Tennsco BCD18-72 Instruction Manual

GENERAL SAFETY INFORMATION
Some parts may have sharp edges. CARE must be taken when handling various pieces to avoid injury.
For safety, wear a pair of work gloves when assembling or performing any maintenance on products.
LIMITED WARRANTY
Tennsco warrants goods purchased hereunder to be free of defects in materials and workmanship for a period of one (1) year from the date of shipment, hereunder. This warranty shall not apply in
the event goods are damaged as a result of misuse, abuse, neglect, accident, improper application, modication or repair by persons not authorized by Seller, where goods are damaged during
shipment, or where the date stamps on the goods have been defaced, modied or removed. UNLESS CONSIDERED UNENFORCEABLE OR UNLAWFUL UNDER APPLICABLE LAW:
a. ALL IMPLIED WARRANTIES, INCLUDING BUT NOT LIMITED TO WARRANTIES OR MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE HEREBY EXCLUDED:
b. BUYERS REMEDY, IF ANY, FOR ANY DEFECTIVE GOODS SHALL BE LIMITED TO A REFUND BY SELLER OR REPLACEMENT OF THE GOODS AT SELLER’S OPTION, AND SHALL IN NO
EVENT INCLUDE DAMAGES OF ANY KIND, WHETHER INCIDENTAL, CONSEQUENTIAL OR OTHERWISE.
NO GOODS ACCEPTED FOR RETURN WITHOUT PRIOR APPROVAL. Seller shall have the right to inspect any goods claimed to be defective at Buyers place of business or require Buyer to return the
goods to Seller for inspection on Seller’s premises. Transportation charges covering returned goods will be borne by Seller only if such goods are proven to be defective, are covered by this warranty
and are returned within the warranty period stated above.
ASSEMBLY INSTRUCTIONS & PARTS MANUAL
RETAIN INSTRUCTIONS FOR FUTURE REFERENCE
Standard Storage Cabinet with Bookcase
Preassembled Model BCD18-72
Tennsco LLC., Dickson, TN 37056-1888 • [phone]
LOAD CAPACITIES PER SHELF LEVEL
36w x 18d 200 lbs.
UNIT SIZE WEIGHT CAPACITY
EVENLY DISTRIBUTED
PK-2530918

REPLACEMENT PARTS
REF. NO. DESCRIPTION
1 Shelf 1 301
2 Left Door 1 978LD
3 Right Door 1 978RD
4 Locking Handle with Keys 1 944LH
5 Locking Cam* 1 944LC
6 Cotter Pin* 1 CTRPN
7 Locking Bar Set 1 978LB
8 Lock Bar Guide Inserts* 2 944GI
9 Hinge Pin (not shown above) 1 944HP
1. To move the shelf, using your hands apply pressure to the underside of the shelf and tap it off the tabs.
2. Place the shelf at the desired level. Insert the shelf edges into the tabs at the new location. Be sure that the shelf is securely tted
into the tabs at all points of contact.
3. The cabinet must be level in order for the doors to close properly. Levelers may be adjusted by placing the nut driver through the
hole in each end of the sill and adjusting the leveling screw.
Ref.
No. 1
Ref.
No. 2
Ref.
No. 3
NOTE: Additional hardware may be included for replacement purposes.
Tennsco makes every effort to ensure that all units ship complete with all parts and arrive undamaged.
However, should your unit contain missing or damaged parts, please contact your purchase location.
Insert hex head driver
through hole (above) to
adjust leveler (below).
Ref.
No. 4
Ref.
No. 5
Ref.
No. 6
Ref.
No. 7

Ref.
No. 8
*Included in Ref. No. 4, locking handle with keys (Part No. 944LH). May be ordered alone or as part of the full hardware set.
QTY. PART NO.
49B253
