Texas Instruments TPA6138A2 EVM User manual

User's Guide
SLOU305A–November 2010–Revised January 2011
TPA6138A2 EVM
Contents
1 Introduction .................................................................................................................. 1
2 Operation ..................................................................................................................... 3
3 Reference .................................................................................................................... 4
4 TPA6138A2EVM Bill of Materials ......................................................................................... 6
List of Figures
1 TPA6138EVM Top View ................................................................................................... 1
2 TPA6138EVM Bottom View ............................................................................................... 2
3 Top Layer .................................................................................................................... 5
4 Bottom Layer ................................................................................................................ 5
List of Tables
1 TPA6138A2EVM Bill of Materials......................................................................................... 6
1 Introduction
This section provides an overview of the Texas Instruments (TI) TPA6138A2 DirectPath™ stereo
headphone amplifier evaluation module (EVM). It includes a brief description of the module and a list of
EVM specifications.
Figure 1. TPA6138EVM Top View
DirectPath is a trademark of Texas Instruments.
1
SLOU305A–November 2010–Revised January 2011 TPA6138A2 EVM
Submit Documentation Feedback © 2010–2011, Texas Instruments Incorporated

Introduction www.ti.com
Figure 2. TPA6138EVM Bottom View
1.1 Description
The TPA6138A2 is a DirectPath™ stereo headphone amplifier capable of delivering 25 mW/Ch into 32 Ω
and requires no output DC blocking capacitors.
The TPA6138A2 EVM is a complete, stand-alone audio board. It contains the TPA6138A2 TSSOP
DirectPath™ stereo headphone amplifier.
1.2 EVM Specifications
Supply voltage range, VDD 3 V to 3.6 V
Supply current, IDD 0.5 A, maximum
Continuous output power, PO, VDD = 3.3 V, 32 Ω, THD+N < 1 % 20 mW
2TPA6138A2 EVM SLOU305A–November 2010–Revised January 2011
Submit Documentation Feedback
© 2010–2011, Texas Instruments Incorporated

www.ti.com Operation
2 Operation
This section describes how to operate the TPA6138A2EVM.
2.1 Quick-Start List for Stand-Alone Operation
Use the following steps when operating the TPA6138A2EVM stand alone or when connecting the EVM
into an existing circuit.
2.1.1 Power and Ground
1. Verify that the external power sources are set to OFF.
2. Set the power supply voltage between 3 V and 3.6 V. When connecting the power supply to the EVM,
first connect the ground connection to the GND connector, and then connect the positive supply to the
VDD connector. Verify that the connections are made to the correct banana jacks.
2.1.2 Inputs and Outputs
2.1.2.1 Audio
1. Verify that the audio source is set to the minimum level.
2. Connect the audio source to the inputs, LIN and RIN. Shunt JP1 and JP2 for single-ended input.
3. Connect a headset or other load to the headphone jack.
2.1.2.2 Shutdown Controls
1. Shutdown is controlled by pushbutton S1. Press and hold S1 to place the TPA6138A2 in shutdown.
Release S1 to reactivate the TPA6138A2.
2.1.3 Power Up
1. Verify the correct connections as described in the Power and Ground and Inputs and Outputs sections.
2. Verify the correct voltage setting of the power supply and turn ON the power supply. Proper operation
of the EVM should begin.
3. Adjust the audio signal source as needed.
3
SLOU305A–November 2010–Revised January 2011 TPA6138A2 EVM
Submit Documentation Feedback © 2010–2011, Texas Instruments Incorporated

15.0K
0603
R6
GND
1.0ufd/16V 0603
C18
GND
10K
0603
R12
2.20K 0603
R13
22.0K
0603
R14
GND
GND
0.5in 0.5in 0.5in 0.5in
180pfd/50V 0805
C7
1
2
J1
GND
GND
S1
GND
R3
0603
100K 100K
0603
R2
GND
100K
0603
R5 R4
0603
100K
R7
0603
15.0K 15.0K
0603
R9
43.0K
0603
R16 R17
0603
43.0K
R15
0603
30.0K
C17
0603 1.0ufd/16V
GND
+3.3V
GND
GND
10
0603
R22
C19
0603 1000pfd/50V
GND
R23
0603
10
1000pfd/50V 0603
C20
GND
GND
43.0K
0603
R18
R11
0603
15.0K
180pfd/50V 0805
C8
C2
0603 0.1ufd/10V
+3.3V
+3.3V
3.3V
0805
Green
R1
0603
392
UVP
Red
GND
0.1ufd/10V 0603
C14
1234567
89
1011121314
U1
TSSOP14-PW
TPA6138A2PW
R21
0603
10K
+3.3V
C13
0603
100pfd/50V GND
MUTE
Orange
30.0K
0603
R20
43.0K
0603
R19
47pfd/50V 0603
C12
1
2
JP3
GND
47pfd/50V 0603
C9
30.0K 0603
R8
GND GND
C10
0603 47pfd/50V
R10
0603 30.0K
GND GND
47pfd/50V 0603
C11
1
2
JP1
GND
JP2 2
1
RIN
RCA (Red)
1
2
3
LIN 3
2
1
RCA (Black)
10ufd/6.3V 0805 C1 1.0ufd/16V
0603
C15
Orange
HPL
HPOUT
3.5mm (Lime Green)
Left
Right
Shield
3
5
2 4
1
HPR
Orange
Black
GND
GND
GND
2.2ufd/50V
C3
VSA
+
VSA
C4
2.2ufd/50V
+
2.2ufd/50V
C5
VSA
+
VSA
C6
2.2ufd/50V
+
HEADPHONE
OUTPUT
DUAL FOOTPRINT PADS
C0603 CERAMIC/SMD-VSA ELECTROLYTIC
MUTE HEAD PHONE
STANDOFFS
HEADPHONE
IN
POWER SUPPLY IN DO NOT POPULATE
Reference www.ti.com
3 Reference
This section includes the EVM schematic, board layout reference, and parts list.
3.1 TPA6138A2EVM Schematic
4TPA6138A2 EVM SLOU305A–November 2010–Revised January 2011
Submit Documentation Feedback
© 2010–2011, Texas Instruments Incorporated

www.ti.com Reference
3.2 TPA6138A2EVM PCB Layers
Figure 3. Top Layer
Figure 4. Bottom Layer
5
SLOU305A–November 2010–Revised January 2011 TPA6138A2 EVM
Submit Documentation Feedback © 2010–2011, Texas Instruments Incorporated

TPA6138A2EVM Bill of Materials www.ti.com
4 TPA6138A2EVM Bill of Materials
Table 1. TPA6138A2EVM Bill of Materials
Qty. Manfacturer Part No. Ref Des Description Manufacturer
1 TPA6138A2PW U1 DIRECTPATH 2V AUDIO LINE DRIVER W/ADJ GAIN TEXAS INSTRUMENTS
TSSOP14-PW ROHS
1 SML-LXT0805GW-TR 3.3V LED, GREEN 2.0V SMD0805 ROHS LUMEX OPTO
4 GRM1885C1H470JA01D C9, C10, C11, C12 CAP SMD0603 CERM 47PFD 50V 5% COG ROHS MURATA
1 GRM1885C1H101JA01D C13 CAP SMD0603 CERM 100PFD 50V 5% COG ROHS MURATA
2 CC0805JRNP09BN181 C7, C8 CAP SMD0805 CERM 180PFD 50V 5% NPO ROHS YAGEO
2 C1608C0G1H102J C19, C20 CAP SMD0603 CERM 1000PFD 50V 5% COG ROHS TDK CORP.
1 C0603C104K8RACTU C2 CAP SMD0603 CERM 0.1UFD 10V 5% X7R ROHS KEMET
4 C1608X7R1C105K C15, C17, C18 CAP SMD0603 CERM 1.0UFD 16V 10% X7R ROHS TDK
4 EEE-1HS2R2SR C3, C4, C5, C6 CAP ALUM-ELECT SMD-VSA 2.2UFD 50V 20% ROHS PANASONIC
1 08056C106KAT2A C1 CAP SMD0805 CERM 10UFD 6.3V X7R 10% ROHS AVX
2 RC0603JR-0710RL R22, R23 RESISTOR SMD0603 THICK FILM 10 OHMS 5% 1/10W ROHS YAGEO
1 ERJ-3EKF3920V R1 RESISTOR SMD0603 392 OHM 1% THICK FILM 1/10W ROHS PANASONIC
1 ERJ-3GEYJ103V R21 RESISTOR SMD0603 10K 5% 1/10W ROHS PANASONIC
4 RMCF0603FT15K0 R6, R7, R9, R11 RESISTOR SMD0603 15.0K OHMS 1% 1/10W ROHS STACKPOLE ELECTRONICS
4 RC0603FR-0743KL R16, R17, R18, R19 RESISTOR SDM0603 20.0K OHM 1% THICK FILM 1/16W YAGEO
ROHS
4 RC0603FR-0730KL R8, R10, R15, R20 RESISTOR SMD0603 THICK FILM 30.0K 1% 1/10W ROHS YAGEO
4 RMCF0603JT100K R2, R3, R4, R5 RESISTOR SMD0603 100K OHMS 5% 1/10W ROHS STACKPOLE ELECTRONICS
4 PBC02SAAN J1, JP1, JP2, JP3 HEADER THRU MALE 2 PIN 100LS GOLD ROHS SULLINS
1 PJRAN1X1U01X LIN JACK, RCA 3-PIN PCB-RA BLACK ROHS SWITCHCRAFT
1 PJRAN1X1U03X RIN JACK, RCA 3-PIN PCB-RA RED ROHS SWITCHCRAFT
1 STX-3150-5N-577C HPOUT JACK MINI STEREO 3.5mm LIME GREEN W/SHUNTS ROHS KYCON
1 5000 UVP PC TESTPOINT, RED, ROHS KEYSTONE ELECTRONICS
1 5001 GND PC TESTPOINT BLACK ROHS KEYSTONE ELECTRONICS
3 5003 HPL, HPR, MUTE PC TESTPOINT ORANGE ROHS KEYSTONE ELECTRONICS
1 TL1015AF160QG S1 SWITCH, MOM, 160G SMT 4X3MM ROHS E-SWITCH
3 SPC02SYAN JP1, JP2, JP3 SHUNT, BLACK AU FLASH 0.100LS SULLINS
4 PMS 440 0025 PH NA 4-40 SCREW, STEEL 0.250 IN BUILDING FASTENERS
4 2027 NA STANDOF ,4-40 0.5IN 3/16IN DIA ALUM RND F-F KEYSTONE ELECTRONICS
6TPA6138A2 EVM SLOU305A–November 2010–Revised January 2011
Submit Documentation Feedback
© 2010–2011, Texas Instruments Incorporated

Evaluation Board/Kit Important Notice
Texas Instruments (TI) provides the enclosed product(s) under the following conditions:
This evaluation board/kit is intended for use for ENGINEERING DEVELOPMENT, DEMONSTRATION, OR EVALUATION
PURPOSES ONLY and is not considered by TI to be a finished end-product fit for general consumer use. Persons handling the
product(s) must have electronics training and observe good engineering practice standards. As such, the goods being provided are
not intended to be complete in terms of required design-, marketing-, and/or manufacturing-related protective considerations,
including product safety and environmental measures typically found in end products that incorporate such semiconductor
components or circuit boards. This evaluation board/kit does not fall within the scope of the European Union directives regarding
electromagnetic compatibility, restricted substances (RoHS), recycling (WEEE), FCC, CE or UL, and therefore may not meet the
technical requirements of these directives or other related directives.
Should this evaluation board/kit not meet the specifications indicated in the User’s Guide, the board/kit may be returned within 30
days from the date of delivery for a full refund. THE FOREGOING WARRANTY IS THE EXCLUSIVE WARRANTY MADE BY
SELLER TO BUYER AND IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED, IMPLIED, OR STATUTORY, INCLUDING
ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR ANY PARTICULAR PURPOSE.
The user assumes all responsibility and liability for proper and safe handling of the goods. Further, the user indemnifies TI from all
claims arising from the handling or use of the goods. Due to the open construction of the product, it is the user’s responsibility to
take any and all appropriate precautions with regard to electrostatic discharge.
EXCEPT TO THE EXTENT OF THE INDEMNITY SET FORTH ABOVE, NEITHER PARTY SHALL BE LIABLE TO THE OTHER
FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES.
TI currently deals with a variety of customers for products, and therefore our arrangement with the user is not exclusive.
TI assumes no liability for applications assistance, customer product design, software performance, or infringement of
patents or services described herein.
Please read the User’s Guide and, specifically, the Warnings and Restrictions notice in the User’s Guide prior to handling the
product. This notice contains important safety information about temperatures and voltages. For additional information on TI’s
environmental and/or safety programs, please contact the TI application engineer or visit www.ti.com/esh.
No license is granted under any patent right or other intellectual property right of TI covering or relating to any machine, process, or
combination in which such TI products or services might be or are used.
FCC Warning
This evaluation board/kit is intended for use for ENGINEERING DEVELOPMENT, DEMONSTRATION, OR EVALUATION
PURPOSES ONLY and is not considered by TI to be a finished end-product fit for general consumer use. It generates, uses, and
can radiate radio frequency energy and has not been tested for compliance with the limits of computing devices pursuant to part 15
of FCC rules, which are designed to provide reasonable protection against radio frequency interference. Operation of this
equipment in other environments may cause interference with radio communications, in which case the user at his own expense
will be required to take whatever measures may be required to correct this interference.
EVM Warnings and Restrictions
It is important to operate this EVM within the input voltage range of 0 V to 3 V and the output voltage range of 0 V to 3.3 V .
Exceeding the specified input range may cause unexpected operation and/or irreversible damage to the EVM. If there are
questions concerning the input range, please contact a TI field representative prior to connecting the input power.
Applying loads outside of the specified output range may result in unintended operation and/or possible permanent damage to the
EVM. Please consult the EVM User's Guide prior to connecting any load to the EVM output. If there is uncertainty as to the load
specification, please contact a TI field representative.
During normal operation, some circuit components may have case temperatures greater than 85°C. The EVM is designed to
operate properly with certain components above 85°C as long as the input and output ranges are maintained. These components
include but are not limited to linear regulators, switching transistors, pass transistors, and current sense resistors. These types of
devices can be identified using the EVM schematic located in the EVM User's Guide. When placing measurement probes near
these devices during operation, please be aware that these devices may be very warm to the touch.
Mailing Address: Texas Instruments, Post Office Box 655303, Dallas, Texas 75265
Copyright © 2011, Texas Instruments Incorporated

IMPORTANT NOTICE
Texas Instruments Incorporated and its subsidiaries (TI) reserve the right to make corrections, modifications, enhancements, improvements,
and other changes to its products and services at any time and to discontinue any product or service without notice. Customers should
obtain the latest relevant information before placing orders and should verify that such information is current and complete. All products are
sold subject to TI’s terms and conditions of sale supplied at the time of order acknowledgment.
TI warrants performance of its hardware products to the specifications applicable at the time of sale in accordance with TI’s standard
warranty. Testing and other quality control techniques are used to the extent TI deems necessary to support this warranty. Except where
mandated by government requirements, testing of all parameters of each product is not necessarily performed.
TI assumes no liability for applications assistance or customer product design. Customers are responsible for their products and
applications using TI components. To minimize the risks associated with customer products and applications, customers should provide
adequate design and operating safeguards.
TI does not warrant or represent that any license, either express or implied, is granted under any TI patent right, copyright, mask work right,
or other TI intellectual property right relating to any combination, machine, or process in which TI products or services are used. Information
published by TI regarding third-party products or services does not constitute a license from TI to use such products or services or a
warranty or endorsement thereof. Use of such information may require a license from a third party under the patents or other intellectual
property of the third party, or a license from TI under the patents or other intellectual property of TI.
Reproduction of TI information in TI data books or data sheets is permissible only if reproduction is without alteration and is accompanied
by all associated warranties, conditions, limitations, and notices. Reproduction of this information with alteration is an unfair and deceptive
business practice. TI is not responsible or liable for such altered documentation. Information of third parties may be subject to additional
restrictions.
Resale of TI products or services with statements different from or beyond the parameters stated by TI for that product or service voids all
express and any implied warranties for the associated TI product or service and is an unfair and deceptive business practice. TI is not
responsible or liable for any such statements.
TI products are not authorized for use in safety-critical applications (such as life support) where a failure of the TI product would reasonably
be expected to cause severe personal injury or death, unless officers of the parties have executed an agreement specifically governing
such use. Buyers represent that they have all necessary expertise in the safety and regulatory ramifications of their applications, and
acknowledge and agree that they are solely responsible for all legal, regulatory and safety-related requirements concerning their products
and any use of TI products in such safety-critical applications, notwithstanding any applications-related information or support that may be
provided by TI. Further, Buyers must fully indemnify TI and its representatives against any damages arising out of the use of TI products in
such safety-critical applications.
TI products are neither designed nor intended for use in military/aerospace applications or environments unless the TI products are
specifically designated by TI as military-grade or "enhanced plastic." Only products designated by TI as military-grade meet military
specifications. Buyers acknowledge and agree that any such use of TI products which TI has not designated as military-grade is solely at
the Buyer's risk, and that they are solely responsible for compliance with all legal and regulatory requirements in connection with such use.
TI products are neither designed nor intended for use in automotive applications or environments unless the specific TI products are
designated by TI as compliant with ISO/TS 16949 requirements. Buyers acknowledge and agree that, if they use any non-designated
products in automotive applications, TI will not be responsible for any failure to meet such requirements.
Following are URLs where you can obtain information on other Texas Instruments products and application solutions:
Products Applications
Audio www.ti.com/audio Communications and Telecom www.ti.com/communications
Amplifiers amplifier.ti.com Computers and Peripherals www.ti.com/computers
Data Converters dataconverter.ti.com Consumer Electronics www.ti.com/consumer-apps
DLP® Products www.dlp.com Energy and Lighting www.ti.com/energy
DSP dsp.ti.com Industrial www.ti.com/industrial
Clocks and Timers www.ti.com/clocks Medical www.ti.com/medical
Interface interface.ti.com Security www.ti.com/security
Logic logic.ti.com Space, Avionics and Defense www.ti.com/space-avionics-defense
Power Mgmt power.ti.com Transportation and www.ti.com/automotive
Automotive
Microcontrollers microcontroller.ti.com Video and Imaging www.ti.com/video
RFID www.ti-rfid.com Wireless www.ti.com/wireless-apps
RF/IF and ZigBee® Solutions www.ti.com/lprfTI E2E Community Home Page e2e.ti.com
Mailing Address: Texas Instruments, Post Office Box 655303, Dallas, Texas 75265
Copyright © 2011, Texas Instruments Incorporated
