Tektronix 5 Series User guide

5 Series Mixed Signal Oscilloscopes
MSO54, MSO56, MSO58
Installation and Safety Manual
*P071351400*
071-3514-00
5 シリーズ・ミックスド・シグナル・オシロスコープ
MSO54 型、MSO56 型、MSO58 型
インストールおよび安全性に関するマニュアル
5 系列混合信号示波器
MSO54、MSO56、MSO58
安装和安全手册

5 Series Mixed Signal Oscilloscopes
MSO54, MSO56, MSO58
Installation and Safety Manual
www.tek.com
071-3514-00
Supports 5 Series MSO Product Firmware V1.0 and above

Copyright © Tektronix. All rights reserved. Licensed software products are owned by Tektronix or its subsidiaries or suppliers, and are
protected by national copyright laws and international treaty provisions. Tektronix products are covered by U.S. and foreign patents, issued
and pending. Information in this publication supersedes that in all previously published material. Specifications and price change privileges
reserved.
TEKTRONIX and TEK are registered trademarks of Tektronix, Inc.
FlexChannel and TekSecure are trademarks of Tektronix, Inc.
TekVPI, FastAcq, and e*Scope are registered trademarks of Tektronix, Inc.
Contacting Tektronix
Tektronix, Inc.
14150 SW Karl Braun Drive
P.O. Box 500
Beaverton, OR 97077
USA
For product information, sales, service, and technical support:
■In North America, call 1-800-833-9200.
■Worldwide, visit www.tek.com to find contacts in your area.

Warranty
Tektronix warrants that this product will be free from defects in materials and workmanship for a period of three (3) years from the date of
shipment. If any such product proves defective during this warranty period, Tektronix, at its option, either will repair the defective product
without charge for parts and labor, or will provide a replacement in exchange for the defective product. Parts, modules and replacement
products used by Tektronix for warranty work may be new or reconditioned to like new performance. All replaced parts, modules and
products become the property of Tektronix.
In order to obtain service under this warranty, Customer must notify Tektronix of the defect before the expiration of the warranty period and
make suitable arrangements for the performance of service. Customer shall be responsible for packaging and shipping the defective
product to the service center designated by Tektronix, with shipping charges prepaid. Tektronix shall pay for the return of the product to
Customer if the shipment is to a location within the country in which the Tektronix service center is located. Customer shall be responsible
for paying all shipping charges, duties, taxes, and any other charges for products returned to any other locations.
This warranty shall not apply to any defect, failure or damage caused by improper use or improper or inadequate maintenance and care.
Tektronix shall not be obligated to furnish service under this warranty a) to repair damage resulting from attempts by personnel other than
Tektronix representatives to install, repair or service the product; b) to repair damage resulting from improper use or connection to
incompatible equipment; c) to repair any damage or malfunction caused by the use of non-Tektronix supplies; or d) to service a product
that has been modified or integrated with other products when the effect of such modification or integration increases the time or difficulty
of servicing the product.
THIS WARRANTY IS GIVEN BY TEKTRONIX WITH RESPECT TO THE PRODUCT IN LIEU OF ANY OTHER WARRANTIES, EXPRESS
OR IMPLIED. TEKTRONIX AND ITS VENDORS DISCLAIM ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE. TEKTRONIX' RESPONSIBILITY TO REPAIR OR REPLACE DEFECTIVE PRODUCTS IS THE SOLE AND
EXCLUSIVE REMEDY PROVIDED TO THE CUSTOMER FOR BREACH OF THIS WARRANTY. TEKTRONIX AND ITS VENDORS WILL
NOT BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES IRRESPECTIVE OF WHETHER
TEKTRONIX OR THE VENDOR HAS ADVANCE NOTICE OF THE POSSIBILITY OF SUCH DAMAGES.
[W4 – 15AUG04]

Table of Contents
Important safety information ................................................................................................................................ iii
General safety summary ................................................................................................................................ iii
Service safety summary ................................................................................................................................. v
Terms in the manual ...................................................................................................................................... vi
Terms on the product .................................................................................................................................... vi
Symbols on the product ................................................................................................................................. vi
Preface ............................................................................................................................................................... vii
Key features .................................................................................................................................................. vii
Related documents ....................................................................................................................................... vii
Installing your instrument
Check shipped accessories ........................................................................................................................... 1
Safely rotate the handle ................................................................................................................................. 1
Operating requirements ................................................................................................................................. 2
Input signal requirements ............................................................................................................................... 3
Secure (lock) the oscilloscope ....................................................................................................................... 3
Powering the oscilloscope .............................................................................................................................. 4
Check that oscilloscope passes power-on self tests ...................................................................................... 5
Connecting Probes ......................................................................................................................................... 5
Rackmount information .................................................................................................................................. 6
Getting acquainted with your instrument
Front panel controls and connectors .............................................................................................................. 7
Rear panel connections ............................................................................................................................... 14
The user interface screen ............................................................................................................................ 15
The user interface elements ......................................................................................................................... 16
Badges ......................................................................................................................................................... 19
Configuration menus .................................................................................................................................... 24
The Zoom user interface elements .............................................................................................................. 26
Using the touch screen interface for common tasks .................................................................................... 27
Configure the instrument
Set the time zone and clock readout format ................................................................................................. 29
Download and install the latest firmware ...................................................................................................... 29
Run Signal Path Compensation (SPC) ........................................................................................................ 30
MSO54, MSO56, MSO58 Installation and Safety Manual i

Compensate the TPP0500B or TPP1000 probes ........................................................................................ 30
Connect to a network (LAN) ......................................................................................................................... 32
Operating basics
Add a channel waveform to the display ....................................................................................................... 33
Configure channel or waveform settings ...................................................................................................... 34
Quickly display a waveform (Autoset) .......................................................................................................... 35
How to trigger on a signal ............................................................................................................................ 36
Set the acquisition mode .............................................................................................................................. 37
Set Horizontal parameters ........................................................................................................................... 38
Add a math, reference, or bus waveform ..................................................................................................... 38
Add a measurement ..................................................................................................................................... 40
Configure a measurement ............................................................................................................................ 42
Add a plot of a measurement ....................................................................................................................... 43
Add a Search ............................................................................................................................................... 45
Delete a Measurement or Search badge ..................................................................................................... 46
Change waveform view settings .................................................................................................................. 47
Display and configure cursors ...................................................................................................................... 47
Remote access from a Web browser ........................................................................................................... 49
Connect the oscilloscope to a PC using a USB cable .................................................................................. 50
Cleaning the instrument
Cleaning ....................................................................................................................................................... 51
EMC, safety and environmental compliance
Compliance Information ............................................................................................................................... 53
EMC compliance .................................................................................................................................... 53
Safety compliance .................................................................................................................................. 54
Environmental compliance ..................................................................................................................... 55
Table of Contents
ii MSO54, MSO56, MSO58 Installation and Safety Manual

Important safety information
Safety information provides warnings and cautions that help you operate the instrument safely and keep the instrument in a safe
working condition.
This manual contains information and warnings that must be followed by the user for safe operation and to keep the product in a
safe condition.
To safely perform service on this product, see the Service safety summary that follows the General safety summary.
General safety summary
Use the product only as specified. Review the following safety precautions to avoid injury and prevent damage to this product or
any products connected to it. Carefully read all instructions. Retain these instructions for future reference.
Comply with local and national safety codes.
For correct and safe operation of the product, it is essential that you follow generally accepted safety procedures in addition to
the safety precautions specified in this manual.
The product is designed to be used by trained personnel only.
Only qualified personnel who are aware of the hazards involved should remove the cover for repair, maintenance, or adjustment.
Before use, always check the product with a known source to be sure it is operating correctly.
This product is not intended for detection of hazardous voltages.
Use personal protective equipment to prevent shock and arc blast injury where hazardous live conductors are exposed.
While using this product, you may need to access other parts of a larger system. Read the safety sections of the other
component manuals for warnings and cautions related to operating the system.
When incorporating this equipment into a system, the safety of that system is the responsibility of the assembler of the system.
To avoid fire or personal injury
Use proper power cord. Use only the power cord specified for this product and certified for the country of use. Do not use the
provided power cord for other products.
Ground the product. This product is grounded through the grounding conductor of the power cord. To avoid electric shock, the
grounding conductor must be connected to earth ground. Before making connections to the input or output terminals of the
product, ensure that the product is properly grounded. Do not disable the power cord grounding connection.
Power disconnect. The power cord disconnects the product from the power source. See instructions for the location. Do not
position the equipment so that it is difficult to operate the power cord; it must remain accessible to the user at all times to allow for
quick disconnection if needed.
Connect and disconnect properly. Do not connect or disconnect probes or test leads while they are connected to a voltage
source. Use only insulated voltage probes, test leads, and adapters supplied with the product, or indicated by Tektronix to be
suitable for the product.
Observe all terminal ratings. To avoid fire or shock hazard, observe all rating and markings on the product. Consult the product
manual for further ratings information before making connections to the product. Do not exceed the Measurement Category
(CAT) rating and voltage or current rating of the lowest rated individual component of a product, probe, or accessory. Use caution
when using 1:1 test leads because the probe tip voltage is directly transmitted to the product.
Do not apply a potential to any terminal, including the common terminal, that exceeds the maximum rating of that terminal.
Do not float the common terminal above the rated voltage for that terminal.
MSO54, MSO56, MSO58 Installation and Safety Manual iii

Do not operate without covers. Do not operate this product with covers or panels removed, or with the case open. Hazardous
voltage exposure is possible.
Avoid exposed circuitry. Do not touch exposed connections and components when power is present.
Do not operate with suspected failures. If you suspect that there is damage to this product, have it inspected by qualified
service personnel.
Disable the product if it is damaged. Do not use the product if it is damaged or operates incorrectly. If in doubt about safety of the
product, turn it off and disconnect the power cord. Clearly mark the product to prevent its further operation.
Before use, inspect voltage probes, test leads, and accessories for mechanical damage and replace when damaged. Do not use
probes or test leads if they are damaged, if there is exposed metal, or if a wear indicator shows.
Examine the exterior of the product before you use it. Look for cracks or missing pieces.
Use only specified replacement parts.
Use proper fuse. Use only the fuse type and rating specified for this product.
Wear eye protection. Wear eye protection if exposure to high-intensity rays or laser radiation exists.
Do not operate in wet/damp conditions. Be aware that condensation may occur if a unit is moved from a cold to a warm
environment.
Do not operate in an explosive atmosphere.
Keep product surfaces clean and dry. Remove the input signals before you clean the product.
Provide proper ventilation. Refer to the manual's installation instructions for details on installing the product so it has proper
ventilation.
Slots and openings are provided for ventilation and should never be covered or otherwise obstructed. Do not push objects into
any of the openings.
Provide a safe working environment. Always place the product in a location convenient for viewing the display and indicators.
Avoid improper or prolonged use of keyboards, pointers, and button pads. Improper or prolonged keyboard or pointer use may
result in serious injury.
Be sure your work area meets applicable ergonomic standards. Consult with an ergonomics professional to avoid stress injuries.
Use care when lifting and carrying the product. This product is provided with a handle for lifting and carrying.
Use only the Tektronix rackmount hardware specified for this product.
Probes and test leads
Before connecting probes or test leads, connect the power cord from the power connector to a properly grounded power outlet.
Keep fingers behind the finger guards on the probes.
Remove all probes, test leads and accessories that are not in use.
Use only correct Measurement Category (CAT), voltage, temperature, altitude, and amperage rated probes, test leads, and
adapters for any measurement.
Important safety information
iv MSO54, MSO56, MSO58 Installation and Safety Manual

Beware of high voltages. Understand the voltage ratings for the probe you are using and do not exceed those ratings. Two
ratings are important to know and understand:
■The maximum measurement voltage from the probe tip to the probe reference lead.
■The maximum floating voltage from the probe reference lead to earth ground.
These two voltage ratings depend on the probe and your application. Refer to the Specifications section of the manual for more
information.
WARNING. To prevent electrical shock, do not exceed the maximum measurement or maximum floating voltage for the
oscilloscope input BNC connector, probe tip, or probe reference lead.
Connect and disconnect properly. Connect the probe output to the measurement product before connecting the probe to the
circuit under test. Connect the probe reference lead to the circuit under test before connecting the probe input. Disconnect the
probe input and the probe reference lead from the circuit under test before disconnecting the probe from the measurement
product.
Connect and disconnect properly. De-energize the circuit under test before connecting or disconnecting the current probe.
Connect the probe reference lead to earth ground only.
Do not connect a current probe to any wire that carries voltages above the current probe voltage rating.
Inspect the probe and accessories. Before each use, inspect probe and accessories for damage (cuts, tears, or defects in the
probe body, accessories, or cable jacket). Do not use if damaged.
Service safety summary
The Service safety summary section contains additional information required to safely perform service on the product. Only
qualified personnel should perform service procedures. Read this Service safety summary and the General safety summary
before performing any service procedures.
To avoid electric shock. Do not touch exposed connections.
Do not service alone. Do not perform internal service or adjustments of this product unless another person capable of rendering
first aid and resuscitation is present.
Disconnect power. To avoid electric shock, switch off the product power and disconnect the power cord from the mains power
before removing any covers or panels, or opening the case for servicing.
Use care when servicing with power on. Dangerous voltages or currents may exist in this product. Disconnect power, remove
battery (if applicable), and disconnect test leads before removing protective panels, soldering, or replacing components.
Verify safety after repair. Always recheck ground continuity and mains dielectric strength after performing a repair.
Important safety information
MSO54, MSO56, MSO58 Installation and Safety Manual v

Terms in the manual
These terms may appear in this manual:
WARNING. Warning statements identify conditions or practices that could result in injury or loss of life.
CAUTION. Caution statements identify conditions or practices that could result in damage to this product or other property.
Terms on the product
These terms may appear on the product:
■DANGER indicates an injury hazard immediately accessible as you read the marking.
■WARNING indicates an injury hazard not immediately accessible as you read the marking.
■CAUTION indicates a hazard to property including the product.
Symbols on the product
When this symbol is marked on the product, be sure to consult the manual to find out the nature of the potential
hazards and any actions which have to be taken to avoid them. (This symbol may also be used to refer the user to
ratings in the manual.)
The following symbols may appear on the product:
Important safety information
vi MSO54, MSO56, MSO58 Installation and Safety Manual

Preface
This manual provides product safety and compliance, how to connect and power on the oscilloscope, and an introduction to the
instrument features, controls and basic operations. See the product Help file for more detailed information.
Key features
Welcome to the 5 Series Mixed Signal Oscilloscope. The 5 Series MSO Oscilloscopes (MSO54, MSO56, and MSO58) are 4-, 6-,
and 8-channel oscilloscopes with the world's first FlexChannel™-based inputs, enabling you to efficiently and cost-effectively
perform mixed signal debugging on virtually any design.
■Bandwidths from 350 MHz to 2 GHz
■4-, 6-, and 8-channel models with FlexChannel inputs
■Each FlexChannel input supports one analog channel or eight digital channels, in any combination
■FlexChannel inputs are compatible with TekVPI® probes
■Large 15.6” HD (1920 x 1080 pixel) capacitive touch-screen display
■User interface designed to optimize touch screen use and quickly access key settings
■Stacked mode places each channel or waveform in its own horizontal 'slice' on the screen, allowing for cleaner signal
viewing and measuring
■Maximum 6.25 GS/s sample rate
■62.5 M points record length on all channels (optional 125 M record length available)
■500,000 waveforms/second maximum waveform capture rate
■No set limit on the number of math, reference, and bus waveforms you can display 1
■Integrated optional features include a 50 MHz arbitrary function generator (AFG), and a DVM and trigger frequency counter
■Optional advanced triggering features let you trigger and take measurements on industry serial bus data standards including
I2C, SPI, USB 2.0, CAN, LIN, FlexRay, RS-232/422/485/UART, Audio (I2S, LJ, RJ, TDM), and Ethernet
Related documents
Use the related documents to access information on how to remotely program or operate the instrument, understand theory of
operation, replace suspected modules, and do other tasks.
To learn about Use this document
How to use instrument
functions
5 Series Mixed Signal Oscilloscope MSO54, MSO56, MSO58 Help (Tektronix part number
077-1303-xx; Printable version of the instrument Help; available at www.tektronix.com/
downloads)
How to remotely control the
instrument
5 Series Mixed Signal Oscilloscope MSO54, MSO56, MSO58 Programmer Manual (Tektronix
part number 077-1305-xx; available at www.tektronix.com/downloads)
Instrument specifications and
procedures to verify the
instrument meets
specifications
5 Series Mixed Signal Oscilloscope MSO54, MSO56, MSO58 Specifications and Performance
Verification Technical Reference (Tektronix part number 077-1306-xx; available at
www.tektronix.com/downloads)
1Actual number of waveforms depends on available system memory.
MSO54, MSO56, MSO58 Installation and Safety Manual vii

To learn about Use this document
Instrument theory of operation,
troubleshooting, disassembly,
and replaceable parts
5 Series Mixed Signal Oscilloscope MSO54, MSO56, MSO58 Service Manual (Tektronix part
number 077-1307-xx; available at www.tektronix.com/downloads)
Installing the instrument in a
rack
RM5MSO Rack Mount Kit Instructions (Tektronix part number 071-3523-xx; available at
www.tektronix.com/downloads)
Using the TLP058 Logic Probe TLP058 FlexChannel Logic Probe Instructions (Tektronix part number 071-3515-xx; available at
www.tektronix.com/downloads)
Preface
viii MSO54, MSO56, MSO58 Installation and Safety Manual

Installing your instrument
Check shipped accessories
Make sure that you received everything you ordered. If anything is missing, contact Tektronix Customer Support. In North
America, call 1-800-833-9200. Worldwide, visit www.tek.com to find contacts in your area.
Check the packing list that came with your instrument to verify that you have received all ordered items. Check that you received
all standard accessories.
Item Quantity Tektronix part number
5 Series Mixed Signal Oscilloscope (MSO54, MSO56, MSO58) Installation
and Safety Manual
1 071-3514-xx
TPP0500B Passive Voltage Probe (500 MHz bandwidth). Shipped with
350 MHz and 500 MHz models.
One per channel TPP0500B
TPP1000 Passive Voltage Probe (1 GHz bandwidth). Shipped with 1 GHz
and 2 GHz models.
One per channel TPP1000
Front cover 1 200-5406-xx
Accessory pouch (attached to front cover) 1 016-2106-xx
Mouse (wired with USB connector) 1 119-7054-xx
Power cord 1 Depends on region
Calibration certificate 1 N/A
If you purchased factory installed options such as Advanced Serial Triggering, tap Help > About to confirm that the option(s) are
listed in the Installed Options table.
Safely rotate the handle
Use the correct process to eliminate the chance of pinching your thumb or rear-panel-connected cables while rotating the handle.
CAUTION. Hold the top of the handle to rotate the handle on the instrument. Do not hold the handle from the sides and rotate, as
this can pinch the base of your thumb between the handle and the case.
If you have routed any cables between the handle and the case, be careful when rotating the handle so that you do not pinch the
cables.
MSO54, MSO56, MSO58 Installation and Safety Manual 1

Operating requirements
Use the oscilloscope within the required operating temperature, power, altitude, and signal input voltage ranges to provide the
most-accurate measurements and safe instrument operation.
Environment requirements
Characteristic Description
Operating temperature 0 °C to +50 °C (+32 °F to +122 °F)
For proper cooling, keep the sides and rear of the instrument clear of obstructions for
2 inches (51 mm).
Operating humidity 5% to 90% relative humidity (% RH) up to +40 °C (+104 °F)
5% to 55% RH above +40 °C up to +50 °C (+104 °F to +122 °F), Noncondensing.
Operating altitude Up to 3000 meters (9842 feet)
Power requirements
Characteristic Description
Power source voltage 100 V - 240 VAC RMS, ±10%, single phase
Power source frequency 50/60 Hz, 100-240 V (90-264 V)
400 Hz, 115 V (103-127 V)
Power consumption All models: 400 W maximum
Installing your instrument
2 MSO54, MSO56, MSO58 Installation and Safety Manual

Input signal requirements
Keep the input signals within allowed limits to ensure the most accurate measurements and prevent damage to the analog and
digital probes or instrument.
Make sure that input signals are within the following requirements.
Input Description
Analog input channels, 1 M Ω setting, maximum input voltage
at BNC
300 VRMS
Measurement Category II
Analog input channels, 50 Ω setting, maximum input voltage at
BNC
5 VRMS
Digital input channels, maximum input voltage range at digital
inputs
Observe probe ratings
TLP058; ±42 VP
Ref In maximum input voltage at BNC (rear panel) 7 VPP
Secure (lock) the oscilloscope
Lock an oscilloscope to a test bench or equipment rack to prevent property loss.
Attach a standard laptop security lock to the rear panel of the oscilloscope, to secure the oscilloscope to a workbench, rack, or
other location.
Installing your instrument
MSO54, MSO56, MSO58 Installation and Safety Manual 3

Powering the oscilloscope
Use this procedure to connect the oscilloscope to line power and power on and off the oscilloscope. Always connect the
oscilloscope to AC power using the power cord that shipped with the instrument.
Prerequisite: Use the AC power cord that shipped with your oscilloscope.
1. Connect the supplied power cord to the oscilloscope power connector.
2. Connect the power cord to an appropriate AC mains source.
Power is supplied to the power supply and some other boards whenever the AC power cord is connected to a live mains
circuit, putting the instrument in standby mode.
3. Push the front panel power button to power the instrument on and off.
The power button indicates instrument power states:
No light – no AC power applied
Yellow – standby mode
Blue – powered on
4. To completely remove power from the instrument, disconnect the power cord.
5. To transport the instrument with its power cord, flip out the power cord supports on the upper edge of the rear panel and
wrap the power cord around the supports.
Installing your instrument
4 MSO54, MSO56, MSO58 Installation and Safety Manual

Check that oscilloscope passes power-on self tests
Power-on self tests verify that all oscilloscope modules are working correctly after power up.
1. Power on the oscilloscope and wait until the oscilloscope screen appears.
2. Select Utility > Self Test from the top-edge Menu bar to open the Self Test configuration menu.
3. Check that the power-on self tests are Passed.
If the power-on self test shows Failed:
a. Power cycle the oscilloscope.
b. Tap Utility > Self Test. If the power-on self test still shows Failed, contact Tektronix Customer Support.
Connecting Probes
Probes and cables connect the oscilloscope to your device under test (DUT). Use a probe that best matches your signal
measurement needs.
Connect TPP0500, TPP1000, TekVPI+®, TekVPI®, or other supported Tektronix analog probes by pushing them into a
FlexChannel connector. The probe base latch locks with a 'click' when the probe is fully seated.
TekVPI probes automatically set the channel input parameters for that probe (bandwidth, attenuation, termination, and so on). If
a probe has a Menu button, push that button to open an on-screen configuration menu. Follow instructions provided with active
probes to set their parameters (auto zero, degauss, and so on).
To connect a TLP058 FlexChannel Logic Probe:
1. Move the locking lever to the unlocked position, then let go to reset locking lever to the center position.
2. Insert the probe into a FlexChannel channel until fully seated and the lock mechanism clicks.
3. Move the locking lever to the locked position. The status light should be a solid green.
4. To disconnect the TLP058 probe, move and hold the locking lever at the unlocked position and pull out the probe. Do not
pull on the ribbon cable while removing the probe.
Connect a BNC probe or cable by pushing it onto a channel BNC bayonet connector and turn the lock mechanism clockwise until
it locks.
Installing your instrument
MSO54, MSO56, MSO58 Installation and Safety Manual 5

Connecting a probe does not automatically display or enable that channel. Tap an Inactive Channel button to turn on that
channel. Double-tap the Channel badge to open its configuration menu to verify or change probe or cable settings (bandwidth,
attenuation, termination and so on).
Rackmount information
The optional RM5 Rackmount Kit lets you install the oscilloscope in standard equipment racks. The rackmount requires seven
rack units (7U) of space to install.
RM5 Rackmount Kit (Option RM5).
1. Purchase or obtain the rackmount kit.
2. Follow the instructions that came with the rackmount kit (RM5 Rackmount Kit Instructions, Tektronix part number 071-3523-
xx).
3. Make sure to allow adequate clearance on the sides and rear for air ventilation, and on the back for any cables you attach to
the rear panel.
Installing your instrument
6 MSO54, MSO56, MSO58 Installation and Safety Manual
