1. INTRODUCTION
TBox20 is a compact monitoring and control device for remote objects with support for
Short Messages (SMS). The device is configurable through internal WEB server interface via
GSM network and RS232 interface. Multiple users can interrogate TBox20 or be notified on
configurable events.
2. TECHNICAL SPECIFICATION
•Power 24V ±10% (for the model TBox20-2401)
•Wireless modem: Quad Band GSM (850/900/1800/1900MHz)
•4 digital inputs (“0” (false) 0 – 1V, “1” (true) 2-24V, terminal blocks)
•2 analog inputs. (0 – 10V max 15V, 0-20mA max 30ma, terminal blocks)
•4 relay outputs (~250V, 7A, terminal blocks)
•Interfaces RS232 (RJ45 connector) and GSM GPRS (antenna MMCX connector)
•Alarm message service via SMS, E-Mail
•Protocols HTTP and SMTP
•Configurable through internal WEB server interface
•Watchdog controller
•Operating temperature range from -20°C to +55°C
•DIN Rail Mounting
3. MECHANICAL INTEGRATION
3.1. PACKAGE CONTENTS
3.1.1. TBox20;
3.1.2. Serial cable PORT1 (one connector – female COM port, another – RJ45);
3.1.3. GSM antenna (MMCX connector);
3.1.4. The CD with Software and User’s Manual.
3.2. DIMENSIONS
The plastic case of TBox20 is light and suitable for fitting with electronic instruments that can
hook to the DIN EN 50022.
When a place for TBox20 is being planned, it should be considered that GSM antenna, which is
supplied in your package, should NOT be placed in metal case. The supplied antenna usually has
2,5 meters length cable, so if you plan to mount TBox20 into a metal case, please mount the
antenna outside the metal case. If cable length of 2,5 meters is not enough, contact our sales
department to order antennas with longer cables.
4

TBox20 user‘s manual
Picture 3.2.1 Picture 3.2.2
3.3. FRONT PANEL
PWR – Power LED turns on when power is applied to Tbox20. It also shows the device’s working
status:
•LED ON;
•LED blink low (0.2s ON, 0.6s OFF) – the device is registered in GSM network;
•LED blink high (0.4s ON, 0.4s OFF) – the device transmits via GSM network.
ERR – Error LED turns on when the device has faulty working conditions.
RX – Indicate the receiving data to the device via serial port.
TX – Indicate the sending data from the device via serial port.
DIN – Indicate the digital input’s voltage “true” level.
ROUT – Indicate the relay output status.
RS232 – Standard serial communication port.
4 digital inputs LED
4 relay outputs state LED
Device
state LED
Serial port connector
2 serial port
state LED
Picture 3.3.1
5

TBox20 user‘s manual
4. CONNECTORS PIN_OUT
4.1. CONNECTORS FRONT UP PIN-OUT
Picture 4.1.1
Pin name Description
AIN 1 -
AIN 1 +
Analog input 1. Input voltage range is from 0 to 10V (max 15V) or input current
range is 0-20mA (max 30mA).
AIN 1 -
AIN 1 +
Analog input 2. Input voltage range is from 0 to 10V (max 15V) or input current
range is 0-20mA (max 30mA).
DIN 1 Digital input 1. This input is optically isolated by two different voltage levels: 0…1V
– false; 2…24V – true.
DIN 2 Digital input 2. This input is optically isolated by two different voltage levels: 0…1V
– false; 2…24V – true.
DIN 3 Digital input 3. This input is optically isolated by two different voltage levels: 0…1V
– false; 2…24V – true.
DIN 4 Digital input 4. This input is optically isolated by two different voltage levels: 0…1V
– false; 2…24V – true.
┴Digital input ground. It is separated from module ground (power supply,
analog input) because digital inputs are optically isolated.
+24V
0V
Device power. Voltage is 24V ±10% DC. Power consumption:
Stand by mode ~50mA@24V, peak up to 300mA@24V. As switched power
regulator is used inside, the smaller the voltage, the bigger the current and
vice versa (power consumption remains about the same)
PE Protection earth.
Table 4.1.1. Connector pin-out
4.2. CONNECTORS FRONT DOWN PIN-OUT
Picture 4.2.1
ROUT 1 NO Relay 1 normally open output.
ROUT 1 CO Relay 1 common output.
ROUT 1 NC Relay 1 normally closed output.
Max load ~250V, 7A.
ROUT 2 NO Relay 2 normally open output.
ROUT 2 CO Relay 2 common output.
ROUT 2 NC Relay 2 normally closed output.
Max load ~250V, 7A.
6

TBox20 user‘s manual
ROUT 3 NO Relay 3 normally open output.
ROUT 3 CO Relay 3 common output.
ROUT 3 NC Relay 3 normally closed output.
Max load ~250V, 7A.
ROUT 4 NO Relay 4 normally open output.
ROUT 4 CO Relay 4 common output.
ROUT 4 NC Relay 4 normally closed output.
Max load ~250V, 7A.
Table 4.2.1. Connector pin-out
4.3. SERIAL PORT (RS232 INTERFACE)
Serial port is used for communication with internal WEB server. Internal WEB server allows to edit
configured data.
Serial port parameters:
•Interface format RS232C
•Logic levels (RS232C levels)
•Speed: 115200 bauds
•Format: 8 bits
•Parity: none
•Stop bits: 1
•Flow control: hardware
Picture 4.3.1. RJ45 connector
The communication connector is an eight way RJ45 PLUG style connector.
RJ45 Pin number Description Direction
1 DSR Output
2 DCD Output
3 DTR Input
4 GND -
5 RXD Input
6 TXD Output
7 CTS Output
8 RTS Input
Table 4.3.1. RS232 Connector pin-out
4.4. SAMPLE ELECTRICAL CONNECTION
7

TBox20 user‘s manual
Picture 4.4.1. Sample scheme
5. INSTALATION AND STARTING
5.1. INSTALLING A SIM CARD
•Remove the cover with screwdriver (see the picture
5.1.1).
•Slide the SIM card holder toward its hinge to unlock it
(see the picture 5.1.2).
•Lift the SIM card holder.
•Remove your SIM card from the package (your SIM
card might be inserted already.)
•Insert the SIM card into the holder so that the notches
align (see the picture 5.1.3).
Picture 5.1.1 •Close the SIM card holder.
•Slide the SIM card holder away from its hinges to lock it
(see the picture 5.1.4).
Picture 5.1.2 Picture 5.1.3 Picture 5.1.4
8

TBox20 user‘s manual
5.2. DIP SWITCH SETTINGS
Dip switch should be set according the picture 5.2.1 for the normal working conditions.
Picture 5.2.1
Switch number OFF ON
1 Serial port works in the normal mode Serial port works in the “AT
Command” mode
2 Normal working conditions Preset factory parameters
3 Normal working conditions Reset GSM module
4 “Watchdog” off “Watchdog” on
Table 5.2.1
5.3. CONNECTION TO PC
5.3.1. Install Tbox20 for windows. To
perform the installation, run the
following programs from your CD or
download folder Tbox20.exe.
5.3.2. Connect PC serial port to the Tbox20
serial port cable PORT1.
5.3.3. After installation you can run the
program by clicking SERVER in
Start/Programs/ Teltonika/Tbox20
directory. To open the program, click the
icon on the taskbar.
5.3.4. Select serial port number to which
Tbox20 is connected.
5.3.5. Write to TCP/IP Port number “5000”.
5.3.6. Click the link http://localhost:5000 and
Internet explorer window will run automatically. There you will see Tbox20
application.
5.3.7. You can find possible port to which is connected TBox20 device by pressing the
button Autodetect. After you need to select detected COM port with record Box.
Sign - (Com2-) – port 2 not exist. Sign + (Com4 Box+) port 4 exists, connected to
TBox20 and currently it is active (+). Record COM1 without sign and “Box” – port
9

TBox20 user‘s manual
exists. If “..” with COM port number, then the port is busy. Maybe it is opened by
another program.
6. DATA CONFIGURATION
Data configuration is executed by the internal WEB server application. You need to connect
Tbox20 to PC and the server program should be run (see section 5.3).
6.1. APPLICATION‘S LOGICAL ELEMENT
System log
Picture 6.1.1
WEB server
Actions RELAY
RS232 GSM connection
Users,
users groups
4 IN
2 AIN
Lo
g
ics
Events
