TECshow ALFIE STREAM User manual

P. 1
Versión Español | Tecshow NEBULA PAR 162 II
ALFIE STREAM
MINI BEYE LED MOVING HEAD LIGHT
USER MANUAL | MANUAL DE USUARIO
PLEASE READ THE INSTRUCTIONS CAREFULLY BEFORE USE
POR FAVOR LEA LAS INSTRUCCIONES ANTES DE USAR

P. 2
English Version | Tecshow ALFIE STREAM
ALFIE STREAM
MINI BEYE LED MOVING HEAD LIGHT
ALFIE STREAM is a compact moving head designed
to deliver powerful multicolored beams oering
eects at high speed. Its rotating panel equipped
with powerful 4in1 LEDs and a central green laser
facilitate ultra-fast and variable movements capable
of delivering total dynamism in all types of settings.
Specifications
Source & Optics
• Light Source: 6 x 12W 4-en-1 LEDs
• Power: 90W
• Voltage: AC95V-245V, 50Hz
• Beam angle: 2º
Movement
• Pan 540 °
• Tilt 180° (16-bit)
Eects & Functions
• Dimmer: 0~100% smooth dimmer
• Strobe: 20 times/second
• Integrated programs
• 4-in-1 LED technology
Control
• DMX channels: 12
• Operational modes: DMX512, Master/Slave
Auto, Sound Control
Physical
• LED display
• Dimensions: 20.5 x 15 x 27cm
• Weight: 2.58 Kgs / 5.7 Lbs.
1· OVERVIEW

P. 3
English Version | Tecshow ALFIE STREAM
• To reduce the risk of electrical shock or re, do
not expose this unit rain or moisture.
• Do not spill water or other liquids into or on to
your unit.
• Do not attempt to operate this unit if the power
cord has been frayed or broken.
• Do not attempt to remove or break o the ground
prong from the electrical cord. This prong is used
to reduce the risk of electrical shock and re in
case of an internal short.
• Disconnect from main power before making any
type of connection.
• Do not remove the cover under any conditions.
There are no user serviceable parts inside.
• Never operate this unit when it’s cover is
removed. Always be sure to mount this unit in
an area that will allow proper ventilation. Allow
about 15cm between this device and a wall.
• Do not attempt to operate this unit, if it becomes
damaged.
For your own personal safety, please
read and understand this manual
completely before you attempt to
install or operate this unit!
2. SAFETY INSTRUCTIONS
• This unit is intended for indoor use only, use of
this product out- doors voids all warranties.
• Always mount this unit in safe and stable matter.
• Power-supply cords should be routed so that they
are not likely to be walked on or pinched by items
placed upon or against them, paying particular
attention to cords at plugs, convenience
receptacles, and the point where they exit from
the appliance.
• Cleaning -The xture should be cleaned only as
recommended by the manufacturer.
• Heat -This xture should be situated away from
heat sources such as radiators, heat registers,
stoves, or other appliances (including ampliers)
that produce heat.
• The xture should be serviced by qualied
service personnel when:
A. Objects have fallen, or liquid has been spilled
into the appliance.
B. The appliance has been exposed to rain
or water.
C. The appliance does not appear to operate
normally or exhibits a marked change in
performance.

P. 4
English Version | Tecshow ALFIE STREAM
3. SYSTEM MENU
4. DMX CHANNELS
OPTION INSTRUCTION
A001-A512 DMX Address Setting
A1 1-A1 9 Auto Running Mode
S1 1-S1 9 Sound Control Mode, 1-9 means the sound sensitive.
CHANNEL FUNCTION DMX VALUE DESCRIPTION
1Pan 0-255 0-540° move.
2Tilt 0-255 0-180° move.
3P/T Speed 0-255 P/T Speed from fast to slow.
4Lens Wheel
Rotation
0-127 0-360° rotate.
128-191 Forward endless rotate from slow to fast.
192-255 Reverse endless rotate from slow to fast.
5Dimmer 0-255 Linear dimmer from dark to brighter.
6Strobe 0-9 No Function.
10-255 Strobe from slow to fast.
7Red 0-255 Red dimmer from dark to brighter.
8Green 0-255 Green dimmer from dark to brighter.
9Blue 0-255 Blue dimmer from dark to brighter.
10 White 0-255 White dimmer from dark to brighter.
11 Macro
Function
0-50 CH1-CH1 Valid.
51-150 Random Auto Running.
150-255 Sound Control.
12 Reset 0-250 None.
251-255 Reset aer 3s.

P. 5
English Version | Tecshow ALFIE STREAM
5. FUSE REPLACEMENT
6. CLEANING
7. TROUBLE SHOOTING
Locate and remove the unit’s power cord. Once
the cord has been removed located the fuse holder
located inside the power socket. Insert a at-head
screw driver into the power socket and gently pry out
the fuse holder. Remove the bad fuse and replace with
a new one. The fuse holder has a built-in socket for a
spare fuse be sure not to confuse the spare fuse with
active fuse.
FIXTURE CLEANING: Due to fog residue, smoke, and
dust cleaning the internal and external lenses should
be carried out periodically to optimize light output.
1. Use normal glass cleaner and a so cloth to wipe
down the out- side casing.
2. Use a brush to wipe down the cooling vents and
fan grill.
Listed below is a problem that you may encounter,
with a solution.
NO LIGHT OUTPUT FROM THE UNIT
1. Be sure the fuse has not blown. The fuse is located
on the rear panel inside the power socket.
See Fuse Replacement.
WARNING: If aer replacing the fuse you continue to
blow fuses, STOP using the unit. Contact customer
support for further instructions. Continuing to use
the unit may cause serious damage.
3. Clean the external optics with glass cleaner and a
so cloth every 20 days.
4. Clean the internal optics with glass cleaner and a
so cloth every 30-60 days.
5. Always be sure to dry all parts completely before
plugging the unit back in.
2. Be sure the fuse holder is completely and properly
seated.
AUTO SENSING VOLTAGE: This xture contains a
automatic voltage switch, which will auto sense the
voltage when it is plugged into the power source.

P. 6
