Teka GF-T User manual

Mounting instructions and
maintenance recommendations
Cooker hoods
GF-T
Montageanleitung und Pflegehinweise
Dunstabzugshauben
GF-T
Instructions pour le montage et
Recommandations pour l’entretien
Hottes
GF-T

Dear Customer,
Thank you for choosing a Teka cooker hood.
We are sure that the appliance you have pur-
chased will fully satisfy your needs.
All of our appliances are made using top qua-
lity materials and undergo strict quality con-
trols throughout the manufacturing process.
Before installing or using your new cooker
hood, please read this manual carefully and
follow the instructions in order to ensure opti-
mum performance of the appliance for many
years.
Keep this instruction book in a safe place so
that you can consult it whenever necessary
and fulfil guarantee requirements.
Safety Instructions
Before using your cooker hood for the first
time, please take note of the installation and
connection instructions.
Do not use the hood if the power cable has
been damaged in any way or if the control swit-
ches shows visible signs of deterioration.
If the hood stops working, or operates abnor-
mally, disconnect its power supply (unplug
from the mains) and get in touch with your
TEKA Technical Service.
Do not leave uncovered gas rings burning
under the hood.
Do not allow grease to accumulate on any part
of the hood, especially in the filter. THIS IS A
FIRE RISK.
Do not flambé under the hood.
Description of the Appliance Page 4
Special Requirements
before First Use 5
Using your Hood 5
Fan motors 5
Light switch 5
Suggestions and Recommendations 6
Cleaning and Maintenance 7
Cleaning the filter 7
Cleaning the hood body 7
Changing light bulbs 8
If Something Doesn’t Work 9
Technical Information 10
Installation 11
Positioning in cabinet 11
Replacement of mains power cable 12
Using this instruction book Contents
2 3

Before connecting the hood to the electricity
mains, make sure that the mains voltage and
frequency correspond to the values indicated
on the rating label inside the hood. Select the desired extraction speed by sliding
the control switch on the hood’s front panel.
The extractor fan has three speed settings
and an on/off pilot light, which lights up when
the fan is operating at any of these speeds.
Position 1:
Off
Position 2:
First
speed
Position 3:
Second
speed
Position 4:
Third
speed
(maximum)
This is independent of the extractor fan motor,
thus allowing the hob lighting to be used irres-
pective of the extractor hood’s operating status.
On
Off
5
Fan motors
Light switch
Special Requirements
before First Use
Using your Hood
Your cooker hood is equipped with:
ASliding three-speed extractor fan control
BLight switch, for illumination with or wit-
hout fan operation
COn/off pilot lamp
DHob lighting, located behind the extrac-
tor panel
EFilter located below the extractor fan
intake. Easy-to-remove for cleaning
FFilter support frame
This hood is designed for the external venting
of gases.
Description
of the Appliance
4
F
E
DD
B C A

•Switch on the extractor fan a few minutes
before you start to cook (3 to 5 minutes)
in order to ensure that a steady air flow
has been established before cooking
fumes appear.
•Allow the extractor fan to run for several
minutes after you have finished cooking
(3 to 5 minutes) in order to expel all the
grease from the outlet duct. This prevents
the return of grease, smoke and smells.
Suggestions and
Recommendations
6
BEFORE CARRYING OUT ANY CLEANING OR
MAINTENANCE OPERATION, ENSURE THAT
THE APPLIANCE IS DISCONNECTED FROM
THE MAINS SUPPLY.
•Remove the filter by releasing its catches
(A).
•Take special care to prevent it from drop-
ping.
•The filter can be cleaned either in a dish-
washer (see note below) or by soaking it in
hot water to soften up the accumulated
greases. Special cleaning sprays can also
be used, taking care to protect non-meta-
llic parts.
•After cleaning, allow the filter to dry.
N.B.: Cleaning the filter in a dishwasher with
strong detergents may blacken its metal surfa-
ce without affecting its grease retention capa-
city.
Warning: Filters must be cleaned at least
once a month, depending on hood usage.
Grease will accumulate on the hood and in the
filters whenever you cook, regardless whether
or not the extractor fan is operating.
•It is recommended to use warm (approx.
40°C) soapy water and a damp cloth to cle-
an the hood body, paying special attention
to the slots on the extractor grille. After
washing, dry thoroughly using a cloth that
does not leave fibres.
Warning:
•Do not use metal scouring pads.
•Do not use abrasive products which could
damage the metal surface.
•Do not scrape with sharp objects such as
knives, scissors, etc.
Cleaning and Maintenance
7
Cleaning the filter
Cleaning the hood body
AA

9
Before calling the repair service, make the
following checks:
If Something Doesn’t Work
•Remove the filter to access the light bulbs.
•Make sure that the hood has previously
been disconnected from the mains supply
and that the bulbs to be replaced are not
hot.
•The maximum bulb rating is 40 W.
8
Changing light bulbs
Fault Possible Cause Solution
Hood does not work
Mains cable not connected Connect mains cable
Power not reaching plug Check/repair mains supply
Hood not extracting
sufficiently or vibrating
Filter saturated with grease Clean or replace filter
Obstruction in venting duct Remove obstruction
Inadequate venting duct Contact installer and follow
the instructions in this manual
Lights do not work
Bulbs blown Replace bulbs
Bulbs loose Tighten up bulbs

11
Before installing the hood, consult the require-
ments of the corresponding authorities concer-
ning air and smoke extraction regulations.
Extracted air must not be channelled through
ducts used for exhaust fumes from appliances
powered by any form of energy other than elec-
tricity.
The room (kitchen) must be well ventilated if
the extractor hood is to be used at the same
time as other extractor fans or other applian-
ces powered by any form of energy other than
electricity.
When the hood is to operate at the same time
as other appliances powered by any form of
energy other than electricity, the air output
pressure must not be more than 4 Pa (4 x 10-5
bar).
To ensure optimum hood performance, the
length of the venting duct should not exceed
FOUR metres and should not have more than
two right angles (90º).
If the hood is supplied without a lead for
mains connection (or if this is replaced), it
must be disconnected from the mains by
means of an omnipolar cut-off switch, with a
minimum contact separation of 3 mm at all
the poles, incorporated into the fixed installa-
tion.
The appliance must be connected to the
mains using flexible cable. Rigid tubing should
not be used.
Using the screws provided in the accessory
bag, bolt the hood to a wooden panel in which
the fitting opening has previously been cut.
The bottom of the hood must be positioned at
a minimum height of 65 cm above electric
hobs and 70 cm in the case of gas hobs. If
gas hob installation instructions indicate a
greater distance, this must be taken into
account.
InstallationTechnical Information
10
Dimensions Fitting Dimensions
(mm) (mm)
500 x 320 x 295 455 x 300
(Width x Depth x Height) (Width x Depth)
MOD.
TYP.
ELECT.
220...230 V ~
50 Hz
330 W
Made in European Community- C.I.F.: A-39004932
GF-T
P-521325
Nº. de fabric.
Fabrík.-Nr.
Serial Nº
24-000001
h
Electrical characteristics: SEE RATING LABEL Positioning in cabinet
455
300
POTENCIA NOM. LÁMPARAS
NENLEISTUNG GLÜHLAMPEN
LAMPS RATE
PUISSANCE LAMPES 2 X 40 W
POTENCIA NOM. DAS LAMPADAS

The mains power cable may only be replaced
by qualified technical service personnel.
12
Replacement of mains power cable
455
500
300 320
87
Ø 158

A sustituiçao do cabo de rede deve realizar-se
por um Serviço de Assistência Técnica qualifi-
cado.
24
Sustituiçao do cabo de rede
455
500
300
320
87
Ø 158
