Tennant T380AMR User manual

T380AMR
(Battery)
Rider-Scrubber
Operator Manual
9020999
Rev. 00 (08-2020)
*9020999*
North America / International
For the latest Parts Manuals and other
language Operator Manuals, visit:
www.tennantco.com/manuals
Hygenic Fully®Cleanable Tanks
TennantTrue®Parts
Insta-Click™ Magnetic Disk R

INTRODUCTION
This manual is furnished with each new model. It provides necessary operation and maintenance instructions.
Read this manual completely and understand
the machine before operating or servicing it.
This machine will provide excellent service. However, the best results will be obtained at minimum costs if:
• The machine is operated with reasonable care.
• The machine is maintained regularly - per the machine maintenance instructions provided.
• The machine is maintained with manufacturer supplied or equivalent parts.
To view, print or download manuals online visit www.tennantco.com/manuals
PROTECT THE ENVIRONMENT
Please dispose of packaging materials, used components such as batteries and
fluids in an environmentally safe way according to local waste disposal regulations.
Always remember to recycle.
Model No. ï
Serial No. ï
Installation Date ï
Please fill out at time of installation for future reference.
MACHINE DATA
Tennant Company
PO Box 1452
Minneapolis, MN 55440
Phone: (800) 553-8033
www.tennantco.com
NOTE: ec-H2O Nanoclean is abbreviated as ec-H2O throughout this manual.
1−Step, Duramer, and Insta-Fit are US registered and unregistered trademarks of Tennant Company
BrainOS®is a US registered trademark of Brain Corp.
Trojan®and HydroLINK®are registered trademarks of Trojan Battery Company.
Specifications and parts are subject to change without notice.
Original Instructions, copyright©2020 TENNANT Company, Printed in U.S.A

INTRODUCTION
This operator manual contains information to allow for quick start−up of the new Tennant T380AMR Scrubber, powered by
BrainOS. This document may be periodically revised. This T380AMR Scrubber, can be used in manual mode or as self−
driving, robotic scrubber. Use in robotic (autonomous) mode requires a subscription to Brain Corp’sAutonomy Services. It
is important to follow all provided instructions and warnings. Failure to adhere to instructions could result in damage to the
machine and injury.
The T380AMR is a commercial floor scrubber powered by BrainOS software. The Brain−enabled scrubber is capable
of functioning in either manual or robotic (autonomous, self−driving) modes. When in robotic mode, the Brain−enabled
scrubber is driven by the BrainOS navigation software. This product may be covered by one or more patents or pending
patent applications. See www.braincorporation.com/patents for details. Discrete portions of this product were made
possible by open source software. Please see www.braincorp.com/open−source−attributions/ for details.
INTENDED USE AND PRECAUTIONS
The T380AMR is an industrial/commercial robotic rider scrubber machine. It is designed exclusively to wet scrub both
rough and smooth hard surfaces (concrete, tile, stone, synthetic, etc). This machine can be operated in either robotic
mode (without operator) or manual mode (with operator). This machine is intended for indoor use only. Do not use this
machine on soil, grass, artificial turf, or carpeted surfaces. This machine is not intended for use on public roadways. Do
not use this machine other than described in this Operator Manual. Only use recommended accessories. The T380AMR
Scrubber, powered by BrainOS, should only be used by trained operators in controlled, restricted environments approved
by Brain Corp/Tennant Company.
Additional training materials may be provided as to the intended use of the T380AMR Scrubber, and it should only be
used in accordance with such training. Use the machine in approved environments in accordance with the Autonomous
Navigation Software End User License Agreement (EULA). Approved environments shall also be limited to cleaning areas
with adequate cellular communication signals permitting cellular data communication with the machine to enable periodic
safety-related updates not less than monthly.
The operator is responsible for the use of each Brain−enabled T380AMR Scrubber in both manual and robotic mode.
Each operator must be mindful to use the machine in accordance with its intended use and precautions at all times.
Operators will not engage in any of the following conduct or activities with respect to the Autonomy Services or BrainOS:
• Transmission of any software or other materials that contain any viruses, worms, trojan horses, defects, spyware,
spiders, screen−scrapers, or other items of a destructive or disruptive nature;
• The machine onboard cameras may capture images of people who happen to be in its surrounding. There may be
local laws of operation relating to use of technology with cameras. Please comply with all applicable laws, including
using signage or obtaining consents as required;
• Exploitation of the Autonomy Services, BrainOS, or the Brain−enabled scrubber hardware in any unauthorized
manner, including by trespassing or burdening server or network capacity or infrastructure;
• Framing, mirroring, or reselling any part of the Autonomy Services or BrainOS without written authorization from Brain
Corp;
• Unauthorized collection of user information; or
• Attempting to deliberately damage the Autonomy Services or BrainOS, or undermine the legitimate operation of the
Autonomy Services or BrainOS.

4T380AMR 9020999 (08-2020)
CONTENTS
CONTENTS
Contents................................................................4
Important Safety Instructions - Save These
Instructions............................................................6
Operation.............................................................11
Machine Components...................................11
Controls And Instruments..............................12
Cameras And Sensors..................................13
Machine Setup..............................................14
Attaching Squeegee Assembly ................14
Installing Brushes/Pads............................15
Attaching Front Perimeter Guard.............15
ec-H2O Nanoclean Water
Conditioning Cartridge (Option)...........16
Filling The Solution Tank..........................16
Operation Of Controls...................................17
Directional Switch.....................................17
Setting Scrub Modes................................17
Setting ec-H2O Button.............................17
Setting Brush Pressure............................18
Setting Solution Flow ...............................18
ec-H2O Solution Flow Setting..................18
Emergency Stop Buttons .........................19
Machine Hour Meter.................................20
ec-H2O System Indicator Light................20
Blue Start/Pause Button...........................20
User Interface (UI) Touchscreen..............21
Battery Discharge Bar..............................21
ROC: Robot Operations Center
(BrainOS Software).............................22
BrainOS Software Updates......................22
How The Machine Works..............................23
Conventional Scrubbing................................23
ec-H2O Scrubbing System (Option) .............23
Brush Information..........................................24
Machine Operation........................................25
Pre-Operation Checklist................................25
While Operating The Machine
(Robotic Mode/Manual Mode)................26
While Operating The Machine
(Robotic Mode Only)...............................26
Scrubbing - Manual Mode.............................27
Double Scrubbing.....................................29
Water Pickup Mode (No Scrubbing).........30
Scrubbing - Robotic Mode ............................31
Establish Home Location Codes..............31
Logging Into BrainOS...............................32
Changing Region/Language ....................33
Positioning The Machine At The
Home Location Code...........................34
Teaching A New Route
(BrainOS Software).............................35
Pairing A Phone With The ROC ...............39
Running A Robotic Cleaning Route
(BrainOS Software).............................40
Autonomous Route History......................46
Learning Center .......................................47
Assist Messages During Robotic
Operation.............................................47
Edit/Deleting Routes ................................48
Draining And Cleaning The Tanks.................51
Alert Messages.............................................53
Alerts - Manual Mode...............................53
Assists - Robotic Mode ............................55
System Errors (Robotic Mode/
Manual Mode) .....................................59
LIDAR Sensor/Camera Errors..................59
Machine Troubleshooting..............................62
ec-H2O System........................................62
Maintenance........................................................63
Maintenance Chart........................................64
Batteries........................................................65
Checking The Electrolyte Level................66
Checking Connections/Cleaning..............66
Charging The Batteries ............................67
Battery Charging Status...........................68
Hydrolink®Battery Watering System
(Trojan®Battery OPTION)...................69
Circuit Breakers And Fuses ..........................70
Circuit Breakers........................................70
Fuses .......................................................70
Electric Motors..............................................70
Cameras And Sensors..................................71
Front And Side 2D And 3D Cameras .......71
Upper And Lower LIDAR Sensors............71
Scrub Brushes And Pads..............................72
Replacing The Brush Or Pad Driver.........72
Replacing The Disk Pad...........................73

5
T380AMR 9020999 (08-2020)
CONTENTS
ec-H2O System.............................................74
ec-H2O Water Conditioning
Cartridge Replacement .......................74
Lubrication ....................................................75
Steering Gear Chain ................................75
Steering U-Joint .......................................75
Squeegee Blades..........................................76
Replacing (Or Rotating) The
Squeegee Blades................................76
Skirts And Seals............................................78
Recovery Tank Seal .................................78
Vacuum Fan Seal.....................................78
Squeegee Seal.........................................79
Perimeter Guards.....................................79
Tires..............................................................80
Pushing, Towing, And Transporting The
Machine..................................................80
Pushing Or Towing The Machine .............80
Transporting The Machine .......................81
Jacking Up The Machine...............................83
Storage Information ......................................84
Freeze Protection.....................................84
ec-H2O Models........................................84
Specifications ......................................................85
General Machine Dimensions/Capabilities...85
General Machine Performance.....................85
Power Type...................................................86
Tires..............................................................86
Conventional Scrubbing................................86
ec−H2O System............................................86

6T380AMR 9020999 (08-2020)
SAFETY
The following precautions are used throughout this
manual as indicated in their descriptions:
WARNING: To warn of hazards or
unsafe practices that could result in
severe personal injury or death.
FOR SAFETY: To identify actions that must be
followed for safe operation of equipment.
The following information signals potentially
dangerous conditions to the operator. Know
when these conditions can exist. Locate all safety
devices on the machine. Report machine damage
or faulty operation immediately.
WARNING: Batteries emit hydrogen
gas. Explosion or fire can result. Keep
sparks and open flame away. Keep
covers open when charging.
WARNING: Flammable materials can
cause an explosion or fire. Do not use
flammable materials in tank(s).
WARNING: Flammable materials or
reactive metals can cause an explosion
or fire. Do not pick up.
WARNING: Spinning brush. Keep hands
away.
WARNING: Magnetic Field Hazard.
Magnetic pad driver/brush can be
harmful to those with pacemakers or
medical implants.
This machine is equipped with technology
that automatically communicates over the
cellular network. This machine is equipped
with BrainOS software that is accessible via
the BrainOS User Interface (UI) Touch Screen.
Avoid operating machine in areas where
other equipment that may be sensitive to
electromagnetic noise is located.
FOR SAFETY:
1. Do not operate machine:
- Unless trained and authorized.
- Unless operator manual is read and
understood.
- Under the influence of alcohol or drugs.
- In Manual Mode: While using a cell phone or
other types of electronic devices.
- Unless mentally and physically capable of
following machine instructions.
- With brake disabled.
- Without filters in place or with clogged filters.
- If it is not in proper operating condition.
- In areas where flammable vapors/liquids or
combustible dusts are present.
- In outdoor areas. This machine is for indoor
use only.
- In areas that are too dark to safely see the
controls or operate the machine.
- In areas with possible falling objects.
- With pads or accessories not supplied or
approved by Tennant. The use of other pads
may impair safety.
2. Before Starting Machine:
- Check machine for fluid leaks.
- Make sure all safety devices are in place
and operate properly.
- Check brakes and steering for proper
operation.
- In Manual Mode: Adjust seat and fasten seat
belt (if equipped).
3. When using machine in manual mode:
- Use only as described in this manual.
- Use brakes to stop machine.
- Reduce speed when turning.
- Go slowly on inclines and slippery surfaces.
- Do not scrub on ramp inclines that exceed
7% / 4° grade or transport (GVWR) on ramp
inclines that exceed 10.5% / 6° grade.
- Drive slowly through doorways and narrow
openings.
- Be cautious of the squeegee near
bystanders and obstacles.
- Keep all parts of body inside operator station
while machine is moving.
- Always be aware of surroundings while
operating machine.
- Use care when reversing machine.
- Keep children and unauthorized persons
away from machine.
- Do not allow machine to be used as a toy.
- Do not carry passengers on any part of the
machine.
- Always follow safety and traffic rules.
- Report machine damage or faulty operation
immediately.
- Follow mixing, handling and disposal
instructions on chemical containers.
- Place proper floor cleaning signage in areas
where the machine is operating and people
are present, in accordance with standard
floor cleaning practices.
- Follow site safety guidelines concerning wet
floors.
IMPORTANT SAFETY INSTRUCTIONS - SAVE THESE INSTRUCTIONS

7
T380AMR 9020999 (08-2020)
SAFETY
4. While machine is operating in robotic mode:
- Use only as described in this manual.
- Remove key from ON/OFF key switch to
prevent unauthorized use without disrupting
robotic route.
- Do not attempt to ride machine.
- Do not grab steering wheel or put hands
or arms through the holes of the steering
wheel. Steering wheel may move rapidly
and unexpectedly while in robotic mode.
- Do not operate machine in environments
requiring fail−safe performance (areas where
machine failure could lead to personal injury
or property damage).
- Guard sudden drops, stairs, escalators,
or moving platforms in area of machine
operation with a physical barrier.
- Do not use ladders, scaffolds, or other
temporary constructed structures in area of
machine operation.
- Only scrub flat, hard surfaces of 0% incline.
- Do not operate machine in low traction
environments (ice, oil, etc...).
- Do not leave electrical cords or low profile
items (anything having a height of less than
10 cm from ground) in area of machine
operation.
- Always operate machine in manual mode
when going into elevators or through
automatic doors. Robotic routes should
never include going into elevators or
through automatic doors.
- Keep children and unauthorized persons
away from machine.
- Do not allow machine to be used as a toy.
- Do not carry passengers on any part of the
machine.
- Always follow safety and traffic rules.
- Report machine damage or faulty operation
immediately.
- Follow mixing, handling and disposal
instructions on chemical containers.
- Place proper floor cleaning signage in areas
where the machine is operating and people
are present, in accordance with standard
floor cleaning practices.
- Follow site safety guidelines concerning wet
floors.
5. Before leaving or servicing machine:
- Stop on level surface.
- Turn off machine and remove key.
6. When servicing machine:
- All work must be done with sufficient lighting
and visibility.
- Keep work area well ventilated.
- Avoid moving parts. Do not wear loose
clothing, jewelry and secure long hair.
- Block machine tires before jacking machine
up.
- Jack machine up at designated locations
only. Support machine with jack stands.
- Use hoist or jack that will support the weight
of the machine.
- Do not push or tow the machine without an
operator in the seat controlling the machine.
- Do not push or tow the machine on inclines
with the brake disabled.
- Do not power spray or hose off machine.
Electrical malfunction may occur. Use damp
cloth.
- Plug the off-board charger into a properly
rated outlet only.
- Do not disconnect the off−board charger’s
DC cord from the machine’s receptacle
when the charger is operating. Arcing may
result. If the charger must be interrupted
during charging cycle, disconnect the AC
power supply cord first.
- Disconnect battery connections before
working on machine.
- Do not pull on battery charger cord to
unplug. Grasp plug at outlet and pull.
- Do not use incompatible battery chargers
as this may damage battery packs and
potentially cause a fire.
- Do not charge frozen batteries.
- Inspect charger cord regularly for damage.
- Avoid contact with battery acid.
- Keep all metal objects off batteries.
- Use a non-conductive battery removal
device.
- Use a hoist and adequate assistance when
lifting batteries.
- Battery installation must be done by trained
personnel.
- Follow site safety guidelines concerning
battery removal.
- All repairs must be performed by trained
personnel.
- Do not modify the machine from its original
design.
- Use Tennant supplied or approved
replacement parts.

8T380AMR 9020999 (08-2020)
SAFETY
When servicing machine (continued)
- Wear personal protective equipment as
needed and where recommended in this
manual.
For Safety: wear hearing protection.
For Safety: wear protective gloves.
For Safety: wear eye protection.
For Safety: wear protective dust mask.
7. When loading/unloading machine onto/off truck
or trailer:
- Use ramp, truck or trailer that will support
the weight of the machine and operator.
- Drain tanks before loading machine.
- Do not drive on a slippery ramp.
- Use caution when operating on a ramp.
- Do not load/unload on ramp inclines that
exceed 15.8% / 9° grade.
- Lower scrub head and squeegee before
tying down machine.
- Turn off machine and remove key.
- Block machine tires.
- Use tie-down straps to secure machine.

9
T380AMR 9020999 (08-2020)
SAFETY
The following safety labels are mounted on the
machine in the locations indicated. Replace
damaged/missing labels.
Flammable
materials
can cause
explosion or
fire.
Do not use
flammable
materials in
tank.
Los materiales
inflamables
pueden
provocar
explosiones
o incendios.
No utilice
materiales
inflamables en
el depósito(s).
Les matières
inflammables
peuvent causer
une explosionou
un incendie.
N’utilisez pas de
matières
inflammables
dans le(s)
réservoir(s).
25815
AVERTISSEMENT AICNETREVDAGNINRAW
27464
Read manual before
operating machine.
Lisez le manuel avant
d’utiliser la machine.
Lea el manual antes de
operar la m
á
quina.
FOR SAFETY
POUR VOTRE SECURITE
PARA SEGURIDAD
WARNING LABEL - Batteries
emit hydrogen gas. Explosion
or fire can result. Keep sparks
and open flame away. Keep
covers open when charging.
WARNING LABEL -
Flammable materials or
reactive metals can cause
explosion or fire. Do not
pick up.
FOR SAFETY LABEL - Read
manual before operating
machine.
Located on front electrical
access panel.
WARNING LABEL - Flammable
materials can cause explosion
or fire. Do not use flammable
materials in tank.
Located on solution tank near
solution tank fill port.
Batteries emit
hydrogen gas.
Explosion or fire can
result.
Keep sparks and
open flame away.
Keep covers open
when charging.
11513
AVERTISSEMENT
WARNING
ADVERTENCIA
Les batteries émettent
de l’hydrogène.
Ce gaz est susceptible
d’exploser ou de
s’enflammer.
Evitez toute étincelle et
toute flamme nue à
proximité des batteries.
Laissez les capots
ouverts pendant la
mise en charge.
Las baterías emiten
hidrógeno gaseoso.
Existe peligro de
incendio o explosión.
Mantenga chispas y
llamas alejadas de
la máquina.
Mantenga las tapas
abiertas durante la
operación de carga.
Located on front electrical
access panel.
Located on front
electrical access
panel.
11535
WARNING
Los materials
inflammables o metales
reactivos pueden
causer explosions o
incendios.
No los recoja.
Les mat
ériaux
inflammables ou les
mé
taux r
éactifs peuvent
causer une explosion
ou un incendie.
Ne les ramassez pas.
AVERTISSEMENT
ADVERTENCIA
Flammable materials
or reactive metals
can cause explosion
or fire.
Do not pick up.

10 T380AMR 9020999 (08-2020)
SAFETY
FOR SAFETY LABEL - Electrical
components, use grounding
strap before opening panel.
Located on controller cover.
32482
1253135
WARNING LABEL - Batteries
emit hydrogen gas. Explosion
or fire can result. Keep sparks
and open flame away. Keep
covers open when charging.
Located on bottom of recovery
tank.
Located on top of
scrub head.
WARNING LABEL -
Spinning brush.
Keep hands away.
WARNING LABEL - Magnetic Field
Hazard. Magnetic pad driver/brush can
be harmful to those with pacemakers
or medical implants.
Located on Insta-Click magnetic pad
driver/brush.

11
T380AMR 9020999 (08-2020)
OPERATION
OPERATION
MACHINE COMPONENTS
A. User Interface (UI) touchscreen
B. Sensor panel
C. Steering wheel
D. Control panel
E. Propel pedal
F. Brake pedal
G. Recovery tank drain hose
H. Solution tank fill cap
I. Solution tank drain hose
J. Solution tank
K. Right perimeter guard
L. Recovery tank
M. Recovery tank cover
N. Flashing light
O. Operator seat
P. Retractable straps (Anti-Joyride)
Q. Battery charging connector
R. Batteries
S. Front perimeter guard
T. Scrub head
U. Squeegee
V. Left perimeter guard
F
R
STU
D
L
Q
A
C
B
G
H
E
I
J
K
M
N
O
P
V

12 T380AMR 9020999 (08-2020)
OPERATION
CONTROLS AND INSTRUMENTS
A. ON/OFF key switch
B. Emergency Stop Button (located on control
panel and back of machine)
C. 1-Step button
D. Horn button
E. Brush pressure button
F. Brush pressure indicator lights
G. Solution flow indicator lights
H. Solution flow button
I. Vacuum fan/squeegee button
J. ec-H2O system indicator light (option)
K. ec-H2O system on/off button (option)
L. Directional switch
M. Blue start/pause button
N. Signal lights (Rear)
O. Flashing light
D
E
FGH
I
J
K
AB
C
L
B
M
N
N
O

13
T380AMR 9020999 (08-2020)
OPERATION
CAMERAS AND SENSORS
A. Sensors - Upper LIDAR
B. Signal lights (Front)
C. Sensors – Front 2D camera
D. Sensors – Front 3D camera
E. Sensors - Side 2D camera (located on
each side of machine)
F. Sensors - Side 3D camera (located on
each side of machine)
G. Sensors - Lower LIDAR
D
EF
A
C
B
B
G

14 T380AMR 9020999 (08-2020)
OPERATION
MACHINE SETUP
ATTACHING SQUEEGEE ASSEMBLY
1. Lower the scrub head.
FOR SAFETY: Before leaving or servicing
machine, stop on level surface, turn off
machine, and remove key.
2. Rotate the squeegee carriage assembly to
the right side of the machine to access the
squeegee carriage.
3. Align the squeegee carriage pins into the
squeegee assembly bracket.
4. Slide the squeegee assembly onto the
squeegee carriage until both squeegee
carriage pins are secured in the bracket.
5. Be sure both squeegee tabs are positioned
above the scrub head skirt.
6. Connect the vacuum hose to the squeegee
assembly.
7. Use the hook-and-loop fastener to secure the
vacuum hose to the squeegee assembly.

15
T380AMR 9020999 (08-2020)
OPERATION
8. Rotate and center the squeegee assembly
underneath the machine.
INSTALLING BRUSHES / PADS
FOR SAFETY: Before leaving or servicing
machine, stop on level surface, turn off
machine, and remove key.
1. Attach the pad to the pad driver before
installing the driver. Secure pad with center
lock.
2. Position the brush under the scrub head and
lift the brush up onto the scrub head until the
magnet in the scrub head secures the brush.
WARNING: Magnetic Field Hazard.
Magnetic pad driver/brush can be
harmful to those with pacemakers or
medical implants.
ATTACHING FRONT PERIMETER GUARD
1. Stop machine on a level surface.
2. Turn the machine ON/OFF key switch off.
FOR SAFETY: Before leaving or servicing
machine, stop on level surface, turn off
machine, and remove key.
3. Place the front perimeter guard underneath the
front of the machine.
4. Install the front perimeter guard onto the front
of the machine.

16 T380AMR 9020999 (08-2020)
OPERATION
ec-H2O NANOCLEAN WATER CONDITIONING
CARTRIDGE (OPTION)
The ec-H2O system is equipped with a water
conditioning cartridge. The cartridge is designed
to protect the machine’s plumbing system from
potential scaling. The cartridge is located under
the recovery tank, near the scrub head actuator.
The cartridge is required to be replaced when it
reaches its maximum water usage or expiration
time of when the cartridge was activated, which
ever comes first.
Depending on machine usage a new cartridge can
last anywhere from 12 to 24 months.
All cartridges are labeled with a manufacture date.
The shelf-life of an un-installed cartridge is one
year from manufacture date. For new cartridge
replacement, the ec-H2O module timer must be
reset. See ec-H2O WATER CONDITIONING
CARTRIDGE REPLACEMENT.
NOTE: During first time use and after replacing the
water conditioning cartridge, the ec-H2O system
will automatically override the selected solution
flow rate for up to 75 minutes.
The ec-H2O system indicator light will blink green/
red when it is time to replace cartridge.
FILLING THE SOLUTION TANK
FOR SAFETY: Before leaving or servicing
machine, stop on level surface, turn off
machine, and remove key.
The machine is equipped with a fill port at the rear
of the machine.
WARNING: Flammable materials can
cause an explosion or fire. Do not use
flammable materials in tank(s).
FOR CONVENTIONAL SCRUBBING: Open
the solution tank fill port and partially fill it with
water (not to exceed 60°C/140°F). Pour the
required amount of detergent into the solution tank
according to mixing instructions on the bottle. Then
continue filling the solution tank with warm water
until the water level is just below the fill port.
FOR SAFETY: When using machine, follow
mixing and handling instructions on chemical
containers.
FOR ec-H2O SCRUBBING: Use cool clean
water only (less than 21°C/70°F). Do not add any
conventional floor cleaning detergents, system
failure may result.
NOTE: When filling the solution tank with a bucket,
make sure that the bucket is clean. Do not use the
same bucket for filling and draining the machine.
NOTE: For Conventional Scrubbing, only use
recommended cleaning detergents. Machine
damage due to improper detergent usage will void
the manufacturer’s warranty.

17
T380AMR 9020999 (08-2020)
OPERATION
OPERATION OF CONTROLS
DIRECTIONAL SWITCH
Press the top of the directional switch to move the
machine forward. The forward arrow light located
at the top of the switch will illuminate when the
machine is placed in the forward direction.
Press the bottom of the directional switch to move
the machine in reverse. The reverse arrow light
located at the bottom of the switch will illuminate
when machine placed in the reverse direction.
SETTING SCRUB MODES
Before scrubbing, select the type of scrubbing
to be used, ec-H2O (option) or conventional
scrubbing. Then set the preferred brush pressure,
and solution flow settings.
NOTE: The machine does not save solution flow
and brush pressure settings for a robotic route, as
cleaning needs may change. Adjust the solution
flow and brush pressure settings before pressing
the blue start/pause button to begin a robotic
route.
SETTING ec-H2O BUTTON
The ec-H2O button enables the ec-H2O system to
come on when the 1-Step button is on. The light in
the button will come on when it is in this mode.
NOTE: The ec-H2O system indicator light will not
turn on until the machine starts scrubbing.
NOTE: ec-H2O Models-During first time use and
after replacing the water conditioning cartridge,
the ec-H2O system will automatically override the
selected solution flow rate for up to 75 minutes.

18 T380AMR 9020999 (08-2020)
OPERATION
SETTING BRUSH PRESSURE
Under normal conditions, the brush pressure
should be set to the minimum setting (the bottom
light). Under heavy grime conditions, the brush
pressure should be set to the maximum setting
(the middle or top lights). Travel speed and floor
conditions will affect scrubbing performance.
With the 1-Step button activated, press the Brush
pressure button to both increase or increase the
brush pressure settings. The brush pressure
indicator lights display the current brush pressure
setting.
SETTING SOLUTION FLOW
Under normal soilage conditions the solution
flow level should be set to the lowest setting (the
bottom light). Under heavy grime conditions, the
solution flow level should be set to a higher setting
(middle or top lights). Travel speed and floor
conditions will affect scrubbing performance.
With the 1-Step button activated, press the
Solution flow button to both increase or decrease
the solution flow. The solution flow indicator lights
display the current solution flow setting.
NOTE: It is recommended that medium or high
solution flow levels be used for uncoated or
unpolished floors (more porous). This applies to
both conventional and ec-H2O scrubbing modes.
NOTE: The machine will operate for a longer time
if the Brush Pressure and Solution Flow settings
are set to lowest setting (bottom lights).
ec-H2O SOLUTION FLOW SETTING
To adjust the solution flow rate when ec-H2O
scrubbing, press the solution flow button located
on the ec-H2O module. One LED= low, two
LED’s=medium, and three LED’s= high. The
ec-H2O module is located under the seat near the
battery compartment.

19
T380AMR 9020999 (08-2020)
OPERATION
EMERGENCY STOP BUTTONS
This machine is equipped with two Emergency
Stop buttons, one on the control panel and one
on the back of the recovery tank cover. Use the
Emergency Stop buttons only in emergency
situations, as solution could be potentially released
from the squeegee vacuum hose and onto the
floor, creating a slipping hazard.
NOTE: These buttons should not be used for
normal stopping, as premature wear to the parking
brake and/or drive system may occur.
Press either Emergency Stop button in an
emergency to halt the machine power.
Immediately after either Emergency Stop button
is pushed the Emergency Stop Button Pressed
screen will appear on the UI touchscreen. Follow
the instructions on the UI touchscreen.
Twist the Emergency Stop button used to stop the
machine clockwise to disengage the emergency
stop function. The Emergency Stop Button
Released screen appears on the UI touchscreen
immediately after the Emergency Stop button is
disengaged. Touch CONFIRM.
If the Emergency Stop button was pressed when
the machine was on a robotic route, press the
blue start/pause button to resume scrubbing in
the robotic mode. As the machine begins robotic
operation, observe scrubbing performance to
ensure that all components are functioning
properly.
If the Emergency Stop button was pressed when
the machine was in the manual mode or when
teaching a new route, press the 1-Step button and
resume operating the machine in the manual mode
or teaching the new route.
NOTE: When teaching the machine, the 1-Step
button must be pressed before beginning to teach
the machine after the Emergency Stop button is
disengaged. The 1-Step button is automatically
turned off when the Emergency Stop button is
engaged and must be turned back on to continue
teaching the machine.

20 T380AMR 9020999 (08-2020)
OPERATION
MACHINE HOUR METER
The hour meter records the number of hours the
machine has been operated. This information is
useful for servicing the machine. The hour meter is
located underneath the operator seat and next to
the circuit breakers.
ec-H2O SYSTEM INDICATOR LIGHT
NOTE: The ec-H2O system indicator light will not
illuminate until the machine starts scrubbing.
ec-H2O SYSTEM
INDICATOR LIGHT
CODE
CONDITION
Solid green Normal operation
Blinking green/red Water conditioning
cartridge expired.
Replace cartridge
Solid or blinking* red Contact Tennant
service representative
If the ec-H2O system indicator light begins to
blink green/red, the water conditioning cartridge
needs to be replaced (See ec-H2O WATER
CONDITIONING CARTRIDGE REPLACEMENT).
*Verify if cleaning detergent was added to solution
tank. If ec-H2O system was operated with cleaning
detergent, drain solution tank, add clear water and
operate the ec-H2O system until the indicator light
code clears.
BLUE START/PAUSE BUTTON
The machine is equipped with a blue start/pause
button on the back that is used to start a robotic
route or pause an in-process robotic route. When
a saved navigation route is selected on the UI
touchscreen, the blue start/pause button flashes.
When pressed to start the route in robotic mode,
the blue start/pause button stops flashing and
remains consistently illuminated during robotic
operation. The blue start/pause button is off when
operating the machine in manual mode.
When a saved navigation route is selected on the
UI touchscreen, press the flashing blue start/pause
button to begin running the route in robotic mode.
If necessary, approach the machine from behind
and press the blue start/pause button again to
pause the in-process robotic route. The machine
stops moving forward and the scrub brush stops
rotating. The vacuum remains on for a short time
to pick up remaining solution and then turns off.
The machine can be driven manually when a
robotic route is paused. This may be necessary
if there is an obstacle that the machine is unable
to maneuver around on its own. The navigation
software will keep track of the current machine
location within the route and allows the route to be
resumed. Press the blue start/pause button again
to resume the robotic route.
