Technoline WS9620 User manual

RADIO CONTROLLED WIRELESS WEATHER
STATION
User’s instructions
43 3M Hz
THERM O SENSOR

The multifunctional weather station is equipped with many
functions providing thorough weather information to you.
The receiver unit has a clear, easy-to-read display that
shows weather forecast, minimum/maximum indoor and
outdoor temperature, as well as time and date. It is able to
receive and display readings from up to 3 remote sensors.
The 433 MHz technology means no wire installation is
required and you can place the sensors anywhere you like.
With radio controlled function, the current time and date are
automatically synchronized with the time signal transmitted
from Germany (DCF77) / UK (MSF) / USA (WWVB) (It
depends on which version you purchase).

114
MAIN FEATHERS:
WEATHER STATION:
1. SNOOZE/LIGHT:
- Press it once to turn on the backlight for 5 seconds.
- Press it to stop the alarm when it is sounding
2. WEATHER INDICATOR WINDOW:
- Shows the weather forecast indicators and moon phase.
3. TEMPERATURE WINDOW:
- Shows the indoor and outdoor temperature.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15 16
No. of remote unit:
RF transmission range:
Temperature sensing cycle:
Radio controlled signal:
POWER
Main unit:
Remote sensor:
DIMENSION
Main unit:
Remote sensor:
up to 3 units
maximum 80 meters free field
around 60-64 seconds
DCF
3V, use 2 xAA 1.5V alkaline
battery
3V, use 2 xAA 1.5V alkaline
battery
86(W) x 164(H) x 60(D) mm
65(W) x 115(H) x 20(D) mm

2
13
4. CLOCK TIME WINDOW
- Displays normal time, alarm time, date and day of the week.
5. TIME key:
- Press and hold it for 2 seconds to enter normal time
setting.
- In normal time setting, press it to step the setting items.
6. ALM key
- Press it to switch between Month/Date and alarm time
mode.
- Press it to stop the current alarm when the bell is ringing
and turn off the alarm and snooze function.
- In alarm time mode, press and hold it for 2 seconds to
enter alarm time setting.
7. UP key
- In setting mode, press it to increase the setting values.
- In normal time mode, press it to switch among Channel
1, 2 and 3.
- In alarm time mode, press it to turn on/off the Alarm and
Snooze.
8. DOWN key
- In setting mode, press it to decrease the setting values.
- In normal time mode, press is to switch between
Second and Day of the week display.
9. MAX/MIN key
- Press it to check th e minimum and maximum
temperature records.
USING THE TABLE STAND OR WALL MOUNTING
The receiver has both desktop and wall-mounting structure.
Place the screw on the desired wall and hang the clock by
the wall mount in the back of it or just simply place it on the
desktop by its table stand.
For the transmitter, fix the wall-mount holder on the wall or
simply place it on the table.
SPECIFICATIONS
MAIN UNIT
Recommended operating
range:
Resolution:
RF transmission frequency:
0°C to 45°C
32°F to 113°F
0.1°C/1°F (above 0°C/32°F)
1°C/°F (below 0°C/32°F)
433MHz

312
- Press and hold it for 3 seconds to delete the minimum
and maximum temperature records.
10. °C/°F key
- Press it to switch between Celsius and Fahrenheit.
- Press and hold it for 3 seconds to receive the RC signal
for reception testing.
11. YEAR key
- Press it to switch between Month/Date and Year display.
12. CHANNEL key
- In setting mode, press it to increase the setting values.
- In normal time mode, press it to switch among Channel
1, 2 and 3.
- In alarm time mode, press it to turn on/off the Alarm and
Snooze.
13. RESET key
- Press it to set all values to default values.
- In case of mal-function, the unit may be required to reset.
14. WALL-MOUNTING HOLDER
- Use it to support the main unit on the wall.
15. BATTERY DOOR
16. TABLE STAND
- Use it to stand the clock on the desktop.
on the weather. In bad weather the displays will not
appear.
BATTERY REPLACEMENT
When the LCD becomes dim, replace with 2 new AA size
batteries at once; while if the low battery indicator “ ”
displays in the channel window, it indicates that the battery
power of the transmitter is not enough, and you should
replace with 2 x AA size batteries at once.
NOTE:
Attention! Please dispose of used unit or batteries in an
ecologically safe manner.
Waxing crescentNew moon First quarter Waxing gibbous
Full moon Waning gibbous Last quarter Waning crescent
Transmitter’s low battery indicator

4
11
TRANSMITTER
1. LED indicator:
- Flashes when the remote unit transmits a reading.
2. CHANNEL SLIDE S WITCH:
- Assign the transmitter to Channel 1, 2 or 3.
3. RESET:
- Press it to restart the transmitter.
4. BATTERY COMPARTMENT:
- Accommodates 2 x A A size batteries.
5. BATTERY DOOR
6. WALL-MOUNTING HOLDER:
- Use it to support the transmitter on the wall.
7. TABLE STAND:
- Use it to stand the transmitter on the desktop.
BEFORE USING THE TRANSMITTER
1. Remove the battery door.
5
43 3MH z
THERMO S ENSOR
1
3 2
4
6
7
thoroughly. Try out where the station
receives the signals best.
CHECKING AND DELETING MAX/MIN TEMPERATURE
RECORDS
1. Press “MAX/MIN” key once to check the maximum
temperature records. Press it twice to check the
minimum records. Press it again to exit.
2. Press and hold “MAX/MIN” for 3 seconds to delete the
maximum and minimum temperature records with
“beep” tone.
ABOUT THE MOON PHASE
The unit has 8 different moon phases. It will change
according to the lunar calendar.
NOTE
1. The icon of the sun will be displayed from 6am to 8pm,
the moon phase and stars will be displayed from 8pm
to 6am.
2. Display of the sun, moon phase and the stars depends
MAX. Temperature records MIN. Temperature records

510
2. Insert 2 x AA size batteries into the battery compartment.
Make sure you insert them the right way according to
the polarity info rmation marked on the battery
compartment.
3. Replace the battery door.
NOTE:
1. Once the channel is assigned to one transmitter, you
can only change it by removing the batteries or resetting
the unit.
2. Avoid placing the transmitter in direct sunlight, rain or
snow.
WEATHER STATION:
1. Remove the battery door and insert 2 x AA batteries into
the battery compartment. Make sure you insert the
batteries the right way according to the polarity
information marked on the battery compartment.
2. Replace the battery door.
3. Press the “RESET” key to re-start the clock and it will
synchronize the channels of transmitter automatically.
NOTE:
1. The building material and the position of the receiver
and transmitter affect the effective range. So try various
locations to obtain the best result.
2. Place the units away from metal objects and electrical
appliances to minimize the interference. Position the
receiver and transmitter within the effective
transmission range: 80m free field in usual circumstances.
NOTE:
1. The alarm and snooze will be automatically turned on
when setting the alarm time.
2. Once the snooze is turned on, the 4-step crescendo
alarm will sound 4 times in 5-minute interval. The alarm
duration is 60 seconds.
3. Pressing the “SNOOZE/LIGHT” key can stop the current
alarm and enter the snooze mode; while pressing the
“ALM” key can not only stop the alarm but also turn off
the snooze function.
VIEW THE CHANNEL
The default channel is Channel 1. In normal time mode,
press “UP” or “CHANNEL” key to view the channel from 1 to
3. Besides, the channels can automatically switch by pressing
and holding the “UP” or “CHANNEL” key for 3 seconds.
READING INDOOR/OUTDOOR TEMPERATURE RECORDS
Change the temperature unit to °C for Celsius or °F for
Fahrenheit by pressing “°C/°F” key.
NOTE:
1. If no signals are received or the transmission is
interfered, “—” will appear on the LCD.
2. Relocate the clock or transmitter in other positions
and make sure the transmission is within the effective
range of 80m approx.
3. After several trails in vain, please reset the clock

6
9
ABOUT THE WEATHER INDICATOR
The built-in barometer can notice atmospheric pressure
changes. Based on the data collected, it can predict the
weather conditions in the forthcoming 12-24 hours.
NOTE:
1. The accuracy of a general pressure-based weather
forecast is about 70% to 75%.
2. The weather forecast is meant for next 12 to 24 hours,
it may not necessarily reflect the current situation.
3. The “Snowy” weather forecast is not based on the
atmosphere pressure, but based on the outdoor
temperature. When the outdoor temperature is below
-3°C (26°F), the “Snowy” weather indicator will be
displayed on the LCD.
RECEPTION OF RADIO CONTROLLED TIME SIGNAL
The time and date are radio-controlled. The current time
and date are automatically synchronized with the time
signal transmitted from Germany (DCF 77)
Sunny Slightly cloudy Cloudy
Rainy Stormy Snowy
4. The 5 languages weekday settings are represented by
the below abbreviations: GB= English FR= French
DE=German ES= Spanish IT= Italian
5. Press “TIME” key to confirm and exit the setting or let it
exit automatically 30 seconds later without pressing
any key.
ALARM AND SNOOZE SETTING
1. In normal time mode, press “ALM” key to enter the
alarm time mode.
2. In alarm time mode, press “UP” key to turn on the
alarm and snooze with the bell icon“ ” and snooze
icon “Zz” displayed together on the LCD.
3. In alarm time mode, press and hold “ALM” key for 2
seconds to enter alarm time setting mode until the
alarm Hour digit flashes.
4. Press “UP” or “DOWN” key to change the value of the
flashing Hour digit.
5. Repeat the above operation to set the alarm Minute.
6. After complete all settings, press “ALM” key to exit the
setting, or let it exit automatically 30 seconds later
without pressing any key.
DO
LU
MA
MI
JU
VI
SA
DO
LU
MA
ME
GI
VE
SA
English
SO
MO
DI
MI
DO
FR
SA
German
DI
LU
MA
ME
JE
VE
SA
French Spanish Italian
SU
MO
TU
WE
TH
FR
SA

7 8
When used for the first time (after inserting the batteries or
pressing the “RESET” key), the clock will start to receive the
RC signal in 5 minutes with the signal strength indicator
flashing.
SIGNAL STRENGTH INDICATOR
The signal indicator displays signal strength in 3 levels.
Wave segment flashing means time signals are being
received. The signal quality could be classified into three
types:
NOTE:
1. Everyday the unit will automatically search for the time
signal at 2:00, 8:00, 14:00 and 20:00.
2. Always place the unit away from interfering sources
such as TV set, computer, etc.
3. Avoid placing the unit on or next to metal plate.
4. Closed area such as airport, basement, tower block
or factory is not recommended.
5. Do not start reception on a moving article such as
vehicle or train.
Weak signal quality
Acceptable signal quality Excellent signal quality
DAYLIGHT SAVINGS TIME (DST)
The clock has been programmed automatically to switch
when the daylight savings time is in effect.Your clock will
show “DST” during the summer.
MANUAL TIME AND CALENDAR SETTING
If you are out of the reach of the Radio Controlled Transmitter
or if the reception is not reachable, the time can be set
manually. As soon as the signal of transmitter is received
again, the clock will automatically synchronize with the
exact time.
1. In normal time mode, press and hold the “TIME” key
for 2 seconds until the HOUR digit flashes.
2. Press the “UP” or “DOWN” key to change the value of
the flashing HOUR digit.
3. Repeat the above operation to set the time and
calendar in this order: Hour > Minute > Second > 12/24
Hr > Year > Month > Date > Day language.
