Tektronix MSO2000B Series Manual

xx
MSO2000B and DPO2000B Series
Oscilloscopes
Installation and Safety
ZZZ
Instructions
*P071307801*
071-3078-01

MSO2000B and DPO2000B Series
Oscilloscopes
Installation and Safety
ZZZ
Instructions
xx
www.tektronix.com
071-3078-01

Copyright © Tektronix. All rights reserved. Licensed software products are owned by Tektronix or its subsidiaries
or suppliers, and are protected by national copyright laws and international treaty provisions.
Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication
supersedes that in all previously published material. Specifications and price change privileges reserved.
TEKTRONIX and TEK are registered trademarks of Tektronix, Inc.
Contacting Tektronix
Tektronix, Inc.
14150 SW Karl Braun Drive
P.O. Box 500
Beaverton, OR 97077
USA
For product information, sales, service, and technical support:
In North America, call 1-800-833-9200.
Worldwide, visit www.tektronix.com to find contacts in your area.

Table of Contents
Preface............................................................................................................... 1
Accessories and Replaceable Parts .......................................................................... 1
Documentation................................................................................................. 4
General Safety Summary .......................................................................................... 5
Compliance Information........................................................................................... 7
EMC Compliance.............................................................................................. 7
Safety Compliance............................................................................................. 9
Environmental Considerations .............................................................................. 11
Operating Requirements .......................................................................................... 12
Electrical Ratings ............................................................................................. 14
Input Ratings .................................................................................................. 14
Environmental Ratings....................................................................................... 15
Physical Specifications....................................................................................... 15
Installation Procedure............................................................................................. 16
Power-On and Power-Off Procedure ............................................................................ 18
Functional Check ............................................................................................. 19
Compensating a Passive Voltage Probe .................................................................... 20
Application Module Free Trial.............................................................................. 21
Upgrading Firmware ......................................................................................... 22
Connecting Your Oscilloscope to a Computer............................................................. 23
Getting Acquainted with the Oscilloscope............ .............................. .......................... .. 24
Front-Panel Menus and Controls............................................................................ 24
Front-Panel Connectors ...................................................................................... 31
Side-Panel Connector ........................................................................................ 31
Rear-Panel Connectors....................................................................................... 32
まえがき .................................................................................................. 33
アクセサリと交換部品 ............................................................................... 33
マニュアル ........................................................................................... 37
安全にご使用いただくために .......................................................................... 38
適合性に関する情報.................................................................................... 40
EMC 適合性 ......................................................................................... 40
安全性 ............................................................................................... 42
環境への配慮 ....................................................................................... 44
動作の要件 .............................................................................................. 45
電気定格 ............................................................................................ 47
入力定格 ............................................................................................ 47
環境要件 ............................................................................................ 48
物理仕様 ............................................................................................ 48
MSO2000B and DPO2000B Installation and Safety Instructions i

Table of Contents
インストール手順 ........................................................................................ 49
電源投入、電源切断の手順............................................................................ 51
機能チェック......................................................................................... 52
受動電圧プローブの補正 .......................................................................... 53
アプリケーション・モジュールの無料トライアル ................................................... 54
ファームウェアのアップグレード.................................................................... 55
オシロスコープとコンピュータの接続 .............................................................. 56
オシロスコープの概要 .................................................................................. 57
フロント・パネル・メニューとコントロール........................................................... 57
フロント・パネル・コネクタ ........................................................................... 64
サイド・パネル・コネクタ............................................................................. 65
リア・パネル・コネクタ ............................................................................... 65
前言 ...................................................................................................... 68
附件和可更换部件 ................................................................................. 68
文档 .................................................................................................. 72
常规安全概要 ........................................................................................... 73
符合性信息 .............................................................................................. 76
EMC 符合性 .......................................................................................... 76
安全符合性.......................................................................................... 78
环境注意事项....................................................................................... 80
操作要求................................................................................................. 81
电气额定值.......................................................................................... 83
输入额定值.......................................................................................... 83
环境额定值.......................................................................................... 84
物理技术规格....................................................................................... 84
安装步骤................................................................................................. 85
开机和关机步骤 ........................................................................................ 87
功能检查 ............................................................................................ 88
补偿无源电压探头 ................................................................................. 89
应用模块免费试用 ................................................................................. 90
升级固件 ............................................................................................ 91
将示波器连接到计算机............................................................................ 92
熟悉示波器 .............................................................................................. 92
前面板菜单和控制 ................................................................................. 92
前面板连接器....................................................................................... 99
侧面板连接器....................................................................................... 99
后面板连接器...................................................................................... 100
ii MSO2000B and DPO2000B Installation and Safety Instructions

Preface
This manual describes the installation and operation of the following
oscilloscopes:
DPO2002B DPO2004B DPO2012B
DPO2014B DPO2022B DPO2024B
MSO2002B MSO2004B MSO2012B
MSO2014B MSO2022B MSO2024B
Important safety precautions to avoid injury and prevent damage to this
product or any products connected to it
EMC (electromagnetic compliance), safety, and environmental standards with
which the product complies
Voltage, power, and environmental requirements to use the product
Installation procedure
Power-on and power-off procedure
Front- and rear-panel controls and connectors
Accessories and Replaceable Parts
Standard Accessories
Accessory Description
Tektronix part
number
DPO2000B and MSO2000B
Series Oscilloscopes Installation
and Safety Instructions
Provides safety and compliance
information along with hardware
installation instructions to present
the associated safety warnings.
This manual is available in English,
Simplified Chinese, and Japanese
071-3078‑XX
DPO2000B and MSO2000B
Series Oscilloscopes
Documentation CD
Electronic versions of documents,
including the Programmer Manual
and the Technical Reference.
063-4472‑XX
Tektronix OpenChoice Desktop
PC Communications CD
Productivity, analysis, and
documentation software.
063-4402‑XX
Calibration certificate
documenting traceability to
national metrology institute(s),
and ISO9001 quality system
registration
——
MSO2000B and DPO2000B Installation and Safety Instructions 1

Preface
Standard Accessories, (cont.)
Accessory Description
Tektronix part
number
French (Option L1) 335-2020-00
Italian (Option L2) 335-2021-00
German (Option L3) 335-2022-00
Spanish (Option L4) 335-2023-00
Japanese (Option L5) 335-2024-00
Portuguese (Option L6) 335-2025-00
Simple Chinese (Option L7) 335-2026-00
Traditional Chinese (Option L8) 335-2027-00
Korean (Option L9) 335-2028-00
Front panel overlay
Russian (Option L10) 335-2029-00
For models 100 MHz bandwidth:
One 200 MHz, 10X passive voltage
probe with 10 Minput resistance
per channel
TPP0200
For DPO2000B and
MSO2000B series: Probes
For models < 100 MHz bandwidth:
One 100 MHz, 10X passive voltage
probe with 10 Minput resistance
per channel
TPP0100
For MSO2000B series: Digital
probe
One, 16-channel digital probe P6316
For MSO2000B series:
Accessories pouch
Pouch that attaches to the handle
for carrying probes and other
accessories.
016-2008-00
Five year warranty For details, refer to the warranty
in the front of the electronic (PDF)
user manual
——
North America (Option A0) 161-0348-00
Universal Euro (Option A1) 161-0343-00
United Kingdom (Option A2) 161-0344-00
Australia (Option A3) 161-0346-00
Switzerland (Option A5) 161-0347-00
Japan (Option A6) 161-0342-00
China (Option A10) 161-0341-00
India (Option A11) 161-0349-00
Brazil (Option A12) 161-0356-00
Power cord
No power cord or AC adapter
(Option A99)
——
2 MSO2000B and DPO2000B Installation and Safety Instructions

Preface
Optional Accessories
Accessory Description Tektronix partnumber
DPO2EMBD The embedded serial triggering and analysis module
enables triggering on packet level information on I2C and
SPI serial buses, as well as bus views, bus decoding,
search tools, and packet decode tables with timestamp
information
DPO2EMBD
DPO2AUTO The automotive serial triggering and analysis module
enables triggering on packet level information on CAN
and LIN serial buses, as well as bus views, bus decoding,
search tools, and packet decode tables with timestamp
information
DPO2AUTO
DPO2COMP The computer triggering and analysis module enables
triggering on RS-232, RS-422, RS-485 and UART serial
buses, search tools, bus views, bus decoding in hex,
binary, and ASCII, and decode tables with timestamp
information
DPO2COMP
DPO2CONN The connectivity module adds an Ethernet port for
remote programmability and a Video Out port to display
the oscilloscope screen on an external monitor
DPO2CONN
NEX-HD2HEADER Adapter that routes the channels from a Mictor connector
to 0.1 inch header pins
NEX-HD2HEADER
TekVPI probes that work with
MSO/DPO2000B Series oscilloscopes
Note: These probes require the use
of the TekVPI external power adapter
listed below.
Visit the Oscilloscope Probe and Accessory Selector
Tool on the Tektronix website at www.tektronix.com
TekVPI external power adapter Supplies external power to a TekVPI probe 119‑7465‑XX
TPA-BNC
Note: This adapter requires the use
of the TekVPI external power adapter
listed above.
TekVPI to TekProbe II BNC Adapter TPA-BNC
Deskew pulse generator Deskew pulse generator and signal source with TekVPI
oscilloscope interface
TEK-DPG
Power measurement deskew and
calibration fixture
Converts TEK-DPG pulse generator output into a series
of test point connections
067-1686-00
TEK-USB-488 Adapter GPIB to USB Adapter TEK-USB-488
Rackmount kit Adds rackmount brackets RMD2000
Soft transit case Case for carrying an oscilloscope ACD2000
Hard transit case Traveling hard case, which requires use of the soft transit
case (ACD2000)
HCTEK4321
DPO2000B and MSO2000B Series
Oscilloscopes Service manual
Service information on DPO2000B and MSO2000B series
oscilloscopes
077-0737‑XX
DPO2000B and MSO2000B Series
Oscilloscopes Application Module
Installation
Describes how to install application modules in
DPO2000B and MSO2000B series oscilloscopes
071-2330‑XX
MSO2000B and DPO2000B Installation and Safety Instructions 3

Preface
Documentation
The following table lists the documentation that is available for the product and
shows where you can find it: in a printed manual, on the product documentation
CD-ROM, or on the Tektronix Web site at www.tektronix.com.
Table 1: Product documentation
Item Purpose Location
Installation and Safety Instructions (this
manual)
Provides safety and compliance
information along with hardware
installation instructions to present the
associated safety warnings. This manual
is available in English, Japanese, and
Simplified Chinese
Printed manual and also
available in electronic format at
www.tektronix.com/manuals
User Manual Provides operation and application
information. This manual is available
in English, French, Italian, German,
Spanish, Japanese, Portuguese,
Simplified Chinese, Traditional Chinese,
Korean, and Russian
Product Documentation CD and available
at www.tektronix.com/manuals
Specifications and Performance
Verification Technical Reference
Specifications and procedures for
checking instrument performance.
Product Documentation CD and available
at www.tektronix.com/manuals
Programmer Manual Command reference for remotely
controlling the instrument.
Product Documentation CD and available
at www.tektronix.com/manuals
Service Manual Provides information about adjustments,
repair, and replaceable parts.
Available at www.tektronix.com/manuals
4 MSO2000B and DPO2000B Installation and Safety Instructions

General Safety Summary
General SafetySummary
Review the following safety precautions to avoid injury and prevent damage to
this product or any products connected to it.
To avoid potential hazards, use this product only as specified.
Only qualified personnel should perform service procedures.
While using this product, you may need to access other parts of a larger system.
Read the safety sections of the other component manuals for warnings and
cautions related to operating the system.
To Avoid Fire or Personal
Injury
Use Proper Power Cord. Use only the power cord specified for this product and
certified for the country of use.
Connect and Disconnect Properly. Do not connect or disconnect probes or test
leads while they are connected to a voltage source.
Connect and Disconnect Properly. De-energize the circuit under test before
connecting or disconnecting the current probe.
Ground the Product. This product is grounded through the grounding conductor
of the power cord. To avoid electric shock, the grounding conductor must be
connected to earth ground. Before making connections to the input or output
terminals of the product, ensure that the product is properly grounded.
Observe All Terminal Ratings. To avoid fire or shock hazard, observe all ratings
and markings on the product. Consult the product manual for further ratings
information before making connections to the product.
Connect the probe reference lead to earth ground only.
Do not apply a potential to any terminal, including the common terminal, that
exceeds the maximum rating of that terminal.
Power Disconnect. The power cord disconnects the product from the power
source. Do not block the power cord; it must remain accessible to the user at
all times.
Do Not Operate Without Covers. Do not operate this product with covers or
panels removed.
Do Not Operate With Suspected Failures. If you suspect that there is damage to
this product, have it inspected by qualified service personnel.
Avoid Exposed Circuitry. Do not touch exposed connections and components
when power is present.
MSO2000B and DPO2000B Installation and Safety Instructions 5

General Safety Summary
Do Not Operate in Wet/Damp Conditions.
Do Not Operate in an Explosive Atmosphere.
Keep Product Surfaces Clean and Dry.
Provide Proper Ventilation. Refer to the manual’s installation instructions for
details on installing the product so it has proper ventilation.
TermsinthisManual These terms may appear in this manual:
WARNING. Warning statements identify conditions or practices that could result
in injury or loss of life.
CAUTION.Caution statements identify conditions or practices that could result in
damage to this product or other property.
Symbols and Terms on the
Product
These terms may appear on the product:
DANGER indicates an injury hazard immediately accessible as you read
the marking.
WARNING indicates an injury hazard not immediately accessible as you
read the marking.
CAUTION indicates a hazard to property including the product.
The following symbol(s) may appear on the product:
6 MSO2000B and DPO2000B Installation and Safety Instructions

Compliance Information
Compliance Information
This section lists the EMC (electromagnetic compliance), safety, and
environmental standards with which the instrument complies.
EMC Compliance
EC Declaration of
Conformity – EMC
Meets intent of Directive 2004/108/EC for Electromagnetic Compatibility.
Compliance was demonstrated to the following specifications as listed in the
Official Journal of the European Communities:
EN 61326-1:2006, EN 61326-2-1:2006. EMC requirements for electrical equipment
for measurement, control, and laboratory use. 123
CISPR 11:2003. Radiated and conducted emissions, Group 1, Class A
IEC 61000-4-2:2001. Electrostatic discharge immunity
IEC 61000-4-3:2002. RF electromagnetic field immunity 4
IEC 61000-4-4:2004. Electrical fast transient/burst immunity
IEC 61000-4-5:2001. Power line surge immunity
IEC 61000-4-6:2003. Conducted RF immunity 5
IEC 61000-4-11:2004. Voltage dips and interruptions immunity 6
EN 61000-3-2:2006. AC power line harmonic emissions
EN 61000-3-3:1995. Voltage changes, fluctuations, and flicker
European Contact.
Tektronix UK, Ltd.
Western Peninsula
Western Road
Bracknell, RG12 1RF
United Kingdom
United Kingdom
1This product is intended for use in nonresidential areas only. Use in residential areas may cause electromagnetic
interference.
2Emissions which exceed the levels required by this standard may occur when this equipment is connected to a
test object.
3To ensure compliance with the EMC standards listed here, high quality shielded interface cables should be used.
4Trace bloom not exceeding 4 divisions pk-to-pk may be induced under the conditions of the IEC 61000-4-3 test.
5Trace bloom not exceeding 1 division pk-to-pk may be induced under the conditions of the IEC 61000-4-6 test.
6Performance Criterion C applied at the 70%/25 cycle Voltage-Dip and the 0%/250 cycle Voltage-Interruption test
levels (IEC 61000-4-11).
MSO2000B and DPO2000B Installation and Safety Instructions 7

Compliance Information
7Add text here to list inrush current information.
Australia / New Zealand
Declaration of
Conformity – EMC
Complies with the EMC provision of the Radiocommunications Act per the
following standard, in accordance with ACMA:
CISPR 11:2003. Radiated and Conducted Emissions, Group 1, Class A, in
accordance with EN 61326-1:2006 and EN 61326-2-1:2006.
Australia / New Zealand contact.
Baker & McKenzie
Level 27, AMP Centre
50 Bridge Street
Sydney NSW 2000, Australia
8 MSO2000B and DPO2000B Installation and Safety Instructions

Compliance Information
Safety Compliance
EC Declaration of
Conformity – Low Voltage
Compliance was demonstrated to the following specification as listed in the
Official Journal of the European Communities:
Low Voltage Directive 2006/95/EC.
EN 61010-1: 2001. Safety requirements for electrical equipment for
measurement control and laboratory use.
U.S. Nationally Recognized
Testing Laboratory Listing
UL 61010-1:2004, 2nd Edition. Standard for electrical measuring and test
equipment.
Canadian Certification CAN/CSA-C22.2 No. 61010-1:2004. Safety requirements for electrical
equipment for measurement, control, and laboratory use. Part 1.
Additional Compliances IEC 61010-1: 2001. Safety requirements for electrical equipment for
measurement, control, and laboratory use.
Equipment Type Test and measuring equipment.
Safety Class Class1–groundedproduct.
Pollution Degree
Description
A measure of the contaminants that could occur in the environment around
and within a product. Typically the internal environment inside a product is
considered to be the same as the external. Products should be used only in the
environment for which they are rated.
Pollution Degree 1. No pollution or only dry, nonconductive pollution occurs.
Products in this category are generally encapsulated, hermetically sealed, or
located in clean rooms.
Pollution Degree 2. Normally only dry, nonconductive pollution occurs.
Occasionally a temporary conductivity that is caused by condensation must
be expected. This location is a typical office/home environment. Temporary
condensation occurs only when the product is out of service.
Pollution Degree 3. Conductive pollution, or dry, nonconductive pollution
that becomes conductive due to condensation. These are sheltered locations
where neither temperature nor humidity is controlled. The area is protected
from direct sunshine, rain, or direct wind.
Pollution Degree 4. Pollution that generates persistent conductivity through
conductive dust, rain, or snow. Typical outdoor locations.
MSO2000B and DPO2000B Installation and Safety Instructions 9

Compliance Information
Pollution Degree Pollution Degree 2 (as defined in IEC 61010-1). Note: Rated for indoor use only.
Installation (Overvoltage)
Category Descriptions
Terminals on this product may have different installation (overvoltage) category
designations. The installation categories are:
Measurement Category IV. For measurements performed at the source of
low-voltage installation.
Measurement Category III. For measurements performed in the building
installation.
Measurement Category II. For measurements performed on circuits directly
connected to the low-voltage installation.
Measurement Category I. For measurements performed on circuits not
directly connected to MAINS.
Overvoltage Category Overvoltage Category II (as defined in IEC 61010-1)
10 MSO2000B and DPO2000B Installation and Safety Instructions

Compliance Information
Environmental Considerations
This section provides information about the environmental impact of the product.
Product End-of-Life
Handling
Observe the following guidelines when recycling an instrument or component:
Equipment Recycling. Production of this equipment required the extraction and
use of natural resources. The equipment may contain substances that could be
harmful to the environment or human health if improperly handled at the product’s
end of life. In order to avoid release of such substances into the environment and
to reduce the use of natural resources, we encourage you to recycle this product
in an appropriate system that will ensure that most of the materials are reused or
recycled appropriately.
This symbol indicates that this product complies with the applicable European
Union requirements according to Directives 2002/96/EC and 2006/66/EC
on waste electrical and electronic equipment (WEEE) and batteries. For
information about recycling options, check the Support/Service section of the
Tektronix Web site (www.tektronix.com).
MercuryNotification. This product uses an LCD backlight lamp that contains
mercury. Disposal may be regulated due to environmental considerations. Please
contact your local authorities or, within the United States, refer to the E-cycling
Central Web page (www.eiae.org) for disposal or recycling information.
Restriction of Hazardous
Substances
This product has been classified as Monitoring and Control equipment, and is
outside the scope of the 2002/95/EC RoHS Directive.
MSO2000B and DPO2000B Installation and Safety Instructions 11

Operating Requirements
Operating Requirements
This section provides the specifications that you need to know to operate your
product safely and correctly. Refer to the complete product specifications in the
MSO/DPO2000B Technical Reference for additional information.
DPO2000B and MSO2000B
Series Oscilloscopes
Power Supply Input Voltage: 100 V to 240 V ± 10%
Power Supply Input Power Frequency:
50/60 Hz at 100 V to 240 V
400 Hz at 115 V
Power Consumption: 80 W maximum
Input Voltage (between the signal and reference): 300 VRMS CAT II
Installation Category II - for measurements performed on circuits directly
connected to the low-voltage installation
Figure 1: MSO2000B series
Figure 2: DPO2000B series
12 MSO2000B and DPO2000B Installation and Safety Instructions

Operating Requirements
TPP0100 or a TPP0200
Passive Probe Single-ended voltage probe (ground referenced): 300 VRMS CAT II safety requirements
Installation Category II - for measurements performed on circuits directly connected to the
low-voltage installation
Temperature:
Operating: -10 °C to +55 °C (+14 °F to +131 °F)
Nonoperating: -51 °C to +71 °C ( -60 °F to +160 °F)
Pollution Degree: 2, Indoor use only
Humidity: 5% to 95% RH
MSO2000B Series
Oscilloscope with a P6316
Digital Probe Threshold Accuracy: ±(100 mV + 3% of threshold)
Threshold Range: ±20 V
Maximum nondestructive input signal to probe: ±40 V peak
Minimum signal swing: 500 mVpeak-to-peak
Input resistance: 101 k
Input capacitance: 8.0 pF
Temperature:
Operating: 0 °C to +50 °C (+32 °F to +122 °F)
Nonoperating: -20 °C to +60 °C (-4 °F to +140 °F)
Altitude:
Operating: 3,000 m (9,843 ft) maximum
Nonoperating: 12,000 m (39,370 ft) maximum
Pollution Degree: 2, Indoor use only
Humidity:
5% to 95% relative humidity
MSO2000B and DPO2000B Installation and Safety Instructions 13

Operating Requirements
Electrical Ratings
Power Requirements
Power connector
The instrument has the following power requirements:
A single-phase power source with one current-carrying conductor at or near
earth-ground (the neutral conductor).
NOTE. Systems with both current-carrying conductors live with respect to ground
(such as phase-to-phase in multiphase systems) are not recommended as power
sources.
The mains supply frequency must be 50 or 60 Hz.
The mains supply voltage must be in the range from 100 to 240 VAC.
WARNING. To reduce risk of fire and shock, ensure the mains supply voltage
fluctuations do not exceed 10% of the operating voltage range.
Fuses Only the line conductor is fused for over-current protection. The fuse is internal
and not user replaceable. Do not attempt to replace the fuse. If you suspect the
fuse has blown, return the instrument to an authorized service center for repair.
Batteries The instrument does not contain any user-replaceable batteries.
Input Ratings
Table 2: Maximum input voltage
Input Rating
At front-panel BNC connector 300 V RMS, Installation Category II; derate above 4 MHz to 6 V RMS at 200 MHz.
At the P6316 probe input, not at the
instrument input
±40 V peak
14 MSO2000B and DPO2000B Installation and Safety Instructions
