WS6825 - INSTRUCTION MANUAL
LED WEATHER STATION WITH RADIO CONTROLLED CLOCK AND ALARM

Words in the figure:
ENGLISH
OTHER LANGUAGE
Front view
ALARM ON
TIME
RCC INDICATOR
INDOOR TEMPERATURE
OUTDOOR TMEPERATURE
WEATHER FORECAST
Back view
SNOOZE/DIMMER
UP/RF
SET
ALARM
DOWN/WAVE
RESET
AC/DC ADAPTOR
DC SOCKET
INSERT AC/DC
ADAPTOR JACK
STAND HOLE
INSERT 1 x CR2032
BATTERY INSIDE THE
BATTERY COMPARTMENT
BATTERY DOOR
HANGER HOLE
OUTDOOR TEMPERATURE SENSOR
LED
RESET
STAND
CHANNEL 1
CHANNEL 2
CHANNEL 3
INSERT 2 x AAA BATTERIES

ENVIRONMENTAL RECEPTION EFFECTS
The weather station obtains the accurate time with wireless technology. Same as all wireless devices,
the reception is maybe affected by the following circumstances:
Long transmitting distance
Nearby mountains and valleys
Among tall buildings
Near freeway, railway, airports, high voltage cable etc.
Near construction site
Inside concrete buildings
Near electrical appliances (computers, TV’s, etc)
Inside moving vehicles
Near metallic structures
Place the station at a location with optimal signal, i.e. close to a window and away from metal surfaces
or electrical appliances.
QUICK SETUP
Step 1 Keep the station and outdoor sensor next to each other. Slide open the battery cover at the
back of the outdoor sensor. Make sure the channel selector is set at position 1 (top position), then
insert 2 x AAA batteries (not included) into the outdoor sensor by observing the correct “+/-“polarity
signs inside the battery compartment. Replace the battery door.
Step 2 Insert the AC/DC adaptor to any 230V AC household outlet. Then insert the DC jack to the
back case of the station. Insert the stand to the bottom of the weather station.
Step 3 Slide open the battery cover at the back of the station, then insert 1 x CR2032 Lithium battery
(not included) to the battery compartment. Make sure “+” polarity of the battery is facing up. Then
replace the battery cover.
Step 4 Peel off the protective label on the front. The weather station is ready to work for you.
The station will receive data signal from the outdoor sensor in few seconds. Then place the outdoor
sensor in a dry and shaded area outdoor.
BACK-UP BATTERIES
When the power supply is not in use, the station will be powered by the back-up batteries. The LED
display is turned off, but time and alarm time remain stored (also in the event of a power failure).
DCF SIGNAL RECEPTION AND SIGNAL INDICATOR
After the station is powered up, it starts to receive DCF signal. The icon flashes.
Receiving DCF signal ( icon flashing)
Successful reception ( icon becomes static)
Failed reception ( icon disappear)
During reception, press the / WAVE button will display reception mode and signal strength indication:
When strong DCF signal is detected, display shows with 3 bars .
When weak or no DCF signal is detected, display shows or .

During reception, the signal strength may move from 1 bar to 2 bars to 3 bars. This is normal since
the clock is detecting DCF signal and other signals in the air at the same time. Press the SET button
will return to the time display with icon flashing.
Successful reception or failed reception
Icon becomes static on (stop blinking) when reception is successful.
Icon disappears when reception is failed.
Automatic reception and manual reception
The station starts automatic reception everyday at 1:00, 2:00, and 3:00. If it fails to receive the DCF signal
at 3:00, it will start reception at 4:00. If it fails again, it will start reception at 5:00. If it fails again, it
will start automatic reception at 1:00 again in the next day.
For manual reception simply press and hold the / WAVE button, the station will gives a short beep
and starts manual reception. Press and hold the / WAVE button to stop DCF reception.
When the weather station is receiving the radio controlled time signal, the display will turn dimmer. It
will resume to the brightness level which you originally selected after the radio controlled time
reception is completed.
During DCF reception all buttons do not function and it does not take temperature measurement. The
temperature readings will get stable and become more accurate after the station clock is powered up
for around 30 minutes.
To cancel DCF reception permanently
Press and hold the / WAVE and the button at the same time for 2 seconds, the station will give
2 short beeps and the radio controlled function is permanently disabled.
To resume the radio controlled function, press and hold the / WAVE and the button at the
same time for 2 seconds, the station will give 2 short beeps and will start DCF reception immediately.
THE WEATHER FORECAST
The weather station has a built-in barometer which measures the barometric pressure. After power
up, the display shows SUNNY & CLOUDY icon. The weather station takes around 24 hours to gather
data of barometric pressure changes and predicts next 6-12 hours weather conditions.
There are four types of weather display in the weather station:
Sunny
Sunny & Cloudy
Cloudy
Rainy
Note: Moving the weather station within the house or in the vicinity will causing a sudden change in
the attitude of the station and it affects the accuracy and correctness of the weather forecast. After
the weather station is powered up, it will take around 24 hours to get stable. The weather icons on
the display give a reference to the next 6-12 hours weather conditions. It may not match with the
current weather condition outside.

TIME SETTING
1. Press and hold the SET button for 2 seconds, hour digits flash. Press the or the button to
set the hours.
2. Then pressthe SET button again, the minute digits flash. Press the or the button to set the minutes.
3. Then press the SET button again, display shows 05 and flash. Press the or the button to
set snooze duration from 5 minutes to 60 minutes.
4. Then press the SET button again, display shows 00 and flash. Press the or the button to
set the time zone:
“-01” GMT +0 (United Kingdom)
“00” GMT +1 (Central Europaen time)
“01” GMT +2 (Eastern Europaen time)
Note: Time zone can only set when the clock successfully receives a radio signal.
5. Press the SET button again to store the settings and return to normal time display. The clock
will return to normal mode in around 10 seconds if no further press of any other buttons.
Note: The time is displayed in 24-hour display format.
ALARM SETTING
(default alarm setting is 6:00 AM)
1. Press and hold the ALM button until the AL icon appears on the display, the hour digits flash.
Press the or the button to set the desired alarm hours.
2. Press the ALM button again, the minute digits flash. Press the or the button to set the
desired alarm minutes.
3. Press the ALM button again to store the alarm settings and return to normal time display. The
clock will return to normal mode in around 10 seconds if no further press of any other buttons.
To turn on or off the alarm
Single press the ALM button during normal time display to turn on or off the alarm. When the alarm
function is turned on the AL icon appears on top of the time digits.
Note: Alarm duration is 2 minutes.
To use the snooze function
When time reaches the set alarm time, the station will give a beep sound to wake you up. The AL
icon will flash.
1. Press SNOOZE once to stop the alarm temporarily, AL icon keeps flashing. The alarm will
beep again after the set snooze duration.
2. To stop the daily alarm, press any button except the SNOOZE button when alarm is beeping.
The alarm will stop and AL icon becomes static. The Alarm will beep again same time next day.
DIMMER FUNCTION
Press the SNOOZE / DIMMER button to adjust high or low brightness of the LED display.
TROUBLE SHOOTING
In case the station shows false digits, it maybe affected by electrostatic discharge or interferences
from other devices. Press the RESET button on the back of the station. The station will be reset to
default setting of time and calendar and it will start to receive radio controlled time signal again.

If you lose the outdoor temperature
When the outdoor temperature digits show “--“, the wireless transmission is either interrupted or lost.
Press and hold the button of the station, then press the RESET button located on the back of the
outdoor transmitter. If you continue to lose the outdoor temperature display, try placing the transmitter
in a different location until you have smooth transmission of temperature data.
Note: Keep in mind that the outdoor transmitter only has a 30 meter transmission range in open area
with no obstructions. Each obstruction between the transmitter and the station (roof, walls, floors,
ceilings, thick trees, etc.) will effectively cut the transmission range in half.
CARE OF THIS ITEM
Do not expose the unit to extreme temperature, water or direct sunlight.
Avoid contact with any corrosive materials.
Do not subject the unit to excessive force, dust or humidity.
Do not open the inner back case or tamper with any components of this unit.
SPECIFICATIONS
Operation temperature: 0°C to +45°C
Temperature measuring range:
Indoor: 0°C to +50°C
(display shows HH.H / LL.L if out of this range)
Outdoor: -50°C to +70°C
(display shows HH.H / LL.L if out of this range)
Temperature resolution: 1°C
Alarm duration: 2 minutes
Snooze duration: 5 to 60 minutes
Consideration of duty according to the battery law
Old batteries do not belong to domestic waste because they could cause damages of
health and environment . End-users are committed by law to bring back needed
batteries to distributors and other collecting points!
