Tele Radio T7-14 User manual

safe smart strong
T7
ED-PN-TX102-EN-v01
Language: English (original)
ENDUSER
INSTRUCTIONS
Transmitters: T7-14, T7-15,
T7-16
























©Tele Radio AB
Datavägen 21
SE-436 32 Askim
Sweden
Phone: [phone]

CHAPTER 1: INTRODUCTION 4
1.1About this document 6
1.2About T7 transmitters 7
CHAPTER 2: SAFETY 8
2.1Warnings & restrictions 8
CHAPTER 3: TECHNICAL DATA 11
3.1Transmitter specifications 11
3.2Radio frequency band 12
CHAPTER 4: PRODUCT GENERAL DESCRIPTION 13
4.1Transmitter front 13
4.2Transmitter back 13
4.3Top LED status indication 14
CHAPTER 5: OPERATION 15
5.1General information 15
5.2Radio mode 16
5.3Radio inactivity timeout (automatic shutdown) 16
5.4Load select mode 16
5.5Functionality test 17
5.6Start the transmitter in discontinuous mode 18
CHAPTER 6: BATTERY 19
6.1Battery precautions 19
6.2Battery information 21
CHAPTER 7: WARRANTY, SERVICE, REPAIRS, AND MAINTENANCE 22
CHAPTER 8: REGULATORY INFORMATION 23
8.1Europe 23
8.2North America 24
8.3AEC 25
ANNEX A: INDEX 26
ED-PN-TX102-EN-v01 3

CHAPTER 1: INTRODUCTION
Thank you for using a Tele Radio AB product
READ ALL INSTRUCTIONS AND WARNINGS CAREFULLY BEFORE OPERATING
THE PRODUCTS.
These Enduser instructions have been published by Tele Radio AB and are not
subject to any guarantees. The Enduser instructions may be withdrawn or revised
by Tele Radio AB at any time and without further notice. Corrections and updates
will be added to the latest version of the manual. Always download the Enduser
instructions from our website, www.tele-radio.com, for the latest available version.
Keep the safety instructions for future reference.
IMPORTANT! These instructions are intended for end users. The instructions can be
printed and handed to end user.
Tele Radio AB remote controls are often built into wider applications. This
documentation is not intended to replace the determination of suitability or
reliability of the product for specific user applications and should not be used for
this purpose. It is the responsibility of any such users or integrators to perform the
appropriate and complete risk analysis, evaluation and testing of the products with
respect to the relevant specific application or use. Tele Radio AB shall not be
responsible or liable for misuse of the information contained herein.
Always refer to the applicable local regulations for installation and safety
requirements relating to cranes, hoists, material handling applications, lifting
equipment, industrial machinery, and/or mobile hydraulic applications using Tele
Radio AB products, e.g.:
lapplicable local and industrial standards and requirements,
lapplicable occupational health and safety regulations,
lapplicable safety rules and procedures for the factory where the equipment is
being used,
luser and safety manuals or instructions of the manufacturer of the
equipment where Tele Radio AB remote control systems are installed.
Tele Radio AB Enduser instructions do not include or address the specific
instructions and safety warnings of the end product manufacturer.
For battery precautions, see "6.1 Battery precautions".
4 ED-PN-TX102-EN-v01

Tele Radio AB products are covered by a warranty against material, construction, or
manufacturing faults. See "Chapter 7: Warranty, service, repairs, and maintenance".
ED-PN-TX102-EN-v01 5

1.1About this document
Before installing or operating the product, read the corresponding documentation
carefully.
Tele Radio AB's product range is composed of transmitters, receivers, and
accessories intended for use together as a system.
These Enduser instructions cover general safety issues, main technical
specifications, standard operating instructions and battery information. Images
shown in this document are for illustrative purposes only.
Please report any error or omission in this document, as well as any improvement
or amendment suggestion to [e-mail].
1.1.1COPYRIGHT
Information in this document is subject to change without notice. No part of this
publication may be reproduced, stored in a retrieval system, or transmitted in any
form or by any means, electronic, photographic, mechanical (including
photocopying), recording or otherwise for any purpose other than the purchaser's
personal use without the written permission of Tele Radio AB.
1.1.2TERM AND SYMBOL DEFINITIONS
The capitalized terms and symbol used herein shall have the following meaning:
lWARNING: indicates a hazardous situation which, if not avoided, could result
in death or serious injury.
lCAUTION: indicates a hazardous situation which, if not avoided, will result in
minor or moderate injury.
lIMPORTANT: is used for information that requires special consideration.
lNOTE: is used to address practices not related to physical injury.
This symbol is used to call attention to safety messages that would be
assigned the signal words "WARNING"or "CAUTION".
6 ED-PN-TX102-EN-v01

1.2About T7 transmitters
Tele Radio AB's remote control systems are suitable for a wide variety of
applications for e.g. stationary or mobile equipments, hydraulic machines,
construction, forestry or agriculture equipments and more. Tele Radio AB's
transmitters and receivers are highly customizable and can be configured to suit
the most wide-ranging application requirements & usage habits.
There are three models available, with three, six and eight buttons.
Number of buttons Article name  Old and alternative names
3T7-16 T00007-16 PN-T7-16
6T7-15 T00007-15 PN-T7-15
8T7-14 T00007-14 PN-T7-14
ED-PN-TX102-EN-v01 7

CHAPTER 2: SAFETY
2.1Warnings & restrictions
Carefully read through the following safety instructions before
proceeding with the installation, configuration, operation, or
maintenance of the product. Failure to follow these warnings could
result in death or serious injury.
This product must not be operated without having read and understood the
Enduser instructions and having received the appropriate training. The purchaser
of this product has been instructed how to handle the system safely. The following
information is intended for use as a complement to applicable local regulations
and standards.
IMPORTANT! Tele Radio AB remote controls are often built into wider
applications. These systems should be equipped with:
• a wired emergency stop where necessary
• a brake
• an audible or visual warning signal
2.1.1OPERATION
This radio system must not be used in areas where there is a risk of
explosion.
Only qualified personnel should be permitted to access the transmitter
and operate the equipment.
The user should:
8 ED-PN-TX102-EN-v01

lAlways follow operating and maintenance instructions as well as all
applicable safety procedures and requirements.
lDo not open the receiver encapsulation unless you are qualified.
lYou must satisfy the age requirements in your country for operating
the equipment.
lIt is strictly prohibited to operate the equipment under the influence
of drugs, alcohol and/or medications.
lAlways test the transmitter stop button before operating it. Press the
stop button then twist and pull it out. This test should be done on
each shift, without a load.
lNever use a transmitter if the stop button is mechanically
damaged.Contact your supervisor or representative for service
immediately.
lNever leave the transmitter unattended.
lAlways switch the transmitter off when not in use. Store in a safe
place.
lKeep a clear view of the work area at all times.
2.1.2MAINTENANCE
Before maintenance intervention on any remote controlled equipments:
• always remove all electrical power from the equipment.
• always follow lockout procedures.
lKeep the safety information for future reference. Always download the
Enduser instructions from our website, www.tele-radio.com, for the latest
available version.
lIf error messages are shown, it is very important to find out what caused
them. Contact your representative for help.
lKeep the product in a clean, dry place.
lDo not try to open the encapsulation.
lAlways contact your representative for service and maintenance work on the
product.
lKeep contacts and antennas clean.
lWipe off dust using a clean, slightly damp cloth.
lNever use cleaning solutions.
ED-PN-TX102-EN-v01 9

lCheck the encapsulation, foils and cable for damages every day. If you use
the product although the encapsulation or foil is damaged, moisture can
cause serious damage to the electronics.
10 ED-PN-TX102-EN-v01

CHAPTER 3: TECHNICAL DATA
3.1Transmitter specifications
 T7-14 T7-15 T7-16
Number of buttons 8 x 1-step
button
6 x 1-step
button
3 x 1-step
button
Power supply 2 x 1.5V AAA / LR03 Alkaline
I/O switch Yes
Radio communication Simplex
Frequency band 2405 – 2480 MHz
Number of channels 16 (channel 11–26)
Radio frequency output
power
EIRP1 < 10dBm (10 mW)
IP code IP65
Operating temperature -20…+55 °C / -4…+130 °F
Dimensions 52 x 83 x 17 mm / 2 x 3.3 x 0.7 in
Weight 70 g / 0.15 lbs
1Equivalent isotropic radiated power
ED-PN-TX102-EN-v01 11

3.2Radio frequency band
For radio systems operating on frequency band 2.4 GHz, the frequency band is
divided into 16 channels (11 to 26). Once the channel has been selected on the
transmitter, the receiver will automatically detect and switch to the same channel.
Channel Frequency (MHz) Channel Frequency (MHz)
11 2405 19 2445
12 2410 20 2450
13 2415 21 2455
14 2420 22 2460
15 2425 23 2465
16 2430 24 2470
17 2435 25 2475
18 2440 26 2480
12 ED-PN-TX102-EN-v01

CHAPTER 4: PRODUCT GENERAL DESCRIPTION
The pictures shown in this chapter are for illustrative purposes only.
4.1Transmitter front
T7-16 T7-15 T7-14
1. LED 1 (red)
2. Top LED (red, green)
3. LED 2 (red)
4. Button 1
5. Button 2
6. Button 3
7. Button 4
8. Button 5
9. Button 6
10. Button 7
11. Button 8
4.2Transmitter back
1. I/O switch
2. Clip
3. Product label
4.2.1I/O SWITCH
The I/O switch on the back of the transmitter interrupts the power supply from the
battery. When in the O/off position, the transmitter cannot be started.
ED-PN-TX102-EN-v01 13

IMPORTANT! When the transmitter is to be transported by air, the I/O switch must
be in the O/off position.
NOTE: The I/O switch should not be used as an on/off button for the transmitter.
4.3Top LED status indication
The top LED is a multicolored LED that lights or flashes green when the battery
capacity is good and red when the battery capacity is poor. When the top LED
lights/flashes red, battery should be changed at the next convenient opportunity
(see ).
14 ED-PN-TX102-EN-v01

CHAPTER 5: OPERATION
5.1General information
5.1.1RECEIVERS WITH LOGIN/LOGOUT1 FUNCTION ACTIVATED
To control a receiver, the transmitter must be registered and logged in to the
receiver. If another transmitter is already logged in to the receiver, it must be
logged out before a different transmitter can be logged in.
If no transmitter is logged in to the receiver, the first registered transmitter to be
started will automatically log in to the receiver. Once a transmitter has been logged
in, it will remain logged in until it is manually logged out.
More than one transmitter can be registered in the receiver, but only one
transmitter can be logged in at a time.
NOTE: For the logout function to work, BOTH the receiver and the transmitter
must have the logout function activated and be set to continuous radio mode.
5.1.2RECEIVERS WI THOUT LOGIN/LOGOUT FUNCTION OR WITH
LOGIN/LOGOUT FUNCTION INACTIVATED
To control a receiver, the transmitter must be registered in the receiver.
If no transmitter is controlling the receiver, the first registered transmitter to be
started will automatically take control of the receiver. Switching the transmitter off
will free the receiver and allow any other registered transmitter that is started to
control the receiver.
More than one transmitter can be registered in the receiver, but only one
transmitter can control the receiver at a time.
5.1.3MULTIPLE TRANSMITTERS REGISTERED IN A SAME
RECEIVER
If more than one transmitter is registered in the same receiver, it is recommended
to select the same frequency channel on all transmitters.
1For more information about login/logout, see the transmitter installation instruction
ED-PN-TX102-EN-v01 15

5.2Radio mode
NOTE: To establish a radio link between the transmitter and the receiver, both
units must be set to the same radio mode.
NOTE: The radio mode cannot be changed from the transmitter. Contact your
representative for assistance.
This transmitter is set to discontinuous radio mode by default. The transmitter
starts transmitting as soon as the batteries are inserted and any transmitter button
is pressed. Radio transmission ends when all transmitter buttons are released.
5.3Radio inactivity timeout (automatic shutdown)
NOTE: Only for continuous radio mode.
NOTE: The inactivity timeout cannot be changed from the transmitter. Contact
your representative for assistance.
Automatic shutdown helps prolong battery capacity by automatically turning the
transmitter off after a preset period of inactivity.
On T7 transmitters, the inactivity timeout is deactivated by default.
5.4Load select mode
NOTE: Only for continuous radio mode.
NOTE: Load select mode cannot be changed from the transmitter. Contact your
representative for assistance.
On T7 transmitters, the Load select mode is deactivated by default (Load select
mode 0).
16 ED-PN-TX102-EN-v01

5.5Functionality test
NOTE: This list is intended for use as a support for the manufacturer of the
equipment where Tele Radio AB remote control systems are installed.
Before operating the radio system, follow the procedure below.
IMPORTANT! This test should be performed at each shift, without a load, and
should include but not be limited to the following steps
lMake sure that the controlled object can not cause any harm in the event of
unexpected movement.
lAlways follow local safety rules and start the equipment according to the
corresponding instructions.
lMake sure that the transmitter can control the receiver by testing all
functions.
lMake sure that the functions respond as expected.
lMake sure that all movements are as planned.
lMake sure the system stops when the batteries are removed from the
transmitter.
ED-PN-TX102-EN-v01 17

5.6Start the transmitter in discontinuous mode
To control a receiver, the transmitter must be registered in the receiver.
If no transmitter is controlling the receiver, the first registered transmitter to be
started will automatically take control of the receiver.
When not in use, transmitters must be stored in a secure storage space.
RISK OF UNINTENDED EQUIPMENT OPERATION. The transmitter will start
transmitting as soon as a button is pressed.
NOTE: Go through the functionality test (see "5.5 Functionality test") before
starting the transmitter.
1. Press a button on the transmitter to start controlling the receiver.
The top LED lights (green when the battery capacity is good, red when the
battery capacity is poor).
NOTE: The radio transmission ends as soon as all buttons are released.
18 ED-PN-TX102-EN-v01

CHAPTER 6: BATTERY
6.1Battery precautions
Carefully read the following safety instructions and warnings before using,
charging or disposing of the batteries.
Batteries contain flammable substances such as lithium or other organic
solvents, which may result in overheating, rupture or combustion. Failure
to read and follow the below instructions may result in fire, personal
injury and damage to property if charged or used improperly.
6.1.1HANDLING AND STORAGE
lRisk of explosion if battery is replaced with a battery of an incorrect
type.
lDo not short-circuit, disassemble, deform or heat batteries.
lNever attempt to charge a visibly damaged or frozen battery.
lDo not use or charge the battery if it appears to be leaking,
deformed or damaged in any way.
lDo not solder directly onto batteries.
lDo not leave the battery in the charger once it is fully charged.
lStore in a cool location. Keep batteries away from direct sunlight,
high temperature, and high humidity.
lImmediately discontinue use of the battery if, while using, charging,
or storing the battery, the battery emits an unusual smell, feels hot,
changes color, changes shape, or appears abnormal in any other way.
lKeep batteries out of reach of small children. Should a child swallow
a battery, consult a physician immediately.
ED-PN-TX102-EN-v01 19

6.1.2DISPOSAL
When discarding batteries, insulate the + and - terminals of batteries with
insulating/ masking tape.
lDo not place multiple batteries in the same plastic bag.
lDo not incinerate or dispose of batteries in fire.
lDo not place used batteries in the household waste. Dispose of used
batteries in accordance with the applicable regulations and legal
requirements.
lBatteries that have been disposed of incorrectly may short circuit,
causing them to become hot, burst or ignite.
20 ED-PN-TX102-EN-v01
