TESTO 300 Manual

testo 300 - Combustion Analyzer
Short instructions

Register your Testo product at www.testo.com/register and receive a one-year
free warranty extension.
The product registration is valid for 30 days after purchase.
For product registration terms and conditions and participating countries, please
go to www.testo.com/register

Contents
Contents
1About this document ...................................................................................5
2Safety and disposal .....................................................................................5
3Product-specific safety instructions ..........................................................5
4Use ................................................................................................................6
5Product description .....................................................................................7
5.1 Front view...............................................................................................7
5.2 Rear view ...............................................................................................8
5.3 Connections ...........................................................................................8
6Commissioning ............................................................................................9
6.1 Power supply / Battery ...........................................................................9
6.1.1 Charge battery.........................................................................9
6.2 Switch instrument on and off ................................................................10
6.3 Display - user interface.........................................................................11
7Using the product ......................................................................................12
7.1 Overview of main menu ( ).............................................................12
7.2 Overview of measurement types ( ).............................................14
7.3 Overview of options ( ) .................................................................15
7.4 Overview of tests ( ) ......................................................................16
7.5 Get the measurement data in 3 steps ..................................................17
8Technical data ............................................................................................18
8.1 Product-specific approvals ...................................................................19
9Contact and support ..................................................................................19

1 About this document
5
1About this document
•The instruction manual is an integral part of the instrument.
•Keep this documentation to hand so that you can refer to it when necessary.
•Please read this instruction manual through carefully and familiarize yourself
with the product before putting it to use.
•Hand this instruction manual on to any subsequent users of the product.
•Pay attention to the safety instructions and warning advice to prevent injury
and damage to the product.
2Safety and disposal
Take the testo information document into account (accompanies the product).
3Product-specific safety instructions
CAUTION
The condensate may be acidic.
Risk of burns to the hands!
-
Wear acid-resistant safety gloves, glasses and overalls to empty the
condensate.
•Make sure that the condensate has been fully emptied out of the condensate
trap before the measuring instrument is stored for a long time.
•Before disposing of the product, the condensate trap must be emptied and
the condensate in the crude gas tube disposed of in a suitable container.
•When testing a gas pipe, pay attention to the following:
WARNING
Dangerous mixture of gases
Danger of explosion!
-
Make sure there are no leaks between the sampling point and the measuring
instrument.
-
Do not smoke or use naked flames during the measurement.

4Use
6
4Use
The testo 300 is a measuring instrument for flue gas analysis on applications,
such as
•residential, commercial and industrial applications (oil, gas, wood, coal)
•low-temperature and condensing boilers
•boilers, furnaces and gas heaters.
Using the instrument, these systems can be adjusted and checked for
applicable limit values.
The instrument has been verified as a short-term measuring instrument and
should not be used as a safety (alarm) device.
The following tasks can also be performed using the instrument:
•Checking the O2, CO and CO2, NO, NOxvalues in combustion plants to
ensure optimum operation.
•Draft measurement.
•Measuring the gas flow pressure in gas heaters.
•Measuring and optimizing the flow and return temperatures of heating
systems.
•Measuring the CO concentration in the ambient air.
A NOxfilter for the CO sensor can be ordered as a spare part to replace a used
filter.

5 Product description
7
5Product description
5.1 Front view
1
USB interface/
mains connection
4
User interface
2
Gas outlet
5
Condensate container
3
On/Off button
6
Connections

5Product description
8
5.2 Rear view
1
Attachment point for carrying
strap
2
Magnets
5.3 Connections
1
Probe connections for additional
probes
3
Flue gas socket
2 Integrated ambient air probe 4 Differential pressure
measurement connection
There must be no more than one extension lead (0554 1202)
connected between flue gas socket and flue gas probe.

6 Commissioning
9
6Commissioning
6.1 Power supply / Battery
The measuring instrument is supplied with a rechargeable battery.
Fully charge the battery before use.
If plugged in
, the measuring instrument is automatically powered via the
power supply.
Only charge the battery at an ambient temperature of 32 to 95°F.
6.1.1 Charge battery
1
Connect the instrument plug of the power supply to the power supply
socket on the measuring instrument.
2
Connect the power plug of the power supply to an outlet.

The charging process starts. LED in the condensate trap flashes red.

The charging process stops automatically when battery is fully
charged. LED in the condensate trap has a continuous red light.
If the battery has discharged completely, the charging time at room
temperature is approx. 5-6 hrs.

6Commissioning
10
6.2 Switch instrument on and off
Current
status
Action Function
Instrument
off
Press the button for
a long time (> 3 s)
Instrument is turned on.
When the measuring instrument is started for the first time, the setup
wizard guides you through the following setting parameters step by
step:
- Country version (basis of calculations)
- Language
- Wi-Fi
- Date and Time
- Own company address
- E-mail account*
- Product registration
A tutorial can be started after the setup wizard.
The tutorial demonstrates the general operation and the most
important functions of the measuring instrument using examples.
*Note: If you don’t have your Email server information available you
can skip this step.
Instrument
on
Press the button
briefly (< 1 s)
Instrument is turned to standby mode.
The instrument is re-activated when the
button is pressed again.
Instrument
off
Press the button for
a long time (> 1 s)
Selection: [OK] Instrument is turned off
or cancel the instrument being turned off
with [Cancel].
Unsaved readings are lost when the measuring instrument is turned off.

6 Commissioning
11
6.3 Display - user interface
1
Measurement types
2
Status bar
3
Menu
4
Open the
Fuels
selection list
5
Select Customer/measuring site
6
Select reading display type
7
Tests
8
Start measurement
Pause measurement
Stop measurement
9 Options
Further symbols on the user interface (without numbering)
Refresh measurement
One level back
One level back
One level back
Cancel process
Print values

7Using the product
12
Save report
Save and send report
7Using the product
7.1 Overview of main menu ( )
Main menu Description
Customer / Measuring site
Create, edit and delete customer and system
information.
TestsCall up, delete and send measurements that
have been performed (various formats
possible).
Saved reports
Call up and delete measurement report.
Gas path check
For flawless operation of the measuring
instrument, regular tightness testing of
measurement systems (measuring
instrument + flue gas probe) is
recommended.

7 Using the product
13
Main menu Description
Device Settings
Settings
- Country version and language
- Wi-Fi
- Date & Time
- My company address
- Bluetooth®
- Hotspot
- Display brightness
- CO sensor protect
- NO2 addition
- O2 reference
- Alarm limits
Sensor Diagnosis Overview of the sensors installed and their
condition.
Error List
Show error reports
Device information
Information
- Device name
- Serial number
- Last service date
- Free memory
- Operating hours
- Operating hours since last service
- Software version
- Firmware version
- Firmware date
Server information
Information about the available server
E-Mail
Set up e-mail account and the e-mail
account can be displayed.
My Apps
Additional applications
- Alarm clock
- E-Mail
- Gallery
- Browser
- Calendar
- Pocket calculator
- QuickSupport
- File manager

7Using the product
14
Main menu Description
Help
Aids
- Device Registration
- Tutorial
- Setup Wizard
- Help Online
- Testo Website
- Update via USB
7.2 Overview of measurement types ( )
Measurement types
Flue Gas Analysis
Draft
CO Air free
Smoke Number
Differential pressure
Differential temperature
O2Air
Clock Meter
Oil flow calculation
CO Ambient
Pipe Commissioning
Pressure Drop test
Pretest
Flue Gas Analysis
Draft

7 Using the product
15
7.3 Overview of options ( )
Options
Description
Config. measurem. view
Add, delete ( ) measurement parameters,
change measurement views ( ) and units
(click on (Unit).
Zeroing Gas Sensors
Manual sensor zeroing.
Menu is only available for measurements
with gas sensors.

7Using the product
16
7.4 Overview of tests ( )
Tests
Feature
Print values
Print out measuring values via Bluetooth®.
Save Save measuring values, including selected
customers / measuring sites. Saved measuring
values can be retrieved in the main menu.
Finish test
Create, save and send measurement report,
including
- Own company data
- Format and print
- Customer data
- Comments and pictures
- Select measurements
- Signature
Saved reports can be retrieved in the main menu.

7 Using the product
17
7.5 Get the measurement data in 3 steps
1
Turn instrument on:
Press button > 1 s.
2
Insert the connector plug into the flue
gas socket and lock it in place by
turning it slightly clockwise (bayonet
lock).
3
Start measurement, the measuring
values will be displayed.
You will also find further information about your testo 300 combustion
analyzer in the online instruction manual on the Testo website,
www.testo.com, under the product-specific download.

8Technical data
18
8Technical data
Feature Value
Temperature measuring instrument
-40 to +2192°F
Draft measurement
-4.01 to +16.06 inH2O
Pressure measurement
-40.15 to 80.29 inH2O
O2measurement
0 to 21 vol.%
CO measurement
0 to 4000 ppm
Option: CO measurement
(H2-compensated)
0 to 8000 ppm
Option: CO measurement with activated
fresh air dilution/measuring range
extension
0 to 15000 ppm
Option: CO measurement
(H2-compensated) with activated fresh
air dilution/measuring range extension
0 to 30000 ppm
NO measurement
0 to 3000 ppm
Efficiency testing (Eta)
0 to 120%
Flue gas losses
0 to 99.9%
CO2determination (calculation from O2)
Display range 0 to CO2 max.
Ambient CO measurement (internal/flue
gas probe)
0 to 2000 ppm
Ambient CO measurement (external with
CO probe)
0 to 500 ppm
Lifetime O2-sensor up to 72 months, depending on the
load
Lifetime CO-sensor
up to 72 months, depending on the
load
Lifetime NO-sensor
up to 72 months, depending on the
load
General technical data
Feature Value
Storage temperature
-4 to +122°F
Operating temperature
23 to +113°F
Charging temperature
32 to +113°F
Energy storage unit
3.6 V/3.5 Ah
Mains unit
5 V / 1 A
Humidity application range
15 to 90% RH, non-condensing

9 Contact and support
19
Feature Value
Power supply
Energy storage unit, USB mains
unit
Energy storage unit service life
10 hrs
Lifetime energy storage
> 1000 charging cycles
Protection class
IP 40
Memory
1 million measuring values
Display
5.0" touch display,
HD 1280x720 pixels
Weight
Approx. 800 g
Dimensions L: 9.6 in. (including probe
connection)
H: 2.3 in.
W: 3.86 in.
Certification
TÜV-tested according to 1st German
Federal Immission Control Ordinance
(BImSchV) EN 50379, Parts 1-3
8.1 Product-specific approvals
As declared in the certificate of conformity, this product complies with Directive
2014/30/EU.
The testo 300 with O2/CO, H2-compensated/NO gas sensors, combustion air
temperature sensor, flue gas temperature sensor and differential pressure
sensor (draught) is TÜV-tested in accordance with VDI 4206.
The CO sensor, H2-compensated, is TÜV-tested in accordance with EN 50379
part 2.
The CO sensor, not H2-compensated, is TÜV-tested in accordance with EN
50379 part 3.
For official measurements in accordance with the first German Federal
Immission Control Ordinance (BImSchV) (chimney sweeps), the measuring
instrument must be checked every six months by a technical testing body of the
Guild of Master Chimney Sweeps or another testing body recognised by the
authorities.
Please find the current country approvals in the attached Approval and
Certification document.
9Contact and support
If you have any questions or need further information, please contact your
dealer or Testo Customer Service. For contact details, please visit
www.testo.com/service-contact.

Testo Inc.
40 White Lake Road
Sparta, NJ 07801
USA
Phone: [phone]
Fax: [phone]
E-mail: [e-mail]
www.testo.com
0971 3010 en-US 02
