TECshow HALO 715 XL User manual

P. 1
Versión Español | Tecshow COSMO MAX
HALO 715 XL
7PCS 15W LED ZOOM WASH LIGHT
USER MANUAL | MANUAL DE USUARIO
PLEASE READ THE INSTRUCTIONS CAREFULLY BEFORE USE
POR FAVOR LEA LAS INSTRUCCIONES ANTES DE USAR

P. 2
English Version | Tecshow HALO 715 XL
HALO 715 XL
7PCS 15W LED ZOOM WASH LIGHT
HALO 715 XL is a compact and versatile moving head
that has 7 15W 4-in-1 LEDs with a zoom function that
allows you to vary its beam angle between 6º and 36º.
Ideal for small and medium scale mobile applications,
the equipment has a compact and lightweight design.
With its quad-color LED technology, the HALO 715
XL achieves smooth RGBW mixing without multicolor
shadows.
Specifications
Source & Optics
• Light Source: 7pcs *15W RGBW 4in1 LED
• Average lifespan: 50,000 hours.
• Power: 105W
• Beam angle: Zoom: 6º to 36º
• Lifespan: 50,000 hours
Photometric data
• 36º Beam Angle: 527 Lux @ 3M (10 ) / 204 Lux @ 5M (32 )
• 6th Beam Angle: 5420 Lux @ 3M (10) / 2090 Lux @ 5M (32)
Eects & Functions
• Electronic dimmer: 0-100% Strobe eect: 0-23 Hz
• 4-in-1 LED technology: Smooth RGBW mixing
without shadows.
Control
• DMX channels: 14/16
• Operation modes: DMX512, Master/Slave, Auto,
Audiorhythmic
• 8 preset programs
Movement
• Pan: 540°
• Tilt: 190°
Physical
• Display: LCD
• IP20 certication
• Weight: 4.66 Kgs
• Dimensions: 245x145x330mm
1· OVERVIEW

P. 3
English Version | Tecshow HALO 715 XL
• Please keep this User Manual for future reference.
If you sell the unit to another user, be sure that he
also receives this instruction booklet.
• Unpack and check the unit carefully that it has
not been damaged during transport before using
the unit.
• Before operating, ensure that the voltage and
frequency of power supply match the power
requirements of the unit.
• The unit should be connected to a main socket
outlet with a protective earth connection.
• The unit is for indoor use only in a dry location.
• The unit must be installed in a location with
adequate ventilation, at least 0,5m from adjacent
surfaces. Be sure that no ventilation slots are
blocked.
Before mounting the xture to any surface ,make sure
that the installation area can hold a minimum point
load of 10 times the device’s weight.
Fixture installation must always be secured with a
secondary safety attachment ,such as an appropriate
safety cable.
CAUTION!
For added protection mount the xtures in areas outside walking paths ,seating areas,or in areas were
the xture might be reached by unauthorized personnel.
Never stand directly below the device when
mounting ,removing ,or servicing the xture, from a
ceiling,or set on a at level surface (see illustration
below). Be sure this xture is kept at least 0.5m (1.5)
away from any ammable (decoration etc.)
Always use and install the supplied safety cable as
a safe cable as safety measure to prevent accident
damage and /or injury in the event the clamp fails.
For your own personal safety, please
read and understand this manual
completely before you attempt to
install or operate this unit!
2. INTRODUCTION
• Disconnect mains power before fuse replacement
or servicing.
• Replace fuse only with the same type.
• Make sure there are no inammable material
close to the unit during operation.
• Use safety cable when xing this unit. In the
event of serious operating problem, stop using
the unit immediately.
• Never try to repair the unit by yourself. Repair
carried out by unskilled people can lead to
damage or malfunction.
• Please contact the nearest authorized technical
assistance center and always use the same type
of spare parts.
• Do not touch any wires during operation as high
voltage might be causing electric shock.

P. 4
English Version | Tecshow HALO 715 XL
Overhead mounting requires extensive experience,
including among others calculating working load
limits, a ne knowledge of the installation material
being used ,and periodic safety inspection of all
installation material and the xture. If you lack these
qualications.
The LED moving head provides a unique mounting
bracket assembly that integrates the bottom of the
base, the included ‘omega bracket’ and the safety
cable rigging point in one unit (see the illustration
below). When mounting this xture to truss be sure
to sere to secure an appropritely rated clamp to the
included omega bracket using a M10 screw tted
through the center hole of the ‘omega bracket’.
As an added safetymeasure be sure to attached at
least one properly rated safety cable to the xture
using on of the safety cable rigging point integrated in
the base assembly.
Connect the provided XLR cable to the female 3-pin
XLR output of your controller and the other side to the
male 3-pin XLR input of the moving head.
You can chain multiple Moving head together through
serial linking. The cable needed should be two core,
screened cable with XLR input and output connectors.
Please refer to the diagram below.
3. MOUNTING POINTS
4. CLAMP MOUNTING
5. DMX-512 CONTROL CONNECTION
Do not attempt the installation yourself ,improper
installation can result in bodily injury.
Be sure to complete all rigging and installation
procedures before connecting the main power cord to
the appropriate wall outlet.

P. 5
English Version | Tecshow HALO 715 XL
For installations where the DMX cable has to run a long
distance or is in an electrically noisy environment,
such as in a discotheque, it is recommended to use a
DMX terminator. This helps in preventing corruption of
the digital control signal by electrical noise.
The DMX terminator is simply an XLR plug with a 120
resistor connected between pins 2 and 3,which is then
plugged into the output XLR socket of the last xture
in the chain. Please see illustrations below.
6. DMX-512 CONNECTION WITH DMX TERMINATOR

7. DISPLAY MENU
1 Addr 001-512 DMX Address
2 CHnd 16CH DMX Channel Mode
14CH
3SLnd
Auto Auto Mode
Soun Sound Control Mode
SL1 DMX Mode
SL2 Slave Mode
4SHnd
SH 0 Eect 0 (Recommend)
SH 1 Eect 1
SH 2 Eect 2
SH 3 Eect 3
5 SEnS 0-99 Slound sensitive
6 bLAnd
bLAc Auto mode, the same as AUTO mode.
Auto Sound mode, the same as Soud mode.
Soun No DMX signal Sound Control
HoLd No DMX signal keep last status
7LEDd OFF Display board will o aer 5s
ON Display keep on
8dISP no Display Reverse
YES Display Positive
9rPAN no Pan Positive
YES Pan Reverse
10 rTiL no Tilt Positive
YES Tilt Reverse
11 REST YES Reset

8. DMX CHANNELS
CH DMX VALUE FUNCTION
CH 1 000-255 Pan
CH 2 000-255 Pan Fine
CH 3 000-255 Tilt
CH 4 000-255 Tilt Fine
CH 5 000-255 P/T Speed
CH 6 000-255 Dimmer
CH 7 000-255 Strobe
CH 8 250-255 Red Dimmer
CH 9 000-255 Green Dimmer
CH 10 000-255 Blue Dimmer
CH 11 000-255 White Dimmer
CH 12 000-255 Zoom
CH 13 000-255 Color Auto Running
CH 14 000-255 Motor Auto Running
CH 15 000-255 Auto Running Speed
CH 16 250-255 Reset aer 5 seconds
CH DMX VALUE FUNCTION
CH 1 000-255 Pan
CH 2 000-255 Tilt
CH 3 000-255 P/T Speed
CH 4 000-255 Dimmer
CH 5 000-255 Strobe
CH 6 000-255 Red Dimmer
CH 7 000-255 Green Dimmer
CH 8 250-255 Blue Dimmer
CH 9 000-255 White Dimmer
CH 10 000-255 Zoom
CH 11 000-255 Color Auto Running
CH 12 000-255 Motor Auto Running
CH 13 000-255 Auto Running Speed
CH 14 250-255 Reset aer 5 Seconds
16 CHANNEL DEFINITION TABLE
14 CHANNEL DEFINITION TABLE
