Tesco HBS07 User manual

COMPONENTS
2 3 4
HBS07 Blender Kit User Guide HBS07 Blender Kit User Guide HBS07 Blender Kit User Guide
thevesseltoavoidsplashingthecontents.
SAFETY GUIDE - PLEASE READ
$After each operation, allow the blender to cool for 3
CAREFULLY
minutesbeforeusingitagain.
Please follow all the safety precautions listed below for safety
$The blade on this blender is sharp. Treat it with care at all
andtoreducetheriskofinjuryorelectricalshock. times and never allow fingers, hair, or clothing to come
$Read all the instructions carefully before using your intocontactwiththeblade.
blenderandkeepthemforfuturereference.
$If you wish to scrape the contents of the bowl with a spatula,
$Unplug the appliance from the mains supply when not in remove the blender first.
use, when removing or attaching accessories, or before
$Do not process food containing hard objects which cannot
cleaninganypartoftheappliance. besafelybrokenupbytheblade.
$Thisapplianceisforoccasionalhouseholduseonly.
$Donotusetheblenderwithhotliquids.
$Donotuseoutdoorsorindampconditions.
$Do not yank or pull the cord as this may damage it and
$Do not immerse the motor unit or the electrical cord or plug eventually cause a risk of electric shock.
inliquids.
$To protect against fire, do not operate the unit in the
$Donotusenearasourceofheatoronanunstablesurface. presence ofexplosive and/orflammablefumes.
$Neverletchildren operate this appliance. Close supervision
$Keep theblender out ofthereach of children.
isnecessarywhenthisapplianceisusednearchildren.
Additional instructions for using the whisk
$Ensure that the power cord does not touch any hot surface
andthatitdoesnotoverhangtheedgeofyourworksurface. $Treat the whisk with care. The wire hoops are fragile - do
$When unplugging the power cord, hold the plug top, not not bendordistortthem.
thepowercord. $If the wire hoops are bent or the whisk becomes
$Do not operate any appliance with a damaged cord or plug unbalanced, stop using the product. An unbalanced whisk is
or after the appliance malfunctions, or is dropped or potentially dangerous and coulddamagethemotor.
damaged in any manner. Return appliance to the nearest $Only use the whisk with liquids, creams, egg whites, etc. If
authorized service facility for examination, repair or you want to cream using butter or solid fats, make sure they
electricalormechanicaladjustment. arevery softbefore starting,orusethe blenderattachment.
$Do not use attachments or accessories which are not $Do notaddsolid ingredients intoamixture whenwhisking.
recommended by the manufacturer. They may cause $Support thejugorbowl.
malfunctionorinjury. Additional instructions for using the chopper
$Do not attempt to replace the power cord on this appliance.
$Exercisecarewhenhandling the blade assembly. The sharp
This should only be carried out by authorised service
edge may cause injury. When inserting or removing the
personnelwithspecialisttools.
blade,holdtheassemblybytheshaft.
$Store the processor away from direct sunlight and out of
$Ensure the lid is securely locked in place before operating
thereachofchildren.
theappliance.
$There are no user serviceable parts in your appliance
$When filling or emptying the processor bowl, switch off the
Unauthorised dismantling or servicing will void the blender and detach it from the lid before opening the lid to
productwarranty. addorremoveingredients.
$Do not use the appliance for any purpose not expressly
$Donotchopmeatwithbonesorfruitswith hardstones.
specifiedinthismanual.
$If the chopper gets clogged, switch off, unplug from the
When operating your blender and attachments: mains and detach the motor from the lid before clearing
Using the blender: theobstruction.
$Make sure the appliance is on a sturdy work surface. Use
$When the blender is not in use make sure that it is safely
bothhandstoholdtheappliance.
unpluggedfromthemainssupply.
$To reduce the risk of injury, never place the cutting blade on
basewithoutfirstputtingthebowlproperlyinplace.
$When using the blender ensure there is adequate room in
NOTE: Never process very hot liquids. This is dangerous.
DANGEROF SCALDING!
PRELIMINARIES yourmains voltage:
$Please read all the instructions in this User Guide with
Unpacking particularreference to thesafety notes.
Unpackyour blender carefully.In the cartonyou should find:
$Clean the blender. Refer to the cleaning notes pn Page 6
$HandBlender Motor for instructions.
$BlenderWand Important Note:
$Whisk
$The maximum time you can run the unit with no load is 15
$WhiskJug seconds.
$Chopper:This consists ofthe Bowl, Lid,Blade assembly.
$The blender is a two speed unit: When using the
$Onewall bracket for housingthe assembled blender. blender at high speed the maximum time you can run the
If any items are missing or damaged return the item to your unit is 1 minute. After each minute of continuous use,
nearest Tesco store for replacement. Please have your receipt switch off and let the motor rest for a further three minutes
withyou when youcall. before continuing.
Retainthe packaging.If you disposeof thepackaging do sowith $Blades are verysharp, handle themwith care.
regardto any recyclingregulations in yourarea.
$Ensure that the blender motor is unplugged from the
Before using your blender for the first time: power outlet before assembling or removing
$Check that the voltage marked on the rating plate matches attachments.
ASSEMBLY AND USE
BLENDER AND WHISK
The blender and the whisk are both hand
held appliances.
To attach the motor:
$Makesurethemotor isunplugged.
$Hold the motor in one hand and the attachment in the
other.
$Push the attachment against the motor and rotate the
motorclockwise to lockthe motor andthe attachment.
$Make sure the attachment is firmly locked to the motor
beforeuse.
$Now plug in the whisk or hand blender and switch
the power on at the mains socket to use the
appliance.
To detach the motor:
$Unplugthe appliance.
$Hold the motor in one hand and the attachment in the
other. Rotate the motor anti-clockwise to separate the
motorand the attachment.
Using the hand blender
Introducethe blender intothe food beforeswitching it onto avoid splashing.
Press and hold down the appropriate button to switch the blender on. Release the button to switch the unit off.
Use the slow speed where possible especially when you commence blending or if you are smoothing out lumps
or reducing food to a puree. The high speed can be used as a finishing touch or when a particularly fine mix is
needed.
NEVER use the blender in a vessel while it is being heated on the stove. NEVER let the base of the blade
housingcome into prolongedcontact with thebody of avessel while blending.
Using the whisk
Youmayuse thesupplied measuring jugto whiskingredients such asegg white,light batters, cream etc. Ifyou
arewhisking egg white,the jug willaccommodate two eggwhites - usea largebowlfor extra amounts.
Press and hold down the appropriate button to switch on. Introduce the whisk into the food before switching it
on to avoid splashing. Use the slow speed where possible -the high speed can be used as a finishing touch.
Releasethe button toswitch the unitoff.
NEVERlet the wiresof the whiskcome into prolongedcontact with thebody ofavessel whileblending.
Theblender is idealfor making purees,cold sauces, mayonnaise,or even formixing drinks.
Blender Motor
Whisk
Blender
Wand
Jug
Chopper
Bracket
WHISK
LOOSEN
TIGHTEN
BLENDER
STEM
MOTOR
Low Speed
High Speed

Tesco Stores Ltd, Delamare Road, Cheshunt, Herts, EN8 9SL
HBS07 Blender Kit User Guide
5
HBS07
Hand Blender
with Attachments
User Guide
HBS07 Blender Kit User Guide
ASSEMBLING AND USING THE CHOPPPER
$Place the chopper bowl on a clean, level and stable
surface.
$Hold the blade assembly by the stem and insert the blade
ontothe spindle.
$Placefood into thechopper bowl.
Remove bones from meat, stones from fruit, etc. and cut the
foodinto small piecesbefore you placethe food intothe bowl.
The max quantity of food you can process at any on tile should
notexceed 200g.
$Attach theLid on thechopper bowl.
$Locate the lid over the blade spindle and align the slots in
thelid with themounting lugs inthe bowl.
$Turnthe lid clockwiseuntil it locksinto position.
$Makesurethe motor isunplugged.
$Insertthe motor into thehole in thechopper lid.
$Hold the motor in one hand and the chopper bowl in the
other.Rotate the motorclockwise to lockit to thechopper.
$Make sure the motor and the chopper lid are firmly locked
inplace before use.
$Nowplug in theappliance and switchthe power on.
$
$
To disassemble the chopper
$Unplugthe appliance.
$Hold the motor in one hand and the chopper in the other.
Rotate the motor anti-clockwise to separate the motor and
theattachment. Rotate thelid anti clockwiseand remove.
$
Useboth hands tooperate!
Operate the processor in short bursts. It may be necessary
with some foods to stop the unit, and re-distribute the food
beforecontinuing.
Removethe blade beforespooning out thefood.
LOCK
Unplugthe appliance afteruse. Wall mounting: Ensure the wall an support the blender and
bracket. Choose a mounting location away from heat and damp
$Disassemblethe appliance into itscomponent parts.
and out of the reach of children. There should be at least
$Wash the blender stem under running water, without the 300mm of freespace above and350mm below thebracket.
useof abrasive cleaneror detergents.
Note: Do not immerse the stem in water because over time the
Draw a horizontal line on the wall and
lubricationon the bearingswill deteriorate.
mark off two vertical lines 51mm
$After finishing cleaning the detachable stem, place it apart.
uprightto drain. Thestem is dishwashersafe. Drill a 6mm hole at each intersection
$Wash the jug, bowl, beater and blade in warm soapy and insert one of the supplied wall
water.The bowl andthe jug arenot dishwasher safe. plugs in each hole. Insert the supplied
$Wipethe motorunit with adamp cloth.Never immerse itin screws through the mounting holes
waterfor cleaning -DANGEROF ELECTRIC SHOCK. and screw the bracket firmly to the
$Dry allcomponents thoroughly. wall.Do NOT overtighten.
Caution:Blades are verysharp, handle withcare. Lead the blender through the opening
$Reassembleall the components. at the front of the bracket and lower
Storage theappliance onto thebracket.
$Store the whisk upside down in the jug and store the jug Form the cable into a loop and lead it
andthe chopper ina dry placeout ofthereach ofchildren. from the top through the slot on the
$Theblender may bestored in acupboard orwallmounted. right of the bracket. Now lower the
pluginto the slot.
CLEANING AND STORAGE
WARRANTY
Your TESCO appliance is covered by a warranty for 12 months UK: Waste electrical products should not be
from the date of purchase. If a fault develops during this period, disposed of with household waste.
please return the unit to your nearest Tesco store together with
theoriginal receiptas proof ofpurchase. Thiswarranty in noway e for
affectsyour consumer rights. details.
SPECIFICATIONS ROI: Produced after 13th August 2005. Waste
Voltage Rating: 220-240V, 50Hz electrical products should not be disposed of with
Power Consumption: 300W household waste. Please recycle where facilities
Net Weight: 1.4 kg exist. Check with your Local Authority or retailer for
recyclingadvice.
Class II construction double insulated. This product must
not be connected to earth.
Separate
disposal facilities exist, for your nearest facilities
see www.recycle-more.co.uk or in-stor
