Tektronix 7623A User manual

COMMITIED TO EXCELLENCE
WARNING
THE FOLLOWING SERVICING INSTRUCTIONS
ARE FOR USE BY QUALIFIED PERSONNEL ONLY.
TO AVOID PERSONAL INJURY, DO NOT
PERFORM ANY SERVICING OTHER THAN THAT
CONTAINED IN OPERATING INSTRUCTIONS
UNLESS YOU ARE QUALIFIED TO DO SO.
PLEASECHECK FOR CHANGE INFORMATION
AT THE
REAR OF THIS MANUAL.
STORAGE
OSCILLOSCOPE
WITH OPTIONS
SERVICE
INSTRUCTION MANUAL
Tektronix, Inc.
P.O. Box 500
Beaverton, Oregon 97077
070-1685-00
Product Group 42
Scans by ARTEK MEDU =>
Serial Number
First Printing MAY 1974
Revised APR 1984

DIGITALY REMASTERED
OUT OF PRINT- MANUAL SCAN S
By
ArtekMedia
P.O. BOX 175
Welch, MN 55089-0175
Phone: [phone]
www.artekmedia.com
“High resolution scans of obsolete technical manuals”
If you are looking for a quality scanned technical manual in PDF format please visit our WEB
site at www.artekmedia.com or drop us an email at [e-mail]
If you don’t see the manual you need on the list drop us a line anyway we may still be able to
obtain the manual you need or direct you to other sources. If you have an existing manual you
would like scanned please write for details. This can often be done very reasonably in
consideration for adding your manual to our library.
Typically the scans in our manuals are done as follows;
1) Typed text pages are typically scanned in black and white at 300 dpi.
2) Photo pages are typically scanned in gray scale mode at 600 dpi
3) Schematic diagram pages are typically scanned in black and white at 600
dpi unless the original manual had colored high lighting (as is the case for
some 70’s vintage Tektronix manuals).
4) Most manuals are text searchable
5) All manuals are fully bookmarked
All data is guaranteed for life (yours or mine …whichever is shorter). If for ANY REASON your
file becomes corrupted, deleted or lost, ArtekMedia will replace the file for the priceof shipping,
or free via FTP download.
Thanks
Dave & Lynn Henderson
ArtekMedia

Copyright @ 1974 Tektronix, Inc. All rights reserved.
Contents of this publicationmay not be reproduced in any
form without the written permission of Tektronix, Inc.
Productsof Tektronix, Inc. and its subsidiaries are covered
by U.S. and foreign patents and/or pending patents.
TEKTRONIX, TEK, SCOPE-MOBILE, and
@ are
registered trademarks of Tektronix, Inc. TELEQUIPMENT
is a registered trademark of Tektronix U.K. Limited.
Printed in U.S.A. Specification and price change privileges
are reserved.
INSTRUMENT SERIAL NUMBERS
Each instrument has a serial number on a panel insert, tag,
or stamped on the chassis. The first number or letter
designates the country of manufacture. The last five digits
of the serial number are assigned sequentially and are
unique to each instrument. Those manufactured in the
United States have six unique digits. The country of
manufacture is identified as follows:
6000000 Tektronix, Inc., Beaverton, Oregon, USA
100000 Tektronix Guernsey, Ltd., Channel Islands
200000 Tektronix United Kingdom, Ltd., London
300000 SonyPTektronix,Japan
700000 Tektronix Holland, NV, Heerenveen,
The Netherlands
Scans by ARTEK MEDIA =>

7623A/R7623A Service
TABLE OF CONTENTS
LlSTOF l LLUSTRATlONS
LlSTOF TABLES
SECTION
1 OPERATING INFORMATION
PRELIMINARY OPERATION
AC POWER SOURCES
AC POWER CORD
OPERATING VOLTAGE
OPERATING TEMPERATURE
RACKMOUNTING
PLUG-IN UNITS
PLUG-ININSTALLATIONAND REMOVAL
CONTROLS AND CONNECTORS
FRONT PANEL CONTROLS AND CONNECTORS
REAR PANEL CONTROLSAND CONNECTORS
GENERAL OPERATING INFORMATION
INTENSITY CONTROL
DISPLAY FOCUS
GRATICULE
LIGHT FILTER
BEAMFINDER
READOUTMODES
DISPLAY PHOTOGRAPHY
STORAGE
CARE OF STORAGE SCREEN
VERTICAL MODE
TRIGGER SOURCE
X-Y OPERATION
INTENSITY MODULATION
RASTER DISPLAY
CALIBRATOR
SIGNALS OUT
APPLICATIONS
SECTION 2 SPEC1FICATIONS
INTRODUCTION
STANDARD ACCESSORIES
Scam by ARTEK MEDL4 =>

7623AlR7623A Service
TABLE OF CONTENTS (cont.)
SECTION 3 THEORY OF OPERATION
LOGIC FUNDAMENTALS
SYMBOLS
LOGICPOLARITY
INPUTIOUTPUTTABLES
NON DIGITALDEVICES
BLOCK DIAGRAM
THEORY OF OPERATION
MAIN INTERFACE
@
LOGIC CIRCUIT 9
Z-AXIS LOGIC
CLOCK GENERATOR
VERTICAL CHOPPED BLANKING
CHOP COUNTER
VERTICAL MODE CONTROL
VERTICAL BINARY
PLUG-INBINARY
OUTPUT BUFFERS
TRIGGER SELECTOR
@
TRIGGER MODE AND ADD SIGNALS
TRIGGER CHANNELSWITCH
TRIGGER OUTPUT AMPLIFIER
VERTICALSIGNAL BUFFER
VERTICAL INTERFACE
@
VERTICAL CHANNEL SWITCH
AUXILIARY Y-AXIS INPUTAMPLIFIER
DELAY-LINE BUFFER
DELAY LINE
VERTICAL AMPLIFIER @
CENTERING AND READOUT AMPLIFIER
INPUTAMPLIFIER
BEAMFINDER NETWORK
OUTPUT AMPLIFIER
HORIZONTAL AMPLIFIER
@
HORIZONTAL CHANNEL SWITCH
RIGHT OUTPUT AMPLlFlER
LEFT OUTPUT AMPLIFIER
Scans by AR TEK MEDL4

7623AIR7623A Service
TABLE OF CONTENTS (cont.)
OUTPUT SIGNALS @
VERT SIG OUT
+ GATE OUT
+ SAWTOOTH OUT
CRT CIRCUIT
@
HIGHVOLTAGE REGULATION
AUTO FOCUS DC RESTORER
AUTO FOCUS
CONTROL GRID DC RESTORER
Z-AXISAMPLIFIER
CRT CONTROL CIRCUITS
LOW-VOLTAGEPOWER SUPPLY
@
POWER INPUT
-50-VOLT SUPPLY
-15-VOLT SUPPLY
+5-VOLT SUPPLY
+15-VOLT SUPPLY
+50-VOLT SUPPLY
+130-VOLTSUPPLY
GRATICULE LIGHT SUPPLY
CALIBRATOR
@
READOUT SYSTEM @
INTRODUCTION
THREE-COMPARTMENTMAINFRAMES
DISPLAY FORMAT
DEVELOPINGTHE DISPLAY
TIMER
TIME-SLOTCOUNTER
WORD TRIGGER
CHANNELCOUNTER
READOUT CONTROL
SINGLE-SHOT LOCKOUT
ENCODINGTHE DATA
COLUMN AND ROW DATASWITCHES
DISPLAY-SKIPGENERATOR
COLUMN AND ROW DECODERS
ZEROS LOGICAND MEMORY
iii
Scam by ARTEK MEDLQ =>

7623AIR7623A Service
TABLE OF CONTENTS (cont.)
CHARACTER GENERATORS 3-64
DECIMAL POINT LOGICAND CHARACTER POSITION COUNTER3-64
FORMAT GENERATOR 3-65
Y-OUTPUTAMPLlFlER 3-67
X-OUTPUTAMPLlFlER 3-67
DISPLAY SEQUENCE 3-67
STORAGE SYSTEM
@ 3-68
LOG
l C 3-68
OPERATIONAL AMPLIFIERS 3-73
SECTION 4 MAINTENANCE
PRELIMINARY INFORMATION
PANEL REMOVAL
POWER UNIT REMOVAL
PREVENTIVE MAINTENANCE
CLEANING
LUBRICATION
VISUAL INSPECTION
SEMICONDUCTOR CHECKS
RECALIBRATION
TROUBLESHOOTING
TROUBLESHOOTING AIDS
TROUBLESHOOTING EQUIPMENT
TROUBLESHOOTINGTECHNIQUES
CORRECTIVE MAINTENANCE
OBTAINING REPLACEMENTPARTS
SOLDERINGTECHNIQUES
COMPONENT REPLACEMENT
SEMICONDUCTOR REPLACEMENT
CATHODE-RAYTUBE REPLACEMENT
SWITCH REPLACEMENT
GRATICULE-BULB REPLACEMENT
POWER TRANSFORMER REPLACEMENT
HIGHVOLTAGE COMPARTMENT
FUSE REPLACEMENT
RECALIBRATIONAFTER REPAIR
INSTRUMENTREPACKAGING
SELECTED COMPONENT CRITERIA
Scans by ARTEK MEDIA =>
REV MAY 1983

7623AlR7623A Service
TABLE OF CONTENTS (cont.)
SECTION 5 PERFORMANCE CHECKICALIBRATION
PRELIMINARY INFORMATION
CALIBRATION INTERVAL
TEKTRONIX FIELD SERVICE
USING THIS PROCEDURE
TEST EQUIPMENT REQUIRED
SPECIAL CALIBRATION FIXTURES
CALIBRATION EQUIPMENTALTERNATIVES
SIGNAL CONNECTIONS
WARM-UPAND TEMPERATURE REQUIREMENTS
PART I-PERFORMANCE CHECK
INTRODUCTION
OUTLINE FOR PART I-PERFORMANCE CHECK
PART II-CALIBRATION
INTRODUCTION
OUTLINE FOR PART II-CALIBRATION
SECTION 6 OPTIONS
SECTION
7 ELECTRICAL PARTS LIST
SECTION 8 DIAGRAMS
SECTION
9 MECHANICAL PARTS LIST
CHANGE INFORMATION
Scans by ARTEK MEDIA =>

7623AlR7623A Service
LIST OF ILLUSTRATIONS
PAGE
Frontispiece
Figure 1-1. Location of voltage-selectorjumper.
Figure1-2. Front panel controls and connectors.
Figure 1-3. Rear panel controls and connectors.
Figure 1-4. Definitionof measurementlinesonthe graticule.
Figure 1-5. Location of Readout Modeswitch.
Figure 1-6. Location of Calibratorjumper on Storagecircuit board.
Figure3-1. Block diagram 7623A.
Figure3-2. Logic circuit block diagram.
Figure3-3. 2-Axis logic block diagram.
Figure3-4. (A)Clock Generator stage of U55A. (B)ldealizedwaveforms from Clock
Generator stage.
Figure3-5. (A) lnput and output pinsfor Vertical Chopped Blankingstage. (B) ldealized
waveformsfor Vertical Chopped Blankingstage.
Figure3-6. (A) Logicdiagramfor Vertical Chopped Blankingstage. (B)Table of input/output
combinationsfor Vertical Chopped Blankingstage.
Figure3-7. Detailedlogicdiagram of Chop Counter stage.
Figure 3-8. ldealized inputand output waveforms for Chop Counter stage
Figure 3-9. Logic diagramof Vertical ModeControl and Vertical Mode Buffer Amplifier
stages.
Figure 3-10. Logic diagramof Vertical Binary stage.
Figure3-11. ldealizedwaveforms showing relationshipbetween input and output waveforms
for Vertical Binary and Plug-InBinary stages when operating inALT mode.
Figure3-12. Logic diagram of Plug-InBinary and Plug-InAlternate Buffer stage.
Figure3-13. Detailed block diagram of Trigger Selector circuit along with simplified diagram
of trigger source selection circuitry.
Figure3-14. lnput levelsat pin4 of U324.
Figure3-15. I nputloutput table for Trigger Channel Switch stage.
Figure 3-16. Vertical Interfacedetailed block diagram.
Figure 3-17. Input/output table for Vertical Channel Switch.
Figure3-18. Vertical Amplifier detailed block diagram.
Figure3-19. Horizontal Amplifier detailed block diagram.
Figure3-20. CRT circuit detailed block diagram.
Figure3-21. Low-VoltagePower Supply detailed block diagram.
Figure3-22. Schematic illustrating voltage drop betweenpower supply output and load due
to resistance of interconnectingwire.
Figure 3-23. Calibratordetailed block diagram.
Figure3-24. Location of readoutwords on the crt identifyingthe originatingplug-inunit
and channel (onecomplete frame shown).
Scans by ARTEK MEDU =>

7623AlR7623A Service
LIST OF ILLUSTRATIONS (cont.)
Figure 3-25. Character SelectionMatrix for 7623A Readout System.
Figure 3-26. Typical readoutdisplay where only channel
2 of the Right Vertical and
Horizontal units
is displayed.
Figure3-27. Detailed block diagram of the ReadoutSystem.
Figure3-28. Output waveforms of Timer stage.
Figure 3-29. Detailof output at pins 12, 13, 14, and 16 of U2126.
Figure3-30. Timer stage operationwhen Display-Skipcondition occurs.
Figure3-31. Time relationshipof the time-slot (TS)pulses producedby U2159.
Figure 3-32. Typical encoding scheme for voltage-sensingamplifier plug-inunit. Coding
shownfor deflection factor of 100microvolts.
Figure3-33. Idealizedcurrent waveforms of: (A)Row analog data, (6)Columnanalog data.
Figure 3-34. Block representationof memory sequence inU2232.
Figure 3-35. Typical output waveformsfor Zeros Logic and Memory stage operation(atpin
7 of U2232).
Figure3-36. Readout word relating10possiblecharacter locationsto the decimal point
instructionsthat can be encoded, and the resultantcrt display.
Figure 3-37. Flow chart for character generation by the Readout System.
Figure3-38. Storage circuit simplified block diagram.
Figure 3-39. Time relationshipof Storage logic pulses.
Figure 3-40. BISTABLE modeStorage waveforms.
Figure3-41. VAR PERSIST mode Storage waveforms.
Figure3-42. FAST BISTABLE mode Storage waveforms.
Figure3-43. FAST VAR PERSIST modeStorage waveforms.
Figure4-1. Power Unit removal.
Figure4-2. Location of circuit boards inthe 7623A.
Figure4-3. Location of circuit boards inthe R7623A.
Figure4-4. Circuit isolation troubleshootingchart.
Figure4-5. Location of screws holding Low Voltage sub-chassis.
Figure4-6. Location of screws holdingSignals Out rear panel.
Figure 5-1. Typical crtdisplay when checking
X-Y phase shift.
Figure5-2. Location of Calibrator ACIDC jumper.
Figure5-3. Location of High-VoltageTest Point.
Figure5-4. Location of adjustments in High-Voltagecover.
Figure5-5. Typical crt display when checking
X-Y phase shift.
Figure5-6. Location of CalibratorACIDC jumper.
PAGE
Section8 figuresare located near their associateddiagrams on the foldout pages.
REV B MAR 1980
Scans by ARTEK MEDL4 =>
vii

7623AIR7623A Service
LIST OF TABLES
PAGE
TABLE 1-1. Power Cord Color-Coding
TABLE 1-2. RegulatingRange and Fuse Data
TABLE 2-1. ELECTRICAL
TABLE 2-2. ENVIRONMENTAL
TABLE 2-3. PHYSICAL
TABLE 2-4. 7623A SYSTEM SPECIFICATIONS
TABLE 3-1. Basic Logic Reference
TABLE 3-2. Standard Readout Format
TABLE 3-3. Channel Address Code
TABLE 4-1. Power Supply Tolerances
TABLE 4-2. Fuse Rating
TABLE 4-3. SelectedComponent Criteria
TABLE 5-1. Test Equipment
TABLE 5-2. Power Supply Tolerances
TABLE 5-3. High-FrequencyCompensationAdjustments
REV MAY 1983
Scans by ARTEK MEDU =>

7623AIR7623A Service
SERVICE SAFETY SUMMARY
FOR QUALIFIED SERVICE PERSONNEL ONLY
Refer also to the preceding Operators Safety Summary.
Do Not Service Alone
Do not perform internal service or adjustment of this
product unless another person capable of rendering first
aid and resuscitation is present.
Use Care When Servicing With Power On
Dangerousvoltages exist at several pointsinthisproduct.
To avoid personal injury, do not touch exposed connec-
tions and components while power is on.
ADD MAR 1982
Disconnect power tiefore removing protective panels,
soldering, or replacing components.
Power Source
This product is intendedtooperate from a power source
that will not apply morethan
250 volts rms betweenthe
supply conductors or between either supply conductor
andground.
A protectivegroundconnection byway of the
grounding conductor in the power cord is essential for
safe operation.
Scans by ARTEK MEDIA =>

The Tektronix 7623AlR7623A Storage Oscilloscope is asolid-stateinstrumentdesigned for fast writing rate storage
applications. The 7623A operates inthreedisplay modes-NON STORE, STORE, and SAVE, and has four storage modes-
BISTABLE, VAR PERSIST, FAST BISTABLE, and FAST VAR PERSIST. This instrumenthas three plug-incompartments
that acceptany 7-series plug-inunits to form ahighly flexible measurementsystem.
7623AlR7623A Service
Scans by ARTEK MEDM =>

Section 1 -7623AlR7623A Service
OPERATING INFORMATION
PRELIMINARY OPERATION
To effectively use the 7623AlR7623A Storage Oscilloscope,the operationand capabilitiesof the instru-
ment must be known. This sectionprovides preliminary operating information, describes operationofcon-
trols and connectors, and providesan operating checkout procedure.
AC POWER SOURCES
This instrument is intendedto be operated from a single-phase, earth-referencedpowersource having
one current-carryingconductor (the NeutralConductor) near earth potential. Operationfrom power sources
where both current-carryingconductors are live with respect toearth (such
as phase-to-phaseon athree-wire
system)
is notrecommendedsince only the Line Conductor has over-current (fuse)protectionwithin the
instrument.
AC POWER CORD
This instrumenthas a three-wirepower cord with athree-terminalpolarized plug for connectionto
the power source and safety-earth. The safety-earthterminal of the plug
is directly connected tothe in-
strumentframe. For electric-shockprotection, insertthis plugonly inamatingoutlet with
a safety-earth
cqntactor otherwiseconnectthe frame to asafety earth system. The color-codingof the cord conductors
is in accordance with recognizedstandardsas shown inTable 1-1.
TABLE 1-1
Power Cord Conductor Identification
Ungrounded (Line) 1 Brown I Black
Conductor
Grounded (Neutral)
I
Blue 1 White
I I
Color
OPERATING VOLTAGE
The 7623AIR7623Acan be operated from either a 110-voltor a220-volt nominal line-voltagesource.
Inaddition, three operatingranges can be selectedwithin each nominal line voltage source. Use the follow-
ing procedure to obtain correct instrumentoperationfrom the line voltage available:
Alternate Color
Grounding (Earthing)
1. Disconnectthe instrumentfrom the power source.
2. Removethe six screws securing the power unit (ninescrews inthe R7623A; see Figure 1-1 ).
Green-Yellow
3. Slidethe power unitout of the rear of the chassis.
Green-Yellow
REV. C, FEB. 1977
Scans by ARTEK MEDLQ *

Operating Information-7623AlR7623A Service
%#
ALT SPARE VOLTAGESELECTOR
JUMPER
Figure
1-1. Locationof voltage-selector jumper.
4.
To convert from 110-voltsto 220-volts nominal line voltage, or vice versa, remove the voltage-
selector jumper and replace it with the spare jumper stored on the pins adjacent tothe voltage selector
.
area (see Figure 1-1). The jumpers are color codedto indicatethe nominalvoltage for which they are in-
tended; brown for 110-voltnominaloperationand red for 220-voltnominaloperation. Change the fuse to
provide protection for the selected nominal line voltage. Use the fuse located inthe Alt Fuse holder on the
Rectifier board (see Figure1-1for fuse location and Table 1-2for fuse type). Also, change the line-cord
plugto match the power-sourcereceptacle or use asuitableadapter.
Scans by ARTEK MEDLQ =>

Operating Information-7623AlR7623A Service
5. To convert the instrumentfrom one regulatingrangeto another, remove the voltage selector
jumper and re-install
it onthe set of pins correspondingtothe desired regulatingrange. The proper reg-
ulating ran& will center about the average line voltage towhich the instrument
is to be connected (see
Table 1-21.
TABLE 1-2
Regulating Range and Fuse Data
OPERATING TEMPERATURE
The 7623A can be operated where the ambient air temperature is between OOC and +50°c. This in-
strument can be stored in ambient temperatures between -55'~ and +75O~.After storage
at temperatures
,beyond the operatinglimits, allow the chassis temperatureto come within the operating limits before power
is applied.
Pins
Selected
LOW
MED
HI
Line Fuse
The 7623A
is cooled by air drawn in through the top, side, and bottom panels and exhausted through
the rear panel. Componentsthat require most coolingare mountedexternally on
a heat radiator. Adequate
clearance must be provided on all sides to allow heat to be dissipatedfrom the instrument. Do not block or
restrict the air flow through the holes inthe cabinetor the heat radiator. Maintainthe clearance provided
by the feet onthe bottom and allow about two inches clearanceon the top, sides, and rear (more if possible).
The R7623A
is cooled by air drawn inthrough the air filter on the rear panel and exhausted through
portson the right side of the instrument. Adequate clearance must be provided at these locations. Allow
at least one and one-half inches clearance behind the air filter and at least one inchon the right side.
Regulating Range'
A thermal cutout interrupts power to the instrument if the internaltemperatureexceeds asafe oper-
ating level. Power
is automatically restored when the temperaturereturnsto asafe level. Operationin
confinedareas or close to
a heat source may cause the thermal cutout to open.
I 10-volts(nominal)
90to
I 10volts
99 to 121volts
108to 132volts
3.2 A slow-blow
RACKMOUNTING
Instructionsand dimensional drawings for rackmountingthe R7623A are given inthe Operatorsmanual.
220-volts (nominal)
180to 220 volts
198to 242 volts
218 to 262 volts
1.6 A slow-blow
Scans by ARTEK MEDL4 =>

Operating Information-7623AlR7623A Service
PLUG-INUNITS
The 7623A will accept up to three 7-series plug-inunits. This plug-infeature permits a variety of
display combinationsand also allows selectionof bandwidth, sensitivity, display mode, etc. to meet many
measurementrequirements. Inaddition,
it allowsexpansionof the oscilloscope systemto meet future
measurementrequirements. The overall capabilities of the resultant system are in large part determined
by the characteristicsof the plug-inselected. For complete informationon plug-insavailablefor use with
this instrument,see the current Tektronix, Inc., catalog.
PLUG-ININSTALLATION AND REMOVAL
To installaplug-inunit intoone of the plug-incompartments,align the slots inthe topand bottom
of the plug-inwith the associated guide rails inthe plug-incompartment. Push the plug-inunit firmly into
the plug-incompartmentuntil
it locksinto place. To remove aplug-in, pull the release latchon the plug-in
unitto disengage
it and pullthe unit out of the plug-incompartment. Plug-inunits can be removedor in-
stalled without turningoff the instrument power.
It is not necessary that all of the plug-incompartmentsbe filled tooperate the instrument;the only
plug-inunits needed are those requiredfor the measurementto be made. However, at environmental ex-
tremes, excess radiation may be radiatedintoor out of this instrumentthrough the open plug-incompart-
ments. Blank plug-inpanels are available from Tektronix, Inc., tocover the unusedcompartment; order
Part No. 016-0155-00.
When the 7623A is calibrated in accordancewith the calibration proceduregiven inSection 5,
the vertical and horizontal gains are standardized. This allowscalibrated plug-inunits to be changed from
one plug-incompartmentto another without recalibration. However, the basic calibration of the individual
plug-inunits should be checked when they are installed in this system toverify their measurement accuracy.
See the plug-inunit instruction manual for verification procedure.
Special purpose plug-inunits may have specific restrictionsregardingthe plug-incompartments in
which they can be installed. This information will be given inthe instruction manual for these plug-inunits.

Operating Information-7623AlR7623A Service
CONTROLS AND CONNECTORS
The major controls for operationof the 7623A are locatedon the front panel of the instrument. These
are illustrated in Figure
1-2. Figure 1-3 shows the location of rear panel controls and connectors. The follow.
ing
is abrief descriptionof the controls and connectors shown in Figures 1-2 and 1-3. More detailedoperat-
ing information
is given under General Operating Information.
'Change
TERNAL ADJUSTSN B130000-up.
Figure 1-2.
Front panel controls and connectors.
REV. B, JUNE, 1976
Scans by A. TEK MEDIA =>

Operating Information-7623AIR7623A Service
FRONT PANEL CONTROLS AND CONNECTORS
The following descriptionsare referencedto Figure 1-2.
@ VERT MODE: Selects vertical modeoperation.
LEFT: Selects signals from the leftvertical amplifier compartmentfor display.
ALT: Selects signals from both vertical compartmentsfor display on alternate
sweeps (dualtrace).
ADD: Algebraically adds the signals from both vertical compartmentsand dis-
playsthe sum.
CHOP: Selects signals from both vertical compartmentsfor display (dualtrace).
The display switches between bothvertical compartmentsignals, during
the sweep, at aone megahertz rate.
RIGHT: Selects signals from the right vertical amplifier compartmentfor display.
@) TRIG SOURCE: Selects the sourceof the internaltrigger for the plug-inunit inthe hori-
zontal compartment.
LEFT: Selects the leftvertical compartmentas the internaltrigger source.
VERT MODE: Internaltrigger signals are determined by the VERT MODE switch.
RIGHT: Selects the right vertical compartmentas the internal trigger source.
@ INTENSITY-Controls the brightnessof the display.
@ READOUT-Turns onthe Readoutsystem and controls the brightness of the Readout display.
(Option
1 deletesthis function.)
@ BEAMFINDER-When pressed, this switch limitsthe display towithin thegraticule area.
@ GRATICULE ILLUM-Controls the illumination of the graticule.

Operating Information-7623AlR7623A Service
FRONT PANEL CONTROLS AND CONNECTORS (cont.)
@ ERASE-Initiates erase cycles; either MANual or PERIODIC.
MANual: When pressed, initiates an erase cycle to erase the storeddisplay and
provideasingle-shotreset commandtothe plug-intime-baseunit.
Operation
is lockedout inSAVE display mode.
PERIODIC: Controls the time betweenautomaticerase cycles. Ifthe erase period
ends during
a sweep, the erasure is delayed till the end of that sweep.
This control has
a counterclockwiseOFF detent position. Operation
is lockedout inthe SAVE display mode.
@ PERSISTENCE-Controls theview time of the VAR PERSIST and FAST VAR PERSIST
storeddisplays. Operation
is lockedout inthe SAVE display mode.
@ FAST-Used in conjunctionwith the VAR PERSISTand BISTABLEstorage selectionstochoose
thefast transfer storage modes of either FAST VAR PERSIST or FAST BISTABLE.
@ VAR PERSIST-Selects the Variable Persistencestoragemode. The storeddisplay is of variable
intensitydependent uponthe setting of the STORAGE LEVEL, density of charge deposited
when storing, etc. The storeddisplay can be erased
at a controllable, continuous rate determined
by the setting of the PERSISTENCEcontrol. When not being erased, the view time
is limited by
the natural brightfading of the storage target.
@ BISTABLE-Selects the BISTABLEstorage mode. The stored display is substantiallyof two
fixed intensity levels; written (bright)and unwritten (background). An erase cyclereturnsthe
display to the unwritten state.
@ POWER-Switch and indicator. Switch appliespower to the instrumentand the indicator illumi-
nates to indicatethe power
is on.
@ CALIBRATOR-Positive going square wave or dc voltage selected by an internaljumper. Output
voltageat pinjacks
(4 V, 0.4 V, and 40 mV).
@ STORAGE LEVEL-Controls thevoltage level on the storagetargets. Adjusts writing speed in
FAST BISTABLE, VAR PERSIST, and FAST VAR PERSIST.
@ SAVE INTEN-Used inconjunctionwith SAVE to control the storage viewing intensity. At
reduced intensity, theview time of the stored VAR PERSISTdisplay
is proportionatelyex-
tended.
@ SAVE-Selects the SAVE display mode. The stored display is retained at a controllableSAVE
INTENSITYand the erase functionsare lockedout. The time-baseunit
is inhibited except
when the SAVE mode
is enteredfrom STORE before a sweep occurs. Ifthis is done, thedis-
play will wait inthe STORE mode and enter SAVE automatically
at the end of the next
Scans by ARTEK MEDU =>
