TERMA ROLO User manual

ROLO
Electric radiator
User Manual

2
User Manual
Our products have been designed and manufactured in such a way to
ensure that all quality, funconality and aesthec requirements are met.
We would like to congratulate you on the purchase of this great product
and wish you a pleasant experience with it.

3
Electric radiator
1. Execuon: the radiator is made of powder coated low carbon steel.
It is lled with synthec oil heang agent and equipped with elec-
tronically controlled heang element.
2. Technical data:
Model designaons
(type of power cable)
PW - straight cable with plug (self-installaon permied) or
PB - straight cable without plug (the permanent hard-wired
connecon to the installaon must be performed by a quali-
ed electrician)
Type of electrical connecon: Y; 230V / 50Hz power supply;
Protecon class of the device: Class I;
Towel rail connecon thread: G 1/2";
Casing protecon class [IP]: IPx5:

4
3. Purpose: as a dryer for clothes, as towel warmer, as a room heater
(see secon "SAFETY USAGE RULES").
4. Place of use: rooms with normal air humidity (including bathrooms,
kitchens, if applies), without the inuence of corrosive media.
5. Installaon to the wall - via the aached mounng brackets.
ATTENTION: The design of the radiator and the physical proper-
es of the heang medium cause an uneven temperature distribu-
on inside the radiator - see chapter "NATURAL PERFORMANCE
OF RADIATOR".

5
THE RIGHT MOUNTING
NOTE:
The device marked “PB” (hard-wired connecon) must be installed by
a qualied electrician, locaon in bathroom is allowed.
The device “PW” (cable with plug) can be self-installed, but only loca-
ons in dry areas/rooms are permied.
1. Due to the heat emied, the radiator/towel rail cannot be located
directly under the electric socket, as well as under any other element
not resistant to high temperatures.
2. To protect against dangers for very young children, an electric clothes
or towel dryer should be installed so that the lowest tube is at least
600 mm above the oor.

6
1 m
Zone 1Zone 2
1 m
60 cm
1 m
1 m
60 cm
60 cm
60 cm
1 m
X
X

7
3. All installaons to which the device is connected should comply with
the regulaons applicable in the country of installaon and use.
4. It must be ensured that the circuit in the electrical installaon to
which the radiator is connected has an appropriate overcurrent cir-
cuit breaker and a residual current device (R.C.D.) with a sensivi-
ty of 30 mA. With the permanent (hard-wired) installaon it is also
mandatory to have an omni polar cut-o for disconnecng the de-
vice on all poles, by points of contact with the clearance of 3 mm.
5. The device version labelled PB can be installed in bathrooms, but at
least 1m from any water source, PW version with the plug can be
installed in dry areas only, (as dened by applicable law, subject to
any addional regulaons concerning electrical installaons in wet
areas).
6. Do not use extension cords or adapters for electrical outlets to plug
the product.

8
7. The mounng locaon should provide a close distance to the elec-
trical connecon in order to:
- avoid straining the power cable aer connecng it to the socket,
- reduce the risk of mechanical damage to the cable,
- limit access of unauthorized persons and pets to the device.
8. Ensure that the power cord is not in contact with hot elements of
the radiator.
9. Use the device only for its intended purpose as described in the op-
erang instrucons.
10. Make sure that the heater has been installed on the wall in accord-
ance with the installaon instrucons.
11. This informaon material should be given to the end user of the
heater.

9
ATTENTION!
Failure to meet the above-menoned requirements is a potenal
source of electric shock hazards or it may cause injury or property
damage.
SAFETY USAGE RULES
1. The device is intended for home use.
2. Electric heater is not a toy. Children under the age of 3 should not
be allowed within close proximity of the device without the supervi-
sion of an adult.
3. Children aged 3 to 8 should only be allowed to operate the heater
when it has been properly installed and connected. The child must
be under adult supervision or have been trained to safely operate
the device while understanding the risks.

10
4. Note: Some parts of the radiator can be very hot and can cause
burns. Pay special aenon to the presence of children or people
with disabilies.
5. Check regularly that the device is not damaged and that it is safe to
use.
6. If the power cord has been damaged, the device is unusable. Dis-
connect from the power supply and contact the manufacturer or
distributor.
7. Do not allow the electronic controller housing to ood with any
liquid.
8. Do not open the electrical controller housing, do not interfere with
the interior of the device.
9. Be careful when pung hands between pipes of the radiator.

11
10. When drying fabrics, pay aenon to the temperature acceptable
for them.
CAUTION ! Detergents used for washing can cause permanent dis-
coloraon of radiator paint. Such cases are not subject to complaint.
11. Aer taking dry clothes o the radiator, its surface may be very hot.
Be careful and wait for the temperature to decrease to a safe level.
12. Do not touch the electric device standing barefoot on the oor or
touching other elements of the ngs at the same me, in parcu-
lar - in condions of increased humidity.
13. Do not put loads exceeding 5 kg on the radiator.

12
INSTALLATION DETAILS
1. Immediately remove the packaging aer unpacking the radiator - they are
a source of potenal danger to children.
2. During assembly or disassembly, the device must not be live.
3. Set the radiator to the wall in its planned locaon. Install the radiator in accordance
with the instrucons supplied with the assembly kit.
4. For detailed installaon hints - see the last pages of this manual.
NATURAL PERFORMANCE OF RADIATOR
Because of the circulaon of the heang agent in the radiator, collector that is
directly connected to the heang element will always be the warmest part of the
radiator, especially its upper secon. At the same me the lower parts will always
be cooler. Such phenomenon is absolutely normal and may not be the reason for
claim.

13
heang element
cold hot
There is also the so-called “dead-zone” in the
radiator which is a non-heang secon just above
the heang element that is designed to isolate
the element controller from the heat.
In ght or very high radiators the highest parts
may be colder than the rest of radiator due to
the air cushion in the top part. It may happen
especially a few minutes aer the heang ele-
ment starts working.
For more informaon please see the website of
the manufacturer.

14
MALFUNCTION
IF YOU NOTICE ANY OF THE SYMPTOMS BELOW
1. Heang medium leaking,
2. Deformaon of pipes or collectors,
3. Any other sign of abnormal work
Switch the device o and contact the seller immediately.
ATTENTION! In case of heang uid leak remain extra careful – uid contains
dangerous substances that – in case of contact – may harm skin, eyes or lungs.
MAINTENANCE
Always disconnect the device from electricity before you start cleaning the radi-
ator or heang element. Cleaning of the device by children under the age of 8 is
only permied under proper supervision. Recurrently check level of the heang
medium inside the radiator. Clean the item with a dry or damp cloth with a small

15
amount of detergent without any solvents or abrasive agents. The radiator surface
must not be painted with any paint or varnish.
DISASSEMBLY
1. Before disassembly, turn the heater o, disconnect the power cord from the mains
and make sure that the heater is not hot.
2. Follow the assembly instrucons based on the drawings no. 3 to 5, but in reverse
order.
RECYCLING OF RADIATOR
This marking indicates that this product should not be disposed with other house-
hold wastes and should be disposed separately throughout the EU. To prevent
possible harm to the environment or human health from uncontrolled waste dis-
posal due to the presence of hazardous substances within the product, recycle it
responsibly to promote the sustainable reuse of materials and resources. To return
your used device, please use the return and collecon systems available to you or
contact the retailer where the product was purchased. Thank you for your contri-
buon to environmental protecon.

16
WARRANTY
1. The subject of this warranty is a Terma electric radiator. The product name and
characteriscs are specied on the packaging.
2. By accepng the device on purchase, the Client conrms that the product is of
full value. The Client should immediately inform the Seller of any discovered faults
— otherwise it will be understood that the product was faultless at the me of
purchase.
This refers especially to any faults or damages of the control panel case or the ra-
diator surface.
3. The warranty period is counted from the date of purchase and amounts to:
a. 8 years for the radiator body,
b. 2 years for electrical parts with a heater control module.
4. The proof of purchase (receipt, invoice, etc.) constutes the basis for warranty
claims. Lack of the proof of purchase allows the manufacturer to reject a warran-

17
ty claim.
5. This warranty does not cover any faults that are due to:
- incorrect (not in accordance with the manual) installaon, use or disassembly,
- incorrect use of the heang element (i.e. for any purpose that is not specied by
the Manufacturer as intended for this type of product),
- product being handled by unauthorized persons,
- fault’s or damages caused by the Client aer having purchased and accepted the
product.
6. The Manufacturer is obliged to remove any producon fault within 14 working
days of receipt of the faulty device at the Manufacturer’s premises.
7. Should the repair be impossible, then the manufacturer is obliged to replace the
faulty product with a new, full-value unit of idencal parameters.
8. The aached User Manual is an integral element of the Warranty. Please read it
carefully prior to the installaon and use of the product.

18
MOA BLUE
RGB LED – TIMER, schedule and Bluetooth communi-
caon indicator
On/O buon and TIMER switch
Temperature adjustment and
Bluetooth pairing
Blue LEDs – temperature seng indicators
MOA Blue electric heating element is equipped with a radiator tem-
perature sensor (acve by default!) and an addional room temperature
sensor that can be acvated by a mobile control applicaon.
Turning on the unit for a specied period of me does not mean that it
will receive the same maximum power at all mes. The element when
switched on, works at nominal power level for a short me to reach pro-
grammed temperature and then periodically turns itself on and o, con-
suming just as much energy as is needed to maintain the set tempera-
ture taking into account external condions.
The heang element’s construcon, as well as the physical characteris-
cs of the heang medium, cause the lower radiator tubes (especially
the boom two) to have a lower temperature than the rest of the radia-
tor – this is perfectly normal.
The device is equipped with a thermal fuse, which in emergency situa-
ons protects against exceeding crical temperatures (this fuse may be
damaged at the temperature of 82° C – it refers in parcular to heang
elements installed in radiators connected to a central heang system).
The MOA can be operated using the buons on the housing (see sec-
on Manual Operaon) or via a mobile device – smartphone, tablet (see
secon Remote Control).

19
Manual Operaon
(a mobile operang device with installed control applicaon may, but
does not need to be in the range)
Press briey the key to switch on the heang element.
Use the key to set the required temperature level. It is possible to
set 5 temperature levels that correspond to a temperature range of 30
... 60° C when measuring the internal radiator temperature or a range of
15 ... 30° C when measuring the room temperature.
Each short press of the key increases the temperature seng from
1 to 5, the next press returns the seng to level 1, and so on.
The number of lit up, blue diodes corresponds to the selected temper-
ature level of the device.
TIMER mode
Press and hold the key to acvate the 2 hour TIMER, i.e. to dry a tow-
el or warm up a room. Single RGB LED will turn red.
When the set me elapses, the heang element automacally returns
to the sengs from before the acvaon of the mer funcon. With
the TIMER funcon acve, you can freely modify the operang temper-
ature ( key).
If the heang element was switched o prior to mer start-up, the unit
will switch itself o automacally aer the me elapses.
Press briey the key to stop the mer funcon at any me.
ANTI-FREEZE protecon
When the appliance is not in use (either o or scheduled to be o) but

20
remains connected to the mains and the temperature in the vicinity of
the temperature sensor drops below 6° C, the heang element will au-
tomacally switch itself on to prevent the heang medium inside the ra-
diator from freezing. Acvaon of this funcon is signaled by a ash-
ing middle blue LED.
Remote Control
The MOA Blue has a built-in and connuously acve Bluetooth Low
Energy communicaon module for remote control of the heang ele-
ment, using popular mobile devices – smartphones and tablets, both
with Android (min 4.4) or IOS (min 6.0) operang systems. The heang
element is visible by other Bluetooth devices and appears as MOA Blue
Terma. You may need to enter a default authorizaon code: 123456.
To start the pairing mode in MOA, press and hold for approx. 5 sec.
Pairing mode is indicated by a ashing single, blue RGB LED.
Pairing mode, when activated, lasts 30 seconds.
The blue RGB LED will light up each me an acve exchange of infor-
maon between the heang element and an external control device,
takes place.
TIMER mode
The control applicaon allows the Timer to be set for a period of 1 ... 240
minutes in the full range of temperatures supported by the heang ele-
ment and any temperature measurement method – either internal radi-
ator temperature or external room temperature. Acvaon of the TIMER
funcon is indicated by a red RGB LED.
Automac heang program schedule
The control applicaon allows you to program many dierent 7-day
work schedules and to upload any of the programmed schedules to the
