Tennsco CC-30 Instruction Manual

ASSEMBLY INSTRUCTIONS & PARTS MANUAL
Cubby Lockers
RETAIN INSTRUCTIONS FOR FUTURE REFERENCERETAIN INSTRUCTIONS FOR FUTURE REFERENCE
PK-2901018PK-2901018
T ennsco LLC., Dickson, TN 37056-1888 • [phone]
GENERAL SAFETY INFORMATIONGENERAL SAFETY INFORMATION
Some parts may have sharp edges. CARE must be taken when handling various pieces to avoid injury.
For safety, wear a pair of work gloves when assembling or performing any maintenance on units.
LIMITED WARRANTYLIMITED WARRANTY
Tennsco warrants goods purchased hereunder to be free of defects in materials and workmanship for a period of one (1) year from the date of shipment, hereunder. This warranty shall not apply in
the event goods are damaged as a result of misuse, abuse, neglect, accident, improper application, modication or repair by persons not authorized by Seller, where goods are damaged during
shipment, or where the date stamps on the goods have been defaced, modied or removed. UNLESS CONSIDERED UNENFORCEABLE OR UNLAWFUL UNDER APPLICABLE LAW:
a. ALL IMPLIED WARRANTIES, INCLUDING BUT NOT LIMITED TO WARRANTIES OR MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE HEREBY EXCLUDED:
b. BUYERS REMEDY, IF ANY, FOR ANY DEFECTIVE GOODS SHALL BE LIMITED TO A REFUND BY SELLER OR REPLACEMENT OF THE GOODS AT SELLER’S OPTION, AND SHALL IN NO
EVENT INCLUDE DAMAGES OF ANY KIND, WHETHER INCIDENTAL, CONSEQUENTIAL OR OTHERWISE.
NO GOODS ACCEPTED FOR RETURN WITHOUT PRIOR APPROVAL. Seller shall have the right to inspect any goods claimed to be defective at Buyers place of business or require Buyer to return the
goods to Seller for inspection on Seller’s premises. Transportation charges covering returned goods will be borne by Seller only if such goods are proven to be defective, are covered by this warranty
and are returned within the warranty period stated above.
CC-78
CC-52
CC-30

ASSEMBLY OF CUBBY LOCKER
Two people are recommended for assembly. Approximate assembly time: 5-10 minutes.
The reference numbers used throughout this sheet refer to the illustration on the back cover.
This is to help you to identify the various parts as they are mentioned.
1. Shelves are secured to the bottom of the unit for
shipping. They are held in place by two shelf clips which
should be removed to be used later. To remove the
shelves, pull the shelf bundle forward and remove them
from the unit.
2. Remove the shelves (Ref. No. 2) from the cabinet.
The shelves are bundled together with plastic wrap.
They must be separated before installing into the unit.
Shelf clips are located between the wrapped shelves.
NOTE: When recieving a 30” or
40” high cubby, the shelves will
be under the locker body for
shipping purposes.
NOTE: Shelf clips are used upside down for shipping. NOTE: The front of the shelf has an extra bend.
Shelves must be separated.
SHELF CLIP SHELF


SHELF
6. Your cubby locker is now complete!
Shelf clips inserted
into slot of partition.
Shelf cutouts align with clips.

3. Place shelf clips (Ref. No. 1) at the desired shelf locations.
Each shelf uses four shelf clips, two in the front slots
of the partition (Ref. No. 4) and two in the rear slots.
5. To attach the coat hook (Ref. No. 3), place the hook
under the shelf and align with the holes in center of
the shelf. Use the provided nuts (Ref. No. 6) and bolts
(Ref. No 5) to secure the hook to the shelf.
4. Align the shelf so the cutouts on the sides of the shelf
are over the clips. Tap the shelf down in all four corners.
Repeat this step until you have placed all shelves.

REPLACEMENT PARTSREPLACEMENT PARTS
REF. NO. DESCRIPTIONREF. NO. DESCRIPTION
1 Shelf Clip CCC-1 12 24 36 48 60
2 Shelf ECS-1 3 6 9 12 15
3 Double Coat Hook LCH-2 3 3 3 3 3
4 Partition CCLP-xx 2 2 2 2 2
5 #8-32 x 3/8” Bolts AVAILABLE LOCALLY 6 6 6 6 6
6 #8-32 Nuts AVAILABLE LOCALLY 6 6 6 6 6
30” High 40” High 52” High 66” High 78” High30” High 40” High 52” High 66” High 78” High
QTY. QTY. QTY. QTY. QTY.QTY. QTY. QTY. QTY. QTY.
PART NO.PART NO.
NOTE: Additional hardware may be included for replacement purposes.NOTE: Additional hardware may be included for replacement purposes.
Tennsco makes every effort to ensure that all units ship complete with all parts and arrive undamaged.Tennsco makes every effort to ensure that all units ship complete with all parts and arrive undamaged.
However, should your unit contain missing or damaged parts, please contact your purchase location.However, should your unit contain missing or damaged parts, please contact your purchase location.
ShelfShelf
(Ref No. 2)(Ref No. 2)

Shelf ClipShelf Clip
(Ref No. 1)(Ref No. 1)
Double Coat HookDouble Coat Hook
(Ref No. 3)(Ref No. 3)
PartitionPartition
(Ref No. 4)(Ref No. 4)

#8-32 x 3/8” Bolt
(Ref No. 5)(Ref No. 5)
#8-32 Nut
(Ref No. 6)(Ref No. 6)
49B29049B290
