buttons simultaneously within a minute of the display turning on to start the power test.
No exercise must be in progress.
After pressing the start button, a 5-second countdown will begin.
The test lasts 20 minutes in total, as described below.
If this is the rst time you are taking the test, or if the test was last taken a long time ago
2 minutes In the rst 2 minutes, adjust the intensity until you nd a level of exertion you perceive as moderate.
Choose a cadence between 70 and 100 rpm and keep it constant.
14 minutes Keep the same cadence and intensity of the previous phase constant.
4 minutes Increase the cadence and intensity to reach your maximum possible level of performance.

9
Group Cycle - Console
TECHNOGYM THRESHOLD POWER TEST
If you have taken the test recently, and so your threshold power is known
16 minutes Maintain 70% of the threshold power resulting from the last test for the rst 16 minutes.
Choose a cadence between 70 and 100 rpm and keep it constant.
4 minutes Increase the cadence and intensity to reach your maximum possible level of performance.
During the test, the following data are shown on the display:
- Pedal cadence, expressed in revolutions per minute (rpm).
- Instantaneous power, expressed in watts.
- Heart rate, expressed in beats per minute. This value is shown if the chest strap is connected.
- Time remaining to the end of the test, in minutes and seconds.
The test cannot be interrupted for a pause.
At the end of the test it is advisable to cool down for 3 minutes.
At the end of the test, the following data are shown on the display:
- Threshold power, expressed in watts.
- Threshold heart rate, expressed in beats per minute. This value is shown if the chest strap is connected.
If the user has logged in, the results of the test are saved to their personal prole; during subsequent training sessions, the ratio between the instantaneous
power output and threshold power is shown on the display.

10
Group Cycle - Console
Receiver
USING THE CHEST STRAP
The lower part of the display contains a receiver which receives the heart rate signals from the
telemetric chest strap.
The transmission technology used is Bluetooth Smart.
The connection must be repeated with each workout.
Press this button to connect the chest strap. The chest strap must be less than 30 cm from the receiver.
Keep as close to the receiver as possible for 10 seconds to facilitate the connection.
The heart icon ashes on the display while the connection is being negotiated; then, when the connection has been successfully
established, the icon remains lit and the instantaneous heart rate is displayed.
The heart rate is expressed in beats per minute.
If the AVG (average) symbol is present, this means that the average heart rate since the beginning of the exercixe is being
displayed.
If the MAX symbol is present, this means that the maximum heart rate reached during the exercixe is being displayed.
If the %symbol is present, the value shown indicates the ratio between the measured heart rate and the maximum heart rate.
The user's maximum heart rate (100%) is calculated on the basis of age using the following formula: HRmax = 206.9 - 0.67 x age (R. L. Gelish).
If the user's age has not been entered, the default value of 30 will be used.

11
Group Cycle - Console
USING THE CHEST STRAP
W
During a workout it is very important that your heart rate never go above 90% of the maximum (unless you are an athlete engaged in competitive
sport).
The sole function of the heart rate monitor is to display the heart rate during exercise and cannot be used for medical cardiac diagnoses of any
kind. The heart rate shown on the display is purely indicative and cannot be considered absolutely certain.
To avoid interference, equipment should be kept at a minimum distance of 170 cm, as shown in the gure.
Heart rate readings may not be accurate near sources of electromagnetic radiation (TVs, mobile
phones etc.).
Should you have any doubts about the accuracy of the readings, contact the Technical Support
Service.
In the event of diculties connecting the chest strap:
- Check that the battery is not at.
- Check that the chest strap is not already connected to other devices.
170 cm
170 cm
170 cm

12
Group Cycle - Console
HEART RATE AND POWER VALUES
Blue
The table shows the training intensity zones with respect to the user's maximum heart rate and functional threshold power (FTP).
The functional threshold power is the maximum power that a subject is able to put out in an hour.
The “% FTP” column gives the ratio between the instantaneous power and the threshold power; this value is expressed as a percentage of watts.
The %FTP value is shown on the display only if the threshold power is known. The threshold power is calculated using the Technogym threshold power test.
The “% MAX HR” column indicates the ratio between the instantaneous heart rate and the maximum heart rate, expressed as a percentage of beats per minute.
This value is shown on the display only if the user's age is known.
The zone column provides information on how to maximise your training on the basis of your specic goal.
The colours (blue, green, yellow, orange, red) help the instructor to guide users when the Group Cycle application is also used.
Active recovery
Endurance
Medium exertion
Lactate threshold
VO2max
Aerobic capacity
Neuromuscular power
% MAX HR% FTPZONE
Red
Orange
Yellow
Green
COLOUR
≤ 55%
56 - 75%
76 - 90%
91 - 105%
106 - 120%
121 - 150%
-
≤ 60%
61 - 70%
71 - 80%
81 - 90%
91 - 100%
-
-

13
Group Cycle - Console
ENTERING PERSONAL DATA
A default threshold power value of 100 watts is displayed.
Press the arrow buttons to set your threshold power, as given by the test.
Press the start exercise button to conrm and proceed to the next parameter.
A default bodyweight of 70 kg is displayed.
Press the arrow buttons to set your actual weight.
Press the start exercise button to conrm and proceed. A warm-up phase now begins.
The user's age is required to calculate the maximum heart rate. If the age is entered, the ratio between the measured heart rate and maximum heart rate is
calculated during the exercise.
The user's weight is required for precise calorie burn data.
The threshold power is calculated with the test. If the threshold power value is entered, the ratio between instantaneous power and threshold power will be
calculated during the exercise.
If the Wi-Fi connection is active and the user has logged in, it is not necessary for him to enter his age and weight; if the test result is stored in his personal
prole, it is similarly not necessary to enter the threshold power.
Press and hold these two buttons simultaneously within a minute of the display turning on to enter age, weight and functional
threshold power values.
The default age of 30 is displayed.
Press the arrow buttons to set your actual age.
Press the start exercise button to conrm and proceed to the next parameter.

14
Group Cycle - Console
CHOOSING UNITS OF MEASUREMENT
Press and hold these three buttons simultaneously within a minute of the display turning on to choose between
metric and imperial/US measurements.
The display shows KM.
Press the arrow buttons to set KM or MI.
Press the start exercise button to conrm and proceed to the next parameter.
The display shows kg.
Press the arrow buttons to set kg or lbs.
Press the start exercise button to conrm and exit.
If the user has logged in, the unit of measurement set in his personal prole will be used.

Group Cycle D92_en_AB
0SM00958
