Tektronix CTRL7100 Series User manual

650-6183-00 and 650-6184-00
RSA7100 and CTRL7100 Series
Packaging Kit
ZZZ
Instructions
xx
www.tek.com
$
071-3736-00

Copyright © Tektronix. All rights reserved. Licensed software products are owned by Tektronix or its subsidiaries
or suppliers, and are protected by national copyright laws and international treaty provisions.
Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication
supersedes that in all previously published material. Specifications and price change privileges reserved.
TEKTRONIX and TEK are registered trademarks of Tektronix, Inc.
Contacting Tektronix
Tektronix, Inc.
14150 SW Karl Braun Drive
P.O. Box 500
Beaverton, OR 97077
USA
For product information, sales, service, and technical support:
In North America, call 1-800-833-9200.
Worldwide, visit www.tek.com to find contacts in your area.

Table of Contents
Packaging kit parts lists............................................................................................ 1
650-6183-00 CTRL7100 packaging procedure ................................................................. 2
650-6184-00 RSA7100 packaging procedure .................................................................. 10
RSA7100 and CTRL7100 Series Packaging Kit Instructions i

Table of Contents
ii RSA7100 and CTRL7100 Series Packaging Kit Instructions

Packaging kit parts lists
These instructions provide procedures for using the following packaging kits.
650-6183-00 CTRL7100 kit
650-6184-00 RSA7100 kit
WARNING. Injury may occur when lifting heavy objects. The CTRL7100 and
RSA7100 are heavy instruments. To avoid injury, ensure proper lifting technique
using two people or a mechanical lift when performing the procedures in this
document.
Identify whichkityouorderedandthenreferto one of the following tables for a
list of items included in your kit.
Table 1: 650-6183-00 CTRL7100 Packaging Kit parts list
Item Description Quantity
004-5964-xx BOX, SHIPPING CTRL7100A 1
004-5965-xx CUSHION, MTL: PACKAGING, TOP AND BOTTOM 4
004-5966-xx CUSHION, MTL: PACKAGING, FRONT & BACK 2
004-5967-xx CUSHION, MTL: PACKAGING, LEFT & RIGHT 2
004-5968-xx CUSHION, MTL: PACKAGING, REAR PANEL 1
006-8267-xx BAG - PLASTIC, 32 X 32 X .004 THK LDPE 1
071-3736-xx [This document.]
CTRL7100 AND RSA7100 SERIES PACKAGING KIT
INSTRUCTIONS
1
Table 2: 650-6184-00 RSA7100 Packaging Kit parts list
Item Description Quantity
004-5969-xx BOX, SHIPPING RSA7100A 1
004-5973-xx BOX, SHIPPING, RSC (for accessories) 1
004-6118-xx CUSHION MATERIAL; PACKAGING FOR RSA7100
CONTROLLER
1
006-8267-xx BAG - PLASTIC, 32 X 32 X .004 THK LDPE 1
071-3736-xx [This document.]
CTRL7100 AND RSA7100 SERIES PACKAGING KIT
INSTRUCTIONS
1
RSA7100 and CTRL7100 Series Packaging Kit Instructions 1

650-6183-00 CTRL7100 packaging procedure
650-6183-00 CTRL7100 packaging procedure
WARNING. Injury may occur when lifting heavy objects. The CTRL7100 is a
heavy instrument. To avoid injury, ensure proper lifting technique using at least
two people when performing the procedures in this document.
2 RSA7100 and CTRL7100 Series Packaging Kit Instructions

650-6183-00 CTRL7100 packaging procedure
1. Using at least two people, slide 32" x 32" bag
[006-8267-xx] around unit and taped closed.
RSA7100 and CTRL7100 Series Packaging Kit Instructions 3

650-6183-00 CTRL7100 packaging procedure
2. Make box [004-5964-xx] and place 2 foam pieces [004-5965-xx] in as shown.
4 RSA7100 and CTRL7100 Series Packaging Kit Instructions

650-6183-00 CTRL7100 packaging procedure
3. Install the following 3 foam pieces as
shown: one 004-5966-xx, two 004-5967-xx.
RSA7100 and CTRL7100 Series Packaging Kit Instructions 5

650-6183-00 CTRL7100 packaging procedure
4. Using at least two people, lift controller and place in box with blue pieces, as
shown.
6 RSA7100 and CTRL7100 Series Packaging Kit Instructions

650-6183-00 CTRL7100 packaging procedure
5. Insert foam pieces [004-5966-xx] and [004-5968-xx],
as shown, with cutout aligning with tab on controller.
RSA7100 and CTRL7100 Series Packaging Kit Instructions 7

650-6183-00 CTRL7100 packaging procedure
6. Place 2 foam pieces [004-5965-xx] as shown.
8 RSA7100 and CTRL7100 Series Packaging Kit Instructions

650-6183-00 CTRL7100 packaging procedure
7. Close and tape box. Attach label 1 of 3 to this box, as shown.
8. Add "Band on Pallet" sheet on box as shown.
RSA7100 and CTRL7100 Series Packaging Kit Instructions 9

650-6184-00 RSA7100 packaging procedure
650-6184-00 RSA7100 packaging procedure
WARNING. Injury may occur when lifting heavy objects. The RSA7100 is a heavy
instrument. To avoid injury, ensure proper lifting technique using two people or a
mechanical lift when performing the procedures in this document. A mechanical
lift can also be used.
1. Install a cardboard protector to the rear of the
instrument, as shown, to protect the connectors.
10 RSA7100 and CTRL7100 Series Packaging Kit Instructions

650-6184-00 RSA7100 packaging procedure
2. Open the 32" x 32" bag [006-8267-xx] and place it on the floor. Place the unit
on its side, with handle up, onto the bag. Lift unit up and pull the bag up
and around unit.
RSA7100 and CTRL7100 Series Packaging Kit Instructions 11

650-6184-00 RSA7100 packaging procedure
3. Form box [004-5969-xx]. Place part of foam packaging [044-6118-xx] into
box bottom. Locate cutout for connectors (see outlined area in image).
4. Using two people or mechanical lift, lower unit
into box, ensuring connectors line up with cutout.
12 RSA7100 and CTRL7100 Series Packaging Kit Instructions

650-6184-00 RSA7100 packaging procedure
5. Tape bag closed as shown.
6. Place other foam piece [044-6118-xx] on
top of unit and align cutout with connectors.
RSA7100 and CTRL7100 Series Packaging Kit Instructions 13

650-6184-00 RSA7100 packaging procedure
7. Close and tape box. Attach label 2 of 3 to this box, as shown.
14 RSA7100 and CTRL7100 Series Packaging Kit Instructions

650-6184-00 RSA7100 packaging procedure
8. If you have accessories and are including them, place all accessories in the
accessories box that may have been included with your kit (004-5973-xx)
and fill all voids with bubble wrap or like material to secure items in place.
9. Close and tape the accessories box and attach the label to the box.
RSA7100 and CTRL7100 Series Packaging Kit Instructions 15
