Automatic Floor Scrubber
5540/5560
607508
Rev. 02 (06-01)
Operator and Parts Manual
Manual de Operación y de Piezas
Model:
607506 - 5540
607541 - 5560
TENNANT COMPANY
Commercial Products
12875 RANSOM STREET
HOLLAND MI 49424 U.S.A.
Fregadora Automática
Home
Find...
Go To..

ELECTRICAL DIAGRAMS
DIAGRAMAS ELECTRICAS
Tennant (11–97)
36
DRIVE
MOTOR
Main
Breaker
SOLENOID 1
(Drive Motor)
Vac
&
Drive
Breaker
CHARGER
LUG
24 VOLTS D.C.
(4 X 6 VOLTS)
S EED CONTROL
CIRCUIT BOARD
RIGHT
BRUSH
MOTOR
SOLENOID 2
(Brush Motors)
SOLENOID 3
(Vacuum Motor)
VACUUM
MOTOR
FLASHER
10A 35A 35A 35A
BRUSH
LIGHTS
LEFT
BRUSH
MOTOR
Brush
Breaker
Brush
Breaker
MAIN
VACUUM
5KW
BATTERY
METER
17
13
8
3 4
9
10
11
RED
RED
20
RED
RED
RED
RED 21
23 25
RED
RED
RED
RED
RED
RED
12
RED
BLK
ORG
BLU
WHT
ORG
WHT/ORG
WHT
RED
BLK
4 3
5
2
26
27
14
RED
RED
35
BLK
BRW
BLK
29
27
28
BLK
36
BLU26
BLK
RED24
21
29
+ +
6
7
+1
Diode (+)
Home
Find...
Go To..

ELECTRICAL DIAGRAMS
DIAGRAMAS ELECTRICAS
37
Tennant (11–97)
LADDER
SOLENOID 2
DRIVE
MOTOR
VACUUM
MOTOR
SOLENOID 3
MAIN SWITCH
Main
Breaker
SOLENOID 1
Vac
&
Drive
Breaker
BRUSH
MOTORS
CHARGER
LUG
24 VOLTS D.C.
(4 X 6 VOLTS)
S EED CONTROL
CIRCUIT BOARD
BRUSH SWITCH
VACUUM SWITCH
OTENTIOMETER
RIGHT
BRUSH
BREAKER
LEFT
BRUSH
BREAKER
FLASHER
LIGHTS
BLK
WHT/ORG
35 118
13 17 20
10
RED
21 14
RED
BLK
WHT
BLU
ORG
WHT ORG
24 28
2725
1
10
9
6 RED 6 RED
+
34
35 35
2
5
26
23
VOLTAGE
METER
Home
Find...
Go To..

PARTS LIST
LISTA DE PIEZAS
Tennant 5540/5560 (10–00)
38
REPLACEMENT BRUSHES AND PAD DRIVER GROUP
CEPILLO DEL REEMPLAZO Y GRUPO DEL MANDO DE LA ALMOHADILLA
1
2
6
5
4
3
Home
Find...
Go To..

PARTS LIST
LISTA DE PIEZAS
Tennant 5540/5560 (10–00) 39
REPLACEMENT BRUSHES AND PAD DRIVER GROUP
CEPILLO DEL REEMPLAZO Y GRUPO DEL MANDO DE LA ALMOHADILLA
REF PART # DESCRIPTION QTY.
∇1 240227 BRUSH, POLY SCRUB PK/2 (5540) 2
240234 BRUSH, NYLON GRIT PK/2 (5540) 2
240236 BRUSH, DYNA SCRUB PK/2 (5540) 2
240243 BRUSH, SCRUB/STRIP PK/2 (5540) 2
240230 BRUSH, POLY SCRUB PK/2 (5560) 2
240235 BRUSH, NYLON GRIT PK/2 (5560) 2
240237 BRUSH, DYNA SCRUB PK/2 (5560) 2
240241 BRUSH, SCRUB/STRIP PK/2 (5560) 2
Y2 240238 LUGS, W/ SCREWS (SET OF 3) 6
∇ASSEMBLY / CONJUNTO
YINCLUDED IN ASSEMBLY / INCLUIDO EN EL CONJUNTO
DRECOMMENDED STOCK ITEMS / ARTICULOS RECOMENDADOS ARA
MANTENER EN EXISTENCIA
REF PART # DESCRIPTION QTY.
∇3 240232 DPAD DRIVER ASM 14”(5540) 2
240233 DPAD DRIVER ASM 17”(5560) 2
Y4 240238 LUGS, W/ SCREWS (SET OF 3) 6
Y5 100106 PLATE, PAD DRIVER BASE 2
Y6 100107 DRING, PAD RETAINER SNAP–IN 2
Home
Find...
Go To..

PARTS LIST
LISTA DE PIEZAS
Tennant 5540/5560 (10–00)
40
RECOVERY TANK GROUP
CONJUNTO DESPOSITO RECUPERAR
11
8
13
14 16
17
15
15
16
18
19
21
23
20
24
25
26
28
27
22
31
32
29
30
6
5
3
4
2
1
7
10
14
9
12
30
29
32
Home
Find...
Go To..

PARTS LIST
LISTA DE PIEZAS
Tennant 5540/5560 (10–00) 41
RECOVERY TANK GROUP
CONJUNTO DESPOSITO RECUPERAR
REF PART # DESCRIPTION QTY.
∇100162 ASM STANDPIPE W/NIPPLE 1
Y1 100759 STANDPIPE, RM–NAT 1
Y2 606088 FITTING, 1–1/2”NIPPLE CPVC 1
3 101714 DGASKET, WASTE AIR CHAMBER 1
4 210240 NUT, FLANGED 1–1/2 1
5 180613 DFLOAT, SHUT–OFF 1
6 607511 TANK, RECOVERY TEAL 1
∇7 100102 DASM, CLEAR LID W/STD HOLE 1
Y8 100105 DLID, CLEAR CENTER ONLY 1
Y9 100109 DLID, OUTER RING ONLY 1
10 140826 SCREW, #6X3/4 6
11 606105 DECAL, DO NOT SPRAY 1
12 3701.6 SCREW, #6X3/8 2
13 230513 ASM, CHAIN 1
14 140027 WASHER, 5/16 FLAT 2
15 140015 WASHER, 5/16 SPLITLOCK 2
16 200031488 SCREW, M8X1.25X20 2
∇ASSEMBLY / CONJUNTO
YINCLUDED IN ASSEMBLY / INCLUIDO EN EL CONJUNTO
DRECOMMENDED STOCK ITEMS / ARTICULOS RECOMENDADOS ARA
MANTENER EN EXISTENCIA
REF PART # DESCRIPTION QTY.
17 140960 DCABLE, REC TANK SUPPORT 1
∇603437 ASM, DRAIN HOSE 1
Y18 621324 DPLUG, EXPANSION 1–1/2”DIA 1
Y19 578441 DSTRAP, DRAIN HOSE 1
Y20 630394 DSLEEVE, DRAIN HOSE 1.5”ID 1
Y21 630068 DHOSE, DRAIN 38.1ID X20”1
Y22 607777 CLAMP, HOSE 1 WIRE BLACK 1
23 140353 SCREW, M6X1.0X108 STUD 3
24 0174..10 DSEAT, NEOPRENE MOTOR 1
25 130477 DMOTOR, VAC 5.7 3S 24V 1
190163 DBRUSH, CARBON 2/PK 2
26 130096 TERMINAL, MALE 2
27 140000 WASHER, 1/4 FLAT 3
28 140284 NUT, M6X1.0 NYLOCK 3
29 140052 WASHER, 1/4 EXT 11
30 140000 WASHER, 1/4 FLAT 11
31 230938 DHINGE, REC TANK 1
32 578187000 SCREW, M6X1.0X12 11
Home
Find...
Go To..

PARTS LIST
LISTA DE PIEZAS
Tennant 5540/5560 (06–01)
42
CHASSIS GROUP
CONJUNTO TELAIO
1
3
31 33
32
28
30
27
29
26
23
25
24
22
19
4
31
35
5
6
78
9
10
11
12
20
21
13
14
15 16
17
18
37
38
39
36
40
41
34
2
42
43
44
Home
Find...
Go To..

PARTS LIST
LISTA DE PIEZAS
Tennant 5540/5560 (06–01) 43
CHASSIS GROUP
CONJUNTO TELAIO
REF PART # DESCRIPTION QTY.
1 130367 CABLE, BATTERY 15”BLK X 6 3
2 606991 BATTERY 6V 305AH DUAL TERM 4
130986 BATTERY 6V 250AH 4
3 100707 PLATE, BATTERY SUPPORT 1
∇607982 ASM, COVER SOL. TANK TEAL 1
Y4 607515 COVER, SOL. TANK TEAL 1
Y5 230626 HINGE, COVER 1
Y6 140706 RIVET, POP 1/8 7
7 3701.6 SCREW, #6X3/8 2
8 140032 WASHER, #6 FLAT 2
9 602529 FILTER, SCREEN 1
10 140300 CLAMP, INSULATED 1/2”ID 1
11 140018 WASHER, #10 INT 1
12 578141000 SCREW, M5X10 1
13 230665 BRACKET, CHARGER PLUG 1
14 140018 WASHER, #10 INT 2
15 578141000 SCREW, M5X10 2
16 604556 ASM, CHARGE PLUG WIRE 1
17 140019 WASHER, #6 EXT 2
18 2728.12 SCREW 6–32X3/4 2
19 120567 DECAL, WARNING BATT. DIAGRAM 1
20 600649 DECAL, SOLUTION LEVER CE 1
21 600650 DECAL, SQUEEGEE LEVER CE 1
22 230925 SUPPORT, RECOVERY TANK 1
23 140116 BUSHING, 5/16ID X 7/16OD X .140 1
∇ASSEMBLY / CONJUNTO
YINCLUDED IN ASSEMBLY / INCLUIDO EN EL CONJUNTO
DRECOMMENDED STOCK ITEMS / ARTICULOS RECOMENDADOS ARA
MANTENER EN EXISTENCIA
REF PART # DESCRIPTION QTY.
24 140027 WASHER, 5/16 FLAT 1
25 140015 WASHER, 5/16 LOCK 1
26 578237000 SCREW M8 X 1.25 X 18 1
27 600476 STRAP, PLUG REAR FILL 1
28 621324 PLUG, EXPANSION 1
29 140012 WASHER, 3/16 1
30 140350 SCREW, #10X1/2 1
31 150529 FITTING, 3/4M X 3/4H BARB 2
32 600796 HOSE, DRAIN W/LEVEL INDCTR 1
33 608915 CLAMP, HOSE 2 WIRE 1
34 608110 DECAL, 5540 2
608111 DECAL, 5560 2
35 120192 DECAL, TENNANT LOGO 1
36 230937.BK SHIELD, LIGHT 1
37 578141000 SCREW, M5X10 2
38 140018 WASHER, #10 INT 2
39 130020 LIGHT, SAFETY 19”1
40 605324 GASKET, 1/2”CLOSED CELL 2
41 607513 TANK, SOLUTION TEAL 1
42 130871 CHARGER, 24VDC 25AMP
(FOR 250–305 AMP BATTERIES) 1
601734 CHARGER, 24VDC 36AMP
(FOR 250–335 AMP BATTERIES) 1
43 130390 ASM., WIRE #6 BLK 29”1
44 130391 ASM., WIRE #6 RED 64”1
Home
Find...
Go To..

PARTS LIST
LISTA DE PIEZAS
Tennant 5540/5560 (10–00)
44
CONTROL CONSOLE GROUP
CONJUNTO CONSOLA DE CONTROLES
17
12
2
3
45
6789
10 12
11
13
14
15
16
17
18
19
20
21
23
22
25 24
26
27
28
29
30
34
31
32
33
35
36
37
38
39 40 41 40
45
44
46
15
16 4342
47
Home
Find...
Go To..

PARTS LIST
LISTA DE PIEZAS
Tennant 5540/5560 (10–00) 45
CONTROL CONSOLE GROUP
CONJUNTO CONSOLA DE CONTROLES
REF PART # DESCRIPTION QTY.
1 606020 DMETER, BATTERY VOLTAGE 24V 1
2 130816 DSWITCH, ROCKER SPST 2
3 130764 DSWITCH, ROCKER DPST 240V 1
4 230698.BK PANEL, CONSOLE BLACK 1
5 600648 DECAL, DASH CE 1
6 100057 GASKET, CONSOLE 1
7 606276 PANEL, REAR COVER 1
8 140018 WASHER, #10 INT 2
9 140887 SCREW, 10–24X3/8 2
10 582150 PLUG, ACCESSORY SWITCH 1
11 120619 DECAL, WARNING 1
12 130198 PLUG, PRY OUT .500 OD 1
13 069764626 PLUG, HOLE 012.7 1
14 140519 NUT, 10–24 KEP 4
15 230652 COLLAR, HANDLE 2
16 140859 SCREW, 1/4–20X1/4 SET 2
17 200823 GRIP, HANDLE TUBE 2
18 230491 PIN, SPRING RETURN 1
19 140409 SPRING, ROLL THROTTLE 1
20 230564 BRACKET, SPRING 1
21 140900 SCREW, 10–24X3/4 1
22 130008 WRAP, LOOM .50DX1.25’1
23 600646 HARNESS, HOUSING 1
24 230613 TUBE, HANDLE ADJUSTMENT 1
DRECOMMENDED STOCK ITEMS / ARTICULOS RECOMENDADOS ARA
MANTENER EN EXISTENCIA
REF PART # DESCRIPTION QTY.
25 230649 PIN, HANDLE ADJUSTMENT 2
26 230648 PIN, HANDLE ADJUSTMENT LOCK 2
27 140415 SPRING, LOCK PIN 1
28 140351 SCREW, M12X1.75X70 2
29 140024 WASHER, 1/2 LOCK 2
30 3148.816 WASHER, .875X.515X.06 FLAT 2
31 140885 SCREW, 1/4–20X1/2 2
32 140052 WASHER, 1/4 EXT 2
33 230690 BRACKET, SPEED POT 1
34 140155 BUSHING, .48X.62X2.00 2
35 190802 KIT, POT REPLACEMENT 1
36 140519 NUT, 10–24 KEP 2
37 230688 LEVER ARM, SPEED POT 1
38 230689 LINK, SPEED POT 1
39 140900 SCREW, 10–24X3/4 2
40 140012 WASHER, 3/16 FLAT 4
41 140138 BUSHING, .19X.25X.14 2
42 140510 NUT 1/4–20 HXJM 1
43 140554 SCREW, 1/4–20X3/4 1
44 230687 BRACKET, SPEED POT TUBE 1
45 140899 SCREW, 10–24X1–1/4 1
46 230671 HANDLE, TUBE 1
47 607509 HOUSING, CONTROL TEAL 1
Home
Find...
Go To..

PARTS LIST
LISTA DE PIEZAS
Tennant 5540/5560 (10–00)
46
LEVER GROUP
CONJUNTO DE PALANCAS
1
2
5
6
4
3
5
7
9
810
9
11
12 7
98
10
9
14
17
1516
13 1
18
25
24
23
26
21 22
20
19
1
28
27
21
20
51
20
20
20 21
51
31
27
21
51
20
21
20
51
20
33
35
17
16
15
34
33
17 15
16
36
32
37
38
5
39
40
41
42
41
546 45
4
3
43
44
47
48
49
50 29
30
27
Home
Find...
Go To..

PARTS LIST
LISTA DE PIEZAS
Tennant 5540/5560 (10–00) 47
LEVER GROUP
CONJUNTO DE PALANCAS
REF PART # DESCRIPTION QTY.
1 200816 GRIP, HANDLE 1/4 X 1 X 2 1/4 3
2 230680 HANDLE, VALVE HANDLE 1
3 140202 SCREW, 3/8–16X1 2
4 140017 WASHER, 3/8 SPLITLOCK 2
5 140028 WASHER, 3/8 FLAT 4
6 140136 BUSHING, .38X.50X.28 1
7 140208 SCREW, 1/4–20X1 2
8 140016 WASHER, 1/4 LOCK 2
9 140000 WASHER, 1/4 FLAT 4
10 140134 BUSHING, .25X.38X.27 2
11 230656 LEVER, VALVE 1
12 140510 NUT, 1/4–20 HEXJAM 1
13 230661 PLATE, LOCK CONTROL HOUSING 1
14 602641 BRACKET, DRAIN HOSE HANGER 1
15 140027 WASHER, 5/16 FLAT 4
16 140015 WASHER, 5/16 SPLITLOCK 4
17 578237000 SCREW, M8X1.25X18 8
18 230654 HANDLE, BRUSH PRESSURE 1
19 140144 BUSHING, .38X.50X.50 1
20 140028 WASHER, 3/8 FLAT 9
21 140017 WASHER, 3/8 SPLITLOCK 5
22 2949.7 SCREW, 3/8–16X7/8 1
23 230631 SPACER, SQUEEGEE LIFT 1
24 230659 LATCH, SQUEEGEE HANDLE 1
25 200817 GRIP, HANDLE .095X7/8X1–3/8 1
26 240208 KNOB, HEIGHT ADJUSTMENT 1
REF PART # DESCRIPTION QTY.
27 140201 SCREW, 3/8–16X3/4 3
28 230658 HANDLE, SQUEEGEE LEVER 1
29 140016 WASHER, 1/4 LOCK 1
30 140259 SCREW, 1/4–20X5/8 1
31 140231 SCREW, 3/8–16X1–1/2 1
32 230660 LINK, SQUEEGEE HANDLE 1
33 140103 BEARING, FLANGE 5/8”2
34 140133 BUSHING, SQUEEGEE MNT BRKT 4
35 230750 BRACKET, SQUEEGEE MOUNT 1
36 230297 PLATE, LOCK CONTROL HOUSING 1
37 140515 NUT, 3/8–16 NYLOCK 1
38 230933.BK PANEL, REAR WELDMENT 1
39 140237 SCREW, 1/2–13X1 1
40 140024 WASHER, 1/2 LOCK 1
41 140045 WASHER, .510X1.25X.06 FLAT 2
42 140139 BUSHING, BRUSH LIFT PEDAL 1
43 230775 LATCH, BRUSH LIFT PEDAL 1
44 102560 PAD, NON–SLIP 1.62 SQ. 1
45 140136 BUSHING, .38X.50X.28 (INNER) 1
46 140145 BUSHING, LIFT LATCH (OUTER) 1
47 140423 SPRING, BRUSH PRESSURE 2
48 140525 NUT, 3/8–16 HEX 1
49 230944 BLOCK, VALVE STOP 1
50 230945 STUD, VALVE ADJUSTMENT STOP 1
51 140136 BUSHING, .38X.50X.28 4
Home
Find...
Go To..

PARTS LIST
LISTA DE PIEZAS
Tennant 5540/5560 (10–00)
48
ELECTRICAL PANEL GROUP
CONJUNTO CONSOLA ELÉCTRICO
4
1
2
3
5
6
7
8
765
9
10
11 12 13
14
15
16
14
15
22 21 20
17
18
19
23
14
15
16
24
25 26
Home
Find...
Go To..

PARTS LIST
LISTA DE PIEZAS
Tennant 5540/5560 (10–00) 49
ELECTRICAL PANEL GROUP
CONJUNTO CONSOLA ELÉCTRICO
REF PART # DESCRIPTION QTY.
1 100151 GASKET, TUBE–ADAPTER 1
2 230664 ADAPTER, TUBE 1
3 140424 SPRING, TUBE–ADAPTER 1
4 230939 BRACKET, TUBE WELDMENT 1
5 578237000 SCREW, M8X1.25X18 5
6 140015 WASHER, 5/16 SPLITLOCK 5
7 140027 WASHER, 5/16 FLAT 5
8 230933.BK PANEL, REAR WELDMENT 1
9 130104 BUSHING, SNAP .88ID –BLACK 1
10 140565 SCREW, 4–40X3/8 1
11 130021 DFLASHER, 24VDC 1
12 605905 DSOLENOID, 24 VDC 3
13 606404 DASM, DIODE W/RING TERMINALS 3
DRECOMMENDED STOCK ITEMS / ARTICULOS RECOMENDADOS ARA
MANTENER EN EXISTENCIA
REF PART # DESCRIPTION QTY.
14 140887 SCREW, 10–24X3/8 10
15 140031 WASHER, #10 EXTERNAL 8
16 140012 WASHER, 3/16 FLAT 8
17 100234 COVER, ELECTRICAL PANEL 1
18 600651 DECAL, CIRCUIT BREAKER CE 1
19 140197 SCREW, 10–24X3/8 2
20 230553 BRACKET, CIRCUIT BREAKER 1
21 130755 DBREAKER, CIRCUIT 10A 1
22 130756 DBREAKER, CIRCUIT 35A 3
23 190959 ASM, SPEED CONTROL 1
24 230552 PANEL, ELECTRICAL 1
25 140000 WASHER, 1/4 FLAT 4
26 140284 NUT, M6X1.0 NYLOCK 4
Home
Find...
Go To..
630010
630011
630267
608706

PARTS LIST
LISTA DE PIEZAS
Tennant 5540/5560 (06–01)
50
DRIVE WHEEL GROUP
CONJUNTO RUEDA DE MANDO
1
2
4
8
9
10 1112
14
13
15
16
17
18
20
21
19
22
23 25
26
27
24
29 30
31
32
30
34
33
28
47
45
44
46
48
43
42
39
41
40
38
36
7
37
5
6
28 35
11
3
49
50
51 55
53
52 56
54
53
57
52
58 59
5958 57
60
61
62 61
63
64
65
66
35
53
66
35
28
48
53
61
61
67
Home
Find...
Go To..

PARTS LIST
LISTA DE PIEZAS
Tennant 5540/5560 (06–01) 51
DRIVE WHEEL GROUP
CONJUNTO RUEDA DE MANDO
REF PART # DESCRIPTION QTY.
1 600349 SCREW, 5/16–18 X 2–3/4 2
2 140015 WASHER, 5/16 SPLITLOCK 2
3 140232 SCREW, 3/8–16X1–1/4 1
4 630450 WHEEL, 76 DIA X 22 WD RUBBER 4
5 140027 WASHER, 5/16 FLAT 2
6 140333 WASHER, M10 LOCK 2
7 140276 SCREW, M10 X 1.5 X 16MM 2
8 230932.BK CHASSIS, WELDMENT 1
9 230655 BRACKET, DRIVE MTR TENSION 1
10 140202 SCREW, 3/8–16 X 1 3
11 140017 WASHER, 3/8 LOCK 3
12 140028 WASHER, 3/8 FLAT 3
13 130713 DRESISTOR, 100 WATT .9 OHM 2
14 140519 NUT, 10–24 KEP 8
15 140900 SCREW, 10–24 X 3/4 4
16 140024 WASHER, 1/2 LOCK 2
17 140352 SCREW, M12 X 1.75 X 25 2
18 103002 DCASTER, 4”SWIVEL 2
19 140036 WASHER, 3/8 FLAT 8
20 140333 WASHER, M10 SPLITLOCK 8
21 140285 NUT, HEX M10 X 1.5 8
22 140859 SCREW, 1/4–20 X 1/4 1
23 240071 SPROCKET, DRIVE MOTOR #40–10 1
∇24 130464DMOTOR, DRIVE 24V 1
Y25 140632 KEY, 1/4 X 1”1
Y26 130507 DCAP, CARBON BRUSH 4
Y27 130508 DCARBON BRUSH 4
28 140525 NUT, 3/8–16 HEX 5
29 140232 SCREW, 3/8–16 X 1–1/4 2
30 140233 SCREW, 3/8–16 X 1–3/4 2
31 140525 NUT, 3/8–16 1
32 230796 BRACKET, WHEEL SUPPORT 1
33 140525 NUT, 3/8–16 1
34 103007 WHEEL, 4”X 1”3/8 1
DRECOMMENDED STOCK ITEMS / ARTICULOS RECOMENDADOS ARA
MANTENER EN EXISTENCIA
REF PART # DESCRIPTION QTY.
35 140510 NUT, 1/4–20 HEXJAM 4
36 230941 BRACKET, FRONT LIFT GUIDE 1
37 140015 WASHER, 5/16 2
38 140275 SCREW, M8 X 1.25 X 16 2
39 606426 DKIT, CHAIN & LINK 1
40 140223 SCREW, 5/16–18 X 3/4 6
41 140015 WASHER, 5/16 6
42 240070 SPROCKET, DRIVE WHEEL 1
43 140124 BEARING 2
44 140232 SCREW, 3/8–16 X 1–1/4 2
45 103058 WHEEL, DRIVE 8”SCRUBBER 1
46 230205 SHAFT, DRIVE WHEEL 1
47 140311.BK CLAMP, WHEEL AXLE BLACK 2
48 140017 WASHER, 3/8 SPLITLOCK 4
49 140509 NUT, 1/2–13 HEXJAM 1
50 140137 BUSHING, .50X.62X.53 1
51 600666 SCREW, 1/2–13X1–3/4 1
52 140208 SCREW, 1/4–20X1 5
53 140000 WASHER, 1/4 FLAT 8
54 230554 BOARD, CONNECTION 1
55 140524 NUT, 1/4–20 KEP 2
56 611396 ARM, BRUSH LIFT WELDMENT 1
57 140272 SCREW, M6X1.0X16 2
58 140016 WASHER, 1/4 LOCK 2
59 140003 WASHER, 1/4X1 FENDER 2
60 230940 PIN, LIFT ARM PIVOT 1
61 140045 WASHER, .510X1.25X.06 FLAT 4
62 140139 BUSHING, BRUSH LIFT PEDAL 1
63 140024 WASHER, 1/2 LOCK 1
64 140237 SCREW, 1/2–13X1 1
65 102560 PAD, NON–SLIP 1.62 SQ. 1
66 140016 WASHER, 1/4 LOCK 6
67 140895 SCREW, 10–24X3/4 2
Home
Find...
Go To..

PARTS LIST
LISTA DE PIEZAS
Tennant 5540/5560 (06–01)
52
BRUSH DRIVE AND SOLUTION HOSE GROUP
ACCIONAMIENTO DEL CEPILLO Y GRUPO DE MANGUERA DE SOLUCION
6
15
4
2
3
7
8
9
11
10
12
13
14
20
21
19
18
17
15
16
11
11
11
29
27
27
28
26
25
24
23
22
31
32
33 30
13
12
34
Home
Find...
Go To..

PARTS LIST
LISTA DE PIEZAS
Tennant 5540/5560 (06–01) 53
BRUSH DRIVE AND SOLUTION HOSE GROUP
ACCIONAMIENTO DEL CEPILLO Y GRUPO DE MANGUERA DE SOLUCION
REF PART # DESCRIPTION QTY.
1 100764 COVER, BRUSH MOTOR 2
∇2 130491 DMOTOR, W/GEARBOX 3/4HP IMP 2
Y190970 DCARBON BRUSH 4
Y3 140632 KEY, 1/4 X 1”1
4 130191 TERMINAL, FEMALE 1/4 #10 2
5 130129 TERMINAL, FML DISCNCT RED 2
6 606243 TAPE, DOUBLE STICK 1
7 230691 BRACKET, MOTOR MOUNT 1
8 140618 PIN, ROLL 1/4 X 1–1/2 4
9 130041 WIRE TIE 1
10 606248 HOSE, 3/8ID X 14.5”1
11 140310 CLAMP, HOSE 5/16–7/8 2
12 140017 WASHER, 3/8 SPLITLOCK 8
13 140202 SCREW, 3/8–16 X 1 8
14 230672 PLATE, DRIVE 1
15 140197 SCREW, 10–24 X 3/8 4
16 606249 HOSE, 3/8ID X 8”1
17 230651 CLAMP, BRUSH PLATE 2
∇ASSEMBLY / CONJUNTO
YINCLUDED IN ASSEMBLY / INCLUIDO EN EL CONJUNTO
DRECOMMENDED STOCK ITEMS / ARTICULOS RECOMENDADOS ARA
MANTENER EN EXISTENCIA
REF PART # DESCRIPTION QTY.
18 140417 CLIP, SPRING 2
19 25732 WASHER, 1.25 X .359 X .093 4
20 140015 WASHER, 5/16 SPLITLOCK 2
21 140219 SCREW, 5/16–18 X 1 2
22 140616 PIN, ROLL 3/32DIAX5/8 1
23 230657 ARM, VALVE 1
24 150516 FITTING, 1/4MX3/8H BARB 1
25 150406 FITTING, 1/4MX1/4F ELBOW 90 1
26 180640 FILTER, SCREEN 1
27 140310 CLAMP, HOSE 5/16–7/8 2
28 600350 TUBING, VINYL 1.1 ft
29 150409 FITTING, 1/4MX5/8H ELBOW 90 1
30 210259 VALVE, 3–WAY 5/16 PORTS 1
31 140552 NUT, 10–24 NYLCK 2
32 605394 FITTING, HOSE BARB 1
33 140895 SCREW, 10–24X3/4 2
34 140028 WASHER, 3/8 FLAT 4
Home
Find...
Go To..
